Aurora Wireless Speaker With
Moodlight Function (BTS21)
Thank you for purchasing the Valore Aurora Wireless Speaker With Moodlight Function
(BTS21).
Get the party started with the Valore Aurora Wireless Speaker. A statement piece with its
unique design and beautiful array of LED moodlight display. Plus, enjoy high-quality stereo
sound from the 5W speaker by pairing it with another Aurora speaker.
Important: Please read the user manual thoroughly before using your wireless speaker.
Specifications: Package Contents:
• Wireless range: Up to 10m
• Built-in battery: 3000mAh Lithium-ion battery
• Playback time: 15 hours
• Charging time: 6 hours
• Standby time: 140 hours
• Power input: DC5V/1A
• Power output: 5W (max)
• Material: ABS rubber oil + Metal speaker mesh
• Dimension (L x W x H): 150 x 148 x 138mm
• Weight: 700g
UNDERSTANDING THE PRODUCT
• Wireless speaker with moodlight
function
• Micro USB charging cable
(800mm)
• Auxiliary cable (800mm)
① Moodlight Mode
② Multi-functional button (M)
③ Pause/Play/Answer
④ Previous/Volume ⑤ Next/Volume +
⑥ AUX in
⑦ Micro SD card slot
⑧ ON/OFF/TWS
⑨ Charging port
⑩ Power indicator
①
② ③
④ ⑤
⑥
⑦ ⑧ ⑨ ⑩
START USING THE WIRELESS SPEAKER
1) Charging the wireless speaker
Connect the USB charging cable provided to the Micro USB charging port located at the back
of the speaker.
Note: Please charge the speaker for at least 8 hours before first use. Please make sure that the speaker is
switched off when charging is in progress.
2) Pairing the wireless speaker (switched off)
Single:
Step 1: Activate Bluetooth function on your mobile device to begin pairing with speaker.
Step 2: Switch on the speaker by shifting the ON/OFF/TWS switch to ON.
Step 3: Connect to the speaker by selecting ‘Valore BTS21’ under the device list.
Step 4: Once connected, the LED light at the will be solid blue.
Twin Speaker:
Step 1: Place both speaker together (within 3 metres) and shift bothe speaker to TWS. Red
and blue led will flash alternatively. Wait about 30 seconds for speakers to finish pairing.
Step 2: Activate Bluetooth function on your mobile device. Select ‘Valore BTS21’ under the
device list to connect.
Note: When in both speakers are connected, turn off either speaker, TWS function will be turn off.
If the pairing is not successful, please turn off wireless speaker first, and then re-pair again. After pairing is
successful, paired devices will remember each other. Unless pairing information is deleted because of new
pairing, no need to pair when using the next time.
If you want to pair the wireless speaker with other devices, please turn off Bluetooth function of existing source
device, and pair the wireless speaker with the new device according to steps 1-4 mentioned above.
3) Wireless speaker controls
Pause/Play/Answer: Short press to play/pause music. Short press to answer. Short press to
hang up. Long press to reject call.
Previous/Volume - : Short press to go to previous song. Long press to reduce volume.
Next/Volume + : Short press to go to next song. Long press to increase volume.
Multi-functional button(M) : Short press to switch between Aux, Micro SD and bluetooth
mode.
