Vaillant ecoMAX, ecoMAX 600 Series, ecoMAX 646, ecoMAX 665, ecoMAX 635 Instructions For Use Manual
For the user
GB
Instructions for use
ecoMAX
Wall hung room sealed fan assisted condensing boilers
2
1 General information . . . . . . . . . . . . . . . . . . 3
1.1 For your information . . . . . . . . . . . . . . . . . . . . . 3
1.2 Key to symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Specified use . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 EC designation . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Safety instructions . . . . . . . . . . . . . . . . . . . 4
2.1 Setup and adjustments . . . . . . . . . . . . . . . . . . . 4
2.2 Gas smell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Modifications in and around the boiler . . . . . . 4
2.4 Explosive and flammable materials . . . . . . . . . 4
2.5 Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Factory guarantee . . . . . . . . . . . . . . . . . . . . 4
3.1 Vaillant warranty . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2 Registering with us . . . . . . . . . . . . . . . . . . . . . . 4
3.3 Immediate help . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.1.1 Operating controls . . . . . . . . . . . . . . . . . . . . . . . 5
4.1.2 Advanced multifunctional system display . . . . 5
4.2 Initial checks before turning ON . . . . . . . . . . . 5
4.2.1 Opening the service valves . . . . . . . . . . . . . . . . 5
4.2.2 Checking the water contents . . . . . . . . . . . . . . 6
4.3 Domestic hot water operation
(ecoMAX 646 and 665 only) . . . . . . . . . . . . . . . 6
4.3.1 Obtaining hot water . . . . . . . . . . . . . . . . . . . . . . 7
4.4 Heating operation . . . . . . . . . . . . . . . . . . . . . . . 7
4.4.1 Setting the maximum radiator temperature
control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.4.2 Setting the external controls . . . . . . . . . . . . . . 7
4.5 Status displays . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.6 Resetting the appliance . . . . . . . . . . . . . . . . . . . 8
4.7 Turning the boiler OFF . . . . . . . . . . . . . . . . . . . 8
4.7.1 To turn OFF the central heating only
(Summer mode) . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.7.2 To turn OFF the domestic hot water operation
(ecoMAX 646 and 665 only) . . . . . . . . . . . . . . . 9
4.7.3 Complete shutdown . . . . . . . . . . . . . . . . . . . . . . 9
4.8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.9 Care and maintenance . . . . . . . . . . . . . . . . . . . 9
4.10 Frost-protection . . . . . . . . . . . . . . . . . . . . . . . . . 9
Table of contents
Instructions for use ecoMAX
3
General information 1
1 General information
1.1 For your information
Thank you for choosing a Vaillant boiler. The information
given in this booklet will enable you to obtain the best
performance from your boiler.
ecoMAX 600 series provides central heating and
domestic hot water where a separate indirect hot water
cylinder is also incorporated to the system.
The benchmark gas boiler commissioning checklist (in
the installation manual) should be completed by the
installer and/or the commissioning engineer.
All CORGI Registered Installers carry a CORGI ID card,
and have a registration number. Both should be recorded
in the Benchmark gas boiler commissioning checklist.
You can check your installer by calling CORGI direct on
01256 372300.
If, after reading these instructions, you have any
questions on the operation of the boiler, please contact
either your installer or Vaillant Technical Department.
1.2 Key to symbols
Attention!
Important Note
Note!
This symbol is used to indicate important
instructions.
• This symbol is used to indicate a required step.
1.3 Liability
Attention!
We can accept no liability whatsoever for damage or injury resulting from failure to observe
these instructions.
1.4 Specified use
Vaillant ecoMAX appliances are made to fulfil the latest
technical specifications and official safety regulations.
These appliances are designed as boilers for use in central heating and hot water supply systems.
If the appliances are used for purposes other than or in
excess of these specifications, this shall be classed as
incorrect operation, and neither the manufacturer nor
supplier will accept any liability for resulting damage or
injury.
Use of this type is entirely at the owner’s risk.
The term “specified use” also covers observance of the
operating and installation instructions, along with adherence to the servicing schedules.
1.5 EC designation
The purpose of EC designation is to certify that the boiler complies with the requirements of the directives
covering gasfired appliances (Council directive
90/396/EEC) and electromagnetic compatibility (Council
directive 89/336/EEC).
These appliances also comply with the requirements of
the directive on operating efficiency (Council directive
92/42/EEC).
Note!
Vaillant Ltd. support the Benchmark initiative.
In the installation manual you will find the
Benchmark gas boiler commissioning checklist.
It is very important that this is completed
correctly at the time of installation and commissioning.
Instructions for use ecoMAX
4
2 Safety instructions
3 Factory guarantee
Instructions for use ecoMAX
2 Safety instructions
2.1 Setup and adjustments
Installation and adjustment of the boiler as well as service maintenance and repair of the boiler may only be carried out by a competent person in accordance with the
Gas Safety (Installation and Use) Regulations 1998. (In
the U.K. “CORGI”. Registered installers undertake the
work to a safe and satisfactory standard).
If the boiler is installed in a compartment do not
obstruct any purpose provided ventilation openings, and
do not use the compartment for storage purposes.
2.2 Gas smell
If you smell gas or suspect a gas leak:
- Turn off the boiler
- Do not switch any electrical switches in the hazardous
area on or off
- Do not smoke in the hazardous area
- Turn off the gas supply at the gas meter
- Ventilate the room
- Consult your gas supplier, service agent or other com-
petent person.
2.3 Modifications in and around the boiler
No modifications may be made to the following items:
- The boiler
- The gas, water and electrical supply
- The flue system
- The safety valve for the heating water
- Any structural changes around the appliance that
could affect the operational safety of the boiler.
2.4 Explosive and flammable materials
Do not use or store any explosive or highly flammable
materials (e.g. gasoline, paper or paint) near to the appliance.
2.5 Inspection
The boiler should be serviced annually. We recommend
that you sign a service agreement with your service
agent or Vaillant Ltd.
Attention!
The device may only be used
• for initial operation
• for testing
• for continuous operation
with the chamber cover closed and with the flue
system fully mounted and sealed.
3 Factory guarantee
3.1 Vaillant warranty
Vaillant provide a full parts and labour warranty for this
appliance. The appliance must be installed by a suitably
competent person in accordance with the Gas Safety
(Installation and Use) Regulations 1998, and the manufacturer's instructions. In the UK 'CORGI' registered installers undertake the work in compliance with safe and
satisfactory standards.
All unvented domestic hot water cylinders must be installed by a competent person to the prevailing building
regulations at the time of installation. (G3) Terms and
conditions apply to the warranty, details of which can be
found on the warranty registration card included with
this appliance.
Failure to install and commission this appliance in compliance with the manufacturer's instructions may invalidate the warranty (this does not affect the customer's
statutory rights).
3.2 Registering with us
Registration is simple. Just complete the Guarantee
Registration Card and return to Vaillant within 30 days
of installation. Your details will then be automatically
registered within the Vaillant scheme.
Note!
No receipt will be issued.
3.3 Immediate help
If your Vaillant boiler develops a fault your first action
should be to contact your installer, as his professional
assessment is needed under the terms of our Guarantee.
If you are unable to contact your installer, phone
Vaillant Service Solutions: 0870 6060 777
