BAT.PAR 8 RGBW
User manual
LED bar
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
07.02.2019, ID: 385438 (V2)
Table of contents
Table of contents
1 General information................................................................................................................................. 6
1.1 Further information........................................................................................................................... 7
1.2 Notational conventions.................................................................................................................... 8
1.3 Symbols and signal words............................................................................................................... 9
2 Safety instructions.................................................................................................................................. 12
3 Features....................................................................................................................................................... 19
4 Installation.................................................................................................................................................. 20
5 Starting up.................................................................................................................................................. 24
6 Connections and controls................................................................................................................... 27
7 Operating.................................................................................................................................................... 36
7.1 Starting the device........................................................................................................................... 36
7.2 Operating on the unit..................................................................................................................... 36
7.3 IR remote control............................................................................................................................. 43
7.4 Menu overview................................................................................................................................. 44
7.5 Functions in 4-channel DMX mode........................................................................................... 45
BAT.PAR 8 RGBW
LED bar
3
Table of contents
7.6 Functions in 7-channel DMX mode........................................................................................... 45
7.7 Functions in 11-channel DMX mode........................................................................................ 49
7.8 Functions in 16-channel DMX mode........................................................................................ 52
7.9 Functions in 19-channel DMX mode........................................................................................ 54
7.10 Charging the battery.................................................................................................................... 58
8 Technical specications....................................................................................................................... 59
9 Plug and connection assignments.................................................................................................. 62
10 Troubleshooting...................................................................................................................................... 63
11 Cleaning....................................................................................................................................................... 66
12 Protecting the environment.............................................................................................................. 67
BAT.PAR 8 RGBW
4
LED bar
BAT.PAR 8 RGBW
LED bar
5
General information
1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
BAT.PAR 8 RGBW
6
LED bar
1.1 Further information
General information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search
Online guides
Personal consultation For personal consultation please contact our technical hotline.
Service
Use the search function in the electronic version to nd the topics of
interest for you quickly.
Our online guides provide detailed information on technical basics
and terms.
If you have any problems with the device the customer service will
gladly assist you.
BAT.PAR 8 RGBW
LED bar
7
General information
1.2 Notational conventions
This manual uses the following notational conventions:
Letterings
Displays
BAT.PAR 8 RGBW
8
LED bar
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’.
General information
Instructions
The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
3. Switch o the device.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Automatic operation is started.
ð
BAT.PAR 8 RGBW
LED bar
9
General information
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – dangerous optical radiation.
BAT.PAR 8 RGBW
10
LED bar
Warning signs Type of danger
Warning – suspended load.
Warning – danger zone.
General information
BAT.PAR 8 RGBW
LED bar
11
Safety instructions
2 Safety instructions
Intended use
This device is intended for use as an electronic lighting eect by means of LED technology. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Extend the life of the device by regular breaks in operation and avoid switching it on and o
frequently. This device is not suitable for continuous use.
BAT.PAR 8 RGBW
12
LED bar
Safety
Safety instructions
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
BAT.PAR 8 RGBW
LED bar
13
Safety instructions
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or re. If in doubt, seek advice from a regis‐
tered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
BAT.PAR 8 RGBW
14
LED bar
Safety instructions
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present sec‐
tion.
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
BAT.PAR 8 RGBW
LED bar
15
Safety instructions
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
BAT.PAR 8 RGBW
16
LED bar
Safety instructions
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or re.
NOTICE!
Risk of re due to incorrect polarity
Incorrectly inserted batteries may destroy the device or the batteries.
Ensure that proper polarity is observed when inserting batteries.
BAT.PAR 8 RGBW
LED bar
17
Safety instructions
NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device.
Take batteries out of the device if it is not going to be used for a longer period.
NOTICE!
Possible damage due to incorrect storage
Deep discharge can cause batteries to become permanently damaged or lose
some of their capacity.
Before prolonged rest periods, charge the batteries to around 50 % of their
capacity and then switch the equipment o. Store the equipment at a tempera‐
ture between 10 °C and 32 °C in as dry an environment as possible. During
extended storage periods, charge the batteries to 50 % approximately every three
months.
BAT.PAR 8 RGBW
18
LED bar
3 Features
Features
Special features of the device:
n Battery operated LED BAR with 8 × 8 W RGBW LED
n Auto, sound-controlled, master/slave and DMX mode
n Control via DMX (ve dierent modes), via the supplied infrared remote and via buttons
and display on the unit
n Operation with up to four battery packs
n Battery or mains powered
n Charging time in the device about 3 hours, with fast charger about 1 hour
n One battery pack, infrared remote control and charging cable for mains operation
included
n Suitable for use in clubs, bars, theatres, exhibitions, etc., also for mobile use due to battery
operation
For technological reasons, the light output of LEDs decreases over their lifetime. This eect
increases with higher operating temperature. You can extend the service life of the illuminants
by providing adequate ventilation and operating the LEDs with the lowest possible brightness.
BAT.PAR 8 RGBW
LED bar
19
Installation
4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
BAT.PAR 8 RGBW
20
LED bar
Installation
NOTICE!
Risk of overheating
The distance between light output and the illuminated surface must be more
than 1.5 m (19.7in).
Provide sucient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
BAT.PAR 8 RGBW
LED bar
21
Installation
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
Mounting options
BAT.PAR 8 RGBW
22
LED bar
You can install the unit in hanging or standing position. When in use, the device must always
be attached to a solid surface or an approved truss.
Always work from a stable platform whenever installing, moving or servicing the unit. In doing
so, the area underneath the unit must be cordoned o.
The safety cable must be threaded through one of the mounting brackets.
Please note that this device must not be connected to a dimmer.
Installation
Inserting batteries into the
remote
Push the lock of the battery holder towards the centre of the housing and pull out the battery
holder like a drawer. Insert the batteries in the correct polarity according to the marking on the
remote. Slide the battery holder back into the remote until it clicks into place.
When shipping, the batteries are already installed in the remote and protected against dis‐
charge by a transparent plastic lm. Remove the plastic lm before initial use.
BAT.PAR 8 RGBW
LED bar
23
Starting up
5 Starting up
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
BAT.PAR 8 RGBW
24
LED bar
Starting up
Connections in DMX mode
Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the rst DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼ W).
BAT.PAR 8 RGBW
LED bar
25
Starting up
DMX indicator
Connections in master/slave
mode
When the device and the DMX controller are operational, the DMX indicator in the display
shows that a DMX signal is being received on the input.
When you congure a group of devices in master/slave mode, the rst unit will control the
other units for an automatic, sound-activated, synchronized show. This function is ideal when
you want to start a show immediately. Connect the DMX output of the master device to the
DMX input of the rst slave device. Then connect the DMX output of the rst slave device to
the DMX input of the second slave device and so on.
BAT.PAR 8 RGBW
26
LED bar
6 Connections and controls
Front panel
Connections and controls
BAT.PAR 8 RGBW
LED bar
27
Connections and controls
1 Locking screw
2 Retaining bracket
3 Sensor for IR remote control
BAT.PAR 8 RGBW
28
LED bar
Rear panel
Connections and controls
BAT.PAR 8 RGBW
LED bar
29
Connections and controls
1 Locking screw
2 Retaining bracket
4 Rechargeable battery slot
When inserting the battery, always make sure that the battery snaps in correctly. To remove the battery, press the
two side buttons on the battery.
5 Connection socket for the 15 V power supply unit
6 [BATTERY INDICATOR]
Remaining battery capacity display.
n All LEDs light up: Charging is complete, all inserted batteries are fully charged.
n LEDs ash from left to right: Charging.
7 Display and function buttons.
8 [DMX IN]
DMX input.
BAT.PAR 8 RGBW
30
LED bar
9 [DMX OUT]
DMX output
10 [SWITCH] [ON], [OFF]
Main switch. Turns the device on and o.
Connections and controls
BAT.PAR 8 RGBW
LED bar
31
Connections and controls
Display and function buttons.
11 Display
12 [MENU]
Calls up the main menu and exits an opened submenu.
13 [UP]
Toggles between the menu items of a menu level, increases the displayed value by
one.
14 [DOWN]
Toggles between the menu items of a menu level, decreases the displayed value by
one.
15 [ENTER]
Selects an option of the respective operating mode, conrms the set value.
BAT.PAR 8 RGBW
32
LED bar
Remote control
Connections and controls
BAT.PAR 8 RGBW
LED bar
33
Connections and controls
16 On / o switch
17 [DMX]
Activates DMX mode. Then you can enter the DMX address with the number buttons
18 [SLAVE]
Activates master / slave mode
19 [SPEED]
Setting the running speed
20 [UP], [DOWN]
Selecting a programme of number. [UP] increases the displayed value or scrolls forward. [DOWN] decreases the dis‐
played value or scrolls back.
BAT.PAR 8 RGBW
34
LED bar
Connections and controls
21 [0…9]
Selecting a programme number
[R], [G], [B], [W], [A], [P]
Selecting a colour. [R], [G] or [B] for primary colours red, green and blue. Use the buttons to turn the respective colour
on or o. When the colour appears in the display of the device, you can adjust its intensity with [UP] or [DOWN] in the
range from 0 to 255.
22 [STROBE]
Activates the strobe eect
[UP] or [DOWN] changes the ash rate.
23 [SOUND 1], [SOUND 2]
Selection of music control programs 1 or 2. [UP] or [DOWN] changes the sensitivity of the built-in microphone.
24 [AUTO 1], [AUTO 2]
Selection of auto programmes 1 or 2. [UP] or [DOWN] changes the running speed of the selected music programme.
BAT.PAR 8 RGBW
LED bar
35
Operating
7 Operating
7.1 Starting the device
7.2 Operating on the unit
Menu control
Connect the device to the mains or insert a charged battery.
Turn on the power using the main switch. The display shows the current operation mode.
1. Press [MENU] to open the main menu or to return to the main menu.
2. Use [UP] or [DOWN] to select the desired submenu, parameter or value.
3. Conrm the selection with [ENTER].
The selected submenu opens up or the selected value is being accepted.
ð
BAT.PAR 8 RGBW
36
LED bar
To return to the next higher menu level without changes, press [MENU].
Operating
DMX address
Operating mode Auto
Use ‘Address’ to select the start address channel for the DMX address.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘Address’ .
2. Conrm the selection with [ENTER].
3. Use [UP] or [DOWN] to select the desired start address from 1 to 512.
4. Conrm the selection with [ENTER].
The selected start address is accepted. When a DMX signal is present, ‘*’ appears
ð
behind the DMX address.
Make sure that this number matches the conguration of your DMX controller.
Use ‘AUTO’ to select six automatic programmes and set a running speed.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘AUTO’ .
2. Conrm the selection with [ENTER].
BAT.PAR 8 RGBW
LED bar
37
Operating
3. Use [UP] or [DOWN] to select the desired automatic programme; display shows ‘AUTO
1…AUTO 6’ .
4. Conrm the selection with [ENTER].
5. Use [UP] or [DOWN] to select the desired running speed; display shows ‘SP1…SP9’ .
6. Conrm the selection with [ENTER].
The selected setting is accepted.
ð
Sound control
BAT.PAR 8 RGBW
38
LED bar
Use ‘Sound’ to select four music control programmes and adjust the microphone sensitivity.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘Sound’ .
2. Conrm the selection with [ENTER].
3. Use [UP] or [DOWN] to select the desired music control programme; display shows
‘Sound 1…Sound 4’ .
4. Conrm the selection with [ENTER].
5. Use [UP] or [DOWN] to select the desired sensitivity of the built-in microphone for music
control between 0 (low sensitivity) and 9 (high sensitivity); display shows ‘SEN 0…SEN 9’ .
6. Conrm the selection with [ENTER].
The selected setting is accepted.
ð
Operating
Constant colour
Dimmer and stroboscope
Use ‘Colour’ to select a pre-set colour.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘Colour’ .
2. Conrm the selection with [ENTER].
3. Use [UP] or [DOWN] to select the desired colour; display shows ‘Colour1…Colour51’ .
4. Conrm the selection with [ENTER].
The selected setting is accepted.
ð
Use ‘STAT’ to adjust the red, green, blue, and white dimmer function, as well as the strobe
speed.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘STAT’ .
2. Conrm the selection with [ENTER].
BAT.PAR 8 RGBW
LED bar
39
Operating
3. Use [UP] or [DOWN] to select the desired colour and intensity of the dimmer as well as
the strobe speed.
Value Function
R000…R255 Intensity red –100 %
G000…G255 Intensity green 0 –100 %
B000…B255 Intensity blue 0 –100 %
W000…W255 Intensity white 0 –100 %
ST 0…ST 9 Strobe speed slow to fast
4. Conrm the selection with [ENTER].
The selected setting is accepted.
ð
DMX mode
BAT.PAR 8 RGBW
40
LED bar
Use ‘Channel’ to select the DMX mode.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘Channel’ .
2. Conrm the selection with [ENTER].
3. Use [UP] or [DOWN] to select the desired DMX mode.
n ‘4Ch’ (4 channels)
n ‘7Ch’ (7 channels)
n ‘11Ch’ (11 channels)
n ‘16Ch’ (16 channels)
n ‘19Ch’ (19 channels)
4. Conrm the selection with [ENTER].
The selected setting is accepted.
ð
Operating
Software version
Device temperature
Use ‘Version’ to display the software version.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘Version’ .
2. Conrm the selection with [ENTER].
The currently installed software version is displayed.
ð
Use ‘TEMP’ to display the device temperature.
BAT.PAR 8 RGBW
LED bar
41
Operating
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘TEMP’ .
2. Conrm the selection with [ENTER].
The device temperature. is displayed.
ð
Master / slave mode
BAT.PAR 8 RGBW
42
LED bar
Use ‘Slave’ to activate the Slave mode.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘Slave’ .
2. Conrm the selection with [ENTER].
The device now operates in slave mode and applies all settings of the master device.
ð
7.3 IR remote control
Operating
Remote control
Use ‘REMO’ to activate or deactivate the remote control.
1. Press [MENU] and use [UP] or [DOWN] to select the submenu ‘REMO’ .
2. Conrm the selection with [ENTER].
3. Use [UP] or [DOWN] to select ‘ON’ to activate the remote control or ‘OFF’ to deactivate
the remote control.
4. Conrm the selection with [ENTER].
The selected setting is accepted.
ð
BAT.PAR 8 RGBW
LED bar
43
Operating
7.4 Menu overview
BAT.PAR 8 RGBW
44
LED bar
7.5 Functions in 4-channel DMX mode
Channel Value Function
1 0…255 Intensity red (0 % to 100 %)
2 0…255 Intensity green (0 % to 100 %)
3 0…255 Intensity blue (0 % to 100 %)
4 0…255 Intensity white (0 % to 100 %)
7.6 Functions in 7-channel DMX mode
Channel Value Function
1 0…255 0 = O
1…255 = Master dimmer
Operating
2 0…7 No function
BAT.PAR 8 RGBW
LED bar
45
Operating
Channel Value Function
8…15 Scene mode 1
16…23 Scene mode 2
24…31 Scene mode 3
32…39 Scene mode 4
40…47 Scene mode 5
48…55 Colour change 1
56…63 Colour change 2
64…71 Colour change 3
72…79 Colour change 4
80…87 Colour change 5
88…95 Colour change 6
96…103 Automatic programme 1
BAT.PAR 8 RGBW
46
LED bar
104…111 Automatic programme 2
Channel Value Function
112…119 Automatic programme 3
120…127 Automatic programme 4
128…135 Automatic programme 5
136…143 Automatic programme 6
144…175 Automatic programme 7
176…183 Automatic programme 8
184…191 Automatic programme 9
192…199 Automatic programme 10
200…207 Automatic programme 11
208…215 Automatic programme 12
216…223 Automatic programme 13
224…231 Automatic programme 14
Operating
232…239 Automatic programme 15
BAT.PAR 8 RGBW
LED bar
47
Operating
Channel Value Function
240…247 Music control programme 1
248…255 Music control programme 2
3 0…255 Speed of the selected eect or strobe speed (slow to fast)
4 0…255 Intensity red (0 % to 100 %)
5 0…255 Intensity green (0 % to 100 %)
6 0…255 Intensity blue (0 % to 100 %)
7 0…255 Intensity white (0 % to 100 %)
BAT.PAR 8 RGBW
48
LED bar
7.7 Functions in 11-channel DMX mode
Channel Value Function
1 0…255 0 = O
1…255 = Master dimmer
2 0…7 No function
8…15 Scene mode 1
16…23 Scene mode 2
24…31 Scene mode 3
32…39 Scene mode 4
40…47 Scene mode 5
48…55 Colour change 1
56…63 Colour change 2
64…71 Colour change 3
Operating
BAT.PAR 8 RGBW
LED bar
49
Operating
Channel Value Function
72…79 Colour change 4
80…87 Colour change 5
88…95 Colour change 6
96…103 Automatic programme 1
104…111 Automatic programme 2
112…119 Automatic programme 3
120…127 Automatic programme 4
128…135 Automatic programme 5
136…143 Automatic programme 6
144…175 Automatic programme 7
176…183 Automatic programme 8
184…191 Automatic programme 9
BAT.PAR 8 RGBW
50
LED bar
192…199 Automatic programme 10
Channel Value Function
200…207 Automatic programme 11
208…215 Automatic programme 12
216…223 Automatic programme 13
224…231 Automatic programme 14
232…239 Automatic programme 15
240…247 Music control programme 1
248…255 Music control programme 2
3 0…255 Speed of the selected eect or strobe speed (slow to fast)
4 0…255 Intensity red (0 % to 100 %)
5 0…255 Intensity green (0 % to 100 %)
6 0…255 Intensity blue (0 % to 100 %)
7 0…255 Intensity white (0 % to 100 %)
Operating
8 0…255 Intensity red (0 % to 100 %)
BAT.PAR 8 RGBW
LED bar
51
Operating
Channel Value Function
9 0…255 Intensity green (0 % to 100 %)
10 0…255 Intensity blue (0 % to 100 %)
11 0…255 Intensity white (0 % to 100 %)
7.8 Functions in 16-channel DMX mode
Channel Value Function
1 0…255 Intensity red (0 % to 100 %)
2 0…255 Intensity green (0 % to 100 %)
3 0…255 Intensity blue (0 % to 100 %)
4 0…255 Intensity white (0 % to 100 %)
5 0…255 Intensity red (0 % to 100 %)
BAT.PAR 8 RGBW
52
LED bar
Channel Value Function
6 0…255 Intensity green (0 % to 100 %)
7 0…255 Intensity blue (0 % to 100 %)
8 0…255 Intensity white (0 % to 100 %)
9 0…255 Intensity red (0 % to 100 %)
10 0…255 Intensity green (0 % to 100 %)
11 0…255 Intensity blue (0 % to 100 %)
12 0…255 Intensity white (0 % to 100 %)
13 0…255 Intensity red (0 % to 100 %)
14 0…255 Intensity green (0 % to 100 %)
15 0…255 Intensity blue (0 % to 100 %)
16 0…255 Intensity white (0 % to 100 %)
Operating
BAT.PAR 8 RGBW
LED bar
53
Operating
7.9 Functions in 19-channel DMX mode
Channel Value Function
1 0…255 0 = O
1…255 = Master dimmer
2 0…7 No function
8…15 Scene mode 1
16…23 Scene mode 2
24…31 Scene mode 3
32…39 Scene mode 4
40…47 Scene mode 5
48…55 Colour change 1
56…63 Colour change 2
64…71 Colour change 3
BAT.PAR 8 RGBW
54
LED bar
Channel Value Function
72…79 Colour change 4
80…87 Colour change 5
88…95 Colour change 6
96…103 Automatic programme 1
104…111 Automatic programme 2
112…119 Automatic programme 3
120…127 Automatic programme 4
128…135 Automatic programme 5
136…143 Automatic programme 6
144…175 Automatic programme 7
176…183 Automatic programme 8
184…191 Automatic programme 9
Operating
192…199 Automatic programme 10
BAT.PAR 8 RGBW
LED bar
55
Operating
Channel Value Function
200…207 Automatic programme 11
208…215 Automatic programme 12
216…223 Automatic programme 13
224…231 Automatic programme 14
232…239 Automatic programme 15
240…247 Music control programme 1
248…255 Music control programme 2
3 0…255 Speed of the selected eect or strobe speed (slow to fast)
4 0…255 Intensity red (0 % to 100 %)
5 0…255 Intensity green (0 % to 100 %)
6 0…255 Intensity blue (0 % to 100 %)
7 0…255 Intensity white (0 % to 100 %)
8 0…255 Intensity red (0 % to 100 %)
BAT.PAR 8 RGBW
56
LED bar
Channel Value Function
9 0…255 Intensity green (0 % to 100 %)
10 0…255 Intensity blue (0 % to 100 %)
11 0…255 Intensity white (0 % to 100 %)
12 0…255 Intensity red (0 % to 100 %)
13 0…255 Intensity green (0 % to 100 %)
14 0…255 Intensity blue (0 % to 100 %)
15 0…255 Intensity white (0 % to 100 %)
16 0…255 Intensity red (0 % to 100 %)
17 0…255 Intensity green (0 % to 100 %)
18 0…255 Intensity blue (0 % to 100 %)
19 0…255 Intensity white (0 % to 100 %)
Operating
BAT.PAR 8 RGBW
LED bar
57
Operating
7.10 Charging the battery
You can charge the batteries while using the device. A maximum of two batteries can be
charged at the same time. Do not remove the batteries until charging is complete.
1. Insert the batteries in the slots provided.
2. Connect the device to the power grid.
Charging starts and the charge indicator ashes from left to right. When the charge
ð
indicator lights steadily, charging is complete.
3. You can remove the batteries when they are fully charged. Press the two push-buttons
on the side of the battery to release the battery from the slot.
During charging, the unit can be turned on and o with the main power switch.
BAT.PAR 8 RGBW
58
LED bar
8 Technical specications
Light source 8 × RGBW LED, 8 W
Optical properties Beam angle 30°
Control DMX
Control protocol DMX 512
Number of DMX channels 4, 7, 11, 16, or 19, depending on operating mode
Input connections Power supply Connection socket
Output connections DMX control XLR chassis socket, 3-pin
Power consumption 64 W
Technical specications
Infrared remote control
DMX control XLR chassis socket, 3-pin
Power supply
Power adapter (15 V / 5 A, centre positive)
BAT.PAR 8 RGBW
LED bar
59
Technical specications
Battery Battery type Lithium-ion
Replaceable rechargeable
battery packs, item no.
385488)
Voltage 10.8 V
Capacity 1500 mAh mAh
Battery remote control Battery type 2 × button cells, LR1130/
AG10, 1.5 V
Degree of protection IP20
Mounting options Standing, hanging
Dimensions (W × H × D) 560.5 mm × 100 mm × 168.5 mm
Weight 1.9 kg
Ambient conditions Temperature range 0 °C…40 °C
Relative humidity 50 %, non condensing
BAT.PAR 8 RGBW
60
LED bar
Further information
Design LED Bar
Number of LEDs 240
Colour mixture RGB
LED type Unicoloured LEDs
Base housing Yes
Fanless Yes
Remote control Included
Wireless DMX No
Housing colour Black
Technical specications
BAT.PAR 8 RGBW
LED bar
61
Plug and connection assignments
9 Plug and connection assignments
Introduction
DMX connections
This chapter will help you select the right cables and plugs to connect your valuable equip‐
ment so that a perfect light experience is guaranteed.
Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug
ts into a socket, the result of an incorrect connection may be a destroyed DMX controller, a
short circuit or ‘just’ a not working light show!
The unit oers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please
refer to the drawing and table below for the pin assignment of a suitable XLR plug.
Pin Conguration
1 Ground, shielding
2 Signal inverted (DMX–, ‘cold signal’)
3 Signal (DMX+, ‘hot signal’)
BAT.PAR 8 RGBW
62
LED bar
10 Troubleshooting
In the following we list a few common problems that may occur during operation. We give you
some suggestions for easy troubleshooting:
Troubleshooting
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
BAT.PAR 8 RGBW
LED bar
63
Troubleshooting
Symptom Remedy
The unit does not work, no light Check the mains connection.
If the device is to be operated independently from the
mains power supply, check the charge status of the bat‐
tery pack.
BAT.PAR 8 RGBW
64
LED bar
Apparently no function despite
proper power supply
No response to the DMX con‐
troller
Check if the unit is in DMX mode or in ‘slave’ mode. If so,
check the unit in another mode.
1. Check whether the DMX controller is switched on.
Check the DMX connectors and cables for proper con‐
nection.
2. Check the address settings and the DMX polarity.
3. Try using another DMX controller.
Troubleshooting
Symptom Remedy
4. If the device is to be controlled wirelessly via DMX,
check whether the module is activated in the menu. If
so, nd a better DMX antenna orientation.
5. Check whether the DMX cables run near or parallel to
high-voltage cables that may cause damage or interfer‐
ence to a DMX interface circuit.
If the procedures recommended above do not succeed, please contact our Service Center. You
can nd the contact information at www.thomann.de.
BAT.PAR 8 RGBW
LED bar
65
Cleaning
11 Cleaning
Optical lenses
Fan grids
Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the
light output. The frequency of cleaning depends on the operating environment: wet, smoky or
particularly dirty surroundings can cause more accumulation of dirt on the optics of the
device.
n Clean with a soft cloth using our lamp and lens cleaner (item no. 280122).
n Always dry the parts carefully.
The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐
ular basis. Before cleaning, switch o the device and disconnect mains-operated devices from
the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit
with a slightly damp lint-free cloth.
BAT.PAR 8 RGBW
66
LED bar
12 Protecting the environment
Disposal of the packaging mate‐
rial
For the packaging, environmentally friendly materials have been chosen that can be supplied
to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
Disposal of batteries
Batteries do contain some hazardous chemicals so they should not be thrown away with the
normal household waste. They should be returned to the manufacturer for disposal or recycled
elsewhere in accordance with your local regulations.
Remove lithium batteries from the device before disposal. Protect used lithium batteries
against short circuit, for example by taping the poles.
Protecting the environment
BAT.PAR 8 RGBW
LED bar
67
Protecting the environment
Disposal of your old device
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE) in its currently valid version. Do not dispose with your normal household waste.
Dispose of this device through an approved waste disposal rm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
