Vari Lite VL2416 User Manual

VL2416™

Wash Luminaire

User’s Manual

02.9661.0001

VARI❋LITE - VL2416™ WASH LUMINAIRE USER’S MANUAL

VARI❋LITE®, Artisan®, VL2® and VLD® are trademarks owned by Vari-Lite, Inc., 201 Regal Row, Dallas TX 75247 USA
and are registered in the United States and other countries.

VL2000™, VL2200™ (and the individual product designations), VL2400™ (and the individual product designations), Series
2000™ (and the individual product designations), Series 300™, Virtuoso™ and the Vari-Lite As ter isk are also trademark s

owned by Vari-Lite, Inc.
VARI❋LITE® products are protected by one or more of the following patents, and other pending patent applications worldwide:
US Patents No. 5,959,758; 5,7 28,994; 5,590,954;5,367,444; 5,329,431; 5,209,560; 5,186,536; 5,073,847; 5,010,459; 4,980,806 ;

4,602,321; 4,392,187; U.S. Desig n Pat e nts No. 366,712; 359,574;
Australia Patents No. 703868 ; 693 691; 683695; 667109; 657152; 649264; 646588; 618559; 586095; 576400; 575271; 546433;

Australia Design Reg. No. 126781;
German Patents No. (DBP) 693 14122.0; 69208615.3; 69207692.1; 69121029.2; 3768727.1; 3750201.8; 3587270.5; 3279888.1;

3274291.6; DGM G9312884; DGM 9407689.8;
European Patents No. 0586049 (FR, G B); 0547732 (BE, DK, FR, GB); 0534710 (BE, FR, GB); 0474202 (BE , DK, FR, GB);

0253082 (BE, FR, GB); 0253081 (BE, FR, GB); 0192882 (BE, FR, GB); 0140994 (BE, FR, GB); 006 006 8 (BE, FR, GB);
France Design Reg. No. 335132 - 33514 7;
Spain Patents No. 2090191; 2084289; 2082384; 2058071; 2020960; 0548328; Spain Ut ilit y Model No. 2031748; Spain Design

Reg. No. 129596;
Japan Patents No. 2,059,669; 2,055,324; 2,002,168; 1,889,481; 1,770,241; 1,723,825; 1,683,007; 1,553,011; KR 206051; 181180;

76310; 47673; Japan Design Reg. N o. 9475 52; 945436-1; 945436;
Korean Design Reg. No. 175178;
Mexico Patents No. 180148; 179138;
Taiwan Patents No. 78726; 66975; 65380; 63471; 40611; 28275;
United Kingdom Design Reg. No. 20 42174; 2033108; 2029499.

All other brand or product na m es wh i ch ma y be mentioned in this manual are trademarks or registered trademarks of their
respective companies or organizations.

VL2416™ Wash Luminaire User’s Manual
The informa tion furnished in thi s manual is for informational use only and is subject to change witho ut notice. Vari-Lite, In c.

assumes no responsibility or liabi lity for any errors or inaccuracies that may appe ar i n thi s ma nual. All information and graphic
representations are property of Vari-Lite, Inc. 201 Regal Row, Dallas, Texas 75247 USA.

Version as of: 22-Feb-02

Printed in th e USA.

Part number: 02.9661.000 1J

VL2416™ Wash Luminaire User’s Manual

© 2000-2002 Vari-Lite, Inc. All Rights Reserved.

ii 22-Feb-02 02.9661.0001J

HOW TO OBTAIN WARRANTY SERVICE

How To Obtain Warranty Service

A copy of the Vari-Lite, Inc. Limited Warranty was included in the shipping package
for this VARI❋LITE® product.

To obtain warranty service, please contact customer service at 1-877-VARI-LITE
(1-877-827-4548) or [e-mail] and request a Return Material
Authorization (RMA) for warranty service. You need to provide the model and serial
number of the item being returned, a description of the problem or failure and the
name of the registered user or organization. If available, you should have your sales
invoice to establish the date of sale as the beginning of the warranty period.

Once you obtain the RMA, pack the product in its original packing material along with
a copy of your invoice (if available) and write the RMA number legibly on or near the
shipping address label. Return the unit, freight prepaid to:

Vari-Lite, Inc.
201 Regal Row
Dallas, TX 75247
Attention: Warranty Service

As stated in the warranty, it is required that the shipment be insured and FOB our
service center.

02.9661.0001J 22-Feb-02 iii

VARI❋LITE - VL2416™ WASH LUMINAIRE USER’S MANUAL

Compliance Notice

FCC

This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when this equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with Vari-Lite system,
service, and safety guidelines, may cause harmful interference to radio communica­tions. Operation of this equipment in a residential area is likely to cause harmful inter­ference, in which case the user will be required to correct the interference at his/her
own expense.

Declaration of Conformity

We declare, under our sole responsibility, that this product complies with the relevant
clauses of the following standards and harmonized documents:

Safety

EN 60598-1:1997 Luminaire Safety Standard, General Requirements
EN 60598-2 17:1989 Specification for Luminaires for Stage and Studio Li ghting

EMC

EN 55022A:1994 Radiated and Conducted Emissions
EN 50082-1:1997 Generic Immunity Standard

We certify that the product conforms to the protection requirements of council direc­tives: 73/23/EEC (LVD) and 89/336/EEC (EMC)

iv 22-Feb-02 02.9661.0001J

SAFETY NOTICE

Safety Notice

It is extremely important to read ALL safety information and instructions provided in
this manual and any accompanying documentation before installing and operating the
products described herein. Heed all cautions and warnings during installation and use
of this product.

Safety symbols used throughout this manual are as follows:

CAUTION advising of potential damage to product.

WARNING advising of potential injury or death to persons.

GENERAL INFORMATION PERTAINING TO PROTECTION AGAINST ELEC­TRICAL SHOCK, FIRE, EXPOSURE TO EXCESSIVE UV RADIATION, AND
INJURY TO PERSONS CAN BE FOUND BELOW.

WARNING:
INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST FIRE

1. VARI❋LITE® luminaires have been designed for use only with certain Philips and

Osram HID lamps. Note lamp type (MSR400, MSR575HR etc.) before replacing lamps.
Installing another type of lamp may be hazardous.

2. Luminaires may be mounted on any type of surface as long as mounting instructions are
followed. See instructions detailed in this manual.

3. Replace fuses with same type and rating only.

4. Note distance requirement from combustible materials or illuminated objects for
VARI❋LITE® luminaires.

WARNING:
INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST ELECTRICAL
SHOCK

1. VARI❋LITE® luminaires are designed for dry locations only. Exposure to rain or
moisture may damage luminaire.

2. Disconnect power before servicing any VARI❋LITE® equipment.

3. Servicing to be performed by qualified personnel only.

02.9661.0001J 22-Feb-02 v

VARI❋LITE - VL2416™ WASH LUMINAIRE USER’S MANUAL

WARNING:
INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST EXCESSIVE
EXPOSURE TO UV RADIATION

1. Many VARI❋LITE® luminaires use an HID type lamp that produces UV radiation. DO

NOT look directly at lamp.

2. It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet
screens shall be changed if the y have become vis ibly damaged to such an extent that their
effectiveness is impaired. For example, by cracks or deep scratches.

WARNING:
INSTRUCTIONS FOR PROTECTION AGAINST INJURY TO PERSONS

1. Exterior surfaces of the luminaire will be hot during operation. Use appropriate safety
equipment (gloves, eye protection, etc.) when handling and adjusting hot equipment and
components.

2. Luminaires will have a hot lamp when operating. Disconnect power and allow lamp to
cool before replacing.

3. Arc lamps emit ultraviolet radiation which can cause serious skin burn and eye
inflammation. Additionally, arc lamps operate under high pressure at very high
temperatures. Should the lamp break, there can exist a danger of personal injury and/or
fire from broken lamp particles being discharged.

4. Wear eye protection when relamping.

5. Appropriate safety equipment (gloves, eye protection) should be used when handling
damaged lamps.

6. If lamp is touched with bare hands, clean lamp with denatured alcohol and wipe with lint­free cloth before installing or powering up the luminaire.

7. The lamp shall be changed if it has become damaged or thermally deformed.

WARNING:
RF INTERFERENCE

1. This is a Class A product. In a domestic environment this product may cause radio
interferen ce, in which case, the user may be required to take adequate meas ures.

ARC LAMP CHARACTERISTIC CONSIDERATIONS

1. Arc lamps require a pe ri od of time to relight aft er a p ower interruption or a severe voltage
dip. In some cases, lamp will auto matica lly rel ight after it ha s cooled dependi ng on Lamp
Power-Up State (L ON/ LOFF) system configuration setting.

2. Burning position is Universal.

vi 22-Feb-02 02.9661.0001J

SICHERHEITSHINWEISE

Sicherheitshinweise

Es ist äußerst wichtig, ALLE Sicherheitsinformationen und -hinweise in diesem
Handbuch und dem beiliegenden Informationsmaterial zu lesen, bevor Sie die hierin
beschriebenen Produkte installieren bzw. bedienen. Halten Sie bei der Installation und
dem Einsatz dieses Produkts alle Warnhinweise und Vorsichtsmaßnahmen ein.

Folgende Sicherheitssymbole werden in diesem Handbuch verwendet:

VORSICHT - weist auf möglichen Produktschaden hin.

WARNUNG - weist auf mögliche Körperverletzung und

Lebensbedrohung hin.

NACHSTEHEND FINDEN SIE ALLGEMEINE HINWEISE ÜBER SICHER­HEITSVORKEHRUNGEN GEGEN ELEKTROSCHOCK, FEUER, ÜBERHÖHTE
UV-STRAHLUNG UND KÖRPERVERLETZUNGEN.

WARNUNG:
HINWEISE ZUM FEUERSCHUTZ

1. VARI❋LITE®-Scheinwerfer sind ausschließlich für den Einsatz mit bestimmten Philips

und Osram HID-Lampen geeignet. Achten Sie auf den Lampentyp (MSR400,
MSR575HR etc.), bevor Sie die jeweiligen Lampen ersetzen. Die Installation eines
anderen Lampentyps kann gefährlich sein.

2. Scheinwerfer können auf jeder beliebigen Oberfläche montiert werden, solange Sie die

Montageanweisungen befolgen. Detaillierte Hinweise finden Sie in diesem Handbuch.

3. Ersetzen Sie Sicherungen nur mit Sicherungen vom gleichen Typ und gleicher Stärke.

4. Beachten Sie die Einhaltung des erforderlichen Sicherheitsabstandes der VARI❋LITE®-

Scheinwerfer von brennbarem Material oder beleuchteten Objekten.

WARNUNG:
HINWEISE ZUM SCHUTZ GEGEN ELEKTROSCHOCK

1. VARI❋LITE®-Scheinwerfer eignen sich ausschließlich für trockene Standorte. Regen

oder Feuchtigkeit können die Scheinwerfer beschädigen.

2. Unterbrechen Sie die Stromzufuhr, bevor Sie mit der Arbeit an VARI❋LITE®-Geräten

beginnen.

3. Die Geräte sollten nur von qualifiziertem Personal gewartet werden.

02.9661.0001J 22-Feb-02 vii

VARI❋LITE - VL2416™ WASH LUMINAIRE USER’S MANUAL

WARNUNG:
HINWEISE ZUM SCHUTZ GEGEN ÜBERHÖHTE UV-STRAHLUNG

1. Viele VARI❋LITE®-Scheinwerfer verwenden einen HID-Lampentyp, der UV-Strahlen
abgibt. SCHAUEN SIE NICHT direkt in die Lampe.

2. Es ist gefährlich, Leuchten ohne Linsen oder Blenden zu bedienen. Blenden, Linsen oder
Ultraviolettschirme müssen ausgetauscht werden, sofern deren Schutzwirkung durch
sichtbare Beschädigung (z. B. Sprünge oder Schrammen) eingeschränkt ist.

WARNUNG:
HINWEISE ZUM SCHUTZ GEGEN KÖRPERVERLETZUNGEN

1. Bei Betrieb sind die Außenflächen der Scheinwerfer heiß. Verwenden Sie bei der
Bedienung von aufgeheizter Apparatur die jeweils geeignete Sicherheitsausrüstung
(Handschuhe, Augenschutz etc.).

2. Bei Betrieb der Scheinwerfer ist die Lampe heiß. Unterbrechen Sie die Stromzufuhr und
lassen Sie die Lampe abkühlen, wenn Sie diese austauschen.

3. Bogenlampen senden ultraviolette Strahlen aus, die Hautverbrennungen und
Augenentzündungen verursachen können. Der Betrieb von Bogenlampen erfolgt unter
Hochdruck und bei hohen Temperaturen. Sollte d ie Lampe ze rbr echen, besteht die Gef ahr
von Körperverletzung bzw. von Feuer, das von Lampenteilen ausgelöst werden kann.

4. Tragen Sie beim Austausch der Lampen einen Augenschutz.

5. Die geeignete Siche rheitsausr üstung (Han dschuhe, Augenschu tz) sollte beim Umgang mi t
beschädigten Lampen verwendet werden.

6. Wenn die Lampe mit bloßen Händen berührt wird, reinigen Sie sie mit denaturiertem
Alkohol und einem flusenfreien Tuch, bevor Sie die Scheinwerfer installieren oder in
Betrieb nehmen.

7. Wenn die Lampe beschädigt oder durch Hitzeeinwirkung deformiert ist, muß diese
ausgetaus cht werden.

WARNUNG:
HF-INTERFERENZ

1. Es handelt sich um ein Produkt der Klasse A. In einer Wohnumgebung kann das Produkt
Hochfrequenzstörungen verursachen. In diesem Fall müssen eventuell geeignete
Maßnahmen getroffen werden.

BESONDERHEITEN VON BOGENLAMPEN

1. Bogenlampen benötigen eine gewisse Zeitdauer, um nach einem Stromausfall oder einem
Spannungsgefälle wieder aufzuleuchten. In einigen Fällen wird die Lampe nach
Abkühlung automatisch wieder aufleuchten, je nach der Systemkonfigurationseinstellung
des Lampeneinschaltungsstatus (L ON/ LOFF).

2. Die Brennposition ist Universa l.

viii 22-Feb-02 02.9661.0001J

NOTES DE SÉCURITÉ

Notes de sécurité

A vant de procéder à l’installation des produits décrits dans ce guide et de les mettre en
marche, il est extrêmement important de lire TOUS les renseignements et TOUTES
les directives de sécurité contenues dans ce guide ainsi que toute documentation jointe.
Tenir compte de tous les avertissements et suivre toutes les précautions pendant
l’installation et l’utilisation de cet appareil.

Les symboles de sécurité utilisés dans ce guide sont les suivants :

ATTENTION Ce symbole annonce que l’appareil risque
d’être endommagé.

AVERTISSEMENT Ce symbole annonce qu’il y a risque
d’accident grave ou même fatal.

CETTE SECTION CONTIENT DES INFORMATIONS GÉNÉRALES POUR SE
PROTÉGER CONTRE LES DÉCHARGES ÉLECTRIQUES , LES INCENDIES,
L’EXPOSITION EXCESSIVE AUX RAYONS UV ET TOUT AUTRE ACCIDENT
POUVANT ENTRAÎNER DES BLESSURES.

AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE LES INCENDIES

1. Les luminaires VARI❋LITE® o nt é té conçus pour être uti li sés uni que me nt ave c c ert aines

lampes Philips et Osram HID. Vérifier le type de lampe (MSR400, MSR575HR etc.)
avant de remplacer les lampes. L’installation d’un autre type de lampe peut poser un
danger.

2. Les luminaires peuvent être fixés sur tout type de surface tant que les directives de

montage sont respectées. Voir les explications détaillées dans ce guide.

3. Ne remplacer les fusibles qu’avec ceux du même type, ayant les mêmes caractéristiques.

4. Vérifier la distance à respecter entre les matériaux combustibles ou les objets illuminés et

les luminaires VARI❋LITE®.

AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE LES DÉCHARGES ÉLECTRIQUES

1. Les luminaires VARI❋LITE® sont conçus pour une utilisation au sec uniquement. Une

exposition à la pluie et à l’humidité risque d’endommager le luminaire.

2. Débrancher l’appareil avant de procéder à la révision de tout matériel VARI❋LITE®.

3. Les révisions doivent être effectuées uniquement par des personnes qualifiées.

02.9661.0001J 22-Feb-02 ix

VARI❋LITE - VL2416™ WASH LUMINAIRE USER’S MANUAL

AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE UNE EXPOSITION EXCESSIVE
AUX RAYONS UV

1. Plusieurs luminaires VARI❋LITE® utilisent une lampe de type HID qui produit des
rayons UV. NE PAS fixer son regard sur la lampe.

2. L’utilisation des luminaires sans lentille ou blindage pose des risques. Tous blindages,
lentilles ou écrans ultraviolet visiblement endommagés au point que leur efficacité en est
affectée doivent être remplacés, par exemple s’il y a des fissures ou de profondes rayures.

AVERTISSEMENT:
DIRECTIVES POUR SE PROTÉGER CONTRE LES ACCIDENTS POUVANT
ENTRAÎNER DES BLESSURES

1. Les surfaces externes du luminaire deviennent brûlantes quand l’appareil est en marche.
Pour manœuvrer ou ajuster des appareils brûlants et leurs composants, se protéger
suffisamment (gants, protection pour les yeux, etc.).

2. La lampe du luminaire est brûlante lorqu’il est en marche. Débrancher le courant et
attendre que la lampe ait refroidi avant de la remplacer.

3. Les lampes à arc émettent des rayons ultraviolets pouva nt caus er de graves brûlures sur la
peau et une inflammation des yeux. De plus, les lampes à arc fonctionnent sous haute
tension à de très hautes températures. Si la lampe se casse, les particules de la lampe
cassée peuvent causer blessures et/ou incendie en s’éparpillant.

4. Se protéger les yeux pour remplacer la lampe.

5. Utiliser des appareils de protection appropriés (gants, protection des yeux) pour manier
des lampes endommagées.

6. Si la lampe a été touchée avec des mains nues, la nettoyer avec de l’alcool dénaturé et
l’essuyer avec un chiffon non-pelucheux avant d’installer ou de brancher le luminaire.

7. Si la lampe a été endommagée ou a reçu une déformation thermique, elle doit être
remplacée.

AVERTISSEMENT:
INTERFÉRENCE RF

1. Cet appareil est d e Classe A. Dans un e nvironnemen t domest ique, ce t appareil peut caus er
des interférences radio, et si c’est le cas, l’utilisateur peut avoir à prendre des mesures
adéquates.

CONSIDÉRATIONS DES CARACTÉRISTIQUES DE LAMPES À ARC

1. Après une interruption de courant ou une baisse importante de voltage, les lampes à arc
mettent du temps avant de se rallumer. Dans certains cas, la lampe se rallumera
automatiquemet après s’êt re r efroi die. Cela dé pen d de l a mani ère do nt le s ystème est rég lé
pour le statut de mise en marche de la lampe (L ON/ LOFF).

2. La position Brûler est Universelle.

x 22-Feb-02 02.9661.0001J

AVISO SOBRE SEGURIDAD

Aviso sobre Seguridad

Es muy importante leer TODA la información e instrucciones sobre seguridad que se
indica en este manual así como en los documentos adjuntos antes de instalar y operar
los productos descritos. Se debe prestar atención a todos los avisos y advertencias
durante la instalación y uso de este producto.

Los símbolos de seguridad usados en este manual son los siguientes:

CUIDADO, indica posibles daños al producto.

ADVERTENCIA, indica posibles lesiones o muerte a las

personas.

LA INFORMACIÓN GENERAL RELACIONADA A LA PROTECCIÓN CON­TRAGOLPES DE CORRIENTE ELÉCTRICA, INCENDIO, EXPOSICIÓN
EXCESIVA A RADIACIÓN ULTRA VIOLETA Y LESIONES A LAS PERSONAS
SE PUEDE ENCONTRAR SEGUIDAMENTE:

ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA INCENDIO

1. Las luminarias VARI❋LITE® han sido diseñadas para ser usadas solamente con algunas

lámparas HID Philips y Osram. Tome nota del tipo de lámpara (MSR400, MSR575HR
etc.) antes de reemplazarla. Instalación de otro tipo de lámpara puede ser peligroso.

2. Las luminarias se pueden instalar en cualquier tipo de superficie siempre que se sigan las

instrucciones de instalación. Vea las instrucciones detalladas en este manual.

3. Reemplaze los fusibles solamente con los del mismo tipo y especificación.

4. Tome nota de los requerimientos de distancia de materiales combustibles u objetos

iluminados para las luminarias VARI❋LITE®.

ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA CHOQUE
ELÉCTRICO

1. Las luminarias VARI❋LITE® están diseñadas solamente para lugares secos. La

exposición a la lluvia o humedad pueden dañar la luminaria.

2. Desconecte la energía antes de dar servicio a cualquier equipo de VARI❋LITE®.

3. El servicio debe ser realizado solamente por personal calificado.

02.9661.0001J 22-Feb-02 xi

VARI❋LITE - VL2416™ WASH LUMINAIRE USER’S MANUAL

ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA LA EXPOSICIÓN
EXCESIVA DE RADIACIÓN ULTRA VIOLETA

1. Muchas luminarias VARI❋LITE® usan un tipo de lámpara HID que produce radiación
UV. NO mire directamente a la lámpara.

2. Es peligroso operar luminarias sin lentes o protectores. Debe cambiar los protectores,
lentes o pantallas ultravioletas si se aprecia que han sido dañadas, y que su efectividad
pudiera estar deteriorada. Por ejemplo, si tuvieran rajaduras o raspaduras profundas.

ADVERTENCIA:
INSTRUCCIONES PARA PROTECCIÓN CONTRA LESIONES DE PERSONAS

1. Las superficies exteriores de las luminarias están calientes durante su operación. Use un
equipo de seguridad apropiado (guantes, protección para los ojos, etc.) cuando haga
ajustes en el equipo y componentes que están calientes.

2. Cuando las luminarias están en operación la lámpara estará muy caliente. Desconecte la
energía y deje que la lámpara se enfríe antes de reemplazarla.

3. Las lámparas de arco emiten radiaciones ultravioletas que pueden ocasionar serias
quemaduras a la piel e inflamación a los ojos. Además, las lámparas de arco operan a alta
presión y muy alta temperatura. Si la lámpara se rompe, puede existir el peligro de
lesiones al personal o un incendio ocasionado por las partículas de la lámpara rota que se
caen.

4. Use protección para los ojos cuando vuelve a colocar una lámpara nueva.

5. Use un equipo de seguridad apropiado (guantes, protección para los ojos, etc.) cuando
trabaje con lámparas dañadas.

6. Si toca la lámpar a con l as manos , limpie la l ámpara c on alc ohol de snatur aliz ado y co n tel a
sin pelusas antes de instalar o volver a conectar la luminaria.

7. Cambie la lámpara si está dañada o deformada term icamente.

ADVERTENCIA:
INTERFERENCIA RF

1. Este es un producto de Clase A. En el ambiente de la casa este producto puede ocasionar
radiointerferencia, en cuyo caso, el usuario debe tomar las medidas adecuadas.

CONSIDERACIONES SOBRE LAS CARACTERÍSTICAS DE LA LÁMPARA DE
ARCO

1. Las lámparas de arco requieren un período de tiempo para volver a iluminarse después de
una interrupció n de ene rgía o de una severa caída de voltaj e. En algunos casos, la lámpara
se volverá a iluminar en forma automática después que se ha enfriado dependiendo de la
configuración del sistema de energía de la lámpara (L ON / L OFF) (L encendida / L
apagada).

2. La posición de encendido es universal.

xii 22-Feb-02 02.9661.0001J

_KHæPÔHçPÄ



Î



SAFETY NOTICE (JAPANESE)

ÎÎæ%¿Ð

á¿~ÒÁ'

êùÕÄQ>X^Åî

ûéQ>X^é_KHæPÔ±ãÿ

ÚsÙæÄ~
îTæÐçÒáÞ:

Ä

Q>X^

âê

é_KQo"öª

ÌÚöªÔÙ

ТбКЫР¿

æêÔôáéHçPÄÅ

Òá¿ùÔ

Hç ~æÊÍÃ¾HǽùÔ

T qPæßåÇ¾H

õ

ûxå±æß¿áê

+4é¢ËÚüé

1. VARI❋LITE®

ÿzU



4. VARI❋LITE®

+4UV|¿æ»Ô2é:´ÅîqP

éÿÅ

:

T

Ef;

ÿzUê

3Ð

MSR575HR

Ìã¾âÔ

Jé+YæâýÌÎãЗвИщФf¦
ó

EXo-dµÔ'

ÒáÊÛп

Òá

á¿ùÔ

åäÕÕzÔ

êÄQ>X^é0æåÞá2ÞÔ

ТбКЫР¿

ÿzUê»H°ùÚêé6.ÆÐåÛÌ

)

ÒáÊÛп

Philips

\fJdµÔÙê

ê+Ó

Åî

ÁæТбКЫР¿é³é\fJ

EXo-Ô+Ó³+Ó

úÊÛп

OsraméHID

\fJé³Ô

ÔôáÅúÊÛпù

ǽùÔ

ËÚüé

\fJöªÔ

MSR400

ÆÉäéÁå

æß¿áêÄQ>X^

"\,Õöª

Áæ



2



:

T

õËÚüé

1. VARI❋LITE®

Ôâè²ÿ(Çé¿²æÌ
ǽùÔ

2. VARI❋LITE®

¿

ÿzUéCPêp,ßÛçéúÇÁÁæТбКЫР¿

02.9661.0001J 22-Feb-02 xiii

Ef;

ÿzUêGÎ

ÿzUCPÔ'

ÒÚcºâöªÔ



Áæ

3Ð

ãÿzUÇÍ

êÕ5æ.¾

á¿ù

ûÎã

ЮбКЫР

VARI❋LITE - VL2416™ WASH LUMINAIRE USER’S MANUAL





c



~

Î

:

T

2é

UV

|¿æÐÐå¿Úüé

Ef;

1. VARI❋LITE®

Òá¿ùÔ



_f-

ùÚê

*o^<¡"¹Y

ÇÊå

T



:

qPËÚüé

ÿzUÇP.

ÿ

&fPo@f;ÒÁÙæê¡¾åUÔ»<ÿ;ªÜÕ

ª

ÒáÊÛп

ÿzUÇP.

ÿzUéÊêUV|¿¢Õ

\fJåÞÔ
*o^<ö

Îãê±ÌáÊÛп

ÕæÿzUP.Ôã¾âÔ

êíîÿÓ¿

ÁæåÞÚ§Ã

ÁæÒùÔ

Ef;

Òá¿ãÈêØé¥Ç²

Òá¿ãÈêØé

\fJDz

HID



ÞÆÈÍåäæ

2Jé\fJöª



Øé

ÊåùÔ²ÊåÞÚzU

ÊåùÔ

\fJdµ

Ô'êÿzUé.¾\fJé÷2ÇÇùâÙÞáÊÛ
п

¾



o".ê¡"|¿
áé;àОФОгЗ½ùÔÐæ

â6

âqPÿ+4Ç¢Ô¾H

cP.Ô
ÊÍ

\fJ

'

ÒÚ

\fJÒÁ'

é

ñÚ½Ìã¤¿

ǽùÔ

ÒùÔÎé¡"æÞáíä¿+Ív

ÒùÔØéÚüû

o".ÇÊÔ

ǽùÔ

ãÈæê;ªÜª

ê¡¾åUÔ»<ÿ;ªÜÕª

,64ÇÛ

¿á

o".êö÷éA

ÒáÊÛп

\fJé.Ç

ã'îÞÚ

ÒáÊÛп

»<ªÖÕæå»â

\fJÈ

.I

ÍÇß¿Ú

¿æÒ{ÊÕé´å¿Óâ¿áÆÿzUÌ

ÁæÒùÔ

\fJÿ²æ

\fJÞÚ'

Þá»

ÒÚ

\fJê§

êH

^&o^öÞá

ÃáÊÛп

_f-

2

ÞÚ



ö

:

T

RF



ä

1.

Ä



ê

Class A

ÎÔ»HǽùÔØé'öª*꡾å
å¿ÎãǽùÔ

o".é$H

1.

ß

ùÚê"Èåö

Ê(FÅÊÁжТбКЫР¿

,9S3oæ

½ùÔ



o".êP6.âÔ

xiv 22-Feb-02 02.9661.0001J

æ½Ð

ùÔ

:6Jßæ

Þáê÷2Ç

Ä~

ê8cº

o".cP.Ô'

æÅ¿áu"äà

£



åÌëå

êÒë

Lamp Power- Up State ÔL ON/ L OFF

Õ

ЗЮЪгИæDGæcP.Ð'





*

ý

Table of Contents

Introduction

About This Manual...................................................................................................... 1

Additional Support and Documentation ...................................................................... 1

Te xt Conventions ......................................................................................................... 2

Chapter 1. Description

Features

Overview...................................................................................................................... 4

Components

VL2416 Wash Luminaire............................................................................................. 5

Menu Display............................................................................................................... 6

LED Indicators............................................................................................................. 6

Accessories

Replacement Items/Accessories................................................................................... 7

TABLE OF CONTENTS

Chapter 2. Installation

Power and Data Cabling Requirements

Power ......................................................................................................................... 10

Current vs. Voltage.................................................. ............................................ 11

Data Cables................................................................................................................ 12

Recommended Cable Types/Manufacturers ....................................................... 13

Male Termination Connector.............................................................................. 14

Loopback Connector........................................................................................... 14

Installation Proce dures

Installing Lamp.......................................................................................................... 15

Hanging the Luminaire.............................................................................................. 16

Floor Mounting the Luminaire................................................................................... 19

Connecting Data and Power....................................................................................... 19

Powering Up

Power-Up Procedure.................................................................................................. 20

Align Lamp for Flat Field ................................................................................... 21

Set DMX Mode.......................................................................................................... 22

Addressing

Program Starting Address.......................................................................................... 23

Program Starting Address Without Calibrating the Luminaire ................................. 23

02.9661.0001J 22-Feb-02 xv

VARI❋LITE - VL2400™ SERIES WASH LUMINAIRE USER’S MANUAL

Chapter 3. Operation

DMX Modes

8-Bit and 16-Bit Modes.............................................................................................. 26

DMX Mapping

Beam Control.............................................................................................................. 27

Color Control.............................................................................................................. 28

Luminaire Timing

Luminaire Timing Channel Information.................................................................... 29

Control Channel Functions......................................................................................... 37

Updating Software

Reprogramming Luminaires....................................................................................... 38

Installation and Reprogramming Procedure ........................................................ 39

Transferring Software From Luminaire to Luminaire................................................ 42

Hardware Requirements....................................................................................... 42

Transfer Procedure............................................................................................... 42

Chapter 4. Menu System

Operation

What Is the Menu System?......................................................................................... 46

Controls Operation ..................................................................................................... 46

Display Orientation.............................................................................................. 47

Default State......................................................................................................... 48

Decimal Placement.............................................................................................. 48

Display Test......................................................................................................... 49

Shortcuts .............................................................................................................. 49

Error Messages..................................................................................................... 50

Mapping

Menu System Overview............................................................................................. 52

Menu System Functions............................................................................................. 53

Function Definitions................................................................................................... 57

Cues and Sequences

Overview .................................................................................................................... 61

Storing.................................................................................................................. 61

Playback............................................................................................................... 61

Hardware Requirements....................................................................................... 61

Cue Operations........................................................................................................... 62

Self Tests

Running Parameter Tests............................................................................................ 66

Diagnostic Tests.......................................................................................................... 68

xvi 22-Feb-02 02.9661.0001J

Appendix A. Troubleshooting and Maintenance

Troubleshooting

Protecting Your Warranty .......................................................................................... 78

Troubleshooting Guide .............................................................................................. 79

Routine Maintenance

Lamp Replacement .................................................................................................... 83

Front Glass Replacement........................................................................................... 85

Cleaning Optical Lenses and Filters .......................................................................... 87

Appendix B. Technical Specifications

Mechanical................................................................................................................. 89

Optical........................................................................................................................ 89

Operational................................................................................................................. 90

Photometric................................................................................................................ 90

TABLE OF CONTENTS

02.9661.0001J 22-Feb-02 xvii

VARI❋LITE - VL2400™ SERIES WASH LUMINAIRE USER’S MANUAL

(This page intentionally blank.)

xviii 22-Feb-02 02.9661.0001J

Introduction

About This Manual

This manual provides necessary information regarding product safety, installation,
operation, and routine maintenance for the VARI❋LITE® VL2416™ Wash
Luminaires. (The VL2402™ Wa sh Luminaire is not covered in this manual. Please see

“Additional Support and Documentation” for information on the VL2402 luminaire.)

Familiarizing yourself with this information will help you to get the most out of your
luminaire.

WARNING: It is important to read ALL accompanying safety and installation
instructions to avoid damage to the product and potential injury to yourself or others.

INTRODUCTION : ABOUT THIS MANUAL

Additional Support and Documentation

A support webpage for the Series 2000™ luminaires is available at:
www.vari-lite.com (connect to the Vari-Lite homepage and follow the Support link).

For information on extended maintenance procedures and troubleshooting for the
VL2416 Wash Luminaire see the VL2400 Series Wash Luminaire Service Manual.
This manual is available in both printed and electronic (PDF) formats.

VL2416 Series Wash Luminaire Service Manual (02.9667.0010).

■

- Troubleshooting, Component Replacement, Illustrated Parts Breakdown.

Note: Performing maintenance procedures contained in the VL2416 Series Wash
Luminaire Service Manual may void the product warranty. Refer to the Vari-Lite, Inc.
Limited Warranty card included in the shipping package for this VARI❋LITE
product.

For more information on the VL2402 Wash Luminaire, please see the VL2402 User’s
Manual (02.9671.0001) or the VL2402 Service Manual (02.9671.0010).

For more information on DMX512 systems, refer to the following document available
from United States Institute for Theatre Technology, Inc. (USITT).

Digital Data Transmission Standard for Dimmers & Controllers plus AMX

■

192 Analog Multiplex Data Transmission Standard for Dimmers &
Controllers. (A copy of Recommended Practice for DMX512 is included.)
USITT Inc.
Suite 5A, 10 West 19th St.
New York, NY 10011-4206 USA
Tel : (212) 924 - 9088 Fax : (212) 924 - 9343
www.usitt.org

02.9661.0001J 22-Feb-02 1

VARI❋LITE® - VL2416™ WASH LUMINAIRE USER’S MANUAL

Text Conventions

The following styles and meanings are used throughout this manual:

[Button] Front panel button. Example: Press [Menu].
[Up] / [Down] arrows Press either [Up] or [Down] arrow button at Menu

Display.

MENU Menu Display read-out. Example: Press [Up] / [Down]

arrows until CFG (Configuration) appears.

2 22-Feb-02 02.9661.0001J

CHAPTER 1.

Description

Description

DescriptionDescription

This chapter contains descriptions of luminaire features and components, along with
a list of accessories which are available.

• Features

• Components

• Accessories

02.9661.0001J 22-Feb-02 3

VARI❋LITE® - VL2416™ WASH LUMINAIRE USER’S MANUAL

Features

Overview

The VL2416 wash luminaire contains the following
standard features:.

•DICHRO❋TUNE™ radial color changer which
employs enhanced dichroic color filters to produce
smooth, full spectrum color crossfades. The
mechanism allows independent blue, amber, and
magenta color control.

• An internal mechanical douser which provides
intensity control and strobing.

• Zoomable beam spreader mechanism which provides
5” to 55” field in less than 1.2 seconds.

• 1200 watt arc source.

• An upper enclosure that houses the control electronics as well as a power factor
corrected arc power supply.

• Control by DMX512 protocol.

• Two truss hook brackets for versatile hanging configurations.

4 22-Feb-02 02.9661.0001J

Components

VL2416 Wash Luminaire

The following illustration shows the major luminaire components and controls.

Truss Hook
Bracket Asse mbly

Yoke
Assembly

Upper Enclosure
Assembly

DESCRIPTION : COMPONENTS

1

Hinged Heatsink
Assembly
(to access lamp
for replacement)

Head Assembly

Input Panel Components

Product Label ID

Main Power
Switch

Power and Data
LED Indicators

AC Input Cable

Beam Adjustment Controls

Adj.
Screws *

* Do not remove or use to access lamp.

Menu Display

AC Input Cable

02.9661.0001J 22-Feb-02 5

Data In

Data Thru

VARI❋LITE® - VL2416™ WASH LUMINAIRE USER’S MANUAL

Menu Display

The Menu System Display is used to access the menu system, which is a
programmable set of commands used to address, operate, and test the luminaire.

The menu system is controlled by four buttons. These buttons function as follows:

Multi-Segment
Display

Displays the menu,
or if at first level, the
current address

Refer to “Menu System” chapter on page 45 for more detailed instructions regarding
display orientation and operation.

Changes a value or
scrolls through menus

Changes a value or
scrolls through menus

Selects the current menu option
or enters current data value

LED Indicators

The LED indicators report the status of power and data to the luminaire.

Indicates DC power is being
supplied via AC Input when lit

Indicates data is being
transmitted when flashing

Indicates data is being
received when flashing fast;

when flashing in 2 sec. heartbeat,
indicates luminaire is idle

6 22-Feb-02 02.9661.0001J

Accessories

Replacement Items/Accessories

The following optional and/or replacement items can be ordered directly from
Vari-Lite. (Please order by Vari-Lite part number.)

Vari-Lite Part No. Accessory

20.9625.0132 Road Case, Plastic (two hole)

22.9620.0194 Safety Cable Assembly

23.9623.0177 DMX Termination Male Connector Assembly

25.9661.0056 Loopback Connector Assembly

28.9661.054 Luminaire Programming (XLR5) Kit

DESCRIPTION : ACCESSORIES

1

55.6841.0001 Mega Claw Truss Hook, 2" Round

55.6840.0001 Mega Clamp Truss Hook, Round and Square

42.5002.0004 Clear Front Glass

42.5002.0005 * Stipple Front Glass

42.5002.0006 Medium Flood / 8-Row Lenticular Front Glass

42.5002.0007 Medium Flood / 10-Row Lenticular Front Glass

42.5002.0008 Medium Flood / 12-Row Lenticular Front Glass

42.5002.0009 Very Wide Flood / Buxom Front Glass

* Factory standard front glass.

02.9661.0001J 22-Feb-02 7

VARI❋LITE® - VL2416™ WASH LUMINAIRE USER’S MANUAL

Notes

8 22-Feb-02 02.9661.0001J

CHAPTER 2.

Installation

Installation

InstallationInstallation

This chapter contains instructions for installation of the luminaire. It includes
connecting power and data, along with instructions for powering up the luminaire for
the first time and addressing it within your system.

• Power and Data Cabling Requirements

• Installation Procedures

• Powering Up

• Addressing

02.9661.0001J 22-Feb-02 9

VARI❋LITE® - VL2416™ WASH LUMINAIRE USER’S MANUAL

Power and Data Cabling Requirements

Power

The luminaire requires standard AC power distribution from 200-240 VAC, 50/60 Hz.
Five amps to twelve amps will be required.

Depending on the application, the luminaire’s AC input cable may require a different
connector. If required, install a new connector meeting your requirements using the
following wire color code reference:

Wire* Connection

Green/Yellow AC Ground

Blue AC Neutral

Brown AC Line

* International (Harmonized) Standard

WARNING: DO NOT connect to three-phase service in countries with 240 volt
power.

Note: The lamp will not strike below 180 volts RMS.

For single-phase power at 200-240 volts RMS:

Connection Pin

AC Neutral X

AC Line Y

Ground (Earth) G

X

G

Y

For three-phase power at 208 volts RMS:

Connection Pin

Phase 1 X
Phase 2 Y

X

G

10 22-Feb-02 02.9661.0001J

Ground (Earth) G

Y

INSTALLATION : POWER AND DATA CABLING REQUIREMENTS

2

Current vs. Voltage

The following table provides the luminaire’s current draw at specific voltages. Current
is calculated with the lamp on and all motors sequencing.

Voltage Current

180.0 8.2

190.0 7.8

200.0 7.4

210.0 7.0

220.0 6.6

230.0 6.3

240.0 6.0

250.0 5.8

02.9661.0001J 22-Feb-02 11

VARI❋LITE® - VL2416™ WASH LUMINAIRE USER’S MANUAL

Data Cables

The luminaire is equipped with two, 5-pin XLR connectors for DATA IN and DATA
THRU (out) applications. DATA IN requires a 5-pin, female XLR connector and
DATA THRU requires a 5-pin, male XLR connector. When purchasing or
constructing data cables, it is important that not only the correct cable type be used,
but also quality cable to ensure a reliable DMX512 system. Your cabling should meet
the following USITT DMX specification requirements:

• Suitable for use with EIA485 (RS485) operation at 250k baud.

• Characteristic impedance 85-150 ohms, nominally 120 ohms.

• Low capacitance.

• Two twisted pairs.

• Foil and braid shielded.

• 24 AWG min. gauge for runs up to 1000 feet (300m).

• 22 AWG min. gauge for runs up to 1640 feet (500m).

Note: Microphone type cables and other general purpose, two-core audio or signal
cables are not suitable for use with DMX512.

Refer to the USITT Recommended Practice for DMX512 guide for additional
information regarding DMX512 systems. How to obtain a copy is detailed in

“Additional Support and Documentation” on page 1.

The XLR 5-pin connectors should be wired as follows:

Pin/Wire Code to XLR Connectors

Data Thru

Cable Pinout

1

2

4

3

Male Conn

Pin 1

Foil &

Braided

Shield

5

Pin 2

1st

conductor

of 1st

twisted

pair

Data (-)

Pin 3

2nd

conductor

of 1st

twisted

pair

Data (+)

Pin 4

1st

conductor

of 2nd

twisted

pair

Data (-)

Pin 5

2nd

conductor

of 2nd

twisted

pair

Data (+)

Data In

Cable Pinout

5

4

2

3

Female Conn

1

12 22-Feb-02 02.9661.0001J
