Standard Products

UT28F256LV Radiation-Hardened 32K x 8 PROM

Data Sheet

December, 2002

FEATURES

q Programmable, read-only, asynchronous, radiation-

hardened, 32K x 8 memory

- Supported by industry standard programmer

q 65ns maximum address access time (-55 oC to

+125 oC)

q Three-state data bus
q Low operating and standby current

- Operating: 50.0mA maximum @15.4MHz

• Derating: 1.5mA/MHz

- Standby: 1.0mA maximum (post-rad)

q Radiation-hardened process and design; total dose

irradiation testing to MIL-STD-883, Method 1019

- Total dose: 1E6 rad(Si)

- LETTH(0.25) ~ 100 MeV-cm2/mg

- SEL Immune >128 MeV-cm2/mg

- Saturated Cross Section cm2 per bit, 1.0E-11

- 1.2E-8 errors/device-day, Adams 90% geosynchronous
heavy ion

- Memory cell LET threshold: >128 MeV-cm2/mg

q QML Q & V compliant part

- AC and DC testing at factory

q Packaging options:

- 28-lead 50-mil center flatpack (0.490 x 0.74)

- 28-lead 100-mil center DIP (0.600 x 1.4) - contact factory

q VDD: 3.0Vto 3.6V
q Standard Microcircuit Drawing 5962-01517

PRODUCT DESCRIPTION

The UT28F256LV amorphous silicon anti-fuse PROM is a high
performance, asynchronous, radiation-hardened, 32K x 8
programmable memory device. The UT28F256LV PROM
features fully asychronous operation requiring no external clocks
or timing strobes. An advanced radiation-hardened twin-well
CMOS process technology is used to implement the
UT28F256LV. The combination of radiation-hardness, fast
access time, and low power consumption make the UT28F256LV
ideal for high speed systems designed for operation in radiation
environments.

DECODER

MEMORY

ARRAY

SENSE AMPLIFIER

PROGRAMMING

CONTROL

LOGIC

DQ(7:0)

A(14:0)

CE

PE

OE

Figure 1. PROM Block Diagram

2

3

DEVICE OPERATION

The UT28F256LV has three control inputs: Chip Enable (CE),
Program Enable (PE), and Output Enable (OE); fifteen address
inputs, A(14:0); and eight bidirectional data lines, DQ(7:0). CE
is the device enable input that controls chip selection, active, and
standby modes. Asserting CE causes IDD to rise to its active value

and decodes the fifteen address inputs to select one of 32,768
words in the memory. PE controls program and read operations.
During a read cycle, OE must be asserted to enable the outputs.

PIN NAMES

Table 1. Device Operation Truth Table

1

Notes:

1. “X” is defined as a “don’t care” condition.

2. Device active; outputs disabled.

ABSOLUTE MAXIMUM RATINGS

1

(Referenced to VSS)

Notes:

1. Stresses outside the listed absolute maximum ratings may cause permanent damage to the device. This is a stress rating only, and functional operation of the

device at these or any other conditions beyond limits indicated in the operational sections of this specification is not recommended. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

2. Test per MIL-STD-883, Method 1012, infinite heat sink.

A14

A12

A7
A6

A5
A4
A3
A2
A1

A0

DQ0
DQ1

DQ2

V

SS

V

DD

PE
A13
A8
A9

A11
OE
A10
CE
DQ7
DQ6

DQ5
DQ4

DQ3

PIN CONFIGURATION

1
2
3
4
5
6
7
8
9
10
11
12
13
14

28
27
26
25
24
23
22
21
20
19
18
17
16
15

A(14:0) Address

CE Chip Enable
OE Output Enable

PE Program Enable

DQ(7:0) Data Input/Data Output

OE PE CE I/O MODE MODE

X 1 1 Three-state Standby

0 1 0 Data Out Read
1 0 0 Data In Program
1 1 0 Three-state

Read

2

SYMBOL PARAMETER LIMITS UNITS

V

DD

DC supply voltage -0.3 to 7.0 V

V

I/O

Voltage on any pin -0.5 to (V

DD

+ 0.5) V

T

STG

Storage temperature -65 to +150 °C

P

D

Maximum power dissipation 1.5 W

T

J

Maximum junction temperature +175 °C

Θ

JC Thermal resistance, junction-to-case

2

3.3 °C/W

I

I

DC input current

±10

mA

4

RECOMMENDED OPERATING CONDITIONS

DC ELECTRICAL CHARACTERISTICS (Pre/Post-Radiation)*

(VDD = 3.0V to 3.6V; -55°C < TC < +125°C)

Notes:

* Post-radiation performance guaranteed at 25°C per MIL-STD-883 Method 1019 at 1E6 rad(Si).

1. Measured only for initial qualification, and after process or design changes that could affect input/output capacitance.

2. Supplied as a design limit but not guaranteed or tested.

3. Not more than one output may be shorted at a time for maximum duration of one second.

4. Functional test.

5. Derates at 1.5mA/MHz.

SYMBOL PARAMETER LIMITS UNITS

V

DD

Positive supply voltage 3.0 to 3.6 V

T

C

Case temperature range -55 to +125 °C

V

IN

DC input voltage 0 to V

DD

V

SYMBOL PARAMETER CONDITION MINIMUM MAXIMUM UNIT

V

IH

High-level input voltage 0.7V

DD

V

V

IL

Low-level input voltage 0.25V

DD

V

V

OL1

Low-level output voltage IOL = 100µA, V

DD

= 3.0V V

SS

+ 0.05 V

V

OL2

Low-level output voltage IOL = 1.0mA, VDD = 3.0V V

SS

+ 0.10 V

V

OH1

High-level output voltage IOH = -100µA, VDD = 3.0V VDD-0.15 V

V

OH2

High-level output voltage IOH = -1.0mA, VDD = 3.0V VDD-0.3 V

C

IN

1

Input capacitance ƒ = 1MHz, VDD = 3.3V

V

IN

= 0V

15 pF

C

IO

1, 4

Bidirectional I/O capacitance ƒ = 1MHz, VDD = 3.3V

V

OUT

= 0V

15 pF

I

IN

Input leakage current VIN = 0V to V

DD

-3 3 µA

I

OZ

Three-state output leakage
current

VO = 0V to VDD
VDD = 3.6V
OE = 3.6V

-8 8 µA

I

OS

2,3

Short-circuit output current VDD = 3.6V, VO = V

DD

VDD = 3.6V, VO = 0V

-90

90 mA

mA

I

DD1

(OP)

5

Supply current operating
@15.4MHz (65ns product)

CMOS input levels (I

OUT

= 0), V

IL

=

0.2V
VDD, PE = 3.6V, VIH = 3.0V

50.0 mA

I

DD2

(SB)

post-rad

Supply current standby CMOS input levels VIL = VSS +0.25V

CE = V

DD

- 0.25 V

IH

= VDD - 0.25V

1.0 mA
