Let’s talk safety
Basic
safety
precautions
Don’ts
This vacuum cleaner is intended for household use only and
NOT for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces and
keep the area your cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts and
openings whilst using the vacuum cleaner.
• Don’t use this vacuum cleaner if it has been dropped,
damaged or left outdoors.
• Don’t run over the power cord or use vacuum cleaner if the
power cord or plug is damaged. Please contact our Customer
Care Line on: 0330 026 8455 (Mon-Fri: 8:30am to 6:30pm,
Sat: 9:00am to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with
wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
• Don’t use the power cord as a handle, pull the power cord
around corners, sharp edges or close a door over the
power cord.
• Don’t unplug vacuum cleaner by pulling on the power cord.
Do’s
• Turn o all controls on the vacuum cleaner before
disconnecting or connecting the power cord.
• Always make sure both the pre-motor/post motor lters are
in place before use.
• Always switch o the vacuum cleaner before disconnecting
or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may
aect the airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse.
• This vacuum cleaner can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the vacuum cleaner in a safe way and understand the
hazards involved. Children shall not play with the vacuum cleaner. Cleaning
and user maintenance shall not be made by children without supervision.
• Only Vax recommended tools and accessories should be used with this
vacuum cleaner.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,
kerosene etc.) or use the vacuum cleaner in an area with explosive vapours
or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws or
coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.
• Always protect the power cable from heated surfaces and open ames.
• Take extra care when positioning and using the vacuum cleaner on the stairs.
• Use only CE approved 13amp extension cords, non-approved extension
cords may overheat. Care should be taken to arrange the extension cord as
it can be a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned
as per user guide instructions ensure they are thoroughly dry before
storing away.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE
Thank you for buying this Power 5.
Taking care of your carpets and hard oors
The Power 5 is designed to make vacuuming carpets and hard oors regularly, as eective and
ecient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer.
You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you
take good care of them.
Taking care of your Power 5
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you are to tackle your carpets and hard oors.
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 0LW, UK
This User Guide can be found online at: vax.co.uk/support
Let us know what you think @VaxUK
Contents
Power 5
(Included with all models)
Included with
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
What to do if it goes wrong
Getting in touch
your machine
Combination
Floorhead
Telescopic
Extension Tube
Crevice Tool
Dusting Brush
Hard Floor Tool
Upholstery Tool
Accessory Hose
Accessories
Initial Setup for normal operation
1. Use the base accessories.
a. Shortest hose.
b. Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All Bleeds must be closed.
5. Floorheads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floorheads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation turned OFF for hard oor cleaning.
Power 5 Pet
All the above, plus
TurboTool
Tool Connector
Getting to know your machine
Separator and shroud
Hose entry point
Dirt container release button
Cord rewind button
Post motor lter
(hidden) and cover
Dirt container
Carry handle
Dirt container lid
Power On/O button
Wheel outer
Technical Specication
Name Power 5
Voltage See rating label on machine for details
Wattage See rating label on machine for details
Cord length 5m
Weight 4.7kg
Subject to technical change without notice.
Accessories & Consumables
Filter Kit (Type 95)*
1-1-134231-00
Pro Cleaning Kit (Type 2)
1-1-133326-00
To purchase consumables and accessories, please visit vax.co.uk
*
TurboTool (Type 6)
1-1-134419-00
Hard oor tool (Type 3)
1-1-135705-00
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Before you begin cleaning
• Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments,
or removing and emptying the dirt container.
• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the
thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o and unplug
from electrical socket. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the
vacuum cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters
to fully dry before putting back into the vacuum machine).
• Tap the pre-motor lter over a bin every 4-6 uses to remove dirt/debris.
• If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
Assembling your cylinder
Click!
Press both buttons at the end of the
hose and push hose into the hose
entry point.
How to use
Fully unwind the power cord.
A yellow mark on the cord indicates
the recommended cord length.
Do not exceed the cord beyond the
yellow mark.
Insert the hose grip into the
telescopic extension tube. Press the
button on the telescopic extension
tube and adjust to required length.
Plug in and switch the unit on by
pressing the power button.
Insert the other end of the telescopic
extension tube into the oor head.
When unwinding the
power cord always pull
out to the yellow marker
but no further.
CAUTION
Using your machine
IMPORTANT: The base of the vacuum cleaner should always be positioned at on the oor when starting and in use.
The dirt container should be locked into place before lifting the vacuum cleaner by the carry handle.
How to use
For use on carpets, click rocker
switch forward.
Lower brushes for hard oors.
Slide vent cover on hose grip open
to reduce suction if required.
For use on hard oors click rocker
switch back.
For most ecient results on hard
oors replace the combination
oorhead with the specialist hard
oor tool.
Raise brushes for carpets.
Brushes on the
oorhead should be
visible when using on
hard oors.
TIP
Using accessories
Using your machine
Choose an accessory. Choose an accessory and push onto
the telescopic extension tube or hose.
Storage
Press the cord rewind button
to retract the cord into the
vacuum cleaner.
Place the oor head into the parking slot on the back of vacuum cleaning for
storage and carrying.
If required use tool connector.
Taking care of your machine
24hr
IMPORTANT: Always switch o and unplug the vacuum cleaner from the electrical socket before assembling,
opening or emptying the dirt container, or before connecting/disconnecting the attachments.
Check the pre-motor lter every time you empty the dirt container and tap against a bin to remove
dirt/debris if required.
The motor is equipped with a thermal cut-out. If for any reason the unit should overheat, the thermostat will
automatically turn the unit o.
Emptying and cleaning the dirt container
Remove dirt container
by pushing down the dirt
container release button
and lifting the dirt container.
Hold the dirt container over a
bin. Press the dirt release clip
at the bottom of the container,
the dirt release door will open
allowing dirt/debris to fall out.
Cleaning the pre-motor lter
Hold the dirt container and
twist the lid anti-clockwise.
T
Lift the lid to reveal the
pre-motor lter.
P
A
!
40˚C
40˚C
MAX
MAX
Lift out the pre-motor lter.
Tap the pre-motor lter
against a bin to remove
any dirt/debris.
Rinse the pre-motor lter
under water (max 40°C).
Leave to dry for 24 hours or
until fully dry before placing
back in the machine.
Cleaning the shroud
Taking care of your machine
Hold the dirt container and twist the
lid anti-clockwise.
Twist the separator cap anticlockwise to unlock and remove.
Make sure the rectangular hole in
the dirt container lines up with the
rectangular hole on the separator.
Lift the lid to reveal the
pre-motor lter.
Lift and remove the separator from
the dirt container.
Replace the separator cap,
twist clockwise to lock.
Lift out the pre-motor lter.
Tap the separator against a bin to
remove any dirt/debris.
Replace the pre-motor lter. Close
dirt bin lid making sure it clicks and
locks into place.
Let’s talk technical
!
40˚C
MAX
Post-motor lter maintenance
IMPORTANT: The exhaust lter is designed to oer long life with no maintenance. The lter should be checked
periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the lter
as this will damage the delicate lter media.
Post-motor lter is located in the
right side wheel. Hold the centre
of the wheel and twist wheel cover
anti-clockwise.
CAUTION: Do not wash the post-motor lter.
With the wheel cover o the
post-motor lter is easily removed.
Removing blockages from the TurboTool (some models only)
Slide the locking ring
to remove.
Lift and separate
the housing.
Using a pair of scissors,
cut any hair or debris free
from around the brushes.
Removing blockages from the hose
Check the post-motor lter
for discolouration.
Tabs
Line up the tabs on front of
housing and push together
to ret. Slide locking ring
into groove to secure.
Remove the hose from the vacuum cleaner and telescopic
extension tube. Insert a broom handle or similar blunt
instrument into the hose to remove blockage.
To test for a blockage in
the hose, drop a small
ball of paper into the
hose. The paper will
drop through if the
hose is clear.
TIP
There is an
accessory missing.
Why won’t the
vacuum cleaner
pick up?
What to do if it goes wrong
SolutionProblem
• Check the ‘This pack contains’ panel on the box to make sure
the part is included with your machine.
• The dirt container may not be correctly tted, remove the dirt
container from the vacuum cleaner and check it’s assembled correctly,
ret ensuring it’s locked into place.
• The shroud is blocked. Go to ‘Taking care of your machine’.
• The separator and shroud are incorrectly tted. Go to ‘Taking care
of your machine’.
• The lter may be clogged, clean the lter. Go to ‘Taking care of
your machine’.
• The dirt container may be blocked, empty the dirt container.
Go to ‘Taking care of your machine’.
• There may be a blockage in the hose/tube. Disconnect from the
vacuum cleaner and carefully remove any blockages.
Go to ‘Let’s talk technical’.
• The plug may not be fully pushed into the electrical socket.
Why does my
vacuum cleaner
have no power?
• Check the fuse in the plug if this needs replacing, always replace
with a 13amp fuse.
• The motor thermostat may have tripped. If this has happened,
unplug the vacuum cleaner. Remove and empty the dirt container
and check the hose for blockages. Clean the lters and allow the
vacuum cleaner to cool for approximately 1 hour (if you have washed
the lters you will need to wait 24 hours for the lters to fully dry
before putting them back into the vacuum cleaner).
• The lters may be clogged, clean the lter. Go to ‘Taking care
of your machine’.
Why is dust escaping
from the vacuum?
CAUTION: To reduce the risk of personal injury, unplug the product before performing maintenance
/troubleshooting checks.
Getting in touch
† Registration required. Terms and conditions apply.
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Pro Cleaning Kit (Type 2)
1-1-133326-00
All our best tools all in one kit that makes cleaning
your home quicker, easier and with even better
results. We’ve taken care of cleaning all of the hard
to reach areas such as on top of cupboards and in
between blinds to the dust that collates behind and
within the radiator.
TurboTool (Type 6)
1-1-134419-00
Use the TurboTool for vacuuming your stairs,
upholstery and car interiors. It’s great for picking
up stubborn pet hair.
Fur ‘n’ Flu Tool
1-1-131392-00
Specically designed to remove extra stubborn
pet hair from upholstery, furniture and carpets.
GET IN TOUCH
0330 026 8455 VaxVacuum sinfo@vax.co.uk vax.co.uk @Vax UK
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
C85-P5-(Be/Pe) manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive.
EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
© 2015 All rights reserved. VAX®, and VAX Lozenge are trade marks or registered trade marks of Techtronic Floor Care
Technology Ltd.
Loading...
