Giga Bar HEX 3
Giga Bar HEX 3 BAT
User manual
LED bar
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
30.10.2019, ID: 472654, 472655
Table of contents
Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 11
3 Features....................................................................................................................................................... 19
4 Installation.................................................................................................................................................. 20
5 Starting up.................................................................................................................................................. 24
6 Connections and controls................................................................................................................... 27
7 Operating.................................................................................................................................................... 34
7.1 Starting the device........................................................................................................................... 34
7.2 Operating on the unit..................................................................................................................... 34
7.3 Menu overview................................................................................................................................. 43
7.4 Functions in 3-channel DMX mode........................................................................................... 44
7.5 Functions in 4-channel DMX mode........................................................................................... 44
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
3
Table of contents
7.6 Functions in 6-channel DMX mode........................................................................................... 45
7.7 Functions in 9-channel DMX mode........................................................................................... 46
7.8 Functions in 11-channel DMX mode........................................................................................ 47
8 Technical specications....................................................................................................................... 49
9 Plug and connection assignments.................................................................................................. 53
10 Troubleshooting...................................................................................................................................... 54
11 Cleaning....................................................................................................................................................... 56
12 Protecting the environment.............................................................................................................. 57
Giga Bar HEX 3Giga Bar HEX 3 BAT
4
LED bar
1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
5
General information
1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Giga Bar HEX 3Giga Bar HEX 3 BAT
6
LED bar
Keyword search
Online guides
Personal consultation For personal consultation please contact our technical hotline.
Service
Use the search function in the electronic version to nd the topics of
interest for you quickly.
Our online guides provide detailed information on technical basics
and terms.
If you have any problems with the device the customer service will
gladly assist you.
1.2 Notational conventions
This manual uses the following notational conventions:
General information
Letterings
Displays
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
7
General information
Instructions
The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
3. Switch o the device.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Automatic operation is started.
ð
Giga Bar HEX 3Giga Bar HEX 3 BAT
8
LED bar
General information
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – dangerous optical radiation.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
9
General information
Warning signs Type of danger
Warning – suspended load.
Warning – danger zone.
Giga Bar HEX 3Giga Bar HEX 3 BAT
10
LED bar
2 Safety instructions
Safety instructions
Intended use
This device is intended for use as an electronic lighting eect by means of LED technology. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Extend the life of the device by regular breaks in operation and avoid switching it on and o
frequently. This device is not suitable for continuous use.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
11
Safety instructions
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
Giga Bar HEX 3Giga Bar HEX 3 BAT
12
LED bar
Safety instructions
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or re. If in doubt, seek advice from a regis‐
tered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
13
Safety instructions
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present sec‐
tion.
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
Giga Bar HEX 3Giga Bar HEX 3 BAT
14
LED bar
Safety instructions
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
15
Safety instructions
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or re.
NOTICE!
Possible damage due to installation of a wrong fuse
The use of dierent types of fuses can cause serious damage to the unit. Fire
hazard!
Only fuses of the same type may be used.
Giga Bar HEX 3Giga Bar HEX 3 BAT
16
LED bar
Safety instructions
NOTICE!
Risk of re due to incorrect polarity
Incorrectly inserted batteries may destroy the device or the batteries.
Ensure that proper polarity is observed when inserting batteries.
NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device.
Take batteries out of the device if it is not going to be used for a longer period.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
17
Safety instructions
NOTICE!
Possible damage due to incorrect storage
Deep discharge can cause batteries to become permanently damaged or lose
some of their capacity.
Before prolonged rest periods, charge the batteries to around 50 % of their
capacity and then switch the equipment o. Store the equipment at a tempera‐
ture between 10 °C and 32 °C in as dry an environment as possible. During
extended storage periods, charge the batteries to 50 % approximately every three
months.
Giga Bar HEX 3Giga Bar HEX 3 BAT
18
LED bar
3 Features
Features
Special features of the device:
n LED BAR with 3 × RGBAWUV LED, 6-in-1, 12 W each
n Mains operation (item no. 472654) or battery operation (item no. 472655)
n Operating modes:
– Automatic
– DMX
– Master/Slave
– Sound control via built-in microphone
n Control via DMX (ve dierent modes), via the supplied infrared remote and via buttons
and display on the unit
For technological reasons, the light output of LEDs decreases over their lifetime. This eect
increases with higher operating temperature. You can extend the service life of the illuminants
by providing adequate ventilation and operating the LEDs with the lowest possible brightness.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
19
Installation
4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Giga Bar HEX 3Giga Bar HEX 3 BAT
20
LED bar
Installation
NOTICE!
Risk of overheating
The distance between light output and the illuminated surface must be more
than 1.5 m (19.7in).
Provide sucient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
21
Installation
Mounting options
You can install the unit in hanging or standing position. When in use, the device must always
be attached to a solid surface or an approved truss.
Always work from a stable platform whenever installing, moving or servicing the unit. In doing
so, the area underneath the unit must be cordoned o.
The safety cable must be attached to the safety eyelet.
Please note that this device must not be connected to a dimmer.
Giga Bar HEX 3Giga Bar HEX 3 BAT
22
LED bar
Installation
Inserting batteries into the
remote
Push the lock of the battery holder towards the centre of the housing and pull out the battery
holder like a drawer. Insert the batteries in the correct polarity according to the marking on the
remote. Slide the battery holder back into the remote until it clicks into place.
When shipping, the batteries are already installed in the remote and protected against dis‐
charge by a transparent plastic lm. Remove the plastic lm before initial use.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
23
Starting up
5 Starting up
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Giga Bar HEX 3Giga Bar HEX 3 BAT
24
LED bar
Starting up
Connections in DMX mode
Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the rst DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼ W).
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
25
Starting up
Connections in master/slave
mode
When you congure a group of devices in master/slave mode, the rst unit will control the
other units for an automatic, sound-activated, synchronized show. This function is ideal when
you want to start a show immediately. Connect the DMX output of the master device to the
DMX input of the rst slave device. Then connect the DMX output of the rst slave device to
the DMX input of the second slave device and so on.
Giga Bar HEX 3Giga Bar HEX 3 BAT
26
LED bar
6 Connections and controls
Front panel
Connections and controls
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
27
Connections and controls
1 LED
2 Locking screw for mounting bracket
3 Mounting bracket
The infrared sensor for the remote control signals is located beneath the right lens.
Giga Bar HEX 3Giga Bar HEX 3 BAT
28
LED bar
Rear panel
4 Safety eyelet for fastening the safety cable
Connections and controls
5 IEC chassis plug with fuse holder (item no. 472654)
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
29
Connections and controls
6 Power supply connection socket for charging the battery (item no. 472655)
7 On / o switch (item no. 472655)
8 Display
[MODE]
Calls up the main menu and exits an opened submenu.
[SETUP]
Selects an option of the respective operating mode, conrms the set value.
[UP]
Toggles between the menu items of a menu level, increases the displayed value by one.
[DOWN]
Toggles between the menu items of a menu level, decreases the displayed value by one.
Giga Bar HEX 3Giga Bar HEX 3 BAT
30
LED bar
9 [DMX IN]
DMX input
10 [DMX OUT]
DMX output
Connections and controls
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
31
Connections and controls
Remote control
11 Buttons to select a single basic colour
12 [+], [–]
Changes the auto or fade programmes, increases or decreases the strobe speed
Giga Bar HEX 3Giga Bar HEX 3 BAT
32
LED bar
13 Selection of a mixed colour
14 Function selection
[Blackout]
Button to turn the blackout on or o
[Strobe]
Turns the Strobe eect (ash) on or o
[Fullon]
Turns all colours to full brightness
[Auto]
Starts a preprogrammed automatic show
[Fade]
Turns the Fade eect (colour transition) on or o
Connections and controls
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
33
Operating
7 Operating
7.1 Starting the device
7.2 Operating on the unit
Menu control
Connect the device to the power grid.
Turn on the power using the main switch. The display shows the current operation mode.
1. Press [MODE] to open the main menu or to return to the main menu.
2. Use [UP] or [DOWN] to select the desired submenu, parameter or value.
3. Conrm the selection with [SETUP].
The selected submenu opens up or the selected value is being accepted.
ð
Giga Bar HEX 3Giga Bar HEX 3 BAT
34
LED bar
To return to the next higher menu level without changes, press [MODE].
Operating
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
35
Operating
DMX address
Use ‘Addr’ to select the start address channel for the DMX address.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘Addr’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired start address from ‘A001’ …‘A512’.
4. Conrm the selection with [SETUP].
The selected start address is accepted.
ð
DMX mode Highest possible start address
3-channel mode 510
4-channel mode 509
6-channel mode 507
9-channel mode 504
11-channel mode 502
Giga Bar HEX 3Giga Bar HEX 3 BAT
36
LED bar
Operating
DMX mode
Manual dimmer
Use ‘Chnd’ to select the DMX mode.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘Chnd’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired DMX mode.
n ‘CH 3’ (3 channels)
n ‘CH 4’ (4 channels)
n ‘CH 6’ (6 channels)
n ‘CH 9’ (9 channels)
n ‘CH 11’ (11 channels)
4. Conrm the selection with [SETUP].
The selected setting is accepted.
ð
Use ‘MAnU’ to manually dim the colours.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘MAnU’ .
2. Conrm the selection with [SETUP].
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
37
Operating
3. Use [UP] or [DOWN] to select the desired colour; display shows ‘red’ , ‘Gree’, ‘bLue’,
‘Uhte’ , ‘YeLL’, ‘UV’.
4. Conrm the selection with [SETUP].
5. Use [UP] or [DOWN] to select the desired intensity in a range from ‘000…255’ .
6. Conrm the selection with [SETUP].
The selected setting is accepted.
ð
Colour selection
Operating mode Auto
Giga Bar HEX 3Giga Bar HEX 3 BAT
38
LED bar
Use ‘CoLo’ to select one of 32 mixed colours.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘CoLo’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired mixed colour; display shows ‘Co 1…Co 32’ .
4. Conrm the selection with [SETUP].
The selected setting is accepted.
ð
Use ‘AUto’ to select ve automatic programmes and set a running speed.
Operating
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘AUto’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired auto programme; display shows ‘SH-1…SH-5’ .
4. Conrm the selection with [SETUP].
5. Use [UP] or [DOWN] to select the desired running speed; display shows ‘SP01…SP15’ .
6. Conrm the selection with [SETUP].
The selected setting is accepted.
ð
Fade eect
Use ‘FAde’ to select ve fade eects and set a running speed.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘FAde’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired fade eect; display shows ‘FA-1…FA-5’ .
4. Conrm the selection with [SETUP].
5. Use [UP] or [DOWN] to select the desired running speed; display shows ‘SP01…SP15’ .
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
39
Operating
6. Conrm the selection with [SETUP].
The selected setting is accepted.
ð
Sound control
Strobe speed
Giga Bar HEX 3Giga Bar HEX 3 BAT
40
LED bar
Use ‘SoUn’ to select 11 sound control programmes.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘SoUn’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired sound control programme; display shows
‘So00…So10’ .
4. Conrm the selection with [SETUP].
The selected setting is accepted.
ð
Use ‘FLSH’ to select 15 strobe speeds.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘FLSH’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired strobe speed; display shows ‘FL01…FL15’ .
4. Conrm the selection with [SETUP].
The selected setting is accepted.
ð
Operating
Master / slave mode
Battery charge display (only
item no. 472655)
Use ‘SLAV’ to activate or deactivate the Slave mode.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘SLAV’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] to select the desired option; display shows ‘SL-N’ (on) or ‘SL-U’ (o).
4. Conrm the selection with [ENTER].
The device now operates in slave mode and applies all settings of the master device
ð
or works in stand-alone mode again.
With ‘bAtt’ you can check the charge status of the battery.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘bAtt’ .
2. Conrm the selection with [SETUP].
The current charge status of the battery is displayed.
ð
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
41
Operating
Remote control
With ‘Ir’ you can activate or deactivate the infrared remote control.
1. Press [MODE] and use [UP] or [DOWN] to select the submenu ‘Ir’ .
2. Conrm the selection with [SETUP].
3. Use [UP] or [DOWN] the desired option; display shows ‘on’ or ‘oFF’.
4. Conrm the selection with [SETUP].
Infrared remote control is activated or deactivated.
ð
Giga Bar HEX 3Giga Bar HEX 3 BAT
42
LED bar
7.3 Menu overview
Operating
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
43
Operating
7.4 Functions in 3-channel DMX mode
Channel Value Function
1 0…255 Intensity red (0 % to 100 %)
2 0…255 Intensity green (0 % to 100 %)
3 0…255 Intensity blue (0 % to 100 %)
7.5 Functions in 4-channel DMX mode
Channel Value Function
1 0…255 Intensity red (0 % to 100 %)
2 0…255 Intensity green (0 % to 100 %)
3 0…255 Intensity blue (0 % to 100 %)
4 0…255 Intensity white (0 % to 100 %)
Giga Bar HEX 3Giga Bar HEX 3 BAT
44
LED bar
7.6 Functions in 6-channel DMX mode
Channel Value Function
1 0…255 Intensity red (0 % to 100 %)
2 0…255 Intensity green (0 % to 100 %)
3 0…255 Intensity blue (0 % to 100 %)
4 0…255 Intensity white (0 % to 100 %)
5 0…255 Intensity amber (0 % to 100 %)
6 0…255 Intensity UV (0 % to 100 %)
Operating
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
45
Operating
7.7 Functions in 9-channel DMX mode
Channel Value Function
1 0…255 Intensity red (0 % to 100 %)
2 0…255 Intensity green (0 % to 100 %)
3 0…255 Intensity blue (0 % to 100 %)
4 0…255 Intensity white (0 % to 100 %)
5 0…255 Intensity amber (0 % to 100 %)
6 0…255 Intensity UV (0 % to 100 %)
7 0…255 Intensity master
8 0…255 Strobe master
9 0…10 No function
11…100 Fade eect, increasing speed
Giga Bar HEX 3Giga Bar HEX 3 BAT
46
LED bar
Channel Value Function
101…200 Colour change, increasing speed
201…255 Sound control
7.8 Functions in 11-channel DMX mode
Channel Value Function
1 0…255 Intensity red (0 % to 100 %)
2 0…255 Intensity green (0 % to 100 %)
3 0…255 Intensity blue (0 % to 100 %)
4 0…255 Intensity white (0 % to 100 %)
5 0…255 Intensity amber (0 % to 100 %)
6 0…255 Intensity UV (0 % to 100 %)
Operating
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
47
Operating
Channel Value Function
7 0…255 Intensity master
8 0…255 Strobe master
9 0…10 No function
11…100 Fade eect
101…200 Colour change
201…255 Sound control
10 0…255 Speed or sensitivity, if channel 9 = 11…200
11 0…14 No function
15…255 Colour macros
Giga Bar HEX 3Giga Bar HEX 3 BAT
48
LED bar
8 Technical specications
Light source 3 × RGBAWUV LED, each 12 W
Optical properties Beam angle 25°
Control DMX
Control protocol DMX 512
Number of DMX channels 3, 4, 6, 9, 11
Input connections Voltage supply Item no. 472654: IEC chassis plug C14
Output connections DMX control XLR chassis socket, 3-pin
Technical specications
Infrared remote control
Buttons and display on the unit
Item no. 472655: Connection socket for
power adapter
DMX control XLR chassis socket, 3-pin
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
49
Technical specications
Power consumption 36 W
Voltage supply
Fuse (item no. 472654) 5 mm × 20 mm, 1 A, 250 V, slow-blow
Operating supply voltage
Battery / rechargeable
battery (Item no. 472655)
Battery remote control Battery type 2 × button cells, LR1130/AG10, 1.5 V
Protection class IP20
Mounting options standing, hanging
Dimensions (W × H × D) 360 mm × 150 mm × 64 mm
Weight Item no. 472654: 1.2 kg
100 – 240 V 50/60 Hz
Item no. 472655: Mains adapter (12.6 V , 1,5 A, centre positive)
Battery type Lithium-ion
Charging time approx. 4.5 h
Item no. 472655: 1.45 kg
Giga Bar HEX 3Giga Bar HEX 3 BAT
50
LED bar
Technical specications
Ambient conditions Temperature
range
Relative humidity 50 %, non-condensing
0 °C…40 °C
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
51
Technical specications
Further information
Construction LED bar
Outdoor capable No
Number of LEDs 3
Colour mixture RGBAWUV
LED type x-in-1
LEDs individually controllable No
Fanless Yes
Remote control included
Wireless DMX No
Housing colour black
Giga Bar HEX 3Giga Bar HEX 3 BAT
52
LED bar
9 Plug and connection assignments
Plug and connection assignments
Introduction
DMX connections
This chapter will help you select the right cables and plugs to connect your valuable equip‐
ment so that a perfect light experience is guaranteed.
Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug
ts into a socket, the result of an incorrect connection may be a destroyed DMX controller, a
short circuit or ‘just’ a not working light show!
The unit oers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please
refer to the drawing and table below for the pin assignment of a suitable XLR plug.
Pin Conguration
1 Ground, shielding
2 Signal inverted (DMX–, ‘cold signal’)
3 Signal (DMX+, ‘hot signal’)
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
53
Troubleshooting
10 Troubleshooting
In the following we list a few common problems that may occur during operation. We give you
some suggestions for easy troubleshooting:
Giga Bar HEX 3Giga Bar HEX 3 BAT
54
LED bar
Symptom Remedy
The unit does not work, no light Check the mains connection.
For item no. 472655 check the charge status of the bat‐
tery.
Troubleshooting
Apparently no function despite
proper power supply
No response to the DMX con‐
troller
If the procedures recommended above do not succeed, please contact our Service Center. You
can nd the contact information at www.thomann.de.
Check if the unit is in DMX mode or in ‘slave’ mode. If so,
check the unit in another mode.
1. Check whether the DMX controller is switched on.
Check the DMX connectors and cables for proper con‐
nection.
2. Check the address settings and the DMX polarity.
3. Try using another DMX controller.
4. Check whether the DMX cables run near or parallel to
high-voltage cables that may cause damage or interfer‐
ence to a DMX interface circuit.
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
55
Cleaning
11 Cleaning
Optical lenses
Fan grids
Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the
light output. The frequency of cleaning depends on the operating environment: wet, smoky or
particularly dirty surroundings can cause more accumulation of dirt on the optics of the
device.
n Clean with a soft cloth using our lamp and lens cleaner (item no. 280122).
n Always dry the parts carefully.
The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐
ular basis. Before cleaning, switch o the device and disconnect mains-operated devices from
the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit
with a slightly damp lint-free cloth.
Giga Bar HEX 3Giga Bar HEX 3 BAT
56
LED bar
12 Protecting the environment
Disposal of the packaging mate‐
rial
For the packaging, environmentally friendly materials have been chosen that can be supplied
to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
Disposal of batteries
Batteries do contain some hazardous chemicals so they should not be thrown away with the
normal household waste. They should be returned to the manufacturer for disposal or recycled
elsewhere in accordance with your local regulations.
Remove lithium batteries from the device before disposal. Protect used lithium batteries
against potential short circuits, e.g. by covering the poles with adhesive tape. Dispose the
built-in lithium batteries together with the device. Please check for an appropriate reception
facility.
Protecting the environment
Giga Bar HEX 3Giga Bar HEX 3 BAT
LED bar
57
Protecting the environment
Disposal of your old device
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE) in its currently valid version. Do not dispose with your normal household waste.
Dispose of this device through an approved waste disposal rm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
Giga Bar HEX 3Giga Bar HEX 3 BAT
58
LED bar
