Vasco Electronics Translator 7” User Manual

Vasco Translator 7”

USER MANUAL

ENGLISH

Copyright © 2019 Vasco Electronics LLC
www.vasco-electronics.com

Table of contents

1. Operation of the device 4

1.1 Function keys 5

1.2 Battery charging 5

1.3 Memory card 6

1.4 Built-in SIM card 6

1.4.1 Top-up 6

1.4.2 SIM card expiration 6

1.4.3 SIM card number 6

1.5 First start 7

2. Vasco Translator 7

2.1 Choosing the source and target languages 7

2.2. Voice recognition 8

2.3. Typing 8

2.4. Pronunciation 9

2.5. Clean 9

2.6. Menu 9

2.6.1. Translator 9

2.6.2 Photo Translator 10

2.6.3. History 12

2.6.4. Counters 12

2.6.5. Phrasebook 13

2.6.6. Conversation 13

2.6.7. Accessories 15

2.6.8. Settings 15

3. Menu 16

4. Device Settings 17

4.1 Networks 17

4.1.1 WiFi conguration 17

4.2 Device 18

4.3 Bottom bar 19

Specication 20

4

1. Operation of the device

1 310 42

5

V-V+

6

R

11

89

7

1. Loudspeaker 2. Earphone input

3. USB 4. Cover lift 5. Volume

6. Power ON/OFF 7. Loudspeaker

8. SIM card 9. SD card 10. Camera

11. Reset

1.1 Function keys

Power

• Device turned o: hold this key for 5 seconds to turn the device on

• Working device:

• push this key to lock the screen, push again to unlock

• push and hold the key for 2 seconds and tap “Power o” to turn the
device o

• push and hold the key for 2 seconds and tap “Reboot” to reboot
the device

• push and hold the key for 2 seconds and tap “airplane mode” to acti­vate ight mode; ight mode disconnects GSM and WiFi; repeat the
steps to deactivate ight mode

Volume

• Working device: push up or down to increase or decrease the volume.

• You will see the following icon. Tap and hold the blue dot and swipe left
to decrease and right to increase the volume: .

5

1.2 Battery charging

• Plug the charger into an electric socket and the USB cable into the
device in order to charge the battery.

• The battery indicator moves to charging mode.

• The battery is fully charged after about 4 hours.

• After the battery is charged, remove the charger and the USB cable.

WARNING: Charge the battery in a well-ventilated area between 14°F
and 95°F (-10C to +35C). To charge the battery use the charger provided
by the manufacturer. Using any other charger may damage the device.

6

1.3 Memory card

A memory card is provided with the device. Removing and/or damaging
the card may cause incorrect functioning of the device. In the event of dam­aging the card, contact the seller.

1.4 Built-in SIM card

The device is equipped with an international SIM card that allows it to
work without WiFi. The built-in SIM card is pre-paid and doesn’t require
any contract.

1.4.1 Top-up

The SIM card is active and topped-up. In order to top up your account visit:
www.vasco-sim.com or contact the seller.

1.4.2 SIM card expiration

The SIM card expires after 2 years from the last use of the device. In order to

prolong this period, just use your device through a GSM network.

1.4.3 SIM card number

Your SIM card number starts with +372. You will nd the complete number

on the inner side of the box, on the protective case or under the cover of

the battery.

WARNING: Don’t bend or scratch the SIM card. It should not have any
contact with water, dust or electricity.

1.5 First start

After turning the device on, swipe left or right and choose your language.
Then, read and accept the terms of service. The language chosen will
change all the regional settings, including the language of the keyboard.

You will see the main screen of Vasco Translator. The device is now ready
to use.
