Attention Installer: Please be sure this manual and warranty information

are left with the power unit or customer when installation is complete.

Operating Instructions For

VACUFLO

®

Central Vacuum Systems

True Cyclonic Models:

260, 466Q, 566Q, 760 & MaxAir

Filtered Cyclonic Models:

FC300, FC550, FC550-C, FC650,

FC650-C & FC1550

Disposable Bag Models:

DB3000, DB5000, DB7000,

DB8000 & DB9000

Read Manual Before Operating System

Read the owner’s manual thoroughly before operating to

ensure the most efficient use of the system.

VACUFLO Central Vacuum Systems

2

Models UL File Ref. # ETL File Ref. #

FC300 77100 N/A
FC550 77125 N/A
FC550-C 77125 N/A
FC650 77130 N/A
FC650-C 77130 N/A
FC1550 77250 N/A
260 Model 260 N/A
466Q Model 466Q N/A
566Q Model 566Q N/A
760 Model 760 N/A
MAXAIR N/A 88100
DB3000 N/A 77400
DB5000 N/A 77500
DB7000 N/A 77600
DB8000 N/A 77800
DB9000 N/A 88200

3

TABLE OF CONTENTS:

Important Safety Instructions ....................................................................... 4

Grounding Instructions ................................................................................. 6

General Information ...................................................................................... 8

Registration ................................................................................................... 8

Operating Instructions .................................................................................. 8

General Maintenance .................................................................................... 9

Emptying the Dirt Canister and Filter Maintenance .................................... 10

Disposable Bag Removal and Replacement ................................................ 13

Troubleshooting ............................................................................................ 14

CONSIGNES DE SÉCURITÉ IMPORTANTES ................................................. 15

INSTRUCTIONS DE MISE À LA TERRE ......................................................... 17

Warranty ........................................................................................................ 19

VACUFLO Central Vacuum Systems

4

This manual contains canister and maintenance instructions for three (3)
different filtration methods. Please be sure to follow the appropriate instructions
for your power unit model number (found on the front of the canister).

To find links to maintenance videos, downloadable manuals,
troubleshooting and warranty information or to register your system,
please visit www.centralvacservice.com.

IMPORTANT SAFETY INSTRUCTIONS

Read These Instructions Before Using This Vacuum System

Installation of this product should be made by a qualified, authorized
central vacuum dealer. Before installing, using, or servicing this product,
the installer should carefully read and fully understand the instructions
including all warnings, cautions, and safety notice statements. To
reduce the risk or personal injury, death and/or property damage, follow
all instructions for proper installation, operation and maintenance.
These instructions are not intended as a complete listing of all details
for installation, operation and maintenance. If you have any questions
concerning any of these procedures, STOP, and call an authorized central
vacuum dealer.

5

When using an electrical appliance, basic precautions should always be
followed, including the following:

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:

• Unplug and disconnect power before servicing.

• Do not allow to be used as a toy. Close attention is necessary when used
by or near children.

• Use only as described in this manual. Use only manufacturer’s
recommended attachments.

• Do not use with damaged cord or plug. If appliance is not working as
it should, has been dropped, damaged, left outdoors, or dropped into
water, return it to an authorized servicing dealer.

• Do not pull or carry by cord, use cord as a handle, close a door on cord,
or pull cord around sharp edges or corners.

• Do not run appliance over cord.

• Keep cord away from heated surfaces.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Do not handle system or appliance with wet hands.

• Use extra care when cleaning on stairs.

• Do not use on wet surfaces.

• Do not put any object into openings. Do not use with an opening blocked.
Keep openings free of dust, lint, hair and anything that may reduce
airflow.

• Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.

• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.

• Connect to a properly grounded outlet. See grounding instructions.

• Turn off all controls before unplugging.

• Do not use to pick up flammable or combustible liquids such as gasoline
or use in areas where they may be present.

• Do not place or store anything on top of power unit- overheating of motor
could occur.

• Any service work required under the top cover should be performed by
an authorized service representative.

• Do not operate without filter/disposable bag in place (if applicable).

• Always turn off this appliance before connecting or disconnecting
motorized nozzle.

VACUFLO Central Vacuum Systems

6

GROUNDING INSTRUCTIONS

This appliance must be grounded. If it should malfunction or break down,
grounding provides a path of least resistance for electric current to reduce
the risk of electric shock. This appliance is equipped with a cord having an
equipment-grounding conductor and grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.

WARNING

Improper connection of the equipment­grounding conductor can result in a
risk of electric shock. Check with a
qualified electrician or service person
if you are in doubt as to whether the
outlet is properly grounded. Do not
modify the plug provided with the
appliance. If it will not fit the outlet,
have a proper outlet installed by a
qualified electrician.

Models FC300, FC550, FC650, 260,
466Q, 566Q, DB3000, DB5000, DB7000
and DB8000 are for use on a nominal
120 volt circuit and have a grounding
plug that looks like the plug in Fig. A.

Models FC1550, DB9000 & MaxAir dual
motor units are for use on a nominal
240 volt circuit and have a grounding
plug that looks like the plug in Fig. B.

Model 760 dual motor unit is for use
on a nominal 120 volt circuit and has a
grounding plug that looks like the plug
illustrated in Fig. C.

Make sure that the appliance is connected to an outlet having the same
configuration as the plug. No adapter should be used with this appliance.

CONNECT TO A PROPERLY GROUNDED OUTLET ONLY.
