US Motors 1694 Dimensional Sheet

K55HXPUG-1680

REF

C37130

CUSTOMER

WHOLESALE-HAC

HPMODEL CATALOG NO.

1/2 605.5

VOLTS

115

AMPS

HZ

RPM

1625/3 SPD

ROTATION

CCW LEAD END REV

1694

DESCRIPTION / REMARKS

(4) .250 FLAG TERMINAL

REVERSING LEADS
2 PUR,
2 ORG

4.000

+2.000

-0.000

2 LEADS, #18, .031 THICK
INSUL WITH .250 Q.C. FLAG TERMS
(2) BROWN = 36.000u1.500

NIDEC MOTOR CORPORATION 23-May-17

NIDEC MOTOR CORPORATION 23-May-17

CREATED DRAWING.

ISSUED BY :

ISSUED BY :

G. MEDINA

REVISION RECORD FOR:

REVISION RECORD FOR:

AUTOMATIC THERMAL
PROTECTOR

90°

3.625

90°

4 LEADS #18, .031 THICK INSUL
TO EXTEND BEYOND MOTOR
RED=36.000u1.500, BLK=36.000u1.500
BLU=36.000u1.500, WHT=36.000u1.500

NOTE:

-KIT - 2 1/2" RING CONVERSION
SHIPPED IN CARTON

E28700

ENGINEER APPROVED :

ENGINEER APPROVED :

H. NAVARRO

6.400 ±.062

WARNING LABEL
OPPOSITE SIDE

TOP

3.625

NAMEPLATE

5.918

#16 GREEN GROUND LEAD TO BE

12.000u.250 BETWEEN CENTERS
OF TERMS. TERM TO FIT #10 SCREW

COLOR CODE

WHITE-COMMON

BLACK-HIGH

BLUE-MEDIUM

RED-LOW

BRONW-CAPACITOR

DIMENSIONS ARE FOR

REFERENCE ONLY

INFORMATION DISCLOSED ON THIS DOCUMENT IS CONSIDERED PROPRIETARY AND SHALL NOT BE

REPRODUCED OR DISCLOSEDWITHOUT WRITTEN CONSENT OF NIDEC MOTOR CORPORATION

UNLESS TOLERANCE

IS SPECIFIED

CUSTOMER DETAIL DRAWING

11.400 ±.062

TOP

5.545 u.047

4.000

.438

.4995

.453

.5000

8-32 UNC
THREAD

1.500 u.062

MALE

FEMALE

R
U

AUX.

ORG

ORG

M1

PROT

WHT

PUR

P

M2 M3

CK

BLA

NIDEC MOTOR CORPORATION

TITLE

TITLE

CODE ITEM NO.

CODE ITEM NO.

V02

V02

5.625

5.125 DIA. B.C.

45°

45°

CONNECTION SHOWN IS
FOR C.CW. LE ROTATION
TO REVERSE ROTATION,
INTERCHANGE ORANGE
AND PURPLE LEADS.

BRN

N

N

R

R

B

B

BLUE

RED

CAP

REFER TO S.E.I.M. 24-1

REFER TO S.E.I.M. 24-1

REVISION DATE :

REVISION DATE :

REV

REV

815744

-

23-MAY-17

SHEET

SHEET

NUMBER

NUMBER

OF

OF

1 3

DWG

DWG

SIZE

SIZE

B

B
