UTStarcom F1000 Series Quick Start Manual
Are you
ready to join
the telephone
revolution? This
Quick Start Guide
has everything you
need to get your
Vonage phone service
working with the
UTStarcom F1000 WiFi
handheld phone. Take a look
at the equipment, follow the
simple instructions and you'll be
talking in no time at all.
F1000 Series
F1000 Series
www.utstar.com
Doc. Code: 8810027600.0510
www.utstar.com
Copyright c 2005, UTStarcom, Inc. All rights reserved.
May not be reproduced without prior written permission.
Getting to know your F1000 Handset
Your handset's keys and navigation
Switch the phone on and off, end a call, or
return to standby mode.
Key in "#" or pause symbol "P" (by pressing
and holding the key), or lock the keypad.
Enter numbers and characters.
Key in "*" or change the text input method.
Scroll through menu lists and move the
cursor.
Scroll up and access the Received Log.
Scroll down and access the Missed Log.
Access the custom functions menu.
Access the current profile menu.
Perform the function shown in the soft key
function display area directly above the soft key.
Make or receive a call; access the Dialed Log
in standby mode.
Key Function
_
Antenna
Earpiece
LCD screen
Left soft key
Talk key
Number keypad
* key / Switch key
Microphone
# key / Lock key
Power key
Right soft key
Soft key function
display area
Display indicators
Earphone socket
4-way
navigation key
II.
I.
How do I...
How do I...
Turn phone on/off
Many of these operations need to be performed while in standby
mode (when Menu is the left soft key function). When the phone
is idle, it enters Screen Saver mode (Clock displayed). To return
to standby mode, press .
You can make a call and use speed dial from either mode.
IMPORTANT 911 SERVICE INFORMATION: Our 911 offering is different
from that offered by traditional telephone companies; please visit the
Features section of our website, www.vonage.com, to learn more about it.
Make a call
Answer a call
Press and hold .
Key in the phone number and press .
Press (Answer) or .
End a call
Reject a call
Clear a keypad
entry
Use speed dial
Adjust listening
volume
Access menu
options
Press (Hangup) or .
Press (Clear) .
While on a call, press .
Press (Menu) to access the main
menu. Press to reach the desired
submenu/option, and then press (Ok).
Press (Hangup) or .The call will
go to voice mail.
Press and hold the speed dial key to
display the phone number, and then
press .
Turn Vibration
on/off
Set Time Zone
and DST
Press and hold until the indicator
appears/disappears.
Press (Menu). Scroll to Tools and press
(Ok). Scroll to Time Zone or DST Setting
and press (Ok). Scroll to the desired
option and press (Ok). The phone's
date and time is provided by the network.
Lock/Unlock
keypad
Press and hold until the indicator
appears/disappears.
WARNING: Prior to placing or receiving calls, the WiFi phone must be
connected to a Wireless Access Point and registered with the Vonage
Network. If you purchased this WiFi phone from a retail store, you need to
activate your device at www.vonage.com/activate. See Section 3,
"Connecting to a Wireless Network" for detailed instructions.
Adjust ring volume
Press . Scroll to Ring Volume and
press (Ok). Scroll to High or Low
and press (Ok).
IV.
III.
