USER’S GUIDE V5.0
Important Instructions
IMPORTANT OPERATING INSTRUCTIONS FOR VAPIR ONE VAPORIZERTM
SUPERCHARGED FAN MODELS
DUE TO HIGH AIR PRESSURE, TEMPERATURES MAY FLUCTUATE SEVERAL DEGREES
CAUSING THE GREEN LIGHT TO FLICKER BETWEEN RED AND GREEN. THIS IS NORMAL.
It is imperative that you place your Vaporizer´s fan setting on the HIGH or H position
when starting it up. Failure to do this may cause damage to your Vaporizer that is
not covered under warranty. This vaporizer has 3 Fan speed settings: L for LOW, M for
MEDIUM and H for HIGH. The unit should always be started on H for HIGH so that it can
properly achieve the speed it requires. The unit might not operate properly if it is not
started on the HIGH position. If the unit is heated without the fan on, it could possibly
overheat and cause damage to the unit that is not covered by the warranty In the event
that this occurs, immediately turn it off and restart on HIGH.
If your fan ever turns off or you notice it is not on, immediately turn the unit to the
off position, adjust the fan speed to H (HIGH position), and turn the unit on with the
heat off (heat is the large button with a flame on it). Do this for 5 minutes. It should
cool your device for usage.
Never unplug or turn your unit off until it has had sufficient time to cool down. Always
leave the fan running without heat for a minimum of 5 minutes after each use.
As a safety precaution, your unit is equipped with an internal safety switch. This switch
will disable your unit should it ever overheat. If your unit malfunctions or stops heating,
leave the fan on H (High position) for 20 minutes to cool the unit down. Then, turn your
unit off. At this time, it is safe to either restart the unit or unplug it and store.
Always unplug the unit from the electrical outlet before cleaning. Always make sure
your unit is completely dry before turning it on. Do not attempt any repairs to your
unit as doing so may cause fatal injury or void your warranty.
1
2
3
5
6
7
8
9
4
13
12
10
11
Identifying the Parts
1. Vapor Outlet Valve
2. Accurate Digital Temperature
Control
Press + to increase temperature. Press
- to decrease temperature. Maximum
temperature is 400 °F (204 °C).
3. Push-Button Heat Control
Turns heat On or Off.
4. Fan Speed Switch
Adjusts speed of fan.
5. LCD Screen
Displays data. Screen toggles
between set temperature and current
temperature.
6. Red/Green Ready Light.
When light is red, it indicates that
heating is activated and the unit is
attempting to reach the temperature
that you set. When light is green, the
set temperature has been reached. It is
normal, once the set temperature has
been reached, for the light to toggle
between red and green as it attempts
to regulate the temperature.
7. Celsius/Fahrenheit Button
Adjusts display to Celsius or Fahrenheit.
8. Tone On/Off Button
Turns Tone On or Off.
9. Power Switch
Turns unit On or Off.
10. AC Power
Insert power cable here.
11. Air Intake Valves
Allows for proper internal ventilation
of your Vapir ONE Vaporizer. Never
cover these holes.
12. Eject Switch for Herb Disk Drive
Ejects herb disk drive.
13. Herb Disk Drive
Insert herb disk here after ejecting drive.
