Vaddio WallVIEW Pro EagleEye User Manual

Camera and Electronic Products for Integrators

Installation and User Guide

WALLVIEW™ PRO EAGLEEYE WITH HSDS™

Vaddio™ PRO Series Cable System with
HSDS for the Polycom® EagleEye High
Definition PTZ Camera

OVERVIEW

The Vaddio WallVIEW PRO EagleEye (Figure 1) is built
for the Polycom EagleEye high definition PTZ Camera
(camera not included). The WallVIEW PRO system
uses high speed differential signaling (HSDS), an active
transmission system that delivers low-loss, high
definition video over Cat. 5 cabling distances up to 500’
(152.4m)
The WallVIEW PRO EagleEye system is capable of
sending video resolution up to 1080i 16:9 format (the
Polycom EagleEye camera is 720p only). WallVIEW
PRO will autoconfigure to either NTSC or PAL video
standards.
The WallVIEW EagleEye system also has many new features including in-camera IR forwarding that allows
the use of the Polycom IR remote, and eliminates the need for an external IR repeater. Other features
include analog component video outputs (Y,Pb, Pr), four position distance adjustment for CAT. 5 cabling, Y­Gain adjustment, 1-RU rack mount Quick-Connect™ PRO Universal System with HSDS, and the EZ
Interface Module (EZIM) and custom break out cable to interface between the EZIM and EagleEye camera.
Like all Vaddio WallVIEW systems, the Thin Profile Wall Mount and mounting hardware is included.

INTENDED USE

Before installing the Vaddio WallVIEW PRO EagleEye Camera System, please read the entire manual
thoroughly. All Vaddio camera systems are designed for use indoors. Outdoor operation is not
recommended, has not been tested, and could damage the camera and/or create a potentially unsafe

operating condition. Use only the Vaddio PowerRite power supply provided.

SAVE THESE INSTRUCTIONS

The information contained in this manual will help you install the Vaddio WallVIEW PRO systems. For
reference, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the website. These documents can be downloaded from
www.vaddio.com

IMPORTANT SAFEGUARDS

Read and understand all instructions before using. Do not operate the any electrical device if it has been
dropped or damaged. In this case, a Vaddio technician must examine the product before operating. To
reduce the risk of electric shock, do not immerse in water or other liquids and avoid extremely humid
conditions.

INFORMATION

Vaddio has prepared a number of TechNotes, specifications and drawings designed to inform and educate
integrators on the value and the specific uses of Vaddio products.

free of charge.

Use only the power supply provided with the Vaddio WallVIEW PRO products.
Use of any unauthorized power supply will void any and all warranties.

Figure 1:

WallVIEW PRO EagleEye System with EagleEye camera
(not included), Wall Mount and EZIM

©2008 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing subject to change.
Vaddio, WallVIEW, EZIM, HSDS, Quick-Connect, and PowerRite are registered trademarks of Vaddio, Inc. All other trademarks are property of their
respective owners. Document Number 341-660 Rev. B

,

UNPACKING

Carefully remove all of the parts from the packaging. Unpack and identify the following parts for the
WallVIEW PRO EagleEye system (Note: The EagleEye camera is not supplied with this system):

• One (1) - Vaddio EZ Interface Module (EZIM)

• One (1) - Vaddio EZIM to EagleEye adapter cable

• One (1) - Vaddio Quick-Connect PRO Universal with HSDS (1-RU Rack Mountable)

• One (1) - Vaddio Thin Profile WallVIEW PRO EagleEye Wall Mount

• One (1) - DB-9 to RJ-45 adapter (998-1004-232) for Polycom HDC 7000, 8000 and 9000 Series Codecs

• One (1) - 36V PowerRite™ Power Supply with AC Cord Set

• One (1) - 2-position Phoenix Connector for IR

• Mounting Hardware

• Documentation and Manuals

INSTALLATION

All WallVIEW products are specifically designed for installation on a vertical wall surface with CAT. 5 cable
connectivity for Power, Video and Control signaling. Installation is simplified in that no custom cables or
expensive multi-coax plenum cables are needed and no power outlets are required near the camera bracket.
All cabling is routed to the head-end using Cat. 5 cables. All RJ-45 connectors need to be terminated

TIA/EIA 568B or A. The use of RJ-45 “EZ” connectors is not recommended.

Before Installing

• Locate the camera mounting location paying close attention to camera viewing angles, lighting conditions,
possible line of site obstructions, and checking for in-wall obstructions. Pick a mounting location to
optimize the performance of the camera.

• Pre-wire all cabling as required from the camera location to the head end equipment.

• The camera mount can be mounted directly to a 2-gang wall box or to drywall using the supplied anchors.

Wiring Diagram Example for HDX 9000 Series:

WallVIEW EagleEye with
Camera (not included),
Wall Mount and EZIM

Figure 2: The WallVIEW EagleEye connected to an HDX 9000 series codec uses the RJ-45 to DB-9 adapter supplied. IR is fed

out of the Quick-Connect rack mount unit to the IR port on the back of the HDX 9000 series codec for IR forwarding from the
camera. The Power, Video and Control Cat. 5 cables can be run up to 500 from the Quick-Connect box to the EZ Interface
Module (EZIM), which connects to the camera. See Step 7 for additional information on HDX 9000 IR wiring. NOTE: The single
wire coming out of the back of the RJ-45 to DB-9 adapter is for use with the HDX 7000 / 8000 series codecs only.

Polycom HDX-9000
Series Codec

RS-232 Cat. 5 to
DB-9 Adapter

Video Cat. 5

Power Cat. 5

Up to 500’ (152.4m) of CAT. 5
for Power

Component Video
(Y, Pb, Pr) to
breakout cable

Video and Control

IR Input

Polycom
Breakout
Cable

IR Output

Quick-Connect PRO

36 VDC
PowerRite
Power Supply

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 2 of 12

Wiring Diagram Example for HDX 7000 and 8000 Series:

For the Polycom EagleEye Camera

RS-232 Cat. 5

Up to 500’ (152.4m) of CAT-5
for Power, Video and Control

Figure 3: Basic connectivity of the WallVIEW Universal PRO EagleEye System with HDX 7000 or 8000 series codec.
The WallVIEW EagleEye connected to an HDX 7000 / 8000 series codec uses the RJ-45 to DB-9 adapter supplied, with
the single wire on the adapter connected to the “SIG” pin on the IR Port of the Quick-Connect. IR is fed out of the Quick­Connect unit, through the RJ-45 to DB-9 adapter to the HDX 7000 / 8000 series codec for IR forwarding from the
camera. The Power, Video and Control Cat. 5 cables can be run up to 500 from the Quick-Connect box to the EZ
Interface Module, which connects to the camera. See Step 7 for additional information on HDX 7000 / 8000 IR wiring.
NOTE: The single wire coming out of the back of the RJ-45 to DB-9 adapter is for use with the HDX 7000 / 8000 series
codecs only.

Polycom HDX-8000
Series Codec

RS-232 and IR
Adapter (see
Page 5)

IR Signal Wire

Power Cat. 5

Video Cat. 5

Polycom
Breakout
Cable

Component Video (Y, Pb, Pr)
to breakout cable

Quick-Connect PRO
Rack Mount Interface

EagleEye EZIM

Cable

EagleEye on Mount

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 3 of 12

MOUNTING AND INSTALLATION INSTRUCTIONS
Step 1:

After determining the optimum location of the camera system, mark locations for the four screw holes and
the vertical oval cable pass-thru (see Figure 4). Install the drywall mounts and cut the hole for the cable
pass-thru. Next, pull the Cat. 5 cables through the hole then install the Wall Mount. Confirm that the mount
is level and tighten the wall mount screws.

Step 2:

Connect the 25-pin cable to the EZIM then, mount the EZIM and break out cable on the back of the mount,
using the two tapped screw holes (see Figure 5). Connect the HDCI connector to the EagleEye camera that
was supplied with the HDX codec.

Step 3:

Align the tapped screw holes on the bottom of the EagleEye camera to the four holes of the mount. Using
the supplied hex head screws, feed the screws through the four holes to attach the camera to the mount.

Figure 4:

Thin Profile Wall Mount with oval cable
feed-through hole. The wall mount may be
attached directly to a 2-gang wall box or to
drywall with the supplied wall anchors.

Figure 5:

25-pin to HDCI adapter
cable connected to EZIM
(left); EZIM and adapter
cable installed on the Wall
Mount (right)

Step 4:

Prior to connecting the Cat. 5 cables, check cables for proper continuity with a Cat. 5 cable tester. Attach the
Cat. 5 cables for Power, Video and Control to the EZIM and feed the excess cabling into the wall opening or
wall box.

Step 5: Connecting the Quick-Connect PRO

The Quick-Connect PRO is a 1-RU rack mount interface that breaks out the signals from the Cat. 5 cables
back to the standard connectors. The basic system connectivity is illustrated in Figures 2 and 3.

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 4 of 12

Step 6:

Attach the Cat. 5 cables for Power, Video and Control to the Quick-Connect PRO rack mount interface.
Connect the HD video outputs to the Polycom HDCI break out cable provided either provided with your
codec, or available from Polycom. Connect the DB-9 to RJ-45 adapter to the Polycom break out cable, then
connect the RS-232 control Cat. 5 cable to the RJ-45 port on the adapter (see Appendix 1 for additional
wiring detail). Connect the PowerRite 36 VDC power supply to the Quick-Connect PRO power input.

Note: Plugging the POWER Cat. 5 Cable into the wrong RJ-45 may cause damage to the camera system and void the warranty.

Step 7: For HDX 9000 Series Installs Requiring IR Pass-Thru

Connect a two-conductor wire to the connectors of both the
Polycom HDX codec and Quick-Connect PRO Universal rack
mount box. Ground from the Quick-Connect PRO Universal
should be terminated to the “-“ connector on the HDX 9000 Series
codec’s IR input. The Signal “SIG” port on the Quick-Connect
PRO Universal should be terminated to the square wave symbol.
See adjacent drawing for additional detail

Connect the IR output from the Quick-Connect PRO Universal to
either the IR spring cage IR input on an HDX series codec (where
available) or a Xantech™ IR probe (compatible models: 282MRP
or 283M). The white striped wire on the IR Probe is the Signal
and the black wire is Ground.

Step 7: For EagleEye IR Pass-Thru on HDX 7000 and 8000 Series Codecs

Using the RJ-45 to DB-9 adapter (998-1004-232) supplied with the system, strip and terminate the single wire
coming out of the back of the adapter, and connect it to the Phoenix-type connector supplied with the Quick­Connect PRO. The wire needs to be terminated to the “SIG” pin on the back of the Quick-Connect PRO.

Figure 7: Required wiring configuration
for IR Forwarding from the camera IR
port to codec. Note: There is no IR port
on the front of the HDX 7000 and 8000
series codecs. The IR receiver on these
codecs is imbedded in the camera.

Figure 6: Wiring Configuration for
IR Forwarding feature

(optional)

RS-232 Cat. 5

Single wire from the back of
the RJ-45 to DB-9 adapter,
connected to the IR Signal
“SIG” port via a Phoenix-type
connector

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 5 of 12

Step 8:

Connect the Vaddio 36 VDC power supply to an AC outlet. Power will travel down the Power Cat. 5 cable to
the cable shoe, powering the camera. The camera will “Home” to a centered position ready for control
information from the provided IR Remote Commander or RS-232 Camera controller of the integrators’ choice.
To insure proper continuity of control and operation of the cameras, the RS-232 controller (control system or
joystick) should be powered on after the camera.

Step 9:

The Quick-Connect PRO Universal interface has an 8-position dip switch on the rear panel to allow the
selection of IR Forwarding Mode for Polycom® codecs. See setting options on next page.

DIP Switch Example

Quick-Connect PRO Universal back panel

UP

DN

Description Dip Switch (Up = ON) 1 2 3 4 5 6 7 8

IR Forwarding through main camera for use with Polycom HDX-9000

* * * * * * UP *

Series Codecs

2-wire Signal (SIG) & GND connection to IR spring cage connector on back panel of

•

IR Forwarding through main camera for use with Polycom HDX-8000 &

codec

* * * * * * DN *

7000 Series Codecs

Single wire from RJ-45 to DB-9 adapter connected to Signal (SIG) pin on Quick-

•

Connect

Step 10: Setting the IR Pass-Through Adjustment

NOTE:

The IR Gain adjustment is factory set for distances below 300 feet (91.4 meters),
and should not have to be adjusted unless the Cat. 5 cabling distance is over this length.
For cable runs above 300 feet, slowly adjust the gain level up while pressing functions on
the remote control, pointed at the EagleEye camera using the WallVIEW PRO system.
Once all remote control functions are operating from the remote, through the camera’s IR
sensor, the IR gain is adjusted properly.

Connecting an IR Probe:

If connecting a Xantech IR Probe to the IR output of the Quick-Connect PRO Universal, the
white striped wire on the probe should be connected to the signal “SIG” terminal and the
ground, or black wire to “GND”. Attach the probe over the IR window of the codec. Make
sure the dipswitch is in the correct position.

CARE AND CLEANING

• Do not attempt to take the products in these systems apart. There are no user-serviceable components.

• Keep these devices away from food and liquid, and do not spill liquids on the products

• For smears or smudges on the lens, wipe with a clean, soft cloth - see Polycom user guide for details.

Do not use any abrasive chemicals on the camera body at any time.

OPERATING AND STORAGE CONDITIONS

Do not store or operate the WallVIEW PRO System under the following conditions:

• Temperatures above 40°C (104°F) or below 0°C (32°F), for Indoor Use Only

• High humidity, condensing or wet environments

• Dusty environments

• In inclement weather

• Under severe vibration

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 6 of 12

GENERAL SPECIFICATIONS

WallVIEW PRO EagleEye System

System Part
Numbers

999-9500-000 North America
999-9500-001 International

Quick-Connect PRO Universal Interface

Connectors

Camera Select
Switch

Video Adjustments

IR Gain
Adjustment

Compatible
Cameras

Max. Cat. 5 Cable
Distance

Power Supply
Dimensions

Power Connector: 5.5mm OD x 2.5mm ID
Power RJ-45: Supplies 36V to EZCamera Interface Module Regulator
IR: 2-Pin Phoenix type spring cage connector
Video Outputs: BNC Connectors for HD Analog Component (Y,PB,PR)
Video RJ-45: Transports HD or SD video from camera

8-Position DIP switch loads camera profiles and IR Forwarding for Polycom HDX-9000 Codecs

Y-Gain (luminance gain) for fine tuning over longer cable distances
Distance Compensation: 100’, 200’, 300’, 400’+

IR Gain for fine tuning IR over 300 feet

Sony BRC-H700, BRC-Z700, EVI-HD1, BRC-300, (EVI-D70, EVI-D100 also in SD Mode)
Polycom EagleEye

Up to 500’ (152.4m) for Video Power and Control

36 VDC, 2.78 Amp

1-RU Rack Mount (1.75” H x 19” W x 6” D)

EZCamera Interface Module

Connectors

Cable Assembly
Power Regulator
Dimensions

Four (4) RJ-45 Connectors
One DB-25 for Power, Video, Control & IR

For Polycom EagleEye: DB-25M to HDCI -M

Supplies 12VDC to Cameras

Approx. (3.035” H x 4.46” W x 1.242” D)

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 7 of 12

Appendix 1: Cable Pin-outs for the EZCamera Interface Module (EZIM)

Power Connector

Pin Signal
1 Power +
2 Power ­3 Power +
4 Power ­5 Power +
6 Power ­7 Power +
8 Power -

RS-232 IN Connector

Pin Signal

1) DTR (Sony® Daisy chain to DSR)

2) DSR (Sony Daisy chain from DTR)

3) Unused

4) Unused

5) Unused

6) Digital GND

7) RXD (from TXD of control source)

8) TXD (to RXD of control source)

RS-232 OUT Connector

Pin Signal

1) DSR (Sony Daisy chain from DTR)

2) DTR (Sony Daisy chain to DSR)

3) Unused

4) Unused

5) Unused

6) Digital GND

7) TXD (to RXD of control source)

8) RXD (from TXD of control source)

Video Connector

Pin Signal
SD HD

1) IR+ IR+

2) IR GND IR GND

3) Y+ Y+

4) C+ PB+

5) C- PB-

6) Y- Y-

7) Comp. Video + PR+

8) Comp. Video - PR-

DB-25 Connector

Signal

Pins

1 GND Out
14 RXD Out
2 TXD Out
15 DTR Out
3 DSR Out
16 GND IN
4 TXD IN
17 RXD IN
5 DTR IN
18 DSR IN
6 IR
19 GND
7 GND
20 CVBS/PR
8 GND
21 C/PB
9 GND
22 Y/Y
10 GND
23 GND
11 GND
24 12V
12 12V
25 12V
13 12V

RS-232
IN

12345678

12345678

12345678

RS-232
OUT

VIDEOPOWER

EZIM

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 8 of 12

Quick-Connect Universal Pin-outs:

POWER

CAMERA

36V 2A

CAM SELECT

IR GAIN

Power Connector

Signal

Pin
1 Power +
2 Power ­3 Power +
4 Power ­5 Power +
6 Power ­7 Power +
8 Power -

Control Adapter Pin-outs (998-1004-232):

3’ Wire at back of connector to (Polycom S1 Connector - Pin 9)
Pin 6 - GND (Polycom S1 Connector - Pin 5)
PIN 7 - RXD (from Polycom TXD - S1 Connector Pin 2)
Pin 8 - TXD (to RXD of Polycom - S1 Connector Pin 3)

3’ Wire for IR forwarding

DB-9M

Cat. 5

RJ-45

IR

VIDEO ADJUST VIDEO OUTPUTS VIDEO

300

200

400+

>100

Y-GAIN

DISTANCE

SIG.

GND

YPB
Y

DB-9F

C

PR HD

COMP

SD

Video Connector

Signal

Pin
SD HD

1) IR+ IR+

2) IR GND IR GND

3) Y+ Y+

4) C+ PB+

5) C- PB-

6) Y- Y-

7) Comp. Video + PR+

8) Comp. Video - PR-

Polycom HDCI Break-out Cable
See Polycom manual for HDCI
and break-out cable pin-outs

To HDX
Codec

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 9 of 12

FCC, ICES-003 Compliance and CE Declaration of Conformity

For Vaddio Quick-Connect and EZIM products

FCC Part 15 Compliance

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his/her own expense.

Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This
device must accept any interference including interference that may cause undesired operation of the device.

Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void
the user’s authority to operate this equipment.

ICES-003 Compliance

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set
out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par
le ministère des Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the standards for Emissions and
Immunity and meets the requirements for E4 environment. This product complies with Class A (E4
environment). In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.

Standard(s) To Which Conformity Is Declared:
EMC Directive 89/336/EEC
EN 55022A Conducted and Radiated Emissions
EN 55024 Electromagnetic Compatibility - Immunity
EN 61000-4-2 Electrostatic Discharge Requirements
EN 61000-4-3 Radiated Electromagnetic Field Requirement
EN 61000-4-4 Electrical Fast Transients / Burst Requirements
EN 61000-4-5 Surge Requirements
EN 61000-4-6 Conducted Immunity Requirements
EN 61000-4-8 Power Frequency Magnetic Field Requirements
EN 61000-4-11 Voltage Dips, Interrupts and Fluctuations Requirements

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 10 of 12

WARRANTY INFORMATION
Hardware* Warranty - One year limited warranty on all parts. Vaddio warrants this product against defects

in materials and workmanship for a period of one year from the day of purchase from Vaddio. If Vaddio
receives notice of such defects during the warranty period, they will, at their option, repair or replace
products that prove to be defective.

Exclusions - The above warranty shall not apply to defects resulting from: improper or inadequate

maintenance by the customer, customer applied software or interfacing, unauthorized modifications or
misuse, operation outside the normal environmental specifications for the product, use of the incorrect power
supply, improper extension of the power supply cable or improper site operation and maintenance.

Vaddio Customer service – Vaddio will test, repair, or replace the product or products without charge if the

unit is under warranty and is found to be defective. If the product is out of warranty, Vaddio will test then
repair the product or products. The cost of parts and labor charge will be estimated by a technician and
confirmed by the customer prior to repair. All components must be returned for testing as a complete unit.
Vaddio will not accept responsibility for shipment after it has left the premises.

Vaddio Technical support - Vaddio technicians will determine and discuss with the customer the criteria for

repair costs and/or replacement. Vaddio Technical Support can be contacted through one of the following
resources: e-mail support at [e-mail] or online at www.vaddio.com

Return Material Authorization (RMA) number - Before returning a product for repair or replacement,

request an RMA from Vaddio’s technical support. Provide a technician with a return phone number, e-mail
address, shipping address, and product serial numbers and describe the reason for repairs or returns as well
as the date of purchase and proof of purchase. Include your assigned RMA number in all correspondence
with Vaddio. Write your assigned RMA number on the shipping label of the box when returning the product.
Please see Vaddio’s website for current RMA policies and procedures.

Voided warranty – The warranty does not apply if the original serial number has been removed or if the

product has been disassembled or damaged through misuse, accident, modifications, or unauthorized repair.
Cutting the power supply cable on the secondary side (low voltage side) to extend the power to the device
(camera or controller) voids the warranty for that device.

Shipping and handling - Vaddio will not pay for inbound shipping transportation or insurance charges or

accept any responsibility for laws and ordinances from inbound transit. Vaddio will pay for outbound shipping,
transportation, and insurance charges for all items under warranty but will not assume responsibility for loss
and/or damage by the outbound freight carrier. If the return shipment appears damaged, retain the original
boxes and packing material for inspection by the carrier. Contact your carrier immediately.

Products not under warranty - Payment arrangements are required before outbound shipment for all out of

warranty products.

*Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in
accordance with industry standard practices.

.

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 11 of 12

Toll Free: 800-572-2011 ▪ Phone: [phone] ▪ FAX: [phone]

©2008 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing
subject to change. Vaddio, WallVIEW, Quick-Connect, EZIM, HSDS and PowerRite are registered trademarks of Vaddio. All other

trademarks are property of their respective owners. Document Number 341-660 Rev. B

WallVIEW Universal PRO EagleEye Installation and User Guide 341-660 Rev. B Page 12 of 12

9433 Science Center Drive, Minneapolis, MN 55428

www.vaddio.com
