Utstarcom CDM7025C, CDM7025 User Manual

TABLE OF CONTENTS

CHAPTER 1. BEFORE USING YOUR PHONE

PACKAGE CONTENTS............................................................................................6

HANDSET DESCRIPTION ........................................................................................7

BATTERY USAGE .................................................................................................11

POWER CONNECTION ........................................................................................................13

BATTERY HANDLING INFORMATION ..................................................................14

DO’s....................................................................................................................................14

DON’Ts................................................................................................................................14

CHAPTER 2. BASIC OPERATION

TURNING THE PHONE ON / OFF ..........................................................................16

TURNING THE PHONE ON...................................................................................................16

TURNING THE PHONE OFF..................................................................................................16

ACCESSING THE MENU .......................................................................................17

MENU SUMMARY ...............................................................................................18

BASIC FUNCTIONS...............................................................................................20

MAKING A CALL .................................................................................................................20

ANSWERING CALLS ............................................................................................................20

SPEAKERPHONE..................................................................................................................21

WAIT/PAUSE FEATURE........................................................................................................21

3-WAY CALLING .................................................................................................................22

CALLER ID FUNCTION.........................................................................................................22

CALL WAITING FUNCTION..................................................................................................22

ADJUSTING VOLUME..........................................................................................................23

DURING A CALL ..................................................................................................24

MUTE (UNMUTE) ................................................................................................................24

SPEAKER ON.......................................................................................................................24

VOICE MEMO .....................................................................................................................24

CONTACTS..........................................................................................................................24

RECENT CALLS....................................................................................................................25

MESSAGING .......................................................................................................................25

MAKING AN EMERGENCY CALL .........................................................................26

911 IN LOCK MODE............................................................................................................26

TABLE OF CONTENTS

911 USING ANY AVAILABLE SYSTEM .................................................................................26

CHAPTER 3. MEMORY FUNCTION

STORING A PHONE NUMBER ..............................................................................28

ENTERING LETTERS, NUMBERS & SYMBOLS.......................................................29

STANDARD INPUT MODE ...................................................................................................30

T9 INPUT MODE..................................................................................................................31

NUMERIC MODE.................................................................................................................32

SYMBOL MODE...................................................................................................................32

MAKING A CALL THROUGH THE CONTACT LIST .................................................33

ONE-TOUCH/TWO-TOUCH DIALING....................................................................................33

CONTACTS...........................................................................................................34

CREATE NEW ......................................................................................................................34

FIND....................................................................................................................................35

GROUPS..............................................................................................................................35

SPEED DIALS.......................................................................................................................37

SERVICE NUMBERS.............................................................................................................38

CHAPTER 4. MENU FUNCTION

RECENT CALLS.....................................................................................................40

ALL CALLS...........................................................................................................................40

MISSED CALLS ....................................................................................................................41

INCOMING CALLS...............................................................................................................42

OUTGOING CALLS ..............................................................................................................43

CALL TIMERS ......................................................................................................................44

SETTINGS.............................................................................................................45

SOUND SETTINGS ...............................................................................................................45

DISPLAY SETTINGS .............................................................................................................53

CALL ...................................................................................................................................57

VR SETTINGS.......................................................................................................................61

SECURITY SETTINGS ...........................................................................................................63

PHONE INFO .......................................................................................................................67

PHONE SETTINGS................................................................................................................69

TABLE OF CONTENTS

CHAPTER 5. PERSONAL ORGANIZER

TOOLS..................................................................................................................72

VOICE MEMO .....................................................................................................................72

SCHEDULE...........................................................................................................................73

ALARM CLOCK....................................................................................................................75

WORLD CLOCK ...................................................................................................................76

NOTEPAD............................................................................................................................77

CALCULATOR......................................................................................................................78

STOPWATCH.......................................................................................................................79

CONVERT UNIT ...................................................................................................................80

CHAPTER 6. MESSAGE

MESSAGE ............................................................................................................82

NEW MSG...........................................................................................................................82

INBOX.................................................................................................................................83

OUTBOX..............................................................................................................................84

DRAFTS...............................................................................................................................84

VOICEMAIL .........................................................................................................................85

SETTINGS............................................................................................................................85

CHAPTER 7. CRICKET CLICKS

CRICKET CLICKS ..................................................................................................90

CHAPTER 8. SAFETY INFORMATION

SAFETY ................................................................................................................92

SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES .............................................92

SAFETY INFORMATION FOR FCC RF EXPOSURE .................................................................96

SAR INFORMATION ............................................................................................................97

FDA CONSUMER UPDATE...................................................................................................99

EMERGENCY CALLS..........................................................................................................107

COMPLIANCE WITH OTHER FCC REGULATIONS...............................................................109

GENERAL SAFETY .............................................................................................................110

ANTENNA .........................................................................................................................111

TABLE OF CONTENTS

BATTERY...........................................................................................................................112

ADAPTER/CHARGER .........................................................................................................114

FCC HEARING-AID COMPATIBILITY (HAC) REGULATIONS FOR WIRELESS DEVICES.........115

GAMES .............................................................................................................................117

RECYCLE YOUR CELL PHONE! ..........................................................................................120

WARRANTY .......................................................................................................119

MANUFACTURER’S WARRANTY.......................................................................................119

CHAPTER 1

BEFORE USING YOUR PHONE

CHAPTER 1

BEFORE

USING

YOUR PHONE

This chapter provides important information about your

UTStarcom handset including:

Package Contents

Handset Description

Battery Usage

Battery Handling Information

PACKAGE CONTENTS

This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.

Handset

Standard Battery Manual

AC Charger

HANDSET DESCRIPTION

Your CDM7025C weighs 3.2 ounces. The dimensions are 3.5"x1.9"x.8".

Earpiece

Color STN Display

Navigation and OK Key

Left Option Button

SEND Key

Microphone

Right Option Button

END/POWER Key

Clear Key

Antenna

Earjack

Volume Keys

HANDSET DESCRIPTION (THE FUNCTION KEYS)

NAVIGATION KEY

In Idle Mode :

Within a Menu :

Send Key

Press to make or receive a call or in idle mode, press to access the All Calls list.

End Key

Press to terminate a call or to return to idle mode. Press and hold to turn the phone on/off.

Left Option Button

Press to access Menu or function displayed on bottom line.

Right Option Button

Press to access the Message Menu or function displayed on bottom line.

CLR Key

Press to clear a digit or press and hold to clear all digits from the display. Press to return to the previous page.

Shift Key

Enters the asterisk [*] character for calling features. In text entry mode, press to change the character input type. Press twice to display a plus sign (+) for international dialing. Press and hold to turn on/off Vibrate mode.

Space Key

In text entry mode, press to accept the word and add a space. Press and hold to lock/unlock the phone.

0 Key

In T9 Mode, press to see other word choices.

Side Volume Key

Allows you to adjust the ringer volume in standby mode (with the flip open) or adjust the voice volume during a call. The volume key can also be used to scroll up or down to navigate through the different menu options. Press to ignore an incoming call and mute the ringer.

Press for Contacts, for Schedule, for Voice Command and For Cricket Clicks.

Within a menu, use to scroll through menu or to select a function displayed on the screen.

HANDSET DESCRIPTION

(DISPLAY INDICATORS)

The idle mode display appears when you are not on a call or using the menu. You must be in the idle mode display to dial a phone number.

Display Indicators

Display various icons.

Text & Graphic area

Soft Key Indicators

Shows the functions currently assigned to each Option Button and displays some icons.

Signal Strength

Current signal strength: the more lines, the stronger the signal.

Roaming

Phone is out of home area.

No Service

Indicates the phone cannot receive a signal from the system.

TTY

Indicates your phone is active in TTY mode.

GPS Icon

Indicates the Location Service of your phone is disabled/enabled.

Battery

Battery charging level — the more blocks, the stronger the charge.

Battery Charging

HANDSET DESCRIPTION (DISPLAY INDICATORS)

Alarm

Appears when either a calendar or an alarm is set.

Emergency Call

Blinks when an emergency call is in progress.

Vibrate Only

Phone will vibrate to notify you of an incoming call.

All Off

Indicates the ringer volume is set to off.

Silence

Phone is set to Silent - no sound will be made to notify you of incoming calls or messages.

Voicemail

Indicates you have voicemail messages.

New Messages

Indicates you have new text messages.

New Voice Messages

Indicates you have both text and voicemail messages.

Download

Downloading is in progress.

BATTERY USAGE

(BATTERY INSTALLATION)

1. Place the battery (label side up) on the back of the phone so the

metal contacts match up on the battery and in the battery cavity.

2. Slide the battery down into the battery cavity until it locks into place.

BATTERY USAGE (BATTERY REMOVAL)

Push down the release latch button, then slide the battery cover off the phone.

Lift the battery up and out of the battery cavity from the top of the battery.

•

Note

If the battery is not correctly placed in the compartment, the handset will not turn on and/or the battery may detach during use.

BATTERY USAGE

(BATTERY CHARGING)

POWER CONNECTION

Plug the AC Charger into a standard outlet.

Plug the other end of the AC Charger into the charging port on your phone. The battery must be installed onto the phone to work

properly.

• When you charge the battery with the phone power off, you will see a

Hot Key

charging status screen. You cannot operate the phone until it is powered on.

• The battery is not charged at the time of purchase.

• Fully charge the battery before use.

• It is more efficient to charge the battery with the handset powered off.

• The battery must be connected to the phone in order to charge it.

• Battery operating time gradually decreases over time.

• If the battery fails to perform normally, you may need to replace the battery.

BATTERY HANDLING

INFORMATION

DO’s

Only use the battery and charger approved by the manufacturer.

Only use the battery for its original purpose.

Try to keep batteries in a temperature between 41ºF (5ºC ) and 95ºF

(35ºC).

If the battery is stored in temperatures above or below the recommended

range, give it time to warm up or cool down before using.

Completely drain the battery before recharging. It may take one to four

days to completely drain.

Store the discharged battery in a cool, dark, and dry place.

Purchase a new battery when its operating time gradually decreases after

fully charging.

Properly dispose of the battery according to local laws.

DON’Ts

Don’t attempt to disassemble the battery – it is a sealed unit with no

serviceable parts.

Don’t accidentally short circuit the battery by carrying it in your pocket or

purse with other metallic objects such as coins, clips and pens. This may critically damage the battery.

Don’t leave the battery in hot or cold temps. Otherwise, it could

significantly reduce the capacity and lifetime of the battery.

Don’t dispose of the battery into a fire.

CHAPTER 2

BASIC OPERATION

CHAPTER 2

BASIC OPERATION

This chapter addresses and explains the basic

features of your phone including:

Turning the Phone On/Off

Accessing the Menu

Menu Summary Basic Functions

During a Call

Making an Emergency Call

TURNING THE PHONE ON / OFF

TURNING THE PHONE ON

Press and hold until your “Welcome” logo appears and the tone sounds.

• If “Password” appears on the display enter your 4-digit password to

Note

unlock your phone.

• The default password is the last 4 digit of your phone number.

TURNING THE PHONE OFF

Press and hold until your “Goodbye” logo appears.

• Immediately change or recharge the battery when

Note

“LOW BATTERY!! PHONE IS TURNING OFF!”appears on the display. Memory may possibly be damaged if the phone turns off due to the battery completely draining.

• Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may be lost.

ACCESSING THE MENU

Your phone can be customized via the menu. Each function can be accessed by scrolling with the or by pressing the number that corresponds with the menu item.

To access the menu in the idle mode, press [Menu].

Press / to scroll through the menu items. Press / to scroll through the submenus for each

menu item.

To return to the previous page, press . To exit the current menu and return to the idle mode, press .

Press to enter a function when its main page is displayed or press its assigned number to have direct access to the function.

Contacts

ScheduleCricket Clicks

Voice Command

MENU SUMMARY

1. MESSAGING

1. New Msg

2. Inbox

3. Outbox

4. Drafts

5. Voicemail

6. Settings

6.1. Notification

6.2. Auto Save

6.3. Auto Erase

6.4. Auto View

6.5. Entry Mode

6.6. Callback #

6.7. Voicemail #

6.8. Signature

6.9. Preset Msgs.

2. CONTACTS

1. Find

2. Create New

3. Group

4. Speed Dials

5. Service Numbers

3. RECENT CALLS

1. All Calls

2. Missed Calls

3. Incoming Calls

4. Outgoing Calls

5. Call Timers

4. CRICKET CLICKS

1. Cricket Clicks

5. SETTINGS

1. Sounds

1.1. Ringer Type

1.1.1. Ringer

1.1.2. Message

1.1.3. Voicemail

1.1.4. Alarm

1.1.5. Roam Ringer

1.2. Volume

1.2.1. Ringer

1.2.2. Key Tone

1.2.3. Speakerphone

1.2.4. Headset

1.2.5. Advanced

1.2.5.1. Messaging

1.2.5.2. Voicemail

1.2.5.3. Alarms

1.2.5.4. Power on/off

1.3. Alerts

1.3.1. Minute Beep

1.3.2. Roaming

1.3.3. Connect

1.3.4. Fade

1.4. Tone Length

2. Display

2.1. Wallpaper

2.1.1. Image

2.1.2. Clock Format

2.2. Screensaver

2.2.1. Time setting

2.2.2. Screensaver

2.3. Backlight

2.3.1. LCD

2.3.2. Keypad

MENU SUMMARY

2.4. Greeting

2.5. Contrast

2.6. Menu Style

3. Call

3.1. Abbrev. Dial

3.2. Contacts Match

3.3. Answer Mode

3.4. Auto Retry

3.5. TTY Mode

3.6. Speed Dial

3.7. Voice Privacy

3.8. Data Setting

4. VR Settings

4.1. Choice List

4.2. Train Voice

4.3. Prompts

4.4. Call Alert

5. Security

5.1. Lock Phone

5.2. Change Lock

5.3. Limit Use

5.3.1. Incoming Calls

5.3.2. Outgoing Calls

5.4. Erase Contects

5.5. Default Settings

5.6. Reset Phone

6. Phone Info

6.1. Phone Number

6.2. Help

6.3. Version

6.4. Advanced

6.5. ESN

7. Phone Settings

7.1. Language

7.2. Airplane Mode

7.3. Location

7.4. Set Mode

6. TOOLS

1. Voice Memo

2. Schedule

3. Alarm Clock

4. World Clock

5. Notepad

6. Calculator

7. Stopwatch

8. Convert Unit

BASIC FUNCTIONS

MAKING A CALL

Enter a phone number.

To modify the phone number you have entered :

Note

• To erase one digit at a time press .

• To erase the entire number, press and hold .

Press .

• If “CALL FAILED” appears on the display or the line is busy,

Note

press or .

• If you activate the “AUTO RETRY” function, the phone will automatically retry for the number of times you have selected.

• When you place or receive a call from stored phone numbers, only the name will be displayed.

• If “Enter Lock Code” appears on the display enter your 4-digit password to unlock your phone.

• Your default password is the last 4 digits of your phone number.

To end a call, press .

ANSWERING CALLS

When your phone rings or vibrates, press to answer the incoming call. (Depending on your phone’s settings, you may also

answer incoming calls by opening the phone or by pressing any digit key. See page 58 for details.)

• To ignore incoming calls, press [Ignore].

To end a call, press .

BASIC FUNCTIONS

•

Note

In Auto Answer Mode, a call is automatically answered after five seconds of ring tones.

SPEAKERPHONE

The speakerphone feature lets you hear audio through the speaker and talk without holding the phone.

To activate the speakerphone while answering or calling modes, press .

The phone returns to normal (SpeakerPhone Off) after ending a call or when the phone is turned off and back on.

WAIT/PAUSE FEATURE

Pauses are used for automated systems (i.e., Voicemail, calling cards). Insert a pause after a phone number then enter another group of numbers. The second set of numbers is dialed automatically after the pause. This feature is useful for dialing into systems that require a code.

To insert a wait/pause, enter a phone number then press [Options]. Select either a P-Hard Pause (“P” appears) or a T-2Sec

Pause (“T” appears).

Press to dial or press [Done] to save phone number.

BASIC FUNCTIONS

3-WAY CALLING

With 3-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be applied for each of the two calls.

Enter a number you wish to call then press .

Once you have established the connection, enter the second number you wish to call then press .

When you’re connected to the second party, press again to begin your 3-Way call.

CALLER ID FUNCTION

Identifies caller by displaying their phone number. If the caller’s name and number are already stored in your phone book, their name will appear. This is a system dependent feature. Please contact your service provider for details.

CALL WAITING FUNCTION

Notifies you of an incoming call when you are already on a call by sounding a beep tone and displaying the caller’s phone number.

To answer another call while on the phone, press . This places the first call on hold. To switch back to the first caller, press

again.

• Call Waiting is a system dependent feature. Please contact your service

Note

provider for details.

BASIC FUNCTIONS

ADJUSTING VOLUME

Adjusts the volume of the ringer, key beep and earpiece.

Press [Menu] then press for the “Settings” menu. Press “Sounds“ then press “Volume“. Select one of

the following options:

• Ringer: Controls the ringer volume.

• Key Tone: Controls the keypad volume.

• Speakerphone: Controls the speakerphone volume.

• Headset: Controls the earpiece volume.

• Advanced: Controls the volume for Message alert, Voicemail alert, Alarms, and

Adjust the volume by pressing or press / , then press to save the setting.

Note

Power On/Off.

• To adjust earpiece volume during a call, press up or down.

• Press and hold down to turn off all sounds.

• Press and hold up to return to normal mode.

• In idle mode, press up/down to adjust the master volume.

• Press and hold the key to turn vibrate mode on/off.

DURING A CALL

MUTE (UNMUTE)

If you press Mute during a call, the person you are speaking with cannot hear you or any sounds from your side of the conversation. However, you can still hear them. To activate Mute during a call, press [Mute].

• To deactivate, press [Unmute].

• The phone will automatically unmute in Emergency Call or Callback Mode.

SPEAKER ON

To activate speakerphone during a call:

Press [Options], then press .

VOICE MEMO

To record a voice memo during a call:

Press [Options], then press .

CONTACTS

To view a phone number from your Contact list during a call:

Press [Options], then press .

DURING A CALL

RECENT CALLS

To select a phone number from your Recent Calls List during a call:

Press [Options], then press .

MESSAGING

To send a text message (SMS) during a call:

Press [Options], then press .

MAKING AN EMERGENCY CALL

The 911 feature puts the phone in the Emergency Call Mode when you dial the preprogrammed emergency number, 911. It also operates in Lock Mode and outside the service area.

911 IN LOCK MODE

The 911 call service is available even in Lock Mode.

Enter “911”, then press .

The call connects.

When the call ends, the phone returns to Lock Mode.

911 USING ANY AVAILABLE SYSTEM

Enter “911”, then press .

The call connects.

The phone maintains the Emergency Mode and the phone can receive an incoming call from any available system. However, it

can’t make a call.

• The 911 call does not appear in the recent call list.

Note

CHAPTER 3

MEMORY FUNCTION

CHAPTER 3

MEMORY

FUNCTION

This chapter addresses memory functions including:

Storing a Phone Number Entering Letters, Numbers and Symbols Making a Call Through the Contact List

Contacts

STORING A PHONE NUMBER

The phone book stores up to 500 entries.

Enter phone number then press [Options], then press “Save”.

Select “Create New“ or “Update Existing“. If “Create New“ is selected, the New Entry icon list appears. Press / to

choose the type of number you are adding. Press to select. If “Update Existing” is selected, your contact list is displayed. Choose the entry to add the number to,then press . Select the type of number you are adding from the icon list, then press .

Enter a name. To change the input mode, press [Options]. Press to enter information in other fields for the contact.

Fields include Name, Mobile 1, Mobile 2, Home, Work, Fax, Email 1, Email 2, Group, Ringer, Memo.

• To select a group, scroll to Group field and press [Assign]. The group list will be displayed. Select a group and press .

• To select a ringer for the contact, scroll to the Ringer field and press [Select]. To play a highlighted ringer, press [Play]. To select the ringer, press [Done].

• To enter a note for the contact, scroll to the Memo field and enter your text. To change the input mode, press [Options].

To store the entry in your contact list, press [Done]. Select Yes and press . “Contact Saved“ will be displayed.

ENTERING LETTERS,

NUMBERS & SYMBOLS

The input mode will automatically be activated when it is necessary to enter letters and numbers. There are 4 available modes: Standard Alphabet mode (Abc), T9 Mode (T9Word), Numeric mode (123) and Symbol mode (Symbols). The input mode indicator appears on the lower portion of the display when letters and numbers are entered. To select the desired input mode, press [Options], then choose from the list on screen.

KEY

Press to change mode.

[T9Word][Abc] [123][Symbols]

KEY

Press to delete a character to the left of the cursor.

In T9 mode, press to view the next matching word if the highlighted word is not the word you intended.

Press to select the letter case: [Abc], [ABC], [abc] / [T9Word], [T9WORD], [T9word].

Press to accept a word and add a space.

ENTERING LETTERS, NUMBERS & SYMBOLS

STANDARD INPUT MODE

Use the digit keys to enter letters, numbers and characters.

Enter letters using the keypad. To change the input mode, press [Options]. Standard input mode is listed as Alphabet.

To enter a space, press . The cursor will automatically move to the next column.

Press each key until the desired letter appears.

To delete one character, press . To delete the entire entry, press and hold .

To change from lowercase to uppercase, press .

Select Abc mode by pressing [Options], then Alphabet.

E.G.

When you select this mode, the Abc icon appears as a visual confirmation.

- Find the key that corresponds to the letter you want to enter.

- Press it as many times as needed for the letter to appear on the screen.

- To enter the name “John”: Press [ ] J Press [,,] o Press [ , ] h Press [ , ] n

ENTERING LETTERS,

NUMBERS & SYMBOLS

T9 INPUT MODE

T9 mode incorporates a built-in-dictionary to determine a word based on the entered characters. A word can be entered more quickly by pressing each key once per character.

Select T9 mode by pressing [Options], then selecting “Entry Mode.”

Press a digit key once to enter the character you want then enter all the characters to input the word you want.

To view the next matching word, press .

To accept the matching word then enter a space, press .

To enter a compound word:

Note

• Enter the first part of the word then press to accept it without adding a space after it.

• Enter the last part of the word then press to accept the word.

To enter “Funfare” in T9 mode:

E.G.

- Press [Options] to select T9 mode.

- Press , , until you see “Fun” highlighted.

- Press to select “Fun”.

- Press , , , and you will see “ease” highlighted. Press until you see "fare" highlighted. Press to select and add a space.

ENTERING LETTERS, NUMBERS & SYMBOLS

NUMERIC MODE

Allows you to enter numbers.

Press [Options] and select “123“ for Numeric mode.

To enter a number, press its digit key.

SYMBOL MODE

Allows you to enter symbols.

Press [Options] and select “Symbol“ for Symbol mode.

Select the symbol you want to enter with the , then press .

MAKING A CALL THROUGH

THE CONTACT LIST

ONE-TOUCH/TWO-TOUCH DIALING

Ideal for frequently dialed numbers, this feature allows entries in your contact list to be dialed via the keypad with only one or two key presses. In order for One-Touch/Two-Touch Dialing to properly work, it must be enabled. To activate this function, press [Menu], ,

, , then select On or Off using the . Press [Done].

ONE-TOUCH DIALING

2-9 : Press and hold the corresponding memory number for more than 1

second.

TWO-TOUCH DIALING

10-99 : Press the first digit and second digits of the memory number

short and long respectively.

• If no phone number is stored in the location entered, "Location is

Note

empty" will appear on the screen.

• If One Touch Dial is set to Off: Enter the speed dial location number then press .

• Location 1 is reserved for voicemail. Location 2-99 are unassigned. To assign a speed dial location, please see page 37.

CONTACTS

Stores up to 500 entries, each of which can be assigned to a group. Entries can be retrieved by name or group.

CREATE NEW

Adds a new entry.

Press [Menu], then press “Contacts”, then "Create New".

Fill in the fields as they are selected. Press / to select a field.

•

PHONE BOOK FIELDS :

To save the entry, press [Done]. To return to the previous page, press .

• If no name is saved for the contact, the primary phone number will be

Note

See page 28 for more detailed information about storing a number.

displayed in the contact list.

Name/Mobile1/Mobile2/Home/Work/Fax/ E-Mail1/E-Mail2/Group/Ringer/Memo.

CONTACTS

FIND

Retrieves an entry by name and calls the primary number by simply pressing . You can review all the entries stored in your contacts list or quickly find an entry by entering a name or its character string.

Press [Menu], then press “Contacts”, then “Find”.

The list of names in your contacts is displayed alphabetically.

Enter a name or its character string or scroll through the list by pressing / .

To edit the entry, press [Edit]. Press [Options] to 1. Create New, 2. Send Message, 3. Call or 4. Erase.

To show the entry details, press . From the View Contacts

screen press [Options] to 1. Send Message, 2. Call, or 3. Erase.

To call the selected number, press [Options] then select “Call” or press .

GROUPS

Allows you to classify phone entries into groups. Existing groups include No Group, Family, Friends, Work. A maximum of 30 groups is allowed.

ADD NEW GROUP

Press [Menu], then press “Contacts”, then “Groups”.

CONTACTS

Press [Add] to add a new group name.

Input a new group name.

To save it, press [Done].

From the group list, press [Options] to 1. Rename, 2. Change Ringer or 3. Erase.

CHANGE GROUP NAME

1. Press [Menu], then press “Contacts”, then

“Groups”.

2. Select an existing group name. The only group name that cannot be

changed is No Group.

3. Press [Options], then scroll to Rename and press .

4. Input a new group name.

5. Press [Done] to save the setting.

SEND TEXT MSG. GROUP

Press [Menu], then press “Contacts”, then “Group”.

Select an existing group name that has phone numbers saved to it.

Press [Options], then scroll to “Send Message” and press .

Input your message. To add a graphic, sound or to use a preset message, press [Options] and select Add.

CONTACTS

To send the message, press [Send]. To save the message, press [Options], select “Save As Draft”, then

press .

ERASE GROUP

Press [Menu], then press “Contacts”, then “Groups”.

Select an existing group name.

Press [Options], then scroll to Erase and press .

“Erase?” will be displayed. Select Yes and press to erase the group.

SPEED DIALS

In idle mode, calls can be placed to numbers stored in speed dial by pressing & holding the location number on the key pad. For a 2-digit location number, press the first number, then press and hold the second number.

• Speed Dial must be activated. See page 59 for additional information.

Note

Press [Menu], then press “Contacts”, then “Speed Dial”.

To assign a phone number to a location, select the location then press [Assign].

• “Unassigned” appears if the location is available.

Note

CONTACTS

Scroll to the contact in the list.

If more than one number exists for the contact, press / to select the phone number for the speed dial location. The

numbers will be displayed above the contact list.

Press [Assign] to set the speed dial location.

SERVICE NUMBERS

Your Contacts list is preprogrammed with contact numbers for various services.

Press [Menu], then press "CONTACTS".

Press "Service Numbers".

Select number then press .

Press to call.

CHAPTER 4

MENU FUNCTION

CHAPTER 4

MENU FUNCTION

This chapter addresses accessing the menu and using

its functions and features to customize your phone.

Recent Calls

Settings

RECENT CALLS

ALL CALLS

Displays information about the most recent received, dialed and missed calls.

Press [Menu], then press for the “Recent Calls” menu. Press “All Calls”. If the number is already stored in your

contact list, only the name appears. If the number is not stored, the number appears.

To view details, press .

• Call details include type of call, date, time and phone number.

Note

Press [Options] and select “Save“ to save it to your contact list or select “Erase“ to delete it.

• Save: To store the phone number in your contact list.

• Send Msg.: To send a message to the highlighted phone number.

• Details: To view the caller's information.

• Lock/Unlock: To lock or unlock the highlighted phone number.

• Erase: To erase the highlighted phone number.

• Erase All: To erase all the phone numbers in the list.

• After the 270th received, dialed or missed calls, the oldest call will

Note

automatically be erased from the history.

RECENT CALLS

MISSED CALLS

Displays information about the 90 most recent missed calls. Place a call to a missed call number by simply pressing .

Press [Menu], then press for the “Recent Calls” menu. Press “Missed Calls”. If the number is already stored in your

contact list, only the name appears. If the number is not stored, the phone number appears.

To view missed call details, press .

• Call details include date, time and phone number.

Note

Press [Options] and select “Save” to save it to your contact list or select “Erase” to delete it.

• Send Msg.: To send a message to the highlighted phone number.

• Details: To view the caller's information.

• Lock/Unlock: To lock or unlock the highlighted phone number.

• Erase: To erase the highlighted phone number.

• Erase All: To erase all the phone numbers in the list.

• After 90 missed calls, the oldest call will be automatically erased from the

Note

history.

RECENT CALLS

INCOMING CALLS

Displays information about the 90 most recently received calls. Place a call to a incoming call number by simply pressing .

Press [Menu], then press for the “Recent Calls” menu. Press “Incoming calls“. If the number is already stored in

your contact list, only the name appears. If the number is not stored, the number appears.

To view incoming call details, press .

• Call details include date, time and phone number.

Note

Press [Options] and select “Save” to save it to your contact list or select “Erase” to delete it.

• Send Msg.: To send a message to the highlighted phone number.

• Details: To view the caller's information.

• Lock/Unlock: To lock or unlock the highlighted phone number.

• Erase: To erase the highlighted phone number.

• Erase All: To erase all the phone numbers in the list.

• After 90 incoming calls, the oldest call will automatically be erased from

Note

the history.

RECENT CALLS

OUTGOING CALLS

Displays information about the 90 most recently dialed numbers. Place a call to a outgoing call by simply pressing .

Press [Menu], then press for the “Recent Calls” menu. Press

“

Outgoing Calls“. If the number is already stored in your contact list, only the name appears. If the number is not stored, the number appears.

To view dialed call details, press .

• Call details include type of call, date, time and phone number.

Note

Press [Options] and select “Save” to save it to your contact list or select “Erase” to delete it.

• Send Msg.: To send a message to the highlighted phone number.

• Details: To view the caller's information.

• Lock/Unlock: To lock or unlock the highlighted phone number.

• Erase: To erase the highlighted phone number.

• Erase All: To erase all the phone numbers in the list.

• After 90 dialed calls, the oldest call will automatically be erased from the

Note

history.

RECENT CALLS

CALL TIMERS

Checks the usage time and manages your calls within the limit you set. The 11 timers include (Last Call, All Calls, Incoming Calls, Outgoing Calls, Roaming Calls, Transmit KB, Received KB, Total KB, Last Reset, Lifetime Calls, Lifetime Data Counter):

Press [Menu], then press for the “Recent Calls” menu. Press “Call Timers”.

To reset the selected timer, press [Options], then select “Reset”. “Reset?” will be displayed.

Select Yes and press . To reset all timers, press [Options], then select “Reset All”. “Reset All?” will be displayed. Select Yes and press .

To return to the previous page, press .

SETTINGS

Customizes your phone and optimizes performance through a variety of settings.

SOUND SETTINGS

RINGER TYPE

Ringer

To select a ringer type for incoming calls:

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Ringer Type” then press “Ringer”.

Select your desired ringer type by pressing / .

• Press [Play] to play/stop the ringer.

Press [Done] to save the setting.

SETTINGS

Messages

This setting allows you to select the alert type for text messages.

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Ringer Type” then press “Messages”.

Select your desired alert type by pressing / .

• Press [Play] to play/stop the alert beep.

Press [Done] to save the setting.

Voicemail

This setting allows you to select the alert type for voicemail messages.

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Ringer Type” then press “Voicemail”.

Select your desired alert type by pressing / .

• Press [Play] to play/stop the alert beep.

Press [Done] to save the setting.

SETTINGS

Alarm

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Ringer Type” then press “Alarm”.

Select your desired ringer type by pressing / .

• Press [Play] to play/stop the ringer.

Press [Done] to save the setting.

Roam Ringer

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Ringer Type” then press “Roam Ringer”.

Select “Normal” or “Distinctive”.

Press [Done] to save the setting.

SETTINGS

VOLUME Ringer

To adjust Ringer volume:

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Volume” then press “Ringer”.

Select one of the following settings by pressing / .

• Silence All, Ringer Off, Vibrate, Level 1~5

Press [Done] to save the setting.

Key Tone

To adjust Key tone volume:

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Volume” then press “Key Tone”.

Select one of the following settings by pressing / .

• Silence All, Level 1~5

Press [Done] to save the setting.

SETTINGS

Speakerphone

To adjust Speakerphone volume:

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Volume” then press “Speakerphone”.

Select one of the following settings by pressing / .

• Level 1~5

Press [Done] to save the setting.

Headset

To adjust Headset volume:

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Volume” then press “Headset”.

Select one of the following settings by pressing / .

• Level 1~5

Press [Done] to save the setting.

SETTINGS

Advanced

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Volume” then press “Advanced”.

Select one of the following settings by pressing / .

• Messaging

• Voicemail

• Alarms

• Power On/Off

Press to highlight volume section. Then press / to adjust the volume level.

• Use Ringer

• Separate

Press [Done] to save the setting.

SETTINGS

ALERTS

Minute Beep

Sounds an alert every minute during a call.

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Alerts” then press “Minute Beep”.

Select “On” or “Off”, then press [Done] to save the setting.

Roaming

Sounds an alert when leaving a service area and entering a roaming service area.

Press [Menu], then press for the “Settings” menu.

Press “Sounds”, and “Alerts” then press “Roaming”.

Select “On” or “Off”, then press [Done] to save the setting.

SETTINGS

Connect

Notifies you that a call has been successfully placed.

Press [Menu], then press for the “Settings” menu. Press “Sounds”, and “Alerts”, then press

“Connect”.

Select “On” or “Off”, then press [Done] to save the setting.

Fade

Press [Menu], then press for the “Settings” menu. Press “Sounds”, and “Alerts”, then press “Fade”.

Select “On” or “Off”, then press [Done] to save the setting.

TONE LENGTH

Press [Menu], then press for the “Settings” menu. Press “Sounds”, and "Tone Length".

Select “Normal” or “Long”, then press [Done] to save the setting.

SETTINGS

DISPLAY SETTINGS

Allows you to customize the display.

WALLPAPER


Press [Menu], then press for the “Settings” menu. Press “Display”, then “Wallpaper” and then

“Image”.

Select 1. Preset Image., 2. Download Image, or 3. EMS Image. A list of images for the submenu will be shown. Press [View] to

view the image full screen.

Press [Done] to save the image as your wallpaper.

Clock Format

Press [Menu], then press for the “Settings” menu. Press “Display”, then “Wallpaper” and then

“Clock Format”.

The following options appear:

• Digital Clock, Analog Clock, Dual Time Clock, Calendar

Press [Done] to save the setting.

SETTINGS

SCREENSAVER

Time setting

Press [Menu], then press for the “Settings” menu. Press “Display”, then “Screensaver” and then

“Time Setting”.

Select one of the following options:

• Off, 5sec, 10sec, 20sec, 30sec

Press [Done] to save the time setting.

Screensaver

Press [Menu], then press for the “Settings” menu. Press “Display”, then “Screensaver” and then

“Screensaver”.

Select "On" or "Off" and press [Done]. If “On” is selected, choose one of the pre-installed images.

Press [View] to view the image full screen.

Press [Done] to save the image as your screensaver.

SETTINGS

BACKLIGHT

Backlights the display and key pad for easy viewing in dark places.

LCD

Press [Menu], then press for the “Settings” menu. Press “Display”, “Backlight”, and then press

“LCD”.

Select one of the following options:

• 7sec, 15sec, 30sec, Always On, Always Off

Press [Done] to save the setting.

Keypad

Press [Menu], then press for the “Settings” menu. Press “Display”, then “Backlight”, and then

press “Keypad”.

Select one of the following options:

• 7sec, 15sec, 30sec, Always On, Always Off

Press [Done] to save the setting.

SETTINGS

GREETING

The greeting can be up to 16 characters and is displayed on your phone’s screen in idle mode.

Press [Menu], then press for the “Settings” menu. Press “Display”, then “Greeting”.

Enter your greeting. To change the input mode, press [Options].

Press [Done] to save the Greeting.

CONTRAST

To adjust the display contrast:

Press [Menu], then press for the “Settings” menu. Press “Display”, then “Contrast”.

Select one of the following options:

• Level 0 - Level 5

Press [Done] to save the setting.

SETTINGS

MENU STYLE

To select how the Menu appears on your phone:

Press [Menu], then press for the “Settings” menu. Press “Display”, then “Menu Style”.

Select “Graphic” or “List”.

Press [Done] to save the menu style.

CALL

ABBREV. DIAL

This function allows you to dial just the last 4 digits of the phone number, instead of all the digits. If you have several phone numbers that start with the same digits, you can enter the beginning numbers here so when you dial the phone, all you enter is the last 4 digits.

Press [Menu], then press for the “Settings” menu. Press “Call“, then “Abbrev. Dial”.

Select “Disable” or “Enable”, then press [Done] to save the setting.

If Enable is selected, a blank screen will appear. Enter the digits that are common to several phone numbers you dial and press

[Done].

• You have 5 numbers you dial often that all begin with (516) 123. In the blank screen that appears when you select "Enable", type in 516123.

• When you need to dial (516) 123-6652, simply press 6652 . Your phone will show it is dialing (516) 123-6652.

SETTINGS

CONTACTS MATCH

This function will match your abbreviated dialed number with an entry from your phone's contact list. So when you dial the 4 digits, your phone will show the name of the contact you are dialing as well as the phone number.

Press [Menu], then press for the “Settings” menu. Press “Call”, then “Contacts Match”.

Select “Disable” or “Enable”, then press [Done] to save the setting.

ANSWER MODE

To select an answer mode:

Press [Menu], then press for the “Settings” menu. Press “Call“, then “Answer Mode”.

Select one of the following options:

• Talk Key : Answers an incoming call by pressing only.

• Any Key : Answers an incoming call by pressing any key except , ,

• Folder Open : Answers an incoming calls by simply opening the phone.

or .

Press [Done] to save the setting.

SETTINGS

AUTO RETRY

Automatically redials a call up to 5 times after a set time interval.

Press [Menu], then press for the “Settings” menu. Press “Call”, then “Auto Retry”.

Select “On” or “Off”, then press [Done] to save the setting.

TTY MODE

Your phone is able to operate with a TTY (Teletypewriter) device in digital modes. This feature is system dependent and may not be available in all areas.

Press [Menu], then press for the “Settings” menu. Press “Call”, then “TTY Mode”.

Select one of the following options:

• TTY + Full

• TTY + Talk

• TTY + Hear

• TTY Off

Press [Done] to save the setting.

SPEED DIAL

Enables you to dial numbers in your speed dial list by pressing and holding the 1 or 2 digit location number.

Press [Menu], then press for the “Settings” menu. Press “Call”, then “Speed Dial”.

Select “On” or “Off”, then press [Done] to save the setting.

SETTINGS

VOICE PRIVACY

Enhances voice privacy and avoids tapping during a call.

Press [Menu], then press for the “Settings” menu. Press “Call”, then "Voice Privacy".

Select “On” or “Off”, then press [Done] to save the setting.

DATA SETTING

Select Port

Press [Menu], then press for the “Settings” menu. Press “Call”, then “Data Setting” and

then “Select Port”.

Select “USB” or “UART1”, then press [Done] to save the setting.

Port Speed

Press [Menu], then press for the “Settings” menu. Press “Call”, then “Data Setting” and

then “Port Speed”.

Select one of the following options:

• 19200 bps, 115200 bps, 230400 bps, Auto[USB]

Press [Done] to save the setting.

SETTINGS

VR SETTINGS

CHOICE LIST

The “Choice List” option will allow you to choose if the Command System prompts you with a list of potential matches. “On” will always present you with a best match list of names or numbers. When multiple matches are found, the system will prompt you to choose from a list of matches. If the Choice List is set to “Off”, the voice command system will select the best match.

Press [Menu], then press for the “Settings” menu. Press “VR Settings”.

Press “Choice List”.

Select “Automatic”, “On” or “Off”.

Press [Done] to save it.

TRAIN VOICE

Train Voice is the process of optimizing the voice recognition software to your voice. Train Voice requires that you make recordings of your voice, which are then used to customize the voice recognition system. This will take a few minutes and you should be in a quiet environment for optimum training.

Press [Menu], then press for the “Settings” menu. Press “VR Settings”.

Press “Train Voice”.

SETTINGS

Select “Train Words” or “Train Digits”. You will be prompted to speak the words listed on the screen. Say each word as you are

prompted.

Press [Stop] to stop train voice.

PROMPT

The prompts settings, “Mode” or “Timeout’, will allow you to set how you are notified by the voice command system and the duration in which you can respond. To access “Prompts:”

Press [Menu], then press for the “Settings” menu.

Press “VR Settings”.

Press “Prompt“.

Select “Mode“ or “Timeout”.

• Mode: Select "Prompt" or “Tones Only”.

• Timeout: Select “5 sec” or “10 sec”.

Press [Done] to save it.

CALL ALERT

The “Call Alert” setting controls how you are notified when receiving a call. “Name + Ring” will first announce the name and then play the set ring tone. “Ring only” will play the set ring tone only. “Name Repeat” continuously states the name or number until the call is answered or incoming call alert ends.

Press [Menu], then press for the “Settings“ menu. Press “VR Settings”.

SETTINGS

Press “Call Alert“.

Select “Ring Only“, “Name+Ring“ or “Name Repeat”.

Press [Done] to save it.

SECURITY SETTINGS

Prevents unauthorized use of your phone. The following settings can be restricted:

LOCK PHONE

Prevents the phone from being used without entering the password first.

Press [Menu], then press for the “Settings” menu.

Press “Security”. Enter your password.

• The default Lock code is the last 4 digit of your phone number.

Press “Lock Phone”.

Select “Lock”, “Unlock”, and “Power Up”. When the phone is locked, will appear in the top row of the display.

• Lock: Lock the phone now.

• Power Up: Do not lock the phone now, but automatically lock when power is

• Unlock: Do not lock the phone.

Press [Done] to save the setting.

recycled.

SETTINGS

CHANGE LOCK

Changes your 4-digit password.

Press [Menu], then press for the “Settings” menu. Press “Security”. Enter your password.

• The default Lock code is the last 4 digit of your phone number.

Press “Change Lock”.

Enter your lock code.

“Enter New Lock Code” screen appears. Enter your new lock code.

“Enter New Lock Code Again” screen appears. Enter your new lock code again, then press [Done] to save the setting.

LIMIT USE

Incoming Calls

Press [Menu], then press for the “Settings” menu. Press “Security”. Enter your password.

• The default Lock code is the last 4 digit of your phone number.

Press “Limit Use”, then “Incoming Calls”.

Select “Allow” or “Restricted”, then press [Done] to save the setting.

SETTINGS

Outgoing Calls

Press [Menu], then press for the “Settings” menu. Press “Security”. Enter your password.

• The default Lock code is the last 4 digit of your phone number.

Press “Limit Use“, then “Outgoing Calls”.

Select “Allow” or “Restricted”, then press [Done] to save the setting.

ERASE CONTACTS

To erase all the names and phone numbers in your internal contact list:

Press [Menu], then press for the “Settings” menu. Press “Security”. Enter your password.

• The default Lock code is the last 4 digit of your phone number.

Press “Erase Contacts”.

Select “Yes” or “No“, then press [Done].

SETTINGS

DEFAULT SETTINGS

Preference setting will be set to factory defaults.

Press [Menu], then press for the “Settings” menu. Press “Security”. Enter your password.

• The default Lock code is the last 4 digit of your phone number.

Press “Default Settings”.

“Preference setting will be set to factory defaults" will be shown. Press [Next].

Select “Yes” or “No”, then press [Done].

RESET PHONE

All saved contents and preference setting will be reset to factory defaults.

Press [Menu], then press for the “Settings” menu. Press “Security”. Enter your password.

• The default Lock code is the last 4 digit of your phone number.

Press “Reset Phone”.

“All saved contents and preference setting will be set to factory defaults" will be shown. Press [Next].

Select “Yes” or “No”, then press [Done].

SETTINGS

PHONE INFO

Displays the information of your phone:

PHONE NUMBER

Displays your MDN and MIN.

Press [Menu], then press for the “Settings” menu. Press “Phone Info“, then press “Phone Number“.

The MDN and MIN will be displayed along with your service provider’s name.

To return to the previous page, press .

HELP

Press [Menu], then press for the “Settings” menu. Press “Phone Info“, then press "Help".

The indicator icons are displayed.

To return to the previous page, press .

VERSION

Displays the PRL, SW Version, HW version:

Press [Menu], then press for the “Settings” menu. Press “Phone Info”, then “Version”.

The PRL, software and hardware version information is displayed.

To return to the previous page, press .

SETTINGS

ADVANCED

Press [Menu], then press for the “Settings” menu. Press “Phone Info”, then "Advanced".

The SID, Channel, Technology and Frequency information is displayed.

To return to the previous page, press .

ESN

Press [Menu], then press for the “Settings” menu. Press “Phone Info”, then "ESN".

The Hex and Dec information is displayed.

To return to the previous page, press .

SETTINGS

PHONE SETTINGS

LANGUAGE

Selects the language in which letters are displayed on the screen.

Press [Menu], then press for the “Settings” menu. Press “Phone Settings”, then “Language”.

Select “English” or “Spanish”.

Press [Done] to save the language setting.

AIRPLANE MODE

Airplane Mode deactivates the wireless connectivity of your phone but allows you to continue using non-network functions like the Calendar and games.

Press [Menu], then press for the “Settings” menu. Press “Phone Settings”, then “Airplane Mode”.

Select “On”, “Off” or “Power Up”, then press [Done] to save the setting.

• You cannot make or receive calls or text messages when Airplane Mode is

Note

On.

SETTINGS

LOCATION

To set the location function:

Press [Menu], then press for the “Settings” menu. Press “Phone Settings”, then “Location”.

Select “Location On” or “E911 Only”.

• Location On: Your location is now available to the network.

• E911 Only: Your location will be hidden from network & application except 911

Press [Done] to save the setting.

• If you have set Lock Mode for Location to “Lock”, you will need to enter

Note

SET MODE

To set the mode function:

your location lock code before you can enter this menu. The default value is the last 4-digits number of the phone number.

Press [Menu], then press for the “Settings” menu. Press “Phone Settings”, then “Set Mode”.

Select “Home Only”, “Automatic A”, or “Automatic B.”

• Home Only: Only within your home area or home affiliated area.

• Automatic A: Scan the radio channels based on the Automatic A setting.

• Automatic B: Scan the radio channels based on the Automatic B setting.

Press [Done] to save the setting.

CHAPTER 5

PERSONAL ORGANIZER

CHAPTER 5

PERSONAL

ORGANIZER

This section shows you how to use these features to turn

your phone into a time management planner that helps you

keep up with your contacts, schedules and appointments.

TOOLS

VOICE MEMO

Voice Memo allows you to record a reminder message that can be up to 60 seconds. To record a memo:

Press [Menu], then press for the “Tools” menu. Press "Voice Memo".

To record a voice memo, select “1. Record New“ and press [Record].

You will see “Press Start to start recording“ on the screen. Press [Start] to begin recording your memo.

To stop recording a voice memo, press [Stop]. Stopping the recording will automatically save the entry. The list is sorted by the

date of the recording.

To play voice memo, select the voice tag you want to play then press [Play]. To erase one or all voice memos, press

[Options] to select one of the following options:

• Erase

• Erase All

TOOLS

SCHEDULE

Sets an event and reminds you of that event.

ADD NEW CALENDAR

Press [Menu], then press for the “Tools” menu.

Press [Menu], then press for the “Tools” menu. Press "Schedule".

Press "Schedule".

Press / / or to choose a date in the calendar,

Press / / or to choose a date in the calendar, then press [Add].

then press [Add].

The New Event screen will be displayed. Enter the event name.

The New Event screen will be displayed. Enter the event name. Press to move to the next fields. In the Start Time field and

Press to move to the next fields. In the Start Time field and End Time field, enter the time. Press for AM or PM. In the

End Time field, enter the time. Press for AM or PM. In the Start Date field and the End Date field, you can edit the date for the

Start Date field and the End Date field, you can edit the date for the event. In the Contents field, enter any notes for the event. In the

event. In the Contents field, enter any notes for the event. In the Notice field, enter when the alert should sound for the event (On

Notice field, enter when the alert should sound for the event (On Time, before 10 min, before 20 min, before 30 min). In the Snooze

Time, before 10 min, before 20 min, before 30 min). In the Snooze field, set the snooze time (5 min, 10 min, 15 min, 20 min). In the

field, set the snooze time (5 min, 10 min, 15 min, 20 min). In the Ringer field, press [Change] to select a ringer for the event.

Ringer field, press [Change] to select a ringer for the event. Press [Done] when the ringer is selected.

Press [Done] when the ringer is selected.

Press [Done] to save the event or to return to the

Press [Done] to save the event or to return to the calendar.

calendar.

The date of the event will be marked on your calendar.

TOOLS

VIEW ADDED CALENDAR

Press [Menu], then press for the “Tools” menu. Press "Schedule".

Scroll to a date in the calendar and press to view the event for that day.

Press [Options] to erase one event or all events in the calendar. “Erase?” and “Erase All?” will be displayed. Select

“Yes”, then press . Press [View] to see the details for the event and to edit or erase the event.

TOOLS

ALARM CLOCK

Press [Menu], then press for the “Tools” menu. Press “Alarm Clock”.

Select Alarm 1, 2 or 3 to set a new alarm. To edit an existing alarm, select the alarm name. Press [Set].

• Set: Press / to select alarm on or off.

• Time: Use the keypad to set a time for the alarm and to select “AM” or

“PM”.

• Repeat: Press / to select Daily/Once/Mon - Fri/Sat & Sun.

• Snooze: Press / to select 5Min/10Min/15Min/20Min.

• Ringer Type: Press [Change] to select a ringtone for the alarm sound.

To save an alarm setting press [Done].

TOOLS

WORLD CLOCK

Press [Menu], then press for the “Tools” menu. Press “World Clock”.

The world map appears with the city, its date and time. Use the to select another city.

• Press [Options] for 1. DST On or 2. Set Dual Time. DST stands for

Note

Daylight Savings Time.

TOOLS

NOTEPAD

Your phone includes an internal notepad that can be used to compose and store reminders and notes.

ADD NEW MEMO

To compose a memo (there is an 80-letter limit):

Press [Menu], then press for the “Tools” menu. Press “Notepad”.

To add a new memo, press [Add]. Input a new text memo.

To save memo, press [Done].

VIEW MEMO

To view a saved memo:

Press [Menu], then press for the “Tools” menu. Press “Notepad”.

The Notepad list of memos is displayed in the order they were saved. To add a new memo, press [Add]. Highlight a memo

and press [Options] to 1. Edit, 2. Erase, or 3. Erase All.

To view a memo, highlight it and press . Press [Erase] to erase the memo or press [Edit] to edit the text, then press

[Done] to save the changes.

TOOLS

CALCULATOR

To access the calculator:

Press [Menu], then press for the “Tools” menu. Press “Calculator”.

Enter the number using your keypad and perform one of the following functions:

• Press for Multiplication (x).

• Press for Division (÷).

• Press for Subtraction (-).

• Press for Addition (+).

• Press for a decimal point.

• Press for change the displayed number from positive (+) to negative (-) and vice versa.

• Press to clear all numbers.

• Press to select left parenthesis or right parenthesis.

Enter the numerical formula and press for Equals (=).

To reset, press [AC].

TOOLS

STOPWATCH

Simultaneously times up to ten different events. To operate the stop watch:

Press [Menu], then press for the “Tools” menu. Press “Stopwatch”.

To measure a time period:

• To start, press [Start].

• To stop a time period and continue measuring another one, press [Check].

• To stop the second and continue measuring a third one, press [Check].

• To measure up to ten time periods, repeat the above steps.

• To stop the stop watch, press [Stop].

• To review the results, press / .

• To reset it, press [Reset].

TOOLS

CONVERT UNIT

To access the conversion tool:

Press [Menu], then press for the “Tools” menu. Press “Convert Unit”.

Select the desired type of measurement, and then press .

• Length/Weight/Volume/Area/Temperature/Speed

To change the unit type (for example: m, cm), press / and use the keypad to enter the unit to convert. If you need to

change the lower unit of measure (the unit you are converting into), press to highlight that area.

CHAPTER 6

MESSAGE

CHAPTER 6

MESSAGE

This chapter addresses voicemail and text messaging.

MESSAGE

NEW MSG

To send a new message:

Press [Message], then press “New Msg”.

Under “TO”, input the phone number.

By pressing [Options], you can choose from the following:

• Recent Calls: Search for the phone number which is stored in the recent calls list.

• Contacts: Search for the phone number which is stored in the contacts list.

• Group List: Search the group which is stored in the contacts list.

• Entry Mode: Change the text input mode for this field.

Press . Under “Message”, input your message.

If you want to add a graphic, sound or use a preset message, press

[Options], then select "Add".

• Graphics: Inserts simple graphic image in message.

• Sound: Inserts sound in message.

• Preset MSG: Inserts already written sentences in message.

To save the Message, press [Options], then select “Save As Draft”. Press [Options], then select “Priority”, select “Urgent”

or “Normal”, then press [Done].

To send the message, press [Send].

MESSAGE

INBOX

The Inbox manages received text/web alert messages. To access:

Press [Message], then press “Inbox”.

Select a message, then press . The message is displayed. To delete a message, press [Erase], then select “Yes” or “No”and

press .

By pressing [Options], you can choose from the following:

• Forward: To forward the message.

• Reply with copy: To reply to a received message and include the received

• Save Graphics: To save a picture.

• Save Sound: To save a sound

• Save Quick Text: Select to save received text message.

• Lock/Unlock: To lock or unlock the message.

• Add to Contacts: Select to save number to contacts.

• Message Info: To show received message information.

message into the message.

MESSAGE

OUTBOX

Manages sent messages.

Press [Message], then press “Outbox”.

Select a message, then press . The message is displayed.

By pressing [Options], you can choose from the following:

• Forward: To forward the message.

• Resend: To resend the text message.

• Lock/Unlock: To lock or unlock the message.

• Add to Contacts: Select to save number to contacts.

DRAFTS

Draft Folder contains any draft messages or saved messages. If message composition is interrupted by a voice call or other interrupting event, the text of the current composition is automatically saved in the drafts folder.

Press [Message], then press “Drafts”.

Select a message then press .

By pressing [Options], you can choose from the following:

• Forward: To forward the message.

• Resend: To resend the text message.

• Lock/Unlock: To lock or unlock the message.

• Add to Contacts: Select to save number to contacts.

MESSAGE

VOICEMAIL

Displays the number of voicemails and accesses them by pressing .

CALL VOICEMAIL

Press [SEND] to dial voicemail”. From the idle screen, press then [SEND] to direct dial voicemail.

If the feature “Speed Dial” is enabled you can press and hold to speed dial voicemail.

Listen to the system prompts to hear your messages.

SETTINGS

NOTIFICATION

Press [Message], then press "Settings". Press "Notification".

Select "MSG. & Icon" or "Only Icon" , then press [Done] to save the setting.

AUTO SAVE

Press [Message], then press "Settings". Press "Auto Save".

Select "Auto Save”, "Prompt" or “Do Not Save”, then press [Done] to save the setting.

MESSAGE

AUTO ERASE

Press [Message], then press "Settings". Press "Auto Erase".

2. Select "On" or "Off".

• On: Oldest message erased from inbox automatically when box is full.

• Off: Oldest message not erased from inbox automatically, user prompted when

box is full.

3. Press [Done] to save the setting.

AUTO VIEW

Press [Message], then press "Settings". Press "Auto View".

Select "On" or "Off" , then press [Done] to save the setting.

ENTRY MODE

Change the text input mode.

Press [Message], then press "Settings". Press "Entry Mode".

Select "T9 Word”, "ABC", “Abc”, or “123” then press [Done] to save the setting.

MESSAGE

CALL BACK #

Press [Message], then press "Settings". Press “Callback #”.

Select "None”, "MDN", or “Custom” then press [Done] to save the setting.

VOICEMAIL #

Press [Message], then press "Settings". Press "Voicemail".

“Enter the desired voicemail access number.” Default setting is *99.

Press [Done] to save the setting.

SIGNATURE

Press [Message], then press "Settings". Press "Signature".

To activate Signature, highlight “Custom” then press [Edit]. The signature input screen appears.

Input your signature and press [Done] to save and exit.

PRESET MSGS.

Press [Message], then press "Settings". Press "Preset Msgs.".

The text messages are displayed.

MESSAGE

Press [Options], then select one of the following options:

• Add New: Write your own preset message and add to the list.

• Send MSG: Send a message with the highlighted preset message inserted.

• Erase: Erase the highlighted preset message.

• Erase All: Erase all the preset messages.

Select the text message, then press .

When the preset message screen is shown with the message:

• Edit: Press [Edit] to edit the message.

• Option: Press [Options] to 1. Send Msg., or 2. Erase.

CHAPTER 7

CRICKET CLICKS

CHAPTER 7

CRICKET CLICKS

Your phone provides a unique feature –Cricket Clicks-

that enables you to download melody ringers, wallpapers,

games and more from the network to

your phone. Please contact your service provider for the

availability of these services or

visit mycricket.com to learn more.

CRICKET CLICKS

Cricket Clicks is a fun collection of features which you can access directly from your phone - download ringtones, games, graphics, and more. Charges apply.

Press [Menu], then press for the “Cricket Clicks” menu. Press “Cricket Clicks“.

You will see 3 icons - Cricket Clicks, Settings, Help. To download images, ringers, games, etc., select Cricket Clicks and press .

Settings: Select to Manage Apps. or Erase Downloads. Help: Select to learn more about Cricket Clicks and how to use it.

Select from “Catalog“ and press . The server will launch. Browse through the catalog and press to select an application

and price plan. Then follow the prompts to download the application. Repeat this process for each additional application.

To exit Cricket Clicks, press .

CHAPTER 8

SAFETY INFORMATION

CHAPTER 8

SAFETY

INFORMATION

Read this information before using your handheld

portable Cellular Telephone.

SAFETY

WARRANTY

SAFETY

SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES

Read This Information Before Using Your Handheld Portable Cellular Telephone

DRIVING SAFETY

Talking on the phone while driving is extremely dangerous and is illegal in some states. Remember, safety comes first. Check the laws and regulations on the use of phones in the areas where you drive. Always obey them. If you must use your phone while driving, please:

• Give full attention to driving. Driving safely is your first responsibility.

• Use hands-free operation and/or one-touch, speed dialing, and auto answer modes.

• Pull off the road and park before making or answering a call.

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

WARNING!:

Failure to follow these instructions could lead to serious personal injury and possible property damage.

SAFETY

ELECTRONIC DEVICES

Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.

Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone. Therefore, use of your phone must be restricted in certain situations.

PACEMAKERS

The Health Industry Manufacturers Association recommends that a minimum separation of six (6”) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Never come closer than six (6) inches to a person with a heart pacemaker implant when using your phone. Doing so could result in interference with the function of the pacemaker.

Persons with pacemakers :

• ALWAYS keep the phone more than six inches from your pacemaker when the phone is turned on.

• Do not carry the phone in a breast pocket.

• Use the ear opposite the pacemaker to minimize the potential for interference.

• If you have any reason to suspect that interference is taking place, turn your phone OFF immediately.

SAFETY

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).

OTHER MEDICAL DEVICES

If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

HOSPITALS AND HEALTH CARE FACILITIES

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or healthcare facilities may be using equipment that could be sensitive to external RF energy.

VEHICLES

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

POSTED FACILITIES

Turn your phone OFF where posted notices so require.

SAFETY

AIRCRAFT

FCC regulations prohibit using your phone while in the air. Turn your phone OFF before boarding an aircraft. Always request and obtain prior consent and approval of an authorized airline representative before using your phone aboard an aircraft. Always follow the instructions of the airline representative whenever using your phone aboard an aircraft, to prevent any possible interference with airborne electronic equipment.

BLASTING AREAS

To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted “Turn off two-way radio”. Obey all signs and instructions.

POTENTIALLY EXPLOSIVE ATMOSPHERES

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations; below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your vehicle’s engine.

SAFETY

SAFETY INFORMATION FOR FCC RF EXPOSURE

Warning! Read this information before using your phone.

In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

BODY-WORN OPERATION

This device was tested for typical body-worn operations with the back of the phone kept 2.0 cm from the body. To maintain compliance with FCC RF exposure requirements, use only belt-clips, holsters or similar accessories that maintain a 2.0 cm separation distance between the user’s body and the back of the phone, including the antenna. The use of belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.

For more information about RF exposure, please visit the FCC website at www.fcc.gov.

SAFETY

SAR INFORMATION

THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model.

SAFETY

The highest SAR value for this model phone when tested for use at the ear is 1.15W/Kg and when worn on the body, as described in this user guide, is 0.393W/Kg. (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on O6Y-CDM7025C.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) website at http://www.phonefacts.net

In the United States and Canada, the SAR limit for mobile phones

used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

SAFETY

FDA CONSUMER UPDATE

U.S. Food and Drug Administration Cell

Phone Facts Consumer Information on Wireless Phones

1. What kinds of phones are the subject of this update?

The term “wireless phone” refers here to handheld wireless phones with built-in antennas, often called “cell,” “mobile,” or “PCS” phones. These types of wireless phones can expose the user to measurable radiofrequency energy (RF) because of the short distance between the phone and the user’s head. These RF exposures are limited by Federal Communications Commission safety guidelines that were developed with the advice of FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person's RF exposure decreases rapidly with increasing distance from the source. The so-called "cordless phones," which have a base unit connected to the telephone wiring in a house, typically operate at far lower power levels, and thus produce RF exposures well within the FCC's compliance limits.

2. Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range while being used. They also emit very low levels of RF when in the standby mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not

SAFETY

been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

3 . What is FDA's role concerning the safety of wireless phones?

Under the law, FDA does not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is hazardous to the user. In such a case, FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA regulatory actions, FDA has urged the wireless phone industry to take a number of steps, including the following:

• Support needed research into possible biological effects of RF of the type emitted by wireless phones;

• Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function; and

• Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health

FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:

100

Utstarcom CDM7025C, CDM7025 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
