Thank You For Your Recent Purchase
At Vaultek
®
we stand behind our product
and you our customer. On behalf of the
entire team thank you for your purchase.
We believe personal defense should be
handled seriously and we’re excited for
you to experience the ultmimate
performance in smart-security.
STAY SAFE. VAULTEK
®
SAFE.
Page 3
TABLE OF CONTENTS
Troubleshooting
15-16
Warnings
17
Mounting
13-14
TABLE OF CONTENTS
Product Overview 02
Step 1: Pair Smart Key to Your Safe
04
Step 2: Assign an Entry Mode
05-07
Unpairing
08-09
Operation
10
Multiple Safe Management
11
Battery Replacement
12
Page 4
Smart Key NANO provides instant access to
your safe in the event you need immediate
entry. It’s small footprint and mountable base
make it easy to hide and conceal anywhere,
making it suitable for use as a panic button.
Be sure to follow ALL steps for proper function:
IMPORTANT
Remove
pull tab to
activate
battery
Pair remote to your safe (see page 04)
STEP 1
Assign an entry mode (see page 05-07)
STEP 2
ENTER BUTTON
STATUS LED
BASE
PRODUCT OVERVIEW
02 Vaultek
®
Page 5
Follow the Smart Key pairing instructions
specific to your safe (refer to your safe user
manual) to begin the pairing sequence.
When your safe is ready to receive a Smart
Key transmission, aim Smart Key NANO
towards your safe and press the central enter
button.
Your safe will indicate if pairing was either
successful or failed, if it failed start the
sequence over again with step 1.
04 Vaultek
®
Continued...
1
2
3
After pairing, assign an entry mode using either
the keypad or smartphone app. Refer to your
safe user manual for instructions specific to
your safe. Smart Key NANO has three available
modes.
PROGRESSIVE ENTRY MODE
Requires the safe to be awakened before
opening with Smart Key. Simply touch the front
of the safe or press any key on the safe to
illuminate the keys RED, then open safe using
Smart Key Nano.
STEP 2: ASSIGN AN ENTRY MODE
STEP 1: PAIR SMART KEY TO YOUR SAFE
Page 6
Immediate access using Smart Key without
having to awaken safe.
WARNING: Draws significant power,
recommend plugging in safe to continuous
power supply using safe charging kit.
ON DEMAND ENTRY MODE
After pairing, Smart Key NANO will open your
safe for only a short time. Be sure and assign an
entry mode.
If you do not assign an entry mode
immediately after pairing the Smart Key will
disable when the safe goes to sleep. This
occurs when the safe has been idle for 20
seconds.
OFF
Tip!
Disables the Smart Key from opening safe
temporarily until one of the other entry
modes are assigned.
STEP 2: ASSIGN AN ENTRY MODE
06 Vaultek
®
STEP 2: ASSIGN AN ENTRY MODE (Contiuned)
Page 7
A
B
You can unpair your Smart Key NANO at any
time in the event it is lost or stolen using a
couple different methods.
Follow the instructions for your safe to begin
pairing a Smart Key. If the safe does not
receive a signal from a Smart Key after 6
seconds, the safe will delete a paired Smart
Key from memory.
NOTE: Assigning the entry mode to OFF
will not delete a paired Smart Key.
Pairing a new Smart Key over the old one
will erase the old Smart Key from the safe
memory.
UNPAIRING YOUR REMOTE
08 Vaultek
®
Page 8
To Open Your Safe:
When in range of your safe, approximately 5-8
feet, press the enter button to open the safe.
If you are using PROGRESSIVE ENTRY mode, you
will need to awaken the safe first. Simply brush
your hand across the keypad to illuminate the
keys and then press the enter button on your
Smart Key to open your safe.
Smart Key has an active range of about 5-8 feet.
Tip!
OPERATION
Multiple Smart Keys can not pair with the
same safe. It is recommended to pair one
Smart Key per safe.
A
Recommended setting when using Smart Key
is progressive entry mode.
B
You can manage multiple safes through the
Vaultek smartphone app.
CAUTION when managing multiple safes in
On Demand entry mode there is chance you
can open all safes within range.
C
MULTIPLE SAFE MANAGEMENT
10 Vaultek
®
Page 9
12 Vaultek
®
The mountable base comes with double-sided
tape allowing for quick and easy installation.
Simply peel off the protective layer on the
reverse side of the base, and place where
desired.
Before installing your mountable base, clean
the mounting area to ensure surface is dry for
proper adhesion.
Tip!
MOUNTING
When Smart Key Nano LED flashes red (3)
times that indicates a low battery. Replace the
battery per steps below:
Twist base of Smart Key counter clockwise to
access battery compartment.
1
Remove old battery and install a new
CR2032 battery.
2
Assemble Smart Key back together, re-pairing
is not required.
3
BATTERY REPLACEMENT
Page 10
After pairing, Smart Key NANO will open your
safe, but be sure and assign an entry mode. If
entry mode is not set immediately after
pairing, Smart Key will be disabled when the
safe goes to sleep. This occurs when the safe
has been idle for 20 seconds.
Make sure you are within range of the safe,
approximately 5-8 feet, for the Smart Key
to operate.
1
2
TROUBLESHOOTING TIPS
14 Vaultek
®
14 Vaultek
®
14 Vaultek
®
TROUBLESHOOTING TIPS
Take caution when using Smart Key Nano.
Install in a secure location out of the hands of
children.
Be responsible. Security can be compromised
in the event Smart Key NANO is lost or stolen.
Only pair Smart Key NANO after thoroughly
understanding the inherent risks.
WARNING!
MOUNTING (Contiuned)
Page 11
16 Vaultek
®
Take caution when using Smart Key Nano and
be responsible. Security can be compromised
in the event the Smart Key is lost of stolen.
Only pair after thoroughly understanding the
inherent risks.
Anyone including children can access safe via
Smart Key.
Unpair Smart Key immediately if lost or stolen.
Refer to safe manual for full list of warnings.
WARNNGS
Make sure safe battery is sufficiently charged
or plugged in. As a built-in failsafe to prevent
Smart Key NANO from using remaining
power, the remote will not open your safe if
the safe battery is less than 5%.
The Smart Key Nano LED flashing red (3)
times indicates a low battery. Refer to battery
information on page 12.
3
4
TROUBLESHOOTING TIPS (Contiuned)
Still having issues please contact our
support team for assistance.
Page 12
FCC Statements
18 Vaultek
®
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation. NOTE: The
manufacturer is not responsible for any radio or
TV interference caused by unauthorized
modifications or changes to this equipment.
Such modifications or changes could void the
user’s authority to operate the equipment.
