GPRS778 / 779 PHONE

USER MANUAL

Table of Contents

Safety Precautions ................3

Unpacking ..............................6

Your Phone ............................7

Your Phone’s parts ...................7

Display ....................................11

Keypad Backlight ....................14

Getting Started ....................15

Installing a SIM Card ..............15

Charging the Battery ..............18

Switching the Phone On or Off

...21

Your Phone’s Modes ..............22

Locking the Keys ....................23

Using the Soft Keys ............24

Call Functions .......................28

Making a Call .........................28

Making an International Call ..29 Making a Call from Phonebook

..29

Redialing the Last Number .....29

Adjusting the Volume ............30

Answering a Call ....................31

Viewing Missed Calls ..............32

Quickly Switching to Etiquette

Mode ......................................33

Options During a Call .............33

Using the Ear-microphone .....39

Entering Text .......................40

Changing the Text Input Language

..41

eZi English Mode ....................44

ALPHABET Mode ...................47

Using the Menus .................50

Accessing a Menu Function by

Scrolling ........................................50

Accessing a Menu Function by Using

Its Shortcut ...................................51

List of Menu Functions .................52

Message ...............................61

SMS ........................................61

MMS ......................................61

Write Message (Menu 1-1) ....61

Inbox (Menu 1-2) ...................64

Outbox (Menu 1-3) ................67

Draft (Menu 1-4) ....................68

Templates (Menu 1-5) ............68

Voice Mail (Menu 1-6) ...........69

Info Message (Menu 1-7) .......70

Settings (Menu 1-8) ...............72

Call Register .........................75

Call History (Menu 2-1) ..........75

Call Duration (Menu 2-2) .......78

GPRS Counter (Menu 2-3) .....79

Call Costs (Menu 2-4) ............80

Table of Contents

Profile ....................................81

General (Menu 3-1) ................81

Setting ..................................83

Time/Date Set (Menu 4-1) ......83

Alarm Set (Menu 4-2) ............84

Call Setting (Menu 4-3) ..........87

Phone Settings (Menu 4-4) ....95

Security Settings (Menu 4-5) .....

GPRS Setting (Menu 4-6) .....102

Network Select (Menu 4-7)

....103

Factory Set (Menu 4-8) .........104

Organizer ...........................105

Phonebook (Menu 5-1) ........105

Scheduler (Menu 5-2) ..........117

File Manager (Menu 5-3) .....122

Camera ...............................123

Shooting (Menu 6-1) ............123

Special Effects (Menu 6-2) ...125

Album (Menu 6-3) ...............125

Configuration (Menu 6-4) ....126

Application .........................127

Othello (Menu 7-1) ..............127

Calculator (Menu 7-2) ..........127

Unit Converter (Menu 7-3) ..129

World Time (Menu 7-4) .......130

Voice Memo (Menu 7-5) .....130

Java .....................................131

Downloads (Menu 8-1) ........131

Install Application (Menu 8-2)

....131

Memory Status (Menu 8-3)

....132

Network

(Menu 8-4)

.............132

Internet ...............................133

Homepage ...........................134

Bookmarks ...........................135

Recent Pages ........................136

Enter Address .......................137

Resume ................................137

Settings ................................138

Push ......................................138

Reference Information .....142

Access Codes .......................142

Using the Batteries ...............144

Safety Information ...............146

Care and Maintenance ........153

Glossary ..............................155

1 2

Safety Precautions

Read these simple guidelines. Failure to comply with them may be dangerous or illegal. For more detailed safety information, see “Reference Information” on page 142.

Road safety comes first

Do not use a hand-held mobile phone while driving; park the vehicle first. Remember that in some countries, it is illegal to use a mobile phone while driving.

Switch off when refueling

Do not use the phone at a refueling point (service station) or near fuels or chemicals.

Switch off on aircraft

Mobile phones can cause interference. Using them on aircraft is both illegal and dangerous.

Switch off in hospital

Follow any regulations or rules. Switch phone off near medical equipment.

Respect special regulations

Follow any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger (in a hospital for example).

Interference

All wireless phones may be subject to radio interference, which may affect their performance.

Use qualified service

Only qualified service personnel must repair equipment.

Use sensibly

Use only in the normal position (to the ear). Do not touch the antenna unnecessarily when the phone is switched on.

Accessories and batteries

Use only approved accessories and batteries.

Safety Precautions

Unpacking

Your package contains the following items:

The shape of the plug varies according to each country’s specification.

Phone Battery coverBattery

Cable

Travel adapter *

Ear-microphone

User Manual

Radio frequency exposure information

In August 1996, the Federal Communications Commission (FCC) of the U.S. adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. These guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

To maintain compliance with FCC RF exposure guidelines, if you wear a handset on your body, use the supplied or approved carrying case, holster, or other body-worn accessory.

If you do not use a body-worn accessory, ensure the antenna is at least one inch (2.5cm) from your body when transmitting. Use of non-approved accessories may violate FCC RF exposure guidelines.

The following illustrations show the main elements of your phone:

Your Phone’s parts

Your Phone

Open View

Closed View

Rear View

Earpiece

Navigation/Hot keys

Right soft key

End/Power on-off key

Clear key

Folder

Display

Internet Service/Confirmation key

Volume keys

Left soft key

Send key

Camera key

Alphanumeric keys

Special function keys

Microphone

Sub LCD

Camera

Battery terminals SIM card socket

Cable connector slot

Hand strap hole

Earphone jack

Key(s) Description

Performs the functions indicated by the text above them, on the bottom line of the display.

In Standby Mode, this key can be used to access ` the Internet browser. In some features, this key also can be used as a confirmation key or a soft key.

In Menu Mode, scrolls through the menu options. In Standby Mode, accesses the following menus:

• : Java

• : Profile

• : Schedule

• : Message Menu

Press to make or answer a call. In Standby Mode, recalls the last dialed number.

Ends a call. Also switches the phone on and off when pressed and held.

Key(s) Description

In Menu Mode, cancels your input and returns to Standby Mode.

Enters numbers, letters and some special characters. In Standby Mode, pressing and holding the 1 key immediately connects you to the Voice Mail server.

Use these keys for various special functions.

• Press and hold to activate Etiquette Mode.

• Press and hold to activate Key Lock Mode.

(On the side of the phone.) Press to directly access the camera menu.

Your Phone

Key(s)

Y our Phone

109

Your Phone

Icons Description

Signal Strength : Shows the received signal strength.

The greater the number of bars, the stronger the signal.

No Service : Appears when you are outside a service area. When it is displayed, you cannot make or receive calls.

Service : Appears when a call is in progress. Roaming : Appears when you are out of your home area

and have registered onto a different network; for example, when traveling in other countries.

New Text Message : Indicates that there is a new message waiting to be checked.

New MMS Icon : Indicates that there is a new MMS message waiting to be checked.

New Voice Mail : Indicates that there is a new voice mail waiting to be checked.

Push Message : Indicates that there is a new Push Message waiting to be checked.

Alarm : Appears when you set an alarm.

Icons

Text and graphic area

Soft key indication area

Icon area

The display has three areas.

Area Description

Icon area Displays various icons (see page 12~13).

Displays messages, instructions and

Text and graphic

any information that you enter

area

(number to be dialed, for example)

Soft key Displays the functions assigned to the indications area two soft keys.

Display

Y our Phone

1211

Sub LCD

Your phone has an external LCD screen on the folder. When the folder is closed, it indicates that you have an incoming call or message. It also alerts you when you have set an alarm at the specified time by flashing its backlight and displaying the corresponding icon.

Your Phone

The backlight illuminates the display and keypad. When you press a key or open the folder, the backlight turns on. The keypad turns off if no key is pressed within a given period of time, depending on the Back light menu option under the Phone Settings menu.

To specify the length of time the phone waits before the key backlight turns off, set the

Backlight menu option (Menu 4-4-4); see page 96

for further details.

Key Back Light

Icons Description

Battery Status : Shows the level of your battery.

The more black area you see, the more power you have left. GPRS : Shows the status that data can be received and sent

using the packet.

Manner : Indicates that all tones are off. Ring : The phone is set to ring when a call comes in. Vibrator : The phone is set to vibrate when a call comes in. Vib+Ring : The phone is set to ring and vibrate when a call

comes in. Silent : The phone is set to show an incoming call message

on sub LCD when a call comes in. Divert : The call divert for calls is set by user.

Icons

Y our Phone

1413

Getting Started

When you subscribe to a mobile network, you are provided with a plugin SIM card loaded with your subscription details, such as PIN, optional services available and so on.

Installing a SIM Card

��Note : The plug-in SIM card and its contacts can be easily

damaged by scratches or bending, so be careful when handling, inserting or removing the card. Follow the instructions supplied with the SIM card. Keep all SIM cards out of the reach of small children.

If necessary, switch the phone off by pressing and holding the key.

Remove the battery. To do so:

① Pull the battery lock above the battery toward the bottom of

the phone and hold it.

② Lift the battery away, as shown.

Install a SIM card. To do so:

① Insert the SIM card into the SIM card socket.

② Make sure that the notched corner is at the top right and the

golden contact area on the card is facing downward.

1615

Getting Started

Reinstall the battery. To do so:

① Place the battery on the back of the phone then slide on the

back cover. Before turning the phone on, make sure the battery is properly installed.

② Push the cover up until it clicks into the right place.

Getting Started

Charging the Battery

Your phone is powered by a rechargeable Li-ion battery. A travel adapter comes with your phone. Use only approved batteries

and chargers. Ask your local dealer for further details.

��Note : You must fully charge the battery before using your

phone for the first time. You can use the phone while the battery is charging.

1817

Getting Started

Low Battery Indicator

To remove the adapter from the phone, press the buttons on both sides of the connector (see

) and pull the adapter out (see ).

Getting Started

When the battery charge level is low, a text message and an empty battery status icon appears at the top right of the display.

When the battery level gets too low, the phone turns off automatically. Unfortunately, if this happens, you lose whatever you are doing and your phone call cuts off. Watch the battery status icon and make sure your battery is adequately charged.

Charging the Battery with the Travel Adapter

You can use the phone while charging the battery attached to the phone.

With the battery in position on the phone, plug the connector of the travel adapter into the connector slot at the bottom of the phone.

Plug the adapter into a standard AC wall outlet.

2019

Standby is the most basic state of your phone. The phone goes into Standby Mode after you turn it on, or whenever you briefly press the key. When your phone is in Standby Mode, you will typically see the current date and time. If you enter a phone number, you can press the key to dial it, or press the soft key to save it in the internal Phonebook.

Press the key at any time to return to Standby Mode. Be careful; if you are on a call when you press the key, your phone disconnects the call and returns to Standby Mode. Press the or soft key several times or hold it down to return to Standby Mode without ending the call.

Getting Started

Your Phone’s Modes

Standby Mode

Talk Mode

You can place and answer calls only when your phone is turned on. During a call, the phone is in Talk Mode. While you are in the talk mode, pressing the soft key displays a list of options. See page 34 for details.

Getting Started

Switching the Phone On or Off

Open the folder.

Press and hold the key for more than one second to switch the phone on.

��Note : If you switch the phone on without a SIM card,

the phone prompts you to insert the card. You can only make emergency calls by pressing the soft key.

When the PIN code of your SIM card is enabled, your phone asks you to enter the PIN (see page 142). Enter the code, and press the soft key. Your phone connects to the GSM network.

��Notes :

●

When the phone locates services, the idle screen appears on both the main and sub LCD.

●

If the phone is out of the service area, No Service appears on the display and you cannot place and receive calls. Wait a little while for a better signal or move into an open area to regain service.

To turn off the phone, press and hold .

WARNING!

Do not switch the phone on when mobile phone use is prohibited or when it may cause interference or danger.

��Note : Do not touch the antenna on the phone unnecessarily

when the phone is switched on. Contact with the antenna affects the call quality and may cause the phone to operate at a higher power level than otherwise needed.

2221

Using the Soft Keys

Press the right soft key to enter the Phonebook feature.

Press the left soft key to enter Menu Mode.

Your phone offers a set of functions that allows you to customize it. These functions are arranged in menus and sub-menus, accessed via the two soft keys ( and ). Each menu and sub-menu allows you to view and alter the settings of a particular function.

The roles of the soft keys vary according to the current context; the label on the bottom line of the display just above each key indicates its current role.

Example : When in standby mode

Getting Started

Use the Key Lock feature to make sure that the keys are not pressed accidentally, such as when the phone slips around inside a briefcase.

In Standby Mode, press and hold the key. “Key Locked” appears on the display and the keys are immediately locked. Note that you can switch the phone off then on by pressing and holding the key.

To unlock the keys, press and hold the key again.

Locking the Keys

2423

To view the various functions/options available and select the one required :

Press the appropriate soft key.

To Press the

Select the: soft key or the

• Function displayed key.

• Option highlighted

Move up or down or key. in the menu

Move right or left or key. in the menu

Move back up one soft key. level in the menu

Exit the menu key. without changing the settings

Using the Soft Keys

Shoot Edit

Using the Soft Keys

2625

To clear Press

The last digit displayed The soft key

The

key until the cursor is to

the right of the digit to be cleared. Press

Any other digit in the number

the soft key. You can also insert a missing digit in the cursor position simply by pressing the appropriate key.

The whole display

And hold down the soft key for more than one second.

When the idle screen displays, press the soft key to enter Menu Mode.

Scroll through the menus until you reach the Setting menu by repeatedly pressing the or key.

To enter the Setting menu, press the soft key.

Scroll through the menus until you reach the Phone Settings menu by pressing the or key repeatedly.

To enter the Phone Settings menu, press the soft key.

To enter the Language sub-menu, press the soft key.

To view the languages available, press the soft key.

●

The display shows the current setting.

Select the appropriate language by pressing the or key.

Press the soft key to confirm your selection.

●

The phone returns to Standby Mode.

Call Functions

Example Setting the Display LanguageExample

Making a Call

��Note : While entering the number, pressing and holding down

the key inserts a pause, indicated by “P.” The number after a pause is sent a few seconds after dialing the first number.

To make a call

In Standby Mode, enter the area code and phone number.

��Note : If you set the Auto Redial menu(Menu 4-3-6) to On,

the phone automatically retries to make the call when no one answers or the line is busy. For further details, see page 91.

Correcting the Number

Press the key.

●

The phone places the call to the entered number.

Using the Soft Keys

2827

Call Functions

Ending a Call

To end a call, press or simply close the phone.

Making an International Call

You can store the phone numbers that you use regularly in the Phonebook. Simply select a name to recall the associated number to dial. For further details about the Phonebook features, see page 105.

Making a Call from Phonebook

Redialing the Last Number

To adjust the volume during a call, press the volume keys on the side of the phone.

In Standby Mode, you can adjust the key tone volume using the volume keys.

Adjusting the Volume

Press and hold the 0 key for the international prefix.

●

The + appears on the display.

Enter the country code, area code, and phone number, then press the key to begin dialing.

To redial the last number you dialed, press the key twice in Standby Mode.

The last 30 numbers you dialed are stored in the Call Records. To recall any of these numbers, refer to “Dialed Numbers” on page 77.

Call Functions

3029

When someone calls you, the phone alerts you by ringing, blinking the color LED and displaying the call alert screen. If you are subscribed to the Caller Line Identification service and the caller can be identified, the caller's phone number or name,(and image if stored in your Phonebook), displays. Contact your service provider for availability.

You can reject the call by pressing and holding the volume keys before opening the folder.

If the Answer Mode menu (Menu 4-3-4) is set to Any Key, open the folder or press any key except the key and the soft key to answer the call.

If the menu is set to Send Key, you must press the key or the soft key to answer the call.

To reject the call, press the key or the soft key.

To end a call, press or simply close the phone.

Call Functions

Answering a Call

If you miss a call, you can view a list of Missed Calls. This is system dependent feature - contact your service provider for availability.

The number of missed calls displays on the idle screen immediately after the call was missed.

Viewing Missed Calls

To immediately view missed calls :

If available, the number corresponding to the most recent missed call displays.

If the folder is Then

Closed Look at the sub LCD screen. Open Press the soft key.

To Press the

Scroll through the

or key

missed calls Call the number key.

displayed Save or delete a soft key.

missed call number

Call Functions

3231

When you have an active call and a call on hold, you can disconnect both calls at one time.

Press the soft key to enter In-call Options.

Press the or key to scroll to Disconnect and press the soft key.

Press the or key to scroll to call you want to disconnect.

Press the soft key.

During a call, press the key. Or, press the soft key and press the soft key when Hold highlights.

The current call is put on hold.

If there is a waiting call, press the key to answer the call.

If you want to make a call, dial the number in the normal way.

To quickly switch your phone to Etiquette Mode, press and hold . In Etiquette Mode, all sounds are turned off and the phone alerts you to an incoming call by vibrating instead of ringing.

Press and hold the key until the Etiquette Mode icon appears on the top right of the display. Your phone goes to the Etiquette Mode immediately.

To return to the normal mode, press and hold the key again.

Call Functions

Quickly Switching to Etiquette Mode

Your phone provides a number of functions that you can use during a call. As many of the functions are network services, you may not be able to use all of them at all times.

Options During a Call

Putting a Call on Hold

You can place the current call on hold whenever you want. By doing this, you can make or receive another call while you have a call in progress if your network supports this service.

Disconnecting the Calls

To make a call while you have a call in progress:

Call Functions

3433

Press the soft key to enter In-call Options.

Press the or key to scroll to Mute Off.

Press the soft key.

●

The other person can hear you again.

During a call, press the soft key to enter In-call Options.

Press the or key to scroll to Mute On.

Press the soft key.

●

The other person can no longer hear you.

Call Functions

Muting the Microphone

You can temporarily mute your phone so the other person cannot hear

you.

To temporarily switch the microphone off :

Example : You wish to say something to another person in the room

but do not want the other person to hear you.

To switch the microphone back on:

Using the Scratch Pad

Your phone has a convenient feature for entering a phone number while you are on a call as if it were a note pad:

During a call, just key in a phone number.

●

The phone number displays as you enter it.

Press the soft key to save the entered number.

When the call ends, you can check the saved number via the Scratch Pad option in PB Manage of the Phonebook menus. See page 115.

Call Functions

3635

If you receive an incoming message during a call, you can immediately read it without ending the call. You can also send a message during a call.

During a call, press the soft key.

Select the Message option and press the soft key.

The phone enters the Message menu. For details about using the message service, see page 61.

During a call, press the soft key.

Press the or key to scroll to DTMF On.

Press the soft key.

During a call, press the soft key.

Press the or key to scroll to DTMF Off.

Press the soft key.

Call Functions

Sending DTMF Tones

Each time you press the keys, your phone sends out DTMF (Dual Tone Multi-Frequency) which are set at the factory. DTMF tones are required to use electronic phone services, such as bank-by-phone or Voice Mail.

Using the Message Service

To mute DTMF tones during a call :

To reactivate your DTMF tones:

Call Functions

3837

Entering Text

Entering T ext

Using the ear-microphone supplied with your phone, you can answer an incoming call without holding the phone.

Connect the ear-microphone to the jack on the side of the phone.

To answer a call, press and hold the button on the ear-microphone for more than one second.

To end the call, press and hold the button for more than 1 second.

Using the Ear-microphone

��Note : If you receive a second call during a call, pressing and

holding the button for more than 1 second will put the first call on hold and answer the second call.

Call Functions

At many times when using your phone, you will need to enter text, such as when storing a name in Phonebook, creating a greeting note, writing a text message or scheduling events on your calendar.

The following text input modes are available :

This phone allows you to enter 9 languages by pressing each key once for each character. English, Russian, French, Germany, Spanish, Italian, Portuguese, Polish and Turkish are available with this phone.

��Note : eZi text input method allows you to enter text easily

and quickly. Simply pressing each key once for each character, you can get the words you want. The word is predicted along with other words that match the letters you have typed. You do not need to input entire characters to make a word.

ABC : allows you to enter letters by pressing the key labeled with the letter you want once, twice, or three times until the letter appears on the display.

Digit : allows you to enter the digits 0-9. Ezi Mode : allows you to use all of the text input modes by pressing

the key one or more times until you find the mode. Edit Symbol : allows you to enter symbols or punctuation marks.

4039

Entering Text

This mode allows you to change text input language.

Changing the Text Input Language

To change to another text input language:

Press the key to access the eZi Sub Menu screen.

Press the or key until you find the Entry mode you want from the list.

Press the soft key.

●

You will see the text input mode indicator on the top line of the display. Directions for using each of the text input modes appear later in this chapter.

Press the or key to scroll to find a language you want.

Press the soft key.

��Note : The text input mode indicator can be found at the top

left hand corner of the screen - please see below for an explanation of each symbol. To change the text input mode press the key until you reach your desired input mode. To insert punctuation marks or a symbol press the key.

Entering Text

Insert Symbol

The symbol mode enables you to enter symbols into your text. Press the key to enter into the symbol mode.

Press the and keys to scroll through the symbols.

When you find the symbol you want to insert, press the Number key corresponding to the symbol you want.

Insert Text Template

The Template mode enables you to enter simple sentences into your text.

Press the soft key and select 'Insert text template' to enter into it.

Press the and keys to scroll through the templates and select the text you want to insert.

4241

Entering Text

The following text input modes are available :

Fix Animation/Fix Sound : You can send EMS messages with Animation and Sound using this mode. If the receiver has the same handset as you, he/she can see or hear the same Animation and Sound you sent. If not, the receiver will see or hear his/her own Animation or Sound that corresponds with the information you sent.

Own Animation/Own Image/Own Sound : You can send EMS messages with your own Animation and Sound.

Insert EMS Content

This mode enables you to enter EMS contents into your text.

Press the soft key and select 'Insert EMS content' to enter into it.

You can insert Animation, Image and Sound contents into your text.

This mode allows you to enter English words with only one key press per letter. Each key on a keypad has more than one letter - a single press on the 5 key could be J, K, or L. The eZi English mode automatically compares your key presses to an internal linguistic database to determine the correct word.

This mode requires far fewer keystrokes than the traditional multi-tap method, the ABC mode.

eZi English Mode

4443

Entering Text

To type a word, press the keys corresponding to the letters you need. Remember the following as you are typing:

Press keys on the phone just once per one letter.

●

For example, to enter “hello”, press the following keystrokes: 4, 3, 5, 5, 6.

The word you are typing appears in the display.

●

It may change with each key you press.

If the word that appears on the display is not the word that you desire, press the or key one or more times to display alternative word choices for the keys you pressed.

●

For example, "of" and "me" share the sequence of 6 and 3. The phone displays the most commonly used choice first.

Press 0 key to select the word choice that appears on the display.

Typing English Words

��Note : The phone displays all of the words containing the letters

you have entered. The eZi mode allows you to enter text quickly using fewer key presses.

To change the case of the word, repeatedly press the key when the word highlights. Lower Case, Capital Lock and Initial Capital are available. You can also insert periods between letters for abbreviations.

Shifting the Case

●To move the cursor left or right through your text message, press

the or key.

●To scroll up or down one line of your text, press the and key.

Scrolling

Press the key one or more times to remove characters from the Text Area.

Clearing Characters

Quickly Switching to Another Mode

●In Ezi mode, you can quickly switch to the ABC mode and then to

digit mode by pressing the key.

●When you press the key, you can access the symbol mode.

4645

Key Characters in the Order Displayed

. , ? ! 1 \ : ’ @ + - ( ) _ ABC2 DEF3 GHI 4 JKL5 MNO6 PQRS7 TUV8 W X Y Z 9

Space 0

Entering Text

61 62

(Caps Lock mode)

ALPHABET Mode

List of available characters

When typing in the ABC mode, press the key labeled with a character:

- Once for the first character

- Twice for the second character and so on. This method is called Multi-tap Typing. For example, quickly press the 2 key three times to display the letter “C”,

or quickly press the 5 key twice to display the letter “K”. The cursor moves to the right when you press a different key. When

entering the same character twice or a different character on the same key, just wait for a few seconds for the cursor to move to the right automatically, and then select the next character.

Refer to the table on the next page for the list of characters assigned to each key.

Entering Text

4847

Using the Menus

61 62

Shifting the Case

Scrolling

Quickly Switching to the Symbol Mode

Clearing Characters

●To move the cursor to the left or right through your text, press the or key.

●To scroll up or down one line of your text, press the and key.

To change the case of words, press the key. There are two cases:

Lower Case is indicated by

abc on the display, and Capitals Lock is

indicated by ABC.

Press the soft key one or more times to remove characters from the Text Area.

●When you press the key, you can access the symbol mode.

Entering Text

Using the Menus

In Standby Mode, press the soft key to access Menu Mode.

Scroll with the navigation keys to reach the main menu,

Call Register. Press the key to enter the menu.

If the menu contains any sub-menus, use the and keys to scroll through the menus. Press key to enter the submenu.

If the menu you have selected contains submenus, repeat this step.

Scroll with the navigation keys to find the setting of your choice. Press the soft key to confirm the chosen setting.

��Notes :

●When you use the navigation keys for setting options, refer to the direction of the triangle at the bottom of the display.

●

You can return to the previous menu level by pressing the soft key.

●You can exit the menu without changing the menu settings by pressing the key.

The phone offers a range of functions that allows you to tailor it to your needs. These functions are arranged in menus and submenus.

The menus and submenus can be accessed by scrolling or by using the shortcuts.

Accessing a Menu Function by Scrolling

5049

In Standby Mode, press the soft key.

Enter the first digit of the shortcut number. Repeat this for each digit of the shortcut number.

Example

: Setting the Auto Redial function to On.

Press the soft key, and key in 4, 3, 6.

Menu enters the menu, 4 selects Setting, 3selects the Call Setting menu, and 6selects the Auto Redial menu function.

Press the or key to highlight On and press the soft key.

Using the Menus

The menu items, menu, submenus and setting options are numbered and can be accessed quickly by using their shortcut numbers. The shortcut number is shown in front of each menu item.

��Note : The numbers assigned to each menu function are

indicated on the list on page 48. They may not match the menu number on the phone, depending on the services supported by your SIM.

Accessing a Menu Function by Using Its Shortcut

The list shows the menu structure available and indicates the number assigned to each option.

��Note : If you use a SIM ToolKit card that provides additional

services, the SIM ToolKit menu appears instead of 9. Internet Menu. The other

menus aren't changed. If it does not provide SIM ToolKit card,

9.Internet

Menu appears.

For details on the SIM ToolKit menu, refer to your SIM card instructions.

List of Menu Functions

Using the Menus

5251

Using the Menus

1-1 : Write Message

1-2 : Inbox

1-3 : Outbox

1-4 : Draft

1-5 : Templates 1-6 : Voice Mail

1-7 : Info Message

1. Message

1-1-1 : SMS 1-1-2 : MMS

1-3-1 : SMS 1-3-2 : MMS

1-4-1 : SMS 1-4-2 : MMS

1-6-1 : Call Voice Mail 1-6-2 : Voice Center

1-7-1 : Read 1-7-2 : Receive 1-7-3 : Topics 1-7-4 : Languages 1-7-5 : Alert

1-2-1 : SMS 1-2-2 : MMS

1-8 : Settings

1. Message

1-8-1 : SMS

1-8-1-1 : SMSC 1-8-1-2 : Status Report 1-8-1-3 : Message Type 1-8-1-4 : Validity Period 1-8-1-5 : Reply Path

1-8-2 : MMS

Sending Retrieval Filters Network

1-8-3 : Memory Status

5453

2-1 : Call History

2-2 : Call Duration

2. Call Register

2-1-1 : Missed No. 2-1-2 : Received No. 2-1-3 : Dialed No.

2-2-1 : Last Incoming 2-2-2 : Last Outgoing 2-2-3 : Total Incoming 2-2-4 : Total Outgoing 2-2-5 : Reset

Using the Menus

2-3 : GPRS Counter

2-4 : Call Costs

2. Call Register

2-3-1 : Last Sent 2-3-2 : Last Received 2-3-3 : Total Sent 2-3-4 : Total Received 2-3-5 : Reset

2-4-1 : Last Call’s Cost 2-4-2 : All Call’s Cost 2-4-3 : Cost Reset 2-4-4 : View Max Cost 2-4-5 : Set Max Unit 2-4-6 : Price/Unit

3-2 : Silent 3-3 : Vibration Only 3-4 : Outdoor 3-5 : Other1 3-6 : Other2 3-7 : Other3

3. Profile

3-1 : General

3. Profile

3-1-1 : Activate 3-1-2 : Personalise

3-1-2-1 : Alert Type 3-1-2-2 : Ring Tone 3-1-2-3 : Ring Volume 3-1-2-4 : Message Tone 3-1-2-5 : Key Volume 3-1-2-6 : Key Tone 3-1-2-7 : Folder Tone 3-1-2-8 : Connect Alert 3-1-2-9 : Power On/Off Melody

3-1-3 : Rename

5655

4-1 : Time/Date Set

4-2 : Alarm Set

4. Setting

4-1-1 : Time Set 4-1-2 : Date Set

4-2-1 : Set Alarm 4-2-2 : Alarm Sound 4-2-3 : Power Off Alarm

Using the Menus

4-3 : Call Setting

4-4 : Phone Settings

4. Setting

4-3-1 : Call Divert

4-3-1-1 : All Voice Calls 4-3-1-2 : If Busy 4-3-1-3 : If not Answered 4-3-1-4 : If out of Reach 4-3-1-5 : If not Available 4-3-1-6 : All Data Calls 4-3-1-7 : All Fax Calls 4-3-1-8 : Cancel Divert

4-3-2 : Call Waiting

4-3-2-1 : Status 4-3-2-2 : Activate 4-3-2-3 : Deactivate

4-3-3 : Send My Caller ID 4-3-4 : Answer Mode 4-3-5 : Min Minder 4-3-6 : Auto Redial 4-3-7 : Auto Answer 4-3-8 : Data Transfer Mode

4-4-1 : Language 4-4-2 : Main LCD 4-4-3 : Sub LCD 4-4-4 : Backlight 4-4-5 : Screen Saver

4-5 : Security Settings

4-6 : GPRS Setting 4-7 : Network Select 4-8 : Factory Set

4. Setting

4-5-1 : PIN Code 4-5-2 : Phone Lock 4-5-3 : Call Barring 4-5-4 : Fixed Dial Number 4-5-5 : Change Codes

5857

5-1 : Phonebook

5. Organizer

5-1-1 : Name Search 5-1-2 : Group Search 5-1-3 : Add Entry 5-1-4 : Speed Dials 5-1-5 : Caller Groups 5-1-6 : PB Manage

5-1-6-1 : Own Number 5-1-6-2 : Scratch Pad 5-1-6-3 : Memory Status 5-1-6-4 : Copy All 5-1-6-5 : Delete All 5-1-6-6 : Memory In Use

Using the Menus

5-2 : Scheduler

5-3 : File Manager

5. Organizer

5-2-1 : Daily View 5-2-2 : Weekly View 5-2-3 : Monthly View 5-2-4 : Make 5-2-5 : Delete All 5-2-6 : Setting 5-2-7 : To do

5-3-1 : Memory Status 5-3-2 : File List

6-1 : Shooting 6-2 : Special Effect 6-3 : Album 6-4 : Configuration

6. Camera

8-1 : Downloads 8-2 : Memory Status 8-3 : Network

8. Java

Homepage Bookmarks Recent Pages Enter Address Resume Settings Push

9. Internet

7-1 : Othello 7-2 : Calculator 7-3 : Unit Converter

7-4 : World Time 7-5 : Voice Memo

7. Application

7-3-1 : Length 7-3-2 : Weight 7-3-3 : Volumes 7-3-4 : Surface 7-3-5 : User Define

7-5-1 : Record 7-5-2 : Play 7-5-3 : Delete All

��Note : If your SIM card supports the

“Service Numbers” function, its menu will appear between 5-1-6-2 and 5-1-6-3 in the Phonebook menu.

6059

Message

The Messages option is a network service and may not be supported by your network. You can send a message by a text messaging system, provided that the service is supported by your network. To send messages by your phone, you must obtain the number of the SMS center from your local service provider.

The memory capacity for incoming and outgoing messages depends on your SIM card. If the memory is full, an error message displays and you cannot receive or save any new messages. Delete obsolete messages.

SMS

Multimedia message (Multimedia Message Service(MMS)) is message service similar to text message(Short Message Service(SMS)) and delivers multimedia messages from phone to phone. Multimedia message can contain image and sound. You can send or receive multimedia messages using this function. This function is available only if it is supported by your local service provider and your phone offers multimedia message function.

MMS

Write Message

Menu 1-1

In this menu, you can write and send a text message.

1. Message

1 Write Message

2 Inbox 3 Outbox 4 Draft 5 Templates 6 Voice Mail

SMS

Menu 1-1-1

Creating and Sending a New Message

You can write and send a text message of up to 160 alphanumeric characters within the limits of the maximum 5 pages.

In Standby Mode, press the soft key twice to enter the Message menu.

●

You can directly enter the Message menu by pressing the key once.

Press the soft key to enter Write Message mode.

Press the soft key to enter SMS mode.

Enter a message. For further details about how to enter text, see page 40.

When you press the key to exit from this menu, the message is automatically saved and displayed when you enter this menu again.

When you finish entering the message, press the soft key then press key. Enter the number directly, or press the soft key, select PB Search, then find the number in your phonebook.

6261

Message

MMS

Menu 1-1-2

You can write and send a multimedia message using the New Multimedia Message option.

In Standby Mode, press the soft key twice to enter the

Message menu.

●

You can directly enter the Message menu by pressing the key once.

Press the soft key to enter Write Message mode.

Use the or key to scroll through the contents and select the MMS mode. Then, press the soft key to enter MMS mode.

A window with To, Cc, Bcc and Subject, Option and Edit Content is displayed. Fill in the message properties, select the Edit Content and press the soft key.

You can write and send messages with text, image and audio.

��Caution: You cannot attach a photo you took and stored in your

phonebook to an MMS message.

When you receive a new text message, the New Text Message icon appears on the display.

To read the message immediately press the soft key and use the or

key to scroll through the contents when the folder is opened.

Your phone stores the received messages in the Inbox on your phone. In Standby Mode, you can access the received messages any time by using the Inbox.

SMS

Menu 1-2-1

In this menu, you can view the messages you received and reply, forward or delete them.

In this menu, you can view SMS/MMS messages you received.

Inbox

Menu 1-2

Viewing an Incoming Message:

1. Message

1 Write Message

2 Inbox

3 Outbox 4 Draft 5 Templates 6 Voice Mail

6463

To access the Message menu, press the soft key in Standby Mode. Then press the key.

Select the Inbox.

Scroll to MMS and press the soft key.

●

The list of the received messages displays.

The screen shows the:

●

Sender's phone number.

●

Icon on the left of each multimedia message to show whether or

not you read it; (Read) or (Unread).

Scroll to a multimedia message you want to view by pressing the or key and press the soft key.

Use the or key to scroll through the contents.

Press the soft key to view the options.

To return to Standby Mode, press the key.

Message

Viewing an Incoming Message:

Upon receiving a new multimedia message, the New Multimedia Message icon ( ) appears on the display.

MMS

Menu 1-2-2

In this menu, you can view the messages you received and reply, forward or delete them.

While viewing a multimedia message, press the option menu. Or, access the Multimedia Message and select the Inbox.

You can choose the

following options.

6665

Message

Access the Message menu by pressing the soft key in standby mode. Then press the key.

Select option 3(Outbox) and SMS by pressing the soft key.

●

The list of the sent messages is displayed.

The screen shows the:

●

Sender’s phone number.

Scroll to a message by pressing the or key and press the soft key.

You can view the SMS messages you sent.

SMS

Menu 1-3-1

To view the messages:

In this menu, you can send and delete the messages saved in the Outbox.

Outbox

Menu 1-3

In this menu, you can view the MMS messages you tried to send.

MMS

Menu 1-3-2

Use the or key to scroll through the contents.

Press the soft key to edit the message text or use the options.

To return to Standby Mode, press the key.

If you write a message and do not send it, it will be saved in the Draft folder. Messages that failed to send are also stored in this folder. You can choose to edit or delete these messages by selecting the Options menu in the Draft folder.

Draft

Menu 1-4

In this menu you can access frequently used messages. Scroll through the template list using the

or keys. Select the desired item then press

the key.

Templates

Menu 1-5

1. Message

1 Write Message 2 Inbox

3 Outbox

4 Draft 5 Templates 6 Voice Mail

1. Message

1 Write Message 2 Inbox 3 Outbox

4 Draft

5 Templates 6 Voice Mail

1. Message

1 Write Message 2 Inbox 3 Outbox 4 Draft

5 Templates

6 Voice Mail

6867

Access the Message menu, scroll to Voice Mail and press the soft key. Select Call Voice Mail.

The voice center number is automatically dialed. When the center answers, follow the voice prompts to listen to the message.

��Note : When you use this feature, if the Voice Mail center

number is not currently stored in your phone, the phone alerts you that the center number is not stored and asks you to enter the number. To enter the number, press the soft key and enter the number.

For further details about the Voice Mail feature, please contact your service provider.

Message

Voice Mail is a network feature. If the Voice Mail is provided by your network, you can access the Voice Mail box with one key press. Before activating this feature on your phone, you must enter the voice center number obtained from your service provider.

When you receive a new voice message, the New Voice Mail icon ( ) appears on the display.

Access the Voice Mail to listen to the voice message:

Voice Center

Menu 1-6-2

Allows you to store or change the number of your voice message center required when listening to your voice messages. You must obtain this number from your service provider.

An Info Message is text message broadcasted by the network. Previously called Cell Broadcasts, these messages provide general information, such as weather reports, traffic news, and stock market prices. Each type of information has an associated information type number.

When you receive a CB Message it is automatically displayed on the screen. If the message is too long, you can read it by scrolling up and down. A Location CB displays on the user text area. If it is too long to display on the screen, it will automatically scroll.

To access the Info Message option:

To access the Message menu, press the soft key in Standby Mode.

Press the soft key.

Press the or key to scroll to Info Message, and press the soft key.

Voice Mail

Menu 1-6

Info Message

Menu 1-7

1. Message

1 Write Message 2 Inbox 3 Outbox 4 Draft 5 Templates

6 Voice Mail

1. Message

2 Inbox 3 Outbox 4 Draft 5 Templates 6 Voice Mail

7 Info Message

7069

Message

You can set several features for the message service on your phone.

Settings

Menu 1-8

Read : Shows you incoming messages. Receive : Lets you view the last received messages. Topics : Allows you to receive broadcast messages about a particular

topic by adding the info message category in the phone or SIM memory.

Manual : Use to manually enter the ID and title for a new topic. You can also add a new topic to the list and remove a topic from the list.

All Channel : Allows you to receive all broadcast messages.

Languages : Allows you to select your preferred languages to display Info messages.

Alert : Allows you to select whether you are notified when you receive the broadcast messages.

The following options are available:

Access the Message Menu and select the 'Settings'sub menu option.

Select SMS and press the or key to scroll to the option you want to view/change and press the soft key.

SMS

Menu 1-8-1

To customize your phone for the message service:

1. Message

3 Outbox 4 Draft 5 Templates 6 Voice Mail 7 Info Message

8 Settings

7271

Message

SMSC : Allows you to store or change the number of your SMS center

required when sending and receiving messages. You must obtain this number from your service provider.

Status Report : Allows you to see the current status of SMS. Message Type : Allows you to select the message type. Validity Period : Allows you to set the length of time for which your

text messages will be stored at the message center while attempts are made to deliver them. The times available are 1 hour, 6 hours, 12 hours, 24 hours, 2 days, 1 week, and maximum.

Reply Path : Allows you to set up the reply path.

The following options are available:

MMS

Menu 1-8-2

To customize your phone for the message service:

To access the Message menu, press the soft key in Standby Mode.

Select Settings and then MMS by pressing the soft key.

Press the or key to scroll to the option you want to use and press the soft key.

Sending : Allows you to set many options regarding Sending MMS. Retrieval : Allows you to set options regarding network and delivery

report etc.

Filters : Allows you to filter messages. Network : Allows you to set Network Account, Bearer, MMSC, WAP

Gateway etc.

The following options are available:

Memory Status

Menu 1-8-3

Lets you view the current amount of memory used in your phone and SIM card.

7473

From Standby Mode, press the soft key, select the Call Register menu, then select Call History.

●

The Received Number list displays.

Press the or key to scroll to the number you want to view on the list.

When the number displays, press the key to dial the number.

Press the soft key for the following options.

●

Details

●

Extract No.

●

Delete

●

Delete All

Call Register

7675

Call Register

Your phone keeps track of calls made from your phone, received calls and missed calls. When you access the CALL Register menu, you can view the list of calls.

The numbers are continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.

Call History

Menu 2-1

If you subscribe to a Caller Identification Service, your phone will record information about the last 30 missed calls.

Missed No.

Menu 2-1-1

To view the missed numbers:

To view the received numbers:

If you subscribe to a Caller Identification Service, your phone will record information about the last 30 incoming calls.

Received No.

Menu 2-1-2

2. Call Register

1 Call History

2 Call Duration 3 GPRS Counter 4 Call Costs

From Standby Mode, press the soft key, select the “Call Register” menu, then select Call History.

With the Missed No. option selected press the soft key.

●

The Missed Number list displays.

Press the or key to scroll to the number you want to view on the list.

When the number displays, press the key to dial the number.

Press the soft key for the following options.

●

Details

●

Extract No.

●

Delete

●

Delete All

From Standby Mode, press the soft key, select the Call Register menu, then select Call History.

●

The Dialled Number list displays.

Press the or key to scroll to the number you want to view on the list.

When the number displays, press the key to dial the number.

Press the soft key for the following options.

●

Details

●

Send Message

●

Send MMS

●

Extract No.

●

Delete

●

Delete All

To exit the call record, press the key.

Call Register

7877

To view the dialed numbers:

If you subscribe to a Caller Identification Service, your phone will record information about the last 30 outgoing calls.

Dialed No.

Menu 2-1-3

This menu allows you to view the timers for calls that you made and received.

The following timers are available:

Call Duration

Menu 2-2

Shows the time of the last incoming call.

Last Incoming

Menu 2-2-1

Shows the time of the last outgoing call.

Last Outgoing

Menu 2-2-2

Shows the time of all incoming calls.

Total Incoming

Menu 2-2-3

Shows the time of all outgoing calls.

Total Outgoing

Menu 2-2-4

You can use the Reset option to reset the call timers; when the phone prompts you to confirm, press the soft key. The timers are reset.

��Note : The actual time invoiced for calls by your service provider

may vary, depending on network features, rounding-off for billing purposes, etc.

Reset

Menu 2-2-5

Call Register

2. Call Register

1 Call History

2 Call Duration

3 GPRS Counter 4 Call Costs

You can use the Reset option to reset the GPRS counter; when the phone prompts you to confirm, press the soft key. The GPRS Counter is reset.

��Note : GPRS is the abbreviation of General Packet Radio Service,

and enables to connect to the data network and to use information and multimedia service. In GPRS technology, the data is sent in 'packets' and is well suited to the sporadic nature of data application. The counter unit is byte.

Call Register

8079

Using this menu, you can check the volume of packets sent or received.

Access the

Call Register menu, and select the

GPRS Counter. Following options are available:

GPRS Counter

Menu 2-3

Displays the volume of last received data.

Last Received

Menu 2-3-2

Displays the volume of last sent data.

Last Sent

Menu 2-3-1

Displays the total volume of all received data.

Total Received

Menu 2-3-4

Displays the total volume of all sent data.

Total Sent

Menu 2-3-3

Call Register

Reset

Menu 2-3-5

2. Call Register

1 Call History 2 Call Duration

3 GPRS Counter

4 Call Costs

2. Call Register

1 Call History 2 Call Duration 3 GPRS Counter

4 Call Costs

This menu allows you to view Call Costs.

��Note : This menu is available if your SIM card

supports this function.

Call Costs

Menu 2-4

Allows you to see the cost for the last call you made.

Last Call’s Cost

Menu 2-4-1

Allows you to see the total cost of all calls you made.

All Call’s Cost

Menu 2-4-2

Allows you to reset all cost.

Cost Reset

Menu 2-4-3

Allows you to see the maximum cost you can make calls.

View Max Cost

Menu 2-4-4

Allows you to set the maximum available unit to calculate the maximum cost.

Set Max Cost

Menu 2-4-5

Allows you to set the price per unit.

Price/Unit

Menu 2-4-6

Profile

8281

Profile

This menu allows you to control the sound settings.

General

Menu 3-1

Activates the General mode and the options you selected.

Activate

Menu 3-1-1

Allows you to select sound options for Alert Type, Ring Tone and Ring Volume.

Personalise

Menu 3-1-2

Alert Type : You can select an alert mode for incoming calls. Press the or key to scroll through the available modes. Ring Tone : This menu allows you to select the melody to be played when you receive a call. Press the or key to select a melody category and the

or key to scroll through the available melodies. From the

melody list, you can select another melody category by pressing or key.

You can adjust the volume level by pressing the side volume key.

Ring Volume : You can adjust the volume level of the ring volume.

Message Tone : This menu allows you to select the melody to be played when you receive a message. Press the or key to scroll through the available melodies. Key Volume : You can adjust the key volume level of the key volume. Key Tone : This menu allows you to select the keypad sound each time you press a key. Folder Tone : This menu allows you to select the folder tone that sounds when you open and close the folder. Connect Alert : The phone sounds a connect tone when your call is connected to the system. Power On/Off Melody : When this option is selected, the phone will sound a melody whenever it is turned on/off.

The following options are available : (Menu 3-1-2)

This menu allows you to set up the sound options fitting for specific situation in advance. How to set up the specific options is all the same. Please, refer to the General Mode below.

Allows you to change the mode name.

Rename

Menu 3-1-3

3. Profile

1 General

2 Silent 3 Vibration Only 4 Outdoor 5 Other1 6 Other2

Setting

8483

Setting

Time/Date Set

Menu 4-1

This option enables you to set the current time in the format you prefer. When you select the Time Set, two fields are displayed. First, you can

select the time format of 24 hours or 12 hours. Use the or key to toggle between 24 hours and 12 hours for time format. If you select 24 hour format, go to the next field to enter the number for the time you want directly. Use the or key to move between the fields.

If you select a 12 hour format, AM and PM will be added and a total of three field options will appear. Select AM or PM then move to the next field to directly enter the time.

Time Set

Menu 4-1-1

Many different features of your phone can be customized to suit your preferences.

This option enables you to set the current date in the format you prefer in one screen.

Date Set

Menu 4-1-2

Date Format : Select a date format. The following formats are available:

• YYYY/MM/DD (year/month/day)

• DD/MM/YYYY (day/month/year)

• MM/DD/YYYY (month/day/year) Select a date format in the upper bar and enter the date in the

lower bar. Press the and key to move between the fields

Set Date : You can use the and key to move the cursor to the

digit. Enter the date using the number keypad and press the soft key.

The following options are available:

This feature allows you to:

• Set the alarm to ring at a specific time.

• Set the phone to ring the alarm at the specified time

even while the phone is switched off (Power Off Alarm is enabled).

Alarm Set

Menu 4-2

4. Setting

1 Time/Date Set

2 Alarm Set 3 Call Setting 4 Phone Settin.. 5 Security Sett.. 6 GPRS Setting

4. Setting

1 Time/Date Set

2 Alarm Set

3 Call Setting 4 Phone Settin.. 5 Security Sett.. 6 GPRS Setting

Press the soft key when Set Alarm is highlighted.

Select an alarm and press the soft key.

●

If you selected 24 hour mode in Time Set, 2 fields are displayed: upper field is to enter alarm time and the lower field is to select frequency option.

●

If you selected 12 hour mode in Time Set, 3 fields are displayed: the first field is to select AM/PM, the second field is to enter alarm time, and the third field is to select frequency option.

Select AM/PM using the or keys.

Enter the required time using the number keypad.

Choose an alarm frequency option using the or keys.

●One Time : The alarm rings only once and is then deactivated.

●Daily : The alarm rings every day at the specified time.

●Morning Call :

The alarm rings Monday to Friday at the specified time.

●Delete : Delete the alarm.

Press the soft key to save the setting.

●

An alarm check mark displays on the right of the alarm you set among Alarm 1/Alarm 2/Alarm 3 once you finish setting the alarm.

To stop the alarm when it rings, open the folder and press the soft key.

Setting

8685

Setting

Set Alarm

Menu 4-2-1

To set an alarm:

From the Alarm Set menu, press the or key to scroll to Power Off Alarm, and press the soft key.

If necessary, press the

key to select On.

●

If you want to cancel setting a power off alarm, select Off.

Press the soft key to save the setting.

��Note : If the phone is turned off at the specified alarm time,

it automatically turns on and sounds the alarm alert. You can stop the alarm when it rings by pressing the volume key. Then, the phone turns off automatically.

Alarm Sound Menu 4-2-2

Allows you to select an alarm sound. 14 pieces of melody and downloaded melody are available.

Power Off Alarm Menu 4-2-3

To set the alarm to ring when the phone is off:

Setting

8887

Setting

Some of the following menu functions are network services. Please contact your service provider to check their availability and subscribe to them.

Call Setting

Menu 4-3

This network service enables incoming calls to be rerouted to the number that you specify. This feature may be unavailable depending on the network.

Call Divert

Menu 4-3-1

Example : You can :

●

Divert fax calls to your office fax machine.

●

Divert voice calls to your colleague if you are already using the phone.

All Voice Calls : All voice calls are diverted. If Busy : Calls are diverted if you are already on another line. If Not Answered : Calls are diverted if you do not answer the

phone. If Out Of Reach : Calls are diverted if you are not in an area covered

by your service provider.

If Not Available : Calls are diverted if you are not available. All Data Calls : All data calls are diverted. All Fax Calls : All fax calls are diverted. Cancel Divert : All call diverting options are cancelled.

Call diverting can be set up in the following ways :

4. Setting

1 Time/Date Set 2 Alarm Set

3 Call Setting

4 Phone Settin.. 5 Security Sett.. 6 GPRS Setting

Select “Set Divert” to either divert the call to Voice Mail or to an alternative number. Enter the number to which the calls are to be diverted and press and hold the soft key.

●

To enter an international code, press and hold the 0 key until the + sign displays.

The phone sends your settings to the network and the network’s acknowledgement displays.

You can deactivate all call diverting settings by selecting the Cancel All option.

Select the situation when you want to divert a call.

Setting

9089

Setting

To set your call diverting options:

To Select

Display current status Status Activate call diverting Set Divert Deactivate call diverting Deactivate

To set your call waiting options:

This network service enables you to be informed when someone is trying to reach you during another call.

Call Waiting is only applicable for voice calls.

Select the Call Waiting option and press the soft key.

●The screen displays Status, Activate and Deactivate.

You can activate or deactivate the call waiting feature as necessary using the Activate or Deactivate soft key respectively.

Call Waiting

Menu 4-3-2

When this menu is set to On, you can send your phone number to the designated phone when making a call so that the recipient can see your phone number.

��Note : Some networks do not allow the user to change this

setting.

Send My Caller ID

Menu 4-3-3

On :

Your number displays on the other person’s phone.

Off :

Your number does not appear on the other person’s phone.

Set by Network :

The setting is determined by your network.

Upon accessing this menu :

Setting

9291

Setting

Answer Mode

Menu 4-3-4

This menu allows you to select how you answer when an incoming call comes in. Your phone is preset to answer when you press the key or soft key.

Min Minder

Menu 4-3-5

This menu allows you to specify whether or not the phone beeps during an outgoing call to keep you informed of the length of your call.

Auto Redial

Menu 4-3-6

When the Auto Redial function is On, the phone makes up to ten attempts to redial the phone number after an unsuccessful call.

��Note : The interval between two call attempts varies.

Auto Answer

Menu 4-3-7

You can set the phone to answer an incoming call. When this menu option is activated, the phone automatically answers calls after a predefined time.

Data Transfer Mode

Menu 4-3-8

Your phone is capable of sending and receiving digital data and fax calls when connected to a computing device, such as a laptop, desktop, handheld, or palmtop running Microsoft Windows NT, Microsoft Windows 95 or later versions. The phone functions just like a typical modem on your PC, enabling you to use wireless data involving a wide variety of Microsoft Windows software applications.

To use digital data or fax services with your phone, you need a digital data/fax kit. This kit contains the necessary cables and software required for you to connect and use your phone with your computing device.

��Note : The phone must be on a digital network to receive or

send fax and data. In the Data Transfer Mode menu, you can set up the call mode to use

data or fax calls as well as normal voice calls.

(Single No.) Voice :

Your phone sends or receives the voice call

if your SIM card allows this option.

(Single No.) Fax :

Your phone sends or receives the Fax call

if your SIM card allows this option.

(Single No.) Data :

Your phone receives the Data call

if your SIM card allows this option.

The following options are available :

Setting

9493

Setting

Making a Data or Fax Call

Choose "(Single No.) Data" item in phone menu.

Connect the phone to your computer with the cable.

After starting the software for network connecting (built in Microsoft Windows System), make the data service using the browser of Microsoft Windows System.

After using the Data Call, set the mode to "(Single No.) Voice"

Usage : Prior to using Data Call, you must first set your phone as a

modem in the Microsoft Windows system(Start > Settings > Control Panel > Modem or Telephone/Modem Option). Register your phone as a "standard 19200 bps modem" and set the COM port number to which the cable is connected. ( Set the port 115200 bit/sec)

Data Call : You set the software using the Windows system (Start > Settings > network connect), and use the data service. ( This service is related to net-work services. For more information, please contact your service provider )

Using a Data Call

To be able to use data or fax services, you need application software such as a data or a fax program. Before using these functions, you need to connect your phone to the computer and make sure that your phone is registered as a modem in your system.

Using a Data or Fax Call

Choose "(Single No.) Fax" item in phone menu.

Connect the phone to your computer with the cable.

After starting the software for Fax, use the Fax services.

After using the Fax Call, set the mode to "(Single No.) Voice"

Example : Fax Call :

1. Connect the phone to the computer using the cable.

2. Open WinFax 10.0 in Microsoft Windows.

3. Check that configuration is set to 19200 bps modem with the compatible

COM port.

4. Set the Receive Mode to AUTO RECEIVE. Otherwise, set MANUAL RECEIVE when the incoming animation plays.

Using a Fax Call

Setting

9695

Phone Settings

Menu 4-4

Language

Menu 4-4-1

You can set the display language. The available languages are

English, Russian, French, Germany, Spanish,

Italian, Portuguese, Polish and Turkish.

��Note : This setting does not affect the Web Browser.

Main LCD

Menu 4-4-2

You can set an image to be displayed on the main LCD in Standby Mode.

Select an image from the category.

User Text (Menu 4-4-2-3)

You can display your own greetings in Standby Mode. Create your own message of up to 40 English characters. For further details on how to enter text, see page 40.

Setting

Sub LCD

Menu 4-4-3

You can set an image to be displayed on the front LCD in Standby Mode.

Sub LCD Contrast (Menu 4-4-3-3)

Your Sub LCDs have contrast settings that can help you see the screen better in different lighting conditions.

Backlight

Menu 4-4-4

When the phone is attached to the optional Hands-Free Car Kit, the backlight remains on while the phone is on. At other times, you can set how long the backlight of the keypad remains on after the last key is pressed. Backlight drains your battery faster.

Screen Saver

Menu 4-4-5

The Screen Saver feature allows you to conserve your battery power by turning off the LCD screens when you do not use the phone.

��Notes :

●When you press a key or receive a call or message, the screen automatically turns on.

●When you press and hold the lower volume key with the folder closed, the sub LCD screen turns on.

●The screen saver will not work when you use the camera function.

4. Setting

1 Time/Date Set 2 Alarm Set 3 Call Setting

4 Phone Settin..

5 Security Sett.. 6 GPRS Setting

Setting

9897

Setting

Using this menu, you can activate use of the password for the personal menu and change the password.

Security Settings

Menu 4-5

PIN Code

Menu 4-5-1

Using this menu, you can activate the use of the PIN (Personal Identification Number) code provided by your SIM card and change the code if possible.

Enable PIN : When this option is selected, you must enter your PIN code each time you switch the phone on. Consequently, any person who does not have your PIN code cannot use your phone features without your approval, except to make emergency calls by pressing the soft key.

Disable PIN : When the option is selected, you don't have to enter your PIN code when you switch the phone on. Your phone connects directly to the network when you switch it on.

The following options are available :

Phone Lock

Menu 4-5-2

Using this menu, you can lock your phone to keep it from being used by unauthorized people. When the phone is locked, you cannot use any function.

You are prompted to enter the password when you try to enter the menu or make a call after turning the phone on. The password is preset to “0000”. To change the password, refer to the 'Change Codes' section on page 101.

Power on : You can lock/unlock the phone when the power is on or the SIM card is changed.

Immediately : You can immediately lock the phone.

The following options are available :

4. Setting

1 Time/Date Set 2 Alarm Set 3 Call Setting 4 Phone Settin..

5 Security Sett..

6 GPRS Setting

Setting

10099

Setting

Call Barring

Menu 4-5-3

The call barring network service allows you to restrict your calls. When you select this option, you are prompted to enter a password.

All Outgoing : Calls cannot be made. International : International calls cannot be made. Incoming When Roam : Calls cannot be received when you are

using your phone outside of your home service area. International Exc. Home : When abroad, calls can be made only to

numbers within the current country and to your home country, which is the country where your home network provider is located.

All Incoming : Calls cannot be received. For each of the above options, you can check the status, set barring

and cancel barring.

Following options are displayed :

To activate the call barring, select Activate.

To deactivate the call barring, select Deactivate.

●

The phone sends your setting to the network and the network's acknowledgement displays.

You can also deactivate all call barring settings by selecting the Cancel All option.

You can set and change the call barring password obtained from your service provider by using the Change password option. You must enter the current password before you can specify a new one. Once you have entered a new password, you are asked to confirm it by entering it again.

To set your call barring options :

Select the Call Barring, and you will be requested to enter current barring password.

●

Outgoing, International Calls, International Exc.Home, Incoming Call, Incoming When Roam and Cancel All Bars and Change Password will appear.

Select the type of calls to be barred by pressing the or key and then press the soft key.

Fixed Dial Number

Menu 4-5-4

Allows you to only call numbers on the Fixed Dial Number list.

On :

Allows you to activate this function.

List :

Allows you to see the FDN list.

Add :

Allows you to add phone numbers to the FDN list.

��Note : This menu is available only if your SIM card supports

FDN functionality.

The following options are available :

The Change Code feature allows you to change your current phone password to a new one.

Enter the current password and press the soft key.

Enter a new password and press the soft key.

To clear the last entry, if necessary, press the soft key. Press and hold the soft key to clear all entries.

Pin code/PIN2 code(Menu 4-5-6-1/4-5-6-2)

This option allows you to change your current PIN to a new one, provided that the Enable PIN feature is enabled.

1. Enter the current PIN and press the soft key.

2. Enter a new PIN and press the soft key.

To clear the last entry, if necessary, press the soft key. Press and hold the soft key to clear all entries.

Setting

102101

Setting

Change Codes

Menu 4-5-5

Barring code :

You can set and change the call barring password obtained from your service provider by using this option. You must enter the current password before you can specify a new one. Once you have entered a new password, you are asked to confirm it by entering it again.

The following options are available :

This menu allows you to set GPRS options.

��Note : This menu is available only when your

phone is connected with GPRS network.

GPRS Setting

Menu 4-6

GPRS Session

Menu 4-6-1

Always online : Allows your phone to always be connected with GPRS service.

When needed : Allows you to use GPRS as needed.

Following options are displayed :

4. Setting

1 Time/Date Set 2 Alarm Set 3 Call Setting 4 Phone Settin.. 5 Security Sett..

6 GPRS Setting

Setting

104103

Setting

The Network Selection feature enables you to automatically or manually select the network used when roaming outside of your home area.

��Note : You can select a network other than

your home network only if it has a valid roaming agreement with your home network.

Network Select

Menu 4-7

This menu allows you to reset the phone. Resetting the phone restores the default value of all of the menu settings.

When you select the factory set, the message “Are You Sure?” will be displayed. Select soft key and your phone will ask you to enter the password. Enter the 4-digit password and press the soft key. The default value is set.

The default phone password is “0000”. For further details about the password, see page 97.

Factory Set

Menu 4-8

Press the or key until the appropriate option highlights and then press the soft key.

●

If you select Automatic, you are connected to the first available network on the preferred list when roaming.

●

If you select Manual, the phone scans for the available networks. Go to Step 2.

Press the

key until the preferred network highlights and

then press the soft key.

●

You are connected to that network.

To automatically or manually select the network when roaming:

4. Setting

2 Alarm Set 3 Call Setting 4 Phone Settin.. 5 Security Sett.. 6 GPRS Setting

7 Network Sele..

4. Setting

3 Call Setting 4 Phone Settin.. 5 Security Sett.. 6 GPRS Setting 7 Network Sele..

8 Factory Set

Organizer

106105

Organizer

Phonebook

Menu 5-1

You can store up to 1,000 entries and their corresponding names and numbers in the Phonebook.

Group Search

Menu 5-1-2

Allows you to view the list of phone numbers assigned to many groups.

In Standby Mode, press the soft key, press the

key to scroll to Group Search and press

the soft key.

Press the or key to scroll to a group you are looking for and press the soft key.

In Standby Mode, press the soft key.

●

The PHONEBOOK options display.

Press the or key to scroll to Name Search and press the soft key.

●

When you enter the Name Search mode, Quick Search Edit Box is displayed. When you key any letter, the phone shows you the search list.

��Note : If you don't press any key for 10 seconds, Quick Search

Edit Box will disappear.

Enter the name and press the soft key.

��Note : For information on how to enter text, see page 40.

The phone searches for the names on the list containing that character(s), and then displays the first name in that section of the list.

If you want another entry, press the

key to scan through

the list.

Press the key to dial the number of the entry.

●

If you press the soft key when you select a Phonebook entry, you can use the following options - Edit, Call, Send Message, Send MMS, Copy, Delete.

Name Search

Menu 5-1-1

5. Organizer

1 Phonebook

2 Scheduler 3 File Manager

Press the key to move to the next field.

●

4 Phone Number fields and 1 E-mail field are available.

●

Press the key to activate the field.

●

Press the key to delete the number one by one and press the soft key to save.

●

Press the key to go to the next Phone Number field.

●

Repeat the steps shown above to save other phone numbers including home phone, office phone, mobile phone and fax number.

Press the key to go to the E-mail field.

●

Press the key to activate the field and enter the e-mail address.

Press the key to go to the Group Select field.

●

Press the or key to change to the caller group you want.

Press the soft key. The Save popup window appears and the number is automatically saved in the first available location in the phone.

●

The phone automatically returns to Standby mode.

Enter the number you want to store.

Press the soft key to go directly to the Add Entry menu of the Phonebook, then select whether you wish to save the number on your SIM or Phone memory.

●

If you selected 'Phone and SIM' option in 'Memory in use' option, the Selection menu window appears for you to select where you are going to store the phone number. You can select either Phone or SIM to store the number. Please, refer to page 116 for more information regarding 'Memory in use' option.

Press the or key to move to the fields you want such as Name field, Phone Number field and E-mail Field.

●

To enter the name for the phone number you entered, press the key to go to the Name field.

●

Press the key to activate this field. Enter the name and press the soft key.

●

For information about how to Enter the name you want to store, see page 40.

Organizer

108107

Organizer

You can store a phone number in the internal Phonebook in two different ways.

To store a phone number in Standby Mode without accessing the Phonebook menu:

Add Entry

Menu 5-1-3

In Standby Mode, press the soft key.

●

The PHONEBOOK options display.

Press the or key to scroll to Add Entry and press the soft key.

Press the or key to scroll to Phone and press the soft key.

Press the or key to move to the fields you want such as Name field, Phone Number field and E-mail Field.

●To enter the name for the phone number you entered,

press the key to go to the Name field.

●Press the key to activate this field. Enter the name and press

the soft key.

●For information about how to enter text, see page 40.

Press the key to move to the next field.

●4 Phone Number fields and 1 E-mail field are available.

●Press the key to activate the field.

●Press the soft key to delete the number one by one and

press the soft key to save.

●Press the key to go to the next Phone Number field.

●Repeat the steps shown above to save other phone numbers

including home phone, office phone, mobile phone and fax number.

Press the key to go to the E-mail field.

●Press the key to activate the field and enter the e-mail address.

●For more information about how to enter e-mail address,

see page 40.

Organizer

110109

Organizer

Saving on Phone memory

Press the key to go to the Group Select field.

●Press the or key to select the caller group you want.

Press the soft key.

●The Save popup window appears and the number is automatically

saved in the first available location in the phone.

To store a phone number by using the Phonebook menu :

In Standby Mode, press the soft key.

●

The PHONEBOOK options display.

Press the or key to scroll to Add Entry and press the soft key.

Press the or key to scroll to SIM and press the soft key.

Press the or key to move to the fields you want.

●To enter the name for the phone number you entered,

press the key to go to the Name field.

●Press the key to activate this field. Enter the name and press

the soft key.

●Repeat the steps shown above to save the phone number.

●For information about how to enter text, see page 40.

Press the key to go to the Group Select field.

●Press the or key to select the caller group you want.

Press the key to go to the SIM address field.

●Press the or key to select the SIM address you want.

Press the soft key.

●The save popup window appears, and the number is saved in the

SIM address you selected in the SIM.

Saving on SIM

In Standby Mode, press the soft key.

●

The PHONEBOOK options display.

Press the or key to scroll to Speed Dials and press the soft key.

●

The Speed Dials list displays.

Press the or key to select an empty location from 2 to 9 and press the soft key.

Organizer

112111

Organizer

Once you have created Phonebook entries, you can assign a speed dial number to a selected Phonebook entry. Then, you can speed-dial the Phonebook entry with one key press. You can assign up to 8 speed dials.

To assign a speed dial number :

In Standby Mode, press and hold the speed dial number from 2 to 9 for about 2 seconds.

The phone number that was stored in the speed dial location dials.

To speed-dial a number :

��Note : Speed Dial location 1 is reserved for your Voice Center

number.

Search the phonebook entry by entering the first few letters of the name and press the soft key.

●

For information on how to enter the name, see page 40.

●

The list of the names beginning with the characters you entered displays.

Press the or key to scroll through the names on the list.

When you find the name, press the soft key.

●

The name displays on the Speed Dials list.

To return to Standby Mode, press the key.

Speed Dials

Menu 5-1-4

In Standby Mode, press the soft key.

●

The PHONEBOOK options display.

Press the or key to scroll to PB Manage and press the soft key.

Press the

key to select an option and press the soft

key.

In Standby Mode, press the soft key.

●

The PHONEBOOK options display.

Press the or key to scroll to Speed Dials and press the soft key.

●

The Speed Dials list displays.

Press the or key to select the speed dial location and press the soft key.

If there is no entry in the location you selected, Name Search screen will appear.

●

Enter the name you’re searching for. All matching entries will appear.

●

If there is an entry in the location you selected, the phone shows the name and phone number stored in the location. Press the soft key.

Organizer

114113

Organizer

To change or delete the speed dial assignment :

Press the or key to select to either edit or delete the entry and press the soft key.

To return to Standby Mode, press the key.

You can use caller groups to add Phonebook entries to a caller group so that the phone alerts you in a particular ring when the person in the group calls you. 6 groups are available with your phone and you can change the name of each group.

Caller Groups

Menu 5-1-5

The PB Manage option in the Phonebook menu allows you to manage your phonebook.

PB Manage

Menu 5-1-6

To access the PB Manage option :

Organizer

116115

Organizer

This option allows you to :

●Store your own phone numbers with a name.

●Edit the names and number.

Once you store the numbers, you can see the number list when you access the Own Number menu.

Own Number

This option allows you to copy or move all contents of the phonebook from either your phone memory or SIM card to the other.

Copy All

This option allows you to delete all contents of the phonebook in your phone memory or SIM card.

Delete All

This option allows you to select which storage you are going to access for the Phonebook contents. You can select either Phone, SIM or both of them.

Memory In Use

Scratch Pad

This option allows you to check how many entries are currently stored in Phonebook; SIM card and Phone memories. You can also see the capacity of both memories.

Memory Status

You can use the following PB Manage options :

This option allows you to view the number saved using the Scratch Pad feature during a call. For details about using the Scratch Pad, see page

36. To save the displayed number, press the soft key. You can make a call directly using this function directly.

Service Numbers

This menu is only available if your SIM card supports the 'Service Numbers' function. The SIM card contains several sets of phone numbers. However, your network operator can put their own service numbers (message box, customer service etc.) into this special directory.

Organizer

118117

Organizer

You can store up to 50 events in your Scheduler. It covers the period from 1, January, 2000 to 31,

December, 2040.

Scheduler

Menu 5-2

This menu can show you the information about the daily event.

Press soft key to show more detailed information after selecting by the or key.

Press soft key to edit the content and to transfer to weekly view or monthly view.

Daily View Menu 5-2-1

This Menu can show you the information about the weekly event.

The and key are used to select the date and the and

key are used to select the time.

Press soft key to show more detailed information after selecting a date by using the or key.

When you search for a date, a scheduled event is highlighted with a colored bar.

If you want to edit or delete the event, press the soft key after selecting the date by pressing the key.

Weekly View Menu 5-2-2

5. Organizer

1 Phonebook

2 Scheduler

3 File Manager

Organizer

120119

Organizer

This Menu can show you the information about the monthly event. In this menu, ‘Today’ is marked in violet.

When you search the date by pressing the

and

key, if the selected date has a scheduled event,

a color bar appears.

If you press the key at the date you want to make the event, you can see the more detailed information.

If you want to edit or delete the event, press the key and then press the soft key after operating step 2.

Monthly View Menu 5-2-3

To add a new event, you should select Category first by pressing

key.

You can set up Subject, Location, Start time, End Time, Repeat, Description or Alarm information by pressing

key after selecting a category.

If you select Call in the Category setting value, you are allowed to set up Subject, Call Time or Call Number.

Press soft key to select a phone number from your Phonebook when you set up a Call Number.

Make Menu 5-2-4

This menu allows you to delete all Schedule events you stored at the same time. Once you select this menu, a confirmation window appears. Press the soft key to delete all Schedule events.

Delete All Menu 5-2-5

This menu allows you to view saved events.

Press

key to select Date Format or Week Start.

You can change the setting value by pressing

key.

You can change the date format displayed at the upper part of Scheduler by changing the Date Format setting value.

You can make Monday or Sunday start a week in your Monthly View and Weekly View by changing Week Start setting value.

Setting Menu 5-2-6

Organizer

122121

Organizer

You can store up to 50 ToDo tasks.

You can view, store or delete ToDo data by pressing

key.

View ToDo List (Menu 5-2-7-1)

This menu allows you to view all ToDo lists.

1. Select a ToDo item by pressing or Key and press soft key to view its detailed information.

2. You can view, add, edit, delete or sort a ToDo item by pressing soft key.

Add ToDo (Menu 5-2-7-2)

This menu allows you to add a new ToDo item.

You can set up Subject, Due Date, Status and Priority information by pressing or key.

Delete All (Menu 5-2-7-3)

This menu allows you to delete all ToDo items at once.

Once you select this menu, a confirmation window appears. Then, press the soft key to delete all ToDo data.

ToDo Menu 5-2-7

Displays the total size, used size and remaining size of your phone’s memory.

Memory Status Menu 5-3-1

You can manage and view the size of image and sound used in the phone and set image files as wallpaper.

File List Menu 5-3-2

File Manager

Menu 5-3

5. Organizer

1 Phonebook 2 Scheduler

3 File Manager

- Time : Use the or to select the time to take a photo from 0, 2 or 10 seconds.

Multi shot : Use the or to select how many shots you take

in series.

After shooting the image, press the soft key to save it into Image Album. Press the "Rename" to change the name of the image.

��Note : If you select the "PBook photo" in the Size Option and

take a photo, you can save the image into the PBook Album automatically by pressing( ).

Camera

124123

Camera

In this menu, you can take a photo, save it as an image photo or PBook photo.

There are two ways to access the camera. If you press the key or select the Camera menu in the Standby mode, the camera menu will be displayed.

Zoom : Use the or to adjust the zoom from 1 to 5 level.

Exposure : Use the or to adjust the contrast from 1 to 8

level.

Effect : Use the or to select various effects to the image.

Size : Use the or to define the size of the image.

- Quality : Use the or to adjust the quality of the image among good, normal and fine.

In this menu, you can take a photo and save it as an image or PB Photo. The following options are available :

Shooting

Menu 6-1

6. Camera

1 Shooting

2 Special Effect 3 Album 4 Configuration

Camera

126125

In this menu, you can take a photo with various sticker frames or couple frames. It has the same functions as the Shooting menu explained above except for the PBook photo and the Multi shot functionality which will not be supported in this menu.

Special Effect

Menu 6-2

In this menu, you can select Shutter Sound, Album Lock, Set Save Name or Auto Save function.

Shutter Sound : You can select shutter sound. Album Lock : The password will be asked either to Enable or to Disable

the Album Lock. Access is granted only when the password is correctly entered.

Set Save Name : You can define the save name of the photo you take. That name can be changed in Rename menu.

Auto Save : If you enable Auto Save, as soon as you take a photo, the image will be automatically saved. However, if you disable this, you can save the image by pressing the soft key.

Configuration

Menu 6-4

In this menu, you can select Image Album or PBook Album to display the image photo that you saved. If you press the Menu on the left side of the each image in the Image Album, Go To Menu, Set Wallpaper, Delete, Delete All and Rename will be displayed. If you select the Set Wallpaper, the image

you chose will be displayed as a Wallpaper. At the Image Album, if you press the soft key, you can insert an unique stamp image into the photo stored in this album. If you press the Menu on the left side of the each image in the PBook Album, Go To Menu, Delete, Delete All and Rename will be displayed. If you select the Rename, you can change the file name of it.

�� Note : You may not set the image as Wallpaper if file memory is full.

Album

Menu 6-3

Camera

6. Camera

1 Shooting

2 Special Effect

3 Album 4 Configuration

6. Camera

1 Shooting 2 Special Effect

3 Album

4 Configuration

6. Camera

1 Shooting 2 Special Effect 3 Album

4 Configuration

Enter the first number using the numeric keys.

●The number displays in the upper box.

��Notes :

●To clear the last entry, press the soft key. Press and hold the key to clear all of the entries from the display.

●To enter a decimal point, press the key.

●To enter a ‘+’ or ‘-’ in front of a number, press the key after you

enter a number.

Press the navigation key to set the operation for your calculation referring to the screen; + (add), - (subtract), x (multiply), ÷ (divide).

Enter the second number.

To calculate the result, press the = soft key.

To reset the calculator, press and hold the soft key.

Application

128127

Application

This menu allows you to use your phone as your assistant providing you with various convenient features, such as Scheduler and Calculator.

You can play ”Othello” on your phone. To stop playing a game, press the key or close the folder.

When you enter the game again, the game asks you whether you want to continue the previous game or not.

Othello

Menu 7-1

You can use your phone as a calculator, which provides the basic arithmetic functions; addition, subtraction, multiplication and division.

Calculator

Menu 7-2

Performing a Calculation

7. Application

1 Othello

2 Calculator

3 Unit Converter 4 World Time 5 Voice Memo

7. Application

1 Othello

2 Calculator 3 Unit Converter 4 World Time 5 Voice Memo

Press the or key to scroll to the unit category. Length, Weight, Volumes, Surface, and User Define are available.

●

The User Define option allows you to set the specified rate as required.

Press the soft key.

Enter the value to be converted using the number keypad.

●

The number appears in the Inbox.

●

If necessary, press the soft key to clear the last entry.

Press the key to move down to the first unit box. Press the or key to select the original unit.

Press the key to move down to the second unit box. Press the or key to select the required unit to convert

the value with.

The converted value automatically displays in the Outbox.

To reset the converter, move up to the Inbox and press and hold the soft key.

Select the city corresponding to your time zone by pressing the or key one or more times.

●

The local date and time display.

If you want to know other cities in the time zone, press the or key one or more times.

When you find your time zone, press the soft key.

Application

130129

Application

This menu allows you to convert a unit into another unit, such as inches to centimeters.

Unit Converter

Menu 7-3

To use the unit converter :

This feature allows you to check the current time for 59 major cities around the world. You can also set your time zone for displaying the date and time in Standby Mode.

When you access the World Time menu, the display shows the:

●

Current date and time ●City name

World Time

Menu 7-4

To select your time zone :

This menu allows you to record a memo with your voice or any sound.

Voice Memo

Menu 7-5

Record : This option allows you to record

your voice for 60 seconds. Play : This option allows you to play the voice

memo. You can select one of the memos you recorded by pressing or key.

Delete All : This option allows you to delete all stored voice memos.

Following options are available

7. Application

1 Othello 2 Calculator

3 Unit Converter

4 World Time 5 Voice Memo

7. Application

1 Othello 2 Calculator 3 Unit Converter

4 World Time

5 Voice Memo

7. Application

1 Othello 2 Calculator 3 Unit Converter 4 World Time

5 Voice Memo

Java

132131

You can download Java contents from the network. Contents you downloaded are added to the list.

��Note : Before you use this menu, you must

confirm that your service provider supports it.

Downloads

Menu 8-1

In this menu, you can view the total and used memory amounts for Java contents.

Memory Status

Menu 8-2

In this menu, you can store the following information for Java application to use Network(Data Service) function.

Network

Menu 8-3

Java

On the Midlets menu, press the menu soft key to show the following options.

Launch : Launches the selected Midlet. Info : Show the Midlet information. Remove : Allows you to remove the Midlet.

Using Java Midlet menu

APN : Operator's Access Point Name User name : User Identification Password : Password

Using Network menu

8. Java

1 Downloads

2 Memory Status 3 Network

8. Java

1 Downloads

2 Memory Status

3 Network

8. Java

1 Downloads 2 Memory Status

3 Network

��Note : To access the startup homepage from any other screen in

the WAP Browser, use the key.

Your phone comes equipped with a WAP (Wireless Application Protocol) Browser, making it possible for you to access the Wireless Web. Note that this feature may be unavailable or vary depending on your network.

The WAP Browser allows you to access up-to-the-minute information via your phone and view specially designed text versions of popular Internet sites, including Yahoo!

, CNN MobileSMand the Weather

Channel

Browsing the Wireless Web using your phone is unlike using your computer, in that site providers select only the critical aspects of their sites for wireless phone users and remove most graphics.

Each time you start the WAP Browser, the phone connects to the Wireless Web. You are billed, after you are connected to the Wireless Web.

The WAP Browser ends the network connection after a certain period of inactivity and automatically reconnects as necessary. For this reason, you may find that you are billed for several network connections within a single session. This is normal and is designed to minimize your bill.

To quickly access the

Internet menu from Standby Mode,

press the key.

Internet

134133

Internet

This menu connects your phone to the Internet. A connection is established with your service provider and the corresponding homepage displays.

The content of the WAP browser’s startup homepage depends on your Wireless Web service provider. To scroll through the screen, use the and keys.

Homepage

Navigating the WAP Browser

To Press the

or key until the Scroll through and item is indicated by the cursor, select browser items and then press the key to

confirm the selection. Select a numbered item Corresponding numeric key. Return to the previous page soft key. Return to the startup

soft key, and then select Home

homepage

Exiting the WAP Browser

To exit the browser, press the key at any time.

9. Internet

Homepage

Bookmarks Recent Pages Enter Address Resume Settings

Internet

136135

Internet

You can set a bookmark for most pages so that they can then be accessed directly from any web page. Bookmarks save you time by reducing the number of steps required to access a given page.

Bookmarks

Add Bookmark

To access the bookmarks list, press the or key to highlight Add Bookmark and press the soft key.

You can edit and add bookmarks.

Create new folder

To create a new folder, press the or key to highlight Create new folder and press the soft key.

You can edit the folder name and create it.

9. Internet

Homepage

Bookmarks

Recent Pages Enter Address Resume Settings

Press the key to access the Internet menu and press the soft key to select Recent Pages.

In the Recent Pages Menu, press the or key until you locate the recent page you want to view. Press the soft key to select it. Your phone will be connected to the recent site.

Recent Pages

9. Internet

Homepage Bookmarks

Recent Pages

Enter Address Resume Settings

Internet

138137

Internet

In this menu, you can manually enter the address of a web page and go there immediately.

Press the key to access the Internet menu and press the soft key to select the Enter Address.

Press the or key to select a URL prefix, and press the soft key.

Enter the address of the web page.

●

For details on how to enter text, see page 40.

Press the soft key to go to the page.

Enter Address

In this menu, you can resume the previous browsing session by loading the page last visited. Note that the Back option will be available for pages visited during this session.

Resume

9. Internet

Homepage Bookmarks Recent Pages

Enter Address

Resume Settings

9. Internet

Homepage Bookmarks Recent Pages Enter Address

Resume

Settings

In this menu, you can configure the browser with different connection type, proxy address and browser options.

Press the key to access the Internet menu and press the soft key to select the Settings.

Press the or key to select one of the following options.

Settings

Edit Homepage

In this menu, you can edit the homepage.

Select Profile

In this menu, you can select profile for WAP browser. You should select the profile first before starting to browse. If you try to change any setting or to load a page without selecting a profile first, an alarm dialogue is displayed, informing that you should select a profile first.

9. Internet

Homepage Bookmarks Recent Pages Enter Address Resume

Settings

Internet

140139

Internet

Connection

In this menu, you can set the connection. You should select a profile before using this function.

Bearer : Allows you to set bearer by selecting CSD or GPRS. GPRS setting : Allows you to edit APN, User name and Password. Connect type : Allows you to set connection type by selecting HTTP

or WSP CO. Timeout : Enables you to set the timeout value to wait for a

response in the number of seconds. Proxy Address : Enables you to specify a proxy gateway to be used

for connecting.

Proxy Port : Enables you to specify proxy port number. Proxy Secure Port : Enables you to change the port number. Security : Allows you see or delete information about certificate.

Following options are available

Rename Profile

In this menu, you can change the name of the currently selected profile.

Clear Recent Page List

In this menu, you can clear the recent page saved in your browser.

In this menu, you can decide whether you use cookie or not and clear information about cookie.

Cache

In this menu, you can decide whether you use cache or not and clear information in cache.

Reference Information

142141

Internet

Reference Information

There are several access codes that are used by your phone and its SIM card. These codes help you protect the phone against unauthorized use.

Access Codes

Phone Password

The phone password can be used to avoid unauthorized use of your phone. The password “0000” is usually supplied with the phone. Change the password before you start using your phone. Keep the new password secret and in a safe place, which is separate from the phone.

PIN code

The PIN (Personal Identification Number) code protects your SIM card against unauthorized use. The PIN code is usually supplied with the SIM card. When the PIN code request is enabled (Menu 4-5-1), the code is asked each time the phone is switched on.

If you key in an incorrect PIN code three times in succession, key in the PUK code and press the soft key. Key in a new PIN code and press the soft key. Key in the new code again and press the soft key.

This menu allows you to view WAP Push Message. Inbox : WAP Push Messages you receive are stored in

this box.

Push

9. Internet

Bookmarks Recent Pages Enter Address Resume Settings

Push

Reference Information

PUK code

The PUK (PIN Unblocking Key) code is required to change a blocked PIN code. The PUK code may be supplied with the SIM card. If not, contact your local service provider for the code.

If you key in an incorrect PUK code ten times in succession, the SIM card cannot be used anymore. Contact your service provider for a new card.

You cannot change the PUK code. If you lose the code, contact your service provider.

PIN2

The PIN2, supplied with some SIM cards, is required to access some functions, such as changing unit counts. These functions are only available if support by your SIM card.

If you key in an incorrect PIN2 three times in succession, key in the PUK2 and press the soft key to unlock the phone. Key in a new PIN2 and press the soft key. key in the new PIN2 again and press the soft key.

PUK2 code

The PUK2 code, supplied with some SIM cards, is required to change a blocked PIN2 code.

If you key in an incorrect PUK2 code ten times in succession, you cannot use the functions requiring the PIN2 code. Contact your service provider for a new card.

You cannot change the PUK2 code. If you lose the code, contact your service provider.

Barring code

The 4-digit barring password is required when you use the Call Barring function. You can obtain the password from your service provider when you subscribe to this function. See page 99 for further details.

Reference Information

Your phone is powered by a rechargeable Li-ion standard battery.

Using the Batteries

Precautions When Using Batteries

●Never use any charger or battery that is damaged in any way.

●Use the battery only for its intended purpose.

●If you use the phone near the network’s base station, it uses less

power; talk and standby times are greatly affected by the signal strength on the cellular network and the parameters set by the network operator.

144143

Reference Information

Safety Information

Traffic Safety

Do not use a hand-held mobile phone while driving a vehicle. If using a hand-held phone, park the vehicle before conversing. Always secure the phone in its holder, do not place the phone on the passenger seat or where it can break loose in a collision or sudden stop.

The use of an alert device to operate a vehicle’s lights or horn on public roads is not permitted.

Remember, road safety always comes first!

Reference Information

Operating Environment

Remember to follow any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference of danger.

When connecting the phone or any accessory to another device, read its user’s guide for detailed safety instructions. Do not connect incompatible products.

As with other mobile radio transmitting equipment, users are advised that for the satisfactory operation of the equipment and for the safety of personnel, it is recommended that the equipment should only be used in the normal operating position (held to your ear with the antenna pointing over your shoulder).

●Battery charging times depend on the remaining battery charge and the type of battery and charger used. The battery can be charged and discharged hundreds of times, but it will gradually wear out. When the operation time (talk time and standby time) is noticeably shorter than normal, it is time to buy a new battery.

●If left unused, a fully charged battery will discharge itself over time.

●Use only approved batteries and recharge your battery only with

approved chargers. When a charger is not in use, disconnect it from the power source. Do not leave the battery connected to a charger for more than a week, since overcharging may shorten its life.

●Extreme temperatures will affect the charging capacity of your battery: it may require cooling or warming first.

●Do not leave the battery in hot or cold places, such as in a car in summer or winter conditions, as you will reduce the capacity and lifetime of the battery. Always try to keep the battery at room temperature. A phone with a hot or cold battery may temporarily not work, even when the battery is fully charged. Li-ion batteries are particularly affected by temperatures below 0 °C (32 °F).

●Do not short-circuit the battery. Accidental short circuiting can occur when a metallic object (coin, clip or pen) causes a direct connection between the + and - terminals of the battery (metal strips on the back of the battery), for example when you carry a spare battery in a pocket or bag. Short-circuiting the terminals may damage the battery or the object causing the short-circuit.

●Dispose of used batteries in accordance with local regulations. Always recycle. Do not dispose of batteries in a fire.

146145

Reference Information

Other Medical Devices

Operation of any radio transmitting equipment, including cellular phones, may interfere with the functionality of inadequately protected medical devices. Consult a physician or the manufacturer of the medical device to determine if they are adequately shielded from external RF energy or if you have any questions. Switch off your phone in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles (for example, electronic fuel injection systems, electronic anti-skid (anti-lock) braking systems, electronic speed control systems, air bag systems). Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Switch your phone off in any facility where posted notices so require.

Reference Information

Electronic Devices

Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your mobile phone.

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 6 inches (20 cm) be maintained between a hand-held mobile phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research. Persons with pacemakers:

●Should always keep the phone more than 6 inches (15 cm) from their pacemaker when the phone is switched on;

●Should not carry the phone in a breast pocket;

●Should use the ear opposite the pacemaker to minimize the potential

for interference.

If you have any reason to suspect that interference is taking place, switch off your phone immediately.

Hearing Aids

Some digital mobile phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider.

148147

Reference Information

Vehicles

Only qualified personnel should service the phone, or install the phone in a vehicle. Faulty installation or service may be dangerous and may invalidate any warranty which may apply to the unit.

Check regularly that all mobile phone equipment on your vehicle is mounted and operating properly.

Do not store or carry flammable liquids, gases or explosive materials in

the same compartment as the phone, its parts or accessories. For vehicles equipped with an air bag, remember that an air bag inflates

with great force. Do not place objects, including both installed or portable wireless equipment in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Switch off your phone before boarding an aircraft. The use of mobile phones in an aircraft may be dangerous to the operation of the aircraft, disrupt the wireless telephone network and may be illegal.

Failure to observe these instructions may lead to the suspension or denial of telephone services to the offender, or legal action, or both.

Reference Information

Potentially Explosive Atmospheres

Switch off your phone when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Users are advised to switch off the phone while at a refueling point (service station). Users are reminded of the need to observe restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas), chemical plants or where blasting operations are in progress.

Areas with a potentially explosive atmosphere are often but not always clearly marked. They include below deck on boats; chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust or metal powders; and any other area where you would normally be advised to turn off your vehicle engine.

150149

Reference Information

Before a phone model is available for sale to the public, it is tested to confirm compliance with the guidelines. The tests are performed in positions and locations (e.g. at the ear) that conform to a uniform testing methodology determined by an expert standards body.

The highest SAR value for this model phone when tested for use at the ear is **(0.856)** w/kg. Whilst there may be differences between the SAR levels of various phones and at various positions, they all meet the governmental requirement for safe exposure.

Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.

* The SAR limit recommended by international guidelines (ICNIRP) for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged over ten (10) grams of tissue. The limit incorporates a substantial margin for safety to give additional protection for the public and to account for any variations in measurements.

** CENELEC is a European Union Standard Body.

Reference Information

Radio Frequency (RF) Signals

This Lobster 485 model meets international standards for exposure to radio waves.

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. These guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate or SAR. Under the guidelines for your phone model, the SAR limit is 2.0 W/kg*.

Tests for SAR are conducted in accordance with CENELEC** testing procedures using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone whilst in operation can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the phone.

152151

Reference Information

Your phone is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you to fulfill any warranty obligations and allow you to enjoy this product for many years. When using your phone:

●Keep it and all its parts and accessories out of small children’s reach.

●Keep it dry. Precipitation, humidity and liquids contain minerals that

will corrode electronic circuits.

●Do not use or store it in dusty, dirty areas as its moving parts can be damaged.

●Do not store it in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.

●Do not store it in cold areas. When the phone warms up (to its normal operating temperature), moisture can form inside the phone, which may damage the phone’s electronic circuit boards.

●Do not drop, knock or shake it. Rough handling can break internal circuit boards.

●Do not use harsh chemicals, cleaning solvents, or strong detergents to clean it. Wipe it with a soft cloth slightly dampened in a mild soapand-water solution.

●Do not paint it. Paint can clog the device’s moving parts and prevent proper operation.

●Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications of attachments could damage the phone and may violate regulations governing radio devices.

●If the phone, battery, charger, or any accessory is not working properly, take it to your nearest qualified service facility. The personnel there will assist you, and if necessary, arrange for service.

Care and Maintenance

154153

Glossary

Airtime

Actual time spent talking on the wireless phone. Most carriers bill customers based on how many minutes of airtime they use each month.

Antenna

A device for transmitting or receiving signals. The size and shape of antennas is determined, in part, by the frequency of the signal they receive. Wireless phones and the base station must have antennas.

Call Barring

Ability to restrict outgoing and incoming calls.

Call Diverting

Ability to reroute calls to another mobile or fixed line.

Call Holding

Ability to put one call on standby while answering or making another call; you can then switch between the two calls, as required.

Call Waiting

Ability to inform users that they have an incoming call when engaged on another call.

Conference Calling

Ability to establish a conference call involving up to five additional parties.

DTMF(Dual-tone Multi Frequency ) You send DTMF signals when you enter numbers by pressing the digit keys.

Hands-Free

A feature that permits a driver to use a wireless phone without lifting or holding the handset - an important safety feature for automobiles, tractors and most other motorized vehicles.

GSM(Global System for Mobile Communication) International standard for cellular communication, guaranteeing compatibility between the various network operators. GSM covers most European countries and many other parts of the world.

LCD(Liquid Crystal Display) Commonly used to refer to the screen display on the wireless phone.

PIN(Personal Identification Number) Security code that protects the phone against unauthorized use. The PIN is supplied by the service provider with the SIM card. It may be a four to eight-digit number and can be changed, as required.

PUK(PIN Unblocking Key) Security code used to unlock the phone when an incorrect PIN has been entered three times in succession. The eight-digit number is supplied by the service provider with the SIM card.

Glossary

156155

Glossary

Voice Mail

Computerized answering service that automatically answers your calls when you are not available, plays a greeting (optionally in your own voice) and records a message.

Wireless

Radio-based Systems that allow transmission of telephone or data signals through the air without a physical connection, such as a metal wire (copper) or fiber optic cable.

Roaming

Use of your phone when you are outside your home area (when travelling for example).

SDN(Service Dialing Numbers) Telephone numbers supplied by your network provider, giving access to special services, such as voice mail, directory inquiries, customer support and emergency services.

SIM(Subscriber Identification Module) Card containing a chip with all the information required to operate the phone (network and memory information, as well as the subscriber’s personal data). The SIM card fits into a small slot on the back of the phone and is protected by the battery.

SMS(Short Message Service) Network service sending and receiving messages to and from another subscriber without having to speak to the correspondent. The message created or received (up to 160 English or French characters long) can be displayed, received, edited or sent.

Soft Keys

The and keys on the phone are the soft keys. The key function:

●varies according to the function that you are currently using

●is indicated on the bottom line of the display just above the

corresponding key

Glossary

158157

Utstarcom GPRS779, GPRS778 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
