CDM7076
Users Manual
174 pgs3.07 Mb0

UTStarcom Korea Technologies CDM7076 Users Manual

TABLE OF CONTENTS
CHAPTER 1. BEFORE USING YOUR PHONE
PACKAGE INCLUDES ............................................................................................. 6
HANDSET DESCRIPTION ........................................................................................7
BATTERY USAGE .................................................................................................12
POWER CONNECTION ........................................................................................................ 14
BATTERY HANDLING INFORMATION...................................................................15
DON’Ts ............................................................................................................................... 15
CHAPTER 2. BASIC OPERATION
TURNING THE PHONE ON / OFF ..........................................................................18
TURNING THE PHONE ON ..................................................................................................18
TURNING THE PHONE OFF .................................................................................................18
ACCESSING THE MENU .......................................................................................19
MENU SUMMARY ............................................................................................... 20
BASIC FUNCTIONS .............................................................................................. 22
MAKING A CALL ................................................................................................................ 22
ANSWERING CALLS ............................................................................................................ 23
WAIT/PAUSE FEATURE........................................................................................................ 23
3-WAY CALLING ................................................................................................................. 24
CALLER ID FUNCTION ........................................................................................................ 24
CALL WAITING FUNCTION ................................................................................................. 25
ADJUSTING VOLUME .......................................................................................................... 25
SPEAKERPHONE ................................................................................................................. 26
DURING A CALL .................................................................................................. 27
MUTE (UNMUTE) ...............................................................................................................27
SEND TXT MSG .................................................................................................................. 27
CONTACTS ......................................................................................................................... 27
RECENT CALLS ................................................................................................................... 27
NOTEPAD ........................................................................................................................... 28
MAKING AN EMERGENCY CALL ......................................................................... 29
911 IN LOCK MODE ........................................................................................................... 29
1
TABLE OF CONTENTS
911 USING ANY AVAILABLE SYSTEM ................................................................................. 29
CHAPTER 3. MEMORY FUNCTION
STORING A PHONE NUMBER .............................................................................. 32
ENTERING LETTERS, NUMBERS & SYMBOLS .......................................................34
STANDARD INPUT MODE ................................................................................................... 35
T9WORD INPUT MODE....................................................................................................... 36
NUMERIC MODE ................................................................................................................37
SYMBOL MODE .................................................................................................................. 37
MAKING A CALL THROUGH THE CONTACT LIST ..................................................38
ONE-TOUCH/TWO-TOUCH DIALING ................................................................................... 38
CHAPTER 4. MENU FUNCTION
CONTACTS ..........................................................................................................42
NEW CONTACT .................................................................................................................. 42
CONTACT LIST .................................................................................................................... 43
GROUPS ............................................................................................................................. 44
SPEED DIALS ...................................................................................................................... 48
IN CASE OF EMERGENCY ................................................................................................... 49
RECENT CALLS .................................................................................................... 53
MISSED .............................................................................................................................. 53
RECEIVED ........................................................................................................................... 54
DIALED ............................................................................................................................... 55
VIEW TIMERS ..................................................................................................................... 57
SETTINGS ............................................................................................................ 58
SOUND SETTINGS ..............................................................................................................58
DISPLAY SETTINGS ............................................................................................................. 65
PHONE SETTINGS ............................................................................................................... 70
CALL SETTINGS .................................................................................................................. 78
MEMORY ........................................................................................................................... 81
PHONE INFO ...................................................................................................................... 83
2
TABLE OF CONTENTS
MY VERIZON .......................................................................................................85
MY VERIZON ...................................................................................................................... 85
CHAPTER 5. TOOLS
TOOLS ................................................................................................................. 88
VOICE COMMAND ............................................................................................................. 88
CALCULATOR ..................................................................................................................... 90
CALENDAR ......................................................................................................................... 91
ALARM CLOCK ................................................................................................................... 93
STOPWATCH....................................................................................................................... 94
WORLD CLOCK ................................................................................................................... 95
NOTEPAD ........................................................................................................................... 95
CHAPTER 6. MEDIA CENTER
MEDIA CENTER ................................................................................................... 98
TUNES & TONES ................................................................................................................. 98
PICTURES ......................................................................................................................... 101
GAMES ............................................................................................................................. 105
MOBILE WEB .................................................................................................................... 106
BROWSE & DOWNLOAD .................................................................................................. 106
EXTRAS ............................................................................................................................ 107
CHAPTER 7. MESSAGING
MESSAGING ...................................................................................................... 110
NEW MESSAGE ................................................................................................................ 110
INBOX .............................................................................................................................. 113
SENT ................................................................................................................................ 114
DRAFTS ............................................................................................................................ 115
VOICEMAIL .......................................................................................................................116
MOBILE IM ....................................................................................................................... 117
EMAIL .............................................................................................................................. 117
CHAT ................................................................................................................................ 117
SETTINGS ......................................................................................................................... 118
3
TABLE OF CONTENTS
CHAPTER 8. MOBILE WEB
MOBILE WEB ..................................................................................................... 124
LAUNCHING MOBILE WEB 2.0 ......................................................................................... 124
BROWSER MENU ............................................................................................................. 124
CHAPTER 9 SAFETY AND WARRANTY
SAFETY .............................................................................................................. 130
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES .........................130
SAFETY INFORMATION FOR FCC RF EXPOSURE ............................................ 134
SAR INFORMATION ........................................................................................135
FDA CONSUMER UPDATE .............................................................................. 138
EMERGENCY CALLS ....................................................................................... 148
COMPLIANCE WITH OTHER FCC REGULATIONS ............................................. 151
GENERAL SAFETY ..........................................................................................152
ANTENNA .......................................................................................................153
BATTERY.........................................................................................................154
CHARGER ....................................................................................................... 156
FCC HEARING-AID COMPATIBILITY (HAC) REGULATIONS FOR WIRELESS
DEVICES ......................................................................................................... 157
GAMES ........................................................................................................... 160
CAMERA ........................................................................................................ 161
RECYCLE YOUR CELL PHONE! ........................................................................ 161
AVOID POTENTIAL HEARING LOSS .................................................................... 163
CAUTION: ....................................................................................................... 163
FCC COMPLIANCE INFORMATION .................................................................... 166
INFORMATION TO USER ................................................................................. 166
WARRANTY ....................................................................................................... 168
MANUFACTURER’S WARRANTY ..................................................................... 168
4
CHAPTER 1
BEFORE USING YOUR PHONE
CHAPTER 1
BEFORE
USING
YOUR PHONE
This chapter provides important information about
using your phone including:
PACKAGE INCLUDES
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
5
PACKAGE INCLUDES
This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.
Handset
User Manual
Standard Battery
AC Charger
6
HANDSET DESCRIPTION
Your CDM7076 weighs 3.5 ounces. The dimensions are
3.5“x1.9“x8.6“.
Camera Lens
Camera Lens
Main Menu/OK Key
Left Soft Key
Camera Key
SEND Key
Microphone
Charger jack
Volume Keys
DIRECTIONAL KEY
Right Soft Key Speakerphone Key
END/POWER Key
CLR Key
Antenna
Earjack
Side Camera Key
Voice Command Key
7
HANDSET DESCRIPTION (THE FUNCTION KEYS)
DIRECTIONAL KEY In Idle Mode:
Directional Key down SHORTCUTS
Within A Menu:
select a function displayed on the screen.
Send Key
Press to make or receive a call. In Idle Mode, press to access the All Calls list.
End Key
Press to terminate a call or to return to Idle Mode. Press and hold to turn the phone on/off.
Left Soft Key
Press to access the Message menu or function displayed on bottom line.
Right Soft Key
Press to access the Contacts menu or function displayed on bottom line.
CLR Key
Press to clear a digit from the display or to return to the previous page. Press and hold to clear all digits.
Speakerphone Key
Press and hold to turn speakerphone On/Off.
Camera Key
Press to access Camera Mode.
Shift Key
Enters the asterisk [*] character for calling features. In text entry mode, press to change the character input type. Press and hold to display a plus sign (+) for international dialing.
Space Key
Enters the pound [#] character for calling features. In text entry mode, press to accept the word and add a space.
Press
the Directional Key up for
and
Calendar, Directional Key right
Directional Key left
Use to scroll through menu options, or to
for
Mobile Web.
for Mobile Web,
for
MY
8
HANDSET DESCRIPTION
(DISPLAY INDICATORS)
Side Camera Key
Press to access Camera Mode.
Voice Command Key
In Idle Mode, press to access the Voice Command menu or to dial a phone number using your voice.
Side Volume Key
Allows you to adjust the master volume in idle mode (with the flip open) or adjust the earpice volume during a call. The volume Key can also be used to scroll up or down to navigate through the different menu options. To mute the ringer during an incoming call, press the volume Key up or down.
9
HANDSET DESCRIPTION (DISPLAY INDICATORS)
This display appears when you are not on a call or using the menu. You must be in Idle Mode display to dial a phone number.
Display Indicators
Display various icons.
Text & Graphic area
Soft Key Indicators
Shows the functions currently assigned to each soft key and displays some icons.
Signal Strength
Current signal strength: the more lines, the stronger the signal (1X Mode/Digital Mode).
Voice Call
Indicates call is in progress.
No Service
Indicates the phone cannot receive a signal from the system.
Roaming
Phone is out of home area.
Battery
Battery charging level — the more blocks, the stronger the charge.
Voicemail
Indicates you have voicemail messages.
New Messages
New TXT or PIX message.
Speakerphone
Phone is in speakerphone mode.
10
HANDSET DESCRIPTION
(DISPLAY INDICATORS)
GPS Icon
Indicates the Location Service of your phone is disabled/enabled.
TTY
Indicates your phone is in TTY mode.
Alarm Only
Phone will alert you with an alarm tone when call is received.
Alarm
The only audible alert you can hear is for an alarm. Will not ring for incoming call or other alerts.
Vibrate Only
Phone will vibrate to notify you of an incoming call.
Sounds Off
Indicates all sounds and alerts are set to off.
Dormant
Indicates your phone is in a dormant state during a data call. Your phone goes to Dormant mode when you have not had any activity on a page for some time - your connection is still active and you can make and receive calls.
Voice Privacy
Indicates Voice Privacy mode.
Standalone Mode
Wireless connectivity is turned off, but non-network functions can still be accessed.
11
BATTERY USAGE (BATTERY INSTALLATION)
1.
Place the battery (label side up) on the back of the phone so the metal contacts match up on the battery and in the battery cavity.
2.
Push the battery down into the battery cavity until it locks into place.
3.
Place the battery cover over the battery and slide up into place.
12
BATTERY USAGE
(BATTERY REMOVAL)
1.
Push down the release latch button, then slide the battery cover off the phone.
2.
Lift the battery up and out of the battery cavity from the top of the battery.
• If the battery is not correctly placed in the compartment,
Note
the handset will not turn on and/or the battery may detach during use.
13
BATTERY USAGE (BATTERY CHARGING)
POWER CONNECTION
1.
Plug the AC Charger into a standard outlet.
2.
Plug the other end of the AC Charger into the bottom of your phone. The battery must be installed onto the phone.
• When you charge the battery with the phone power off,
Hot Key
you will see a charging status screen. You cannot operate the phone until it is powered on.
• The battery is not charged at the time of purchase.
• Fully charge the battery before use.
• It is more efficient to charge the battery with the handset powered off.
• The battery must be connected to the phone in order to charge it.
• Battery operating time gradually decreases over time.
• If the battery fails to perform normally, you may need to replace the battery.
14
BATTERY HANDLING
INFORMATION
DO’s
l
Only use the battery approved for use with your phone.
l
Only use the battery for its original purpose.
l
Try to keep batteries in a temperature between 41ºF (5ºC ) and
95ºF (35ºC).
l
If the battery is stored in temperatures above or below the
recommended range, give it time to warm up or cool down before using.
l
Completely drain the battery before recharging. It may take one to four
days to completely drain.
l
Store the discharged battery in a cool, dark, and dry place.
l
Purchase a new battery when its operating time gradually decreases
after fully charging.
l
Properly dispose of the battery according to local laws.
DON’Ts
l
Don’t attempt to disassemble the battery – it is a sealed unit with no
serviceable parts.
l
Don’t accidentally short circuit the battery by carrying it in your pocket
or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery.
l
Don’t leave the battery in hot or cold temps. Otherwise, it could
significantly reduce the capacity and lifetime of the battery.
l
Don’t dispose of the battery into a fire.
15
MEMO
16
CHAPTER 2
BASIC OPERATION
CHAPTER 2
BASIC
OPERATION
This chapter addresses and explains the basic
features of your phone including:
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
17
TURNING THE PHONE ON / OFF
TURNING THE PHONE ON
1.
Press and hold the END Key until your “Power On” logo appears and the tone sounds.
• If “Phone Locked“ appears on the display, press Right
Note
Softkey [Unlocked] then enter your 4-digit lock code.
• The default lock code is the last 4 digits of your phone number.
TURNING THE PHONE OFF
1.
Press and hold the END Key until your “Power Off” logo
appears.
• Immediately change or recharge the battery when “LOW
Note
BATTERY!! PHONE IS TURNING OFF!” appears on the display. Memory may possibly be damaged if the phone turns off due to the battery completely draining.
• Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may be lost.
18
ACCESSING THE MENU
Your phone can be customized via the menu. Each function can be accessed by scrolling with the Directional Key or by pressing the number that corresponds with the menu item.
1.
To access the men u from Idle Mode, press the OK Key [MENU].
2.
Pressing the Directional Key up or down scrolls through the submenus for the menu item you are in. Pressing the Directional Key left or right enables you to scroll through the menu items.
3.
To return to the previous page, press the Clear Key . To exit the current menu and return to the idle mode, press the END Key .
4.
Press to enter a function when its main page is displayed or press its assigned number to have direct access to the function.
Mobile Web
Browse &
Download
Calendar
Please see page 71 for directions on how to change the
Note
function of the Set Shortcut.
MY SHORTCUTS
19
MENU SUMMARY
MEDIA CENTER
1.
Tunes & Tones
1.1. Get New Ringtones
1.2. My Ringtones
1.3. My Sounds
2.
Pictures
2.1. Get New Pictures
2.2. My Pictures
2.3. Take Picture
2.4. Online Album
3.
Games
4.
Mobile Web
5.
Browse & Download
6.
Extras
MESSAGING
1. New Message
1.1. TXT Message
1.2. Picture Message
1.3. Voice Message
2. Inbox
3. Sent
4. Drafts
5. Voicemail
6. Mobile IM
7. Email
8. Chat
CONTACTS
1.
New Contact
2.
Contact List
3.
Groups
4.
Speed Dials
5. In Case of Emergency
RECENT CALLS
1.
Missed
2.
Received
3.
Dialed
4.
All
5.
View Timers
SETTINGS & TOOLS
1. My Verizon
2. Tools
2.1. Voice Commands
2.2. Calculator
2.3. Calendar
2.4. Alarm Clock
2.5. Stop Watch
2.6. World Clock
2.7. Notepad
3. Sounds Settings
3.1. Call Sounds
3.1.1. Call Ringtone
3.1.2. Call Vibrate
3.2. Alert Sounds
3.2.1. TXT Message
3.2.2. Pic/Voice Message
3.2.3. Voicemail
3.2.4. Emergency Tone
3.3. Keypad Volume
3.4. Service Alerts
3.4.1. ERI
20
MENU SUMMARY
3.4.2. Minute Beep
3.4.3. Call Connect
3.5. Power On/Off
3.5.1. Power On
3.5.2. Power Off
4. Display Settings
4.1. Banner
4.1.1. Personal Banner
4.1.2. ERI Banner
4.2. Backlight
4.2.1. Display
4.2.2. Keypad
4.3. Contrast
4.4. Wallpaper
4.5. Screensaver
4.6. Display Themes
4.7. Main Menu
4.8. Dial Fonts
4.9. Clock Format
5. Phone Settings
5.1. Airplane Mode
5.2. Set Shortcuts
5.2.1. Set My Shortcuts
5.2.2. Set Directional Keys
5.3. Voice Commands
5.3.1. Prompts
5.3.2. Call Alert
5.4. Language
5.5. Location
5.6. Security
5.6.1. Edit Codes
5.6.2. Restrictions
5.6.3. Phone Lock Settings
5.6.4. Lock Phone Now
5.6.5. Restore Phone
5.6. System Select
6. Call Settings
6.1. Answer Options
6.2. Auto Retry
6.3. TTY Mode
6.4. One Touch Dial
6.5. Voice Privacy
6.6. Assisted Dialing
6.7. DTMF Tones
7. Memory
7.1. Phone Memory Usage
7.2. My Pictures
7.3. My Ringtones
7.4. My Sounds
8. Phone Info
8.1. My Number
8.2. SW/HW Version
8.3. Icon Glossary
21
BASIC FUNCTIONS
MAKING A CALL
1.
Enter a phone number.
To modify the phone number you have entered :
Note
• To erase one digit at a time press
• To erase the entire number, press and hold .
2.
Press the SEND Key .
• If “CALL FAILED” appears on the display or the line is
Note
3.
busy, press the SEND Key
• If you activate the “AUTO RETRY” function, the phone will automatically retry for the number of times you have selected.
• When you place or receive a call to or from stored phone
numbers, only the name will be displayed.
• If “Enter Lock Code” appears on the display enter your 4-digit lock code to unlock your phone.
To end a call, press the END Key .
the Clear Key
the Clear Key
or the END Key
.
.
22
BASIC FUNCTIONS
ANSWERING CALLS
1.
When your phone rings or vibrates, press the SEND Key to answer the incoming call. (Depending on your phone’s settings, you may also answer incoming calls by opening the phone or by pressing any digit key. See page 78)
To ignore incoming calls, press
2.
To end the call, press the END Key .
In Auto Answer Mode a call is automatically answered after
Note
five seconds of ring tones.
Right Soft Key
[Unlock].
WAIT/PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail, calling cards). Insert a pause after a phone number then enter another group of numbers. The second set of numbers is dialed automatically after the pause. This feature is useful for dialing into systems that require a code.
1.
To insert a wait/pause, enter a phone number then press Right Soft Key [OPTIONS]. Select either a 2-Sec Pause (“P” appears) or a Wait (“W” appears).
2.
Press the SEND Key to dial or press Left Soft Key to
save phone number.
23
BASIC FUNCTIONS
3-WAY CALLING
With 3-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be applied for each of the two calls.
1.
Enter a number you wish to call then press the SEND Key
.
2.
Once you have established the connection, enter the second number you wish to call then press the SEND Key .
3.
When you’re connected to the second party, press the SEND Key again to begin your 3-Way call.
If one of the people you called hangs up during your
Note
call, you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all three callers are disconnected.
CALLER ID FUNCTION
Identifies caller by displaying their phone number. If the caller’s name and number are already stored in your phone book, their name will appear. This is a system dependent feature. Please contact your service provider for details.
24
BASIC FUNCTIONS
CALL WAITING FUNCTION
Notifies you of an incoming call when you are already on a call by sounding a beep tone and displaying the caller’s phone number.
1.
To answer another call while on the phone, press the SEND Key . This places the first call on hold. To switch back to the first caller, press the SEND Key again.
Call Waiting is a system dependent feature.
Note
Please contact your service provider for details.
ADJUSTING VOLUME
To adjust the volume:
1.
Adjust the volume by pressing the Volume Key up or down then press the OK Key to save the setting.
• To adjust earpiece volume during a call, press the Volume
Note
Key
up or down.
- Press and hold the Volume Key sounds.
- Press and hold mode.
- In idle mode, press the master volume.
the Volume Key
the Volume Key
down to turn off all
up to return to normal
up/down to adjust
25
BASIC FUNCTIONS
SPEAKERPHONE
The speakerphone feature lets you hear audio through the speaker and talk without holding the phone.
1.
To activate the speakerphone while on a call, press the Speakerphone Key .
2.
The phone returns to normal (Speakerphone Off) after ending a call or when the phone is turned off and back on.
26
DURING A CALL
MUTE (UNMUTE)
The caller cannot hear you or any sounds from your side but you can still hear them.
1.
Press Left Soft Key [Mute].
• To deactivate, press
• The phone will automatically unmute in Emergency Call or Callback mode.
Left Soft Key
[Unmute].
SEND TXT MSG
To send a TXT message during a call:
1.
Press Right Soft Key [OPTIONS], then press “Messaging”.
CONTACTS
To select the phone number in your internal Contact List:
1.
Press Right Soft Key [OPTIONS], then press “Contact List”.
RECENT CALLS
To select a phone number in your Recent Calls List:
1.
Press Right Soft Key [OPTIONS], then press “Recent Calls”.
27
DURING A CALL
NOTEPAD
To access the notepad during a call:
1.
Press Right Soft Key [OPTIONS], then press
"Notepad."
28
MAKING AN EMERGENCY CALL
The 911 feature puts the phone in Emergency Call Mode when you dial the preprogrammed emergency number, 911. It also operates in Lock Mode and out of the service area.
911 IN LOCK MODE
The 911 call service is available even in Lock Mode.
1.
Enter “911”, then press the SEND Key .
2.
The call connects.
3.
When the call ends, the phone returns to the Lock Mode.
911 USING ANY AVAILABLE SYSTEM
1.
Enter “911”, then press the SEND Key .
2.
The call connects.
3.
The phone maintains Emergency Mode and the phone can receive an incoming call from any available system. However, it can’t make a call.
The 911 call does not appear in the recent call list.
Note
29
MEMO
30
Loading...
+ 144 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
