The Blue Evolution’s Extraction feature
allows the user to clean with hot water.
Extraction increases cleaning
performance, and when used with the
Vacuum, leaves a relatively dry surface.
Ø Activate the Extraction by pushing
the button on the hose handle.
Ø Turn ON the Va cu u m by pushing
vacuum symbol on the hose
handle.
Ø The symbol will illuminate on
the display while the Blue Evolution
is in Extraction mode.
Ø You w il l he ar t he p ump w he n
activated.
Ø Extraction spray can be increased or
decreased in 10% increments by
pushing button on the console.
Ø Default Setting: 60%
Ø 010 - Lowest Setting minimum
amount of water
Ø 100 - Highest Setting Maximum
amount of water
Ø To t urn OFF the Extraction and
return to Steam only, push the
button on the hose handle.
Va cu u m
Extraction
Extraction Shut Down
After Each Use:
It is important to clean accessories and
brushes.
Ø Run the vacuum for 30 seconds to
remove any water from the hose.
Ø Use hot soapy and water to clean
brushes and nozzles.
Ø Empty and use hot soapy water to
clean the collection tank and
remove all debris.
Ø If using the Blue Evolution on an
extremely dirty or greasy surface,
clean hose after use by activating
the vacuum mode and suck water
through the hose on low suction.
Ø If working in a healthcare
environment, the hose can be
cleaned with a disinfection
solutions.
Every 3 Months
Ø Check Boiler cap and descale (see
Page 13).
Ø Descale the reservoir tanks and
boiler. (see page 12).
Ø Check HEPA filter clean or replace.
(see page 10).
Ø Check O-Rings on hose and
extension wands. If damaged,
replace.
Every Year
Ø Replace HEPA filter
Ø Change the O-Rings on the hose
and extension wands (page 10)
6
