Page 1
Important!
Before You Start Using Your
Sprint PCS Vision Smart Device
(You'll thank us later.)
Installing the Pocket PC
Desktop Software on Your
Windows Operating System
Synchronizing Your Sprint PCS Vision
Smart Device PPC6601
Page 2
3
Page 3
This guide will walk you through
the necessary steps to complete,
verify, and perform ActiveSync.
This guide will help you install the Pocket PC Desktop
Software on your Windows
synchronize your Sprint PCS Vision Smart Device for the
rst time.
If you have previously loaded any Pocket PC software
Note:
If you need assistance, please call us at
1-888-987-HELP (4357).
or device USB drivers, please remove the prior software
and follow this guide to install the new Pocket PC
Desktop software.
operating system and
Important
Microsoft Outlook must be closed before loading
!
ActiveSync software.
DO NOT plug in the USB cable before loading the
!
software.
3
Page 4
5
Step
Insert the PPC6601 CD-ROM
into your computer's CD
1
drive.
One of two things will happen:
If auto-run is enabled on the computer, the CD
will launch and the Main Menu will appear.
If auto-run is not enabled, you must manually
launch the software by doing the following:
1. Double-click on MY COMPUTER.
2. Double-click on the CD drive for the
computer.
3. Double-click SETUP to run the program.
4
Page 5
Step
5
Select "Getting Started" to
log in to the Main Menu.
2
When you click on Getting Started, you will see
the following:
Start Here
Enhance Your Experience
Learn More
About This CD
Help
Page 6
Step
6
7
Select Start Here.
3
When you click on Start Here, you will see the
following:
Overview
Install Outlook 2002
Install ActiveSync
Get Sprint PCS Business ConnectionSM
Before you start installing Outlook 2002 or ActiveSync,
please read through Important Installation Notes.
You can click on Main Menu to return to
the previous page at anytime.
Page 7
Step
4
Install Outlook 2002 and
ActiveSync.
If your computer does not have Microsoft Outlook
98 or later installed, click on Install Outlook 2002, then
click on Install. The installation wizard will guide you
through the process.
Once you have installed Outlook 2002 (if necessary),
click on Install ActiveSync, read the Product Details and
Installation Guidelines, then click on Install to begin
the installation. Follow the instructions on the dialog
boxes to install and congure ActiveSync on your PC.
Start Installation
7
Page 8
Step
9
Restart Your Computer.
5
After the software has been completely installed,
restart your PC. When your PC boots up, verify that
the ActiveSync icon appears in the Desktop Menu
Tray (the lower right hand corner of your desktop
screen).
Desktop Menu Tray
ActiveSync Icon in Desktop Menu Tray
8
Page 9
Step
9
Your PPC6601 comes with a USB cradle which allows
you to connect to an available USB port on your
desktop PC to run ActiveSync and to recharge your
device with the supplied AC Adapter.
To connect the USB cradle to your PC, insert
the USB connector attached to the cradle
into an available USB port on your PC.
To allow the cradle to recharge your device’s
batteries, insert the supplied AC adapter into
the adapter port on the cradle and plug the
other end into a standard power outlet.
Connect the USB Cradle to
your PC.
6
Note:
You will be able to synchronize and recharge your
PPC6601 simultaneously using the USB cradle.
AC Adapter plugs
into the back of the
cradle for battery
recharging
Page 10
Step
11
Insert Your PPC6601 into
the USB Cradle and Run
7
ActiveSync.
With the USB cradle attached to your PC, insert the
PPC6601 into the slot on the front of the cradle.
Once connected, ActiveSync will automatically detect
your device and prompt you to set up a partnership.
Follow the prompts on your PC to select your
partnership settings, synchronization method, and
synchronization settings. Once setup is complete,
click <Finish>. ActiveSync will open and begin
synchronizing the selected information between your
PPC6601 and your desktop PC.
If ActiveSync doesn’t launch automatically, right
click on the ActiveSync icon in the Desktop
Menu Tray and select Open Microsoft ActiveSync.
If it does not automatically recognize your
PPC6601, select File, and then Get Connected
to connect manually.
10
Page 11
Helpful Hints
If you are having difculties with the software
installation, please refer to“Troubleshooting” in the
Section 11 of the User’s Guide located on the
installation CD and www.sprintpcs.com.
Never start an ActiveSync operation while your system
is booting up. ALWAYS wait until you see the ActiveSync
icon in the System Tray (see page 8) prior to starting an
ActiveSync operation.
For more information about avoiding problems and
diagnosing common errors, please see Section 11 of
the User’s Guide located on the Installation CD, or visit
www.sprintpcs.com. If you need further assistance, please
call 1-888-987-HELP (4357).
