UTStarcom Pe rsonal Communications • 555 Wireless Bouleva rd
Hauppauge, N ew York 11788
• USA • www.uts tar.com/handsets • OM8915
REV.00 NT
5U010229000
TABLE OF CONTENTS
CHAPTER 1. BEFORE USING YOUR PHONE ......................7
INSIDE THE PACKAGE....................................................8
HANDSET DESCRIPTION ................................................9
PHONE VIEW.......................................................................9
THE FUNCTION KEYS........................................................10
DISPLAY INDICATORS..................................................11
DISPLAY INDICATORS........................................................11
BATTERY USAGE ..........................................................13
BATTERY INSTALLATION...................................................13
BATTERY REMOVAL ..........................................................13
BATTERY CHARGING.........................................................14
BATTERY HANDLING INFORMATION...........................15
DO’s....................................................................................15
DON’Ts...............................................................................15
CHAPTER 2. BASIC OPERATION......................................17
TURNING THE PHONE ON / OFF...................................18
TURNING THE PHONE ON................................................18
TURNING THE PHONE OFF...............................................18
ACCESSING THE MENU................................................19
MENU SUMMARY........................................................20
BASIC FUNCTIONS .......................................................24
MAKING A CALL ...............................................................24
ANSWERING A CALL.........................................................25
SPEAKER PHONE...............................................................25
CALLER ID ..........................................................................25
ENTER LOCK MODE..........................................................26
3-WAY CALLING................................................................26
CALL WAITING..................................................................27
WAIT/PAUSE......................................................................27
ADJUSTING VOLUME ........................................................28
DURING A CALL...........................................................29
AVAILABLE OPTIONS DURING A CALL............................29
MAKING AN EMERGENCY CALL.................................31
911 IN LOCK MODE..........................................................31
911 USING ANY AVAILABLE SYSTEM..............................31
32
TABLE OF CONTENTS
CHAPTER 3. MEMORY FUNCTIONS ................................33
STORING A PHONE NUMBER.......................................34
ENTERING LETTERS, NUMBERS & SYMBOLS ..............35
STANDARD INPUT MODE.................................................36
T9WORD INPUT MODE.....................................................37
NUMERIC MODE...............................................................38
SYMBOL MODE .................................................................38
MAKING A CALL FROM THE PHONE BOOK ................39
ONE-TOUCH/TWO-TOUCH DIALING ................................39
CHAPTER 4. MENU FUNCTIONS......................................41
PHONE BOOK...............................................................42
FIND...................................................................................42
ADD NEW..........................................................................44
GROUP...............................................................................45
SPEED DIAL........................................................................47
MSG. GROUPS...................................................................48
MY PHONE #.....................................................................50
RECENT CALLS.............................................................51
ALL CALLS..........................................................................51
MISSED CALLS...................................................................52
RECEIVED CALLS ...............................................................53
DIALED CALLS...................................................................54
CALL TIMERS.....................................................................55
MESSAGING.................................................................58
WHEN A NEW MESSAGE ARRIVES...................................58
VOICE MAIL .......................................................................58
CREATE NEW TEXT MESSAGE..........................................59
CREATE NEW PHOTO MESSAGE.......................................61
INBOX................................................................................64
OUTBOX ............................................................................67
WEB ALERTS ......................................................................69
SAVED MESSAGES.............................................................70
QUICK TEXT.......................................................................71
ERASE ALL MESSAGES......................................................71
SETTINGS ...........................................................................72
TABLE OF CONTENTS
BREW............................................................................76
START BREW......................................................................76
DOWNLOADING APPLICATIONS......................................76
DOWNLOADING MELODIES/WALLPAPERS......................77
APPLYING MELODIES/WALLPAPERS.................................77
CHECKING DATA FOLDER MEMORY................................77
ERASING AN APPLICATION...............................................78
MOBILE WEB BROWSER ..............................................79
ACCESS THE INTERNET .....................................................79
BROWSER MENU...............................................................79
MEDIA GALLERY..........................................................84
IMAGES..............................................................................84
PHOTO...............................................................................86
TONES................................................................................87
SETTINGS .....................................................................88
SOUNDS.............................................................................88
DISPLAY.............................................................................94
DATA SVC..........................................................................99
SECURITY.........................................................................100
OTHERS............................................................................106
SYSTEM............................................................................110
PHONE INFO. ...................................................................112
TOOLS.........................................................................113
VOICE TOOLS ..................................................................113
SCHEDULE........................................................................119
ALARM.............................................................................121
MEMO PAD.....................................................................123
CALCULATOR...................................................................124
WORLD CLOCK................................................................125
STOP WATCH ...................................................................126
CAMERA.....................................................................127
TAKE A PHOTO...............................................................127
PHOTO GALLERY.............................................................130
PHOTO MESSAGE............................................................131
HELP.................................................................................132
5
TABLE OF CONTENTS
4
CHAPTER 5. SAFETY AND WARRANTY........................133
SAFETY INFORMATION FOR WIRELESS HANDHELD
PHONES......................................................................134
SAFETY INFORMATION FOR FCC RF EXPOSURE.......139
SAR INFORMATION....................................................140
FCC HEARING-AID COMPATIBILITY (HAC)
REGULATIONS FOR WIRELESS DEVICES....................142
FDA CONSUMER UPDATE ..........................................144
12 MONTH LIMITED WARRANTY ..............................151
MEMO
6
CHAPTER 1
BEFORE
USING
YOUR PHONE
This chapter provides important information about using the
CDM-8915 including:
INSIDE THE PACKAGE
HANDSET DESCRIPTION
DISPLAY INDICATORS
BATTERY USAGE
BATTERY HANDLING INFORMATION
CHAPTER 1 BEFORE USING YOUR PHONE
HANDSET DESCRIPTION
BEFORE USING
■
PHONE VIEW
9
This phone is a single mode CDMA2000 1X digital phone with
camera and WEB browsing capabilities. The CDM-8915 weighs
3.8 oz. The dimensions are 1.9” X 3.4” X 1.0”.
BEFORE USING
INSIDE THE PACKAGE
8
This package should include all items pictured below.
If any are missing or different, immediately contact the
retailer where you purchased the cellular telephone.
Handset Standard Battery
Antenna
Camera Lens
Sub LCD
User Manual AC Travel Charger
Camera
Flash
State LED
Earjack
Camera
Key
Volume Keys
Clear Key
Lock Mode Key
Etiquette
Mode Key
End Key
Camera Key
Left/Right Soft
Keys
Send Key
Speaker Key
Volume Key
Navigation Keys
DISPLAY INDICATORS
BEFORE USING
■
DISPLAY INDICATORS
11
Signal Strength
Current signal strength: the more lines, the stronger the
signal.
BEFORE USING
HANDSET DESCRIPTION
■
THE FUNCTION KEYS
10
Soft Key Indicators
Displays the functions
currently assigned to
each soft key and
displays some icons.
Clear
Press to clear a digit from
the display or to return to
the previous page.
Press and hold to enter
lock mode.
Press and hold to enter
etiquette mode.
Press to turn the phone
on/off, to terminate a
call or to return to the
initial page.
Short press OK key
Go to Take Photo Menu
Long press OK key
Go to Take Photo
Viewfinder
Go to Take Photo
Viewfinder
THE FUNCTION KEYS
Left Soft Key
Press to access the
main menu or
function displayed on
bottom line of LCD.
Right Soft Key
Press to access contacts
menu or function
displayed on bottom
line.
Text & Graphic area
Display Indicators
See page 11 for a
list of icons.
THE NAVIGATION KEYS
In Idle Mode
Press Up for Phone Book
Down for Messaging, Left
for Mobile Web Browser
and Right for BREW
Inside a menu
Within a menu, use to
scroll through menu
options, or to select a
function displayed on the
screen.
Press to make or
receive a call.
Short press: Recent Calls.
Long press: Voice Dial.
Speaker Phone
On/Off in idle.
Short Press
Go to Take Photo
Viewfiner
Roaming
Phone is out of home area.
Service Indicator
Indicates call is in progress or the phone cannot receive
a signal from the system.
Digital Mode
Phone is operating in digital mode.
Battery
Battery power level – the more blocks, the more power
you have left.
Mute
Phone is muted during a call.
Silent
Appears when Silent is selected as the ring mode.
Emergency call
Blinks when an emergency call is in progress.
Auto Answer
Phone is in answering machine mode.
Speaker Phone
Phone is in speaker phone mode.
Message
New TEXT or voice message.
BATTERY USAGE
BEFORE USING
■
BATTERY INSTALLATION
As shown in the picture below, put the metal locators of the
battery into the holes located in the bottom of the unit.
Place the battery on the back of the handset and
slide into place.
Push the battery down until it locks into place.
13
If the battery is not correctly placed in the compartment,
the handset will not turn on and/or the battery may detach
during use.
BEFORE USING
DISPLAY INDICATORS
12
Etiquette
Phone will vibrate when call is received.
Schedule
When the Schedule is set, the idle screen appears. The idle
screen disappears if the schedule expires or is disabled.
Alarm
When the Alarm is set, the idle screen appears. The idle
screen disappears if the alarm is in operation or disabled.
Dormant
Indicates your phone is in a dormant state during a data
call. Your phone lapses into Dormant mode when you have
not had any activity on a page for some time - your
connection is still active and you can make and receive calls.
Data Only
Phone is ready to receive a data call.
GPS Icon
Indicates the Location Service of your phone is
disabled/enabled.
1X
Phone is in the 1x service area.
Scratch Pad
Displays when scratch pad is in use during a call.
UP Browser
UP Browser is in use.
Web Message Icon
Phone has Web Alert message. (Web
Message + TEXT Message + Voice Message)
Ring Mode
Appears when a ringer is set for the
ringer mode.
■
BATTERY REMOVAL
Pull up the release latch, lift up the battery.
Remove the battery from the handset.
BATTERY HANDLING
INFORMATION
BEFORE USING
15
BEFORE USING
BATTERY USAGE
■
BATTERY CHARGING
POWER CONNECTION
Plug the AC Charger into a standard outlet.
Plug the other end of the AC Charger into the
bottom of your phone. The battery must be
installed onto the phone.
14
•
When you charge the battery with the phone power off,
you will see a charging status screen. You cannot operate
the phone until it is powered on.
•
The battery is not charged at the time of purchase.
•
Fully charge the battery before use.
•
It is more efficient to charge the battery with the handset
powered off.
•
The battery must be connected to the phone in order to
charge it.
•
Battery operating time gradually decreases over time.
•
If the battery fails to perform normally, you may need to
replace the battery.
■
DO’S
•
Only use the battery and charger approved by the
manufacturer.
•
Only use the battery for its original purpose.
•
Try to keep batteries in a temperature between 41ºF (5ºC )
and 95ºF (35ºC).
•
If the battery is stored in temperatures above or below the
recommended range, give it time to warm up or cool
down before using.
•
Completely drain the battery before recharging. It may
take one to four days to completely drain.
•
Store the discharged battery in a cool, dark and dry place.
•
Purchase a new battery when the operating time of the
current battery has decreased gradually over time.
•
Properly dispose of the battery according to local laws.
■
DON’TS
•
Don’t attempt to disassemble the battery – it is a sealed
unit with no serviceable parts.
•
Don’t accidentally short circuit the battery by carrying it in
your pocket or purse with other metallic objects such as
coins, clips and pens. This may critically damage the
battery.
•
Don’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the capacity and
lifetime of the battery.
•
Don’t dispose of the battery into a fire.
CHAPTER 2
BASIC
OPERATION
This chapter addresses and explains the basic features of your
cellular telephone including:
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
CHAPTER 2 BASIC OPERATION
MEMO
BATTERY HANDLING
INFORMATION
16
ACCESSING THE MENU
BASIC OPERATION
To access the menu in idle mode,
press [MENU].
Use to scroll through the menu.
To return to the previous page, press .
To exit the current menu and return to idle mode,
press .
Press to enter a function when its
main page is displayed or press its assigned
number to have direct access to the function.
19
Your phone can be customized via the menu. Each function
can be accessed by scrolling with the or by
pressing the number that corresponds with the menu item.
Hotkey
In idle mode, press as follows to access
these functions:
•
Upward movement: Phone Book
•
Downward movement: Messaging
•
Rightward movement: BREW
•
Leftward movement: Mobile Web Browser
BASIC OPERATION
TURNING THE PHONE
ON / OFF
■
TURNING THE PHONE ON
Press and hold , until “Power On” Logo and
animation appears and the wake up tone sounds.
18
•
If “Password” appears on the display, enter your 4digit password to unlock your phone.
•
The default password is the last 4 digits of your
phone number.
■
TURNING THE PHONE OFF
Press and hold , until “Power Off” Logo and
animation appears and the tone sounds.
•
Immediately change or recharge the battery when
“Low Battery Warning Power Off” appears on the display. Memory may possibly be damaged if the phone
turns off due to the battery completely draining.
•
Turn the phone off before removing or replacing the
battery. If the phone is on, unsaved data may be lost.
MENU SUMMARY
BASIC OPERATION
21
BASIC OPERATION
MENU SUMMARY
20
MAIN MENU 2ND DEPTH 3RD DEPTH 4TH DEPTH
1. Phone Book
2. Recent Calls
3. Messaging
4. BREW
1. Find
2. Add New
3. Group
4. Speed Dial
5. Msg. Group
6. My Phone #
1. All Calls
2. Missed Calls
3. Received Calls
4. Dialed Calls
5. Call Timers
1. New Text Msg
2. New Photo Msg
3. Voice Mail
4. Inbox
5. Outbox
6. Web Alerts
7. Saved
8. Quick Text
9. Erase All
10. Settings
1. BREW
1. By Name
2. By Number
1. Last Call
2. All Calls
3. Home Calls
4. Roam Calls
5. Cumulative Calls
1. Inbox
2. Outbox
3. Saved
1. Auto Save
2. Auto Erase
3. Default Callback
4. Edit Voice C.B
5. Remind
6. Edit Signature
7. Direct View
8. Entry Mode
9. Block or Unblock
BREW
1. Old Inbox
2. Entire Inbox
1. Save sent MSG
2. Photo receive
mode
1. Inbox
2. Outbox
1. Block
2. Unblock
3. View List of
Blocked Address
MAIN MENU 2ND DEPTH 3RD DEPTH 4TH DEPTH
5. Mobile Web
6. Media Gallery
7. Settings
1. Connect web
1. Images
2. PHOTO
3. Tones
1. Sounds
2. Display
3. Data Svc.
4. Security
1. Graphics
2. Animations
1. Ringer Type
2. Volume
3. Alert
4. Roam Ringer
5. Tone Length
6. Etiquette
1. Menu Style
2. Graphics
3. Sub Screen
4. Greeting
Message
5. Contrast
6. Backlight
1. Connection
1. Phone Lock
2. Restrict
3. Change Code
4. Special #’s
1. Ringer
2. Messages
3. Voice Mail
1. Ringer
2. Key Tone
3. Voice Call
4. Speaker Phone
1. Minute
2. Roam
3. Connect
4. Fade
1. Wallpaper
2. Power On
3. Power Off
4. Received
5. Dialed
6. Screen Saver
1. Dialed
2. Recent Calls
3. Camera
4. Data Call
5. 900#s
6. Long Distance
1. Special #1
2. Special #2
3. Special #3
2322
MENU SUMMARY
BASIC OPERATIONBASIC OPERATION
MENU SUMMARY
MAIN MENU 2ND DEPTH 3RD DEPTH 4TH DEPTH
8. Tools
5. Others
6. System
7. Phone Info
1. Voice Tools
2. Schedule
3. Alarm
4. Memo Pad
5. Calculator
6. World Clock
7. Stop Watch
5. Erase All
6. Reset Phone
1. Answer Options
2. Auto Retry
3. Language
4. Voice Privacy
5. TTY Mode
6. Location
1. Set Mode
2. Nam Setting
3. PRL ID
1. S/W Version
2. H/W Version
3. BREW Version
1. Voice Memo
2. Voice Dial
3. Train Words
4. Voice Setting
1. Add New Plan
2. View Plan
1. Alarm 1
2. Alarm 2
3. Alarm 3
1. Add Memo
2. View Memo
3. Settings
1. Call Answer
2. Active Flip
3. Auto Answer
1. Auto NAM
2. Change NAM
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Yes
2. No
3. Wake-Up
4. Undo Train All
Set Active
HFK Mode
MAIN MENU 2ND DEPTH 3RD DEPTH 4TH DEPTH
9. Camera 1. Take a Photo
2. Photo Gallery
3. Photo Message
4. Help
1. New Photo
2. Saved Photo
BASIC FUNCTIONS
BASIC OPERATION
■
SPEAKER PHONE
The speaker phone feature lets you hear audio through the speaker
and talk without holding the phone.
To activate the speaker phone in idle, answering or
calling modes, press .
The phone returns to normal (Speaker Phone Off)
after ending a call or when the phone is turned off
and back on.
25
BASIC OPERATION
BASIC FUNCTIONS
■
MAKING A CALL
24
To modify the phone number you have entered:
•
Erase one digit at a time by pressing .
•
Erase the entire number by pressing and holding .
To send a Text or Photo message to the phone number:
•
Enter a part of the phone number, then press [MENU],
select “Send Text Msg or Send Photo Msg”.
Please refer to page 59 or page 61 for more details on
“Create New Text Message or Create New Photo Message”.
•
If “CALL FAILED” appears on the display or the line is
busy, press or .
•
If you activate the “AUTO RETRY” function, the phone
will automatically retry for the number of times you have
selected. (refer to page 107).
•
When you place or receive a call from stored phone
numbers, both the name and phone number will be
displayed.
•
You may also place calls using Voice Activated Dialing
(VAD) in the VR mode. Please refer to page 114 (Voice
Services) for more details.
•
If “Enter Lock Code” appears on the display enter your
4-digit password to unlock your phone. The default
password is the last 4 digits of your phone number.
NUMBER
Press .
The indicator, , appears on the display.
To end a call, press .
Enter a phone number.
■
ANSWERING A CALL
When your phone rings or vibrates, press to
answer the incoming call. (Depending on your
phone’s settings, you may also answer incoming
calls by opening the phone or by pressing any
number key.)
To end the call, press .
To ignore incoming calls and silence the ringer, press
[IGNORE].
■
CALLER ID
Identifies callers by displaying their phone number.
If the caller’s name and number are already stored in
your phone book, they will both appear.
The caller ID information is stored in Recent Calls.
BASIC FUNCTIONS
BASIC OPERATION
27
Call Waiting is a system dependent feature. Please contact
your service provider for details.
BASIC OPERATION
BASIC FUNCTIONS
■
3-WAY CALLING
With 3-Way Calling, you can talk to two people at the same time.
When using this feature, normal airtime rates will apply to both of
the calls.
Enter a number you wish to call and press .
Once you have established the connection, enter
the second number you wish to call and press .
When you’re connected to the second party,
press again to begin your 3-Way call.
26
If one of the people you called hangs up during your call,
you and the remaining caller stay connected.
If you initiated the call and are the first to hang up, all
three callers are disconnected.
NUMBER
NUMBER
■
CALL WAITING
Notifies you of an incoming call when you are already on a call by
sounding a beep tone and displaying the caller’s phone number.
To answer another call while on the phone, press .
This places the first call on hold. To switch back to the
first caller, press again.
■
ENTER LOCK MODE
To lock the phone, press and hold .
To unlock the phone, press or [UNLOCK],
input your password, and press .
■
WAIT/PAUSE
Pauses are used for automated systems (i.e., voice mail, calling
cards). Insert a pause after a phone number then enter another
group of numbers. The second set of numbers is dialed
automatically after the pause. This feature is useful for dialing into
systems that require a code.
To insert a pause, enter a phone number then
press [MENU]. Select either a Hard Pause
(“P” appears) or a Timed Pause (“T” appears).
Press to dial or [SAVE] to store.
Please refer to page 34 for more details about
storing a phone number.
NUMBER
Select
“P”or”T”
OR
DURING A CALL
BASIC OPERATION
■
AVAILABLE OPTIONS DURING A CALL
To display menu options during a call, press [MENU].
MESSAGING
Enables you to send a message during a call.
Press [MENU] .
MUTE (UNMUTE)
The caller cannot hear you or any sounds from your side but you
can still hear them.
Press [MENU] .
SCRATCH PAD
Stores a new phone number during a call without the calling party
hearing the key pad tones.
Press [MENU] .
SEND MY PHONE #
Automatically transmits your phone number to a pager during a
call. (Dependent on pager service)
Press [MENU] .
29
BASIC OPERATION
BASIC FUNCTIONS
■
ADJUSTING VOLUME
Adjusts the volume of the ringer, key beep and speaker.
Select one of the following.
Adjust volume and press to save it.
28
•
Ringer: Controls the ringer volume.
•
Key Tone: Controls the key pad tone.
•
Voice Call: Controls the earpiece volume.
•
Speaker Phone: Controls the speaker volume.
Move the to adjust Earpiece volume during a call.
•
To deactivate, press [MENU] .
•
The phone will automatically unmute in Emergency Call or
Callback mode.
•
Press [MENU] to deactivate it.
MAKING AN
EMERGENCY CALL
BASIC OPERATION
This 911 feature puts the phone in the Emergency Call Mode when
you dial the preprogrammed emergency number, 911.
It also operates in the lock mode and out of the service area.
■
911 IN LOCK MODE
The 911 call service is available even in the lock mode.
Enter “911” and press .
The call connects.
The phone exits the Lock Mode for 5 minutes.
■
911 USING ANY AVAILABLE SYSTEM
The 911 call service is available even in the lock mode.
Enter “911” and press .
The call connects.
The phone maintains the Emergency Mode for 5
minutes.
31
•
When the call ends, the phone returns to the Lock Mode.
•
While the phone is in the emergency mode for 5 minutes,
the phone can receive an incoming call from any available
system. However it can't make a call.
The 911 call is not recorded in the recent call list.
BASIC OPERATION
DURING A CALL
30
MY PHONE #
Displays your phone number.
Press [MENU] .
VOICE PRIVACY
Increases security during a call.
Press [MENU] .
LOCATION
Enables the network to locate your current location using Global
Positioning System (GPS). (Refer to page 109 for more details.)
Press [MENU] .
Emergency
Number
CHAPTER 3
MEMORY
FUNCTIONS
This chapter addresses memory functions including:
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
CHAPTER 3 MEMORY FUNCTIONS
MEMO
32
ENTERING LETTERS,
NUMBERS & SYMBOLS
MEMORY FUNCTIONS
The input mode (Alpha editor) will automatically be
activated when necessary to enter letters and numbers.
As shown below, there are 4 available modes ; Standard
input mode (Abc), T9Word input mode (T9Word),
Numeric mode (NUM), and symbol mode (Symbols).
The input mode indicator appears on the upper right of
the display when letters and numbers are entered.
To select the desired input mode among the 4 modes
below, press [Abc], then enter letters and
numbers.
The following illustrates the function assigned to
each key in the Alpha Editor.
35
MEMORY FUNCTIONS
STORING
A PHONE NUMBER
The phone book stores up to 300 entries.
Enter phone # then press [SAVE] then choose
“New Contact” or “Existing Contact”. Press to
select.
If “New Contact” is selected, the phone number
will appear above a list. Press to choose the
type of number you’re adding, as indicated by the
icon. Press to select. If “Existing Contact” is
selected, your contact list is displayed. Choose the
entry to add the phone number to, then
press .
You will then see the phone number listed.
Press to select.
Enter a name.
Please refer to page 35 for more details on entering
letters, numbers & symbols.
To change the input mode, press [Abc].
Press to select other options.
If you entered a phone number, press [MENU]
to select one of the following options:
To store the entry, press [SAVE].
“New contact added!” will be displayed.
34
•
Send Text Msg
•
Send Photo Msg
•
Prefix
•
Hard Pause
•
Timed Pause
FUNCTIONKEY
Abc
Press to change mode. [T9Word][Abc][NUM][Symbols]
Next
Press to view the next matching word if the
highlighted word is not the word you intended in
T9Word input mode.
Space
Press to accept a word and add a space.
Clear
Press to delete a character to the left of the cursor.
OK
Confirm the letters and numbers you entered.
Caps Lock
Press to select a letter case of the standard text
input or T9 text input mode. [Abc], [ABC] and [abc]
indicate the standard text input. [T9Word],
[T9WORD] and [T9word] indicate the predictive text
input. Press and hold to change mode.
ENTERING LETTERS,
NUMBERS & SYMBOLS
MEMORY FUNCTIONS
■
T9WORD INPUT MODE
The T9Word input mode incorporates a built-in-dictionary to
determine a word based on the entered characters. A T9Word can
be entered more quickly by pressing a key once per character.
Select the T9Word mode by pressing [Abc].
Press a digit key once to enter the character you
want then enter all the characters to input the
word you want.
To view the next matching word, press .
To accept the matching word and enter a space,
press .
37
To enter a compound word:
•
Enter the first part of the word then press to
accept it.
•
Enter the last part of the word then press to
enter the word.
MEMORY FUNCTIONS
ENTERING LETTERS,
NUMBERS & SYMBOLS
■
STANDARD INPUT MODE
Use the number keys to enter letters, numbers and characters.
Enter letters using the key pad as follows:
Press repeatedly, until the desired symbol
appears (. @ ? ! - , & : _ / ; ’).
To change the input mode, press [Abc].
To enter a space, press . The cursor will
automatically move to the next column.
Repeat until letters are entered.
To delete one digit, press .
Press and hold to delete the entire entry.
To change from lowercase to uppercase, press .
36
Key Pad
Press
1 Time
Press
2 times
Press
3 times
Press
4 times
Press
5 times
2ABC
3DEF
4GHI
:
9WXYZ
A
D
G
:
W
B
E
H
:
X
C
F
I
:
Y
2
3
4
:
Z
A
D
G
:
9
MAKING A CALL FROM
THE PHONE BOOK
MEMORY FUNCTIONS
■
ONE-TOUCH/TWO-TOUCH DIALING
Ideal for frequently dialed numbers, this feature allows phone book
entries to be dialed via the keypad with only one or two key
presses.
ONE-TOUCH DIALING:
2-9: Press and hold the corresponding memory number
for more than 1 second.
TWO-TOUCH DIALING:
10-20: Press the first digit and second digits of the
memory number short and long respectively.
39
MEMORY FUNCTIONS
ENTERING LETTERS,
NUMBERS & SYMBOLS
■
NUMERIC MODE
Allows you to enter numbers.
Press [Abc] and scroll down to “NUM” and
press to change to Numeric Mode.
To enter a number, press a digit key.
■
SYMBOL MODE
Allows you to enter symbols.
Press [Abc] and scroll down to “Symbols” and
press to change to Symbol Mode.
Select the symbol you want to enter with the
.
38
•
Use the to view a different line of symbols.
If no phone number is stored in the location entered,
“There is no number” will appear on the screen.
CHAPTER 4
MENU
FUNCTIONS
This chapter addresses accessing the menu and using its functions
and features to customize your phone.
PHONE BOOK
RECENT CALLS
MESSAGING
BREW
MOBILE WEB BROWSER
MEDIA GALLERY
SETTINGS
TOOLS
CAMERA
CHAPTER 4 MENU FUNCTIONS
MEMO
40
PHONE BOOK
MENU FUNCTIONS
43
MENU FUNCTIONS
PHONE BOOK
Stores up to 500 entries, each of which can be assigned to a group.
Entries can be retrieved by name, phone number or group.
■
FIND
Retrieves an entry by name and number, and calls the number by
simply pressing . You can review all the entries stored in your
phone book list or find an entry quickly by entering all or part of a
name.
BY NAME
Lists contacts alphabetically so you can quickly find a name.
Press [MENU] .
The list of names in your phone book is displayed
alphabetically.
Enter a name or part of a name or scroll through
the list with the . Please refer to
page 35 for more details on entering letters,
numbers & symbols.
All matching entries will be displayed. Highlight
an entry. Press to edit the entry. Select the
mobile number, then press [MENU] to 1. Send
Text Msg, 2. Send Photo Msg, 3. Prefix or 4. Erase.
To call the selected number, press .
42
•
If the entry is set to secret, you will be asked for your
password.
BY NUMBER
Lists contacts numerically so you can quickly find a number.
Press [MENU] .
The list of phone numbers saved in your phone
book will be displayed in numerical order.
Enter a part of the phone number or scroll through
the list with the .
The name associated with that number will be
displayed at the bottom of the screen.
All matching entries will be displayed. Highlight
an entry. Press to edit the entry.
Press [MENU] to 1. Send Text Msg,
2. Send Photo Msg, 3. Prefix or 4. Erase.
To call the selected number, press .
•
If the entry is set to secret, you will be asked for your
password.
OR
PHONE BOOK
MENU FUNCTIONS
■
GROUP
Allows you to classify phone entries into groups. Existing groups
include Personal, Business, Etc. and All. A maximum of seven groups is
allowed.
ADD NEW GROUP
To add a new group, press [MENU] .
A maximum of seven groups is allowed.
Press [MENU] to select “Add Group”.
Input a new group name.
Press to save it.
CHANGE GROUP NAME
Press [MENU] . Select an existing group
name that you have added with the .
Press [MENU] to select “Rename”.
Input a new group name.
Press to save it.
45
The default group names (All, Personal, Business, Etc.)
cannot be changed.
MENU FUNCTIONS
PHONE BOOK
44
■
ADD NEW
Adds a new entry.
To add a new entry to the phone book,
press [MENU] .
To enter a name or number, use the
to select the phone book field.
To save the entry, press [SAVE].
To return to the previous page, press .
•
Phone Book Field: Name/Mobile/Home/Office/Pager/Fax/
E-Mail/Wireless Addr./Group/Ringer/Msg.Ringer/Graphic/
Memo/Set Secret.
Please refer to page 35 for more details on entering letters,
numbers & symbols.
PHONE BOOK
MENU FUNCTIONS
47
MENU FUNCTIONS
PHONE BOOK
46
ERASE GROUP
Press [MENU] . Use the
to select, then delete the group.
Press [ERASE] to delete it.
Press to erase it.
•
The default group names (All, Personal, Business, Etc.)
cannot be erased.
•
When using Erase Group, the saved entries are
moved to the Etc. group.
•
“Unassigned” appears if the location is available.
•
If a phone number is set as Secret, you will have to
enter the password.
•
To call an assigned number, press & hold the last digit
of the speed dial #.
■
SPEED DIAL
In idle mode, calls can be placed to numbers stored in speed dial by
pressing & holding the location number on the key pad. For a 2digit location number, press the first number, then press and hold
the second number.
Press [MENU] .
To assign a phone number to a location, select the
location and press [SET].
Select the entry with the and
press .
“Speed Dial # X edited!” will be displayed.
•
If a phone number is already assigned to the location,
press [ERASE] and to delete.
•
If the entry is set to secret, you will be asked for your
password.
PHONE BOOK
MENU FUNCTIONS
49
MENU FUNCTIONS
PHONE BOOK
48
■
MSG. GROUPS
Allows the user to group up to 10 phone numbers. The user can
add, change, and delete Msg.Groups.
ADD NEW MSG. GROUP
To add a new group, press [MENU] .
A maximum of five groups is allowed.
Press [MENU] to select “Add Group”.
Input a new group name.
Press to save it.
CHANGE MSG. GROUP NAME
Press [MENU] . Select an existing group
name with the .
Press [MENU] to select “Rename”.
Input a new group name.
Press to save it.
SEND TEXT MSG. GROUP
Press [MENU] . Select an existing group
name with the .
Press [MENU] to select “Send Text Msg”.
Input a “Message”, “Default CB#”, “Priority”, and
“Insert Signature”.
To send the text message, press [MENU]
and select “Send” then press .
To save the text message, press [MENU] and
select “Save to Outbox” then press .
SEND PHOTO MSG. GROUP
Press [MENU] . Select an existing group
name with the .
Press [MENU] to select “Send Photo Msg”.
Input a “Message”, “Subject”, “CC” and “BCC”.
To send the photo message, press [MENU]
and select “Send” then press .
Please refer to page 59 for more details on
“Create New Text Message”.
Please refer to page 61 for more details on
“Create New Photo Message”
RECENT CALLS
MENU FUNCTIONS
51
MENU FUNCTIONS
PHONE BOOK
50
■
MY PHONE #
To display your phone number and service provider:
Press [MENU] .
To return to the previous page, press .
ERASE MSG. GROUP
Press [MENU] . Select an existing group
name with the .
Press [ERASE] to delete it.
Press to erase it.
■
ALL CALLS
Displays information about the most recent incoming, outgoing
and missed calls.
To see a list of the 60 most recent received, dialed
and missed calls, press [MENU] . If the
number is already stored in your phone book, only
the name appears. If the number is not stored, only
the phone number appears.
To view details, press .
To save a selected number, press [MENU] then
select “Save;” to delete the number, press
[ERASE]]. Other menu options include:
•
Save: To store the phone number in your phone book.
•
Prefix: The user may add the desired number before the
existing number. It is useful when you add “1”
during a long distance call. You may save it in the
phone book after Prefix.
•
Send Text Msg: To send a Text Message, insert the phone
number.
•
Send Photo Msg: To send a photo message, insert the
phone number.
•
Erase All: To erase all recent calls.
Call details include type of call, date, time and phone
number.
After 20 received, dialed or missed calls, the oldest call will
automatically be erased from the history when a new call is
added.
RECENT CALLS
MENU FUNCTIONS
53
MENU FUNCTIONS
RECENT CALLS
52
■
MISSED CALLS
Displays information about the 20 most recently missed calls.
Place a call to a missed call number by simply pressing .
To see a list of the 20 most recently missed calls,
press [MENU] . If the number is already
stored in your phone book, only the name appears.
If the number is not stored, only the phone number
appears.
To view missed call details, press .
To save a selected number, press [MENU] then
select “Save;” to delete the number, press
[ERASE]]. Other menu options include:
•
Save: To store the phone number in your phone book.
•
Prefix: The user may add the desired number before the
existing number. It is useful when you add “1”
during a long distance call. You may save it in the
phone book after Prefix.
•
Send Text Msg: To send a Text Message, insert the phone
number.
•
Send Photo Msg: To send a photo message, insert the
phone number.
•
Erase All: To erase all missed calls.
Call details include date, time and phone number.
After 20 missed calls, the oldest call will automatically
be erased from the history.
■
RECEIVED CALLS
Displays information about the 20 most recently answered calls.
Place a call to a received call by simply pressing .
To see a list of the 20 most recently answered calls,
press [MENU] . If the number is already
stored in your phone book, only the name appears.
If the number is not stored, only the phone number
appears.
To view received call details, press .
To save a selected number, press [MENU] then
select “Save;” to delete the number, press
[ERASE]]. Other menu options include:
•
Save: To store the phone number in your phone book.
•
Prefix: The user may add the desired number before the
existing number. It is useful when you add “1”
during a long distance call. You may save it in the
phone book after Prefix.
•
Send Text Msg: To send a Text Message, insert the phone
number.
•
Send Photo Msg: To send a photo message, insert the
phone number.
•
Erase All: To erase all received calls.
Call details include date, time and phone number.
After 20 received calls, the oldest call will automatically
be erased from the history.
RECENT CALLS
MENU FUNCTIONS
55
MENU FUNCTIONS
RECENT CALLS
54
■
DIALED CALLS
Displays information about the 20 most recently dialed numbers.
Place a call to a dialed call by simply pressing .
To see a list of the 20 most recently dialed numbers,
press [MENU] . If the number is already
stored in your phone book, only the name appears.
If the number is not stored, only the phone number
appears.
To view dialed call details, press .
To save a selected number, press [MENU] then
select “Save;” to delete the number, press
[ERASE]]. Other menu options include:
•
Save: To store the phone number in your phone book.
•
Prefix: The user may add the desired number before the
existing number. It is useful when you add “1”
during a long distance call. You may save it in the
phone book after Prefix.
•
Send Text Msg: To send a Text Message, insert the phone
number.
•
Send Photo Msg: To send a photo message, insert the
phone number.
•
Erase All: To erase all dialed calls.
Call details include type of call, date, time and phone
number.
After 20 dialed calls, the oldest call will automatically
be erased from the history.
•
Voice Call
•
Data Call
■
CALL TIMERS
Checks the usage time and manages your calls within the limit you
set. The five timers include:
LAST CALL
Displays usage time of last call.
Press [MENU] .
To return to the previous page, press .
ALL CALLS
Displays usage time of all incoming and outgoing calls, excluding
web access calls.
Press [MENU] .
View the time of the following items:
To return to the previous page, press .
RECENT CALLS
MENU FUNCTIONS
57
MENU FUNCTIONS
RECENT CALLS
56
HOME CALLS
Displays usage time of all calls made within Home area.
Press [MENU] .
View the time of the following items:
To reset the timer, press [RESET].
To return to the previous page, press .
ROAM CALLS
Displays usage time of roaming calls.
Press [MENU] .
View the time of the following items:
To reset the timer, press [RESET].
To return to the previous page, press .
CUMULATIVE CALLS
Displays usage time of all incoming and outgoing calls, excluding
web access calls.
Press [MENU] .
View the time of the following items:
To reset the timer, press [RESET].
To return to the previous page, press .
•
Voice Call
•
Data Call
•
Voice Call
•
Data Call
•
Voice Call
•
Data Call
MESSAGING
MENU FUNCTIONS
■
CREATE NEW TEXT MESSAGE
To send a new message:
Press [MENU] or .
Under “Send To”, input the phone number and
press .
Under “Message”, input a new text message and
press .
59
•
By pressing [MENU], you can choose from the following:
1. Find: Search for a phone number stored in the
phone book.
2. Save: Stores the phone number the message was sent to.
3. Msg. Group: Select all the phone numbers in a group.
MENU FUNCTIONS
MESSAGING
■
WHEN A NEW MESSAGE ARRIVES
The following display appears
when a new message arrives.
To display the message,
press [READ].
■
VOICE MAIL
Displays the number of voice mails and accesses them by
pressing .
To access your voice mail, press [MENU]
or .
FIRST TIME USER (Voice mail set-up may vary by carrier)
Dial Voice mail access number and press .
At the recording, press .
Follow the voice tutorial to set up your account.
EXISTING USER
Dial Voice mail access number and press .
At the recording, enter your 4 digit password, then
press .
To listen to new messages, press .
58
•
By pressing [MENU], in the message input screen you
can choose from the following:
1. Insert Quick Text: Inserts previously saved sentences.
2. Insert Sound: Inserts sound in a Text Msg.
3. Insert Picture: Inserts a photo in a Text Msg.
4. Insert Animation: Inserts Animation in a Text Msg.
5. Save to Quick Text: Save to Quick Text function saves
the written sentences to the Quick
Text list.
OR
OR
MESSAGING
MENU FUNCTIONS
61
MENU FUNCTIONS
MESSAGING
The default call back number is automatically
inputted into the Default CB# field. You can scroll
to the number and edit it or simply
press [EDIT].
Press for more fields. Under “Priority”, select
“Normal” or “Urgent”.
Under “Insert Signature”, select “On” or “Off” to
insert a preset signature.
To send the Text message, press [MENU],
select “Send” then press .
To save the Text message, press [MENU],
select “Save to Outbox” then press .
60
■
CREATE NEW PHOTO MESSAGE
To send a new photo message:
Press [MENU] or .
Phone goes into camera mode automatically.
Take a photo and press .
Under “Send To’, input the phone number and
press .
Under “Message”, input a new text message and
press .
•
By pressing [MENU], you can choose from the following:
1. Find: Allows the user to search the phone numbers
stored in the phone book.
2. Save: Stores the phone number the message was sent to.
3. Msg. Group: Allows you to select all the phone numbers
in a group.
4. Online Album: To send pictures using the online
Address Book.
OR
MESSAGING
MENU FUNCTIONS
63
MENU FUNCTIONS
MESSAGING
62
•
By pressing [MENU], in the message input screen you
can choose from the following:
1. Take Photo: To take a new photo.
2. Voice Record: To record a voice memo.
3. Insert Q.Text: To insert a previously saved sentence.
4. Insert/Delete Photo: To insert/delete a photo from your
photo gallery.
5. Insert/Delete Sound: To Insert/delete a sound in a
Photo Msg.
6. Insert/Delete Slide: To insert/delete a slide in a
Photo Msg.
7. Slide Duration: To select a slide duration time.
Please refer to page 35 for more details on entering letters,
numbers and symbols.
Under “Subject”, input a message subject and
press .
To send a message to another person, select
“CC” or “BCC” and input the phone numbers,
then press .
•
By pressing [MENU], you can choose from the following:
1. Find: Allows the user to search the phone numbers
stored in the phone book.
2. Save: Stores the phone number the message was sent to.
3. Msg. Group: Allows you to select all the phone numbers
in a group.
To send the photo message, press [MENU],
select “Send”, then press .
To save the photo message, press [MENU],
select “Save to Outbox”, then press .
•
By pressing [MENU], you can choose from the following:
1. Send: To send a photo message.
2. Preview: To preview a written photo message.
3. Send to Outbox: To save a message to “Outbox” folder.
4. Priority: To select priority “Normal” or “High”.
5. Expiration: To select expiration time “Off”, “1 day”,
“2 days”, “3 days”, “4 days” or “5 days”.
MESSAGING
MENU FUNCTIONS
REPLY
Type your reply and then press .
REPLY WITH COPY
To reply to a received message and include the
received message into the message:
The default call back number is automatically
inputted into the Default CB# field. You can scroll
to the number and edit it.
Under “Insert Signature”, select “On” or “Off”.
To send the Text message, press [SEND].
To save the Text message, press [MENU],
select “Save to Outbox”, then press .
FORWARD
To forward the Text message:
Input the phone number of the person you are
sending the message to, then press .
Input any Text message to go along with the
forwarded message, then press .
SAVE MEDIA
To save a photo to the media gallery folder.
65
“Save Media” menu appears only when you receive a
photo message or EMS message.
MENU FUNCTIONS
MESSAGING
64
■
INBOX
The Inbox manages received Text or Photo messages. To access:
Press [MENU] or .
Select a message and press .
The message is displayed. To delete a message,
press [ERASE].
By pressing [MENU], the user can choose from
the following:
PHOTO INFO
To show photo message information.
PLAY SLIDE SHOW
One photo message is comprised of 3 slides,
each of which can contain photo, sound and texts.
The Slide Show displays each slide every 5 seconds
and ends after repeating once.
OR
"Photo Info" menus appear only when you receive a
photo message.
“Play Slide Show” menus appear only when you receive a
photo message.
MESSAGING
MENU FUNCTIONS
67
MENU FUNCTIONS
MESSAGING
SAVE TO CONTACT
To save number to contact.
SAVE TO SAVED
To save the Text message in your phone.
SAVE TO QUICK TEXT
To save received Text message to “Quick Text”.
BLOCK SENDER
To block all incoming messages from addresses on
block list.
LOCK & UNLOCK
To lock or unlock the Text message.
Select “Lock” to lock the message or “Unlock” to
unlock the message, then press .
66
■
OUTBOX
Manages sent TEXT messages or messages waiting to be sent.
Press [MENU] or .
Select a message and press .
The message is displayed. To delete a message,
press [ERASE].
By pressing [MENU], the user can choose from
the following:
PHOTO INFO
To show photo message information.
RESEND
To resend a Text message.
EDIT MESSAGE
To send a message to another person:
Input a Text message and press .
Input the phone number and press .
OR
"Photo Info" menus appear only when you receive a photo
message.
MESSAGING
MENU FUNCTIONS
69
MENU FUNCTIONS
MESSAGING
68
“State” menu appears only when you send a text message.
SAVE TO CONTACT
To save number to contact.
SAVE TO SAVED
To save the Text message in your phone.
LOCK & UNLOCK
To lock or unlock the Text message:
Select “Lock” to lock the message or “Unlock” to
unlock the message, then press .
STATE
To display the status of an outbox message:
■
WEB ALERTS
Press [MENU] or .
To select GoTo, press .
To select Erase Message, press .
The Web Alerts message will be displayed.
OR
•
[]:Read Message.
•
[]:Unread Message.
•
[]:Displays the remaining text.
•
GoTo: Connecting Selected Site.
•
Erase: Erase Selected Message.
MESSAGING
MENU FUNCTIONS
71
MENU FUNCTIONS
MESSAGING
70
•
“*Photo Info” or “*Play Slide Show” menu only appears
when you receive a photo message.
•
“*Save Media” menu appears only when you receive a
photo message or EMS message.
•
“*State” menu appears only when you send a text
message.
■
SAVED MESSAGES
Manages saved messages from the Inbox/Outbox.
Press [MENU] or .
Select a message and press .
The message is displayed. To delete a message,
press [ERASE].
Pressing [MENU], the user can choose from
the following:
If the Text message is saved from the “Inbox”
menu, this screen will be displayed.
If the Text message is saved from the “Outbox”
menu, this screen will be displayed.
OR
*Photo Info, *Play Slide Show, Reply, Reply With Copy,
Forward, Save to Quick Text, *Save Media, Block Sender,
Save to Contact, Lock & Unlock
*Photo Info, Resend, Edit Message, Save to Contact,
Lock & Unlock, *State
■
QUICK TEXT
To edit the Quick Text message you have saved:
Press [MENU] or .
Select a message from the list. Press [MENU].
To add a new Quick Text message,
select “Add New”. To edit the Quick Text message
you have selected, select “Edit”.
To erase the saved Quick Text message, press
[ERASE].
OR
■
ERASE ALL MESSAGES
Press [MENU] or .
To erase all the inbox messages, press .
To erase all the outbox messages, press .
To erase the saved messages, press .
Select “OK” or “Cancel” with or [CANCEL].
OR
•
Old Inbox: To erase all messages already read.
•
Entire Inbox: To erase all messages.
MESSAGING
MENU FUNCTIONS
OUTBOX
Press [MENU] or .
Select “Disable” or “Enable” with
then press .
DEFAULT CALLBACK
Edits a default callback number so that the recipient can callback or
reply.
Press [MENU] or .
Input a callback number, then press .
AUTO ERASE
Automatically erases inbox/outbox messages when new messages
arrive.
INBOX
Press [MENU] or .
Select “Disable” or “Enable” with
then press .
73
MENU FUNCTIONS
MESSAGING
■
SETTINGS
Manages messaging features through various features.
72
AUTO SAVE
SA
VE SENT MSG
Press [MENU] or .
Select either “Off”, “On” or “Prompt” with the
then press .
PHOTO RECEIVE MODE
Controls whether photos are received automatically or if you are
prompted to accept them.
Press [MENU] or .
Select “Automatic” or “Prompt” with
then press .
OR
•
You can look it up from the phone book by pressing
[FIND].
MESSAGING
MENU FUNCTIONS
DIRECT VIEW
If the Direct View is set to on, the user will be able to view the
message by pressing the read key. If the Direct View is set to off,
the user can view the message by entering SMS Menu-> Inbox.
Press [MENU] or .
Select “Off” or “On” with the ,
then press .
ENTRY MODE
Sets an Entry Mode as a default. For example, the T9 mode
indicator will appear when T9 mode is set as the default.
Press [MENU] or .
Select “Alpha Mode” or “T9 Mode” with the
, then press .
BLOCK OR UNBLOCK
Press [MENU] or .
Select “Block”, “Unblock” or “View List of
Blocked Addresses” with the ,
then press .
75
MENU FUNCTIONS
MESSAGING
REMIND
To send yourself a message to remember important notes or events:
Press [MENU] or .
Select “Off” or “On” with the ,
then press .
EDIT SIGNATURE
To create a signature that can be automatically inserted at the end
of a message:
Press [MENU] or .
To input “Signature”, put the cursor on Edit
Signature and enter Signature Edit window by
using .
To activate Signature function, put the cursor on
Insert Signature and select “On” by using .
To deactivate Signature function, select “Off”.
Press .
74
•
On: Set to read msg without entering inbox in SMS menu.
•
Off: Set to read msg after entering inbox in SMS menu.
•
Block: Enter the address to block.
•
Unblock: Enter the address to remove from block.
•
View List of Blocked Addresses: Display the blocked
list on LCD.
EDIT VOICE CALLBACK
Press [MENU] or .
Input a new voice callback number or edit voice
callback number, then press .
•
You can look it up from the phone book by pressing
[FIND].
BREW
MENU FUNCTIONS
■
DOWNLOADING MELODIES/WALLPAPERS
Before downloading melody ringers and wallpapers,
you need to download the dedicated downloader.
Please contact your service provider for details.
■
APPLYING MELODIES/WALLPAPERS
Downloaded melody ringers apply to several functions
including the incoming call alert, new text message
alert, alarm clock and scheduler alarm. Downloaded
wallpapers apply to the standby mode.
■
CHECKING DATA FOLDER MEMORY
Downloaded melody ringers, wallpapers and applications are saved
to the data folder in your phone.
Press [MENU] or .
Select “Settings” with and
press .
Select “Manage Apps -> System Info” with
and press .
The memory status will be displayed.
To exit, press .
77
MENU FUNCTIONS
BREW
Your phone provides a unique feature -BREW- that enables you to download melody ringers, wallpapers, games and more from your network to
your phone. Please contact your service provider for the availability of
these services.
■
START BREW
To launch “BREW ” from the standby mode,
press [MENU] or .
When three or more icons appear on the screen,
select an application with the .
To start the application, press .
To end the application, press .
The phone will return to the standby mode.
■
DOWNLOADING APPLICATIONS
Press [MENU] or .
Select “BREW ” with and
press .
Select “Catalog” with and press .
The phone will access your service provider’s server.
Follow the prompt to download applications.
76
OR
•
To select an option, press then press .
•
When a prompt appears, press to proceed or to
cancel.
MOBILE WEB BROWSER
MENU FUNCTIONS
■
ACCESS THE INTERNET
Now you can access news, sports, weather, and e-mail from your
phone. Accessing the Mobile Web keeps you updated by providing
access to up-to-date information such as news, sports, weather and
stock quotes when you subscribe to Internet service with your service provider. Please contact your service provider for a list of available websites and service details.
To launch the Mobile Web Browser and access websites
through your wireless handset.
Press [MENU] or .
■
BROWSER MENU
The browser menu has various options. To access the browser menu,
press [MENU] or press .
HOME
When “Home” is selected from the Browser Menu, the phone
displays the homepage.
To display the homepage:
Press [MENU] or .
79
Using the Mobile Web Browser requires digital service and
is not available everywhere. Mobile Web text
messages/alert fees apply for messages/alerts both sent and
received. Airtime charges apply.
MENU FUNCTIONS
BREW
■
ERASING AN APPLICATION
Press [MENU] or .
Select “Settings -> Manage Apps” with
and press .
Select the application to be erased with
and press .
Press to remove it.
78
OR
MOBILE WEB BROWSER
MENU FUNCTIONS
ADDRESS
Selecting “Address” from the Browser Menu displays the URL of the
current page.
To select “Address”:
Press [MENU] or .
CLEAR MEMORY
The user may clear the cache, history, cookies and auto fill entries
from the memory.
To clear the browser memory:
Press [MENU] or .
SETTINGS
To select “Settings”:
Press [MENU] or .
81
•
Downloads: Selecting “Downloads” allows the user to
enable/disable the ability to download images, background
sounds, and objects when a URL is accessed.
•
Restart Browser: Selecting “Restart Browser” causes the
history and cache to be cleared and returns the user to the
homepage.
•
Scroll Mode: Selecting “Scroll Mode” allows the user to
select between time-square scrolling (referred to as block
scrolling) and smooth scrolling as well as selecting the speed
of the smooth scrolling. Scrolling speed choices are medium,
fast, and slow.
•
Send Referrer: When “Send Referrer” is selected
from the Settings menu, the browser allows the user to turn
on or off sending the refering URL.
MENU FUNCTIONS
MOBILE WEB BROWSER
BACK
When “Back” is selected from the Browser Menu, the phone displays the previous page in the history.
To return to the previous page:
Press [MENU] or .
FORWARD
When “Forward” is selected from the Browser Menu, the phone
displays the next page in the history. This is only available if the
user has navigated backward in the history.
To forward to the next page:
Press [MENU] or .
REFRESH
Selecting “Refresh” from the Browser Menu refreshes the current
page.
To select “Refresh”:
Press [MENU] or .
HISTORY
The history list is available from the Browser Menu and the user
may delete all stored pages from the history.
To select “History”:
Press [MENU] or .
80
MOBILE WEB BROWSER
MENU FUNCTIONS
83
MENU FUNCTIONS
MOBILE WEB BROWSER
82
•
Key Press Timeout: When the “Key Press Timeout” item is
selected from the Settings menu, the browser allows the
user to set the key press timeout as fast, medium or slow.
Medium is 1.5 seconds, slow is 2 seconds and fast is 1 second.
The key press timeout is the period of time after which the
cursor auto-advances to the next entry position. In most
cases, a single key can be used to enter more than one
character. Each time the key is pressed, the last character of
the line is replaced by the next choice for that key. As long
as the same key is re-pressed within key press timeout, the
last character cycles between all the choices for the key.
•
Connection Timeout: When the Connection Timeout item
is selected from the Settings menu, the browser allows the
user to set the connection timeout. The connection timeout
determines how long the browser will wait for a response
from the network for a network request.
•
About...: When “About” is selected, information
about the browser version, copyright information and
certificate information is displayed.
•
Encryption: Selecting “Encryption” from the
Advanced Menu enables the user access to Encryption
features of the browser.
1. Authentication: The “Authentication” item in the Encryption
menu allows the user to toggle authentication caching.
2. Root Certificate: The “Root Certificate” item in the Encryption
menu allows the user to view the list of certificates.
3. Current Certificate: The “Current Certificate” item in the
Encryption menu allows the user to view the current certificate.
This is only available if a secure connection is established.
ADVANCED
Selecting “Advanced” in the Browser Menu displays the advanced
menu items.
To select “Advanced”:
Press [MENU] or .
EXIT
When “Exit” is selected from the Browser Menu, the user exits out
of the browser and the phone returns to idle mode.
To exit the browser:
Press [MENU] or .
OR
Press .
MEDIA GALLERY
MENU FUNCTIONS
85
MENU FUNCTIONS
MEDIA GALLERY
84
■
IMAGES
GRAPHICS
This menu shows the list of downloaded still images.
Press [MENU] .
Scroll through the captured pictures to display the
photo you want to send and press [SEND].
Write your photo message.
To send the photo message, press [MENU]
select “Send”, then press .
To save the photo message, press [MENU]
select “Save to Outbox”, then press .
•
Press [MENU] to select 1.Erase, 2.Erase All, 3.Change Title.
ANIMATIONS
This menu shows the list of downloaded or saved images.
Press [MENU] .
Scroll through the captured pictures to display the
photo you want to send and press [SEND].
Write your photo message.
To send the photo message, press [MENU]
select “Send”, then press .
To save the photo message, press [MENU]
select “Save to Outbox”, then press .
•
Press [MENU] to select 1.Erase, 2.Erase All, 3.Change Title.
MEDIA GALLERY
MENU FUNCTIONS
87
MENU FUNCTIONS
MEDIA GALLERY
86
■
This menu shows the list of photos that have been taken with the
camera.
•
Press [MENU] to select 1.Erase, 2.Erase All, 3.Change Title.
■
TONES
This menu shows the list of downloaded ringtones.
Press [MENU] .
Scroll to the saved voice memo you want to send
then press [SEND].
Write your message.
To send the message, press [MENU]
select “Send”, then press .
To save the message, press [MENU]
select “Save to Outbox”, then press .
Press [MENU] .
Scroll through the captured pictures to display the
photo you want to send and press [SEND].
Write your photo message.
To send the photo message, press [MENU]
select “Send”, then press .
To save the photo message, press [MENU]
select “Save to Outbox”, then press .
SETTINGS
MENU FUNCTIONS
VOICE MAIL
To select a ringer type for receiving voice mail:
Press [MENU] .
Press to select “Tone 1, 2, 3, 4, 5”.
To confirm, press [SELECT].
VOLUME
Controls the Ringer, Key tone, Voice Call and Speaker Phone
volume.
RINGER
Controls the Ringer volume and alerts you to incoming calls in the
modes listed in the gray box below (You can also adjust the ringer
volume in standby mode with the side volume key):
Press [MENU] .
Select one of the following options by pressing .
To confirm, press .
89
MENU FUNCTIONS
SETTINGS
Customizes your phone and optimizes performance through a variety of settings.
■
SOUNDS
Sets Ringer Type, Volume, Alert, Roam Ringer, Tone Length and
Etiquette.
RINGER TYPE
To select a ringer type for incoming calls:
RINGER
Press [MENU] .
Select your desired ringer type.
Select one of the available ring types.
To confirm, press [SELECT].
MESSAGES
To select a ringer type for receiving messages:
Press [MENU] .
Press to select “Tone 1, 2, 3, 4, 5”.
To confirm, press [SELECT].
88
•
Left or Right key: Select “Ring Tones”, “Music Bells” or
“Downloads.”
•
Up or Down key: Select “Ringer.”
•
Downloads: Downloaded ringer types and familiar music.
•
Silent: Mute the ringer, press [MIN].
•
Ringer Off
•
Vibrate On
•
Ringer Mode: Up & Down (Level 1~5)
•
High & Vib: The ringer sounds after vibration,
press [MAX].
SETTINGS
MENU FUNCTIONS
ALERT
When set, this setting alerts you to the following handset changes:
MINUTE
Sounds an alert every minute during a call.
Press [MENU] .
Select “Off” or “On” with the .
To save, press .
ROAM
Sounds an alert when leaving a service area and entering a roaming
service area.
Press [MENU] .
Select “Off” or “On” with the .
To save, press .
CONNECT
Notifies you that a call has been successfully placed.
Press [MENU] .
Select “Off” or “On” with the .
To save, press .
91
MENU FUNCTIONS
SETTINGS
KEY TONE
To adjust the keypad tone:
Press [MENU] .
Adjust the keypad tone with the .
To save, press .
VOICE CALL
To adjust the earpiece volume:
Press [MENU] .
Adjust the earpiece volume with the .
To save, press .
SPEAKER PHONE
To adjust speaker phone volume:
Press [MENU] .
Adjusts the speaker phone volume using the .
To save, press .
90
•
Off (MIN- )
•
Level 1 - 5 (level 5, MAX- )
•
Level 1 - 5 (MIN- , MAX- )
•
Level 1 - 5 (MIN- , MAX- )
SETTINGS
MENU FUNCTIONS
ETIQUETTE
To place the phone in Etiquette Mode so all phone sounds are
muted:
Press [MENU] .
Select “Off” or “On” with the .
To save, press .
TONE LENGTH
To adjust tone length:
Press [MENU] .
Select “Normal” or “Long” with the .
To save, press .
93
•
Off: Etiquette Mode off.
•
On: Etiquette Mode on.
From standby mode, press and hold to turn Etiquette
Mode On/Off.
MENU FUNCTIONS
SETTINGS
92
FADE
Sounds an alert when entering an area where calls cannot be made
due to weak signal strength.
Press [MENU] .
Select “Off” or “On” with the .
To save, press .
ROAM RINGER
To select a different ringer to sound in a Roaming area:
Press [MENU] .
Select “Normal” or “Distinctive” with the .
To save, press .
•
Normal: Sounds the same ringer type as used in Home area.
•
Distinctive: Sounds a different ringer type.
SETTINGS
MENU FUNCTIONS
POWER ON
Press [MENU] .
Select “UTStarcom” with the .
Select a display from the Animation list using the
.
Press [SELECT] to save it.
POWER OFF
Press [MENU] .
Select “UTStarcom” with the .
Select a display from the Animation list using the
.
Press [SELECT] to save it.
RECEIVED
Press [MENU] .
Select Default to choose a pre-installed display,
Downloads or Photo # to choose a display you have
downloaded to your phone.
Select a display from the Animation and the
Graphic list using the .
Press [SELECT] to save it.
95
MENU FUNCTIONS
SETTINGS
94
■
DISPLAY
Allows you to customize the display.
MENU STYLE
To select a display menu style:
Press [MENU] .
Select “Grid” or “List” with the .
To save, press .
GRAPHICS
Allows you to set Wallpaper, Power On/Off image, Received/Dialed
image and Screen Saver.
WALLP
APER
Press [MENU] .
Select Default to choose a pre-installed display,
Downloads or Photo # to choose a display you have
downloaded to your phone.
Select a display from the Animation or the Graphic
list using the .
Press [SELECT] to save it.
SETTINGS
MENU FUNCTIONS
SUB SCREEN
Press [MENU] .
Select “Digital” or “Analog” with the .
To save, press .
GREETING MESSAGE
To input a personal greeting:
Press [MENU] .
The message field will be highlighted. Press
to choose between on and off. Press to move to
the next field, font. Press to choose a font color.
Press to move to the next field, BG. Press to
choose a BG color. Repeat for both fields. Press to
enter the message. Enter your greeting.
To save, press [SAVE].
97
MENU FUNCTIONS
SETTINGS
DIALED
Press [MENU] .
Select “Default” with the .
Select a display from the Animation list using the
.
Press [SELECT] to save it.
SCREEN SAVER
Set the number of seconds of inactivity before the Screen Saver
activates and select the Image that will be displayed on the LCD.
Press [MENU] .
Select “Time Setting” or “Screen Saver” with the
.
Press [SELECT] to save it.
96
•
Time Setting: Off, 5 Secs, 10 Secs, 20 Secs, 30 Secs.
•
Screen Saver: Select photo image.
(Photos/Multimedia/Images).
•
By pressing [MENU], the user can choose from the
following:
1. Erase: To erase pictures saved in the current album.
2. Erase All: To erase all pictures saved in the current album.
3. Change Title: To edit the title of a photo file.
•
Message: On/Off.
•
Font: White, Blue, Dark blue, Magenta, Gray, Black.
•
Bg: Transparent, White, Blue, Yellow, Gray, Black.
•
Entry Message: Enter message (Default-UTStarcom).
SETTINGS
MENU FUNCTIONS
■
DATA SVC.
CONNECTION
Choose the connection mode for the usage of your phone.
Press [MENU] .
Select one of the following connection modes with
the .
To save, press .
99
MENU FUNCTIONS
SETTINGS
98
CONTRAST
To adjust the display contrast:
Press [MENU] .
Select “Main LCD” or “Sub LCD” and select one of
the following options with the .
To save, press .
BACKLIGHT
Backlights the display, key pad and dimming for easy viewing in
dark places.
Press [MENU] .
Select “LCD”, “Key Pad” or “Dimming” and
select one of the following options with
the .
To save, press .
•
Main LCD: Level 1~5.
•
Sub LCD: Level 1~5.
•
LCD: 5 Secs/15 Secs/30 Secs/60 Secs/Always On.
•
Key Pad: 5 Secs/15 Secs/30 Secs/60 Secs/ Always On/
Always Off.
•
Dimming: On/Off.
•
Voice Call: To receive a voice call.
•
Data Only: To receive data when connected to PC.
This function is available only when the phone is connected
by data cable to a PC.
SETTINGS
MENU FUNCTIONS
RESTRICT
When you attempt to make a restricted call, “Please Enter your
code” appears on the screen.
DIALED
Blocks all dialed calls – except emergency calls – but allows an
incoming call to be placed.
Press [MENU] and enter your
password.
Press and select “Allow” or “Restrict” with
the .
To save, press .
RECENT CALLS
Blocks access to the Recent Calls List.
Press [MENU] and enter your
password.
Press and select “Allow” or “Restrict” with
the .
To save, press .
101
MENU FUNCTIONS
SETTINGS
100
■
SECURITY
Prevents unauthorized use of your phone. The following settings
can be restricted:
PHONE LOCK
Prevents the phone from being used without entering the password
first.
Press [MENU] and enter your
password.
Press and select “Lock Now”, “Lock on Power
Up” or “Unlock”.
To save, press .
The default password is the last 4 digits of your phone
number.
The default password is the last 4 digits of your phone
number.
•
Lock Now: Lock the phone now.
•
Lock on Power Up: Not locked, but it is automatically
locked when power is recycled.
•
Unlock: Do not lock the phone.
•
Allow: Allows a dialed call.
•
Restrict: Restricts a dialed call.
The default password is the last 4 digits of your phone
number.
•
Allow: Allows a recent call.
•
Restrict: Restricts a recent call.
SETTINGS
MENU FUNCTIONS
103
MENU FUNCTIONS
SETTINGS
102
CAMERA
Restricts access to the camera mode.
Press [MENU] and enter your
password.
Press and select “Allow” or “Restrict” with
the .
To save, press .
DATA CALL
Restricts a data call from being placed.
Press [MENU] and enter your
password.
Press and select “Allow” or “Restrict” with
the .
To save, press .
The default password is the last 4 digits of your phone
number.
•
Allow: Allows access to the camera.
•
Restrict: Restricts access to the camera.
•
Allow: Allows a data call.
•
Restrict: Restricts a data call.
The default password is the last 4 digits of your phone
number.
900#S
Restricts calling 900 dial service numbers.
Press [MENU] and enter your
password.
Press and select “Allow” or “Restrict” with
the .
To save, press .
LONG DISTANCE
Restricts calling long distance numbers – the phone is limited to
calling numbers within the area.
Press [MENU] and enter your
password.
Press and select “Allow” or “Restrict” with
the .
To save, press .
The default password is the last 4 digits of your phone
number.
•
Allow: Allows calls to a 900-dial service.
•
Restrict: Restricts calls to a 900-dial service.
•
Allow: Allows a long distance call.
•
Restrict: Restricts a long distance call.
The default password is the last 4 digits of your phone
number.
SETTINGS
MENU FUNCTIONS
105
MENU FUNCTIONS
SETTINGS
104
CHANGE CODE
Changes your 4-digit password.
Press [MENU] and enter your
password.
Press .
Enter a new password and press .
Enter the new password again and press .
SPECIAL #’S
Stores 3 phone numbers that can be called even in the lock mode.
Press [MENU] and enter your
password.
Press .
Select a location with the .
Press and input a phone number,
press again to save.
The default password is the last 4 digits of your phone
number.
The default password is the last 4 digits of your phone
number.
ERASE ALL
Clears all phone book, downloads, and photo gallery entries from
your phone.
Press [MENU] and enter your
password.
Press .
Press to check “Phone Book”, “Downloads” or
“Photo Gallery” and press to erase all the
items in those categories.
RESET PHONE
Resets phone to default settings.
Press [MENU] and enter your
password.
Press .
Select “Yes” or “No” with the .
Press .
To reset the phone, press .
The default password is the last 4 digits of your phone
number.
The default password is the last 4 digits of your phone
number.
When you select “Yes” and , you will see “Reset Phone!
this will reset to default settings” on the display.
SETTINGS
MENU FUNCTIONS
AUTO ANSWER
Automatically answers a call after a preset amount of time.
Auto Answer only works when the phone is open.
Press [MENU] .
Select one of the following with the
.
To save, press .
AUTO RETRY
Automatically redials a call up to 1~5 times after a set time interval.
Press [MENU] .
Retry time to field is shown. Press
to choose the amount of time. (Off, 3 Secs, 5 Secs, 7
Secs, 10 Secs.)
When a time is chosen for retry time, the repeat
field is shown. Press to highlight the repeat
field. Press to choose the amount of
repeats. (1 Time, 3 Times, 5 times).
To save, press .
107
•
Off/5 Secs/10 Secs/18 Secs.
This function will not be active when you select Vibrate,
Silent, Etiquette or Ringer Off as a ringer mode.
MENU FUNCTIONS
SETTINGS
106
■
OTHERS
ANSWER OPTIONS
CALL ANSWER
To select an answer mode:
Press [MENU] .
Select “Any Key” or “Send Key” with the
.
To save, press .
ACTIVE FLIP
To select active flip answer mode.
Press [MENU] .
Select “Off” or “On” with the .
To save, press .
•
Any Key: Press any key to answer an incoming call except
, , , , and .
•
Send Key: Press the only to answer a call.
•
When Active Flip On is selected, an incoming phone call can
be answered simply by opening the phone.
•
When Active Flip Off is selected, you will need to open the
phone and follow the Answer mode you have selected.
SETTINGS
MENU FUNCTIONS
109
MENU FUNCTIONS
SETTINGS
LANGUAGE
Selects the language in which letters are displayed on screen.
Press [MENU] .
Select either “English” or “Spanish” with the
.
To save, press .
VOICE PRIVACY
Enhances voice privacy and avoids tapping during a call.
Press [MENU] .
Select “Standard” or “Enhanced” with the
.
To save, press .
TTY MODE
Your phone is able to operate with a TTY (Teletypewriter) device in
digital mode. This feature is system dependent and may not be
available in all areas.
Press [MENU] .
Select one of the following options “TTY Off”,
“TTY + TALK”, “TTY + HEAR”, “TTY Full” with the
.
To save, press .
108
•
Enhanced: Makes it more difficult to wire tap.
LOCATION
To determine whether or not the network system can detect your
position:
Press [MENU] .
Select “911 Only” or “Location On” with the
.
To save, press .
•
911 Only: Your location will be hidden from network
& application except 911.
•
Location On: Your location is now available to the network.
SETTINGS
MENU FUNCTIONS
CHANGE NAM
Changes the NAM used by the phone when you have multiple
registrations.
Press [MENU] .
Select “NAM1” or “NAM2” with the .
To save, press .
PRL ID
Displays the phone’s PRL (Preferred Roaming List).
Press [MENU] .
To return to the previous page, press .
111
MENU FUNCTIONS
SETTINGS
110
■
SYSTEM
SET MODE
Selects the Preferred System.
Press [MENU] .
Select one of the following options “Automatic B”,
“Automatic A”, “Home Only” with the .
To save, press .
NAM SETTING
Enables Auto NAM (Number Assignment Modules) or manually
selects a NAM.
AUTO NAM
Automatically switches phone to proper NAM when you have
multiple NAM registrations.
Press [MENU] .
Select “No” or “Yes” with the .
To save, press .
•
Automatic B: Scans the radio channels based on the
Automatic B setting.
•
Automatic A: Scans the radio channels based on the
Automatic A setting.
•
Home Only: Only within your home area or home affiliated
area.
TOOLS
MENU FUNCTIONS
■
VOICE TOOLS
VOICE MEMO
Voice Memo allows you to record a reminder message that can be up
to 60 seconds. To record a memo:
Press [MENU] .
To record a voice memo, press . Instructions will
be displayed and you will hear “Please record at the
tone”.
- To stop recording a memo, press [STOP] or
[PAUSE/RESUME].
- Press [MENU] after recording a voice memo
to “Re-record” or “Review”.
- Press [SAVE] to input a “Voice Memo” title,
then press . (See page 35 for more information
on entering letters, numbers and symbols.)
- Press [SEND] to access the “New Photo Msg”.
See “Create New Photo Message” on page 61.
To play voice memo, press . Select the message
you want to play then press [PLAY] or press
[MENU] to 1. Edit Title or 2. Send. Press [ERASE]
to erase the voice memo.
To play speaker mode, press . Select the
message you want to play then press [PLAY] or
press [MENU] to 1. Edit Title or 2. Send.
Press [ERASE] to erase the voice memo.
113
MENU FUNCTIONS
SETTINGS
112
■
PHONE INFO.
Displays the software, hardware and BREW versions of your phone:
S/W VERSION
Press [MENU] .
The software version appears.
To return to the previous page, press .
H/W VERSION
Press [MENU] .
The hardware version appears.
To return to the previous page, press .
BREW VERSION
Press [MENU] .
The “BREW” software version appears.
To return to the previous page, press .
TOOLS
MENU FUNCTIONS
115
MENU FUNCTIONS
TOOLS
To erase all voice memos, press . “Erase all
voice memos?” will be displayed. Press to erase
all voice memos.
VOICE DIAL
Voice Dial allows you to call a person by simply saying their name.
To access Voice Dial:
Press [MENU] .
To record a voice dial, press . The phone book
list will be displayed alphabetically. Select a name
and press . Instructions will be displayed and
you will hear “Name Please”.
- Say the name for the voice tag and repeat the
name when prompted. You will hear “Added”.
To play a voice dial, press . Highlight the
message you want to play then press [PLAY].
Press [ERASE] to erase the voice dial.
To play speaker mode, press . Highlight the
message you want to play then press [PLAY].
Press [ERASE] to erase the voice dial.
To erase all voice dials, press . “Removing all
voice tags Proceed?” will be displayed. Press to
erase all voice dials.
114
TRAIN WORDS
Train allows you to use Control words to make a call without using
the keypad.
YES
Use to train or untrain the Voice Recognition with the control
word, “Yes”.
Press [MENU] .
“Please listen closely to hear instructions” will be
displayed and you will hear “Now training control
words. Please say the word yes”.
Say “Yes”. You will hear “Again”. Say “Yes” again.
You will hear “Training word successful”.
NO
Use to train or untrain the Voice Recognition with the control
word, “No”.
Press [MENU] .
“Please listen closely to hear instructions” will be
displayed and you will hear “Now training control
words. Please say the word no”.
Say “No”. You will hear “Again”. Say “No” again.
You will hear “Training word successful”.
TOOLS
MENU FUNCTIONS
117
MENU FUNCTIONS
TOOLS
116
WAKE-UP
Use to train or untrain the Voice Recognition with the control
word, “Wake-Up”.
Press [MENU] .
“Please listen closely to hear instructions” will be
displayed and you will hear “Now training control
words. Please say the word Wake-Up”.
Say “Wake-Up”. You will hear “Again”.
Say “Wake-Up” again. You will hear “Training word
successful”.
UNDO TRAIN ALL
Undo Train All erases all “trained” words.
Press [MENU] .
“Undo voice recognition for all procedures?” will
be displayed. Press to undo all trained words.
VOICE SETTING
SET ACTIVE
Allows the user to activate or deactivate voice dial service.
Press [MENU] .
Select “Active Flip” or “Send Key” by pressing the
.
To save, press .
HFK MODE
While using the Hands Free Kit, activates or deactivates the voice
recognition function.
Press [MENU] .
Scroll to HFK Mode. Select “On” or “Off” by
pressing .
To save, press .
TOOLS
MENU FUNCTIONS
■
SCHEDULE
Sets an event reminder.
ADD NEW PLAN
Press [MENU] .
Move the to choose a date in the
calendar and press .
The date field is highlighted. Press to set the
alarm options.
DATE
Use the keypad to change or enter the date then
press .
TIME
Use the keypad to set a time and press to select
“AM” or “PM” then press .
PLAN
Use the keypad to input a plan message then
press .
119
MENU FUNCTIONS
TOOLS
VOICE RECOGNITION MODE
Voice Recognition (VR) enables you to place calls using your voice
and to record voice memos.
Press and hold until your phone turns to Voice
Recognition mode.
“Please say the name after the prompt tone” will
be displayed and you will hear “Name please”.
NAME
Press and hold until your phone turns to Voice
Recognition mode.
Say a tag name when prompted. The number and
name will appear on the display and you will hear
“Calling (name)”.
118
If there are no recorded voice dial entries, a “No entries
recorded” message will be displayed.
TOOLS
MENU FUNCTIONS
121
MENU FUNCTIONS
TOOLS
SETTING
Select an alert time interval option (On Time, 10 Min
Before, 30 Min Before, 1 Hour Before, No Alarm) by
pressing .
RINGER
To set a Ringer, press [MENU], then select
“Default” or “Change” using the .
To save it press [SELECT].
Press [SAVE] to save it or [CLR] to return to
the calendar.
The date of the event will be marked on your
calendar.
VIEW PLAN
To view the Event List,
press [MENU] .
Move the to choose an event and
press or [ERASE]. Press [MENU], then
select “Erase All” using the .
“Erase all plans?” will be displayed. Press to
delete.
120
•
Default: To set default ringer type.
•
Change: Choose a ringer type from the list.
■
ALARM
You can set up to 3 alarms.
To display alarm entries, press [MENU] .
Select one of the entries using the .
To set a new alarm, choose alarm 1, 2 or 3.
To edit an existing alarm, select that alarm.
Press .
The setting field will be highlighted. Press to
select alarm options.
SETTING
Use the to select a setting for the alarm (Once,
Daily, Weekly, Monthly, Off).
DATE
Use the keypad to change or enter the date for the
alarm then press . If Weekly is chosen for the setting, date field becomes a day of the week.
•
Once: Select a single date for the alarm.
•
Daily: Select alarm for same time each day.
•
Weekly: Select “Monday”, “Tuesday”, “Wednesday”,
“Thursday”, “Friday”, “Saturday”, “Sunday”.
•
Monthly: Select day 1 through 31.
•
Off
TOOLS
MENU FUNCTIONS
123
MENU FUNCTIONS
TOOLS
TIME
Use the keypad to set a time for the event and press
to select “AM” or “PM” then press .
SNOOZE SETTING
Use the to select a Snooze setting.
(Off, 1 time after 5 min, 1 time after 10 min, 3 times by
5 min)
RINGER
To set a “Ringer” press [MENU], then select “Default”
or “Change” using the . To save it
press [SELECT] to save it.
PLAN
Using the keypad, input an alarm message then
press .
To save an alarm setting press [SAVE].
122
•
Default: To set default ringer type.
•
Change: Choose a ringer type from the list.
■
MEMO PAD
Your phone includes an internal memo pad that can be used to
compose and store reminders and notes.
ADD MEMO
To compose a memo (there is an 80-letter limit):
Press [MENU] .
Input a new text memo. (Please refer to page 35 for
more details on entering letters, numbers & symbols.)
Press to save memo.
VIEW MEMO
To view a saved memo:
Press [MENU] .
The list of all memos, in saved order, is displayed.
Select a memo and press .
- To erase a memo, press [ERASE].
- To add a new memo, press [MENU]
“New Memo”.
- To erase all memos, press [MENU]
“Erase All”.
The selected memo will appear. To edit it, press
[MENU], select “Edit” and input a new text memo,
then press to save edit memo.
TOOLS
MENU FUNCTIONS
125
•
Use the to select another city.
MENU FUNCTIONS
TOOLS
124
SETTINGS
To select memo pad background image:
Press [MENU] .
Select (Paper/Pattern/Sea/Sky/Flower) by pressing
.
To save, press .
■
CALCULATOR
To access the calculator:
Press [MENU] .
Follow the instructions below to calculate 8*6/4-2.5
To reset, press [RESET].
•
Input 8.
•
Press (*).
•
Input 6.
•
Press (/).
•
Input 4.
•
Press (-).
•
Input 2 and press the to input (.).
•
Press 5, .
•
Answer appears on the right side of the grey box
below calculation.
■
WORLD CLOCK
To display the time and date in pre-programmed cities:
Press [MENU] .
Select a city with the .
The world map appears with the city, its date and
time.
To return to the previous page, press .
Since daylight saving time is not applied, it may be
different from the actual time during DST.
CAMERA
MENU FUNCTIONS
127
MENU FUNCTIONS
TOOLS
126
■
STOP WATCH
Simultaneously times up to six different events.
To operate the stop watch:
Press [MENU] .
To measure a time period.
- To start the stop watch, press [START].
- To pause it, press [STOP].
- To resume it, press or [RESET]. To return to
the previous page, press [EXIT].
To time up to six events at once:
- To start, press [START].
- To stop a time period and continue measuring
another one, press [CONT].
- To stop the second and continue measuring a third
one, press [CONT].
- To measure up to six time periods, repeat the above
steps.
- To stop the stop watch, press [STOP].
- To review the results, press [VIEW].
- To return to the stop watch, press [OK].
- To reset it, press [RESET].
■
TAKE A PHOTO
Taking pictures with your phone’s built-in camera is as simple as
choosing a subject, pointing the lens, and pressing a button. You can
activate the Camera Mode and take pictures when the phone is
open.
TAKING A PHOTO THROUGH THE MENU
Press [MENU] .
Point the camera lens at your subject.
You can check the photo framing through the main
display screen.
Press , or the side camera button to take the
photo.
To save the photo, press [SAVE] then input a
photo title and press . To go back to idle mode
without saving the photo, press . To send the
photo to someone, press .
OR
CAMERA
MENU FUNCTIONS
ZOOM
Press to change the magnification. (Zoom to
1x, 2x or 4x magnification.)
UNDER [MENU] - SUB LCD
The sub LCD will show a representation of the photo to
be taken. Use the sub LCD to help frame yourself for a
self portrait.
UNDER [MENU] - FLASH
To activate the flash function. (Off / On this shot /
Always On / Auto Flash)
UNDER [MENU] - SELF TIMER
To activate the camera’s timer function.
(Off / 5 Secs / 10 Secs)
UNDER [MENU] - ADD FRAMES
To select your favorite fun photo frame to decorate
your photo.
UNDER [MENU] - IMAGE CONTROLS
To select an option from the following.
129
MENU FUNCTIONS
CAMERA
TAKING A PHOTO IN IDLE MODE
Press or to activate Camera Mode.
Point the camera lens at your subject.
You can check the photo framing through the main
display screen.
Press the side camera button or press to take
the photo.
To save the photo, press [SAVE] then input a
photo title and press . To go back to idle mode
without saving the photo, press . To send the
photo to someone, press .
CAMERA MODE OPTIONS
When the phone is open and in Camera Mode, several user options
are available.
GALLERY
Press [GALLERY] to enter Review Mode. From there
you can view the captured pictures, view a running
count of stored pictures and more.
RESOLUTION
Press to adjust the photo size from High
(480x640 pixels) to Med (240x320 pixels) to Low
(120x160 pixels). The current photo size appears at the
top of the display screen.
128
•
Brightness: Auto/Manual
•
Image Effect: Normal/Sepia/Gray/Negative/Emboss/Sketch
•
White Balance: Auto/Sunny/Cloudy/Tungsten/Fluorescent
•
Quality: High/Medium/Low
4x magnification only occurs when you are in low
resolution 120x160 pixels.
CAMERA
MENU FUNCTIONS
131
MENU FUNCTIONS
CAMERA
UNDER [MENU] - SHUTTER SOUND
To select a shutter sound. (Off / Shutter 1 / “Ready 123”
/ Say “Cheese”)
■
PHOTO GALLERY
Your phone enters Review Mode after taking a photo.
Press [MENU] .
Press to select a photo.
130
•
In Review Mode you can view all the pictures you have
taken, store selected images in your phone, send pictures to
the Online Album, delete images and access additional
photo options.
•
Press [MENU] to display the following options :
1. Thumbnail: To switch the display from full-screen to thumbnail view.
2. Edit Title: Edit the photo’s title.
3. Send Photo: Upload the photo to a message.
4. Assign Picture: Assigns the selected photo to display for specific
tasks. (Wallpaper/Screen Saver/Picture Caller ID/
Incoming Call).
5. Erase: Erase the current photo from your phone.
6. View Lists: Displays all photos.
7. Photo Info: Displays information on the selected photo,
such as title, date/time, size, etc.
•
Press [CAM] to return to Camera mode to take another
photo.
■
PHOTO MESSAGE
Once you’ve taken a photo, you can use the messaging capabilities of
your phone to instantly share it with family and friends. To send a
photo to a recipient’s email address or to their wireless phone:
Press [MENU] .
Press for “New Photo” or for a “Saved
Photo”. If you are looking for a saved photo, scroll
through the captured photos to select the photo you
want to send.
Highlight the photo and press .
Under “Send To”, enter the email address or mobile
phone number and press .
Under “Message”, press . The photo will come
up with the flashing cursor underneath. Enter the
message and press . Press [MENU] to
1. Voice Record, 2. Insert Q.Text, 3. Delete Photo,
4. Insert Sound, 5. Insert Slide or 6. Slide Duration.
Under “Subject”, enter a subject line for the
message. Press .
If you want to send the photo to any additional
recipients, enter their information under “CC” or
“BCC’. Press [MENU] to 1. Find, 2. Save or
3. Msg. Group.
CHAPTER 5
SAFETY AND
WARRANTY
This chapter addresses the safety guidelines and precautions to
follow when operating your phone. Before operating your phone,
please be aware of all the safety details.
This chapter contains the terms and conditions of services and the
warranty for your phone. Please review them thoroughly.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES
SAFETY INFORMATION FOR FCC RF EXPOSURE
SAR INFORMATION
FCC HEARING-AID COMPATIBILITY (HAC) REGULATIONS FOR
WIRELESS DEVICES
FDA CONSUMER UPDATE
12 MONTH LIMITED WARRANTY
CHAPTER 5 SAFETY AND WARRANTY
MENU FUNCTIONS
CAMERA
To send the photo, press [MENU] then select
“Send”. Press [MENU] to 1. Send, 2. Preview,
3. Save to Outbox, 4. Priority or 5. Expiration.
Please refer to page 61 for more details on
“Create New Photo Message”.
■
HELP
Press [MENU] .
132
•
Use up/down keys to change photo size, left/right keys to
change zoom on preview mode.
•
Camera menu provides more settings:
1. SUB LCD: Enable previewing on external LCD.
2. FLASH: Provides just enough light to allow pictures to be taken.
3. SELF TIMER: Set timer to take a self portrait.
4. ADD FRAMES: Choose from 20 different frames to make picture
taking fun.
5. IMAGE CONTROLS
5.1 BRIGHTNESS
5.2 IMAGE EFFECT
5.3 WHITE BALANCE
5.4 QUALITY
6. SHUTTER SOUND: Select a sound to use for shutter.
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
SAFETY AND WARRANTY
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is
illegal in some states. Remember, safety comes first. Check the laws
and regulations on the use of phones in the areas where you drive.
Always obey them.
Also, if using your phone while driving, please:
If you must use the phone while driving, please use one-touch,
speed dialing, and auto answer modes.
An airbag inflates with great force. DO NOT place objects, including
both installed or portable wireless equipment, in the area over the
airbag or in the air bag deployment area. If in-vehicle wireless
equipment is improperly installed and the air bag inflates, serious
injury could result.
135
SAFETY AND WARRANTY
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends
out radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld
wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards
bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. For example, over
120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available
body of research to develop the ANSI Standard (C951).
The design of your phone complies with the FCC guidelines (and
those standards).
ANTENNA CARE
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could
damage the phone and may violate FCC regulations.
134
Read This Information Before Using Your
Handheld Portable Cellular Telephone
1* : American National Standards Institute.
2* : National Council on Radiation protection and measurements.
3* : International Commission on Nonionizing Radiation Protection.
•
Give full attention to driving. Driving safely is your first
responsibility.
•
Use hands-free operation, if available.
•
Pull off the road and park before making or answering a
call, if driving conditions so require.
WARNING: Failure to follow these instructions may lead to
serious personal injury and possible property damage.
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
SAFETY AND WARRANTY
POSTED FACILITIES
Turn your phone OFF where posted notices so require.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC and Transport Canada Regulations prohibit using your phone
while in the air. Turn your phone OFF before boarding an aircraft.
BLASTING AREAS
To avoid interfering with blasting operations, turn your phone OFF
when in a “blasting area” or in areas posted: “Turn off two-way
radio.” Obey all signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even
death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gas
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust, or metal powders; and any other area where you would
normally be advised to turn off your vehicle’s engine.
137
SAFETY AND WARRANTY
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF energy.
However, certain electronic equipment may not be shielded against
the RF signals from your wireless phone.
PACEMAKERS
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a
handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are
consistent with the independent research by and recommendations
of Wireless Technology Research.
Persons with pacemakers :
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the
manufacturer of your device to determine if they are adequately
shielded from external RF energy. Your physician may be able to
assist you in obtaining this information.
Turn your phone OFF in healthcare facilities when any regulations
posted in these areas instruct you to do so. Hospitals or healthcare
facilities may be using equipment that could be sensitive to
external RF energy.
136
•
ALWAYS keep the phone more than six inches from your
pacemaker when the phone is turned on.
•
Do not carry the phone in a breast pocket.
•
Use the ear opposite the pacemaker to minimize the
potential for interference.
•
If you have any reason to suspect that interference is taking
place, turn your phone OFF immediately.
SAFETY INFORMATION FOR
FCC RF EXPOSURE
SAFETY AND WARRANTY
WARNING! READ THIS INFORMATION BEFORE USING
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of
the United States with its action in Report and Order FCC 96-326
adopted an updated safety standard for human exposure to radio
frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety
standard previously set by both U.S. and international standards
bodies. The design of this phone complies with the FCC guidelines
and these international standards. Use only the supplied or an
approved antenna. Unauthorized antennas, modifications, or
attachments could impair call quality, damage the phone, or result
in violation of FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes into contact with
the skin, a minor burn may result. Please contact your local dealer
for replacement antenna.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the
back of the phone kept 2.0 cm. from the body. To maintain
compliance with FCC RF exposure requirements, use only belt-clips,
holsters or similar accessories that maintain a 2.0 cm. separation
distance between the user’s body and the back of the phone,
including the antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
139
For more information about RF exposure, please visit the
FCC website at www.fcc.gov.
WARNING!
•
This product contains a chemical known to the State of
California to cause cancer.
•
This product contains a chemical known to the State of
California to cause birth defects or other reproductive
harm.
SAFETY AND WARRANTY
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of
equipment. Before operating, read all instructions and cautionary
markings on (1) AC Adaptor (2) Battery and (3) Product Using
Battery.
138
•
DO NOT use this equipment in an extreme environment
where high temperature or high humidity exists.
•
DO NOT abuse the equipment. Avoid striking, shaking or
shocking. When not using, lay down the unit to avoid
possible damage due to instability.
•
DO NOT expose this equipment to rain or spilled beverages.
•
DO NOT use unauthorized accessories.
•
DO NOT disassemble the phone or its accessories. If service
or repair is required, return unit to an authorized cellular
service center. If unit is disassembled, the risk of electric
shock or fire may result.
•
DO NOT short-circuit the battery terminals with metal items
etc.
SAR INFORMATION
SAFETY AND WARRANTY
The SAR testing for Body-worn operation was performed with a
belt clip that provided a 20mm separation. The User’s Manual
indicates that any holsters/clips used with this device should contain
no metallic components.
The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance with
the FCC RF exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/ oet/fccid after searching on
PP4TX-215A.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications Industry Association
(CTIA) web-site at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram
of tissue. The standard incorporates a sub-stantial margin of safety
to give additional protection for the public and to account for any
variations in measurements.
141
SAFETY AND WARRANTY
SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits for
exposure to radiofrequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits
are part of comprehensive guidelines and establish permitted levels
of RF energy for the general population. The guidelines are based
on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of age and
health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are
conducted with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum
value. This is because the phone is designed to operate at multiple
power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g.,
at the ear and worn on the body) as required by the FCC for each
model. The highest SAR value for this model phone when tested for
use at the ear is 1.3 W/Kg and when worn on the body, as described
in this user guide, is 0.6W/Kg. (Body-worn measurements differ
among phone models, depending upon available accessories and
FCC requirements). While there may be differences between the
SAR levels of various phones and at various positions, they all meet
the government requirement for safe exposure.
140
FCC HEARING-AID COMPATIBILITY
(HAC) REGULATIONS FOR
WIRELESS DEVICES
SAFETY AND WARRANTY
In the above example, if a hearing aid meets the M2 level rating
and the wireless phone meets the M3 level rating, the sum of the
two values equal M5. This should provide the hearing aid user with
“normal usage” while using their hearing aid with the particular
wireless phone. “Normal usage” in this context is defined as a
signal quality that is acceptable for normal operation.
The M mark is intended to be synonymous with the U mark. The T
mark is intended to be synonymous with the UT mark. The M and T
marks are recommended by the Alliance for Telecommunications
Industries Solutions (ATIS). The U and UT marks are referenced in
Section 20.19 of the FCC Rules. The HAC rating and measurement
procedure are described in the American National Standards
Institute (ANSI) C63.19 standard.
143
SAFETY AND WARRANTY
FCC HEARING-AID COMPATIBILITY
(HAC) REGULATIONS FOR
WIRELESS DEVICES
On July 10, 2003, the U.S. Federal Communications Commission
(FCC) Report and Order in WT Docket 01-309 modified the
exception of wireless phones under the Hearing Aid Compatibility
Act of 1988 (HAC Act) to require digital wireless phones be
compatible with hearing-aids. The intent of the HAC Act is to
ensure reasonable access to telecommunications services for persons
with hearing disabilities.
While some wireless phones are used near some hearing devices
(hearing aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are more
immune than others to this interference noise, and phones also
vary in the amount of interference they generate.
The wireless telephone industry has developed a rating system for
wireless phones, to assist hearing device users find phones that may
be compatible with their hearing devices. Not all phones have been
rated. Phones that are rated have the rating on their box or a label
located on the box.
The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device
happens to be vulnerable to interference, you may not be able to
use a rated phone successfully. Trying out the phone with your
hearing device is the best way to evaluate it for your personal
needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are
likely to generate less interference to hearing devices than phones
that are not labeled. M4 is the better/higher of the two ratings.
Hearing devices may also be rated. Your
hearing device manufacturer or hearing
health professional may help you find this
rating. Higher ratings mean that the hearing
device is relatively immune to interference
noise. The hearing aid and wireless phone
rating values are then added together. A sum of 5 is considered
acceptable for normal use. A sum of 6 is considered for best use.
142
For information about hearing aids and digital wireless
phone
•
Fcc Hearing Aid Compatibility and Volume Control
http://www.fcc.gov/cgb/dro/hearing.html
•
Gallaudet University, RERC
http://tap.gallaudet.edu/DigWireless.KS/DigWireless.htm
•
Self Help for Hard of Hearing People Inc. [SHHH]
www.hearingloss.org/hat/TipsWirelessPhones.htm
•
The Hearing Aid Compatibility FCC Order
http://hraunfoss.fcc.gov/edocs_public/attachmatch/
FCC-03-168A1.pdf
FDA CONSUMER UPDATE
SAFETY AND WARRANTY
FDA belongs to an interagency working group of the federal agencies
that have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies belong
to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency
working group activities, as well. FDA shares regulatory responsibilities
for wireless phones with the Federal Communications Commission (FCC).
All phones that are sold in the United States must comply with FCC
safety guidelines that limit RF exposure. FCC relies on FDA and other
health agencies for safety questions about wireless phones. FCC also
regulates the base stations that the wireless phone networks rely upon.
While these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these base
stations are typically thousands of times lower than those they can get
from wireless phones. Base stations are thus not the subject of the safety
questions discussed in this document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with
built-in antennas, often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose the user to measurable
radiofrequency energy (RF) because of the short distance between the
phone and the user’s head. These RF exposures are limited by Federal
Communications Commission safety guidelines that were developed with
the advice of FDA and other federal health and safety agencies. When
the phone is located at greater distances from the user, the exposure to
RF is drastically lower because a person’s RF exposure decreases rapidly
with increasing distance from the source. The so-called “cordless
phones,” which have a base unit connected to the telephone wiring in a
house, typically operate at far lower power levels, and thus produce RF
exposures far below the FCC safety limits.
145
SAFETY AND WARRANTY
FDA CONSUMER UPDATE
U.S. Food and Drug Administration Center for Devices and Radiological Health
Consumer Update on Wireless Phones
144
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems
are associated with using wireless phones. There is no proof, however,
that wireless phones are absolutely safe. Wireless phones emit low levels
of radiofrequency energy (RF) in the microwave range while being used.
They also emit very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects (by heating tissue),
exposure to low level RF that does not produce heating effects causes no
known adverse health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies have suggested that
some biological effects may occur, but such findings have not been
confirmed by additional research. In some cases, other researchers have
had difficulty in reproducing those studies, or in determining the reasons
for inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be sold, as it
does with new drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to emit
radiofrequency energy (RF) at a level that is hazardous to the user. In
such a case, FDA could require the manufacturers of wireless phones to
notify users of the health hazard and to repair, replace or recall the
phones so that the hazard no longer exists. Although the existing
scientific data do not justify FDA regulatory actions, FDA has urged the
wireless phone industry to take a number of steps, including the
following:
• Support needed research into possible biological effects of RF of the
type emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the
user that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human
health.
FDA CONSUMER UPDATE
SAFETY AND WARRANTY
6. What is FDA doing to find out more about the possible health
effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priority
animal studies are conducted to address important questions about the
effects of exposure to radiofrequency energy (RF). FDA has been a
leading participant in the World Health Organization International
Electromagnetic Fields (EMF) Project since its inception in 1996.
An influential result of this work has been the development of a detailed
agenda of research needs that has driven the establishment of new
research programs around the world. The Project has also helped
develop a series of public information documents on EMF issues. FDA
and the Cellular Telecommunications & Internet Association (CTIA) have
a formal Cooperative Research and Development Agreement (CRADA) to
do research on wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government, industry, and
academic organizations. CTIA-funded research is conducted through
contracts to independent investigators. The initial research will include
both laboratory studies and studies of wireless phone users. The CRADA
will also include a broad assessment of additional research needs in the
context of the latest research developments around the world.
7. How can I find out how much radiofrequency energy exposure
I can get by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit radiofrequency
energy (RF) exposures. FCC established these guidelines in consultation
with FDA and the other federal health and safety agencies. The FCC limit
for RF exposure from wireless telephones is set at a Specific Absorption
Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is
consistent with the safety standards developed by the Institute of
Electrical and Electronic Engineering (IEEE) and the National Council on
Radiation Protection and Measurement. The exposure limit takes into
consideration the body’s ability to remove heat from the tissues that
absorb energy from the wireless phone and is set well below levels
known to have effects. Manufacturers of wireless phones must report
the RF exposure level for each model of phone to the FCC. The FCC
website (http://www.fcc.gov/oet/rfsafety) gives directions for locating the
FCC identification number on your phone so you can find your phone’s
RF exposure level in the online listing.
147
SAFETY AND WARRANTY
FDA CONSUMER UPDATE
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many
studies have suffered from flaws in their research methods. Animal
experiments investigating the effects of radiofrequency energy (RF)
exposures characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories. A few animal
studies, however, have suggested that low levels of RF could accelerate
the development of cancer in laboratory animals. However, many of the
studies that showed increased tumor development used animals that had
been genetically engineered or treated with cancer-causing chemicals so
as to be predisposed to develop cancer in the absence of RF exposure.
Other studies exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions under which people
use wireless phones, so we don’t know with certainty what the results of
such studies mean for human health. Three large epidemiology studies
have been published since December 2000. Between them, the studies
investigated any possible association between the use of wireless phones
and primary brain cancer, glioma, meningioma, or acoustic neu-roma,
tumors of the brain or salivary gland, leukemia, or other cancers. None
of the studies demonstrated the existence of any harmful health effects
from wireless phone RF exposures. However, none of the studies can
answer questions about long-term exposures, since the average period of
phone use in these studies was around three years.
5. What research is needed to decide whether RF exposure from
wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of
people actually using wireless phones would provide some of the data
that are needed. Lifetime animal exposure studies could be completed in
a few years. However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if one exists.
Epidemiological studies can provide data that is directly applicable to
human populations, but 10 or more years’ follow-up may be needed to
provide answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a cancer-causing
agent and the time tumors develop - if they do -may be many, many
years. The interpretation of epidemiological studies is hampered by
difficulties in measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement, such as the angle
at which the phone is held, or which model of phone is used.
146
FDA CONSUMER UPDATE
SAFETY AND WARRANTY
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps to
lower exposure to radiofrequency energy (RF), the measures described
above would apply to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF exposure. Some
groups sponsored by other national governments have advised that
children be discouraged from using wireless phones at all. For example,
the government in the United Kingdom distributed leaflets containing
such a recommendation in December 2000. They noted that no evidence
exists that using a wireless phone causes brain tumors or other ill effects.
Their recommendation to limit wireless phone use by children was strictly
precautionary; it was not based on scientific evidence that any health
hazard exists.
11. What about wireless phone interference with medical
equipment?
Radiofrequency energy (RF) from wireless phones can interact with some
electronic devices. For this reason, FDA helped develop a detailed test
method to measure electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless telephones. This test
method is now part of a standard sponsored by the Association for the
Advancement of Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and many other groups,
was completed in late 2000. This standard will allow manufacturers to
ensure that cardiac pacemakers and defibrillators are safe from wireless
phone EMI. FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers (IEEE). This standard
specifies test methods and performance requirements for hearing aids
and wireless phones so that that no interference occurs when a person
uses a “compatible” phone and a “compatible” hearing aid at the same
time. This standard was approved by the IEEE in 2000. FDA continues to
monitor the use of wireless phones for possible interactions with other
medical devices. Should harmful interference be found to occur, FDA will
conduct testing to assess the interference and work to resolve the
149
SAFETY AND WARRANTY
FDA CONSUMER UPDATE
8. What has FDA done to measure the radiofrequency energy
coming from wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a
technical standard for measuring the radiofrequency energy (RF)
exposure from wireless phones and other wireless handsets with the
participation and leadership of FDA scientists and engineers.
The standard, “Recommended Practice for Determining the Spatial-Peak
Specific Absorption Rate (SAR) in the Human Body Due to Wireless
Communications Devices: Experimental Techniques,” sets forth the first
consistent test methodology for measuring the rate at which RF is
deposited in the heads of wireless phone users. The test method uses a
tissue-simulating model of the human head. Standardized SAR test
methodology is expected to greatly improve the consistency of
measurements made at different laboratories on the same phone. SAR is
the measurement of the amount of energy absorbed in tissue, either by
the whole body or a small part of the body. It is measured in watts/kg (or
milliwatts/g) of matter. This measurement is used to determine whether
a wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency
energy from my wireless phone?
If there is a risk from these products—and at this point we do not know
that there is—it is probably very small. But if you are concerned about
avoiding even potential risks, you can take a few simple steps to
minimize your exposure to radiofrequency energy (RF). Since time is a
key factor in how much exposure a person receives, reducing the amount
of time spent using a wireless phone will reduce RF exposure.
• If you must conduct extended conversations by wireless phone every
day, you could place more distance between your body and the source
of the RF, since the exposure level drops off dramatically with distance.
For example, you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected to a remote
antenna.
Again, the scientific data do not demonstrate that wireless phones are
harmful. But if you are concerned about the RF exposure from these
products, you can use measures like those described above to reduce
your RF exposure from wireless phone use.
148
12 MONTH LIMITED
WARRANTY
SAFETY AND WARRANTY
UTStarcom Personal Communications (the Company) warrants to the
original retail purchaser of this UTStarcom handheld portable cellular
telephone, that should this product or any part thereof during
normal consumer usage and conditions, be proven defective in
material or workmanship that results in product failure within the
first twelve (12) month period from the date of purchase, such
defect(s) will be repaired or replaced (with new or rebuilt parts) at
the Company’s option, without charge for parts or labor directly
related to the defect(s).
The antenna, keypad, display, rechargeable battery and battery
charger, if included, are similarly warranted for twelve (12) months
from date of purchase.
This Warranty extends only to consumers who purchase the product
in the United States or Canada and it is not transferable or
assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial
number has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or
other product not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items
such as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding, dirt,
sand, weather conditions, battery leakage, blown fuse, theft or
improper usage of any electrical source.
151
SAFETY AND WARRANTY
FDA CONSUMER UPDATE
12. Where can I find additional information?
For additional information, please refer to the following resources:
• FDA web page on wireless phones
(http://www.fda.gov/cdrh/phones/index.html)
• Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
• International Commission on Non-Ionizing Radiation Protection
(http://www.icnirp.de)
• World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
• National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)
150
12 MONTH LIMITED
WARRANTY
SAFETY AND WARRANTY
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY.
ANY ACTION FOR BREACH OF ANY WARRANTY MUST BE BROUGHT
WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR AN
SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH
OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN
RENDERING SERVICE UNDER THIS WARRANTY OR LOSS OF USE
DURING THE TIME THE PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the
Company any liability other than expressed herein in connection
with the sale of this product.
Some states or provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitation or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you
may also have other rights, which vary from state to state or
province to province.
IN USA : UTStarcom Personal Communications
555 Wireless Blvd.
Hauppauge, NY 11788
(800) 229-1235
IN CANADA : UTStarcom Canada Company
5535 Eglinton Avenue West
Suite# 234
Toronto, ON M9C 5K5
(800) 465-9675
153
SAFETY AND WARRANTY
12 MONTH LIMITED
WARRANTY
The Company disclaims liability for removal or reinstallation of the
product, for geographic coverage, for inadequate signal reception
by the antenna or for communications range or operation of the
cellular system as a whole.
When sending your wireless device to UTStarcom Personal
Communications for repair or service, please note that any personal
data or software stored on the device may be inadvertently erased
or altered. Therefore, we strongly recommend you make a back up
copy of all data and software contained on your device before
submitting it for repair or service. This includes all contact lists,
downloads (i.e. third-party software applications, ringtones, games
and graphics) and any other data added to your device.
In addition, if your wireless device utilizes a SIM or Multimedia
card, please remove the card before submitting the device and
store for later use when your device is returned, UTStarcom
Personal Communications is not responsible for and does not
guarantee restoration of any third-party software, personal
information or memory data contained in, stored on, or integrated
with any wireless device, whether under warranty or not, returned
to UTStarcom Personal Communications for repair or service.
To obtain repairs or replacement within the terms of this Warranty,
the product should be delivered with proof of Warranty coverage
(e.g. dated bill of sale), the consumer’s return address, daytime
phone number and/or fax number and complete description of the
problem, transportation prepaid, to the Company at the address
shown below or to the place of purchase for repair or replacement
processing. In addition, for reference to an authorized Warranty
station in your area, you may telephone in the United States (800)
229-1235, and in Canada (800) 465-9672 (in Ontario call 416-695-
3060).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRAN-
TY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE
AND, IN NO EVENT, SHALL THE COMPANY’S LAIBILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
152
Loading...
