IN-WALL RECESSED CAMERA MOUNTING SYSTEMS

Recessed Camera Mounting Systems for Vaddio™, Sony®, Polycom®, LifeSize® and
Cisco

The Vaddio IN-Wall camera mounting systems are an attractive way to mount PTZ cameras on a wall where room
aesthetics are critical. These mounting systems use the depth of the wall cavity to minimize the camera’s extension
into the room while providing a finished look to the installation.

Cameras from Vaddio, Sony BRC series, Sony EVI series, Cisco (Precision HD, PrecisionHD 1080p, Precision60),
Polycom (EagleEye, EagleEye 1080 HD an EagleEye IV) and LifeSize (4X and 10X) were selected and the camera
enclosures were carefully designed and sized to fit the Vaddio EZCamera™ Interface Module (EZIM™) in the back
of the box to enable use of the Vaddio Quick-Connect™ CCU and PRO Cat-5 cabling systems for applicable
cameras (see below). For the EVI-D70/80/90 the Vaddio EZCamera Shoe is attached to the back of the camera.
The in-wall mounting box can be installed during room build-out, and the camera platform and face frame can be
added at a later time. All of the parts are powder coated in a white finish, but can be painted to match any décor.

®

PTZ Cameras.

Images: IN-Wall Systems, Top Row (left to right) Vaddio RoboSHOT™ and HD-Series (HD-18/19/20/22/30/USB), LifeSize 10X and 4X, Cisco Precision 60
and PrecisionHD. Bottom Row (left to right): Polycom EagleEye and Sony EVI-D100, EVI-D70, EVI-HD1, BRC-Z330/Z700/H700 (select cameras shown).

W

HAT’S INCLUDED

Each IN-Wall Recessed PTZ Camera Mounting System

cludes:

in
 Wall Box Enclosure for the Camera

Face


 Heavy Duty Ca
 Mounting


Frame

Do

cumentation

mera Platform

Hardware

(Cameras not included)

T

ECHNICAL FEATURES

Back Box Enclosure

Deep

The 3-15/16” deep metal wall box uses the maximum
depth of a standard 2” x 4” framed wall cavity and
minimizes the camera’s protrusion into the room.

Cable Management

Each Enclo

sure is outfitted with three (3) conduit
knockouts (2-sides, 1-top) for flexibility and easy access
to cabling. The bottom of each wall box and platform has
an additional cable slot for running standard cables to the
cameras.

S

UPPORTED

C

MERA

S

STEMS

The Vaddio IN-Wall Enclosures are available for most
of the best-selling cameras worldwide including Vaddio,
Sony, Polycom, Cisco, LifeSize and Panasonic

®

cameras.

IN-W

ALL

IN-Wall Part

P

RT

#

S

Number

999-2225-018

999-2225-118 Vaddio RoboSHOT 12 and 30 Models

999-2225-012

999-2225-014

999-2225-015

999-2225-016

999-2225-019

999-2225-020 Cisco Precision 60

999-2225-220 LifeSize 10X PTZ

See dra

wings at vaddio.com for dimensional information.

S

UPPORTED CAMERA PLATFORMS

Supported Camera Platforms

ClearVIEW™ and PowerVIEW™ HD-Series Cameras
(HD-18/19/20/22/30 and HD-USB)

Vaddio ZoomSHOT and WideSHOT, Sony EVI-D70 ,
Vaddio WallVIEW 70 System

Sony EVI-HD1, Vaddio WallVIEW CCU or PRO HD1
PTZ System, WallVIEW EagleEye 1080 HD and
Polycom EagleEye 1080 HD

Polycom EagleEye and EagleEye IV, Vaddio WallVIEW
PRO EagleEye, Cisco PrecisionHD, Cisco PrecisionHD
1080p and LifeSize 4X PTZ

Sony BRC-H700, Vaddio WallVIEW CCU or PRO H700,
Sony BRC-Z700, Vaddio WallVIEW CCU or PRO Z700,
Sony BRC-H900 Vaddio WallVIEW CCU or PRO H900,
PanasonicAW-HE120 and Vaddio CCU for AW-HE120

Sony BRC-Z330, Vaddio WallVIEW CCU or PRO Z330,
EVI-D80/D90/H100, WallVIEW 80/90
