V
ax Careline 0870 606 1248
3
assembly / attachments / operation / storage
WARNING: Always
switch off and unplug
the vacuum cleaner from the
electrical outlet before
assembling, opening or
emptying the dirt container,
or before connecting/
disconnecting the attachments.
NOTE: When rewinding the power cord, guide the cord
with one hand, This will prevent the cord from whipping
which could cause damage or injury.
NOTE: For convenience there is a parking slot located at
the rear of the vacuum cleaner where the floor tool and
hose can be parked for carrying and storage.
!
CLICK!
NOTE: Fully unwind the
power cord. A yellow mark on
the power cord indicates the
recommended cord length.
Do not exceed the cord
length beyond the red mark.
12
1
2
12
1
6
1
5
15
2. Assembling your vacuum cleaner
3. Choose the attachments for the job:
4. Operating the appliance
5. Packing away and storage
IMPORTANT: Always unplug the vacuum from the electrical
outlet and rewind the power cord as directed before storing.
!
14
13 18
12 12 12 16
www.vax.co.uk
4
dirt bag / filters
6. Dirt Bag: Maintenance
Removing the paper dirt bag
Replacing the paper dirt bag
7. The Filters: Maintenance
IMPORTANT : Always switch off and unplug the vacuum cleaner from the electrical outlet before removing the Dirt
Container.
!
IMPORTANT : Do NOT use the
vacuum without ALL of the
filters in place.
Vax recommends that the pre- motor
filter should be checked and cleaned
periodically depending on the
frequency of use and the volume of
dirt being picked up on each
occasion.
NOTE : The Pre- motor Filter can be
rinsed in warm water (max 40°C).
Allow to air dry for 24 hours before
replacing. Do NOT use any
detergents or boiling water to wash
the filter.
IMPORTANT: Your vax vacuum cleaner is fitted with high performance filters it is essential that these
are well maintained and cleaned according to the following instructions.
!
DISPOSE
!
