Vax C91-P2 SERIES, C90-P2 SERIES, Power2 C90-P2 Series Instruction Manual
1
2
7 6
5
1
2
5
6
3
4
5
11
1. Parts Overview
The Unit
1 On/Off Button
Insert the plug into the electrical outlet. Press the
on/off switch on the top of the vacuum cleaner, to
switch the vacuum cleaner on and press the button
again to turn the vacuum cleaner off.
2 Post-motor filter cover
3 Plug
4 Floor tool parking slot
For convenience there is a parking slot located at the
rear of the vacuum cleaner where the Floor Tool can
be parked for carrying and storage.
5 Pre-motor filter
Located inside the dirt bin.
6 Dirt container
7 Hose inlet
8 Carry handle
Located on the top of the unit, used to move the
vacuum cleaner from room to room.
9 Auto-Cord rewind
To rewind the power cord, press the cord rewind
button, located on the top of the vacuum cleaner
10 Variable power
Power can be increased or reduced for greater
suction control
11 Dirt bin quick release button
Hold the dirt container over a bin and press the
release button.
12 Dirt Container Carry Handle
Use the carry handle located on the front of the dirt
bin to carry the dirt container.
Retain this guide for future reference.
powerpower
22
Bagless cylinder
Vax model number: C91-P2 & C90-P2 SERIES
instruction manual
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
vax.co.uk
8
9
10
What is your vax’s model number?
C 9 P 2
--
What is your vax’s serial number?
(on the base of your cleaner)
-----
Note this down in case you need it in future
C91-P2 & C90-P2 Series User Guide.qxd:C91-P2 Series User Guide 29/1/10 14:44 Page 1
vax.co.uk
To replace or purchase parts for your vacuum
cleaner, please visit our website:
vax.co.uk
If your Vacuum Cleaner or Accessories are Damaged/Faulty
Please Call our Vax Careline on: 0844 412 8455
!
Your Filters:
2
parts overview
Replacement filter kits are available at vax.co.uk
KEEP YOUR VAX LIKE NEW!
14
1
5
1
6
18
1
9
13
25
26
24
The Accessories
13 Hose
14 Dusting brush
For delicate surfaces.
15 Crevice tool
For crevices, corners and cracks
16 Upholstery tool
For carpet, upholstery and stairs etc.
17 TurboTool
(Some models only)
Perfect for picking up pet hair
18 Combination floor tool (Some models only)
For carpet and rug cleaning: Press the rocker switch
on the Combination floor tool to raise the brushes.
For hard floor cleaning: Press the rocker switch on the
Combination floor tool to lower the brushes.
19 Telescopic extension tube
The telescopic tube can be lengthened or shorted by
pushing the button in and sliding the tube apart or
together as required. The small tools can be stored on
the telescopic tube.
20 TurboTool connector
(Some models only)
IMPORTANT: The connector must be added to
the hose handle before the TurboTool may be
attached.
21 Stretch Hose
(Some models only)
For full height stair cleaning.
NOTE: This should not be used as the main hose.
The stretch hose is recommended to be used for stair
cleaning. The unit should always be positioned at the
bottom of the stairs
22 Hard Floor Tool (Some models only)
For parquet and laminate flooring.
23 Turbo Brush
(Some models only)
NOTE: Not recommended for hard floors.
F
or large carpeted areas.
24 HEPA pre-motor filter
25 Pre-motor filter mesh shroud
26 Foam post-motor
(Some models only)
anti-bacterial filter (Some models only)
IMPORTANT: The condition of the filters affects
the performance of your vacuum cleaner. Please
check and wash filters periodically (depending on level
of use). For full cleaning instructions see page 4-5.
IMPORTANT: Do not use the vacuum cleaner
without all the filters in place.
!
!17!
20
23
2
1
2
2
PLEASE NOTE: some parts may vary according to model. Please check inside flap of box for more details.
C91-P2 & C90-P2 Series User Guide.qxd:C91-P2 Series User Guide 29/1/10 14:44 Page 2
WARNING: Always switch off and unplug the vacuum cleaner from the electrical outlet before assembling, opening
or emptying the dirt container, or before connecting/ disconnecting the attachments.
!
3
assembly / attachments / operation / storage
NOTE: Fully unwind the
power cord. A yellow mark on
the power cord indicates the
recommended cord length.
Do not exceed the cord
length beyond the red mark.
NOTE: When rewinding the power cord, guide the cord
with one hand, This will prevent the cord from whipping
which could cause damage or injury.
NOTE: For convenience there is a parking slot located at
the rear of the vacuum cleaner where the floor tool and
hose can be parked for carrying and storage.
CLICK!
1
9
1
9
1
8
2. Assembling your vacuum cleaner
3. Choose the attachments for the job:
4. Operating the appliance
5. Packing away and storage
IMPORTANT: Always unplug the vacuum from the electrical outlet and rewind the power cord as directed before
storing.
!
Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308
C91-P2 & C90-P2 Series User Guide.qxd:C91-P2 Series User Guide 29/1/10 14:44 Page 3
vax.co.uk
4
dirt container / filters
6. Dirt Container: Maintenance
Emptying the Dirt Container
Cleaning the dirt bin
7. The Filters: Maintenance
Cleaning the HEPA Pre- Motor Filter
IMPORTANT : Always switch off and unplug the vacuum cleaner from the electrical outlet before removing the Dirt
Container.
!
IMPORTANT : Do NOT use the
vacuum without ALL of the
filters in place.
Vax recommends that the pre- and
post-motor filter should be checked and
cleaned periodically depending on the
frequency of use and the volume of dirt
being picked up on each occasion.
NOTE : Both Pre- and Post-Motor Filters
can be rinsed in warm water (max 40°C).
Allow to air dry for 24 hours before
replacing. Do NOTuse any detergents or
boiling water to wash the filters.
IMPORTANT: Your vax vacuum cleaner is fitted with high performance filters it is essential that these are well
maintained and cleaned according to the following instructions.
!
!
24
TAP
1
2
TAP
