Product Reference Guide
Read and follow the instructions contained within carefully before use. Retain this guide in
a safe and easily accessible place for future reference.
Drawings, pictures and specifications contained in this manual are for illustration
purposes only – actual product may vary. VALCO BABY reserves the right to alter any
specification(s), colour or features without prior notice or incurring any obligation to
similarly alter products previously purchased.
Thank you for purchasing a quality VALCO product. Due to our policy of continuous product
development, this product is constantly evolving. It is possible that some features or
procedures outlined here have changed since this document was written. If you are unsure of
any procedure outlined here please contact the store from which you purchased it to obtain
the most up to date information, or contact us via the internet. See relevant web contact
addresses on the back page.
Stroller Overview
*
1 x Chassis installed with Seat Liner and Basket
Basic Components
2 x Front Forks & Front Wheels
2 x Rear Wheels
1 x Rear Axle-Brake System
2 x Rear Axle Pins (SQR Axles)
2 x Hoods (Left & Right Side)
1 x Twin Runabout Front Bar 4 x Nylon Housing Bracket Plugs
Remove the stroller from the carton and dispose of all packaging immediately including the
black rubber protectors on either side of the brake bar and front wheel protector. The front
wheel forks, rear wheels, front bar, and hood all need to be installed prior to use.
Stroller Assembly
1. Take the rear axle with the longer
part of the centre pedal facing to
the rear.
2. Identify the locking pins (A)
located on both rear frame legs.
3. Align the locking pins (A) with the
corresponding notches in the
brake housing (B).
4. Push brake housing upwards on
frame leg until pins (A) lock into
the housing (B).
5. Pull on the entire axle to test
that it is securely locked into
place.
Installing/Removing the rear axle-brake system
Lay the stroller flat on the floor and
carefully cut the cable tie which holds
the frame.
To unfold the chassis, locate the rear
legs.
NOTE: The rear centre leg is
highlighted in red.
Opening the stroller chassis
6. Should you need to remove the
brake system for long-term
storage, release each brake
housing by pressing on the pin
release flap (C) and
simultaneously pushing the
housing downwards.
IMPORTANT WARNING: Always test that all latches are securely engaged before use.
Installing/Removing the rear wheels
Unfold the chassis:
1. Holding the rear centre leg, lift
the stroller upwards.
2. Pull the centre leg outwards as
far as it can go.
3. Lift the handle upward and back to
a vertical position.
4. Secure the handle by swinging the
locking clamps (located on both sides
of the frame) and fully engaging them
tightly onto the frame.
5. Press down on the basket frame
locking hinge with your hand or
foot.
1. Pressing on the centre hub
button, insert the SQR axle
through the outside of the hub in
each wheel.
IMPORTANT: Insert through outside
of the wheel (the side which does
NOT have the nylon brake cog).
Installing/Removing and using the front wheel forks
Pressing the axle button, insert the
protruding long axle into the opening in
the axle tube. (Refer to ‘Using your
brakes’)
NOTE: Ensure that the brake pedal is fully
retracted, so that the brake pin
(highlighted in red) does not obstruct the
wheel cog from fully engaging the housing.
Repeat the procedure for the other side.
TEST that each wheel is securely engaged
by pulling on it.
To remove the wheel, simply press the
axle button in the centre of the wheel hub
and simultaneously pull the wheel
If your brakes do not engage, check to see
the nylon brake cogs are on the INSIDE of
each wheel when it is attached to the
chassis. If not, remove the wheel and SQR
axle and re-insert the SQR axle from the
other side of the wheel, so that the cog will
be on the inside of the wheel.
Your Twin Runabout stroller utilises our
unique and revolutionary new DUAL TRIMODE™ front swivel system:
1. Tilt the stroller frame upward so that
it rests on the handle and the rear
wheels.
2. Insert each fork shaft respectively into
each TRI-MODE housing till it “clicks”
into place.
IMPORTANT: Before use, always test that
the fork is securely engaged in the
housing by pulling on it.
To remove the front fork:
1. Rotate the TRI-MODE selection
dial to the centre (45°) position.
2. Tilt the stroller frame upward so
that it rests on the handle and
the rear wheels.
3. Press the centre release button
and pull the fork away from the
mechanism.
The unique TRI-MODE™ swivel system is as
flexible as it is functional over a variety of
terrains and uses.
1. LOCK
: This position is best for use on
extremely rough or soft terrain such as sand
etc which inhibit wheel swivel. To lock your
wheel, rotate the dial to the “LOCK” position.
Swivel the wheel around till it locks into
position.
2. O
:
The central position locks the wheel into a
tight 45°
swivel arc. This provides more
stability for use with a toddlerseat or when
going down inclines so as not to turn so
sharply!
3. SWIVEL:
This position allows full, unfettered
360° swivel action.
Installing/Removing your hoods
Identify left right side hoods, where
each hood centre housing (A) is in
the middle of the pram.
Place the rear hood skirt OVER the
stabiliser bar (C).
1. Insert hood section housing (A)
into the corresponding housing in
the centre of the seat (B).
2. Place the other plastic hood housing
above the corresponding housing on the
side of the stroller. Be sure that the
locking strap is out of the way and ABOVE
the hood housing.
3. Align the raised track on the stroller
housing with the corresponding channel in
the hood housing.
4. Slide the hood housing downward,
engaging the track in the channel,
continue sliding downward until
the rivet outside (D) is fully
engaged in the housing.
5. Repeat the procedure for the
other hood.
6. Secure each hood to the rear of
the frame with Velcro straps at
the centre (E), and both sides of
the hood (F).
NOTE: Before using your stroller, be
sure to attach the tether straps
around the stroller frame by feeding
the strap through the slit in the
steel buckle. While not essential for
safety, these additionally secure the
seat to the stroller frame.
The new “no zip” recline offers an
almost infinite amount of seat
adjustments:
1. RECLINE: While squeezing the
centre release mechanism in a
pincer action, ease the seat down
to the desired position.
2. INCLINE: Place your hand in the
centre of the rear of the seat.
3. Pull the incline strap while gently
pushing on the rear of the seat
until the desired position has
been reached.
IMPORTANT WARNING: Always test that the seat is securely locked in place.
Using your brakes
1. Remove the plugs from the nylon
housing at either side of the stroller
frame by pressing each inner “release
button” and pulling the plug upward.
NOTE: DO NOT remove the plugs in the
centre between both seats. Be sure to
store the removed plugs in a secure place
as they MUST be used whenever nothing
is engaged in the front bar housing to
prevent finger entrapment.
2. Insert the bar ends into the nylon
housing located on either side of the
frame. Be sure that the red buttons
are facing towards the seat and that
the bar is securely engaged.
3. Adjust the front bar by simultaneously
pressing the two red buttons and
swivelling the bar (forward or
backward) to the desired position.
4. Insert the bar ends into the nylon
housing located on either side of
the frame. Be sure that the red
buttons are facing towards the
seat and that the bar is securely
engaged.
5. Adjust the front bar by
simultaneously pressing the two
red buttons and swivelling the bar
(forward or backward) to the
desired position.
IMPORTANT WARNING: The front bar IS NOT a carrying or restraining
device.
TO ENGAGE:
1. Press down on the centre pedal until
the brake pins engage in the nylon brake
cogs in the wheel hub.
IMPORTANT: Always check that the brake
has engaged before use, if not you may
need to move the stroller forward or back
slightly until it locks into place.
2. To disengage, lift the centre pedal
upward till it locks in the upright
position.
Installing/Removing your front bar
Folding/Opening your stroller
1. Fold the hood back up against the
handle.
2. Release the locking clamps at
3. Simultaneously lift the secondary safety catch (located at the left hand side of
the stroller while standing behind) and swing the handle forward.
4. Holding the rear legs at both
sides, press down with your foot
on the rear basket tube. This will
disengage the basket frame
locking hinges.
5. Continue pushing the rear of the
basket, moving the rear wheels
forward beneath the frame.
6. You can lock the frame closed by
stretching each locking strap
(located at either side of the
chassis) over the frame, placing each
catch over the rivet on the chassis.
7. To open, unlock each locking catch by
pushing downward in the catch till it
disengages from the rivet head.
8. Push the handle bar downward to
assist in fastening and releasing the
locking strap.
Your Twin Runabout stroller is equipped
with a tyre pump that hangs in a special
pocket found sewn beneath the right hand
seat at the rear.
Your tires should be kept at a pressure of
40 psi (hard when pressed). Underinflated tyres can cause excessive and
uneven tire wear, greater susceptibility
to punctures and greater difficulty in
smooth operation. By squeezing the tyres
between two fingers, there should be a
small amount of give in the tyre.
EXTRAS
IMPORTANT WARNING: Always test that all axles, wheels, front bar, hinges and locks are
securely engaged before use.
9. With your foot on the inside of the
rear wheels, stopping them from
moving, lift the handle upwards.
(This will begin to move the rear
wheels away from the front of the
chassis).
10. Press down on the basket frame
locking hinges to lock the frame in
the open position.
11. Secure the handle to the frame
by engaging the locking clamps on
both sides.
Your Twin Runabout stroller is
equipped with a removable “Head
Hugger” and shoulder harness
covers. The “Head Hugger” is
designed to optimise the comfort of
newborn babies within the stroller.
The shoulder straps increase your
child’s comfort levels when in the
harness as well as keeping harness
adjusters away from busy fingers.
UV Protective Insect Net
Our unique insect net zips directly in to
the inside of your RUNABOUT Tri Mode
hood. In addition to keeping baby cool,
comfortable and safe from insects, it also
blocks up to a massive 80%* of the sun’s
harmful UV rays.
(* tested to Australian Standard 4399)
Your Twin Runabout hoods are fitted with zips to which attaches our unique silver insect mesh.
3. Secure the front edge of the
insect mesh by fastening the
studs under the footplate as
1. Align the centre of the mesh
above both expanded hoods,
ensuring that the zip ends are in
the correct position as shown in
(A).
2. Run the zips all the way across
each hood arches for the mesh to
fully cover the front end.
4. Having individual zip openings on
each side of the stroller, the
insect mesh can be opened by
pulling on either side of the seat
respectively.
TO SECURE YOUR CHILD IN THE HARNESS:
1. Overlap buckles (A) and (B) so that they fit together to form one
complete buckle.
2. Insert the completed buckle into the Buckle Housing (C) until it
engages securely in place.
3. Carefully adjust the harness straps to snugly fit your child by
adjusting the Sliders located on all Shoulder Straps, Waist
Straps and the Crotch Strap.
4. Your harness can be adjusted for even more comfort for smaller
or larger children (at the top of the seat back and front of the
seat) by threading/removing the crotch or shoulder straps
through the webbing sewn into the seat. You will need to detach
the waist straps at the sides of the stroller in order to do so.
(To detach the waist straps: With a pincer movement, depress
the centre buckle button and pull the strap free from the
housing.)
5. To prevent older children tampering with the strap adjustments
and for greater child comfort, your RUNABOUT stroller is
provided with 2 soft strap covers for each harness. To fit,
detach the waist straps at the sides of the stroller (as in point
4) and thread the strap through the strap cover. Re-attach
each strap.
The harness should be snugly fitted to the baby’s body, tight
enough so that the baby cannot wriggle itself free of the straps
but loose enough so as not to cause the baby any discomfort.
1
2
Usin
g y
our harness
AIRGO™ SYSTEM
Your Twin Runabout has been designed to
maximise air flow within the stroller by way of
our exclusive Airgo™ system. This unique
system combines a special breathable seat
fabric, with our unique hood skirt. This
incorporates a zip-off bag which reveals a
mesh air vent, which allows additional air flow
for your child’s comfort. The bag can be hung
from the stroller handles.
TO OPEN YOUR HARNESS:
1. Press down on the Buckle Prongs (1).
2. Simultaneously push the release button in the centre of the buckle (2)
3. Pull the buckles from the Buckle Housing.
Your harness system has been designed to meet very stringent safety standards and
incorporates our unique secondary action. This helps ensure that your child cannot release
the harness unaided.
A
B
C
Your Runabout stroller is fitted with our unique new multi point safety harness system.
Your child MUST always be harnessed while in the stroller.
OPTIONAL/ADDITIONAL ACCESSORIES
Toddlerseat
Available in versions for both Single and Twin Runabout
models, the optional toddlerseat sits firmly inside the chassis.
Perfect for twins and an older sibling (Twin model) or when a
new baby comes along and junior still likes to go for a ride!
Both Twin and single models even fold totally out of the way
with the stroller! See your local specialist retailer for more
info and suitability.
T
ravel Storage Bag
Available in BLACK only,
the travel bag is
specifically tailored to the
RUNABOUT model and
provides sections and
compartments for all the
components including
wheels, axles etc.
Sunstopper (Universal fit)
The unique SUNSTOPPER
provides the ultimate
protection from the suns
harsh rays, while providing a
comfortable open environment
for the child. The roll up blind
system means that the child
can be shielded from the sun
without being fully enclosed,
and folds up into its own self
enclosed pouch for easy
storage.
Boot cover
The generous proportions
of this fleecy lined boot
keep your child warm and
protected from the
elements while offering a
sense of space without
constriction.
Foot Muff
With tailored slots for the
harness system, the fleecy
lined muff keeps your child
comfortable in cool
conditions, while the top
zips off to convert it to a
comfy stroller pad.
4 Season Foot Muff
With all the features of the
standard model, the 4
season model includes a zip
out top section which
reveals our unique 80%* UV
protective net. This allows
even more cool and
regulated airflow in warmer
conditions.
Bottle/Cup Holde
r
(Universal fit)
The revolutionary VALCO
BABY cup/bottle holder was
designed for the busy
lifestyle of today’s parents
and carers. With the
specially designed holding
section big enough to
accommodate up to a 1.5
litre bottle or those big
coffee cups, refreshment is
always within easy reach!
UV Protective Insect Net
Our unique insect net zips directly in to the inside of your
RUNABOUT Tri Mode hood. In addition to keeping baby
cool, comfortable and safe from insects, it also blocks up
to a massive 80%* of the sun’s harmful UV rays.
(* tested to Australian Standard 4399)
The VALCO HITCHHIKER is a boon to any parent with a child who is old enough to walk but
young enough to need to rest along the way. Made of high quality and extremely sturdy
materials (maximum weight 30 kg’s / 66 lb’s), the HITCHHIKER is easily adjustable for
height, width and distance from the stroller which makes it fit most brands, makes and
models of strollers. The handy “hang up” system means it can hang out of the way when
not in use, while the unique quick release systems allows for quick and easy removal.
All this and more makes the HITCHHIKER the perfect option for that “in between” age
child. See your local specialist retailer for more information.
WARNINGS
Your child’s safety is your responsibility ………
• Be sure to check that all clamps and buckles are securely fixed and in place before use.
• Check all parts for breakage or fatigue before use. Discontinue immediately if any part is found to
be damaged or broken.
• The maximum weight of the child for which this stroller is intended is 22 kg’s (48 lbs)
• The maximum height of the child for which this stroller is intended is 106 cm (42 in)
• This product will become unstable if the recommended load is exceeded.
• Can be used from birth +. A cocoon specially designed to be used with a stroller is recommended
when any fully reclining stroller is used with a newborn.
• NEVER jog with a newborn baby in any pram or stroller until the child can sit up
unassisted (approximately 6 months).
• ALWAYS ensure that the child is clear of all moving parts when adjusting the stroller.
• ALWAYS beware of little fingers when folding or unfolding your stroller to prevent finger
entrapments.
• ALWAYS engage the brake system when the stroller is at rest.
• NEVER leave any child unattended in the stroller.
• NEVER use on escalators or stairs.
• When in the stroller the child must ALWAYS wear the safety harness, correctly fitted and adjusted,
at all times.
• DO NOT hang shopping bags from the handle as this may affect the stroller’s stability.
• Always use the basket provided, the maximum weight in the basket is 6 kg’s (13 lbs)
• Do not carry additional children. It may be unsafe to use any accessories other than VALCO
approved ones.
• ALWAYS be aware of the risks provided by fire and other significant sources of heat such as radiators
etc. which may be in the immediate vicinity of your stroller.
• This product is intended for domestic use only. It is not intended for commercial use.
• Continued and extended exposure to sunlight and the elements can change the colours of many
materials. To avoid fadin
g,
always cover and store in a shaded area.
Caring for your stroller
Moving parts may be lubricated with silicone based lubricants – do not use oil.
Regularly check wheels for loose spokes – tighten as necessary.
Your Twin Runabout chassis is made of aluminium alloy but does include some metal parts. Special
care must always be taken to avoid rust. If this pram is used near the ocean or salty air
environments, spray the chassis and seat frame w ith water and dry thoroughly. This is particularly
important for parts such as wheel spokes and springs. We recommend rust inhibiting product
should be applied to prevent accelerated rust and fatigue of these metal parts!
We recommend that you wipe down axles and lubricate the wheels every 3 months,
particularly the front wheel and housing. Sand and dirt can grind down axles so, if you live,
walk or run near/on the beach or in a dusty environment, you must remove and wipe down
the axles and wheels, then lubricate them MONTHLY.
AXLES AND MOVING PARTS ARE BEST LUBRICATED WITH SILICONE BASED
PRODUCTS. DO NOT USE OIL BASED PRODUCTS.
© Copyright VE 2006
www.valco.com.au
www.valco.co.nz
In Australia/NZ
www.valcobaby.com
1 800 610-7850
In North America
Loading...
