U-STAGE
70 mm
58 mm
Super High-Pressure Discharge Lamps for Moving Stage Lights
U-stage lamps from USHIO are a series of super high-pressure discharge lamps
pre-aligned into a reflector to deliver a high luminosity and a highly reliable light source.
This optimized compact design makes the U-stage lamps the ideal light source for
high-performance moving stage lights.
As a leader in projector lamp technology, USHIO has a long history of developing short-arc
discharge lamp targeting longer life, higher brightness and higher efficiency.
FEATURES & BENEFITS:
• High Pressure Short Arc Lamps
• High Lumen Output
• Long Life
• High Color Temperature - 8000K
APPLICATIONS:
• Moving Lights
• Stage
• Concert
• Night Clubs
• Available in 132W, 189W
Case Quantity: 1
Arc Color Lumen Working Average
Watts
(W)
132 5002463 NSL-132 (2R) 69 45 0.8 8000 5150 37.7 Any 6000
189 5002464 NSL-189 (5R) 75 56 0.9 8000 8000 34.5 Any 2000
Ordering
Code
Lamp
Description
U-STAGE
45 mm
Volts
(V)
MOL
(mm)
Gap
(mm)
56 mm
Temp
(K)
Output
(lm)
All dimensions shown in millimeters unless otherwise noted.
Distance
(mm)
Burn
Position
Rated
Life (h)
46 mm
NSL-132 NSL-189
Form No. S-USTAGE/1016
Specifications may be subject to change without prior notice. Refer to www.ushio.com for the most current product specifications.
51 mm
