WELCOME
Thank you for choosing the up-to-date CDM-8910, our new
model, developed by top researchers to support the
CDMA2000 1X system through Qualcomm-manufactured
MSM6050 chips and CDMA technologies. This product allows
for high speed communication services, such as web browsing,
data & fax services, and a GUI animation menu.
T9 input mode makes it much easier to enter text, while VR
(Voice Recognition) makes the CDM-8910 more user friendly.
Other proven technologies include:
Full graphic display of 9 text input line and 1 icon line with
variable font size.
Easy to dial through the VR feature.
Easy to enter letters through the T9 text input mode.
Enhanced for web browsing & data services (i.e.; wireless
internet access, wireless fax send/receive, UP browser)
GUI & Animation display compliant with CDMA2000 1X.
CSTN 65K Color LCD.
Mobile camera (310K pixels)
Navigation Key and 21 keys aligned for more convenience.
Sophisticated features of speaker phone, and voice
recognition.
Additional services of text messaging and Web browsing on
top of authentication, call forwarding, call transfer, call
waiting.
IMPORTANT INFORMATION
This CDM-8910 user guide contains very important
information about how to handle and use the product. Please
read this manual thoroughly, pay attention to the warranty on
the back page and be alert to the exclusions and limitations of
your warranty, which are related with the unauthorized use of
components.
TABLE OF CONTENTS
CHAPTER 1. BEFORE USING YOUR PHONE .................................5
INSIDE THE PACKAGE .....................................................................................6
HANDSET DESCRIPTION.................................................................................7
THE FUNCTION KEYS.............................................................................................8
DISPLAY INDICATORS ...........................................................................................9
BATTERY USAGE...........................................................................................10
BATTERY INSTALLATION ....................................................................................10
BATTERY REMOVAL.............................................................................................11
BATTERY CHARGING ...........................................................................................11
POWER CONNECTION ......................................................................................11
Chapter 1
BATTERY TALK TIME .........................................................................................12
BATTERY LIFE TIME (FOR NEW BATTERY) ......................................................12
BATTERY HANDLING INFORMATION..........................................................13
DOs.........................................................................................................................13
DON’Ts...................................................................................................................13
CHAPTER 2. BASIC OPERATION ..................................................15
TURNING THE PHONE ON / OFF ..................................................................16
TURNING THE PHONE ON...................................................................................16
TURNING THE PHONE OFF..................................................................................16
ACCESSING THE MENU................................................................................17
MENU SUMMARY .........................................................................................18
BASIC FUNCTIONS ........................................................................................21
MAKING A CALL ...................................................................................................21
SPEAKER PHONE..................................................................................................22
PAUSE FEATURE ..................................................................................................22
ANSWERING A CALL............................................................................................23
3 WAY CALL FUNCTION ......................................................................................23
CALLER ID FUNCTION..........................................................................................24
CALL WAITING FUNCTION ..................................................................................24
ADJUSTING VOLUME ..........................................................................................24
ETIQUETTE ............................................................................................................25
KEY GUARD...........................................................................................................25
Chapter 2
DURING A CALL .............................................................................................26
MUTE (UNMUTE)..................................................................................................26
SPEAKER MODE ...................................................................................................26
SILENT (SILENT QUIT) .........................................................................................26
SEND MY PHONE # ..............................................................................................26
LOCATION .............................................................................................................26
PHONE INFO..........................................................................................................27
PHONEBOOK.........................................................................................................27
CALL HISTORY ......................................................................................................27
MESSAGING .........................................................................................................27
MAKING AN EMERGENCY CALL..................................................................28
911 IN LOCK MODE ..............................................................................................28
911 USING ANY AVAILABLE SYSTEM ...............................................................28
CHAPTER 3. MEMORY FUNCTION...............................................29
STORING A PHONE NUMBER ......................................................................30
ENTERING LETTERS, NUMBERS & SYMBOLS ...........................................31
STANDARD INPUT MODE....................................................................................32
T9 INPUT MODE....................................................................................................33
NUMERIC MODE...................................................................................................34
Chapter 3
SYMBOL MODE ....................................................................................................34
MAKING A CALL THROUGH THE PHONE BOOK ........................................35
SPEED DIAL#’S......................................................................................................35
CHAPTER 4. MENU FUNCTION ....................................................37
CALL HISTORY ...............................................................................................38
ALL CALLS.............................................................................................................38
OUTGOING CALLS ...............................................................................................39
INCOMING CALLS ................................................................................................40
MISSED CALLS .....................................................................................................41
Chapter 4
ERASE HISTORY ...................................................................................................42
ALL CALLS..........................................................................................................42
OUTGOING CALLS .............................................................................................42
INCOMING CALLS..............................................................................................42
1
TABLE OF CONTENTS TABLE OF CONTENTS
MISSED CALLS ..................................................................................................43
AIR TIME ................................................................................................................43
LAST CALL..........................................................................................................43
ALL CALLS..........................................................................................................43
PHONE BOOK .................................................................................................44
FIND .......................................................................................................................44
NEW ENTRY ..........................................................................................................45
SPEED DIAL#’S......................................................................................................46
MY PHONE # .........................................................................................................46
GROUP...................................................................................................................47
ADD NEW GROUP .............................................................................................47
CHANGE GROUP NAME ....................................................................................47
ERASE GROUP ...................................................................................................48
PICTURES .......................................................................................................49
TAKE A PHOTO .....................................................................................................49
TAKING A PICTURE THROUGH THE MENU......................................................49
TAKING A PICTURE IN IDLE MODE...................................................................49
TAKING A PICTURE WITH THE PHONE CLOSED .............................................50
CAMERA MODE OPTIONS ................................................................................51
MY PICTURES .......................................................................................................52
ONLINE ALBUMS..................................................................................................53
ACCOUNT INFO ....................................................................................................53
DOWNLOADS.................................................................................................54
START DOWNLOADS...........................................................................................54
DOWNLOADING APPLICATIONS ........................................................................54
GAMES ..................................................................................................................55
RINGERS................................................................................................................56
SCREEN SAVERS ..................................................................................................57
OTHERS .................................................................................................................58
TOOLS.............................................................................................................59
SCHEDULE.............................................................................................................59
ADD NEW PLAN.................................................................................................59
VIEW PLAN.........................................................................................................60
MEMO PAD............................................................................................................61
Chapter 4
ADD MEMO........................................................................................................61
VIEW MEMO ......................................................................................................61
SETTINGS ...........................................................................................................61
ALARM...................................................................................................................62
CALCULATOR........................................................................................................64
STOPWATCH.........................................................................................................65
WORLD CLOCK .....................................................................................................66
SETTINGS .......................................................................................................67
SOUNDS ................................................................................................................67
VOLUME.............................................................................................................67
RINGERS.............................................................................................................70
ALERTS...............................................................................................................71
ROAM RINGER...................................................................................................72
TONE LENGTH ...................................................................................................72
DISPLAY.................................................................................................................73
MENU STYLE......................................................................................................73
GRAPHICS ..........................................................................................................73
SUB LCD.............................................................................................................74
GREETING ..........................................................................................................75
BACKLIGHT ........................................................................................................75
CONTRAST .........................................................................................................76
ROAMING ..............................................................................................................77
DATA SVC..............................................................................................................78
CONNECTION.....................................................................................................78
GAMES/TOOLS .....................................................................................................79
BACKLIGHT ........................................................................................................79
VOLUME.............................................................................................................79
MSG ALERT........................................................................................................79
LOCATION .............................................................................................................80
SECURITY ..............................................................................................................81
LOCK PHONE ....................................................................................................81
CHANGE LOCK...................................................................................................81
2
SPECIAL #’S .......................................................................................................82
LIMIT USE...........................................................................................................82
ERASE PBOOK ...................................................................................................85
ERASE DOWNLOADS ........................................................................................85
RESET PICTURE ACCOUNT ...............................................................................86
RESET PHONE....................................................................................................86
AIRPLANE MODE ..................................................................................................87
OTHERS .................................................................................................................88
CALL ANSWER...................................................................................................88
ACTIVE FLIP........................................................................................................88
Chapter 4
AUTO ANSWER..................................................................................................89
AUTO REDIAL.....................................................................................................89
LANGUAGE.........................................................................................................90
TTY MODE..........................................................................................................90
VOICE SETTING..................................................................................................91
KEY GUARD........................................................................................................91
PHONE INFO..........................................................................................................92
VERSION.............................................................................................................92
ICONS .................................................................................................................92
CHAPTER 5. VOICE SERVICE ........................................................93
VOICE RECOGNITION MODE ........................................................................94
NAME.....................................................................................................................94
VOICE TOOLS MENU.....................................................................................95
VOICE MEMO ........................................................................................................95
VOICE DIAL............................................................................................................96
TRAIN WORDS ......................................................................................................97
Chapter 5
YES .....................................................................................................................97
NO.......................................................................................................................97
WAKE-UP............................................................................................................98
UNDO TRAIN ALL...............................................................................................98
CHAPTER 6.
WHEN A NEW MESSAGE ARRIVES ...........................................................100
VOICE MAIL ..................................................................................................100
SEND TEXT MSG....................................................................................................101
SEND PICTURE MSG..............................................................................................102
INBOX ......................................................................................................................103
OUTBOX ..................................................................................................................105
SAVED .....................................................................................................................107
WEB ALERTS...........................................................................................................108
QUICK TEXT ............................................................................................................109
ERASE ALL ..............................................................................................................110
SETTINGS................................................................................................................111
VOICE MAIL, TEXT MESSAGE AND PICTURE MESSAGE
REPLY ...............................................................................................................103
REPLY WITH COPY ..........................................................................................103
FORWARD........................................................................................................104
ERASE...............................................................................................................104
SAVE TO CONTACT..........................................................................................104
SAVE TO SAVED...............................................................................................104
SAVE TO QUICK TEXT......................................................................................104
LOCK & UNLOCK .............................................................................................104
CHECKING SENT TEXT MESSAGES .................................................................105
RESEND............................................................................................................105
SEND TO...........................................................................................................105
Chapter 6
ERASE...............................................................................................................106
SAVE TO CONTACT..........................................................................................106
SAVE TO SAVED...............................................................................................106
LOCK & UNLOCK .............................................................................................106
STATE ...............................................................................................................106
SAVED..................................................................................................................107
WEB ALERTS.......................................................................................................108
QUICK TEXT ........................................................................................................109
ERASE ALL ..........................................................................................................110
SAVE SENT MSG ................................................................................................111
DEFAULT CALLBACK..........................................................................................111
REMINDER...........................................................................................................111
.99
3
TABLE OF CONTENT
AUTO ERASE.......................................................................................................112
INBOX ...............................................................................................................112
OUTBOX ...........................................................................................................112
ENTRY MODE......................................................................................................112
MESSAGE LOG ...................................................................................................113
INCOMING LOG ...............................................................................................113
OUTGOING LOG...............................................................................................113
RESET LOG.......................................................................................................113
RETRY TIME ........................................................................................................114
EDIT VOICE CB# ..................................................................................................114
PUSH SETTINGS.................................................................................................114
CHAPTER 7. MOBILE BROWSER ................................................115
START MOBILE BROWSING .......................................................................116
ACCESS THE INTERNET.....................................................................................116
MOBILE BROWSER MENU..........................................................................116
BACK ....................................................................................................................116
HOME...................................................................................................................116
FORWARD ...........................................................................................................116
BOOKMARKS ......................................................................................................117
SEARCH ...............................................................................................................117
GO TO URL ..........................................................................................................117
SHOW URL ..........................................................................................................117
RELOAD ...............................................................................................................117
SETTINGS............................................................................................................118
HOMEPAGE......................................................................................................118
Chapter 7
DOWNLOADS ..................................................................................................118
RESTART BROWSER .......................................................................................118
VIEW TITLE REGION ........................................................................................118
SCROLL MODE ................................................................................................118
SEND REFFERER..............................................................................................119
KEY PRESS TIMEOUT ......................................................................................119
SECURITY .........................................................................................................119
HISTORY ..............................................................................................................120
ABOUT..............................................................................................................120
CHAPTER 8. SAFETY AND WARRANTY ....................................121
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ..............122
EXPOSURE TO RADIO FREQUENCY SIGNALS..............................................122
ANTENNA CARE...............................................................................................122
DRIVING SAFETY ................................................................................................123
ELECTRONIC DEVICES .......................................................................................124
PACEMAKERS ..................................................................................................124
OTHER MEDICAL DEVICES .............................................................................124
POSTED FACILITIES.........................................................................................124
OTHER SAFETY GUIDELINES ............................................................................125
AIRCRAFT .........................................................................................................125
Chapter 8
BLASTING AREAS ............................................................................................125
POTENTIALLY EXPLOSIVE ATMOSPHERES ...................................................125
PRECAUTIONS ....................................................................................................126
SAFETY INFORMATION FOR FCC RF EXPOSURE ....................................127
CAUTIONS...........................................................................................................127
BODY-WORN OPERATION ..............................................................................127
VEHICLE MOUNTED EXTERNAL ANTENNA (OPTIONAL, IF AVAILABLE)......127
SAR INFORMATION.....................................................................................128
FDA CONSUMER UPDATE ..........................................................................130
PROTECT YOUR WARRANTY .....................................................................134
12 MONTH LIMITED WARRANTY...............................................................135
Chapter 1
BEFORE USING
YOUR PHONE
This chapter provides important information about using the
CDM-8910 including:
INSIDE THE PACKAGE
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
C
H
1
“Licensed by QUALCOMM Incorporated under one or more of the following Patents : U.S.Patent No.
4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No. 5,101,501 U.S. Patent No.
5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”
4
5
INSIDE THE PACKAGE
HANDSET DESCRIPTION
This package should include all items pictured below.
C
If any are missing or different, immediately contact the retailer where
H
you purchased the cellular telephone.
1
AC Charger
Handset
Standard Battery
This cellular telephone is a tri mode (800 MHz AMPS/CDMA, 1900
MHz PCS) CDMA2000 1X digital cellular telephone with camera and
web browsing capabilities. The CDM-8910 weighs 3.7oz. And the
dimensions are 4.5" X 1.8" X 0.9".
Antenna
Earjack
Camera
Menu
Camera
Lens
Volume Key
If the folder is
suddenly closed
while controlling
volume with side
keys, the changed
value won't be
saved.
Earpiece
LCD Screen
Function Keys
Navigation &
Camera Button
C
H
1
User Manual
Handstrap
END/
Power Key
Belt Clip
Microphone
Send Key
6
7
HANDSET DESCRIPTION HANDSET DESCRIPTION
C
H
1
Display Indicators
See page 9 for a list of icons.
Text & Graphic area
DISPLAY INDICATORS
Signal Strength - Current signal strength: the
more lines, the stronger the signal.
C
H
1
Roaming
Phone is out of home area.
Service Indicator
Indicates call is in progress, indicates the
phone cannot receive a signal from the system.
Message
New text or voice message.
Digital Mode
Phone is operating in digital mode.
Analog Mode
Menu
Soft Key Indications
Shows the functions currently
assigned to each soft key and
displays some icons.
Find
Short Press : Camera Menu.
Long Press : Camera
Preview.
Phone is operating in analog mode.
Battery
THE FUNCTION KEYS
Phone Book
ScheduleMobile Web
Messaging
Press to make or receive a call.
Press and hold to turn on VR mode.
Press to turn the phone on/off, to terminate a call
or to return to the initial page.
(Left Soft Key) Press to access the menu or
function displayed on bottom line.
(Right Soft Key) Press to access the phone
book find or function displayed on bottom line.
Press to clear a digit from the display or to return
to the previous page.
Press and hold to enable speaker phone mode.
Press and hold to enter etiquette mode.
Press and hold to enter lock mode.
In Idle Mode
- Press UP to access the Phone Book,
DOWN to access the Messaging, RIGHT
for Schedule and LEFT for Mobile Web.
Inside the menu
- Within a menu, use to scroll through
menu options, or to select a function
displayed on the screen.
8
Battery charging level – the more blocks, the
stronger the charge.
Mute
Phone is mute during a call.
Silence
Appears when Silent is selected as the ring mode.
Emergency Call
Blinks when an emergency call is in progress.
Auto Answer
Phone is in answering machine mode.
Speaker phone
Phone is in speaker phone mode.
Etiquette
Phone will vibrate when call is received.
Schedule
Appears when either an event or an alarm is set.
Ring Mode
Appears when a ringer is set as a ringer
mode.
Dormant
Indicates the phone is in disconnection condition
while on “Server Connection”.
9
BATTERY USAGE BATTERY USAGE
C
H
1
Fax Only
Receives a fax call as a voice call.
Data Only
Receives an async. call as a voice call.
GPS Icon
Indicates the Location Service of your cellular
telephone
1X
Phone is in the 1x service area.
Silent
Displays when Silent is in use during a call.
Web Msg
This is Web Alert message.
Web + Text Msg
Phone has Web Alert Msg and Text Msg.
Web + Voice Msg
Phone has Web Alert Msg and Voice Msg.
Web + Text + Voice Msg - Phone has Web Alert
Msg, Text Msg and Voice Msg.
Web Browser
Phone is in the progress of Browser.
is disabled/enabled.
BATTERY INSTALLATION
Place the battery on the back of the handset
1
u
and slide into place.
Push the battery down
v
until it locks into place.
BATTERY REMOVAL
Pull down the release latch, lift up the
1
u
battery and
remove the battery from the
v
handset.
If the battery is not correctly placed in the compartment, the
handset will not turn on and/or the battery may detach during use.
BATTERY CHARGING
POWER CONNECTION
Plug the AC charger into a standard outlet.
1
Plug the other end of the AC Charger into the
2
bottom of your cellular telephone. The battery
must be installed on to the cellular telephone.
C
H
1
10
11
BATTERY USAGE BATTERY HANDLING INFORMATION
C
H
1
•
When you charge the battery with the phone power off, you
will see a charging status screen. You cannot operate the
phone until it is powered on.
•
The battery is not charged at the time of purchase.
•
Fully charge the battery before use.
•
It is more efficient to charge the battery with the handset
powered off.
•
The battery must be connected to the phone in order to
charge it.
•
Battery operating time gradually decreases over time.
•
If the battery fails to perform normally, you may need to
replace the battery.
BATTERY TALK TIME
The operating time is subject to your handset usage and configuration.
Battery Capacity
STD 1000 mAh
EXT 1700 mAh
DCS PCS AMPS
200 m
330 m
190 m 80 m
330 m 130 m
BATTERY LIFE TIME (FOR NEW BATTERY)
The operating time is subject to your handset usage and configuration.
Battery Capacity
STD 1000 mAh
EXT 1700 mAh
DCS PCS AMPS
107~190 hours 150~250 hours
160~220 hours 380~450 hours
20 hours
35 hours
DOs
l Only use the battery and charger approved by the
manufacturer.
l Only use the battery for its original purpose.
l Try to keep batteries in a temperature between
41ºF (5ºC ) and 95ºF (35ºC).
l If the battery is stored in temperatures above or
below the recommended range, give it time to
warm up or cool down before using.
l Completely drain the battery before recharging.
It may take one to four days to completely drain.
l Store the discharged battery in a cool, dark, and
dry place.
l Purchase a new battery when its operating time
gradually decreases after fully charging.
l Properly dispose of the battery according to local
laws.
DON’Ts
l Don’t attempt to disassemble the battery – it is a
sealed unit with no serviceable parts.
l Don’t accidentally short circuit the battery by
carrying it in your pocket or purse with other
metallic objects such as coins, clips and pens.
This may critically damage the battery.
l Don’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the
capacity and lifetime of the battery.
l Don’t dispose of the battery into a fire.
C
H
1
These times are for a new battery. Talking and Standby time may
decrease over time.
12
13
MEMO
C
H
1
C
H
2
Chapter 2
BASIC OPERATION
This chapter addresses and explains the basic features of your
cellular telephone including.
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
14
15
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
TURNING THE PHONE ON
Press and hold , until “Bell” Logo appears
1
and the tone sounds.
C
H
2
•
To select a logo, refer to page 73 for more details.
(Settings>Display>Graphics) for more detail.
•
If your cellular telephone is locked when “Password” appears
on the display, enter your 4-digit password to unlock your
cellular celephone.
•
The default password is the last 4 digits of your phone number.
TURNING THE PHONE OFF
Press and hold , until your “Bell” Logo
1
Your Cellular Telephone can be customized via the menu. Each
function can be accessed by scrolling with the Navigation Key or by
pressing the number that corresponds with the menu item.
Call History
Phonebook
Messaging
Pictures
Web
To access the menu in the idle mode,
1
Downloads
Voice SVC
Tools
Settings
press [MENU].
Use the Navigation Key to scroll through the
2
menu.
C
H
2
appears.
l To search through the menu in numerical order, press down.
•
Immediately change or recharge the battery when
“Low Battery Warning Power Off” appears on the display.
Memory may possibly be damaged if the phone turns off
due to the battery completely draining.
•
Turn the phone off before removing or replacing the battery.
If the phone is on, unsaved data may be lost.
To return to the previous page, press [CLR].
3
To exit the current menu and return to the idle
mode, press .
Press the Navigation Key to enter a function
4
when its main page is displayed or press its
assigned number to have direct access to
the function.
16
Hotkey
In idle mode, move the Navigation Key as follows to access these
functions:
•
Upward movement : Phonebook
•
Downward movement : Messaging
•
Rightward movement : Schedule
•
Leftward movement : Mobile Web
17
MENU SUMMARY MENU SUMMARY
C
H
2
1. Call History
2. Phonebook
3. Messaging
4. Pictures
5. Web
1. All Calls
2. Outgoing Calls
3. Incoming Calls
4. Missed Calls
5. Erase History
6. Air Time
1. Find
2. New Entry
3. Speed Dial#’s
4. My Phone #
5. Group
1. Send Text Msg
2. Send Picture Msg
3. Voice Mail
4. Inbox
5. Outbox
6. Saved
7. Web Alerts
8. Quick Text
9. Erase All
10. Settings
1. Camera
2. My Pictures
3. Online Albums
4. Account Info
1. Wireless Web
1. All Calls
2. Outgoing Calls
3. Incoming Calls
4. Missed Calls
1. Last Call
2. All Calls
1. Voice Mail
2. Inbox
3. Outbox
4. Saved
5. Web Alerts
6. Quick Text
1. Save Sent Msg
2. Default Callback
3. Reminder
4. Auto Erase
5. Entry Mode
6. Message Log
7. Retry Time
8. Edit Voice CB#
9. Push Settings
1. In Camera
2. Save to Phone
1. Read Msg
2. Entire Msg
1. Inbox
2. Outbox
1. Incoming Log
2. Outgoing Log
3. Reset Log
6. Downloads
7. Voice SVC
8. Tools
9. Settings
1. Games
2. Ringers
3. Screen Savers
4. Applications
5. Others
1. Voice Memo
2. Voice Dial
3. Train Words
1. Schedule
2. Memo Pad
3. Alarm
4. Calculator
5. Stopwatch
6. World Clock
1. Sounds
2. Display
1. Get New
1. Get New
1. Get New
1. Get New
1. Get New
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Yes
2. No
3. Wake-Up
4. Undo Train All
1. Add New Plan
2. View Plan
1. Add Memo
2. View Memo
3. Settings
1. Alarm 1
2. Alarm 2
3. Alarm 3
1. Volume
2. Ringers
3. Alerts
4. Roam Ringer
5. Tone Length
1. Menu Style
2. Graphics
3. Sub LCD
1. Ringer
2. Voice Call
3. Key Beep
4. Messages
5. Speaker
6. Power On
7. Power Off
1. Voice Call
2. Messages
3. Voice Mail
1. Service
2. Minute
3. Connect
4. Fade
5. Low Signal
1. Screen Saver
2. Power On
3. Power Off
4. Incoming Call
C
H
2
18
19
MENU SUMMARY
BASIC FUNCTIONS
4. Greeting
5. Backlight
3. Roaming
4. Data SVC
C
H
2
5. Games/Tools
6. Location
7. Security
8. Airplane Mode
9. Others
10. Phone Info
6. Contrast
1. Connection
1. Backlight
2. Volume
3. Msg Alert
1. Lock Phone
2. Change Lock
3. Special #’s
4. Limit Use
5. Erase PBook
6. Erase Downloads
7. Reset Picture
Account
8. Reset Phone
1. Call Answer
2. Active Flip
3. Auto Answer
4. Auto Redial
5. Language
6. TTY Mode
7. Voice Setting
8. Key Guard
1. Version
2. Icons
1. Special #1
2. Special #2
3. Special #3
1. Outgoing Calls
2. Call History
3. Pictures
4. Data Calls
5. 900#s
6. Long Distance
1. Hands Free Kit
2. Headset
MAKING A CALL
Enter a phone number.
1
To modify the phone number you have entered :
•
To erase one digit at a time press .
•
To erase the entire number, press and hold .
Press .
2
The indicator , appears on the display
•
If “CALL FAILED” appears on the display or the line is
busy, press or .
•
If you activate the “AUTO REDIAL” function, the phone
will automatically redial for the number of times you have
selected. (Refer to page 89).
•
When you place or receive a call from stored phone
numbers, both the name and phone number will be
displayed.
•
There is another way to make a call through the VR mode,
which is called “VAD (Voice Activated Dialing)”.
Please refer to page 96 (Voice Service) for more details.
To end a call, press .
3
C
H
2
20
21
BASIC FUNCTIONS BASIC FUNCTIONS
SPEAKER PHONE
The speaker phone feature lets you hear audio through the speaker and
talk without holding the phone.
C
H
To activate the speaker phone in idle, answering
1
or calling modes, press and hold .
2
The phone returns to normal (Speaker phone off)
2
after ending a call or when the phone is turned off
and back on.
PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail, calling cards).
Insert a pause after a phone number then enter another group of
numbers. The second set of numbers is dialed automatically after the
pause. This feature is useful for dialing into systems that require a code.
To insert a pause, enter a phone number then
1
press [OPTIONS]. Select either a Hard Pause
(“P” appears) or a Timed Pause (“T” appears).
Press to dial or [SAVE] to store.
2
Please refer to page 30 for more details about
storing a phone number.
ANSWERING A CALL
To answer a call, press any key except , ,
1
or .
l By pressing , you can select either “Any Key”
or “Talk Key” to answer a call. lf “Talk Key” is selected, the
phone can only be answered by pressing .
See page 88 for more information.
To end the call, press .
2
In Auto Answer Mode a call is automatically answered after a
preset number of ring tones. See page 89 for more details.
3 WAY CALL FUNCTION
With Three-Way Calling, you can talk to two people at the same time.
When using this feature, the normal airtime rates will be applied for
each of the two calls.
Enter a number you wish to call and press .
1
Once you have established the connection,
2
enter the second number you wish to call and
press .
C
H
2
22
When you’re connected to the second party,
3
press again to begin your three-way call.
If one of the people you called hangs up during your call, you
and the remaining caller stay connected. If you initiated the call
and are the first to hang up, all three callers are disconnected.
23
BASIC FUNCTIONS BASIC FUNCTIONS
CALLER ID FUNCTION
Identifies caller by displaying their phone number. If the caller’s name
and number are already stored in your phone book, they both will
appear.
C
H
The caller ID is stored in the call history.
2
CALL WAITING FUNCTION
Notifies you of an incoming call when you are already on a call by
sounding a beep tone and displaying the caller’s phone number.
To answer another call while on the phone,
1
press . This places the first call on hold.
To switch back to the first caller, press
again.
Call Waiting is a system dependent feature. Please contact your
service provider for details.
ADJUSTING VOLUME
Adjust the volume of the ringer, key beep and speaker.
Press [MENU] then select one
1
of the following.
l
Ringer : Controls the ringer volume.
l
Voice Call : Controls the earpiece volume.
l
Key Beep : Controls the key pad tone.
l
Messages : Controls the received messages alert volume.
l
Speaker : Controls the speaker volume.
l
Power On : Controls the power on volume.
l
Power Off : Controls the power off volume.
ETIQUETTE
Mutes key tones and activates the vibration mode to alert you of an
incoming call or message.
To turn etiquette mode on/off, press and hold .
1
will be displayed to indicate etiquette mode
is active.
KEY GUARD
The Key guard feature of your cellular telephone locks the keypad to
protect against accidental key presses when the phone is turned on
and no call is in progress. You can still answer or silence an incoming
call.
To lock the phone, press and hold .
1
To unlock the phone, press any key then input
2
the password.
Lock feature will deactivate when the phone is powered
l
off. Upon next power up, you will need to press to
lock phone again.
Press 1, 2, 3 to unlock the key guard.
C
H
2
Adjust volume then press to save it.
2
To adjust earpiece volume during a call move the Navigation
Key up or down.
24
25
DURING A CALL DURING A CALL
To display menu options during a call, press [MENU].
MUTE (UNMUTE)
The caller cannot hear you or any sounds from your side but you can
still hear them.
C
H
2
Press [MENU] .
1
l
To deactivate, press [MENU] .
l
The phone will automatically unmute in Emergency
Call or Callback mode.
SPEAKER MODE
Activates the speaker phone when you are on a call. The phone
returns to normal (speaker phone off) after ending or call or when the
phone is turned off and back on.
Press [MENU] .
1
SILENT (SILENT QUIT)
Prevent the other end from hearing tones if any key is pressed during
a call.
Press [MENU] .
1
Press [MENU] to deactivate it.
l
SEND MY PHONE #
Automatically transmits your phone number to a pager during a call.
(Dependent on pager service)
PHONE INFO.
Notifies you of your handset information.
Please see page 92 for more details.
Press [MENU] .
1
PHONEBOOK
Display the Phonebook menu.
Press [MENU] .
1
CALL HISTORY
Display the Call History menu.
Press [MENU] .
1
MESSAGING
Enables you to send a message (SMS) during a call.
(Refer to page 101 for more datails.)
Press [MENU] .
1
C
H
2
Press [MENU] .
1
LOCATION
Enables the network to locate your current location through Global
Positioning System (GPS). (Refer to page 80 for more details.)
Press [MENU] .
1
26
27
MAKING AN EMERGENCY CALL
This 911 feature puts the phone in the Emergency Call Mode when
you dial the preprogrammed emergency number, 911.
It also operates in the lock mode and out of the service area.
911 IN LOCK MODE
The 911 call service is available even in the lock mode.
C
H
Enter “911” then press .
2
1
The call connects.
2
The phone exits the Lock Mode for 5 minutes.
3
When the call ends, the phone returns to the Lock Mode.
l
Chapter 3
MEMORY FUNCTION
C
H
3
911 USING ANY AVAILABLE SYSTEM
Enter “911” then press .
1
The call connects.
2
The phone maintains the Emergency Mode
3
for 5 minutes.
l
The phone returns to the Lock Mode.
l
While the phone is in the emergency mode for 5 minutes,
the phone can receive an incoming call from any available
system. However it can't make a call
28
This chapter addresses memory functions including:
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
29
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
The phone book stores up to 300 entries.
Enter phone number then press .
1
Choose “New Entry” or “Existing Entry”.
2
Press [OK] to select.
The Phone # will appear above a list of icons.
3
C
H
.
3
The name of the icon is displayed below the list.
Use the Navigation Key to choose the type of #
you’re adding, as indicated by the icon.
Press [OK] to select.
Enter a name then press .
4
Please refer to page 31 for more details on
entering letters, numbers & symbols.
To change the input mode, press [Abc].
Press the Navigation Key down to select the
group. To select other options, press the
Navigation Key down.
l
Group : Family, Friends, Work, Etc.
l
Ringer.
Graphic.
l
l
Set Secret : Lock, Unlock.
l
The other fields are set to Numeric mode as a default.
To store the entry, press [SAVE].
5
“Phone Book Entry Saved!” or “Entry edited!”
will be displayed.
The input mode (Alpha editor) will be automatically activated when
necessary to enter letters and numbers. As shown below, there are
4 available modes ; Standard input mode (Abc), T9 input mode
(T9Word), Numeric mode (NUM), and Symbol mode (Symbols).
The input mode indicator appears on the upper right
of the display when letters and numbers are entered.
To select the desired input mode among the 4 modes
below, press [MODE], then enter letters and
numbers.
Input mode indicator
T9Word : T9 mode
Abc : Abc mode
NUM : Number mode
Symbols : Symbol mode
The following illustrates the function assigned to each key in the
Alpha Editor.
KEY FUNCTION
Press to change mode.
Mode
Next
Space
Caps Lock
Clear
[T9Word][Abc][NUM][Symbols]
Press to view the next matching word if
the highlighted word is not the word you
intended.
Press to accept a word and add a space.
Press to select a letter case of the
standard text input or T9 text input mode.
[Abc], [ABC], and [abc] indicate the
standard text input.
[T9Word], [T9WORD], and [T9word]
indicate the predictive text input.
Press to delete a character to the left of
the cursor.
C
H
3
30
Save
Store the letters and numbers you enter.
31
ENTERING LETTERS, NUMBERS & SYMBOLS
ENTERING LETTERS, NUMBERS & SYMBOLS
STANDARD INPUT MODE
Use the digit keys to enter letters, numbers and characters.
Enter letters using the key pad as follows:
1
1
Key Pad
1
2ABC
C
H
3
3DEF
4GHI
:
9WXYZ
Time
1
A
D
G
W
Repetitions
:
2 times
.
B
E
H
:
X
Repetitions
3 times
@
C
F
Y
To change the input mode, press [Abc].
To enter a space, press . The cursor will
2
automatically move to the next column.
Repeat until letters are entered.
3
Text messages have a 140-character limit.
Picture message have a 120-character limit.
To delete one digit, press . To delete the
4
entire entry, press and hold .
To change from lowercase to uppercase,
5
press .
Select Abc mode, by pressing [Abc].
When you select this mode, the Abc icon appears as a visual
confirmation.
- Find the key that corresponds to the letter you want to enter.
- Press it as many times as needed for the letter to appear on the
screen.
- To enter the name “John”:
Press [ ] J
Press [ ] o
Press [ ] h
Press [ ] n
I
:
Repetitions
4 times
-
2
3
4
:
Z
Repetitions
5 times
’
A
D
G
:
9
T9 INPUT MODE
The T9 input mode incorporates a built-in-dictionary to determine a
word based on the entered characters. A word can be entered more
quickly by pressing a key once per character.
Select the T9Word mode by pressing [Abc].
1
Press a digit key once to enter the character
2
you want then enter all the characters to input
the word you want.
To view the next matching word, press .
3
To accept the matching word then enter a space,
4
press .
To enter a compound word.
•
Enter the first part of the word then press to accept it.
•
Enter the last part of the word then press to enter the word.
To enter “hilltop” in the T9 input mode.
- Press [Abc] to select the T9 input mode and to choose the
small letter case (T9Word).
- Press and you will see “hill” highlighted.
Press to select it.
- Press and you will see “top” highlighted.
C
H
3
32
33
ENTERING LETTERS, NUMBERS & SYMBOLS MAKING A CALL THROUGH THE PHONE BOOK
NUMERIC MODE
Allows you to enter numbers
Press [Abc] until the current input mode
1
changes to the “NUM (Numeric mode)”.
To enter a number, press a digit key.
2
C
H
3
SYMBOL MODE
Allows you to enter symbols.
Press [Abc] until the
1
“Symbols (Symbol mode)” appears.
Select the symbol you want to enter with the
2
Navigation Key.
l Use the Navigation Key to view a different line of symbols.
Press [ ],
or
Press [ ],
SPEED DIAL#’S
Press [MENU] .
1
To assign a phone number to a location, select
2
the location then press [SET].
If a phone number is already assigned to the
l
location, press [ERASE] and or [YES] to delete.
Select the entry with the Navigation Key and
3
press .
If the entry is set to secret, you will be asked for your
l
password.
•
“Unassigned” appears if the location is available.
•
If a phone number is set as Secret, you will have to enter the
password.
•
To call an assigned number, press & hold the last digit of the
speed dial #.
“Speed dial # X edited” will be displayed.
4
C
H
3
34
35
MEMO
Chapter 4
C
H
3
This chapter addresses accessing the menu and using its functions
and features to customize your cellular telephone.
MENU FUNCTION
CALL HISTORY
PHONE BOOK
PICTURES
DOWNLOADS
TOOLS
SETTINGS
C
H
4
36
37
CALL HISTORY
CALL HISTORY
In idle mode, you can access call history by pressing [MENU] .
ALL CALLS
Displays information about the 60 most recent incoming, outgoing or
missed calls.
To see a list of the 60 most recent incoming,
1
outgoing or missed calls, press [MENU] .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view call details, press .
2
C
H
Call details include date, time, and phone number.
4
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: Sends a message to the phone number.
l
Send Picture: Sends a MMS to the phone number.
l
Prepend: Adds numbers to the beginning of the phone
l
l
After 60 incoming, outgoing or missed calls, the oldest
call will automatically be erased from the history.
number.
Erase All: To erase all recent calls list.
OUTGOING CALLS
Displays information of the 20 most recently outgoing calls.
Place a call to a received number by simply pressing .
To see a list of the 20 most recent outgoing
1
calls, press [MENU] .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view outgoing call details, press .
2
Call details include date, time, and phone number.
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: Sends a message to the phone number.
l
Send Picture: Sends a MMS to the phone number.
l
Prepend: Adds numbers to the beginning of the phone
l
l
After the 20thoutgoing call, the oldest call will automatically be
erased from the history.
number.
Erase All: To erase all outgoing calls list.
C
H
4
38
39
CALL HISTORY CALL HISTORY
INCOMING CALLS
Displays information of the 20 most recently incoming calls.
Place a call to a received number by simply pressing .
To see a list of the 20 most recent incoming
1
calls, press [MENU] .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view incoming call details, press .
2
C
H
4
Call details include date, time, and phone number.
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: Sends a message to the phone number.
l
Send Picture: Sends a MMS to the phone number.
l
Prepend: Adds numbers to the beginning of the phone
l
l
After the 20thincoming call, the oldest call will automatically be
erased from the history.
number.
Erase All: To erase all incoming calls list.
MISSED CALLS
Displays information of the 20 most recently missed calls.
Place a call to a received number by simply pressing .
To see a list of the 20 most recently missed
1
calls, press [MENU] .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view missed call, use the navigation keys
2
to select then press .
Call details include date, time, and phone number.
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: Sends a message to the phone number.
l
Send Picture: Sends a MMS to the phone number.
l
Prepend: Adds numbers to the beginning of the phone
l
l
After the 20thmissed call, the oldest call will automatically be
erased from the history.
number.
Erase All: To erase all missed calls list.
C
H
4
40
41
CALL HISTORY CALL HISTORY
ERASE HISTORY
Erases individual Call History entries.
ALL CALLS
Press [MENU] .
1
You will see a message on the display
2
(Erase All calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all of the entries from your Call History list.
OUTGOING CALLS
C
H
4
Press [MENU] .
1
You will see a message on the display
2
(Erase Outgoing calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all outgoing calls from your Call History list.
INCOMING CALLS
Press [MENU] .
1
MISSED CALLS
Press [MENU] .
1
You will see a message on the display
2
(Erase Missed calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all missed calls from your Call History list.
AIR TIME
Checks the talk time and manages your calls within the limit you set,
and the message “Not intended for billing purposes” appears for 5
seconds.
LAST CALL
Displays talk time of last call.
Press [MENU] .
1
The last call time appears on the display.
2
To return to the previous page, press [OK].
3
ALL CALLS
Displays talk time of all incoming and outgoing calls, excluding web
access calls.
C
H
4
You will see a message on the display
2
(Erase Incoming calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all incoming calls from your Call History list.
42
Press [MENU] .
1
View the time of the following items:
2
Voice Call: To display all the number of case calls or total
l
Data/Fax Call: To display all the number of case calls or total
l
To return to the previous page, press [OK].
3
call time.
call time.
43
PHONE BOOK PHONE BOOK
Stores up to 300 entries, each of which can be assigned to a group.
Entries can be retrieved by name or group.
FIND
Retrieves an entry by name and calls by simply pressing .
You can review all the entries stored in your phone book list or find an
entry quickly by entering a name or its character string.
Press [MENU] .
1
2
The list of names in your phone book is
displayed alphabetically.
Use Navigation Key to select the name.
Enter a name or its character string or scroll
C
H
4
3
through the list with the Navigation Key.
Please refer to page 31 for more details on
entering letters, numbers & symbols.
All matching entries will be displayed. Highlight
4
an entry. To edit the entry, press .
Press [OPTIONS] to 1. Send Text, 2. Send
Picture, 3. Prepend, 4. View or 5. Erase.
l
If the entry is set to secret, you will be asked for your password.
(Refer to page 81 for password information.)
Please refer to page 101, page102 for more
details on “Send Text Msg” or “Send Picture Msg”.
NEW ENTRY
Adds a new entry.
To add a new entry to the phone book,
1
press [MENU] .
To enter a name or number, use the Navigation
2
Key to select the phone book field.
PHONE BOOK FIELDS :
l
Name/Mobile/Home/Office/Pager/Fax/E-Mail/Group/Ringer
/Graphic/Memo/Set Secret.
Please refer to page 31 for more details on entering
letters, numbers & symbols.
3.1 To save the entry, press [SAVE].
3
3.2 To return to the previous page, press .
C
H
4
To call the selected number, press .
5
44
45
PHONE BOOK PHONE BOOK
SPEED DIAL#’S
In idle mode, calls can be placed to numbers stored in speed dial by
pressing & holding the location number on the key pad. For a 2-digit
location number, press the first number, then press and hold the
second number.
Press [MENU] .
1
To assign a phone number to a location, select
2
the location then press [SET].
If a phone number is already assigned to the
l
location, press [ERASE] and [OK] to delete.
Select the entry with the Navigation Key and
C
H
4
3
press .
If the entry is set to secret, you will be asked for your
l
password.
•
“Unassigned” appears if the location is available.
•
If a phone number is set as Secret, you will have to enter
the password. (Refer to page 81 for password information.)
•
To call an assigned number, press & hold the last digit of
the speed dial #.
“Speed dial # X edited” will be displayed.
4
GROUP
Allows you to classify phone entries into groups. Existing groups
include Family, Friends, Work, Etc. and All. A maximum of seven
groups is allowed.
ADD NEW GROUP
To add a new group, press [MENU] .
1
A maximum of seven groups is allowed.
Press [OPTIONS] to select “Add Group”.
2
Input a new group name.
3
To save, press .
4
CHANGE GROUP NAME
Select an existing group name with the
1
Navigation Key.
Press [OPTIONS] to select “Rename”.
2
Input a new group name.
3
C
H
4
MY PHONE #
To display your phone number and service provider:
Press [MENU] .
1
To return to the previous page, press [OK].
2
46
To save, press .
4
The default group names (All, Etc.) cannot be changed.
47
PICTURESPHONE BOOK
ERASE GROUP
C
H
4
Use the Navigation Key to select, then delete
1
the group.
To delete it, press [ERASE].
2
To erase it, press or [YES].
3
The default group names (All, Etc.) cannot be erased.
TAKE A PHOTO
Taking pictures with your phone’s working integrated camera is as simple
as choosing a subject, pointing the lens, then pressing a button. You can
activate the Camera Mode and take pictures when the phone is open.
TAKING A PICTURE THROUGH THE MENU
Press [MENU] .
1
Point the camera lens at your subject.
2
You can check the picture framing through the
main display screen.
Press or the Side Camera button to take
3
the picture.
To send the picture to someone, press [NEXT]
4
then select “Send Picture”.
You can receive a call while in camera mode just not when
sending. All incoming voice calls will be forwarded to
voicemail.
TAKING A PICTURE IN IDLE MODE
Press the Side Camera button to activate
1
Camera Mode.
C
H
4
Point the camera lens at your subject.
2
You can check the picture framing through the
main display screen.
Press the Side Camera button to take the
3
picture.
To send the picture to someone, press [NEXT]
4
then select “Send Picture”.
4948
PICTURESPICTURES
TAKING A PICTURE WITH THE PHONE CLOSED
Press and hold the side camera button to
1
activate camera mode.
Point the camera lens at your subject.
2
You can check the picture framing through
the sub display screen.
Press the Side Camera button to take the
3
picture.
Please be sure that Side button can operate the camera
C
H
functionality when the folder of handset is closed.
4
CAMERA MODE OPTIONS
When the phone is open and in Camera Mode, several user options
are available.
RESOLUTION
Press the Navigation Key up or down to adjust the picture size from
High (640x480 pixels) to Med (320x240 pixels) to Low (160x120 pixels).
The current picture size appears at the top of the display screen.
ZOOM
Press the Navigation Key left or right to change the magnification.
(Zoom to 1x, 2x or 4x magnification.)
UNDER [OPTIONS]
SELF PORTRAIT
Switch the viewfinder to the Sub LCD. (Take a picture of yourself by
checking the view on the Sub LCD.)
FLASH
Activate the flash function. (Off / On this shot / Always On)
SELF TIMER
Activate the camera’s timer function. (Off / 5 Secs / 10 Secs)
FUN FRAME
Select your favorite fun picture frame to decorate your picture then
press [SEL]. (Off / Angel Heart / Birthday / Bohemian / Bubble Bath /
Celebration / Circular Eyes / Coffee / Cupid / Enamored / Enlargement /
Female / Flower Frame / Flower Mirror / Frog / Funny Lips / Gentleman / Gift /
Ice Cream / Koala / Love Frame / Love Heart / Love Tree / Magic
Santaclause / Male / My Christmas / Noon Window / Postage Stamp /
Princess Frame / Red Man / Rose Grove / Santaclause / Seashore / Sexy
Lips / Sexy Woman / Sunflower / Sunglasses / Tree Frame / White Christmas
/ White Window / Winter Frame)
IMAGE CONTROLS
Select an option from the following. (Brightness / Image Effect / Quality)
SHUTTER SOUND
Select a shutter sound. (Shutter 1 / Shutter 2 / Say “Cheese” / Ready 123)
DATE
Display date on the take picture. (On/Off)
GO TO MY PICTURES
Go to your phone’s picture storage folder.
C
H
4
5150
PICTURESPICTURES
MY PICTURES
Press [MENU] .
1
Select an option from the following and
2
ONLINE ALBUMS
Press [MENU] .
1
Select a picture from your online Picture Mail.
2
press [OK].
Press [OPTIONS] to access the in online
In Camera: To store photos you have captured with your camera.
l
Save to Phone: To select the folder storing pictures you have
l
downloaded or assigned.
Press [OPTIONS] to access the in camera
3
options.
Upload to Albums: To select an option from the following to
C
H
4
l
Assign: To assign the selected picture to display for specific
l
l
l
l
l
tasks: (Picture ID / Screen Saver / Incoming Call)
Take New Picture: To return to Camera mode to take
Erase: To erase selected pictures. Select an option from the
following, then press [OK].
Edit Caption: To enter or edit a caption for the picture.
Picture Info: To display picture information such as caption,
upload pictures saved in your cellular
telephone to the Picture Mail Website.
another picture.
time/date,size,etc.
Press [OPTIONS] to access the save to phone
options.
Assign Picture ID: To display the picture for incoming calls from a
l
Assign Screen Saver: To display the picture as an LCD screen
l
Assign Incoming Call: To display the selected picture for all
l
Erase: Erase the current picture from your cellular telephone.
l
Expand: To switch the display from thumbnail to full-screen view.
l
4
To access “Send Picture Msg” press [SEND].
specific Contacts list entry.
saver.
incoming calls.
3
camera options.
l
Download: To download the selected picture file
l
Edit/Erase: Copy/Move-To copy or move pictures to a
l
Picture Info: To display information on the selected picture,
l
New Album: To create a new album.
l
Album List: To display album list.
l
Goto Picture: To take a new picture.
Expand: To switch the display from thumbnail to full-screen
l
When uploading/sending the picture, code the picture
through Lightsurf SSL(Secure Socket Layer) on Lightsurf Picture
Mail Server to transact it safely between Server and Handset.
ACCOUNT INFO
User purchases Picture Mail through the Web, Customer Solutions or
at point-of-sale with activation a real-time feed from cellular telephone
Billing system to LightSurf is sent to validate on both sides.
In the below example, user attempts to upload or Send the first time
(after they have purchased the Vision Picture Mail service), the
handset will display only the account password creation screens.
Press [MENU] .
1
to your cellular telephone.
selected album.
Edit Caption-To edit the picture’s caption.
Erase-To erase pictures saved in the current
album (or Uploads). Select This Picture,
Selected Pictures, or All Pictures.
Rotate Picture-To rotate the selected picture.
such as title,time/date,size,etc.
view.
C
H
4
Follow the procedures in “Mobile Browser Main
2
Menu” on page 115.
5352
DOWNLOADSDOWNLOADS
Your cellular telephone provides a unique feature -Downloads- that
enables you to download games, ringers, screen savers, applications
and more from your network to your cellular telephone. Please
contact your service provider for the availability of these services.
START DOWNLOADS
To launch “Downloads” from the standby mode,
1
press [MENU] .
When five or more icons appear on the screen,
2
select an application with Navigation Key.
To start the application, press [OK].
3
C
H
4
To end the application, press .
4
The phone will return to the standby mode.
DOWNLOADING APPLICATIONS
Press [MENU] .
1
Select “Get New” with Navigation Key and
2
press [OK].
The phone will access your service provider’s
3
server.
Follow the prompt to download applications.
When a prompt appears, press to proceed or
l
to cancel.
GAMES
You can play a variety of entertaining and graphically-rich games on
your cellular telephone. New games are easy to download and play.
Press [MENU] .
1
Select “Get New” then press [OK].
2
The Mobile Browser will launch and take you to
the “Game” download menu.
Use the Navigation Key to select the game you
3
wish to download.
From the item information page, select
4
“Purchase”.
A confirmation page will notify you that the game
5
has been purchased and show the folder that the
game stored. To download the game, select
“Download”.
Refer to page 115 for “Browser” as “Mobile Browser”.
C
H
4
Refer to page 115 for “Browser” as “Mobile Browser”.
5554
DOWNLOADS
DOWNLOADS
RINGERS
Press [MENU] .
1
Select “Get New” then press [OK].
2
The Mobile Browser will launch and take you to
the “Ringers” download menu.
Use the Navigation Key to select a ringer you
3
wish to download.
From the item information page, select “Buy”.
4
If you have not previously purchased an item,
C
H
4
you will be prompted to enter your account
password and create your purchasing profile.
A confirmation page will notify you that the ringer
5
has been purchased and is stored in the “My
Downloads” folder. To download the ringer,
select “Download”.
Refer to page 115 for “Browser” as “Mobile Browser”.
SCREEN SAVERS
Press [MENU] .
1
Select “Get New” then press [OK].
2
The Mobile Browser will launch and take you to
the “Screen Savers” download menu.
Use the Navigation Key to select the Screen
3
Savers you wish to download.
From the item information page, select “Buy”.
4
If you have not previously purchased an item,
you will be prompted to enter your account
password and create your purchasing profile.
A confirmation page will notify you that the
5
Screen Savers has been purchased and is stored
in the “My Downloads” folder. To download the
Screen Savers, select “Download”.
Refer to page 115 for “Browser” as “Mobile Browser”.
C
H
4
56
56
57
DOWNLOADS
TOOLS
OTHERS
Press [MENU] .
1
Select “Get New” then press [OK].
2
The Mobile Browser will launch and take you to
the “Others” download menu.
Use the Navigation Key to select the item you
3
wish to download.
From the item information page, select “Buy”.
4
If you have not previously purchased an item,
C
H
4
you will be prompted to enter your account
password and create your purchasing profile.
A confirmation page will notify you that the item
5
has been purchased and is stored in the “My
Downloads” folder.
Refer to page 115 for “Browser” as “Mobile Browser”.
SCHEDULE
Sets schedule and reminds you of that event.
ADD NEW PLAN
Press [MENU] .
1
Move the Navigation Key left, right, up or down to
2
choose a date in the calendar then press .
To select alarm options press the Navigation Key
3
downwards.
DATE SETTING
Use the keypad to change or enter the date
then press [OK].
TIME SETTING
Use the keypad to set a time and to select
“AM” or “PM” then press .
PLAN SETTING
Use the keypad to input a plan message then
press .
SETTING
Select an alert time interval option (On Time, 10 Min
Before, 30 Min Before, 1 Hour Before, No Alarm)
using the Navigation Key.
C
H
4
58
58
RINGER SETTING
To set a Ringer, press [OPTIONS], then select
“Default” or “Change” using the Navigation Key.
To save it press .
Default : To set default ringer type.
Change : To set custom ringer type.
59
TOOLS
TOOLS
C
H
4
Press [SAVE] to save it or [CLR] to
4
return to the calendar.
The date of the event will be marked on your
5
calendar.
VIEW PLAN
To view the Event List,
1
press [MENU] .
Move the Navigation Key to choose an event
2
then press or [ERASE].
Press [OPTIONS], then select “Erase All”
using the Navigation Key.
MEMO PAD
Your cellular telephone includes an internal memo pad that can be
used to compose and store reminders and notes.
ADD MEMO
To compose a memo (there is an 80-letter limit):
Press [MENU] .
1
Input a new text memo.
2
(Please refer to page 31 for more details on entering letters,
numbers & symbols.)
Press to save memo.
3
VIEW MEMO
To view a saved memo:
1.1. Press [MENU] .
1
1.2. To erase a memo, press [ERASE].
1.3. To add a new memo, press [OPTIONS]
“New Memo”.
1.4. To erase all memos, press [OPTIONS]
“Erase All”.
The list of all memos, in saved order, is displayed.
2
Select a memo then press .
The selected memo will appear. To edit it,
3
press [OPTIONS], select “Edit” and input a
new text memo.
Press to save edited memo.
4
C
H
4
60
60
SETTINGS
To select memo pad background image:
Press [MENU] .
1
Select (Paper/Pattern/Sea/Sky/Flower) with the
2
Navigation Key (left or right) then press .
61
TOOLS TOOLS
ALARM
You can set up to 3 alarms.
To display alarm entries, press [MENU] .
1
Select one of the entries using the Navigation Key.
2
To set a new alarm, choose alarm 1, 2 or 3.
To edit an existing alarm, select that alarm.
Press .
Press the Navigation Key down to select alarm
3
options.
C
H
4
SETTING
Use the Navigation Key to select a setting for the
alarm (Daily/Weekly/Monthly/Off/Once).
DATE SETTING
Use the keypad to change or enter the date for
the alarm then press [OK].
Once: To enter the date filed.
Daily: Don’t editing filed
Weekly: To select “Monday”, “Tuesday”, “Wednesday”,
“Thursday”, Friday”, “Saturday”, “Sunday”.
Monthly: To select 1~31.
Off
RINGER SETTING
To set a “Ringer” press [MENU], then select
“Default” or “Change” using the Navigation Key.
To save it, press .
Default : To set default ringer type.
Change : To set custom ringer type.
PLAN SETTING
Using the keypad, input an alarm message then
press .
To save an alarm setting press [SAVE].
4
C
H
4
TIME SETTING
Use the keypad to set a time for the event and the
to select “AM” or “PM” then press [OK].
SNOOZE SETTING
Use the Navigation Key to select a Snooze setting
(No use, 1 time after 5 min, 1 time after 10 min,
3 times by 5 min).
62
63
TOOLS TOOLS
CALCULATOR
To access the calculator:
1
2
C
H
4
3
Press [MENU] .
Follow the instructions below to calculate
(8*6)/4-2.5
Input 8.
Move the Navigation Key rightward.
Input 6 then press the Navigation Key.
Move it leftward.
Input 4 then press the Navigation Key.
Move it downward.
Input 2 then press the to input (.).
Press 5, .
: X, : -, : /, : +, : ., : Reset, : =.
To reset, press [RESET].
STOPWATCH
Simultaneously times up to six different events. To operate the
stopwatch:
Press [MENU] .
1
To measure a time period.
2
1. To start the stop watch, press or [START].
2. To pause it, press or [STOP].
3. To resume it, press or [RESET] to return
to the previous page.
To time up to six events at once:
3
1. To start, press or [START].
2. To stop a time period and continue
measuring another one, press [CONT].
3. To stop the second and continue measuring
a third one, press [CONT].
4. To measure up to six time periods, repeat the
above steps.
5. To stop the stop watch, press [STOP].
6. To review the results, press [VIEW].
7. To return to the stop watch, press [OK].
8. To reset it, press [RESET].
C
H
4
64
65
TOOLS
SETTINGS
WORLD CLOCK
To display the time and date in pre-programmed cities:
Press [MENU] .
1
Select a city.
2
The world map appears with the city, its date
3
and time.
Use the Navigation Key to select another city.
As the daylight saving time is not applied, it may be different from
C
H
4
the actual time during DST.
To return to the previous page, press [OK].
4
Customizes your cellular telephone and optimizes performance
through a variety of settings.
SOUNDS
Sets Volume, Ringers, Alerts, Roam Ringer, Tone Length.
VOLUME
Controls the Ringer, Voice Call, Key Beep, Messages, Speaker,
Power On, Power Off. For all volume setting outline to the user they
can change using one of the following (Navigation Key, Side buttons,
“Min”, “Max” Selection).
RINGER
Controls the Ringer volume and alerts you to incoming calls in the
following modes.
Press [MENU] .
1
Select one of the following options by pressing
2
the Navigation Key to the right and press .
Silence All : Mute all of the sounds, press [Min].
Ringer Off : Mute the ringer only.
Vibrate On : Vibrate instead of the ringer and sms alert.
Ringer Mode : Up & Down (Level 1~5)
High & Vib : Play the sounds and vibrate as the ringer
at the same time, press [Max].
VOICE CALL
To adjust earpiece volume:
C
H
4
66
Press [MENU] .
1
Adjust the earpiece volume with the
2
Navigation Key and press .
Level1-5 (Min- , Max- )
67
SETTINGS
SETTINGS
KEY BEEP
To adjust key pad tone:
Press [MENU] .
1
Adjust the key pad tone with the Navigation Key
2
and press .
Off (Min- )
Level 1 - 5 (level 5, Max- )
MESSAGES
To adjust messages volume:
Press [MENU] .
C
H
4
1
Adjust the message volume using the
2
Navigation Key and press .
Ringer Off (Min- )
Vibrate On
1-Beep
Ringer Mode : Up & Down (Level 1~5, Max- )
SPEAKER
To adjust speaker phone volume:
Press [MENU] .
1
POWER ON
To adjust power on volume:
Press [MENU] .
1
Adjust the power on volume using the
2
Navigation Key and press .
Off (Min- )
Level 1 - 5 (level 5, Max- )
POWER OFF
To adjust power off volume:
Press [MENU] .
1
Adjust the power off volume using the
2
Navigation Key and press .
Off (Min- )
Level 1 - 5 (level 5, Max- )
C
H
4
Adjusts the speaker phone volume using the
2
Navigation Key and press .
Level1-5 (Min- , Max- )
68
69
SETTINGS
SETTINGS
RINGERS
To select a ringer type for incoming calls:
VOICE CALL
Press [MENU] .
1
Select “With Caller ID” or “No Caller ID” then
2
press [OK].
Select your desired ringer type.
3
Music Bells : Radetzky March, Peer Gynt Suite No.1,
C
H
4
Ring Tones : Ring Tone 1~5.
Downloads : Downloaded ringer types and familiar music.
Select one of the available ring types.
4
Opera from La Traviata, A theme by Mozart,
Behind story, Funky, My friend rudy,
O Canada, Music1, Music2, Music3.
To confirm, press .
MESSAGES
show tones after you make the menu selections, should show
messages.
Press [MENU] .
1
Select your desired ringer type.
2
Music Bells : Radetzky March, Peer Gynt Suite No.1,
Ring Tones : Tone 1~10.
Downloads : Downloaded ringer types and familiar music.
Select one of the available ring types.
3
Opera from La Traviata, A theme by Mozart,
Behind story, Funky, My friend rudy,
O Canada, Music1, Music2, Music3.
To confirm, press .
70
VOICE MAIL
show tones after you make the menu selections, should show voice mail.
Press [MENU] .
1
Select your desired ringer type.
2
Music Bells : Radetzky March, Peer Gynt Suite No.1,
Ring Tones : Tone 1~10.
Downloads : Downloaded ringer types and familiar music.
Select one of the available ring types.
3
Opera from La Traviata, A theme by Mozart,
Behind story, Funky, My friend rudy,
O Canada, Music1, Music2, Music3.
To confirm, press .
ALERTS
When set, this setting alerts you to the following handset changes:
SERVICE
Sounds an alert when leaving a service area then entering a roaming
service area.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
MINUTE
Sounds an alert every minute during a call.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
CONNECT
Notifies you that a call has been successfully placed.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
71
C
H
4
SETTINGS
SETTINGS
FADE
Sounds an alert when the signal begins to fade.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
LOW SIGNAL
Sounds an alert when you encounter low signal strength during a call.
Press [MENU] .
1
C
H
4
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
ROAM RINGER
Sounds a different ringer when you are in a roaming service area.
Press [MENU] .
1
Select “Normal” or “Distinctive” with the
2
Navigation Key then press [OK] to save it.
Normal : Sounds the same ringer type as used in Home area.
l
Distinctive : Sounds a different ringer type.
l
DISPLAY
Allows you to customize display.
MENU STYLE
To select a display menu style:
Press [MENU] .
1
Select “Fold”, “Grid” or “List” with the
2
Navigation Key then press [OK] to save it.
GRAPHICS
To select an LCD display:
SCREEN SAVER
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
POWER ON
C
H
4
TONE LENGTH
To adjust tone length:
Press [MENU] .
1
Select “Normal” or “Long” with the Navigation
2
Key then press [OK] to save it.
72
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
73
SETTINGS
SETTINGS
POWER OFF
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
INCOMING CALL
Press [MENU] .
C
H
4
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
SUB LCD
To change the sub LCD display clock image setting only:
Press [MENU] .
1
Select “Digital” or “Analog” with the
2
Navigation Key and press [OK].
GREETING
To input a personal greeting:
Press [MENU] .
1
Select “Setting”, “Font”, “Bg” or “Entry Message”
2
with the Navigation Key and press [SAVE].
Setting : On/Off.
l
Font : White, Blue, Dark blue, Magenta, Gray, Black.
l
Bg : Transparent, White, Blue, Yellow, Gray, Black.
l
Entry Message : Enter message (Default-Bell Mobility).
l
BACKLIGHT
Backlights the display and key pad for easy viewing in dark places.
LCD/KEY PAD
Press [MENU] .
1
Select “LCD” or “Key Pad” then select the duration
2
with the Navigation Key and press [OK].
LCD : 8 Secs/15 Secs/30 Secs/Always On.
l
Key Pad : 8 Secs/15 Secs/30 Secs/Always On/Always Off.
l
When the Subscriber terminal is connected to external power
(Hands Free Car Kit), The backlight setting change to”Always On”.
C
H
4
74
75
SETTINGS
SETTINGS
CONTRAST
To adjust the display contrast:
MAIN LCD/SUB LCD
Press [MENU] .
1
Select “Main LCD” or “Sub LCD” then select one
2
of the following options with the Navigation Key
and press [OK].
l
l
C
H
4
Main LCD : Level 1~5.
Sub LCD : Level 1~5.
ROAMING
Your Cellular Telephone allows you to control your ability to roam.
By using the Roaming menu option, you can determine which signals
your cellular telephone accepts.
Press [MENU] .
1
Select one of the following options by pressing
2
the Navigation Key and press [OK].
Home Only: Only within your home area or home
Analog Only: Stays in the analog setting until the
Analog Home Only: Analog only within your home
Digital Only: Stays in the digital setting until the
Automatic: Scan the radio channels based on the
affiliated area.
hand set is powered on after being
powered off.
area or home affiliated area.
hand set is powered on after being
powered off.
Automatic setting.
C
H
4
76
77
SETTINGS
SETTINGS
DATA SVC
Allows you to transfer data when your cellular telephone is connected
to a PC.
CONNECTION
To select a connection mode based on the handset usage:
Press [MENU] .
1
Select one of the following connection modes
2
and press [OK].
Voice Call: To receive a voice call.
Data Only: To receive data when connected to PC.
C
H
4
Fax Only: To function as a fax when connected to PC.
This function is available only when the phone is connected to a
data cable.
GAMES/TOOLS
BACKLIGHT
While playing a game, select how long the display screen and
keypad are backlight after any key press is made.
Press [MENU] .
1
Select one of the following connection modes
2
and press [OK].
8 Secs / 15 Secs / 30 Secs / Always On
VOLUME
While playing a game, controls game volume.
Press [MENU] .
1
Select one of the following connection modes
2
and press .
Off (Min- )
Level 1 - 5 (level 5, Max- )
MSG ALERT
A function that displays the received SMS/Voice mail while playing
a game.
Press [MENU] .
1
C
H
4
78
Select “On” or “Off” by pressing the Navigation Key
2
and press [OK].
79
SETTINGS SETTINGS
LOCATION
Your Cellular telephone is equipped with a Location feature for use in
connection with location-based services that may be available in the
future. The Location feature allows the network to detect your
position. Turning Location off will hide your location from everyone
except 911.
Press [MENU] .
1
Read the message then press [OK].
2
Turning location “on” lets the network Detect your geographic
location using GPS, making some features easier to use.
Turing location “off” disables GPS, but some features may
still detect your whereabouts using Cell tower technology.
C
H
Except for basic telephone and 911 service, your location
information will only be used with your consent.
4
Select “On” or “Off” by pressing the
3
Navigation Key and press [OK].
On: Turning location “on” lets the network detect your
whereabouts using GPS.
Off: Turning location “off” disables GPS –except for 911 –but
cell tower technology may still used to detect your
whereabouts for some features and basic telephone
service.
SECURITY
Prevents unauthorized use of your cellular telephone. The following
settings can be restricted:
LOCK PHONE
Prevents the phone from being used without entering the password first.
Press [MENU] then enter “Password”.
1
The default password is the last 4 digits of your phone number.
Press then select “Lock Now”, “Lock On
2
Power Up” or “Unlock” and press [OK].
Lock Now : Lock the phone now.
l
Lock On Power Up : Do not lock the phone now, but it is
l
Unlock : Do not lock the phone.
l
automatically locked when power
recycled.
CHANGE LOCK
Changes your 4-digit password
Press [MENU] then enter “Password”.
1
C
H
4
80
Press .
2
Enter a new password then press .
3
Enter the new password again and
4
press .
81
SETTINGS SETTINGS
SPECIAL #’S
Stores 3 phone numbers that can be called even in the lock mode.
Press [MENU] then enter “Password”.
1
Press then select a location with the
2
Navigation Key.
Press [SET] and input a phone number,
3
press again to save.
LIMIT USE
C
H
OUTGOING CALLS
4
Blocks all outgoing calls – except emergency calls – but allows an
incoming call to be placed.
Press [MENU] then enter “Password”.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key and press [OK].
Allow : Allows a dialed call.
l
Restrict : Restricts a dialed call.
l
Refer to page 81 for password information.
CALL HISTORY
Blocks access to call history.
Press [MENU] then enter “Password”.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key and press [OK].
Allow: Allow access to call history.
l
Restrict: Restrict access to call history.
l
PICTURES
Restricts access to camera mode.
Press [MENU] then enter “Password”.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key and press [OK].
Allow : Allows access to the pictures.
l
Restrict : Restricts access to the pictures.
l
DATA CALLS
Restrict a data call from being placed.
Press [MENU] then enter “Password”.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key and press [OK].
Allow : Allows data calls.
l
Restrict : Restricts data calls.
l
C
H
4
82
83
SETTINGS
SETTINGS
900#S
Restricts calling 900 dial service numbers.
Press [MENU] then enter “Password”.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key.
Allow : Allows calls to a 900-dial service.
l
Restrict : Restricts calls to a 900-dial service.
l
To save, press [OK].
3
LONG DISTANCE
C
Restricts calling long distance numbers – the phone is limited to
H
calling numbers within the area.
4
Press [MENU] then enter “Password”.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key and press [OK].
Allow : Allow a long distance call.
l
Restrict : Restrict a long distance call.
l
ERASE PBOOK
To erase all the names and phone numbers in your internal
Phone Book:
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (Erase Phone Book?) then
3
press [YES] or [NO].
ERASE DOWNLOADS
To erase all the downloaded item:
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (Erase Downloads?) and
3
press [YES] or [NO].
C
H
4
84
85
SETTINGS
SETTINGS
RESET PICTURE ACCOUNT
To erase all photo album entries.
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (Clear Token?) and
3
press [YES] or [NO].
RESET PHONE
Resetting the phone restores all the factory defaults, including the
C
ringer types and display settings. The internal Phone Book, Call
H
History, Scheduler, and Messaging are not affected.
4
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (It’ll be erase all data on your
3
phone. Reset Phone?) then press [YES] or
[NO].
When you select “Yes” you will see “Reset Phone! Your cellular
telephone will reboot now” on the display and your cellular
telephone will reset all settings to the factory defaults.
AIRPLANE MODE
When your cellular telephone is in Airplane Mode, it cannot send or
receive any calls or access online information. In this mode you may
still use the phone’s other features such as Games and Voice Memos.
To set your cellular telephone to Airplane Mode:
Press [MENU] .
1
Read the message then press [OK].
2
Turn on airplane mode will prevent any outgoing and
Incoming calls as well as any online access.
You can make emergency calls regardless of airplane mode
setting.
Select “On” or “Off” by pressing the Navigation
3
Key.
To save your Airplane Mode setting,
4
press [OK].
While in Airplane Mode, your phone’s standby screen will display
“Phone off” and the Time/Date display disappears.
C
H
4
86
87
SETTINGS
SETTINGS
OTHERS
CALL ANSWER
To select an answer mode:
Press [MENU] .
1
Select “Any Key” or “Talk Key” with the
2
Navigation Key and press [OK].
Any Key : Press any key to answer an incoming call except
l
Talk Key : Press only to answer a call.
l
C
H
ACTIVE FLIP
4
Selects an Active Flip Answer mode as follows.
Press [MENU] .
1
Select “On” or “Off” with the Navigation Key
2
, , , and .
and press [OK].
When Active Flip On is selected, an incoming phone call can
l
be answered simply by opening the phone.
When Active Flip Off is selected, you will need to open the
l
phone and follow the call answer institution with Answer mode
you have selected.
AUTO ANSWER
To answer calls when your cellular telephone is connected to an
optional hands-free car kit or headset:
Press [MENU] .
1
Select “Hands Free Kit” or “Headset” with the
2
Navigation Key.
Select one of the following options and
3
press [OK].
Off / 5 Secs / 10 Secs / 18 Secs
This function will not be active when you select Vibrate, Silent,
Etiquette or Ringer after Vib as a ringer mode.
AUTO REDIAL
Automatically redial a call up to 5 times after a set time interval.
Press [MENU] .
1
Select a redial time option (Off, 3 Secs, 5 Secs,
2
7 Secs, 10 Secs). The Repeat Category will
appear when a time frame is chosen.
C
H
4
88
Under Repeat, select a time interval option
3
(1 Time, 3 Times, 5 Times).
It disappears when Redial Time is “Off”
To save, press [OK].
4
89
SETTINGS
SETTINGS
LANGUAGE
Selects the language in which letters are displayed on screen.
Press [MENU] .
1
Select either “English” or “Français” with the
2
Navigation Key and press [OK].
TTY MODE
A TTY (also known as a TDD or Text Telephone), is a
telecommunications device that allows people who are deaf or hard
of hearing, or who have speech or language disabilities, to
communicate via a telephone.
C
Your cellular telephone is compatible with select TTY devices. Please
H
check with the manufacturer of your TTY device to ensure that it
4
supports digital wireless transmission. Your cellular telephone and
TTY device will connect via a special cable that plugs into your
phone's headset jack. If this cable was not provided with your TTY
device, contact your TTY device manufacturer to purchase the
connector cable.
Press [MENU] .
1
Read the message, then press .
2
Enabling TTY may impair headset use and non-TTY accessory
performance.
Select either “Enable TTY” or “Disable TTY”
3
with the Navigation Key and press [OK].
VOICE SETTING
To answer calls when your cellular telephone is connected to an
optional hands-free car kit or headset:
Press [MENU] .
1
Select “Set Active” or “HFK Mode” with the
2
Navigation Key.
Select one of the following options and
3
press [OK].
Set Active : Talk Key / Active Flip / Off
HFK Mode : On, Off
KEY GUARD
Press [MENU] .
1
2
Select “Off” or “On” with the Navigation Key.
To save, press [OK]. (“Key Guard Mode is
3
now on” displays.)
Press 1,2,3 to unlock your keypad.
4
C
H
4
90
91
SETTINGS
PHONE INFO
VERSION
Displays the (Phone Number / Software Ver / PRL / Hardware Ver /
Decimal ESN / Hex ESN / MSID / Browser Ver / Browser Name /
MCL Ver) version.
Press [MENU] .
1
You are to see the version of software,
2
hardware and others.
To return to the previous page, press [OK].
3
C
H
ICONS
4
Displays the Indicator Icons of your cellular telephone.
Press [MENU] .
1
You are to see the Indicator Icons of your
2
cellular telephone.
To return to the previous page, press [OK].
3
Chapter 5
VOICE SERVICE
This chapter addresses Voice Service, an advanced feature that
allows you to place calls using your voice. With Voice Memo (VM) you
can record voice messages and set the Answering Machine. Topics
include:
VOICE RECOGNITION MODE
VOICE TOOLS MENU
C
H
5
92
93
93
VOICE RECOGNITION MODE
VOICE TOOLS MENU
Voice Recognition (VR) enables you to place calls using your voice
and to record voice memos.
Press and hold until your cellular telephone
1
turns to Voice Recognition mode.
If no recorded voice dial, “No entries recorded” message
will be displayed. (Refer to page 96 for how to set one up.)
“Please say the name after the
2
prompt tone” will be displayed
and you will hear “Name please”.
NAME
C
H
5
Press and hold until your cellular telephone
1
turns to Voice Recognition mode.
If you say a name or tag that is already in the
2
phone book, the number and name will be
displayed and you will hear “Calling (name).”
VOICE MEMO
Voice Memo allows you to record a reminder message that can be up
to 60 seconds. To record a memo:
To start Tools menu, press [MENU] .
1
To enter a voice memo, press .
2
1.1.To record a voice memo, press .
3
Instructions will be displayed and you will
hear “Please record at the tone.”
1.2.To stop recording a memo, press [STOP]
or [PAUSE/RESUME].
1.3. Press [OPTIONS] after recording a voice
memo to “Re-record”, “Review” or “Save.”
1.4. Select “Save” to input a “Voice Memo” caption,
then press . If not given a name, identify
the voice memo with default to untitled.
(See page 31 for more information on
entering letters, numbers and symbols.)
2.To play voice memo, press .
Select the message you want to play.
Press [OPTIONS] for “Play” or “Edit Caption.”
Press [ERASE] to erase the memo.
C
H
5
94
3.To play using the speaker mode, press .
Select the message you want to play.
Press [OPTIONS] for “Play” or “Edit Caption.”
Press [ERASE] to erase the memo.
4.To erase all voice memos, press .
“Erase all voice memos?” will be displayed.
Press [YES] or [NO].
95
VOICE TOOLS MENU
VOICE TOOLS MENU
VOICE DIAL TRAIN WORDS
Voice Dial allows you to call a person by simply saying their name.
To access Voice Dial:
Train allows you to use Control words to make a call without using the
keypad.
Press [MENU] to start Voice Tools menu.
1
To enter a voice dial, press .
2
1.1. To record a voice dial, press .
3
C
H
5
The phone book list will be displayed
alphabetically. Select a name then press .
Instructions will be displayed and you will
hear “Name Please”.
1.2. Say the name for the voice tag and repeat the
name when prompted. You will hear “Added”.
2. To play a voice dial, press .
Highlight the message you want to play then
press [PLAY] or press [ERASE].
3. To play speaker mode, press .
Highlight the message you want to play then
press [PLAY] or press [ERASE].
4. To erase all voice dials, press .
“Removing all voice tags Proceed?” will be
displayed.
Press [YES] or [NO].
YES
Use to train or untrain the Voice Recognition with the control word,
“Yes”.
Press [MENU] .
1
“Please hold phone to ear and follow
2
instructions” will be displayed and you will hear
“Now training control words. Please say the
word yes”.
Say “Yes”. You will hear “Again”. Say “Yes”
3
again. You will hear “Training was Succelssful”.
NO
Use to train or untrain the Voice Recognition with the control word,
“No”.
Press [MENU] .
1
“Please hold phone to ear and follow
2
instructions” will be displayed and you will hear
“Now training control words. Please say the
word no”.
Say “No”. You will hear “Again”. Say “No” again.
3
You will hear “Training was Succelssful”.
C
H
5
96
97
VOICE TOOLS MENU
WAKE-UP
Use to train or untrain the Voice Recognition with the control word,
“Wake-Up”.
Press [MENU] .
1
“Please hold phone to ear and follow
2
instructions” will be displayed and you will hear
“Now training control words. Please say the word
Wake-Up”.
Say “Wake-Up”. You will hear “Again”.
3
Say “Wake-Up” again. You will hear “Training
was Succelssful”.
UNDO TRAIN ALL
Undo Train All erases all “trained” words.
C
H
5
Press [MENU] .
1
“Undo voice recognition for all procedures?”
2
will be displayed. Press [YES] or [NO].
Chapter 6
VOICE MAIL, TEXT
MESSAGE AND
PICUTURE MESSAGE
This chapter addresses Voice Mail and Text Messaging or Picture
message functions including:
WHEN A NEW MESSAGE ARRIVES
VOICE MAIL
SEND TEXT MSG
SEND PICTURE MSG
INBOX
OUTBOX
SAVED
WEB ALERTS
QUICK TEXT
ERASE ALL
SETTINGS
C
H
6
98
99
99
WHEN A NEW MESSAGE ARRIVES SEND TEXT MSG
The following display appears
1
when a new message arrives.
To display the message, press [READ].
2
VOICE MAIL
Displays the number of voice mails and accesses them by pressing .
To access your voice mail,
1
press [MENU] or .
C
H
6
To send a new text message:
Press [MENU] or .
1
Under “Send To”, input the phone number and
2
press .
By pressing [OPTIONS], the user can choose from the
following:
Find : Allows the user to search the phone number which is
stored in the phone book.
Save : Stores the phone number the message was sent to.
Under “Message”, input a new text message
3
then press .
(Please refer to page 31 for more details on entering letters,
numbers and symbols.)
By pressing [OPTIONS], the user can choose from the
following:
Insert Quick Text: Inserts canned text into a Text Msg.
Save to Quick Text: Saves the written sentences into
The default call back number is automatically
4
Quick Text.
included into the Default CB# field. You can scroll
to the number and edit it or simply press .
This will default to you mobile number provide
by the carrier
C
H
6
100
Press the Navigation Key down for more fields.
5
Under “Priority”, select “Normal” or “Urgent”.
6.1. To send the text message, press [SEND].
6
6.2. To save the text message press [OPTIONS],
select “Save to Outbox,” then press [OK].
101
SEND PICTURE MSG INBOX
To send a new picture message:
Press [MENU] or .
1
2.1. Press for “From My Pictures”. Looking for
2
a saved photo, scroll through the captured
pictures to select the picture you want to
send, then press [SEL].
2.2. Press for “Take New Picture”. Phone goes
into camera mode automatically.
Take a picture and press .
Under “Send To”, input the phone number and
3
press .
By pressing [OPTIONS], the user can choose from the
following:
Find : Allows the user to search the phone number which is
Save : Stores the phone number the message was sent to.
Press [OPTIONS] and select “Record” then
4
press .
4.1. Under “Voice Memo:” To record a memo,
press [RECORD] or [SKIP].
C
H
6
4.2. To stop recording a memo, press [STOP]
or [PAUSE/RESUME].
4.3. Press [OPTIONS] after recording a voice
memo to “Play” or “Erase.”
Under “Message”, input a new text message then
5
press .
(Please refer to page 31 for more details on entering letters,
numbers and symbols.)
By pressing [OPTIONS], the user can choose from the
following:
Insert Quick Text: Inserts canned text into a Text Msg.
Save to Quick Text: Saves the written sentences into Quick Text.
To send the picture message, press [SEND].
6
stored in the phone book.
102
The Inbox manages received text messages. To access:
Press [MENU] or .
1
: Urgent New Msg (not read)
: Urgent Read Msg
: New Msg (not read)
: Old Msg (already read)
: Lock (already read and locked)
Select a message then press .
2
The message is displayed.
Press [OPTIONS]. To reply to the text message,
3
press [REPLY].
REPLY
To reply to the text message.
1
Type your reply and press .
2
REPLY WITH COPY
To reply to a received message and include the
1
received message into the message.
The default call back number is automatically
2
inputted into the Default CB# field.
You can scroll to the number and edit it.
To send the text message, press [SEND].
3
To save the text message, press [OPTIONS] and
4
select the “Save to Outbox” then press .
103
C
H
6
INBOX OUTBOX
FORWARD
To forward the text message, select “Forward”.
1
Input the phone number of the person you are
2
sending the message, then press .
Input any text message to go along with the
3
forwarded message, then press .
To send the text message, press [SEND].
4
ERASE
To erase this message, select “Erase”.
1
“Erase This Message?” will be displayed.
2
Press [YES] or [NO].
SAVE TO CONTACT
To save number to contact, select “Save to
1
Contact”.
SAVE TO SAVED
C
H
6
To save the text message in your cellular
1
telephone, select “Save to Saved”.
SAVE TO QUICK TEXT
To save received text msg to “Quick text”,
1
select “Save to Quick text”.
LOCK & UNLOCK
To lock or unlock the text message, select
1
“Lock & Unlock”.
Select “Lock” to lock the message or “Unlock”
2
to unlock the message, then press [OK].
104
Manages sent text messages or messages waiting to be sent.
CHECKING SENT TEXT MESSAGES
Press [MENU] or .
1
: Auto resend
: Fail
: Not send
: Sent
: Canceled
2.1. Select a message, then press .
2
The text message is displayed.
2.2. To erase message, press [ERASE].
Press [OPTIONS]. To resend to the text
3
message, press [SEND TO].
RESEND
To resend a text message, select “Resend”.
1
SEND TO
To forward the text message, select “Send to”.
1
Input the phone number of the person you are
2
sending the message, then press .
Input any text message to go along with the
3
forwarded message, then press .
To send the text message, press [SEND].
4
105
C
H
6
OUTBOX
SAVED
ERASE
To erase this message, select “Erase”.
1
“Erase This Message?” will be displayed.
2
Press [YES] or [NO].
SAVE TO CONTACT
To save number to contact, select “Save to
1
Contact”.
SAVE TO SAVED
To save the text message in your cellular
1
telephone, select “Save to Saved”.
LOCK & UNLOCK
To lock or unlock the text message, select
1
“Lock & Unlock”.
Select “Lock” to lock the message or “Unlock”
2
C
H
6
to unlock the message, then press [OK].
STATE
SAVED
Manages saved messages from the Inbox/Outbox.
Press [MENU] or .
1
2.1. Select a text message then press [OK].
2
3
4
5
The text message is displayed.
2.2. To erase message, press [ERASE].
Press [OPTIONS].
If the text message is saved from the “Inbox”
menu, this screen will be displayed.
To select inbox menu : Reply, Reply with Copy, Forward,
Erase, Save to Contact,
Save to Quick Text, Lock & Unlock
If the text message is saved from the “Outbox”
menu, this screen will be displayed.
To select outbox menu : Resend, Send to, Erase, Save to
Contact, Lock & Unlock, State
Select one by pressing .
C
H
6
To display the status of an outbox message,
1
select “State”.
To return to the previous page, press [OK].
2
106
107
WEB ALERTS
QUICK TEXT
WEB ALERTS
Press [MENU] or .
1
To select GoTo, then press and press to
2
connecting selected site.
To select erase message, press to erase
selected message.
The Web Alert message will be displayed.
3
• [ ] : Read Message.
• [ ] : Unread Message.
• GoTo : Connecting Selected Site.
• Erase : Erase Selected Message.
C
H
6
QUICK TEXT
To edit the Quick Text message you have saved:
Press [MENU] or .
1
2.1. Select a message from the list.
2
3
Press [OPTIONS].
2.2. To add a new Quick Text message,
select “Add New”. To edit the Quick Text
message you have selected, select “Edit”.
To erase the saved Quick Text message,
press [ERASE].
Yes / No / Call me / Need directions / Where are you? /
Will call later / Busy / On my way / Will arrive 15 minutes /
Thank you / Love you
C
H
6
108
109
SETTINGSERASE ALL
ERASE ALL
Manages messaging features through various features.
SAVE SENT MSG
Press [MENU] or .
1
Press [MENU] or .
1
1. To erase all the voice mail, press .
2
Select one from “Off”, “On” or “Prompt” with
2. To erase all the Inbox messages, press .
Read Msg Only : To erase all messages already read.
(However, the locked Message(s) will not be deleted).
Entire Msg : To erase all messages.
3. To erase all the Outbox messages, press .
4. To erase the saved messages, press .
5. To erase all the web alerts, press .
6. To erase the quick text, press .
Press [YES] or [NO].
3
C
H
6
2
the Navigation Key and press [OK].
DEFAULT CALLBACK
Edits a default callback number so that the recipient can call back or
reply.
Press [MENU] or .
1
Input a callback number, then press [OK].
2
You can look it up from the phone book by
pressing [FIND].
REMINDER
Press [MENU] or .
1
C
H
6
110
2
Select “On” or “Off” with the Navigation Key
and press [OK].
111
SETTINGSSETTINGS
AUTO ERASE
Automatically erases inbox/outbox messages when new messages
arrive.
INBOX
Press [MENU] or .
1
Press .
2
Select “Disable” or “Read Msg” with Navigation
Key and press [OK].
OUTBOX
1
Press [MENU] or .
Press .
2
Select “Disable” or “Old Msg” with Navigation Key
and press [OK].
ENTRY MODE
Sets an Entry Mode as a default. For example, if T9 Mode is the
default, its icon will appear.
C
H
1
6
Press [MENU] or .
Select “Alpha Mode” or “T9 Mode” with
2
the Navigation Key and press [OK].
MESSAGE LOG
INCOMING LOG
Press [MENU] or .
1
Press .
2
Displays information on the incoming messages
including “Stored Msg/Read Msg.”
To return to the previous page, press [OK].
3
OUTGOING LOG
Press [MENU] or .
1
2
Press .
Displays information on the outgoing messages
such as "Sent Msg."
To return to the previous page, press [OK].
3
RESET LOG
Press [MENU] or .
1
2
Press .
Select “Incoming Log” or “Outgoing Log” with
Navigation Key.
C
H
6
112
3
“Reset Incoming/Outgoing Log?” will be displayed.
Press [YES] or [NO].
113
SETTINGS
RETRY TIME
Press [MENU] or .
1
Select on of the following with the Navigation Key
2
and press [OK].
3 mins / 5 mins / 10 mins / 30 mins.
l
Chapter 7
EDIT VOICE CB#
MOBILE BROWSER
Press [MENU] or .
1
Input a new voice call back number or edit
2
voice call back number.
You can look it up from the phone book by
pressing [FIND].
Press [OK].
3
C
H
6
PUSH SETTINGS
Press [MENU] or .
1
Select one from “Yes” or “No” with the
2
Navigation Key and press [OK].
This chapter addresses Internet services and Mobile Browser.
For more detailed information contact your service provider.
START MOBILE BROWSING
MOBILE BROWSER MENU
C
H
7
114
115
START MOBILE BROWSING MOBILE BROWSER MENU
ACCESS THE INTERNET
To start your mobile browsing and access
1
websites through your wireless handset
press [MENU] or .
MOBILE BROWSER MENU
The Mobile Browser Menu lists the actions necessary to operate the
mobile browsing.
press [MENU] or press to access the Mobile Browser
Menu.
BACK
To return to the previous page, press [MENU]
1
HOME
.
BOOKMARKS
To view your “Bookmark List”, press [MENU]
1
.
This provides easy website access without
entering a URL.
SEARCH
To launches a “Google” search, press [MENU]
1
.
GO TO URL
To allows the user to enter and access a URL,
1
press [MENU] .
SHOW URL
To displays the current URL, press [MENU]
1
.
To display the homepage, press [MENU]
C
H
7
1
.
RELOAD
To Allows the user to refresh the current URL,
1
press [MENU] .
C
H
7
FORWARD
To forward to the next page, press [MENU]
1
.
116
117
MOBILE BROWSER MENU MOBILE BROWSER MENU
SETTINGS
To accesses the mobile browsing settings menu,
1
press [MENU] .
HOMEPAGE
Show the homepage URL.
To select “Homepage”, press .
1
DOWNLOADS
Allows the user to turn on/off object display (images and sounds).
To select “Downloads”, press .
1
RESTART BROWSER
Restarts the mobile browsing dumping the cache and returning to
the home page.
To select “Restart Browser”, press .
1
VIEW TITLE REGION
To allows users to set the mode and display for long title URL.
SEND REFFERER
To allows the user allow the mobile browsing send the URL of the
current site when navigating to a new site (only in HTTP stack).
To select “Send Refferer”, press .
1
KEY PRESS TIMEOUT
To duration between how long the mobile browsing will wait for
acknowledgement after key press.
To select “Key Press Timeout”, press .
1
SECURITY
To accesses the security menu and settings as follows.
To select “Security”, press .
1
Secure Prompt : Displays prompt before you exit from a
Authentication : Gives the option to turn authentication
Current Certificate : Shows the current site security key for
secure site.
caching “ON” or “OFF”.
TLS/SSL (if applicable)
To select “View Title Region”, press .
1
C
SCROLL MODE
H
To allows users to set the mode and scrolling speed for long texts.
7
To select “Scroll Mode”, press .
1
118
119
C
H
7
MOBILE BROWSER MENU
HISTORY
To display URLs that you visited recently.
1
press [MENU] or , then press .
ABOUT...
Displays the name of the supplier of the Mobile browsing, the Mobile
browsing software version and root certificate list.
Chapter 8
To select “About...”.
1
SAFETY AND
WARRANTY
This chapter addresses the safety guidelines and precautions to
follow when operating your cellular telephone. Before operating your
cellular telephone, please be aware of all the safety details.
This chapter contains the terms and conditions of services and the
warranty for your cellular telephone. Please review them thoroughly.
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR FCC RF EXPOSURE
SAR INFORMATION
FDA CONSUMER UPDATE
C
H
7
PROTECT YOUR WARRANTY
12 MONTH LIMITED WARRANTY
C
H
8
120
121
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
Read This Information Before Using Your Handheld
Portable Cellular Telephone
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld wireless
phones. Those guidelines are consistent with the safety standards
previously set by both U.S. and international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations
of the relevant scientific literature. For example, over 120 scientists,
engineers, and physicians from universities, government health agencies,
and industry reviewed the available body of research to develop the ANSI
Standard (C951).
The design of your cellular telephone complies with the FCC guidelines
(and those standards).
ANTENNA CARE
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the phone and
may violate FCC regulations.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in
some areas. Remember, safety comes first. Check the laws and regulations
on the use of phones in the areas where you drive. Always obey them.
Also, if using your cellular telephone while driving, please:
l Give full attention to driving. Driving safely is your first responsibility.
l Use hands-free operation, if available.
l Pull off the road and park before making or answering a call, if driving
conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing,
and auto answer modes.
An airbag inflates with great force. DO NOT place objects, including both
installed or portable wireless equipment, in the area over the airbag or in the
air bag deployment area. If in-vehicle wireless equipment is improperly
installed and the air bag inflates, serious injury could result.
WARNING: Failure to follow these instructions may lead to serious
personal injury and possible property damage.
C
H
8
1* : American National Standards Institute.
2* : National Council on Radiation protection and measurements.
3* : International Commission on Nonionizing Radiation Protection.
122
123
C
H
8
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF energy. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
PACEMAKERS
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers :
l ALWAYS keep the phone more than six inches from your
pacemaker when the phone is turned on.
l Do not carry the phone in a breast pocket.
l Use the ear opposite the pacemaker to minimize the potential for
interference.
l If you have any reason to suspect that interference is taking place,
turn your cellular telephone OFF immediately.
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.
Turn your cellular telephone OFF in healthcare facilities when any
regulations posted in these areas instruct you to do so. Hospitals or
healthcare facilities may be using equipment that could be sensitive to
external RF energy.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC and Transport Canada Regulations prohibit using your cellular
telephone while in the air. Turn your cellular telephone OFF before boarding
an aircraft.
BLASTING AREAS
To avoid interfering with blasting operations, turn your cellular telephone
OFF when in a “blasting area” or in areas posted: “Turn off two-way
radio.” Obey all signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your cellular telephone OFF when in any area with a potentially
explosive atmosphere and obey all signs and instructions. Sparks in
such areas could cause an explosion or fire resulting in bodily injury
or even death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gas
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust, or metal powders; and any other area where you would
normally be advised to turn off your vehicle's engine.
POSTED FACILITIES
C
H
Turn your cellular telephone OFF where posted notices so require.
8
124
125
C
H
8
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR
FCC RF EXPOSURE
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of
equipment. Before operating, read all instructions and cautionary
markings on (1) AC Adaptor (2) Battery and (3) Product Using Battery.
DO NOT use this equipment in an extreme environment where
high temperature or high humidity exists.
DO NOT abuse the equipment. Avoid striking, shaking or
shocking. When not using, lay down the unit to avoid possible
damage due to instability.
DO NOT expose this equipment to rain or spilled beverages.
DO NOT use unauthorized accessories.
DO NOT disassemble the phone or its accessories. If service
or repair is required, return unit to an authorized Audiovox
cellular service center. If unit is disassembled, the risk of
electric shock or fire may result.
DO NOT short-circuit the battery terminals with metal items etc.
C
H
8
WARNING! Read this Information before using
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of
the United States with its action in Report and Order FCC 96-326
adopted an updated safety standard for human exposure to radio
frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The
design of this phone complies with the FCC guidelines and these
international standards.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement antenna.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the
back of the phone kept 2.0 cm. from the body. To maintain
compliance with FCC RF exposure requirements, use only belt-clips,
holsters or similar accessories that maintain a 2.0 cm. separation
distance between the user’s body and the back of the phone,
including the antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
VEHICLE MOUNTED EXTERNAL ANTENNA
(OPTIONAL, IF AVAILABLE)
A minimum separation distance of 7.9 inches (20cm) must be
maintained between the user/bystander and the vehicle mounted
external antenna to satisfy FCC RF exposure requirements.
For more information about RF exposure, please visit the FCC
website at www.fcc.gov
C
H
8
126
127
SAR INFORMATION SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the
phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure.
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the ear is 1.15
W/Kg and when worn on the body, as described in this user guide, is
0.393W/Kg. (Body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement for
safe exposure.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
C
http://www.fcc.gov/ oet/fccid after searching on PP4TX-110C.
H
8
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications Industry Association (CTIA) website
at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a sub-stantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
C
H
8
128
129
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
U.S. Food and Drug Administration -Center for Devices and
Radiological Health Consumer Update on Wireless Phones
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low levels of radiofrequency
energy (RF) in the microwave range while being used. They also emit very low
levels of RF when in the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF that does not produce
heating effects causes no known adverse health effects. Many studies of low level
RF exposures have not found any biological effects. Some studies have suggested
that some biological effects may occur, but such findings have not been confirmed
by additional research. In some cases, other researchers have had difficulty in
reproducing those studies, or in determining the reasons for inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer
products such as wireless phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard and to repair, replace or recall
the phones so that the hazard no longer exists. Although the existing scientific data
do not justify FDA regulatory actions, FDA has urged the wireless phone industry
to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the user
that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have
responsibility for different aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group
activities, as well. FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety questions about wireless
phones. FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these base stations are
typically thousands of times lower than those they can get from wireless phones.
C
Base stations are thus not the subject of the safety questions discussed in this
H
document.
8
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose the user to measurable radiofrequency
energy (RF) because of the short distance between the phone and the user’s head.
These RF exposures are limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF exposure decreases
rapidly with increasing distance from the source. The so-called “cordless phones,”
which have a base unit connected to the telephone wiring in a house, typically
operate at far lower power levels, and thus produce RF exposures far below the
FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies
have suffered from flaws in their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF) exposures characteristic of
wireless phones have yielded conflicting results that often cannot be repeated in
other laboratories. A few animal studies, however, have suggested that low levels
of RF could accelerate the development of cancer in laboratory animals. However,
many of the studies that showed increased tumor development used animals that
had been genetically engineered or treated with cancer-causing chemicals so as to
be pre-disposed to develop cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day. These conditions are not
similar to the conditions under which people use wireless phones, so we don’t
know with certainty what the results of such studies mean for human health. Three
large epidemiology studies have been published since December 2000. Between
them, the studies investigated any possible association between the use of
wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects from wireless
phone RF exposures. However, none of the studies can answer questions about
long-term exposures, since the average period of phone use in these studies was
around three years.
5. What research is needed to decide whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people actually
using wireless phones would provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few years. However, very large
numbers of animals would be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or more years’ follow-up may be
needed to provide answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a cancer- causing agent and
the time tumors develop - if they do -may be many, many years. The interpretation
of epidemiological studies is hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones. Many factors affect this
measurement, such as the angle at which the phone is held, or which model of
phone is used.
6. What is FDA doing to find out more about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address important questions about the effects of exposure to
radiofrequency energy (RF). FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF) Project since its inception
in 1996. An influential result of this work has been the development of a detailed
agenda of research needs that has driven the establishment of new research programs around the world.
131130
C
H
8
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
The Project has also helped develop a series of public information documents on
EMF issues. FDA and the Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development Agreement (CRADA)
to do research on wireless phone safety. FDA provides the scientific oversight,
obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts to independent
investigators. The initial research will include both laboratory studies and studies of
wireless phone users. The CRADA will also include a broad assessment of
additional research needs in the context of the latest research developments
around the world.
7. How can I find out how much radiofrequency energy exposure I can get by
using my wireless phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC
established these guidelines in consultation with FDA and the other federal health
and safety agencies. The FCC limit for RF exposure from wireless telephones is set
at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC
limit is consistent with the safety standards developed by the Institute of Electrical
and Electronic Engineering (IEEE) and the National Council on Radiation Protection
and Measurement. The exposure limit takes into consideration the body’s ability to
remove heat from the tissues that absorb energy from the wireless phone and is
set well below levels known to have effects. Manufacturers of wireless phones
must report the RF exposure level for each model of phone to the FCC. The FCC
website (http://www.fcc.gov/oet/rfsafety) gives directions for locating the FCC
identification number on your cellular telephone so you can find your phone’s RF
exposure level in the online listing.
8. What has FDA done to measure the radiofrequency energy coming from
wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless
phones and other wireless handsets with the participation and leader-ship of FDA
scientists and engineers. The standard, “Recommended Practice for Determining
the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to
Wireless Communications Devices: Experimental Techniques,” sets forth the first
consistent test methodology for measuring the rate at which RF is deposited in the
heads of wireless phone users. The test method uses a tissue-simulating model of
the human head. Standardized SAR test methodology is expected to greatly
improve the consistency of measurements made at different laboratories on the
same phone. SAR is the measurement of the amount of energy absorbed in tissue,
either by the whole body or a small part of the body. It is measured in watts/kg (or
milliwatts/g) of matter. This measurement is used to determine whether a wireless
phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy
from my wireless phone?
If there is a risk from these products—and at this point we do not know that there
is—it is probably very small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key factor in how much exposure a
person receives, reducing the amount of time spent using a wireless phone will
C
reduce RF exposure.
H
• If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since
8
the exposure level drops off dramatically with distance. For example, you could
use a headset and carry the wireless phone away from your body or use a
wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless phones are harmful. But
if you are concerned about the RF exposure from these products, you can use
measures like those described above to reduce your RF exposure from wireless
phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower exposure to
radiofrequency energy (RF), the measures described above would apply to children
and teenagers using wireless phones. Reducing the time of wireless phone use
and increasing the distance between the user and the RF source will reduce RF
exposure. Some groups sponsored by other national governments have advised
that children be discouraged from using wireless phones at all. For example, the
government in the United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health hazard exists.
11.What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can interact with some
electronic devices. For this reason, FDA helped develop a detailed test method to
measure electromagnetic interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by the
Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids and wireless phones so
that that no interference occurs when a person uses a “compatible” phone and a
“compatible” hearing aid at the same time. This standard was approved by the
IEEE in 2000. FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interference be found to
occur, FDA will conduct testing to assess the interference and work to resolve the
problem.
12.Where can I find additional information?
For additional information, please refer to the following resources:
• FDA web page on wireless phones (http://www.fda.gov/cdrh/ phones/index.html)
• Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
• International Commission on Non-Ionizing Radiation Protection
(http://www.icnirp.de)
• World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
• National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)
C
H
8
133132
PROTECT YOUR WARRANTY 12 MONTH LIMITED WARRANTY
Read your Warranty carefully, with the special consideration to
paragraph seven of the Limited Warranty for your unit.
“Warranty does not apply to... or to any product or part
thereof which has suffered through alteration... mishandling
misuse, neglect or accident”.
Many companies are making look alike accessories and in some
cases, promoting that their product is equal to or better than the
Audiovox product. Be careful. Some of these products may not be
compatible to use with your Audiovox product and may damage the
unit or cause it to malfunction. If service is required on your unit and it
is determined that a non-Audiovox accessory has created the
problem with your unit, the Warranty will not apply. In addition, if the
unit has already suffered irreversible damage by reason of a noncompatible accessory, the Warranty will be voided. To protect your
Warranty, use only compatible accessories which cannot damage or
interfere with the functioning of your Audiovox product.
AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd., Hauppauge, New York 11788, 800-229-1235
16808 Marquardt Avenue, Cerritos, California 90703, 562-802-5100
Audiovox Canada
5155 Spectrum Way, Unit #5, Mississauga, Ontario
Canada L4W 5A1, 800-465-9672
C
H
8
Audiovox Communications Corp. (the Company) warrants to the
original retail purchaser of this Audiovox handheld portable cellular
telephone, that should this product or any part thereof during normal
consumer usage and conditions, be proven defective in material or
workmanship that results in product failure within the first twelve (12)
months period from the date of purchase, such defect(s) will be
repaired or replaced (with new or rebuilt parts) at the Company’s
option, without charge for parts or labor directly related to the defect(s).
The antenna, key pad, display, rechargeable battery and battery
charger, if included, are similarly warranted for twelve (12) months from
date of purchase.
This Warranty extends only to consumers who purchase the product in
the United States or Canada and it is not transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial number
has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or
other product not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding, dirt,
sand, weather conditions, battery leakage, blown fuse, theft or
improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the
product, for geographic coverage, for inadequate signal reception by
the antenna or for communications range or operation of the cellular
system as a whole.
To obtain repairs or replacement within the terms of this Warranty, the
product should be delivered with proof of Warranty coverage (e.g.
dated bill of sale), the consumer’s return address, daytime phone
number and/or fax number and complete description of the problem,
transportation prepaid, to the Company at the address shown below or
to the place of purchase for repair or replacement processing.
C
H
8
134
135
12 MONTH LIMITED WARRANTY
In addition, for reference to an authorized Warranty station in your area,
you may telephone in the United States (800) 229-1235, and in Canada
(800) 465-9672 (in Ontario call 905-712-9299).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S
LAIBILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST
BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF
ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR AN SPECIAL CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT
BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS
WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS
BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of
this product.
Some states or provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitation or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you may
also have other rights which vary from state to state or province
to province.
IN USA : AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd.
Hauppauge, NY 11788
(800) 229-1235
IN CANADA : AUDIOVOX CANADA LTD.
C
H
5155 Spectrum Way, Unit #5
Mississauga, Ontario L4W 5A1
(800) 465-9672
8
136
Model : CDM-8910
Loading...
