CHAPTER 1

BEFORE USING YOUR PHONE

CHAPTER 1

BEFORE

USING

YOUR PHONE

This chapter provides important information about your

UTStarcom handset including:

Package Contents

Handset Description

Battery Usage

Blocking Antenna while Making a Call

Battery Handling Information

PACKAGE CONTENTS

HANDSET DESCRIPTION

This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.

Handset Standard Battery

Manual AC Charger

Your CDM7176M weighs 0.0 ounces. The dimensions are X.X” x X.X” x X.X”.

Earpiece

Color STN Display

Navigation and OK Key

Left Soft Key

Speakerphone Key

SEND Key

Ear Jack

Volume Keys

VR Key

Right Soft Key Bluetooth Key END/Power Key

Clear Key

Microphone

USB Jack

Side Camera Key

HANDSET DESCRIPTION

THE FUNCTION KEYS

NAVIGATION KEY In Idle Mode:

MetroWEB and for Scheduler.

Within a Menu:

select a function displayed on the screen.

Send Key

Press to terminate a call or to return to idle mode. Press and hold to turn the phone on/off.

End Key

Press to terminate a call or to return to idle mode. Press and hold to turn the phone on/off.

Left Soft Key

Press to access Main Menu or function displayed on bottom line.

Right Soft Key

Press to access the Message Menu @metro or function displayed on bottom line.

CLR Key

Press to clear a digit or press and hold to clear all digits from the display. Press to return to the previous page.

Shift Key

Enters the asterisk [*] character for calling features. In text entry mode, press to change the character input type. Press and hold to turn on/off Vibrate mode.

Space Key

In text entry mode, press to accept the word and add a space. Press and hold to lock/unlock the phone.

Press for Contacts, for Messages, for

Within a menu, use to scroll through menu or to

0 Key

In T9 Mode, press to see other word choices.

Speakerphone Key

In idle mode, press to access the Voice Commands Main Menu. In calling mode, press to turn speakerpone On or Off.

Bluetooth Key

Press to access the Bluetooth Main Menu.

Side Volume Key

Allows you to adjust the ringer volume in standby mode or adjust the voice volume during a call. The volume key can also be used to scroll up or down to navigate through the different menu options. Press to ignore an incoming call and mute the ringer.

DISPLAY INDICATORS

The idle mode display appears when you are not on a call or using the menu. You must be in idle mode to dial a phone number.

Display Indicators

Display various icons.

Text & Graphic Area

Soft Key Indicators

Shows the functions currently assigned to each Option Button and displays some icons.

Signal Strength

Current signal strength: the more lines, the stronger the signal.

Roaming

Phone is out of home area.

HANDSET DESCRIPTION

No service

Indicates the phone cannot receive a signal from the system.

TTY mode

Indicates your phone is active in TTY mode.

GPS icon

Indicates the Location Service of your phone is disabled/enabled.

Battery

Battery charging level — the more blocks, the stronger the charge.

Battery charging

Indicates the battery is charging.

Roaming call

Blinks when an roaming call is in progress.

Emergency call

Blinks when an emergency call is in progress.

Vibrate

Phone will vibrate to notify you of an incoming call.

Ringer off

Indicates the ringer volume is set to off.

Silence all

Phone is set to Silent - no sound will be made to notify you of incoming calls or messages.

Level 5 or 1 & vibrate

Phone is set to ring and vibrate.

New text message

Indicates you have new text messages.

New voice messages

Indicates you have both text and voicemail messages.

Data service

Downloading is in progress.

1x mode

Phone is in the 1x service area.

Digital mode

Phone is in the digital service area.

Bluetooth connected

Indicates Bluetooth Connected.

Bluetooth on

Indicates Bluetooth mode.

Airplane mode

Transmitting and receiving information is restricted.

Data securtiy

Appears when the phone is accesing a secure Web Site.

Voice privacy

Indicates Voice Privacy mode.

Alarm & Schedule

Appears when either a calendar or an alarm is set.

Lock

Indicates your phone is locked.

1110

BATTERY USAGE

BATTERY INSTALLATION

Place the battery (label side up) on the back of the phone so the metal contacts match up on the battery and in the battery cavity.

Slide the battery down into the battery cavity until it locks into

place.

BATTERY REMOVAL

Push down the release latch button, then slide the battery cover off the phone.

Lift the battery up and out of the battery cavity from the top of the

battery.

If the battery is not correctly placed in the compartment, the handset

Note

will not turn on and/or the battery may detach during use.

1312

BATTERY USAGE

BLOCKING ANTENNA WHILE

MAKING A CALL

BATTERY CHARGING

POWER CONNECTION

Plug the AC Charger into a standard outlet.

Plug the other end of the AC Charger into the charging port on

your the right side of your phone. The battery must be installed onto the phone to work properly.

• When you charge the battery with the phone powered off, you

Hot Key

will see a charging status screen. You cannot operate the phone until it is powered on.

• The battery is not charged at the time of purchase.

• Fully charge the battery before use.

• It is more efficient to charge the battery with the handset powered off.

• The battery must be connected to the phone in order to charge it.

• Battery operating time gradually decreases over time.

• If the battery fails to perform normally, you may need to replace the battery.

CORRECT/INCORRECT FINGER POSITION

CORRECT FINGER POSITION INCORRECT FINGER POSITION

Your phone is equipped with an intenna. For optimal call quality, hold

Note

the phone by the gripped edges on the side and avoid touching the top and bottom of the phone.

1514

BATTERY HANDLING INFORMATION

DO’S

• Only use the battery and charger approved by the manufacturer.

• Only use the battery for its original purpose.

• Try to keep batteries in a temperature between 41ºF (5ºC ) and 95ºF

(35ºC).

• If the battery is stored in temperatures above or below the

recommended range, give it time to warm up or cool down before using.

• Completely drain the battery before recharging. It may take one to

four days to completely drain.

• Store the discharged battery in a cool, dark, and dry place.

• Purchase a new battery when its operating time gradually decreases

after fully charging.

• Properly dispose of the battery according to local laws.

DON’TS

• Don’t attempt to disassemble the battery – it is a sealed unit with no

serviceable parts.

• Don’t accidentally short circuit the battery by carrying it in your pocket

or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery.

• Don’t leave the battery in hot or cold temps. Otherwise, it could

significantly reduce the capacity and lifetime of the battery.

• Don’t dispose of the battery into a fire.

CHAPTER 2

BASIC OPERATION

CHAPTER 2

BASIC

OPERATION

This chapter addresses and explains the basic features of your

phone including:

Turning the Phone On/Off

Accessing the Menu

Menu Summary Basic Functions

During a Call

Making an Emergency Call

1716

TURNING THE PHONE ON / OFF

ACCESSING THE MENU

TURNING THE PHONE ON

Press and hold the End Key until your “metroPCS” logo appears and the tone sounds.

• If “Password” appears on the display enter your 4-digit password to

Note

unlock your phone.

• The default password is the last 4 digits of your phone number.

TURNING THE PHONE OFF

Press and hold the End Key until tone sounds.

• Immediately change or recharge the battery when “LOW BATTERY!!

Note

PHONE IS TURNING OFF!”appears on the display. Memory may possibly be damaged if the phone turns off due to the battery completely draining.

• Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may be lost.

Your phone can be customized via the menu. Each function can be accessed by scrolling with the Navigation Key number that corresponds with the menu item.

To access the menu in the idle mode, press Left Soft Key [Menu].

Press the Navigation Key left or right to scroll through the

menu items. Press the Navigation Key

submenus for each menu item.

To return to the previous page, press . To exit the current

menu and return to the idle mode, press the End Key

Press to enter a function when its main page is displayed or

press its assigned number to have direct access to the function.

up or down to scroll through the

Contacts

Messaging

or by pressing the

SchedulerMetro Web

1918

MENU SUMMARY

1. Messages

1.1. Send text msg

1.2. Inbox

1.3. Web alerts

1.4. Voicemail

1.4.1. Call voicemail

1.4.2. Last voicemail detail

1.4.3. Clear voicemail icon

1.5. Saved

1.6. Sent

1.7. Erase msgs

1.8. Msg settings

1.8.1. Sound

1.8.2. Reminder

1.8.3. Auto text

1.8.4. Text entry

1.8.5. Signature

1.8.6. Save to sent folder

1.8.7. Auto erase

1.8.8. Notification

1.8.9. Callback #

1.8.0. Delivery settings

2. Contacts

2.1. Find name

2.2. Add new

2.3. Group settings

2.3.1. Unassigned

2.3.2. Personal

2.3.3. Family

2.3.4. Business

2.4. Speed dial

2.5. My phone number

3. Recent Calls

3.1. All calls

3.2. Missed calls

3.3. Incoming calls

3.4. Outgoing calls

3.5. Call timer

4. @metro

4.1. @metro

5. MetroWEB

5.1. Connect to Web

6. Bluetooth

6.1. My device

6.2. Settings

6.3. Support service

6.4. Information

7. My Stuff

7.1. My images

7.2. My tuness

8. Tools

8.1. Voice

8.1.1. Voice memo

8.1.2. Voice commands

8.1.2.1. Call

8.1.2.2. Digit dial

8.1.2.3. Voicemail

8.1.2.4. My phone #

8.1.2.5. Status

8.1.2.6. Help

8.2. Tip calculator

8.3. Calculator

8.4. Alarm clock

8.4.1. Alarm #1

8.4.2. Alarm #2

8.4.3. Alarm #3

8.5. Scheduler

8.6. Notepad

8.7. Stopwatch

8.8. World clock

8.9. Airplane mode

8.0. Memory manager

9. Settings

9.1. Sound

9.1.1. Ringer type

9.1.1.1. With caller ID

9.1.1.2. No caller ID

9.1.1.3. Roam ringer

9.1.2. Volume

9.1.2.1. Ringer

9.1.2.2. Receiver

9.1.2.3. Speakerphone

9.1.2.4. Headset

9.1.2.5. Key tone

9.1.2.6. Applications

9.1.2.7. Others

9.1.3. Alerts

9.1.3.1. Minute minder

9.1.3.2. Connect tone

9.1.3.3. Service tone

9.1.3.4. Fade tone

9.2. Display

9.2.1. Graphics

9.2.1.1. Wallpaper

9.2.1.2. Clock and calendar

9.2.1.3. Screensaver

9.2.2. Incoming calls

9.2.2.1. My graphics

9.2.2.2. My images

9.2.3. Menu style

9.2.4. Greeting

9.2.5. Backlight

9.2.5.1. Display

9.2.5.2. Keypad

9.2.6. Service lamp

9.3. Messaging

9.3.1. Sound

9.3.2. Reminder

9.3.3. Auto text

9.3.4. Text entry

9.3.5. Signature

9.3.6. Save to sent folder

9.3.7. Auto erase

9.3.8. Notification

9.3.9. Callback #

9.3.0. Delivery settings

9.4. Security

9.4.1. Headset lock

9.4.2. Special number

9.4.3. Change lock code

9.4.4. Erase data

9.4.4.1. Erase contacts

9.4.4.2. Erase downloads

9.4.4.3. Erase voice memo

2120

MENU SUMMARY

BASIC FUNCTIONS

9.4.4.4. Erase message

9.4.5. Reset browser

9.4.6. Default settings

9.4.7. Reset handset

9.5. Location

9.6. Call settings

9.6.1. Answer mode

9.6.2. Auto answer

9.6.3. Voice privacy

9.7. Others

9.7.1. Language

9.7.2. TTY

9.7.3. Abbrev. dial

9.7.4. Contacts match

9.7.5. Typing mode

9.7.5.1. Auto capital

9.7.5.2. Auto space

9.7.5.3. My words

9.7.5.4. T9 settings

9.7.5.5. Help

9.7.6. Voice commands

9.7.6.1. VR results

9.7.6.2. Voice calibration

9.7.6.3. Prompts

9.7.6.4. Number format

9.8. Roaming

9.9. Phone info

9.9.1. My mobile number

9.9.2. Version

9.9.3. Icon glossary

9.9.4. Advanced

MAKING A CALL

Enter a phone number.

To modify the phone number you have entered:

Note

• To erase one digit at a time press .

• To erase the entire number, press and hold

Press the Send Key .

• If “CALL FAILED” appears on the display or the line is busy, press the

Note

To end a call, press the End Key .

Send Key

• When you place or receive a call from stored phone numbers, only the name will be displayed.

• If “Enter Lock Code” appears on the display enter your 4-digit password to unlock your phone.

• Your default password is the last 4 digits of your phone number.

or the End Key .

ANSWERING CALLS

When your phone rings or vibrates, press the Send Key to answer the incoming call. (Depending on your phone’s settings, you may also answer incoming calls by opening the phone or by pressing any digit key. See page 73 for details.)

To ignore incoming calls, press Right Soft Key [Ignore].

To end a call, press the End Key .

In Auto Answer Mode, a call is automatically answered after five

Note

seconds of ring tones.

2322

BASIC FUNCTIONS

SPEAKERPHONE

The speakerphone feature lets you hear audio through the speaker and talk without holding the phone.

To activate the speakerphone while answering or calling modes, press the Speakerphone Key

The phone returns to normal (Speakerphone Off) after ending a call

or when the phone is turned off and back on.

WAIT/PAUSE FEATURE

Pauses are used for automated systems (i.e., Voicemail, calling cards). Insert a pause after a phone number then enter another group of numbers. The second set of numbers is dialed automatically after the pause. This feature is useful for dialing into systems that require a code.

To insert a wait/pause, enter a phone number then press Right Soft

[Options]. Select either a Type “P“(“P” appears) or a Type

Key “T“ (“T” appears).

Press the Send Key to dial, or press Left Soft Key [Save]

to save the number.

3-WAY CALLING

With 3-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be applied for each of the two calls.

BASIC FUNCTIONS

Once you have established the connection, enter the second number

you wish to call then press the Send Key

When you’re connected to the second party, press the Send Key

again to begin your 3-Way call.

CALLER ID FUNCTION

Identifies caller by displaying their phone number. If the caller’s name and number are already stored in your phone book, their name will appear. This is a system dependent feature. Please contact your service provider for details.

CALL WAITING FUNCTION

Notifies you of an incoming call when you are already on a call by sounding a beep tone and displaying the caller’s phone number.

To answer another call while on the phone, press the Send Key

. This places the first call on hold. To switch back to the first

caller, pressthe Send Key

Call Waiting is a system dependent feature. Please contact your service

Note

provider for details.

again.

Enter a number you wish to call then press the Send Key .

2524

BASIC FUNCTIONS

DURING A CALL

ADJUSTING VOLUME

Adjusts the volume of the ringer, key beep and earpiece.

In idle mode, press the Side Volume Key up or down. Choose from Silence All, Vibrate All or Level 1 ~ Level 5. You can also choose to have the phone vibrate as well when the the phone rings. Press to check the box on/off for Always vibrate.

Press the Left Soft Key [Save] to save the setting.

MUTE (UNMUTE)

If you press Mute during a call, the person you are speaking with cannot hear you or any sounds from your side of the conversation. However, you can still hear them. To activate Mute during a call, press Left Soft

[Mute].

Key

• To deactivate, press the Left Soft Key [Unmute].

• The phone will automatically unmute in Emergency Call or Callback Mode.

3-WAY CALLS

To call a second party during a call, dial the number or select it from the directory by accessing the menu during a call.

Press Right Soft Key [Options], then press .

VOICE PRIVACY

Increases security during a call.

Press Right Soft Key [Options], then press .

VOICE MEMO

To record a voice memo during a call:

Press Right Soft Key [Options], then press .

2726

DURING A CALL

MAKING AN EMERGENCY CALL

CALL HISTORY

Displays call information:

Press Right Soft Key [Options], then press .

FIND NAME

To select the phone number in your internal Contact List:

Press Right Soft Key [Options], then press .

MESSAGING

To send a text message during a call:

Press Right Soft Key [Options], then press .

BLUETOOTH

To connect to a Bluetooth-enabled device, such as a wireless headset (sold separately):

Press Right Soft Key [Options], then press .

The 911 feature puts the phone in the Emergency Call Mode when you dial the preprogrammed emergency number 911. It also operates in Lock Mode and outside the service area.

911 IN LOCK MODE

The 911 call service is available even in Lock Mode.

Enter “911”, then press the Send Key .

The call connects.

When the call ends, the phone returns to Lock Mode.

911 USING ANY AVAILABLE SYSTEM

Enter “911”, then press the Send Key .

The call connects.

The phone maintains Emergency Mode and the phone can receive

an incoming call from any available system. However, it can’t make a call.

The 911 call does not appear in the recent call list.

Note

2928

MEMO

CHAPTER 3

MEMORY FUNCTION

CHAPTER 3

MEMORY

FUNCTION

This chapter addresses memory functions including:

Storing a Phone Number

Entering Letters, Numbers & Symbols

Making a Call Through the Contact List

Contacts

3130

STORING A PHONE NUMBER

The phone book stores up to 500 entries.

Enter the phone number, press Left Soft Key [Save].

Select “New entry“ or “Existing entry“. If “Existing entry” is

selected, your contact list is displayed. Choose the entry to add the number, then press Left Soft Key

[Done]. Select the type of

number you are adding from the icon list, then press Left Soft Key

[Select]. Press Left Soft Key [Save]. Press the Navigation

up or down to select primary phone number, then press Left

Key Soft Key

If “New entry“ is selected, the New entry icon list appears. Press

the Navigation Key you are adding. Press Left Soft Key a name. To change the input mode, press Right Soft Key [Options]. Press the Navigation Key

[Select] to save contact.

up or down to choose the type of number

[Select] to select. Enter

down to enter information in other fields for the contact. Fields include “Name”, “Mobile”, “Phone number”, “Email Address”, “URL”, “Group”, “Ringtone”, “Vibration”, “Msg alert”, “Secret”, “Memo”.

• Group:

To set a group for the contact, highlight the Group Name. Press

the Navigation Key Family or Business.

• Ringtone:

•

To set a ringtone for the contact, highlight a Ringtone. Select Preloaded ringtones or My tunes. Press the Navigation Key up or down to select Use phone ring, Ringer 1, Ringer 2, Ringer 3, Ringer 4, Alert tone 1, Alert tone 2, Alert tone 3 or My tunes.

Vibration:

To set a vibration for the contact, highlight the Vibration. Press the Navigation Key vib. or Vibration 1 ~ Vibration 6.

left or right to select Unassigned, Personal,

left or right to select Use phone

•

Msg alert:

To set a msg alert for the contact, highlight the Msg alert. Select

Preloaded ringtones or My tunes. Press the Navigation Key up or down to select Use phone alert, Ringer 1, Ringer 2, Ringer

• Secret:

• Memo:

To store the entry in your contact list, press Left Soft Key [Save]

3, Ringer 4, Alert tone 1, Alert tone 2, Alert tone 3 or My tunes. To set a secret for the contact, highlight a Secret. Press the Navigation Key To add a memo for a contact, highlight the memo field and press

. The Memo screen will appear. Enter your Memo and press Left

Soft Key

left or right to select Lock or Unlock.

[OK].

to save contact.

3332

ENTERING LETTERS, NUMBERS & SYMBOLS

ENTERING LETTERS,

NUMBERS & SYMBOLS

The input mode will automatically be activated when it is necessary to enter letters and numbers. There are 5 available modes: Alphabet mode (Abc/ABC), Numeric mode (123), Standard T9 Mode (T9 Word), Symbol mode (Symbols), Smileys mode (Smileys) and Emoticon mode (Emoticon). The input mode indicator appears on the lower portion of the display when letters and numbers are entered.

KEY

To change the entry mode - [T9 Word] [Abc] [ABC] [123] [Symbols] [Emoticon] [Smileys]

In T9 mode, press to view the next matching word if the highlighted word is not the word you intended.

Press to accept a word and add a space.

KEY

Press to delete a character to the left of the cursor.

Press to select the letter case: [Abc], [ABC], [abc] / [T9w], [T9W], [t9w].

STANDARD INPUT MODE

Use the digit keys to enter letters, numbers and characters.

Enter letters using the keypad. To change the input mode, press Right Soft Key

To enter a space, press . The cursor will automatically move to

the next column.

Repeat until letters are entered.

To delete one letter, press .

To delete the entire entry, press and hold

E.G.

Select Abc mode by pressing the Right Soft Key [Options], then Abc. When you select this mode, the Abc icon appears as a visual confirmation.

- Find the key that corresponds to the letter you want to enter.

- Press it as many times as needed for the letter to appear on the

- To enter the name “John”: Press [ Press [ Press [ Press [

[Options]. Select “Abc”.

screen.

] J , , ] o , ] h , ] n

3534

ENTERING LETTERS, NUMBERS & SYMBOLS

ENTERING LETTERS,

NUMBERS & SYMBOLS

T9 INPUT MODE

T9 mode incorporates a built-in-dictionary to determine a word based on the entered characters. A word can be entered more quickly by pressing each key once per character.

Press Right Soft Key [Options], then select “T9 Word”.

Press a digit key once to enter the character you want then enter all

the characters to input the word you want.

To view the next matching word, press .

To accept the matching word then enter a space, press .

To enter a compound word:

Note

• Enter the first part of the word then press the Navigation Key right to accept it without adding a space after it.

• Enter the last part of the word then press to accept the word.

To enter “Funfare” in T9 mode:

E.G.

- Press Right Soft Key [Options] to select T9 mode.

- Press , , until you see “Fun” highlighted.

- Press the Navigation Key

, , , and you will see “ease” highlighted.

- Press

Press until you see “fare” highlighted. Press to select and add a space.

right to select “Fun”.

NUMERIC MODE

Allows you to enter numbers.

Press Right Soft Key [Options], then select “123”.

To enter a number, press its corresponding digit key.

SYMBOL MODE

Allows you to enter symbols.

Press Right Soft Key [Options], then select “Symbols.”

Select the symbol you want to enter by pressing the Navigation Key

up, down, left or right, then press Left Soft Key [Done].

EMOTICON MODE

Allows you to enter Emoticon.

Press Right Soft Key [Options], then select “Emoticon”.

Select the Emoticon you want to enter by pressing the Navigation

up, down, left or right, then press Left Soft Key [Done].

Key

SMILEYS MODE

Allows you to enter Smileys Icon.

Press Right Soft Key [Options], then select “Smileys”.

Select the Smileys Icon you want to enter by pressing the

Navigation Key

[OK].

up, down, left or right, then press Left Soft Key

3736

MAKING A CALL THROUGH THE CONTACT LIST

CONTACTS

ONE-TOUCH/TWO-TOUCH DIALING

Ideal for frequently dialed numbers, this feature allows entries in your contact list to be dialed via the keypad with only one or two key presses. In order for One-Touch/Two-Touch Dialing to properly work, it must be enabled.

ONE-TOUCH DIALING

2-9: Press and hold the corresponding memory number for more than 1

second.

TWO-TOUCH DIALING

10-99: Press the first digit and second digits of the memory number

short and long respectively.

• If no phone number is stored in the location entered, “Speed dial is

Note

empty” will appear on the screen.

• If One Touch Dial is set to Off: Enter the speed dial location number then press the Send Key

• Location 1 is reserved for voicemail. Location 2-99 are unassigned. To assign a speed dial location, please see page 45.

Stores up to 500 entries, each of which can be assigned to a group. Entries can be retrieved by name or group.

FIND NAME

Retrieves an entry by name and calls the primary number by simply pressing the Send Key your contacts list or quickly find an entry by entering a name or its character string.

Press Left Soft Key [Menu], then press “Contacts”, then

“Find name“. Or, in idle mode, press the Navigation Key

up, then

The list of names in your contacts is displayed alphabetically.

Enter a name or scroll through the list. If more than one contact is

listed, highlight the contact you want.

To select the contact, highlight it and press . The contact

information is displayed.

To edit the contact information, press Left Soft Key [Edit].

The Edit Contact screen will appear with the selected contact information shown. See page 32 for Storing a Phone Number.

To save the entry, press Left Soft Key [Save]. To return to the

previous page, press

Highlight a field in the contact and press Right Soft Key

[Options] for various functions for the fields.

“Find name“.

. You can review all the entries stored in

3938

CONTACTS

• Send Msg:

• Prepend:

• Edit:

• Assign speed dial:

• Erase:

To call the selected number, press the Send Key .

Send a message to the contact.

Adds numbers to the beginning of the phone number.

To edit the selected entry.

To assign speed dial the selected entry.

To erase the selected entry.

ADD NEW

Adds a new entry.

Press Left Soft Key [Menu], then press “Contacts”, then

“Add new“. Or, in idle mode, press the Navigation Key up,

then “Add new“.

Fill in the fields as they are selected. Press the Navigation Key

up or down to select a field.

PHONE BOOK FIELDS:

To save the entry, press Left Soft Key [Save]. To return to the

previous page, press

See page 32 for more detailed information about storing a number.

Note

Name/Mobile/Email address/URL/Group/Ringtone/ Vibration/Msg alert/Secret/Memo

GROUP SETTINGS

Allows you to classify phone entries into groups. Existing groups include Unassigned, Personal, Family, Business. A maximum of 30 groups is allowed.

ADD NEW GROUP

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Press Left Soft Key [Add] to add a new group name.

Input a new group name.

Press Left Soft Key [OK] to save a new group.

CHANGE GROUP NAME

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Select the group you want to rename. Only new groups you added

can be changed. The default groups Personal, Family and Business cannot be renamed.

Press Right Soft Key [Options], then scroll to “Rename“ and

press .

Input a new group name.

Press Left Soft Key [OK] to change the name.

4140

CONTACTS

SETTING A RINGER TYPE FOR A GROUP

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Select an existing group name.

Press Right Soft Key [Options], then scroll to “Ringtone“

and press . Select Preloaded ringtones or My tunes. Press the Navigation Key Ringer 2, Ringer 3, Ringer 4, Alert tone 1, Alert tone 2, Alert tone 3 or My tunes.

Press Right Soft Key [Play] to play ringtone. Select ringtone and

press Left Soft Key

up or down to select Use phone ring, Ringer 1,

[Select].

SETTING A VIBRATION TYPE FOR A GROUP

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Select an existing group name.

Press Right Soft Key [Options], then scroll to “Vibration“ and

press . Press the Navigation Key up or down to select Use phone vib. or Vibration 1 ~ Vibration 6.

Press Right Soft Key [Play] to play ringtone. Select ringtone and

press Left Soft Key

[Select].

ADD PHONE NUMBER TO GROUP

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Select an existing group name.

Press Right Soft Key [Options], then scroll to “Add member“

and press . Your contact entries appear in alphabetical order. Select the contact you want to add by pressing the Navigation Key

up or down, then press to check or uncheck.

Press Left Soft Key [Done]. “DONE” will be displayed. Repeat

for each location for the Group.

REMOVE PHONE NUMBER TO GROUP

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Select an existing group name.

Press Right Soft Key [Options], then scroll to “Remove

member“ and press Select the contact you want to remove by pressing the Navigation

up or down, then press to check or uncheck.

Key

Press Left Soft Key [Done]. “REMOVE” will be displayed.

Repeat for each location for the Group.

. Group entries appear in alphabetical order.

4342

CONTACTS

REMOVE ALL PHONE NUMBER TO GROUP

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Select an existing group name.

Press Right Soft Key [Options], then scroll to “Remove all“ and

press .

“Remove all?” will be displayed. Select “Yes” and press to

remove all phone number to group.

ERASE GROUP

Press Left Soft Key [Menu], then press “Contacts”, then press “Group settings“. Or, in idle mode, press the Navigation

up, then “Group settings“.

Key

Select an existing group name. Only new groups you added can be

changed. The default groups Personal, Family and Business cannot be deleted.

Press Right Soft Key [Options], then scroll to “Erase” and press

“Erase?” will be displayed. Select “Yes” and press to erase the

group.

SPEED DIALS

In idle mode, calls can be placed to numbers stored in Speed Dial by pressing & holding the location number on the key pad. For a 2-digit location number, press the first number, then press and hold the second number.

Speed Dial must be activated.

Note

Press Left Soft Key [Menu], then press “Contacts”, then

“Speed dial“, Or, in idle mode, press the Navigation Key

up, then

To assign a phone number to a location, select the location then

press Left Soft Key

Note

Select a name from your contact list. If the contact has more than 1

number saved, press the Navigation Key correct number for the Speed Dial location is shown.

Press Left Soft Key [Done] to save the number to the Speed

Dial location. You will see the contact name next to the Speed Dial location number in the Speed Dial lists.

“Speed dial“.

[Assign].

“empty” appears if the location is available.

up or down until the

4544

CONTACTS

MY PHONE NUMBER

Displays your phone number.

Press Left Soft Key [Menu], then press “Contacts”, then press “My phone number”. Or, in idle mode, press the Navigation Key

Your phone number will be displayed.

To return to the previous page, press [Close].

up, then “My phone number”.

CHAPTER 4

MENU FUNCTION

CHAPTER 4

MENU FUNCTION

This chapter addresses accessing the menu and using its

functions and features to customize your phone.

Recent Calls

Settings

4746

+ 53 hidden pages

UTStarcom Korea Technologies CDM7176 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
