Vaddio™ AutoTrak™ 2.0

Camera Tracking System featuring Automatic Pan/Tilt/Zoom
Camera Tracking

Part Numbers:
AutoTrak 2.0
Camera Tracking System: North America
999-7250-000

Quick-Connect DVI/HDMI Interface-North America

999-7260-000

Quick-Connect DVI/HDMI Interface-North America

AutoTrak 2.0
Camera Tracking System: International
999-7250-001

Quick-Connect DVI/HDMI Interface-International

999-7260-001

Quick-Connect DVI/HDMI Interface-International

: AutoTrak 2.0-Dual HD-18 Kit with
: AutoTrak 2.0-HD-18 & HD-20 Kit with

: AutoTrak 2.0-Dual HD-18 Kit with
: AutoTrak 2.0-HD-18 & HD-20 Kit with

Optional:

EasyTalk AutoTrak 2.0 Wireless Audio Interface:
998-7230-000: EasyTalk AutoTrak 2.0 Wireless Audio Interface - North America
998-7230-001: EasyTalk AutoTrak 2.0 Wireless Audio Interface - International

©2014 Vaddio - All Rights Reserved. AutoTrak 2.0 with Optional EasyTalk Wireless Audio Interface - Document 342-0382 Rev. E

AutoTrak 2.0 Camera Tracking System

Inside Front Cover - Blank

Inside Front Cover - Blank

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 2 of 52

AutoTrak 2.0 Camera Tracking System

AutoTrak 2.0 System Overview

The AutoTrak 2.0 System is an IR tracking system that consists of an IR
lanyard attached to a rechargeable Lithium Ion Belt Pack that is worn by a

AutoTrak 2.0, 999-7250-000

Dual HD-18 PTZ Cameras

presenter or instructor. Within the lanyard’s cloth cover, there are fifteen
(15) 850nm wavelength IR LEDs on a flat flex circuit that emit IR light that
is tracked by a HD-18 PTZ IR Reference Camera with special IR filters.
The IR position is relayed to the AutoTrak 2.0 CPU which in turn controls
the HD-18 PTZ (or the HD-20 PTZ) Tracking Camera which follows the
presenter and keeps the presenter framed in the camera shot throughout
the presentation environment.

The AutoTrak 2.0 System is designed to integrate with the optional
EasyTalk AutoTrak 2.0 Wireless Audio System. The EasyTalk AutoTrak

2.0 Wireless Audio System includes a HD wireless receiver that receives
the HD wireless microphone audio transmitted from the AutoTrak 2.0 IR
Lanyard and Belt Pack. It also provides audio outputs for connection to
an audio amplifier/speaker system or a video conference system. It
includes a USB output that can directly connect to a PC USB port which
will provide connection of the microphone and room speaker audio for use
with Unified Communication clients such as Skype, Microsoft Lync,
Google+ and others.

AutoTrak 2.0, 999-7260-000
HD-18 PTZ IR Reference and
HD-20 PTZ Tracking Camera

There are two versions of AutoTrak 2.0:

 AutoTrak 2.0 Dual HD-18

999-7250-000 North America
999-7250-001 International
Includes: One (1) HD-18 PTZ IR Reference Camera and one (1)
HD-18 Tracking Camera

 AutoTrak 2.0 HD-18/HD-20

999-7260-000 North America
999-7260-001 International
Includes: One (1) HD-18 PTZ IR Reference Camera and one (1)
HD-20 PTZ Tracking Camera

The HD-18 and HD-20 cameras use the Vaddio Quick-Connect DVI/HDMI Interface to provide Cat-5e
cabling systems for ease of set up and installation. The system can be permanently installed or
configured as a cart system for portability and ease of positioning in the largest of lecture halls. Each
system includes a dual camera mount which can be wall mounted or mounted on top of the Vaddio Edge
series video carts.

The optimum operating range or the system (from the IR Lanyard to the IR Reference camera) is between
12’ (3.65m) and up to 40’ (12.2m). System positioning is critical for proper and consistent operation.

The AutoTrak 2.0 can be installed as a standalone system or can be used in conjunction with myriad
Vaddio Presenter controlled solutions including AutoPresenter™, PresenterPOD™, ControlVIEW XHD™,
TouchVIEW™, AutoVIEW™ IR, StepVIEW™ Mats, and MicVIEW™. As an added benefit, once the
AutoTrak 2.0 system is configured the Mouse, Keyboard and Monitor I/O devices can be removed from
the system to ensure the system isn’t subject to unauthorized modification.

The AutoTrak’s camera tracking has been improved and the new SmoothTrak™, AutoTilt™ and
SmoothTilt™ functions have been implemented. AutoTilt works to keep the presenter centrally framed in
the shot as they move side to side and now closer and further away from the camera too. SmoothTrak
provides for a much more natural set of camera movements as the presenter moves around the room.
SmoothTilt allows the camera to follow the presenter in multiple directions for concurrent pan and tilting of
the camera, which more closely resembles a professional production.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 3 of 52

AutoTrak 2.0 Camera Tracking System

p

Intended Use:

Before operating the device, please read the entire manual thoroughl y. The s ystem was designed, built and teste d for
use indoors, and with the provided power supply and cabling . The use of a power supply other than the one provided
or outdoor operation has not been tested and could damage the device and/or create a potentially unsafe operating
condition.

Important Safeguards:

Read and understand all instructions before using. Do n ot operate a ny device if it has been dropped or damaged. In
this case, a Vaddio technician must examine the product befo re operating. To reduce the risk of electric shock, do
not immerse in water or other liquids and avoid extremely humid conditions.

Use only the power supply provided with the system. Use of any unauthorized power
supply will void any and all warranties.

Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not
work well for professional installations and can be the cause of intermittent conn ections which
can result in the RS-232 control line failing and locking up, and/or compro mising the HSDS™
signals. For best results please use standard RJ-45 connectors and test all cables for proper

in-outs prior to use and connection to Vaddio product.

Please treat the AutoTrak 2.0
CPU like a computer.

Save These Instructions:

The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User G uides and most pertinent product dra wings
for the Vaddio product line on the Vaddio website. These documents can be downloaded from www.vaddio.com free.

UNPACKING:

Carefully remove all of the parts for the AutoTrak 2.0 999-7250-000 Dual HD-18 Kit with Quick Connect DVI/HDMI Interface (North
America Only) packaging:

 One (1) AutoTrak 2.0 CPU (closed system preloaded with AutoTrak 2.0 software and video card)
 One (1) AC Cord Set for AutoTrak 2.0 CPU
 One (1) PS/2 Keyboard and PS/2 Mouse
 One (1) IR and Audio Lanyard with attached cable with 5-pin mini XLR connector,
 One (1) Audio-Technica AT8439 Cable Clip to attach Lanyard Central Medallion to clothing
 One (1) Triple Circle Magnet Kit for attaching the Lanyard Central Medallion to clothing from the inside
 One (1) Belt Pack Unit “BPU” with 1” (1/4 wave) RP-SMA straight antenna and attached belt clip with rechargeable lithium-ion

battery pack and 5 VDC USB charging power supply for North America

 One (1) USB Type A-Male to micro-B-Male Charging Cable
 One (1) Vaddio PowerRite 12 VDC, 1A Switching Power Supply with North American Power Cord
 One (1) AutoTrak POD Kit (for presets and rescan) and Manual (in separate box)

AutoTrak 2.0-Dual HD-18 Kit:

 One (1) *HD-18 PTZ Camera with AutoTrak 2.0 Software preloaded - Tracking Camera
 One (1) Quick-Connect DVI/HDMI SR Interface (998-1105-018) for Tracking Camera
 One (1) 24VDC, 2A, Switching Power Supply with North American Power Cord
 One (1) *HD-18 PTZ Camera with AutoTrak 2.0 Software preloaded – IR Reference Camera
 One (1) 37mm female lens ring adapter, One (1) 37mm to 58mm adapter ring, One (1) 58mm polarizing filter, One (1) 58mm

band-pass IR filter, all parts adapters and filters attached to HD-18 Camera

 One (1) AutoTrak 2.0 Quick-Connect Box (998-1105-020)
 One (1) Standard Quick-Connect Box (998-1105-001)
 One (1) 24VDC, 2A, Switching Power Supply with North American Power Cord
 One (1) 18”/45.8cm Video Cable (BNC to RCA)
 One (1) 12”/30.48cm Cat 5e Patch Cable
 One (1) 998-2100-000 - Vaddio IR Remo te & Manual (2-AAA batteries not included)
 One (1) **535-2000-233 Stacked Dual Mount for two cameras and Mounting Hardware
 Three (3) 998-1001-232 Contr ol Adapters
 One (1) 998-7200-232 Control Adapter for use with the AutoPresenter - (Only needed when used with the AutoPresenter for

Tracking Camera PTZ Presets)

 One (1) AutoTrak Pod Kit 998-7200-110 (for presets and rescan) and Manual (in separate box)
 Documentation and Manuals (Document Number (342-0382)

For the 999-7260-000 System¨ Start with the 999-7250-000 System
Remove: One (1) *AutoTrak HD-18 PTZ Camera with AutoTrak 2. 0 Software preloaded - Tracking Camera
Add: One (1) *AutoTrak HD-20 PTZ Camera with AutoTrak 2.0 Software preloaded - Tracking Camera

Please shut down

the CPU before

removing power,

like all business
computers, or…

The AutoTrak 2.0 CPU is a computer running a Linux OS. Please do not
remove power from the AutoTrak 2.0 CPU without first shutting the system
down, as you would any other busin ess computer. Only after the AutoTrak

2.0 CPU has been shut down, it is safe to remove power. Consistently power
cycling the CPU with the Rear Power Switch ma y cause the system to load
improperly, which could potentially result in data errors requiring factory
service.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 4 of 52

AutoTrak 2.0 Camera Tracking System

UNPACKING:
Carefully remove all of the parts for the AutoTrak 2.0 999-7250-001 (Int’l) Dual HD-18 Kit with Quick
Connect DVI/HDMI Interface) packaging:

 One (1) AutoTrak 2.0 CPU (closed system preloaded with AutoTrak 2.0 software and video card)
 One (1) Euro Power Cord for AutoTrak 2.0 CPU
 One (1) UK Power Cord for AutoTrak 2.0 CPU
 One (1) PS/2 Keyboard and PS/2 Mouse
 One (1) IR and Audio Lanyard with attached cable with 5-pin mini XLR connector
 One (1) Audio-Technica AT8439 Cable Clip to attach Lanyard Central Medallion to clothing
 One (1) Triple Circle Magnet Kit for attaching the Lanyard Central Medallion to clothing
 One (1) Belt Pack Unit “BPU” with 1” (1/4 wave) RP-SMA straight antenna and attached belt clip with

rechargeable lithium ion battery pack

 One (1) 5 VDC USB Charging Supply for Europe
 One (1) 5 VDC USB Charging Supply for UK
 One (1) USB Type A-Male to micro-B-Male Charging Cable
 One (1) Vaddio PowerRite 12 VDC, 1A Switching Power Supply
 One (1) Euro Power Cord
 One (1) UK Power Cord
 One (1) AutoTrak POD Kit (for presets and rescan) and Manual (in separate box)

AutoTrak 2.0-Dual HD-18 Kit:

 One (1) *HD-18 PTZ Camera with AutoTrak 2.0 Software preloaded - Tracking Camera
 One (1) Quick-Connect SR Interface (998-1105-016) for Tracking Camera
 One (1) 24VDC, 2A, Switching Power Supply
 One (1) Euro Power Cord
 One (1) UK Power Cord
 One (1) *HD-18 PTZ Camera with AutoTrak 2.0 Software preloaded - IR Reference Camera
 One (1) 37mm female lens ring adapter, One (1) 37mm to 58mm adapter ring, One (1) 58mm

polarizing filter, One (1) 58mm band-pass IR filter, all parts adapters and filters attached to HD-18
Camera

 One (1) AutoTrak 2.0 Quick-Connect Box (998-1105-020)

 One (1) Standard Quick-Connect Box (998-1105-001)
 One (1) 24VDC, 2A, 50/60Hz 110-240V Switching Power Supply (451-2000-0024)
 One (1) Euro Power Cord
 One (1) UK Power Cord
 One (1) 18”/45.8cm Video Cable (BNC to RCA)
 One (1) 12”/30.48cm Cat 5e Patch Cable
 One (1) 998-2100-000 - Vaddio IR Remote & Manual (2-AAA batteries not included)
 One (1) **535-2000-233 Stacked Dual Mount for two (2) cameras and Mounting Hardware
 Three (3) 998-1001-232 Control Adapters
 One (1) 998-7200-232 Control Adapter for use with the AutoPresenter - (Only needed when used with

the AutoPresenter for Tracking Camera PTZ Presets)

 One (1) AutoTrak Pod 998-7200-110
 Documentation and Manuals (Document Number (342-0382)

For the 999-7260-001 System - Start with the 999-7250-001 System
Remove: One (1) *HD-18 PTZ Camera with AutoTrak 2.0 Software preloaded - Tracking Camera
Add: One (1) *HD-20 PTZ Camera with AutoTrak 2.0 Software preloaded - Tracking Camera

*Note 1: The Vaddio HD-18 and HD-20 cameras are preloaded with AutoTrak 2.0 control protocols which

differ from the modified VISCA type control codes normally used in the stock HD-18 PTZ Camera. The
HD-18 and HD-20 cameras will work with the Vaddio IR Remote but is recommended that the PTZ
positions of the camera be set with the AutoTrak 2.0 Software. The HD-18 and HD-20 AutoTrak 2.0
cameras will not work with any other controller other than AutoTrak 2.0 at this time.

**Note 2: The stacked camera arrangement is required for the AutoTrak 2.0 software to track properly.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 5 of 52

AutoTrak 2.0 Camera Tracking System

AutoTrak 2.0 Components:
AutoTrak 2.0 CPU

The AutoTrak 2.0 CPU is a 1-RU rack mount computer that will come preloaded with the AutoTrak 2.0
software. The exact specifications are subject to change and any changes that will be made will be in the
spirit of product improvement only. The AutoTrak 2.0 CPU uses an Intel® Atom™ Dual Core Processor,
Intel Graphics Media Accelerator, 1GB DDR2 Memory, four (4) RS-232 Ports, six (6) USB 2.0 ports, two
(2) PS/2 interfaces for keyboard/mouse, 16GB Compact Flash and Video capture card.

Note: The AutoTrak 2.0 CPU may be subject to change in cosmetics due to the extraordinarily turbulent nature of the PC industry,
parts availability and model year upgrades. If changes are made, Vaddio will be certain to make changes in the documentation
accordingly.

An important feature: After the AutoTrak 2.0 CPU and software is configured using the mouse, keyboard
and monitor, these I/O devices can be removed to prevent any unauthorized access to the system. To
reattach the mouse and keyboard, the system will need to be rebooted to recognize these devices.

 Front Panel Controls of AutoTrak 2.0 Worldwide CPU:

①②

1) Power Indicator: Illuminates when power in on

2) Hard Drive Activity Indicator: Indicates when solid state drive is active

3) Recessed Reset Switch: A Momentary press of this switch resets the system and prepares the

CPU for an orderly shut-down. When the green light blinks, it is ready to be turned off or it is safe
to restart (power cycle).

4) USB Ports: Two (2) Front Panel USB Ports

 Rear Panel of AutoTrak 2.0 Worldwide CPU:

①

1) Power Receptacle: IEC60320 C14 for power cable

2) Power Switch: Turns ON/OFF AutoTrak 2.0 CPU

Shut Down
CPU First

3) COM PORT 1: RS-232 Port for HD-18 IR Reference Camera

4) COM PORT 2: RS-232 Port for HD-18 Tracking Camera

5) COM PORT 3: Use RS-232 Port 3 when AutoTrak 2.0 is used with the AutoTrak POD or the
AutoPresenter 6x1 HD Switcher

6) RGBHV (on DE-15) Output: To setup and view software menus (800 x 600 @ 60Hz)

7) Ethernet Ports: Not used with AutoTrak 2.0 Application

8) USB Ports: Four USB Ports on the back panel for use with Keyboard, Mouse and USB Flash
Drive

9) Audio I/O: Not used with AutoTrak 2.0 Application

10) Video Input Port: Plug the HD-18 IR Reference Camera into the center yellow composite video
connector

③

②

NOTE: Do not turn the power off with the power switch on the rear panel or rack
power switch unless the computer has been shut down first. Repeated power
cycling without shutting down the computer first will cause harm to the system
(like all other business computers) and any warranties will be voided.

④

④⑤⑥⑦

③

⑧

⑩

⑨

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 6 of 52

AutoTrak 2.0 Camera Tracking System

The IR Lanyard and Belt Pack for use with the AutoTrak 2.0 Camera Tracking Systems:

999-7250-000 and 999-7260-000 North America
999-7250-001 and 999-7260-001 International

⑤

⑥

⑦

④

①

②③

1) IR Lanyard: Cloth covered flat flex circuit with IR LEDs terminates at the Central Medallion

Note: Do not fold the Lanyard Necklace at any time as it contains a
flexible circuit that may cease to work if the necklace is hard folded.

2) Central Medallion: Supplies a connection point for the flat flex cable, contains an integrated

condenser microphone and a rubber over-molded cable strain relief that attaches the 32” cable.

3) 32” (813mm) Cable: Terminates the Central Medallion to the Belt Pack with a 5-Pin Mini XLR-F
connector.

4) Belt Pack: Holds power circuitry, wireless microphone transmitter, transmitter frequency control
switches (see pages 6-7) and rechargeable lithium battery pack.

5) Belt Pack Front Panel Controls: The System on/off controls and LED indicator as well as the
Microphone on/off controls are located on the Belt Pack Control Panel (see page 6-7).

6) Belt Clip: To clip the Belt Pack on a belt like device that the presenter wears.

7) Antenna: 1” (25.4mm) ¼-wave RP-SMA straight antenna to transmit RF wireless audio at 2.4 GHZ

utilizing Adaptive Frequency Hopper (AFH) from the integrated unidirectional microphone element.

The Lanyard’s Central Medallion Clothing Clips:

The system is shipped with two types of clothing clips to keep the
unidirectional mic built-in to the medallion facing the right direction and
keep it from flopping around when the presenter moves their hands and
arms to make a point.

1. A Triple Circle Magnet is a 2-piece magnetic kit meant to attach the
central medallion to the presenter’s clothes with magnets.

 Peel off the adhesive backing cover and place the metal plate to the

back of the medallion and push to make good contact

 Place the Central Medallion next to the clothing (shirt or dress) and

from the back side of the clothing attach the magnet. The magnet
will hold the medallion firmly against the clothing.

Note: Please do not use the magnet solution if the pres enter
has a pacemaker or implantable cardioverter-defibrillator (ICD).
Magnets can negatively affect the operation of these medical
devices. The magnet side is labeled with a caution to warn the
user. Use only the Cable Clip for pacemaker and ICD patients

Attach metal plate
with the adhesive
backing to the back of
the medallion. Use
the triple magnets to
attach trough clothing.

2. Additionally, an Audio-Technica AT8439 Cable Clip is also included.
This clip for clothing is a small and is to be attached to the cable just
below the central medallion’s cable strain relief. The clip will hold the
medallion firmly to the clothing

Attach Cable
Clip to a point
just below the
strain relief.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 7 of 52

AutoTrak 2.0 Camera Tracking System

Belt Pack Control Panel

1) Lanyard Cable Connector (5-pin mini XLR - M): Plug the cable attached to the Lanyard into

the mini XLR connector to allow audio to be received by the Belt Pack and for power to be
provided to the IR LEDs in the Lanyard.

2) Radio: This LED indicates an active radio link with the EasyTalk AutoTrak 2.0 Wireless Audio

Interface. Solid blue LED indicates connection with the AutoTrak 2.0 Wireless Audio Interface.
Flashing blue LED indicates radio link has been lost.

Note: Radio link operates up to 100 feet line of sight of the AutoTrak 2.0 Wireless Audio
Interface.

3) System Power: To use the Belt Pack or IR Lanyard, turn the SYSTEM POWER switch to the on

position and the LED will illuminate. Be sure to turn off the SYSTEM POWER switch when the
system is not in use to save the battery life. The Rechargeable Lithium Ion Battery Pack provides
up to ten (10) hours with full charge.

4) Microphone ON/OFF: This switch turns the wireless microphone on or off at the Belt Pack

allowing the presenter to use an existing room system microphone instead, or for momentary
microphone muting.
Note: The System Status light on the EasyTalk AutoTrak 2.0 Wireless Audio Interface will light if
the microphone signal is detected. If the Microphone is turned off at the Belt Pack, the System
Status light will not light.

5) 1” ¼-Wave Antenna: Used to transmit the wireless microphone audio back to the AutoTrak 2.0

Wireless Audio Interface.

①

②

Note: It is highly recommended that the Rechargeable Lithium Ion Battery Pack be
fully charged prior to using the Belt Pack for the first time!

③④

⑤

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 8 of 52

AutoTrak 2.0 Camera Tracking System

Belt Pack Views:

①

Belt Pack and Battery Compartment:

1) Removable Battery Compartment Cover: To open, carefully press down at the top of the

Removable Battery Cover near the center of the small opening and slide the cover downward. To
replace the Removable Battery Cover, start sliding the cover on at the bottom of the Battery Pack
Compartment and slide cover upward to the top to the small opening until the cover latches in place.

2) Micro-B USB Charging Port: The Belt Pack rechargeable battery can be charged by the micro-B
USB connector on the bottom side of the belt pack enclosure. A USB charger is included with the
Belt Pack. The Belt Pack can also be recharged by using a micro-B USB to USB adapter which can
be connected to a PC or Laptop USB port for recharging. Use only the charging power supply
provided.

3) Dip Switches: There are two (2) 4-position dip switches located on the circuit board, SW4 and SW5.
They provide configuration settings for Microphone Gain Control, Filtering, Compression and
Microphone Filtering and Pairing of the Wireless Belt Pack to the AutoTrak 2.0 Wireless Audio
Interface.

4) Rechargeable Lithium Ion Battery: The battery is housed and attached inside the Battery
Compartment and under normal use should last up to ten (10) hours when fully charged.

5) Battery Indicator LED: The Battery Indicator LED is located on the bottom of the Belt Pack.
 When the USB Charger is not connected to the Belt Pack: The Battery Indicator LED will be

off when battery power is adequate for the Belt Pack. The Battery Indicator LED will blink Red
indicating that the battery power is low and needs to be recharged soon.

 When the USB Charger is connected to the Belt Pack: The Battery Indicator LED will be

Yellow when the battery is charging. The Battery Indicator LED will be Green when the battery is
fully charged. Average charging time from dead battery to full charge is 10 hours.

6) Radio Pairing Button SW3: push this button in conjunction with the Pairing button on the front panel
of the Optional Wireless Receiver to “pair” the transmitting Belt Pack with the Receiver.

⑤

②

④

③

⑥

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 9 of 52

AutoTrak 2.0 Camera Tracking System

Belt Pack Dip Switch Settings:

Switch

Number

1 Not Used
2 ON/OFF - IR LED’s in Lanyard

3 ON/OFF - Radio in Belt Pack *Turn off when not

using Optional EasyTalk Wireless Receiver

4 Clear Pairing (pairing is required for proper operation)

1 ON/OFF: ON adds 3dB Gain Boost on Microphone
2 ON/OFF: ON adds 6dB Gain Boost on Microphone
3 ON/OFF: ON adds 9dB Gain Boost on Microphone
4 ON/OFF: Automatic Gain Control Mode

Dip Switch Function

Switch Set 4

Switch Set 5

SW5

SW3

SW4

Belt Pack Configuration Settings:

The Belt Pack has a number of custom settings that can be enabled or disabled for specific applications.
These settings can be applied by activating dip switch settings on the two (2) 4-position dip switches SW4
and SW5 located on the Belt Pack Circuit Board.

Switch Set 4:

 SW4: Dip Switch 1 - Not Used
 SW4: Dip Switch 2 - IR Transmitter: ON enables the IR Transmitter LED’s in the IR Lanyard. OFF

disables the IR Transmitters in the Lanyard and the camera tracking will not function.

 SW4: Dip Switch 3 - Radio in Belt Pack: ON enables the Radio circuit in the Belt Pack. OFF

disables and will turn off the Radio circuit to increase battery life. Make sure this switch is in the ON
position for use with Audio Interface (if applicable). It ships from the factory in the OFF position.

Note: Turn OFF Dip Switch 3 when not using the optional EasyTalk AutoTrak 2.0
Wireless Audio Interface with the AutoTrak 2.0 System.

 SW4: Dip Switch 4 - Clear Pairing: ON clears the pairing setting of the receiver in the Belt Pack.
.

Switch Set 5:

 SW5: Dip Switch 1 - 3dB Gain Boost: Enable adds a three (3) dB gain to the microphone audio.

Disable provides zero gain.

 SW5: Dip Switch 2 - 6dB Gain Boost: Enable adds a six (6) dB gain to the microphone audio.

Disable provides zero gain.

 SW5: Dip Switch 3 - 9dB Gain Boost: Enable adds a nine (9) dB gain to the microphone audio.

Disable provides zero gain.

Note: The following Gain Boost Switches, 1 through 3, can be used individually or in
combination. For example, if Dip Switch 1, 3dB Gain and Dip Switch 2, 6dB Gain are
both ON, they will add a total of 9 dB of gain

 SW5: Dip Switch 4 - Automatic Gain Control: ON enables an Automatic Gain Control function that

maintains a constant audio level to regulate soft talkers as well as loud talkers. OFF disables the
Automatic Gain Control, of course.

Optional: AutoTrak 2.0 Wireless Audio Interface for AutoTrak 2.0 Sy stems:

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 10 of 52

AutoTrak 2.0 Camera Tracking System

998-7230-000: EasyTalk AutoTrak 2.0 Wireless Audio Interface-North America
998-7230-001: EasyTalk AutoTrak 2.0 Wireless Audio Interface-International

 Front Panel Controls

①② ③ ④ ⑤⑥⑦

1) Power ON/OFF: This switch turns the power for the AutoTrak 2.0 Wireless Audio Interface on or off.

To use, push the power button until the blue LED is lit and the system is ready for operation.

2) Pair: This button initiates the automatic pairing (Pairing is the matching of the same Adaptive

Frequency Hopper AFH hopping sequence for both devices) for the Belt Pack Radio Transmitter and the
AutoTrak 2.0 Wireless Audio Interface Radio Receiver in the AutoTrak 2.0 Wireless Audio Interface.

3) Mute: This control mutes (turns off) the audio outputs of the AutoTrak 2.0 Wireless Audio Interface.

4) Volume: The + (plus) and – (minus) buttons are used to raise and lower the audio outputs (Balanced

and Unbalanced) from the AutoTrak 2.0 Wireless Audio Interface.

5) Audio Level: This LED display will indicate the relative audio level output (from all sources) of the

AutoTrak 2.0 Wireless Audio Interface. Red Line at the top of the LED Display indicates clipping of the
audio signal.

6) Radio, EQ Filter and Compressor Status LED’s:

 Radio LED: Solid blue light indicates normal operations. Fast flashing indicates no link

established with the Belt Pack Wireless Microphone. Slow flashing indicates the Pairing cycle is in
progress.

 EQ Filter: Blue light on indicates the EQ Filter is turned on. Blue light off indicates the EQ Filter is

off. When EQ Filter is enabled, it helps increase speaker intelligibility for voice applications.

 Compressor: Solid blue light indicates that the Compressor is on. No light indicates that the

Compressor is off. Compressor on minimizes the potential of “clipping” by attenuating the audio
signals that exceed the maximum output levels.

7) Antenna: The 4” antenna is tuned to receive 2.4 GHZ signals from the IR Lanyard Belt Pack
Microphone. Note: If the AutoTrak 2.0 Wireless Audio Interface is installed deep inside a metal
equipment rack or is surrounded by other metal cased equipment, the antenna may need to be
extended away from the rack to improve reception.

Optional Antenna Extension Kit

The Audio Interface has an Optional Antenna Extension Kit available which will add
approximately 6dB gain to the system and extend the front panel receiver antenna to a
base antenna that would sit on top of the rack. It also includes a longer ½ wave whip
RP-SMA antenna for the belt pack.
See part number: 999-1234-000.

Optional Antenna

Extension Kit

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 11 of 52

AutoTrak 2.0 Camera Tracking System

Optional: AutoTrak 2.0 Wireless Audio Interface/Rear Panel Connections

①②③④⑤⑥⑦

1) 12 VDC, 1.0 Amp Power Connector: The 5.5mm OD and 2.5mm ID power connector should be
plugged into the PowerRite power supply provided by Vaddio. Use of any unauthorized power
supplies will void any and all warranties.

2) RS-232 Control: The DB-9 female connector is provided for 3rd party control systems using the
Wireless Audio Interface Application Protocol Interface (API). See the Command List.

3) Settings (8-Position Dip Switch): The eight position dip switch is used for system configuration of
the AutoTrak 2.0 Wireless Audio Interface:

 Dip Switch 1 - Compressor: Enable adds a Dynamic Range Compressor for the Audio Line

Level Outputs (balanced or unbalanced). Disable turns it off.

 Dip Switch 2 - Speaker EQ Filter: Enable adds a specialized output filter for improved

intelligibility for voice applications. Disable turns it off.

 Dip Switch 3 - ON Position/USB Conference Mode: Enable (Dip Switch 3 On) creates the

desired audio mixing (Near and Far ends) for USB conferencing applications such as Skype.
Disable turns off the USB Conference Mode.
o Note: In the USB Conference Mode, the PC USB Speaker Audio is sent to the balanced and

unbalanced audio line outputs, which allows the Far End Audio to be presented in the room.
The Belt Pack Wireless Microphone Audio is also sent to the PC to send to the Far End.

o The AutoTrak 2.0 Wireless Audio Interface will also be recognized as a USB Audio Device by

the PC with recording (the Belt Pack Wireless Microphone Audio) and playback (the Speaker
Audio) capabilities. Disable turns the USB Conference Mode off.

 Dip Switch 3 - OFF Position/USB Record Mode: Disable (Dip Switch 3 Off) creates a USB

Record Mode for PC Audio Recording (PC requires Audio Recording Software-not included) and
Playback through the USB port (Audio output through the Balanced or Unbalanced Audio Line
Outputs).
o The AutoTrak 2.0 Wireless Audio Interface will be recognized as a USB Audio Device by the

PC with recording (the Belt Pack Wireless Microphone Audio) and playback (the Speaker
Audio) capabilities.

 Dip Switch 4 - Radio ON/OFF: ON enables the Radio Receiver for the Wireless Microphone on.

OFF turns it off, naturally.

 Dip Switch 5 - Baud Rate Selection ON/OFF: OFF sets the Baud Rate to the default 9600bps.

ON sets the Baud Rate to 38400bps.

 Dip Switch 6 - Front Panel Buttons Lock ON/OFF: ON locks the Front Panel Buttons and

disables the buttons from functioning. OFF allows the front panel buttons to be used.

 Dip Switch 7 - Software Control ON/OFF: When ON, dip switches 1, 2, 3, 4, and 8 are ignored

to allow full serial control of the audio interface

 Dip Switch 8 - Resets to Factory Defaults ON/OFF: When ON and power is plugged in, the

interface is set to factory defaults. Leave OFF for normal operation.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 12 of 52

AutoTrak 2.0 Camera Tracking System

4) GPIO Port: The GPIO Port provides the ability to interface with external control systems. Inputs

are logic level low. Output is an open collector.

Pin Function

1
2
3
4
5
6
7

Power (12 VDC)
Mute Toggle (Input)
Mute Status (Output)
Volume Up (Input)
Volume Down (Output)
Not Used
Ground

5) USB Type B Connector: This connector is used to interface with the Host PC for soft-client

codec type applications.

6) Audio Outputs: There are two (2) Audio Outputs on the rear panel:

 Balanced Audio Output Jack: Balanced Line Level (on XLR - M connector) +4dBu
 Unbalanced Audio Output Jack: Unbalanced Line Level (on RCA-F connector) -10dbV

Pairing Procedure for Belt Pack Pairing with the AutoTrak 2.0 Wireless Audio Interface:

A. Place the Belt Pack in close proximity to the AutoTrak 2.0 Wireless Audio Interface.
B. Remove the Battery Compartment Cover: To open: See top of page 9.
C. Locate Pairing Button Switch labeled SW3. Press the button and release. The Radio LED on the

Belt Pack will begin blinking at a slow rate.

Important Note: The Pairing button on the AutoTrak 2.0 Wireless Audio Interface must
be pushed within ten (10) seconds of pressing the pairing button SW3 on the Belt Pack or
pairing will not occur!

D. Press the Pair Button on the front panel of the EasyTalk AutoTrak 2.0 Wireless Audio Interface.
E. The Belt Pack and the AutoTrak 2.0 Wireless Audio Interface will automatically sync with each

other. The blue Radio LED’s on the Belt Pack and the AutoTrak 2.0 Wireless Interface will
illuminate solid blue indicating they are paired and ready for operation.

Lanyard, Belt Pack Controls:

The central medallion of the lanyard has an attached, strain-relieved, 32” cable
that terminates to a 5-pin mini XLR female connector. Attach the 5-pin mini XLR
to the 5-pin mini XLR male connector on the belt pack. The microphone element
is on the top of the central medallion. The lanyard material houses a flat flex type
circuit where the IR LEDs are mounted. After the initial setup is complete, the
presenter should slip the lanyard over their head and position the medallion away
from the presenter and face the Vaddio logos on the lanyard cloth cover out,

24”
Lanyard
Necklace

toward the cameras. Clip the belt pack onto the clothing, belt or waistband
securely. Please avoid dropping the belt pack! A smashed Belt Pack isn’t a
happy thing. However, replacements are available.

Central
Medallion

Power to illuminate the IR LEDs is supplied from the Belt Pack and if the System
Power Switch is ON, the IR LEDs will illuminate at 850 nanometers (out of the
range of visible light for mere humans). Each Lanyard has 15 IR LEDs spread

32” Cable to
Belt Pack

out evenly throughout the Lanyard Necklace. This invisible light is picked up by
the IR reference camera of the AutoTrak 2.0 System and information is sent to
the Tracking Camera in order to follow the presenter throughout the presentation
environment.

Note: Do not fold the Lanyard Necklace at any time as it con tains a
flexible circuit that may cease to work if the necklace is hard folded.
Folding the Lanyard Flex Circuit will void any and all warranties.

AutoTrak 2.0 Belt
Pack and Lanyard

Mic
Element

Belt Pack

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 13 of 52

AutoTrak 2.0 Camera Tracking System

(

)

(

)

Basic System Configuration 1:

AutoTrak 2.0 999-7250-000 Dual HD-18 Kit with Quick Connect DVI/HDMI Interface (North America Only)

AutoTrak 2.0 IR Lanyard,
attached cable, Rechargeable
Belt Pack and 1-inch RP-SMA

HD-18

IR Reference

Camera with

Adapters and

Filters

Composite Video

feed to AutoTrak

2.0

AutoTrak 2.0 Quick-Connect

Cat-5e
Power to
EZ
Port

Note: Belt Pack is capable of

transmitting Wireless Mic Audio at 2.4

GHz to Optional EasyTalk AutoTrak 2.0

Wireless Audio Interface

HD-18

Tracking Camera

Quick-Connect DVI/HDMI - SR

Interface 998-1105-018

Cat-5e

Power to Camera
Differential HSDS Video from Camera

Cat-5e Cable to EZ Power Video Port

24 VDC
PWR
Supply

DVI-D or
HDMI with
adapter

YPbPr

Instructor’s Confidence
Monitor

(Not Included)

Simulated Video Feed

HDMI

Video

C60 Codec

Not Included

RS-232
Cat-5e

HD Video Monitors

Really Simulated Video Feeds

(Not Included)

Optional Wireless Audio

EasyTalk AutoTrak 2.0 Wireless Audio Interface
Receiving Audio from Wireless Belt Pack at 2.4 GHz

RGBHV Monitor

Not Included

4” RP-SMA
Antenna

RGBHV

Serial to Cat-5e
Control Adapters
Use Adapter P/N:
998-1001-232 on
these Ports

Port 2

Port 1

Balanced Line Level (on XLR +4dBu) or
Unbalanced Line Level (on RCA -10dBV)

AutoTrak 2.0 CPU

Keyboard & Mouse

Sound System
(Not Included)

Box 998-1105-020

CVBS
BNC to RCA

Cat-5e

AutoTrak

2.0

Dual HD-18

Mount

Cat-5e

Power to

Cat-5e

Std Quick-Connect
Box 998-1105-001

CVBS in
Video 2

Camera

CVB from

Camera

Cat-5e

24 VDC
PWR
Supply

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 14 of 52

AutoTrak 2.0 Camera Tracking System

(

)

(

)

Basic System Configuration 2:

AutoTrak 2.0 999-7260-000 HD-18 IR Reference Camera and HD-20 Tracking Camera Kit with Quick Connect DVI/HDMI
Interface (North America Only)

AutoTrak 2.0 IR Lanyard,
attached cable, Rechargeable
Belt Pack and 1-inch RP-SMA

HD-18

IR Reference

Camera with

Adapters and

Filters

Composite Video

feed to AutoTrak

2.0

Note: Belt Pack is capable of

Transmitting Wireless Mic Audio at 2.4

GHz to Optional EasyTalk AutoTrak

2.0 Wireless Audio Interface

HD-20

Tracking Camera

AutoTrak 2.0 Quick-Connect

Box 998-1105-020

Cat-5e
Power to
EZ
Port

CVBS
BNC to RCA

Cat-5e

AutoTrak

2.0

HD-18-

HD-20
Mount

Cat-5e

Quick-Connect DVI/HDMI - SR

Interface 998-1105-018

Cat-5e

Power to Camera
Differential HSDS Video from Camera

Cat-5e Cable to EZ Power Video Port

24 VDC
PWR
Supply

DVI-D or
HDMI with
adapter

YPbPr

Instructor’s Confidence

(Not Included)

Monitor

Simulated Video Feed

T C60 Codec

Not Included

RS-232
Cat-5e

Cat-5e

Optional Wireless Audio

EasyTalk AutoTrak 2.0 Wireless Audio Interface
Receiving Audio from Wireless Belt Pack at 2.4 GHz

Balanced Line Level (on XLR +4dBu) or
Unbalanced Line Level (on RCA -10dBV)

HD Video Monitors

Simulated Video Feeds

(Not Included)

RGBHV Monitor

Not Included

4” RP-SMA
Antenna

RGBHV

AutoTrak 2.0 CPU

Serial to Cat-5e
Control Adapters
Use Adapter P/N:
998-1001-232 on
these Ports

Port 2

Std Quick-Connect
Box 998-1105-001

CVBS in
Video 2

Port 1

Keyboard & Mouse

Sound System
(Not Included)

Cat-5e

Power to

Camera

CVBS

from

Camera

24 VDC
PWR
Supply

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 15 of 52

AutoTrak 2.0 Camera Tracking System

The AutoTrak 2.0 CPU, Camera and Software Operating Instructions

The AutoTrak 2.0 CPU is a 1-RU rack
mount computer that comes preloaded
with the AutoTrak 2.0 software. It is a
closed system based on a Linux operating
system.

One More Time: The AutoTrak 2.0 CPU is a computer running a Linux OS. Please do not remove power from the AutoTrak 2.0
CPU without first shutting the system down, as you would any other business computer. It is safe to remove power only after the
AutoTrak 2.0 CPU has been shut down. Consistently power cycling the CPU with the Rear Power Switch will eventually wreck the
AutoTrak 2.0 CPU and void the warranty.

The AutoTrak 2.0 CPU uses an Intel® Atom™ Dual Core Processor, Intel Graphics Media Accelerator,
1GB DDR2 Memory with six (6) USB ports, four (4) RS-232 Ports, two (2) PS/2 interfaces for
keyboard/mouse, 16GB Compact Flash and Video capture card. CPU specifications and cosmetics are
subject to change.

Getting Started:

1) Take the AutoTrak 2.0 CPU out of the box (typical) and start the system connection.

2) Connect two (2) of the 998-1001-232 control adapters (check part numbers carefully) to serial com
ports 1 and 2. The IR Reference camera will be connected to Port 1 and the Tracking Camera will be
connected to Port 2.

3) Connect the Keyboard and the Mouse to the AutoTrak 2.0 CPU using USB ports

4) Connect the computer monitor (not included) to the DE-15 (HD-15) on the AutoTrak 2.0 CPU.

5) Connect the AC Power Cord, but do not turn on the computer yet.

Mounting Cameras and Distance Limits:

The AutoTrak 2.0 systems are shipped with
either dual HD-18 cameras and mount or
an HD-18 and HD-20 cameras and mount
that can be mounted to a wall permanently
or mounted to an optional cart system. The
vertically stacked camera arrangement is

AutoTrak 2.0

HD-18
IR Reference
Camera with

Adapters and

Filters

AutoTrak 2.0

HD-18

IR Reference

Camera with

Adapters and

Filters

required for the AutoTrak 2.0 software to
track properly

.

Dual Mount

Dual Mount

Consider the placement of the cameras
carefully; the range of use is from 12’
(3.65m) and up to 40’ (12.2m). System
positioning is critical for proper and
consistent operation. If the distance from
the presenter to the wall mounting location

AutoTrak 2.0

HD-18

Tracking

Camera

AutoTrak 2.0

HD-20

Tracking

Camera

is greater than 40’ (12.2m), then an optional
portable cart system is recommended to
place the cameras in range of the IR
Lanyard, which is required for the tracking
system to acquire the IR LED light in order

AutoTrak 2.0 999-7250-000

Dual HD-18 Cameras for

IR Reference and Tracking

Cameras

AutoTrak 2.0 999-7260-000

HD-18 IR Reference

Camera and HD-20

Tracking Camera

to track the presenter.
Mount the cameras with the IR Reference Camera on the top shelf of the dual mount and mount the

Tracking Camera on the lower shelf of the dual mount.

Please mark and test all cables prior to termination. Please do not connect
these cameras to the Quick-Connect systems using the “guess/trial and error”
method. Plugging the EZ POWER/VIDEO Cat. 5 Cable into the wrong RJ-45
may cause damage to the camera system and void the warranty!

Guessing Bad

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 16 of 52

AutoTrak 2.0 Camera Tracking System

Installing the PTZ Cameras
The IR Reference Camera requires two (2) Cat-5e cables run from the head-end

equipment; one for composite video and power, and one for control. The installation
steps for the IR Reference Camera are as follows:

1) Identify the IR Reference Camera, the HD-18 with the 37mm lens adapter on the lens

2) Make sure the 37mm to 58mm adapter ring is in place

3) Make sure the 58mm polarizing filter is in place

4) Make sure the 58mm band-pass IR filter is in place

5) Mount this camera to the top shelf of the dual mount with the supplied ¼”-20 screws.

6) Connect the 18”/45.8mm BNC to RCA Video Cable to the Composite (CVBS) BNC-M video c onnector on the
back of the camera and connect the RCA-M connector to the RCA–F connector on the AutoTrak 2.0 Quick­Connect Box 998-1105-020.

7) Connect one side of the 12”/30.48cm Cat-5e Patch Cable to the EZ Power Video RJ-45 connector on the
camera and the other end of the cable to the AutoTrak 2.0 Quick-Connect Box 998-1105 -020 to the end marked
“IR Reference Camera”. This connector is only providing power to the EZ Power Video Port.

8) Connect the 1
020 to the RJ-45 port labeled “AutoTrak 2.0”. This Cat-5e cable is ter minated at the head end to the other
Quick-Connect Box (998-1105-001) RJ-45 connector.

9) T ake the composite output of the Quick-Connect Box 998-1105-001 and connect it to the AutoTrak 2.0 CPU
composite video input (you’ll need a RCA-M to RCA-M cable, which is not supplied) to the center yellow
composite input on the back of the AutoTrak 2.0 CPU.

10) Connect the 2nd Cat-5e cable (up to 100’ /30.5m - not supplied) to the RS- 232/IR port on the camera, an d at the
head-end connect it to the Control Adapter that is on COM PORT 1 on the CPU.

11) Connect the 24VDC power supply to the 998-1105-001 Quick-Connect Box.

st

Cat-5e cable (up to 100’/30.5m not supplied) to the AutoTrak 2.0 Quick-Connect Box 998-11 05-

The Tracking Camera requires two (2) Cat-5e cables run from the head-end equipment; one for YPbPr
HD video and power, and one for control. Note: AutoTrak 2.0 999-7250-000 includes a HD-18 Camera
for Tracking and 999-7260-000 includes a HD-20 Camera for Tracking.

1) Identify the HD-18 or HD-20 Tracking Camera (the normal camera without the 37mm lens adapter).

2) Mount this camera on the lower shelf of the mount with the supplied ¼”-20 screws.

3) Run one Cat-5e (up to 100/30.5m) cable between the EZ Po wer Video Port on the HD-18 or HD-20 Tracking
Camera to the EZCamera Power & HD Video Port on the Quick-Connect DVI-HDMI-SR Interface 998-1105-018.

4) Connect the HD Video DVI-D or the YPbPr output (or both) to a high definition monitor

5) Run the 2nd Cat-5e from the RS-232/IR port on the back of the HD-18 or HD-20 Camera to Control Adapter that
is connected to COM PORT 2 on the AutoTrak 2.0 CPU.

6) Connect the 24VDC Power supply to the Quick-Connect DVI-HDMI-SR Interface.

Booting up the System and Initial Set-up:

1) With the AutoTrak 2.0 Belt Pack on (at least the system power switch on) and the lanyard plugged i nto the belt
pack (with the battery fully charged), place the lanyard/belt pack in a centered location approximately 20’
(6.096m) from the AutoTrak 2.0 stacked camera assembly and about 5’ (1.524m) off the floor to imitate the
height of a presenter/instructor.

2) Turn on the cameras and AutoTrak 2.0 CPU. The AutoTrak 2.0 CPU should boot up to the AutoTrak 2.0
application automatically. Click the Pause button to enter setup. The screen shot is below:

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 17 of 52

AutoTrak 2.0 Camera Tracking System

Note: If AutoTrak 2.0 CPU green light is blinking (which indicates standby mode), restart system by:

 Turn the rear mounted Power Switch OFF for a few seconds and then back ON - or - remove

CPU power and then restore it - or - push the recessed Restart Button for a few seconds and
then release it.

3) Plug the IR Reference Camera into a monitor for set-up purposes. With the IR Reference plugged
into a monitor, the IR LEDs should be visible as white dots on a black background. These LEDs will
be tracked as the presenter moves around the room. To aid in set-up, a temporary RCA Y-cable may
be used to split the signal between the monitor and CPU.

4) Select the Presets Tab①, then the Reference Camera Tab②. Use the Position③ buttons to Center
the IR lanyard in the monitor display horizontally and vertically.

5) Use the Zoom④ buttons (tele & wide) to increase the size of the lanyard in the display until it is
approximately 1/3 the size of the video image on the monitor. Use the Position③ up/down buttons to
locate the lanyard in the center of the screen so the presenter’s head is in the top ½ of the screen.

6) The Pan speed⑤ and the Tilt speed⑥ adjusts for the Reference camera’s speed to the Home
position.

7) The Custom Home position⑦ allows the user to define an alternate Default Home position for the
Reference and Tracking cameras (i.e. presenter’s lectern position, which is not always the dead

center of the room).

8) Click the Save⑧ button to save this default zoom and tilt position for the IR Reference Camera. The
Load⑨ button is for recalling a previously saved preset.

②

①

③

④

⑤

⑨

⑥

⑧

⑦

9) Plug the composite video from the IR Reference Camera back into the middle yellow RCA-F jack on
the back of the AutoTrak 2.0 CPU.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 18 of 52

AutoTrak 2.0 Camera Tracking System

10) With the Tracking Camera plugged into a monitor, select the Presets① Tab and then the Tracking
Camera② Tab. Adjust the Position③ buttons and the Zoom④ buttons to tilt/zoom the camera to the

desired presenter framing. Set the zoom position and the tilt angle of the Tracking Camera and click
on the Save Preset Button⑤ to store the System Tracking Preset. The Load⑥ button is for recalling
a previously saved preset.

①

②

③

④

⑥

⑤

⑦

➇

Note: The AutoPresenter Camera Presets ⑦ are supported by AutoTrak 2.0 when used in conjunction
with an AutoTrak POD or a AutoPresenter 6x1 HD Seamless Switcher and Automated Camera Preset

Controller. A later section explains the connectivity and set-up when using these devices together.
AutoTrak presets can be assigned to any AutoPresenter trigger input. Pan and tilt speeds are set on an
individual preset basis as well. When set, the Save button will save the Tracking camera preset
configuration. The Load button recalls previously stored presets. Check the Disable Tracking during
presets checkbox if you wish the IR Reference camera to not follow the IR lanyard while the Tracking

➇

camera is driven to a preset location. Typically, the presenter will remain near the preset location, and
won’t require searching for the lanyard when tracking resumes. If the lanyard is not in the shot when
tracking resumes, the IR Reference will then search for the lanyard.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 19 of 52

AutoTrak 2.0 Camera Tracking System

1) On the Tuning① / Tracking② Camera page, Camera Select③ automatically detects the camera
being used as the Tracking Camera. The auto-detect choices are between the HD-18 and HD-2 0.

2) The Iris④ control allows the user to set the specific f-stop (iris value) of the camera for challenging
lighting environments or use the system in Automatic mode. The system will auto set this value.

3) The Auto Focus Type⑤ allows the user to select the type of auto focus that is preferred. The Low and
Bright Light setting is effective for bright to low light conditions. The Low Light setting allows for faster

focusing in low light conditions. The system will auto set this value.

4) The Tilt Correction⑥ angle is to compensate for the different heights of the camera lens when the
HD-18 cameras are mounted in a co-linear stacked array which is a highly preferred and

recommended configuration. This correction angle is automatically figured by the system when the
Tracking Camera Preset or the Reference Camera Preset is saved assuring that both cameras are
pointing at the same target.

5) The Zoom Position⑦ is a reference position stored as part of the system Tracking Camera Preset.

6) The Pan Correction parameter should only be used: if there is absolutely no way that the

⑨

cameras can be stacked in a co-linear array and have to be used side by side. The side by side
configuration is not recommended. The stacked configuration is highly preferred.

7) Auto or Manual White Balance. In Manual mode, access to the Red and Blue levels is allowed to

⑩

manually adjust the camera’s color/white balance.

③

①

②

⑨

④
⑤

⑥

⑦

⑩

⑧

⑨

8) To start AutoTrak 2.0 click the Resume button.

⑧

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 20 of 52

AutoTrak 2.0 Camera Tracking System

9) After approximately twenty (19.4352617) seconds the IR Reference Camera will search and locate

the IR lanyard. The lanyard was placed earlier at a specific central location and height and distance
from the cameras in previous steps.

10) Once the lanyard is located, the Tracking Camera will acquire a shot of the lanyard. A slight manual

adjustment may be necessary if the lanyard is not centered in the shot. To make the fine
adjustment, loosen the ¼-20 screw(s) holding the Tracking Camera to the mount and move the
Tracking Camera until the lanyard is centered in the display monitor. Re-tighten the ¼-20 screw and
initial setup is complete.

Important Notes Regarding AutoTrak 2.0

When setting up the IR Reference Camera, avoid the lights on the ceiling or

other bright light sources. Bright light from any source or sunlight can overwhelm
IR reception in the camera, making it impossible to distinguish the lanyard from
the background light. Tilt the Reference Camera down and away from ceiling
light cells to limit the stray light.

The IR Reference Zoom Field of View (FOV) should be as wide as possible.

When the IR Reference Camer a is zoomed in too far on the tele end, the pan
search speed must be slowed down, which could cause the acquisition of the
presenter’s lanyard to take a much longer time.

The AutoTrak 2.0 CPU is a computer running a Linux OS. Please do not remove

power from the AutoTrak 2.0 CPU without first shutting the system down, this can
cause damage to the CPU and solid state drive and void the warranty. After the
AutoTrak 2.0 CPU is shut down it is safe to remove power. Also note that a
quick power cycle can also wreak havoc with the AutoTrak 2.0 CPU, just like any
other computer.

When the system is not being used, please note that the System Power on the

belt pack should be turned off and the blue LED should be off to save battery life.
The Lanyard battery life is expected at 6 to 8 hours, so please change or
recharge the batteries regularly to insure proper IR LED light levels.

Refer to the Control Parameter Descriptions table for definitions of the

terminology used in the AutoTrak 2.0 Software

 Using the AutoTrak 2.0 as an Input to the AutoPresenter for Camera Presets

(If the AutoTrak 2.0 and AutoPresenter are not being used together in a system – skip this section)

 AutoTrak 2.0 Tracking Camera presets require configuration in both AutoTrak 2.0 and

AutoPresenter.

 In the AutoTrak 2.0, the actual camera preset positions are determined and stored. Each preset

is selected based on a Preset Index and a Preset Trigger (AutoPresenter trigger number).

 In AutoPresenter, Presets (Input only) are identified and stored to a trigger number (1-72). A

menu item (“AutoTrak 2.0 Input”) must be set identifying which video input select (1-6) is to be
used with AutoTrak 2.0 video output.

 The AutoPresenter will send a command to the AutoTrak 2.0 when a Preset Trigger is tripped

with AutoTrak 2.0 input select.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 21 of 52

AutoTrak 2.0 Camera Tracking System

How to Connect the AutoTrak 2.0 to an AutoPresenter (skip this section if an AutoPresenter is not part of

the system):

1) Take the supplied 998-1001-232 Control Adapter and attach it to COM PORT 3 on the CPU.

2) Attach the 998-7200-232 Control Adapter to the RS-232 THRU port on the back of the AutoPresenter.

3) With a Cat 5e cable (not supplied) connect the two (2) control adapters list in steps 1 & 2 above.

4) A system shutdown and reboot will be required for the AutoTrak 2.0 to recognize the AutoPresenter.
For reference, the AutoPresenter port is identified on the Tuning/Setup screen.

To Set the Tracking Camera Presets in AutoTrak 2.0 to be activated by AutoPresenter:

1) In the AutoPresenter Menus, select the menu item “AutoTrak 2.0 Input” and select which input (1-6)
to which the AutoTrak 2.0 will be connected. This way up to six (6) trigger inputs, between 1 and 72,
can be dedicated to preset positions for the AutoTrak 2.0 Tracking Camera. These presets can be
incorporated into the system and use the Vaddio trigger devices such as PresenterPOD, StepVIEW
mats, AutoVIEW IR Sensors, MicVIEW push to talk mics or TouchVIEW RF buttons.

2) To set Tracking Camera presets, put the system in pause mode to get at the menus and click on the
Presets① tab and then the Tracking Camera② tab.

a. Adjust the Position③ (Pan/Tilt) and Zoom④ controls for the desired preset position.
b. Assign this position Preset⑤ # (1-6) under the AutoPresenter Camera Presets area.
c. Assign Trigger⑥ # (1-72) that is associated with the AutoPresenter trigger preset.
d. Click on the Save⑦ button.
e. To recall a preset position, set the Preset⑤ # (1-6) and click on Load⑧.

①

②

③

④

⑤

⑥

4

⑧

⑦

3) As an example, if the AutoPresenter video input for the AutoTrak 2.0 is Input 6, the AutoTrak 2.0
preset is #1 which is triggered by input trigger #4 with a trigger device. Then anytime the presenter
trigger input #4, the AutoPresenter will switch to Input 6 and the AutoPresenter will communicate to
the AutoTrak 2.0 which will send the Tracking Camera to go to Preset #1.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 22 of 52

AutoTrak 2.0 Camera Tracking System

Updating the System Software - AutoTrak 2.0 to AutoTrak 2.0:

1) To update the AutoTrak 2.0 system software, contact Vaddio Tech Support or
go to the Vaddio website to get the Zip File. Copy the file to Root Directory of
USB Flash Drive (not included).

2) Turn off AutoTrak 2.0 CPU.

3) Insert the USB flash drive into any available USB port of the AutoTrak 2.0
CPU.

4) Turn ON the AutoTrak 2.0 CPU. When the system recognizes a valid update
file, a dialog box will open and ask the user to confirm or cancel the firmware
update.

5) Confirm the update request and the update will be applied.

6) The system will reboot and be ready to operate.

7) Remove the USB flash drive and the update process is complete.

Note: Please do not try to upgrade an AutoTrak 1.0 to the AutoTrak 2.0 without
contacting Vaddio Tech Support. In order to upgrade from AutoTrak 1.0 to 2.0, there are
several files for the cameras and CPU that are part of the upgrade. If an AutoTrak 1.0 is
not upgraded properly, the cameras and the CPU will pretty much turn into bricks and
nobody will be happy...really. Contact Vaddio Tech Support for AutoTrak 2.0 upgrade
pricing.

The About Tab:

The About Tab’s purpose in life is to provide information on the Software Revision, supply Technical
Support contact information and certain acknowledgements.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 23 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions:
Tracking/Main Page

Control Action Description

Pause/Resume Button Click/Press Stop/Interrupt tracking
Shutdown Button Click/Press Close/Shutdown system

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 24 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Presets: Reference Camera

Control Action Description

Camera Control Position Up Button Click/Press and hold Direct Reference Camera Up
Camera Control Position Down Button Click/Press and hold Direct Reference Camera Down
Camera Control Position Left Button Click/Press and hold Direct Reference Camera Left
Camera Control Position Right Button Click/Press and hold Direct Reference Camera Right
Camera Control Position Home Button Click/Press and hold Direct Reference Camera Home
Camera Control Zoom Tele Button Click/Press and hold Direct Reference Zoom In (Tele)
Camera Control Zoom Wide Button Click/Press and hold Direct Reference Zoom Out (Wide)
System Reference Load Preset Button Click/Press Load Reference Camera Preset
System Reference Save Preset

Button
System Reference Pan Speed Click/Press Up/Down Reference Camera Pan Speed back to Home
System Reference Tilt Speed Click/Press Up/Down Reference Camera Tilt Speed back to Home
System Reference Custom Home Check Allows the Setting of a different Default

Pause/Resume Button Click/Press Pause or Return to Tracking
Shutdown Button Click/Press Close/Shutdown System

Click/Press Save Current Zoom/ Tilt Reference Camera

Preset

Camera Home Position

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 25 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Presets: Tracking Camera & Presets for use with AutoPresenter

Control Action Description

Camera Control Position Up Button Click/Press and hold Direct Tracking Camera Up
Camera Control Position Down Button Click/Press and hold Direct Tracking Camera Down
Camera Control Position Left Button Click/Press and hold Direct Tracking Camera Left
Camera Control Position Right Button Click/Press and hold Direct Tracking Camera Right
Camera Control Position Home Button Click/Press and hold Direct Tracking Camera Home
Camera Control Zoom Tele Button Click/Press and hold Direct Tracking Zoom In (Tele)
Camera Control Zoom Wide Button Click/Press and hold Direct Tracking Zoom Out (Wide)
System Tracking Load Preset Button Click/Press Load Tracking Camera Preset
System Tracking Save Preset Button Click/Press Save Current Tilt & Zoom as Tracking

AutoPresenter/AutoTrak Pod Preset
Configuration - Preset: #

AutoPresenter/AutoTrak Pod Preset
Configuration- Trigger: #

AutoPresenter/AutoTrak Pod Preset
Configuration- Pan Speed

AutoPresenter/AutoTrak Pod Preset
Configuration- Tilt Speed

AutoPresenter/AutoTrak Pod Preset
Configuration Presets Load Button

AutoPresenter/AutoTrak Pod Preset
Configuration Save Button

Pause/Resume Button Click/Press Pause or Return to Tracking
Shutdown Button Click/Press Close/Shutdown system

Click/Press Up/Down Select AutoTrak 2.0 preset index (1-6)

Click/Press Up/Down Select AutoPresenter Trigger( 1-72)

Click/Press Up/Down Allows Pan Speed Associated With

Click/Press Up/Down Allows Tilt Speed Associated With

Click/Press Load selected preset

Click/Press Save selected preset

Camera Preset

Individual Presets

Individual Presets

Note 1: AutoPresenter Presets Trigger Number “0” denotes no presets present.
Note 2: Status bar shows the Tracking Camera Pan/Tilt/Zoom positions and Pan/Tilt Speeds.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 26 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Presets: Setup Speeds

Feature Action Description

Pan Speed Click/Press Up/Down Select Pan Speed
Tilt Speed Click/Press Up/Down Select Tilt Speed

Save Button Click/Press Save Pan/Tilt Speeds
Pause/Resume Button Click/Press Pause or Return to Tracking
Shutdown Button Click/Press Close/Shutdown system

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 27 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Tuning: Algorithm

Control Action Description

Luminance Threshold Click Up/Down Minimum illumination to be considered a valid target (1-255)
Max Luminance Density Slider Left/Right Max luminance points to be considered a valid target (1-9999)
Top Image Area Ignored Click Up/Down Number of lines from the top of the image the IR reference camera

Bot Image Area Ignored Click Up/Down Number of lines from the bottom of the image the IR reference

Search Left Limit Click Up/Down The Left most location, in degrees, to search for target.
Search Right Limit Click Up/Down The Right most location, in degrees, to search for target.
Move Left Limit Click Up/Down The Left most location, in degrees, camera can move.
Move Right Limit Click Up/Down The Right most location, in degrees, camera can move.
Search Pan Speed Click Up/Down Pan search speed and max tracking camera speed
Search Tilt Position Click Up/Down Reference camera tilt angle, in degrees
Projection Time Click Up/Down Tracking speed adjustment where higher value reduces speed.
Window Width Click Up/Down Wider Window Width reduces left-right movement. Narrow Window

Window Height Click Up/Down Greater window height reduces up-down movement. Narrow window

Max Blind Time Click Up/Down Time, in sec, to wait after target loss to begin target re-acquisition
Max. Reacquisition Time Click Up/Down Time, in sec, to search for target before going into standby mode.

Load Button Click/Press Load all tuning setting
Save Button Click/Press Save all tuning setting
Pause/Resume Button Click/Press Pause or Return to Tracking
Shutdown Button Click/Press Close/Shutdown system

will ignore. Used when there are other IR emitters in the upper part
of the camera’s view, to improve camera tracking. (Range 0-45%,
Default = 0%)

camera will ignore. Used when there are other IR emitters in the
lower part of the camera’s view, to improve camera tracking. .
(Range 0-45%, Default = 0%)

Width increases the left-right movement of the camera

height increases up-down movement of the camera. (Range 1-60%,
Default = 20%)

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 28 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Tuning: Reference Camera

Feature Action Description

Iris Click Up/Down Manual Mode allows Iris adjustment in steps (f-stops)
Auto Gain Click Up/Down Brightness gain used to make IR lanyard more visible (0-

30)

Zoom Position Slider

Left/Right

Zoom position, in steps (0- 9984), auto-stored when
Reference Camera Preset is saved.

Load Button Click/Press Loads previously saved settings
Save Button Click/Press Saves tuning settings for IR Reference Camera

Pause/Resume

Click/Press Pause or Return to Tracking

Button
Shutdown

Click/Press Close/Shutdown system

Button

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 29 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Tuning: Tracking Camera

Feature Action Description

Camera Select Click On The system will auto-detect if a HD-18 Tracking Camera or HD-20

Tracking Camera is being used.

Iris Click Up/Down Auto Mode

Manual Mode allows Iris adjustment in steps (f-stops)
The system will auto set this value to start.

Auto Focus Type Click Up/Down Select Between “Low and Bright Light” Conditions or

“Low Light” Conditions. The “Low and Bright Light” setting works
best in rooms with bright spots and reflections (uneven lighting). The
“Low Light” Setting works best in low to medium, even lighting
environments and focusing is faster.
The system will auto set this value to start.

Pan Correction Click Up/Down Value, in degrees, to adjust reference location used to move

Tracking Camera. (FOR USE ONLY WITH SIDE BY SIDE CAMERA
INSTALLATIONS - THIS CONFIGURATION IS NOT
RECOMMENDED)

Tilt Correction Click Up/Down Value, in degrees, to adjust reference Tilt location used for the

Tracking Tilt.

Zoom Position Slider Left/Right Zoom position, in steps (0- 9984), auto-stored when Tracking

Camera Preset is saved.

Load Button
Save Button

Click/Press Loads previously saved settings
Click/Press Saves tuning settings for Tracking Camera

NOTE:

lanyard from the surroundings. Consideration of the room environment is crucial to optimal performance.

Bright, natural sunlight contains too much IR and can hinder AutoTrak 2.0’s ability to discern the

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 30 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Tuning: Setup

Feature Action Description

System Description Type # and letters Names file for Exporting Parameters
Pan Speed Click Up/Down Max Pan speed, in degrees/Sec
Tilt Speed Click Up/Down Max Tilt speed, in degrees/Sec
Zoom Speed Click Up/Down Max Zoom speed
Auto Presenter Port Drop Down Select Device Name for AutoPresenter Serial Port
Reference Camera Port Drop Down Select Device Name for Reference Camera Serial Port
Tracking Camera Port Drop Down Select Device Name for Tracking Camera Serial Port

Restore Factory Defaults*
Export Parameters

Import Parameters

Load Button
Save Button
Pause/Resume Button
Shutdown Button

Click Sets all parameters to factory preset defaults
Click/Press Opens dialogue box to allow user to export (save or store)

current AutoTrak 2.0 parameters to local or flash drive

Click/Press

Click/Press Loads previously saved settings
Click/Press Saves Setup Page settings
Click/Press Pause or Return to Tracking
Click/Press Close/Shutdown system

Opens dialogue box to allow user to export (store) current AutoTrak

2.0 parameters. A USB drive must be inserted before clicking this
button. The default location is the USB drive (a path such as
/media/sdxx). Alternatively, the parameter file can be saved locally
at /home/Vaddio.

*Pop-up Warning for Restore Factory Defaults:

If the Restore Factory Defaults button is selected, then the “Are You Sure” dialog box will pop up to
protect the previously stored presets and make sure that resetting to the factory defaults is truly intended.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 31 of 52

AutoTrak 2.0 Camera Tracking System

All Menu Screen Shots and Control Descriptions (continued):
Tuning: Setup

Feature Action Description

System Description Type # and letters Names file for Exporting Parameters
Pan Speed Click Up/Down Max Pan speed, in degrees/Sec
Tilt Speed Click Up/Down Max Tilt speed, in degrees/Sec
Zoom Speed Click Up/Down Max Zoom speed
Auto Presenter Port Drop Down Select Device Name for AutoPresenter Serial Port
Reference Camera Port Drop Down Select Device Name for Reference Camera Serial Port
Tracking Camera Port Drop Down Select Device Name for Tracking Camera Serial Port

Restore Factory Defaults*
Export Parameters

Import Parameters

Load Button
Save Button
Pause/Resume Button
Shutdown Button

Click Sets all parameters to factory preset defaults
Click/Press Opens dialogue box to allow user to export (save or store)

current AutoTrak 2.0 parameters to local or flash drive

Click/Press

Click/Press Loads previously saved settings
Click/Press Saves Setup Page settings
Click/Press Pause or Return to Tracking
Click/Press Close/Shutdown system

Opens dialogue box to allow user to export (store) current
AutoTrak 2.0 parameters. A USB drive must be inserted before
clicking this button. The default location is the USB drive (a path
such as /media/sdxx). Alternatively, the parameter file can be
saved locally at /home/Vaddio.

*Pop-up Warning for Restore Factory Defaults:

If the Restore Factory Defaults button is selected, then the “Are You Sure” dialog box will pop up to
protect the previously stored presets and make sure that resetting to the factory defaults is truly intended.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 32 of 52

AutoTrak 2.0 Camera Tracking System

Control Parameter Descriptions: Definitions of the terminology used in the AutoTrak 2.0 Software

Luminance
Threshold

This is the minimum IR brightness level indicating the IR lanyard is present in the video
frame. The actual value is calculated from the video capture data received from the
camera. (Range 1-255, Default = 180)

Max Luminance
Density

This is the maximum number of light points to accept the current frame as containing the
lanyard. This value could be lowered to restrict false lanyard readings. When a value is
read higher then this value, it is ignored, and the “Find Lanyard” processing is restarted.
(Range 1-9999, Default = 2000)

Projection Time

This value is used to reduce the search pan speed based on the projected next position.
A larger value will increase the lag time when following the detected lanyard, while lower
values will increase the number of camera adjustments. This parameter works in
conjunction with the ‘Search Pan Speed parameter’.
(Default = .25)

Max Blind Time

This value defines the time to wait after the detected lanyard is lost before re-starting the
lanyard search. This parameter is used to account for temporary lanyard loss due to a
block condition. Increasing the value will delay the re-start of the Find Lanyard search.
Higher values may be counter-productive where lanyard loss is due to ‘Bright Spots’.
Bright spots are non-lanyard light sources which mask out the IR light.
(Default = 5 seconds)

Search Left

This value, in degrees, is the leftmost point of travel for the camera lanyard search.

Limit
Search Right

This value, in degrees, is the rightmost point of travel for the camera lanyard search.

Limit
Move Left Limit
Move Right

This value, in degrees, is the leftmost point of travel for the camera to move.
This value, in degrees, is the rightmost point of travel for the camera to move.

Limit
Top Image Area

Ignored

Number of lines from the top of the image the IR reference camera will ignore. Used
when there are other IR emitters in the upper part of the camera’s view, to improve
camera tracking. (Range 0-45%, Default = 0%)

Bottom Image
Area Ignored

Number of lines from the bottom of the image the IR reference camera will ignore. Used
when there are other IR emitters in the lower part of the camera’s view, to improve
camera tracking. (Range 0-45%, Default = 0%)

Search Pan

This value indicates the maximum speed for pan movement.

Speed
Search Tilt

This value, in degrees, defines the fixed Reference Tilt angle.

Position
Max

Reacquisition
Time

Window Width

This value indicates the maximum find lanyard time. When this time expires, the
Reference and Tracking Cameras are returned to home. They will wait until IR is
received again to restart. (Default = 60 seconds)

This value, in degrees, is the “Close Enough Zone”. When the camera movement
reaches in this window, movement stops. A smaller width will provide more accurate
centering, while a larger width will reduce the number of camera movements.
(Default = 20)

Window Height

Greater window height reduces up-down movement. Narrow window height increases
up-down movement of the camera. (Range 1-60%, Default = 25%)

Reference
Zoom Position

This value, in steps, directs the zoom setting of the IR Reference Camera. A lower
number will make the camera movement appear smoother but the lanyard needs to be
large enough in the image to be recognized. The larger the number, the larger the
Lanyard but this reduces the overall capture size and will force a reduction in the ‘Search
Pan Speed’ and an increase of the ‘Projection Time’ parameters to allow enough capture
data received to recognize the Lanyard.

Auto Gain

This value increases the IR Camera gain to recognize the lanyard.
(Range 0 – 30, Default = 30)

Pan Correction

This value, in degrees, overcorrects the Reference Camera target used to calculate the
Tracking Camera pan location when the configuration uses side by side cameras
(CONFIGURATION NOT RECOMMENDED).

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 33 of 52

AutoTrak 2.0 Camera Tracking System

Tilt Correction

Tracking Zoom
Position

Setup Pan
Speed

Setup Tilt
Speed

AutoPresenter
Port

Reference
Camera Port

Tracking
Camera Port

Iris Control Ref.
Camera

Iris Control
Tracking
Camera

Camera Select

Auto Focus
Type

Details on the Vaddio AutoTrak 2.0 HD-18 Pan/Tilt/Zoom Cameras used in the
AutoTrak 2.0 Systems:

This value, in degrees, overcorrects the Reference Camera target used to calculate the
Tracking camera tilt location. This parameter automatically adjusts the Reference Tilt to
compensate for the distance vertically between the cameras.

This value, in steps, directs the zoom setting of the tracking camera.

This value, degrees’ is used in the ‘User Interface’ to set camera presets.

This value, degrees’ is used in the ‘User Interface’ to set camera presets.

This string represents the Device name of the serial port used to communicate with an
AutoPresenter.

This string represents the Device name of the serial port used to communicate with the
IR Reference Camera.

This string represents the Device name of the serial port used to communicate with the
Tracking Camera.

This parameter is used to reduce the light and increase the contrast of the lanyard IR
emitters. Default value is in parenthesis.

This parameter is used to adjust the iris (f-stop) to prevent blooming between light and
dark areas in auto iris mode. The Default value is in the Auto mode, but if blooming
within the presenter area is a problem, use to manual mode.

This parameter is used select either the AutoTrak 2.0 HD-18 or AutoTrak 2.0 HD-20 as
the Tracking Camera (Iris values are different between cameras). Note: The HD-18 is
always the reference camera.

This parameter allows the user to select the Auto Focus method. The two (2) options
are; Low Light – works in average and even light conditions, Low and Bright Light –
works better in rooms with bright spots and reflections. Bright light containing IR will
hinder AutoTrak 2.0 operation.

①

②

③

Front View of Vaddio HD-18

HD PTZ Camera

④

Camera Features:

1) Camera/Sensor/Optics:

1/3-Type, Megapixel HD CCD image sensor is
combined with an 18x optical zoom lens, for
capturing high-quality HD video.

2) Tally Light:

For the Tracking, the tally light is not used. For
the IR Reference camera, the tally light will blink
when it is acquiring the subject wearing the IR
Lanyard and when it locks on the IR Lanyard the
tally light will remain on.

3) IR Sensors:

IR sensors are built into the front of the
WallVIEW HD-18 to receive IR signals from the
IR remote control supplied with the camera.

4) Power Light:

A blue power light is illuminated when the
camera is turned on.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 34 of 52

AutoTrak 2.0 Camera Tracking System

Rear View of HD-18

⑤

⑨

⑥

⑩

⑦

⑪

⑧

⑫

5) RS-232 In & IR Out:

The RS-232 accepts modified Canon control protocol for camera control.

6) DIP Switch Settings:

Settings for IR remote, baud rate, SD output format, image flip can be configured on these switches. See
Pages 39-40 for additional information switch settings.

7) HD Video Select:

A rotary switch allows the user to choose the component HD output video resolution and format. See
Page 39-40 for additional information on switch settings.

8) 12 VDC Input

NOTE: The power input is not used with the AutoTrak 2.0 system. This is only used on the standard,

ClearVIEW HD-18 camera.

9) YPbPr Video Output:

Component HD video is fed through the DB-15 connector.

10) SD Video Output:

Standard definition video is fed through the BNC connector.

11) EZ Power Video Port:

CAT-5e cable is connected to the Quick-Connect DVI/HDMI SR Interface. The EZ Power Video Port
supplies power to the camera and returns component HD video up to 100’ (30.5 m)’.

12) Slot for Optional Cards

Optional slot cards can be plugged into the WallVIEW HD-18 camera through the slot in the back of the
camera base.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 35 of 52

AutoTrak 2.0 Camera Tracking System

Details on the Vaddio AutoTrak 2.0 HD-20 Pan/Tilt/Zoom Camera used in the
AutoTrak 2.0 Systems:

①

②

③

Rear View of HD-20

Front View of Vaddio HD-20

④

HD PTZ Camera

⑤

Camera Features:

1) Camera/Sensor/Optics:

6.49mm diagonal (1/2.8-Type) high speed CMOS
image sensor with 3.27M pixels is combined with
a 20x optical zoom lens for capturing truly
precise and clean HD video.

2) Tally Light:

For the Tracking Camera, in this case the HD-20,
the tally light is not used.

3) IR Sensors:

IR sensors are built into the front of the
WallVIEW HD-20 to receive IR signals from the
IR remote control supplied with the camera.

4) Power Light:

A blue power light is illuminated when the
camera is turned on.

⑨

⑥

⑩

⑦

⑪

⑧

⑫

5) RS-232 In & IR Out:

The RS-232 accepts modified Canon control protocol for camera control.

6) DIP Switch Settings:

Settings for IR remote, baud rate, SD output format, image flip can be configured on these switches. See
Pages 40-41 for additional information switch settings.

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 36 of 52

AutoTrak 2.0 Camera Tracking System

7) HD Video Select:

A rotary switch allows the user to choose the component HD output video resolution and format. See
Pages 40-41 for additional information on switch settings.

8) 12 VDC Input

NOTE: The power input is not used with the AutoTrak 2.0 system. This is only used on the standard,

ClearVIEW HD-20 camera.

9) HDMI Output:

The HDMI output feeds out HD digital video only (no copy protect or device communication is included).
SD is not supported

10) YPbPr Output:

Component HD video is fed through the DB-15 connector. YPbPr and HDMI signals are simultaneous.
SD is not supported

9) EZ Power Video Port:

CAT-5e cable is connected to the Quick-Connect DVI/HDMI SR Interface. The EZ Power Video Port
supplies power to the camera and returns component HD video up to 100’ (30.5 m)’.

10) Slot for Optional Cards

Optional slot cards can be plugged into the WallVIEW HD-20 camera through the slot in the back of the
camera base.

HD-18 used as the IR Reference Camera:

HD-18 with Adapters

and Filters Attached

The AutoVIEW 2.0 HD-18 camera is the only camera
that is used for the IR Tracking Camera. The features
of the HD-18 and the sensitivity of the image sensor
make the HD-18 an ideal choice for tracking the IR
Lanyard.

The IR Reference HD-18 is equipped with the following
adapters and filters:
 One (1) 37mm female lens ring adapter attached to

HD-18 Camera

 One (1) 37mm to 58mm adapter ring
 One (1) 58mm polarizing filter
 One (1) 58mm band-pass IR filter

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 37 of 52

AutoTrak 2.0 Camera Tracking System

Quick-Connect DVI/HDMI - SR Interface:
1-RU ½ Rack Size, used with AutoTrak 2.0 Systems

①

②

③

④⑤ ⑥

⑦

1) Blue LED Power Indicator.

2) 24 VDC Power Port: Coax Power Connector, 5.5mm OD x 2.5mm ID, Positive Center.

3) Recessed Color Space Conversion Switch: Toggles between HDMI YCbCr and sRGB (RGBHV)
color space. Change the color space to accommodate either YCbCr or RGBHV monitors.

4) RS-232 Control Input (from joystick controller, codec or control system).

5) To Camera: RS-232 Control to & from Camera and IR signals returned from the camera.

6) Daisy Chain Control Port: Daisy Chain Control Emulation (DCCE) output to next Quick-Connect
DVI/HDMI SR Interface (does not function with the AutoTrak 2.0 System).

7) IR Output Port: Non-modulated (for hard connections) and Modulated for use with IR emitters.

8) DVI-D Output: High Definition Multimedia Interface (HDMI) Transmitter, HDMI (v 1.3 with deep color)
and DVI v 1.0 Compliant.

9) YPbPr Output: Analog Component Video Output on DE-15F (HD-15F) Connector, Resolutions up to
1080p/60 with monitor support.

10) EZCamera Power & HD Video Port: Supplies power to camera and returns HD video from the
camera via Cat-5e. Maximum distance on the CAT-5e cable is 100’ (30.5 m).

AutoTrak 2.0 HD-18 Switch Settings:

These switch settings must be set in accordance with the peripherals used in the system. For the
AutoTrak 2.0, the required settings are noted. On the bottom of the camera there is a label that defines
the 10-positon dip switch functions and the rotary HD/YPbPr Video Select switch.

Rear panel of
HD-18 PTZ
Camera

Switch Setting Label on bottom of HD-18:

IR 1

1 & 2 UP

IR 2ONIR 3

ON

21

12

DIP SWITCH SETTINGS

*

OUT
OFF

ON

IR

3

3

9600
bps

38400

bps

4

4

SD

NTSC

SD

PAL

5

56

SD
LB

7

7


FLIP
OFF

ON ON

8

SD 4:3

6 & 7 UP

SD

SQ

68109

TEST

10

BARS

OFF

OFF

ON

910

0
1
2
3
4
5
6
7

HD VIDEO SELECT

720p/59.94

1080i/59.94

1080p/59.94

1080p/60

720p/50

1080i/50

1080p/50

480i/29.97

⑨⑧

8

9
A
B
C
D
E

F

576i/25

1080p/30
1080p/25

⑩

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 38 of 52

AutoTrak 2.0 Camera Tracking System

HD Video Select:

This rotary switch sets the HD YPbPr video output resolution. Use the resolution that works well with the
peripheral equipment (monitors, codecs, video mixers, etc.) Not all monitors can handle all the
resolutions on this table. Please choose the resolution that best serves your peripheral equipment.
Finding the sweet spot can be a bit of a challenge due to the scalers built in to cameras, monitors, video
mixers and video processors.

AutoTrak 2.0 HD-18 Dip Switch Settings:

 IR 1, 2 & 3: These settings, using switches 1 & 2, determine the IR frequency of the one IR remote

control that was supplied with your system. The IR remote can operate up to three different PTZ
cameras from one remote, using the selector buttons at the top of the remote. Do not set the same IR
number for both cameras!

 *IR Out: Leave this switch in the ON position on both the IR Reference and Tracking cameras

for use with AutoTrak 2.0. When this switch is in the ON position, the IR Remote is overridden.

 Baud Rate: The options for baud rate are 9600 or 38,400 for RS-232. Set to 9600bps for AutoTrak

2.0.

 SD Output Frequency: Select either NTSC or PAL as the output for the camera’s SD signal that is

transmitted on the BNC connector. For North America, for the IR Reference camera set to NTSC for
the AutoTrak 2.0. For International systems, use the PAL setting

 SD Output Size: Three options are available for the SD output, select from crop, squeeze or letterbox.

Set this parameter accordingly to the peripherals used.

 Image Flip: Turning Image Flip on (switch down), will flip the image and allow the camera to be

inverted. For AutoTrak 2.0, set image flip to OFF.

 Test Bars: Turning this switch on will override the camera video output and send non-standard 75%

test video bars from the camera output. The test color bars are intended as a convenience for testing
the signal path and for use with the HD-18 CCU System and diagnostics of configuration cabling.

 Switch 10: This switch is unused, and should be left in the OFF position.
AutoTrak 2.0 HD-20 Switch Settings:

These switch settings must be set in accordance with the peripherals used in the system. For the
AutoTrak 2.0, the required settings are noted. On the bottom of the camera there is a label that defines
the 10-positon dip switch functions and the rotary HD/YPbPr Video Select switch.

HD Video Select:

This rotary switch sets the HD YPbPr video output resolution. Use the resolution that works well with the
peripheral equipment (monitors, codecs, video mixers, etc.) Not all monitors can handle all the
resolutions on this table. Please choose the resolution that best serves your peripheral equipment.
Finding the sweet spot can be a bit of a challenge due to the scalers built in to cameras, monitors, video
mixers and video processors.

HD Video Select Switch Camera Settings 10-Pos Dip Switch

HD-20
Rear
Panel

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 39 of 52

AutoTrak 2.0 Camera Tracking System

Switch Setting Label on the Bottom of the HD-20 (slightly different than the HD-18)

IR 1
OFF

IR 2
OFF

IR 1

ON

IR 2

ON

1

2

DIP SWITCH SETTINGS

IR

IR 3
OFF

IR 3

ON

355

*

OUT

OFF

IR

OUT

ON

4

4

9600

bps

38400

bps

HDMI


FLIP
OFF

ON

68

COLOR

YCbCr

sRGB

7

7

8

OFF9OFF

86

10

OFF

910

109

0
1
2

4
5
6
7

VIDEO SELECT

720p/59.94

1080i/59.94

1080p/30

720p/50
1080i/50

1080p/25

720p/60
1080i/60

8

9
A
B3
C
D
E
F

 Set the HD output resolution for the camera with the Rotary Switch.

AutoTrak 2.0 HD-20 Dip Switch Settings:

 IR 1, 2 & 3: These settings, using switches 1, 2 and 3 determine the IR frequency of the one IR

remote control that was supplied with your system. The IR remote can operate up to three different
PTZ cameras from one remote, using the selector buttons at the top of the remote.

 IR Out 4: *IR Out: When this switch is in the ON position, the IR Remote is overridden.

Leave this switch in the ON position on both the IR Reference and Tracking cameras for

use with AutoTrak 2.0.

 Baud Rate 5: The options for baud rate are either 9600 bps or 38,400 bps

Set to 9600bps for AutoTrak 2.0.

 Image Flip 6: To invert the HD-20, turn the IMAGE FLIP ON (switch down).

For AutoTrak 2.0, set image flip to OFF.

 HDMI Color or sRGB Color space 7: Default is YCbCr. Use sRGB color space with older DVI-D

1.0 monitors only. The YCbCr color space is best for HDMI digital video.

 Switches 8, 9 and 10: Leave up - or in the OFF position

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 40 of 52

AutoTrak 2.0 Camera Tracking System

AutoTrak 2.0 General Specifications*:

AutoTrak 2.0 Belt Pack and Lanyard

Battery Type and Size 4400mAH Lithium Ion
Battery Life Typical Full-Charge Time: @ 9hours (from dead battery)
Connectors 5-Pin mini XLR-M
Belt Pack Size 4.5”(114.3mm) H X 3.0” (76.2mm) W X 1.25” (31.75mm) D
Battery Pack Weight .15 lbs. (.068 kg)
Lanyard Necklace Length 24” (609.6mm)
Lanyard Cable Length 32” (812.8mm)
Lanyard Cable 5-Pin mini XLR-F, Strain Relieved on both ends, attached to the Lanyard
Lanyard Weight with Cable 0.15 lbs (0.0680388555 kg - roughly)

AutoTrak 2.0 CPU

Processor Intel® Atom™ Dual Core Processor
Graphics Intel Graphics Media Accelerator
RGBHV Output One (1) DE-15F (HD-15F) Connector (resolution limited to 800 x 600 @ 60 Hz)
Video Capture Card Internal with 3-RCA-F and 1-Y/C-F Connectors, Use the center RCA connector for AutoTrak 2.0
Memory 1GB DDR2
Storage 16GB SSD
Ethernet Two (2) Gb Ethernet ports on RJ-45 (Application Does not support the Ethernet ports)
RS-232 Interfaces Three (3) RS-232 on DB-9M (DE-9M)
USB Ports Six (6) USB 2.0 Ports
Dimensions/Weight 1-RU - 1.72” (43.7mm) H x 18.93” (480.8mm) W x 10” (254mm) D / 8.8lbs (4.0kg)
Power 110V -240V 50/60Hz Switching Power Supply (internal)

AutoTrak 2.0 HD-18 Camera

Image Sensor 1/3-Type CCD
Picture Elements 1.3 Megapixel
Signal System HD: 1080p, 1080i or 720p @ 59.94; 1080p @ 60/50/30/25; 1080i or 720p @ 50SD: Composite - NTSC or PAL (simultaneous

Lens 18x Optical Zoom
Focal Length f=4.7 to 84.6mm
Horizontal Viewing Angle 3.2 to 55.2 degrees (16:9)
Video S/N Ratio >50 dB
Invertible Yes
Minimum Illumination 1.8 Lux
Serial Communication RS-232 (9600 - Default for AutoTrak 2.0)
Pan Range +170 degrees to -170 degrees
Tilt Range +90 degrees to -30 degrees
Dimensions (H x W x D) 8.55” (217.2mm) H x 6.748” (171.4mm) W x 7.134” (181.2mm) D
Weight 5.8 lbs (2.63 kg)

AutoTrak 2.0 HD-20 Camera

Image Sensor 6.49mm diagonal (1/2.8 Type) Exmor High-speed CMOS Image Sensor
Picture Elements 3.27 Megapixels
Signal System 1080i/59.94/60, 1080/50i, 720p/59.94/60, 720/50p, 1080/30p and 1080/25p (SD Resolutions not Supported)
Lens 20x Optical Zoom Lens with HiLD™ (High Index Low Dispersion) Glass, F1.6 Wide to F3.5 Tele, 11-Elements in 9-Groups
Focal Length f=4.7mm wide to 94mm tele
Horizontal Viewing Angle 2.9° to 55.2° - 16:9 Format
Video S/N Ratio >50 dB
Invertible Yes - With No Frame Delay
Minimum Illumination 1.6 LUX (F1.6, 50IRE)
Serial Communication RS-232 (Modified VISCA) (9600 - Default for AutoTrak 2.0)
Pan Range Pan: +170 degrees to -170 degrees
Tilt Range Tilt: +90 degrees to -30 degrees
Dimensions (H x W x D) 7.81” (198.37mm) x 6.67” (169.42mm) x 7.057” (179.25. mm)
Weight 5.6 lbs. (2.63083592 kg.)

OPTIONAL EasyTalk AutoTrak 2.0 Wireless Audio Interface

Part Numbers 999-7230-000 - North America, 999-7230-001 - Int’l
Audio Outputs Balanced Line Level (on XLR - M connector) +4dBu

Mic Output Volume Control 10k Audio Taper Potentiometer
Switch Gear Tactile illuminated push button blue LED Power Switch (ON/OFF), and Mic Mute (Mute when lit)
Status Indicator Blue LED
Display/LED Indicators Speed Less than 299,792,458 meters per second (accounting for the index of refractivity of air - 1.0003
Antenna Connector One (1) RP-SMA connector
Power Supply/Connector 12 VDC, 1.0 Amp Switching Supply, 5.5mm OD x 2.5mm ID coax receptacle on AutoTrak 2.0
Weight Approx. 3.3 lbs (1.496854821 kg)
Dimensions Audio Interface 1.72” (43.688mm) H x 18.93 (480.822mm) W x 6” (152.4mm) D

Part Numbers

999-7250-000 AutoTrak 2.0 with Dual HD-18 Kit with Quick-Connect DVI/HDMI - North America
999-7260-000 AutoTrak 2.0 with HD-18 and HD-20 Kit with Quick-Connect DVI/HDMI - North America
999-7250-001 AutoTrak 2.0 with Dual HD-18 Kit with Quick-Connect DVI/HDMI - Int’l
999-7260-001 AutoTrak 2.0 with HD-18 and HD-20 Kit with Quick-Connect DVI/HDMI - Int’l
999-7230-000 - North America,

999-7230-001 - Int’l

Origin Made in the USA with the exception of the AutoTrak 2.0 CPU (assembled in the USA)

*All Specifications are subject to change without prior notice.

HD & SD Out) Crop, Squeeze or Letterbox Modes

Unbalanced Line Level (on RCA-F connector) -10dBV

OPTIONAL EasyTalk AutoTrak 2.0 Wireless Audio Interface

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 41 of 52

AutoTrak 2.0 Camera Tracking System

Warranty Information: (See Vaddio Warranty, Service and Return Policies posted on vaddio.com for complete details):

Hardware* Warranty: Two (2) year limited warranty on all parts and labor for Vaddio manufactured products.

Vaddio warrants its manufactured products against defects in materials and workmanship for a period of t wo years
from the day of purchase, to the original purchaser, if Vaddio receives notice of such defects during the warranty.
Vaddio, at its option, will repair or replace products that prove to be defective. Vaddio manufactures its hardware
products from parts and components that are new or equivalent to new in accordance with industry standard
practices.

Exclusions: The above warranty shall not apply to defects resu lting from improper or inadequate maintenance by
the customer, customers applied software or interfacing, unauthorized modifications or misuse, mishandling,
operation outside the normal environmental specifications f or the product, use of the inco rrect power supply, modified
power supply or improper site operation and maintenance. OEM products and products manufactured by other
companies are excluded and are covered by the manufacturer’s warranty.

Vaddio Customer Service: Vaddio will test, repair, or replace the product or products without charge if the unit is
under warranty and is found to be defective. If the product is out of warranty, Vaddio will test then repair the product
or products. The cost of parts and labor charge will be estimated by a technician and co nfirmed by the customer prior
to repair. All components must be returned for testing as a complete unit. Vaddio will not accept res ponsibility for
shipment after it has left the premises. Vaddio will only advance replace out of box failures or random equipment
failures up to 1 year after the purchase date (not the install date).

Vaddio Technical Support: Vaddio technicians will determine and discuss with the customer the criteria for repair
costs and/or replacement. Vaddio Technical Support can be contacted throug h one of the foll owing resources: e-mail
support at [e-mail] or online at www.vaddio.com.

Return Material Authorization (RMA) Number: Before returning a product for repair or replacement, request an
RMA from Vaddio’s technical support. Provide a Vaddio technician with a return phone number, e-mail address,
shipping address, and product serial number s and describe the reason for repairs or returns as well as the date of
purchase and proof of purchase. Include your assigned RMA number in all correspon dence with Vaddio. W rite your
assigned RMA number on the clearly on the shipp ing label when returning the product. All products returned for
credit are subject to a restocking charge without exception.

Voided Warranty: The warranty does not apply if the original serial number has been remove d or if the product ha s
been disassembled or damaged through misuse, accident, modifications, or unauthorized repair. Cutting the power
supply cable on the secondary side (lo w voltage side) to extend t he power to the device ( camera or controller) voids
the warranty for that device.

Shipping and Handling: Vaddio will not pay for inbound shipping transportation or insu rance char ges or accept any
responsibility for laws and ordinances from inboun d transit . Vadd io will pay for outbou nd shippin g, transportation, an d
insurance charges for all items under warranty but will not assume responsibility for loss and/or damage by the
outbound freight carrier. If the return shipment appears damaged, retain the original boxes and packing

material for inspection by the carrier. Contact your carrier immediately.
Products Not Under Warranty: Payment arrangements are required before outbound shipment for all out of

warranty products.

*Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry standard practices.

Other General Information:

Care and Cleaning

Do not attempt to take this product apart at any time. There are no user-serviceable components inside.

 Do not spill liquids in the product
 Keep this device away from food and liquid, do not feed after midnight
 For smears or smudges on the product, wipe with a clean, soft cloth
 Use a lens cleaner on the lens
 Do not use any abrasive chemicals

Operating and Storage Conditions:

Do not store or operate the device under the following conditions:

 Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)
 High humidity, condensing or wet environments
 In inclement weather
 In swimming pools, airport bathrooms or bat caves
 Dry environments with an excess of static discharge
 Treat the CPU like a business computer. Please shut it down prior to removing power.
 Under severe vibration

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 42 of 52

AutoTrak 2.0 Camera Tracking System

Compliance and CE Declaration of Conformity: AutoTrak 2.0 CPU

Compliance testing was performed to the following regulations:

 FCC 47 CFR Part 15, Subpart B/Oct. 2009 Class A
 ICES-003, Issue 4: 2004 Class A
 EN-55011: 2007 + A2: 2007 Class A
 EN 55022: 2006 + A1: 2007 Class A
 CISPR 22: 1997 Class A
 EMC Directive 2004/108/EC Class A

FCC Part 15 Compliance

This equipment has been tested and found to comply with the limits for a Class A digital device, p ursuant to Part 15
of the FCC Rules. These limits are designed to provide re asonable pr otection against ha rmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own expense.
 Operation is subject to the follo wing two conditions: (1) This device may not cause interference, and (2) This

device must accept any interference including interference t hat may cause undesired operation of the device.

 Changes or modifications not expressly a pproved by Vaddio can affect emission c ompliance and could void the

user’s authority to operate this equipment.

ICES-003 Compliance

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital appar atus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioél ectriques dépassant les limites applicables aux appareils
numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectriqu e édicte par le ministère des
Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.

Standard(s) To Which Conformity Is Declared:
EMC Directive 2004/108/EC
EN-55011: 2007 + A2: 2007 Emissions
EN 55022: 2006 + A1: 2007 Conducted and Radiated Emissions
EN 61000-6-4: 2007 Electromagnetic Compatibility
EN 61000-3-2: 2006 Limits for Harmonic Content
EN 6100-3-3: 2008 Limits for Voltage Fluctuations and Flicker
EN 61000-6-2: 2005 Immunity for Industrial Environments
EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 Immunity

 EN 61000-4-2: 2008 Electrostatic Discharge
 EN 61000-4-3: 2008 Radiated Immunity
 EN 61000-4-4: 2004 + Corrigendum 1:2006 + Corr. 2:2007 Electrical Fast Transients
 EN 61000-4-5: 2005 Surge Immunity
 EN 61000-4-6: 2008 Conducted Immunity
 EN 61000-4-8: 2009 Power Frequency Magnetic Field
 EN 61000-4-11: Second Edition: 2004 Voltage Dips, Interrupts and Fluctuations

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 43 of 52

AutoTrak 2.0 Camera Tracking System

Compliance and CE Declaration of Conformity: AutoTrak 2.0 Worldwide Belt Pack and Lanyard

Compliance testing was performed to the following regulations:

 FCC Part 15 Subpart B Class A
 FCC Part 15, Subpart C, Section 15.247 Class A
 Industry Canada RSS-210 Issue 8 Class A
 Industry Canada RSS-Gen Issue 3 Class A
 IEC 60950-1/A1: 2009 Safety
 ETSI EN 300 328 V1.7.1 Class A
 EN 55022 A: 2010 (CISPR 22, 2008, Modified) Class A
 ICES-003, Issue 4: 2004 Class A
 EN 55022 A: 2010 Class A
 AS/NZS CISPR 22: 2009 +A1:2010 Class A
 VCCI V-3/2011.04 Class A
 EMC Directive 2004/108/EC Class A

FCC Part 15 Subpart B, Subpart C, Section 15.249 Compliance and Industry Canada RS-210
Compliance

 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15, Subpart C

of the FCC Rules and RS210 of Industry Canada. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his/her own expense.

 Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must

accept any interference including interference that may cause undesired operation of the device.

 Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s

authority to operate this equipment.

 Do not use any antenna other than the one provided on the unit.
 This equipment complies with the FCC/IC radiation exposure limits set forth for portable transmitting devices operating in an

uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance.

ICES-003 Compliance
ICES-003, Issue 4: 2004

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux appareils numeriques de
la classe B préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.

EMC Directive 2004/108/EC

 EN 55024: 2010

 EN 61000-4-2: 2009
 EN 61000-4-3: 2006 + Amendments A1: 2008 + A2: 2010
 EN 61000-4-4: 2004 + Corrigendum 2006 - Not applicable
 EN 61000-4-5: 2006 - Not applicable
 EN 61000-4-6: 2009 - Not applicable
 EN 61000-4-8: 2010
 EN 61000-4-11 Second Edition: 2004 - Not applicable

Radio and Telecommunications Terminal Equipment Directive 1999/5/EC

 ETSI EN 301 489-17 V2.1.1: 2009 referencing ETSI EN 301 489-1 V1.2.1: 2008

 EN 61000-4-2: 2009
 EN 61000-4-3: 2006 + Amendments A1: 2008 + A2: 2010
 EN 61000-4-4: 2004 + Corrigendum 2006 - Not applicable
 EN 61000-4-5: 2006 - Not applicable
 EN 61000-4-6: 2009 - Not applicable
 EN 61000-4-11 Second Edition: 2004 - Not applicable
 ISO 7637-2 Second Edition: 2004 + Amendment A1: 2008 - Test not applicable for base station equipment

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 44 of 52

AutoTrak 2.0 Camera Tracking System

Compliance and CE Declaration of Conformity: HD-18 HD PTZ Camera

Compliance testing was performed to the following regulations:

 FCC Part 15, Subpart B Class A
 ICES-003, Issue 4: 2004 Class A
 EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005) Class A
 AS/NZS CISPR 22: 2009 Class A
 VCCI V-3/2009.04 Class A
 EMC Directive 2004/108/EC Class A

FCC Part 15 Compliance

This equipment has been tested and found to comply with the limits for a Class A digital device, p ursuant to Part 15
of the FCC Rules. These limits are designed to pr ovide rea sonable protec tion against harmful interf erence when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own expense.
 Operation is subject to the following t wo conditions: (1) This device may not cause interference, and (2) This

device must accept any interference including interference that may cause undesired operation of the device.

 Changes or modifications not expressly a pproved by Vaddio can affect emission compli ance and could void the

user’s authority to operate this equipment.

ICES-003 Compliance

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital appar atus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioél ectriques dépassant les limites applicab les aux appareils
numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des
Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.

Standard(s) To Which Conformity Is Declared:
EMC Directive 2004/108/EC

EN 55022 A: 2006 + A1 2007 (CISPR 22:2005/A1:2005) Conducted and Radiated Emissions
EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 Immunity

 EN 61000-4-2: 1995 + Amendments A1: 1998 + A2: 2001 Electrostatic Discharge
 EN 61000-4-3: 2006 Radiated Immunity
 EN 61000-4-4: 2004 + Corrigendum 2004 Electrical Fast Transients
 EN 61000-4-5: 2006 Surge Immunity
 EN 61000-4-6: 2007 Conducted Immunity
 EN 61000-4-8: 1993 + Amendment A1: 2001 Power Frequency Magnetic Field
 EN 61000-4-11: Second Edition: 2004 Voltage Dips, Interrupts and Fluctuations

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 45 of 52

AutoTrak 2.0 Camera Tracking System

Compliance and CE Declaration of Conformity - HD-20 HD PTZ Camera

Compliance testing was performed to the following regulations:

 FCC Part 15, Subpart B Class A
 ICES-003, Issue 4: 2004 Class A
 EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005) Class A
 AS/NZS CISPR 22: 2009 Class A
 VCCI V-3/2010.04 Class A
 Korean Requirements KN22: KCC Notice Number 2009-27 Class A
 EMC Directive 2004/108/EC Class A

FCC Part 15 Compliance

This equipment has been tested and found to com ply with the limits for a Class A digit al device, pursuant to Part 15,
Subpart B, of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a comme rcial environme nt. This equipment ge nerate s, uses, and ca n
radiate radio frequency energy and, if not installed and used i n accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his/her own expense.

Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) T his device
must accept any interference including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the
user’s authority to operate this equipment.

ICES-003 Compliance

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital appar atus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioél ectriques dépassant les limites applicab les aux appareils
numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des
Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.

Standard(s) To Which Conformity Is Declared:

EMC Directive 2004/108/EC
EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 Immunity

 EN 61000-4-2: 1995 + Amendments A1: 1998 + A2: 2001 Electrostatic Discharge
 EN 61000-4-3: 2006 + A1: 2008 Radiated Immunity
 EN 61000-4-4: 2004 + Corrigendum 2006 Electrical Fast Transients
 EN 61000-4-5: 2006 Surge Immunity
 EN 61000-4-6: 2009 Conducted Immunity
 EN 61000-4-8: 2010 Power Frequency Magnetic Field
 EN 61000-4-11: Second Edition: 2004 Voltage Dips, Interrupts and Fluctuations

Korean Requirements:

 KN 61000-4-2 with KCC Notice No. 2009-27
 KN 61000-4-3 with KCC Notice No. 2009-27
 KN 61000-4-4 with KCC Notice No. 2009-27
 KN 61000-4-5 with KCC Notice No. 2009-27
 KN 61000-4-6 with KCC Notice No. 2009-27
 KN 61000-4-8 with KCC Notice No. 2009-27
 KN 61000-4-11 with KCC Notice No. 2009-27

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 46 of 52

AutoTrak 2.0 Camera Tracking System

Compliance and CE Declaration of Conformity:
Quick-Connect DVI/HDMI SR Interface

Compliance testing was performed to the following regulations:

 FCC Part 15, Subpart B Class A
 ICES-003, Issue 4: 2004 Class A
 European Standard EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/ A1:2005) Class A
 EMC Directive 2004/108/EC Class A

FCC Part 15 Compliance

 This equipment has been test ed and found to comply with the limits for a Class A digital device, pursuant to Part

15, Subpart B, of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environm ent. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in acc ordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipm ent in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his/her own
expense.

 Operation is subject to the following two conditions: (1) This device may n ot cause interference, and (2) This device

must accept any interference including interference that may cause undesired operation of the device.

 Changes or modifications not expr essly approved by Vaddio can affect emission compliance and could void the

user’s authority to operate this equipment.

ICES-003 Compliance

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital appar atus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioél ectriques dépassant les limites applicab les aux appareils
numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des
Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.

Ferrite cylinders are included in order to the Quick-Connect DVI/HDMI SR Interface to strictly comply with the
European Community EMC Directives compliance. Use these ferrites to ensure the elimination of possible EMI
interference from cell phones and AC motors.

Standard(s) To Which Conformity Is Declared:
EMC Directive 2004/108/EC

EN 55022 A: 2006 + A1 2007 (CISPR 22:2005/A1:2005) Conducte d and Radiated Emissions
EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 Immunity

 EN 61000-4-2: 1995 + Amendments A1: 1998 + A2: 2001 Electrostatic Discharge
 EN 61000-4-3: 2006 Radiated Immunity
 EN 61000-4-4: 2004 + Corrigendum 2006 Electrical Fast Tr ansients
 EN 61000-4-5: 2006 Surge Immunity
 EN 61000-4-6: 2007 Conducted Immunity
 EN 61000-4-8: 1993 + Amendment A1: 2001 Power Frequency Magnetic Field
 EN 61000-4-11 Second Edition: 2004 Voltage Dips, Interrupts and Fluctuations

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 47 of 52

AutoTrak 2.0 Camera Tracking System

Compliance and CE Declaration of Conformity: EasyTalk AutoTrak 2.0 Wireless Audio Interface

Compliance testing was performed to the following regulations:

 FCC Part 15 Subpart B
 FCC Part 15, Subpart C Section 15.247 Class A
 FCC Part 15, Subpart C Section 15.207 Class A
 Industry Canada RSS-210 Issue 8 Class A
 Industry Canada RSS-Gen Issue 3 Class A

IEC 60950-1/A1: 2009 Safety


 ETSI EN 300 328 V1.7.1 Class A
 EN 55022 A: 2010 (CISPR 22, 2008, Modified) Class A
 ICES-003, Issue 4: 2004 Class A
 EN 55022 A: 2010 Class A
 AS/NZS CISPR 22: 2009 +A1:2010 Class A
 VCCI V-3/2011.04 Class A
 EMC Directive 2004/108/EC Class A

FCC Part 15 Subpart B, Subpart C, Section 15.249 Compliance and Industry Canada RS-210
Compliance

 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15, Subpart C

of the FCC Rules and RS-210 of Industry Canada. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his/her own expense.

 Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must

accept any interference including interference that may cause undesired operation of the device.

 Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s

authority to operate this equipment.

 Do not use any antenna other than the one provided on the unit.
 This equipment complies with the FCC/IC radiation exposure limits set forth for portable transmitting devices operating in an

uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance

ICES-003 Compliance
ICES-003, Issue 4: 2004

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux appareils numeriques de
la classe B préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and Immunity and meets
the requirements for a Class A digital device. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.

Standard(s) To Which Conformity Is Declared:

EMC Directive 2004/108/EC

 EN 55024: 2010

 EN 61000-4-2: 2009
 EN 61000-4-3: 2006 + Amendments A1: 2008 + A2: 2010
 EN 61000-4-4: 2004 + Corrigendum 2006
 EN 61000-4-5: 2006
 EN 61000-4-6: 2009
 EN 61000-4-8: 2010
 EN 61000-4-11 Second Edition: 2004

Radio and Telecommunications Terminal Equipment Directive 1999/5/EC

 ETSI EN 301 489-17 V2.1.1: 2009 referencing ETSI EN 301 489-1 V1.2.1: 2008

 EN 61000-4-2: 2009
 EN 61000-4-3: 2006 + Amendments A1: 2008 + A2: 2010
 EN 61000-4-4: 2004 + Corrigendum 2006
 EN 61000-4-5: 2006
 EN 61000-4-6: 2009
 EN 61000-4-11 Second Edition: 2004
 ISO 7637-2 Second Edition: 2004 + Amendment A1: 2008 - Test not applicable for base station equipment

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 48 of 52

AutoTrak 2.0 Camera Tracking System

Appendix 1: HD-18 Connector Information

 DE-15-F (HD-15F Connector)

Pin YPbPr

1 Pr
2 Y
3 Pb
4 ­5 ­6 Pr GND
7 Y GND
8 Pb GND

9 ­10 ­11 ­12 ­13 ­14 ­15 -

 EZCamera Power & HD Video RJ-45 Connector Pin-outs

Quick-Connect DVI/HDMI SR Interfaces - 568B Wiring Standard)

Pin YPbPr

1 Power+
2 Power­3 Y+
4 PB+
5 PB GND
6 Y GND
7 PR+
8 PR-

12345678

(For HD-18 Camera and Quick-Connect SR and

 RS-232 and IR OUT RJ-45 Connector Pin-outs

DVI/HDMI SR Interfaces - 568B Wiring Standard)

Pin # RS-232 and IR OUT RJ-45

1 Unused
2 Unused
3 ­4 ­5 ­6 GND
7 RXD (from TXD of control source)
8 TXD (to RXD of control source)

(For HD-18 Camera and Quick-Connect SR and Quick-Connect

12345678

Communication Specification AutoPresenter or Serial CPU Interface

Communication Speed: 9600 bps

 Start bit: 1
 Stop bit: 1
 Data bits: 8
 Parity: None
 No Flow control

Notes:

 A total of six (6) presets can be accessed with a control

system via RS-232

 Each Command must be followed by a line feed <lf>
 Presets are set up on the Preset-Tracking Camera tabs under the AutoPresenter Camera Preset Area. No trigger assignments

are needed. Set the Tracking Camera position and store the preset. Recall the preset with the commands above.

 The Preset OFF command must be issued to return to active tracking.
 R99<lf> Will reset/reboot the AutoTrak CPU

RS-232 Command Description

P00<lf> Preset Off (back to active tracking)
P01<lf> Preset 1 for Tracking camera
P02<lf> Preset 2 for Tracking camera
P03<lf> Preset 3 for Tracking camera
P04<lf> Preset 4 for Tracking camera
P05<lf> Preset 5 for Tracking camera
P06<lf> Preset 6 for Tracking camera
R99<lf> CPU Reset Command

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 49 of 52

AutoTrak 2.0 Camera Tracking System

AutoTrak 2.0 HD-18 PTZ Camera Dimensions

AutoTrak 2.0 HD-20 PTZ Camera Dimensions

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 50 of 52

AutoTrak 2.0 Camera Tracking System

AutoTrak 2.0 Dual Mount Dimensions

HD-18*

HD-18
or
HD-20

* To allow for full tilt movement of the upper (Reference) HD-18 camera, an overall “build out” height of 20” is suggested.

AutoTrak System Notes:

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 51 of 52

AutoTrak 2.0 Camera Tracking System

©2014 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to
change without notice. Vaddio, AutoTrak, AutoPresenter, Quick-Connect, ClearVIEW, WallVIEW, EZCamera, HSDS and PowerRite are registered
trademarks of Vaddio. All other trademarks are property of their respective owners. Document 342-0382 Rev. E

AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 52 of 52

Toll Free: 800-572-2011 ▪ Phone: [phone] ▪ FAX: [phone]

www.vaddio.com
