VacuBlend Action User Manual

User manual

This product is for home use only. Usage in commercial or industrial environments is prohibited. Read this manual carefully before use and keep it where you can ﬁnd easily. Do read “Important Safeguards” before using the product. Your original purchase receipt is the proof for product warranty, keep it well. The product design and functionality are subject to change without notice

Part names and components

Important safeguards before use

How to use the VacuBlend

Cleaning and maintenance

Check before reporting trouble

Warranty and contact

Part Names and Components

Technical Speciﬁcations

Model name: Action Rated Operating Time: Less than 1 minute Dimensions: 200(W) X 220(D) X 448(H) Weight: 3.4kg Rated Power Consumption: 960 W Max. vacuum level: -80 Kpa

What's in the box

1 Set of Vacuum Blender 1 Sub Vacuum Container 1 User Manual 1 spare vacuum valve

Vacuum Body (Main Body)

Power Plug

Auto Button

Main Body Vacuum Valve

Vacuum Valve

Blender Container Lid

Vacuum Container

Speed Control Dial

Vacuum Button

Pulse Button

Power Button

Support

Vacuum Cap

Vacuum Container Components Sub Vacuum Container Components

Vacuum Valve

Container Lid

Container Packing

Backﬂow Prevention Cap

Container

Blade Body Disassembly Device

Lid for Blender Container

Upper Packing

Side Packing

Backﬂow Prevention Cap

Blender Container

Blade Body Packing

Hexa-Blade (Blade)

Blade Body

When disassembling or assembling the vacuum container for washing ALWAYS:

You can do this by turning them counter clockwise and assemble them by turning them clockwise (refer to section 04 for details).

Ÿ Disassemble the backﬂow prevention cap Ÿ Disassemble the blade body

※

Use a proper outlet for the electric capacity of the product. Do not connect or disconnect the plug by the cord; do so by the plug. It can cause ﬁre, electric shock, or electric leakage.

Do not bend, tie, or pull the power cord by force. It can cause electric shock or ﬁre.

Clean any dirt on the power plug. Do not touch or connect the power cord with wet hands. It can cause

electric shock.

Do not disassemble or remodel the product or press the safety device by force in order to start the product. It can cause trouble, ﬁre, electric shock or injury.

Do not place the product in a hot and humid area or near an electric heater or inﬂammable substances.

It can cause ﬁre, electric shock, or other safety accidents.

Do not wash the main body in water. Do not use dish washer or dish dryer for the main body. It can cause trouble, ﬁre, or electric shock. Remove dirt using dampened dry cloth.

Do not use the product longer than 60 seconds continuously. When using it multiple times, do not use it more than 2 times within 30 minutes. It can cause damage to the product. The motor will stop automatically

when the safety device (temperature sensor) is activated to prevent the motor's overheating. This is not a defect. Cool down the motor for at least 30 minutes and then try again.

Do not put hot water (40°C or hotter) on the materials. Be careful if hot liquid is poured into the blender as it can be ejected out of the appliance due to sudden steaming. It may cause damage or injury to the

product.

Do not open the vacuum cap or move the product in use. After use, turn off the power and open the vacuum cap after the knife comes to a complete stop. It can cause injury or damage.

Always operate the product on a ﬂat, hard and dry surface. Do not place the product on an unstable place where it might fall easily. Do not put place the product on a rug or cushion. It can cause electric

shock or an accident.

Do not idle the blender while the vacuum container is empty. For ice and solid materials, peel off and break into pieces to use with other materials containing moisture (Refer to section 03). It can cause damage or ﬁre.

This appliance CANNOT be used by children under the age of 8 years. Children aged 8 and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge can use the product if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

Important safeguards before use

WARNING

The safety related information in the following is intended to prevent unpredicted danger or damage by guiding you to use the product safely and properly. The safety related cautions for this product comply with certiﬁed technical standards and the electric safety standards. Read the descriptions carefully and follow the instructions to avoid danger. The following symbols are used to remind the user of the matters and operations that can lead to danger.

※

WARNING Refers to the case where the noncompliance with instructions can lead to serious injury or death. CAUTION Refers to the case where the noncompliance with instructions can lead to light injury or product damage.

When you open or close the vacuum cap, do not use excessive force, and make sure the vacuum container does not bump into vacuum cap. It can cause breakage.

Do not apply extreme shock to the product or drop the product. It can cause trouble and problems with

safety.

Do not clean the product with paint thinner, benzene, or insecticide. It can damage the appearance through discoloration or exfoliation.

When disassembling the blade body for washing, take cautions to avoid injury by the sharp blade. (Wear protective gear).

If the product generates a strange sound or an odor while in use, pull out the power plug immediately and contact customer support center. If you run the blender at a high RPM, it can produce a slight smell due

to the friction of the motor. However, this is not a defect.

Disconnect power plug when the product is not in use, or to store or wash the product. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualiﬁed persons in order to avoid a hazard.

Use the product for designated uses only (do not use the product for kneading, mincing, pulverizing, or for dried food materials). Do not put the product and its parts into boiling water or a microwave. It may cause damage or injury.

Do not put a ﬁnger or metal spoon in the vacuum container. It can cause injury and product damage.

After blending, separate the container only after the blade comes to a complete stop. Wash the blade and container immediately and store it after it is completely dry. If not, it can become the cause of foul odor,

bacterial propagation, and corrosion.

After each use, the container lid must be washed for next use (refer to section 04). If the expanding bubble or food material goes into the backﬂow prevention cap on the container lid, it can cause trouble.

Do not use the exclusive container and designated parts with other devices or undesignated parts. It can cause breakage.

After vacuuming, keep the food in the refrigerator (never in the freezer). The vacuum does not sterilize the foods. Take cautions when storing food.

Do not use carbonated beverages, large frozen foods, or sticky foods, etc.). It can cause injury or breakage.

Take cautions to make sure the food material does not go into the safety device. It can cause injury or

breakage.

Keep the maximum or the minimum volume for each type of material (refer to section 03). It can cause breakage. Maximum level for smoothies to blend (MAX 1,000ml), Maximum level for milky ﬂuids to blend (MAX 750ml), Minimum level for materials to blend (400ml).

When disposing used appliances as waste, follow designated disposal procedures.

CAUTION

How to use the VacuBlend

Open the blender container lid, put an appropriate amount of materials, and close the lid (Refer to section 03, item 15 for volume of materials). Match the bump on the container's pouring section and the bump on the lid. (If not, the vacuum may not work).

Turn the vacuum container clockwise until the handle comes to the “Lock” position on the front side.

※

Check if the vacuum container and vacuum cap are connected properly.

If the vacuum container is not set properly, all lamps on the front side will ﬂicker with the buzzer sound while the blender is in use. Press the power button to cancel the buzzer and check whether the container is set properly.

※

Press the power button to turn on the blender and use the required function to prepare the materials.

All lamps on the front side will be on when the container is set properly and is ready. Check before use!

Completely close the vacuum cap that you had opened to the left.

Open the vacuum cap of the blender's main body to the left and turn the container until its handle comes to the “Open” position to set it on the main body.

Like it simple? Go to: www.vacublend.com and watch the video.

AUTO

LOW HIGH

VACUUM

PUSH

PULSE

LOWLOW





※



※

Turning on the power

Connect the power plug of the main body to 220V outlet, press the power button to turn on the lamps on the control panel with the signal sound. Lamps will turn on partially when the vacuum container is not set properly or when the vacuum cap is not closed properly. The blender function will not operate when the lamp is not on.

Even when the power is off, a small amount of electricity is ﬂowing through the product.

This switch puts power on suspend, but does not completely turn it off.

If an error occurs without the operation being complete, the problem may be due to lose seal. Tap the top of the vacuum valve in the main part when the vacuum starts.

LOW HIGH

PULSE

PUSH

LOW HIGH

PULSE

PUSH

※

Speed Control

Turn the speed control dial clockwise to start the blender. The blending speed increases by the ratio of turning the dial, and decreases to a stop when the dial is turned the other way around.

(Lamp will ﬂicker at various rates depending on the blending speed).

The blender will stop when you press Pulse button while controlling the speed.

It will operate for a ﬁxed period of time and stop automatically.

PUSH

AUTO

LOW HIGH

VACUUM

PULSE

※

Vacuum

When you press the vacuum button, it will automatically reach the automatically set vacuum pressure. The lamp will ﬂick during vacuum action, and it will stop when you press the button again.

When an error occurs, the vacuum and pulse lamps will ﬂicker simultaneously with the buzzer sound, and this will be cancelled when you press the power button again. Check the connection between vacuum container and main body and the vacuum valve for trouble.

10.

PUSH

AUTO

LOW HIGH

VACUUM

PULSE

※

Auto

When you press auto button, it will automatically carry out vacuum, pulse, and blend functions in respective order and also automatically stop without additional control of the user.

Lamps will ﬂicker when the blender is running and stop when you press the auto button again.

11.

PUSH

AUTO

LOW HIGH

VACUUM

PULSE

(Dial's lamp will ﬂicker at a fast rate).

Pulse

When you press the pulse button on the speed control dial, the blender will instantly run at full power.

Release of Vacuum (2 steps)

When you want to remove the vacuum container after vacuum blending, you must ﬁrst open the vacuum valve on the top to release the vacuum, after this you can open the vacuum cap and separate the container. On the vacuum container you must also release vacuum by opening the vacuum valve on the top of the lid.

12.

Sub Vacuum Container (Storage Container)

You can keep blended juice or other foods in vacuum using the storage container to keep them fresh for a long time (Vacuum delays oxidation but does not sterilize the contents. Keep them refrigerated and consume

them as soon as possible). Some food products, including fruits, emit gas. In such case it may seem that the

vacuum container does not preserve food well, even when in fact, it is well sealed.

13.

Maximum Level

Do not exceed the maximum level for each substance indicated by the scale on the container. Bubbles or ﬂuids getting into the vacuum pump can cause a malfunction.

14.

Powdered Materials / Dry Materials

Powdered materials shall be completely dissolved in water or beverage for use, and dry materials shall not be used by themselves.

16.

1250

1000

750

500

Limit for Milk / Soymilk

Foods with Milk / Soymilk

Only Milk / Soymilk

Minimum Level

All materials must be inserted above the minimum (MIN) level indicated by the scale on the container. If not, the blade will idle and will not be able to crush the materials, and this can lead to a malfunction or a

performance problem.

15.

If the material is too large or too thick, the contents might not be blended well. In this case, add liquid such as water or milk. If you put ingredients over the reference mark of the container, expanded content may suck in to the backﬂow prevention cap during vacuum and cause malfunction of the vacuum pump. Please make sure to stop the operation before reaching the backﬂow prevention cap.

Maximum level to blend (MAX)

Maximum level for smoothies (1,000ml)

Maximum level for products containing milk and soymilk (750ml)

Minimum level for materials to blend (400ml) Maximum level for ice cream insertion (400ml)

How to Insert your ingredients

※ ※

Ice and Solid Materials

Ice and solid materials shall not be used by themselves; break into small pieces and insert in the following order.

17.

Liquid such as water or beverage Watery or soft materials Ice or solid materialsLight materials

① → ② → ③ → ④

How to use the Vacublend (continued)

Before using the product make sure that the blade body is inserted all the way into the connecting part of the container. When loosely assembled, the contents may pour out and cause malfunction.

※

You can easily assemble/disassemble the blade by using the footlid of the Sub Vaccum container. I has a double function as a tool for better grip.

※

Cleaning and maintenance

Make sure the components such as packing and backﬂow prevention cap are not missing when reassembling them after washing.

※

OPEN

Blades are sharp. Take cautions to avoid injury. (Wear protective gear).

Washing Blade Body

Blade body is not waterproof. Do not put it directly into the water. Wash only the blades using the brush under running water in order to prevent corrosion and remove moisture completely. If there is dirt on the bottom of the blade body, clean it with soft cloth or kitchen cloth.

※

Washing Lid

After each use, wash the lid and remove moisture, for next use. If a large quantity of blended materials spattered on it, separate and wash the backﬂow prevention cap on the container lid and dry it well before use. If the vacuum valve is spattered with food, it can block the vacuum passage and cause trouble. Take cautions to avoid trouble. In case the valve is spattered with food, separate and wash the vacuum valve and dry it well before use.

Assembly and Disassembly of Backﬂow Prevention Cap Turn it counter clockwise as in the picture on the right to disassemble

and clockwise to assemble.

※

Assembly and Disassembly of Vacuum Valve Pull up as in the picture on the right to disassemble and press down

to assemble.

※

Storing after Cleaning

When storing after washing, completely wipe and dry the product and store it in a well-ventilated place away from heat or direct sunlight.

Other Cautions

You must turn off and unplug the product before cleaning or storing the product.

Rough and sharp tools such as steel wool or steel brush can damage the product to cause leakage of materials or vacuum failure. Do not use such tools. For the risk of ﬁre, never use benzene, paint thinner, and wax.

※

Cleaning Main Body

Clean the main body using a small amount of neutral detergent mixed in warm water and soft cloth or kitchen cloth.

Do not sprinkle water or other liquid agents on the main body or do not put the main body into water. It can cause ﬁre or electric shock.

※

If the water gets inside the main body, dry it thoroughly before use.

※

Cautions for Disassembling and Cleaning Blade Blades are sharp. Take cautions to avoid injury. Using the blade disassembly device as in

the picture on the right, turn it counter clockwise to disassemble and clockwise to assemble.

Cleaning Container

To wash the container and the blade, ﬁll half of the container with water, assemble it to the main body, and run for 15 seconds to wash the remnants caught in the blades easily. Do not operate the product with foaming detergent in it (The foam can cause product damage).

※

Please Check before Reporting Trouble

When you experience the following symptoms while using the product, check again. You may be able to resolve the issue yourself.

※

When the error occurs, turn off the power, unplug the product, and then take action.

※

AUTO

LOW HIGH

VACUUM

PUSH

PULSE

Error Action

Auto Error

Vacuum Error

Safety Device

Error

Auto and

Pulse

Beep - Beep - Beep - Beep - Beep

(5 times)

Beep - Beep - Beep - Beep - Beep

(5 times)

Beep - Beep - Beep - Beep - Beep

(5 times)

Vacuum and

Pulse

All

Lamps

Buzzer Sound

Buzzer / Lamp Reaction to Errors

For following symptoms

Take following measures

It is not working at all

It stops while in use

Check whether the earth leakage breaker is down or whether the power cord is unplugged.

Check whether the vacuum container is set on the main body properly or whether the vacuum cap is closed properly.

Materials not pulverized well

Did you put too much or too little materials? Refer to how to feed food materials in section 3.

Check operating voltage. This product is exclusively for AC 220V.

Materials are leaking Check whether the vacuum container is set on the main body properly and whether the

container's lid or blade body are connected to the container properly. Check whether the container's lid or blade packing is damaged and if it is, then contact

your retailer or customer service center.

Vacuum is not working Check whether the vacuum container components such as packing and backﬂow

prevention cap are assembled properly. Check whether the container's lid is contaminated. If it is, clean it according to the

descriptions in section 4. Check if the container cover seal is in correct position and press the vacuum valve on the

vacuum cap of the main body as it starts vacuuming (see section 3, the top of the right page).

Check whether the earth leakage breaker is down or whether the power cord is unplugged.

Did you use the product continuously for a long time? When the motor overheats, it is designed to stop automatically for safety and run again when it cools down.

Cool down the motor fully for 30 minutes and try again.

Check whether materials are caught in the blades. Check whether the vacuum cap is open or whether the vacuum container is loosened

from the main body.

Warranty and contact

You can register your purchase on the website of Versapers. http://versapers.com/warranty. Your warranty is executed at the local distributor where you have purchased the product.

Please always keep your invoice or receipt as original proof of purchase in case of making a claim on the warranty. We certify that your Vacublend vacuum blender is warranted by Versapers to be free from

defects in material construction and workmanship.

All parts are warranted for two (2) years from the date of purchase to the original purchaser. This warranty does not apply to damages caused by accident, misuse, abuse, commercial use, alteration, failure to follow the operating instructions in this manual, or damage caused by parts or

service unauthorized by Versapers.

Damages caused by transportation must be claimed with the carrier. Versapers disclaims all responsibilities for consequential damages from incidental losses caused by use of this appliance. If service should be necessary, please contact our local Customer Care Center for technical support.

Manufacturer : Versapers De Steeg 10 9473 TT De Groeve The Netherlands

You have bought a VacuBlend and thus you now belong to the leading group of health innovators. In the nutritional ﬁeld, you show that you only want the best for yourself and your family. By nourishing your knowledge about the healthiest food trends and tools, you have managed to ﬁnd us.

We think it's super cool that VacuBlend has got a place in your life. All the super healthy juices, smoothies and soups that you will make with it, will bring you mentally and physically feel better.

For me personally VacuBlend is the newest baby in our mission to make the world a little healthier every day. Of course we will do our best to inspire as much as possible with creative recipes and applications, enabling you as our health ambassador to further inspire the people in your environment. Together, we have made a new step in our juice revolution. Yeah!

Welcome to the brand new world of vacuum blending.

With healthy regards,

Joost Founding father Versapers

Congratulations!

A Dutch brand, made in South Korea

VB_ACT_V1.0_EN

www.versapers.com
