Page 1
User’s Manual
PRO275
Model:
PRO275
Register your product and get support at www.VacMasterFresh.com
Page 2
www.VacMasterFresh.com | 800-821-7849
Welcome!
Thank you for purchasing the VacMaster® PRO275 Suction Vacuum Sealer. You
are about to revolutionize your home with one of the strongest vacuum packaging
systems available. With the help of the PRO275 Vacuum Sealer, you will now be
able to keep food fresher, longer in the refrigerator, freezer and pantry. The PRO275
effectively removes air and extends freshness up to five times longer than normal
preservation methods. Beyond that, the PRO275 can be used to preserve and
organize household items like keepsakes, small toys and easy-to-lose items. You
will soon find your Vacuum Sealer to be so versatile and convenient; it will never
leave your countertop.
By using vacuum bags and canisters, you can significantly extend food life, maintain
food quality, reduce freezer burn, and reduce food waste and costs.
The style of the Vacuum Sealer is clean and simple with a lightweight, compact
design. Its unique slanted layout design and wide vacuum trough makes it easy to
load bags and ensure a positive seal every time. Only high quality, fully tested and
rated components have been used in the construction in order to ensure the best
performance.
Read and follow all directions for usage and maintenance carefully and you’ll benefit
from years of trouble-free and cost effective vacuum packaging.
SAVE THESE INSTRUCTIONS
Page 3
www.VacMasterFresh.com | 800-821-7849
Register Your VacMaster
®
Table of Contents
Important Safeguards
PRO275 Features
How to Use Your PRO275
Control Panel
Important Safetguards
Make a Pouch Using a Roll
Seal One End of a Cut Off Pouch
Cleaning and Care
Troubleshooting
Warranty
3
4-5
6
7
8
9
9
9
10
11
Register your product and get support at
www.vacmasterfresh.com/product-registration
Page 4
www.VacMasterFresh.com | 800-821-7849
Important Safeguards
3
For your safety, always follow these basic precautions when using a VacMaster®
PRO275 Vacuum Sealer:
Read all instructions in this User’s Manual before use.
Do not use the PRO275 near a heat source or on a wet or hot surface.
To protect against electrical shock, do not immerse any part of the
vacuum sealer plug or power cord in water or any other liquid.
Unplug the machine before cleaning or when not in use.
To disconnect, unplug the power cord from the electrical outlet.
Do not disconnect by pulling on the cord.
Do not operate the PRO275 if it has a damaged cord or plug.
Do not operate the PRO275 if it malfunctions or is damaged.
Contact Customer Service at 800-821-7849.
Use the PRO275 only for its intended use.
Closely supervise children when using any electrical appliance.
Do not allow the PRO275 to be used as a toy.
Use only a grounded electrical outlet. To reduce risk of electrical
shock, do not modify the plug in any way.
Do not use an extension cord.
The power cord should not drape over a counter or tabletop, as the
cord could be tripped over or pulled on unintentionally.
Do not place or operate near an electric/gas burner or a heated oven.
Extreme caution and care must be used when sealing or handling any
pouches containing hot foods.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Page 5
www.VacMasterFresh.com | 800-821-7849
3
PRO275 Features
Control Panel
Machine Lid
Lock
Lower Seal Gasket
Seal Foam
Upper Seal Gasket
Roll Storage
Roll Cutter
Seal Wire (Under Tape)
Seal Tape (Not to be Removed)
1
2
3
4
5
6
7
8
9
10
2
5
6
7
8
9
4
1
3
10
4
Page 6
www.VacMasterFresh.com | 800-821-7849
2
Important Safeguards
Vacuum packaging is not a substitute for canning. All perishables still
need to be refrigerated or frozen.
Follow all food safety regulations as outlined by the FDA at
www.FDA.gov.
Use only VacMaster® Vacuum Full Mesh Pouches and accessories.
Some fruits and vegetables may release gases, known as outgassing.
When packaging these fruits and vegetables, outgassing can cause
the vacuum to be gradually lost over time. Blanching or freezing
before vacuum packaging helps prevent this from occurring.
Delicate foods can be frozen prior to packaging to protect them from
getting crushed by the vacuum.
Use VacMaster® Bone Guard to cover an item’s sharp edges to
prevent pouch punctures.
Allow foods to cool before vacuum packaging.
Avoid overfilling the pouch. Leave a minimum of 3” of space between
the contents and the open end of the pouch. This is called head
space. This will prevent spills during the vacuum sealing process.
To prevent wrinkles from forming in the seal, gently stretch the pouch
flat along the seal bar before closing the lid.
VacMaster® pouches are boilable, freezable, and microwavable.
When microwaving, it is important to pierce or make a small cut in the
pouch.
Whether you are a pro or a beginner, here are some good tips to make sure you
are Vacuum Packaging correctly:
•
•
•
•
•
•
•
•
•
•
•
PRO275 Features
IMPORTANT: The PRO275 will not do liquids or high moisture
content products.
5
Page 7
www.VacMasterFresh.com | 800-821-7849
3
Vacuum Packaging TipsHow to Use Your PRO275
Vacuum Cycle
Runs for a set time - counting down to zero
Sealing Cycle
Runs for a set time - counting down to zero
Inspect the pouch - When the lid opens, remove and inspect the pouch.
Vacuum confirmation - Check the quality of the vacuum by looking at the tight-
ness of the pouch and the product. Look for air pockets or air leaks. If you notice
that the product is not vacuum packaged tightly, then increase the vacuum time by
5 seconds and vacuum and seal again.
Seal confirmation - Inspect the pouch seal. A positive seal will appear clear upon
inspection. If the seal is spotty or incomplete, increase the seal time by 0.1 second.
If the seal appears white or milky, decrease the seal time by 0.1 second. Once the
settings are determined for your application, vacuum and seal again.
Set your vacuum sealing time - Starting at 5 set your time on the control
panel. Press start after you make sure everything is secure.
3
4
5
6
If the product is vacuumed and sealed tightly, then the process is complete.
Place the bag across the seal bar - Close the lid on the front corners.1
6
Press in the sides of the PRO275 - Make sure your PRO275 is locked by
pressing in the side buttons on the machine.
2
Lid Release
After sealing, the lid will unlock, then
BEEP. You may then open it.
Page 8
www.VacMasterFresh.com | 800-821-7849
2
Important Safeguards
Control Panel Features
ON/OFF Button - Turn the VP275 ON/OFF with this button. The
machine will enter Ready-to-Work mode as the default mode. If the
vacuum sealer is on and there has been no activity in 10 minutes, it
will enter standby mode automatically.
Auto Vacuum Button (START) - Press the “Start” button to get
the machine to vacuum and seal automatically. After it’s finished, the
machine will beep.
SEAL Button - Press “Seal” button to stop the vacuum cycle then
the pouch will seal and the unit will stop. You can also use this button
to make your own bag sizes with our rolls.
During the vacuum process, press Seal or Pulse to change working
mode.
STOP Button (Cancel) - Press to stop the cycle and immediately
seal the pouch. This button will only work when the machine is in the
vacuum process.
PULSE Button - Press “Pulse” until the digital display shows P.
Continue pressing the “Pulse” button again and again to vacuum
seal the bag little by little. If no actions are detected within 10
seconds, machine will go back to Ready-to-Work mode.
Accessory Vacuum Button - Only use this function for vacuum
canisters, wine bottle stoppers, and other accessories. Press
“Accessory” button to start the vacuum cycle. After the vacuum
cycle, the PRO275 will stop automatically WITHOUT sealing.
6
1 4
5
2 3
1
2
3
4
5
6
7
Page 9
www.VacMasterFresh.com | 800-821-7849
3
Vacuum Packaging Tips
7
Vacuum Level Button - Press the “Vacuum Level” button to set
the vacuum level needed. There are two options - High or Low. The
default setting is high.
Digital Display - This displays the vacuum cycle time. During the
vacuum cycle, the display will count up from 0 to 9. When it shows 9,
the vacuum cycle is finished. Then the unit will seal automatically.
It also displays the seal time which can be adjusted and set from 0-9
seconds.
When it is displaying an “E”, the machine is in protective status. See
Troubleshooting on page __ for more help.
Seal Time Adjusting Button (“+” “-”) - Simply adjust the seal time
up or down by using the “+” or “-” buttons. When it is adjusted to 0,
the machine will not seal. Set the seal time from 0-9 seconds. Start at
5 seonds.
The PRO275 will memorize the last seal time setting used.
7
8
9
8
9
Important Safeguards
8
Page 10
www.VacMasterFresh.com | 800-821-7849
2
Important SafeguardsMake a Pouch Using a Roll
9
Cleaning and Care
Disconnect the power cord from the electrical outlet by unplugging it. DO NOT
disconnect by pulling on the cord.
Check the Vacuum Sealer, making sure it’s clean and free of debris. If needed,
use a clean, damp cloth with mild soap.
a. Wipe the gasket clean.
b. Wipe the seal area clean.
DO NOT use any acetone-based or abrasive cleaners on the unit. Only clean
with a damp cloth and mild soap.
•
•
•
Lift the lid and put the roll in the back cradle.
Life the cutting bar and put the open end of the roll underneath the
cutting bar.
Pull out the desired length. Let the cutting bar go down.
Firmly push down on the cutting button and slide it across the unit.
This will make a clean cut off of the pouch roll.
1
2
3
4
5
To Seal a Cut Off Pouch
Open the lid.
Put an open end of the cut off pouch over the seal bar.
Push the lid down firmly on the front corners with the palm of your
hands, then push the locks in on the sides of the unit with your
fingers.
Press the seal button.
1
2
3
4
Page 11
www.VacMasterFresh.com | 800-821-7849
12
Troubleshooting
PRO275 will not turn on -
Make sure the machine is properly plugged into a grounded outlet.
Check the power cord for tears and frays. Do not use this machine if
the power cord is damaged.
Make sure the power switch is turned on. The LED screen will be
illuminated when on.
Vacuum pouch loses vacuum after being sealed -
Sharp items can poke small holes in pouches. To prevent this, cover
sharp edges with a paper towel or VacMaster® Bone Guard and
vacuum in a new pouch.
Some fruits and vegetables can release gases (out-gassing) if not
properly blanched or frozen before packaging. Open the pouch. If you
think food spoilage has begun, discard the food. If food spoilage has
not yet begun, consume immediately. If in doubt, discard the food.
PRO275 is not sealing pouch properly -
The seal time may not be long enough. Increase the seal time and
try again.
Pouches will not seal if any moisture, food particles or debris are
present in the seal area. Wipe the inside of the pouch clean and
try again.
Pouches must be properly placed along the seal bar. Make sure
the entire pouch is over the seal bar and there are no wrinkles in
the pouch material and half way across the trough.
1
2
3
1
2
1
2
3
10
Page 12
www.VacMasterFresh.com | 800-821-7849
2
Important SafeguardsLimited Warranty
ARY, Inc., a distributor and manufacturer of vacuum packaging and other machines
(collectively, the “Goods”), extends to the purchaser of the Goods a Limited One
Year Warranty, from the receipt of the Goods, under terms and conditions set out
herein.
All Goods sold by ARY, Inc. are warranted to be free from defects in material
and workmanship at the time of delivery to purchaser. Defective material may be
returned to ARY, Inc. after inspection by an agent of ARY, Inc. and upon receipt
from ARY, Inc. of shipping instructions specific to the defective Goods authorized
by ARY, Inc. to be returned. ARY, Inc. at its sole option, may either (i) replace or
repair any defective materials and workmanship (and return the Goods to purchaser
without charge), (ii) refund the purchase price, or (iii) grant a reasonable allowance
with the foregoing procedure.
This warranty is subject to the following limitations:
ARY, Inc.’s responsibility and the purchaser’s exclusive remedy under this
warranty is limited to the repair or replacement of defects in material and
workmanship, refund of the purchase price, or grant of a reasonable allowance
on account of such defects, all as set forth above. ARY, Inc. is not responsible
for any consequential damages resulting from the breach of this or any other
express or implied warranty with respect to the Goods.
This express warranty is the only warranty applicable. It excludes all other
express oral or written warranties and all warranties implied by law with respect
to the Goods, including any warranties or merchantability or fitness for a
particular purpose.
Every claim under this warranty shall be deemed waived by purchaser unless
made in writing within one (1) year of the receipt of the Goods to which such
claim relates.
This warranty, as to the Goods, is void (a) to repairs made by anyone other
than ARY, Inc. without prior authorization from ARY, Inc., (b) to performance
of any system of which ARY, Inc.’s Goods are a component part, (c) to
deterioration by corrosion or any cause of failure other than defect of material
or workmanship, (d) to any components of the Goods, including, without
limitation, Teflon tape, lid gaskets and seal wire, or (e) if any of the Good or
parts thereof have been tampered with or altered by someone other than ARY,
Inc., or subjected to misuse, neglect, abuse, or misuse in application.
ARY, Inc.’s maximum liability hereunder, arising from any cause whatsoever, whether
based in contract, tort (including negligence), strict liability, or any other theory
of law, shall not exceed the purchase price. A suit based on any aforementioned
cause of action must be commenced within one year from the date said action
accrues.
I
II
III
IV
12
11
Page 13
www.VacMasterFresh.com | 800-821-7849
3
Vacuum Packaging Tips
All Rights Reserved. VACMASTER® and VacStrip® are trademarks or registered trademarks
of ARY, Inc. in the United States and other countries.
ARY, Inc.
5200 W. 110th Street
Overland Park, KS 66211
www.VacMasterFresh.com
800-821-7849
v.2016-10.21
Loading...
