Manual
PAR 64 long
2 / 8
Table of contents
1. Safety instructions ............................................................................................................................ 3
1.1. For safe and efficient operation ............................................................................................... 3
2. Designated use ................................................................................................................................ 4
2.1. Overhead installation ............................................................................................................... 5
3. Introduction ....................................................................................................................................... 6
3.1. Product overview ..................................................................................................................... 6
4. Connections ..................................................................................................................................... 6
4.1. Electrical connections .............................................................................................................. 6
5. Replacing the lamp ........................................................................................................................... 7
6. Technical data .................................................................................................................................. 7
1. Safety instructions
• This
device is suitable for indoor use (not outdoors) only
•
All modifications to the device will void the warranty.
•
Repairs are to carry out by skilled personnel
•
Use only fuses of the same type and original parts as spare parts.
•
Protect the unit from rain and humidity to avoid fire and electric shocks.
•
Make sure to unplug the power supply before opening the housing.
1.1.
For safe and efficient operation
Be carefu
l with heat and extreme temperature!
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32
Keep away from humidity, water and dust!
Do not place the set in a locati
on with high humidity or lots of dust. Containers with water
should not be placed on the set.
To avoid placing on un-
stable location!
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning!
Use a
clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately!
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing, do not
open the cabinet by yourself,
it might result a danger of electric shock.
Take care with the power cable!
Never pull the power cable to remove the plug from the receptacle, be sure to hold the plug. When not
using the device for an extended period of time, be sure to disconnect the plu
IMPORTANT!
Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not
accept liability for any resulting defects or problems. Make sure the electrical connection is carried out
by qualified p
ersonnel. All electrical and mechanical connections have to be carried out according to
the European safety standards.
3 / 8
.
only.
°F /0°C, or exceeding 104°F /40°C.
on with high humidity or lots of dust. Containers with water
g from the receptacle.
4 / 8
2. Designated use
This device was developed for professional use on stages, in discos, theatres etc. The device is only
approved for a connection up to 230V 50/60 Hz AC voltage and only for indoor use.
Regular breaks during operation increase the lifetime of your device.
Avoid convulsions or any form of forceful impact during the installation or the start-up of the device.
Make sure that the device is not exposed excessive heat, humidity or dust at the place of installation.
Take care that no cables are lying around. You would endanger your own safety and also the safety of
a third party.
It is not allowed to operate or store the device in an environment in which spray water, rain, humidity
or fog is expected. Humidity or very high atmospheric humidity could reduce the isolation of the device
and could cause deathly electric shocks. If you use fog devices the device has not be exposed to a
direct smoke jet. There has to be a safety distance of at least 0,5m between this device and the fog
machine. Make sure that the saturation of the fog has to enable a visibility of at least 10m.
Fire hazard!!
Make sure when installing the projector, that there are no flammable materials within a distance of at
least 1m.
Operate the device not during thunderstorms. Surge voltages could destroy the device. Unplug the
power supply during thunderstorms.
Surrounding objects or surfaces should not be in contact with the device.
Make sure that during the installation and removal of the device the area below the place of
installation is basically cordoned off. This also applies to implementation of service.
The device has basically been protected by a suitable safety.
Make familiar yourself with the functions of the device before start-up. People without the experience
should not handle with the device. The most cause of functional disorder is inappropriate handling.
Do not use chemicals or volatile liquids for cleaning. Use a clean dry cloth to wipe off the dust, or a
wet soft cloth for stubborn dirt.
For transport use the original packing or designated accessory to avoid damages during the transport.
For reasons of safety unauthorized changes are forbidden.
A usage of the device which differs from usages which are described in this manual can cause
damages of the device. In that case the warranty expires. Additional you should notice that every
differed usage is related with dangers and can cause e.g. an electrical short, fire, electric shock or
crash.
2.1.
Overhead installation
Danger of life!
You have to observe the regulations of BGV C1 (formerly VBG 70) and
EN60598-2-
17
The suspension devices have to
of the payload without suffering a permanent detrimental deformation.
Basically installation has to be made by using a second separate suspension. This can be e.g. a
suitable net. The se
cond suspension must be designed and attached so no part of the installation can
fall down in case of failure.
During construction, reconstruction and deconstruction unnecessary stay in the range of moving
areas, on lightning bridges, under elevated work
The operator is obliged to following safety
- Before the first start-
up or after critical changes before restarting it has to be checked by an
expert.
- Review in the frame
of the inspection test at least all four years by an expert. .
-
Review by a qualified person at least once a year.
How to carry out the overhead installation:
In tidal fall you should install the device out of the lounge area of people
IMPORTANT!
Overhead installation requires a high level of experience. This includes knowledge of calculating the
payload, used installation material and safety inspections of the used material and the projector
whereas the required experience is not limited to this.
any circumstances if you are not qualified. Contact a professional installer. An inappropriate
installation can lead to injuries and/or damaged properties.
It is not allowed to install the device in the
If the device may hang from the ceiling or from high beams, the use of truss systems is mandatory.
The device may not be installed so it can swing freely in the room.
Please note: Crashing down items can cause serious injuries! Do
the safety of a possible installation form!
Before installation make sure that the mounting surface has the ability to carry the tenfold point load of
the own weight of the device.
Mount the device with the mountin
During overhead installation the device must be always secured by a safety rope which is designed to
hold the twelvefold weight of device. Only safety ropes with quick
may be used. Hang up the safety rope in the hole of the mounting bracket. Direct the rope over the
truss or an appropriate fastening point. Hang up the end in the fastening element and tie up the
locking nut. A safety rope once exposed to failing
5 / 8
Installations are to carry out by skilled personnel only.
be build and measured so they can withstand for an hour the tenfold
stations or any other danger zones is forbidden.
-related and mechanical facilities:
Do not try to carry out installation yourself under
grip area of people.
not install the projector, if you doubt
g-
bracket to your trussing system using an appropriate clamp.
-
release safety fastener
load or damaged may not be used furthermore.
elements
6 / 8
The maximum drop exceed must not exceed 20cm.
A safety rope once exposed to failing load or damaged may not be used furthermore.
Adjust the desired inclination angle via the mounting bracket and tighten the screw.
3. Introduction
Thank you for buying the PAR 64 long. It is a powerful device.
For a successful installation and operation, please read this manual carefully.
3.1. Product overview
1. Housing cover
2. Mounting bracket
3. Locking bracket
4. Hole for safety
5. Cone
6. Filter frame
7. Extension lead
8. Locking screw
9. Hole for safety for filter frame
10. Retaining clips
4. Connections
4.1. Electrical connections
If you wish to change the power supply settings, see the chapter Appendix. Connect the fixture to the
mains with the enclosed power cable and plug. The earth has to be connected.
Cable (EU) Cable (US) Pin International
Brown Black Live L
Light blue White Neutral N
Yellow/Green Green Earth
5.
Replacing the lamp
Danger of Life!
Seat in the lamp only when the power is off. Unplug the power cord!
Attention!
If the lamp is damaged or has lamp deformed by heat, it should be replaced
immediately.
Unplug the unit completely from the mains before you change a
cord. Allow the lamp to cool before changing necessarily. This takes approximately 5 minutes.
Do not touch the glass body with your bare hands. Notes the lamp manufacturer should also be strictly
observed.
No lamps may
be used with a higher power rating in the device. For lamps with higher performance
arise during operation higher temperatures, for which the equipment was not designed. Non
compliance will invalidate the warranty.
This spotlight is optimal for 230 volt.
Do not turn on the device before you have not closed the housing cover!
6. Technical data
Power supply
Energy efficiency
Power consumption max.
Light source
LM type
Socket
Connections
Power in
Hardware
Protection class
Suitability
Dimension (L/B/H)
Material
Weight
7 / 8
lamp. To do this, unplug the power
Application up to max. 1000 W.
A++ to F
1000 W
Halogen
GX16D
Schutzko
IP20
Indoor
470 x 260 x 275 mm
Aluminium
1,60 kg
-
8 / 8
Importer:
B & K Braun GmbH
Industriestraße 2
D-76307 Karlsbad
www.bkbraun.com
