Tip Sheet
mounting
track
GEOMETRIX
panels
Celebration™ and
™
Geometrix
Wall Mount Solution
CELEBRATION™ and GEOMETRIX™ metal ceiling panels may be installed vertically
Panels
on walls using a system of purpose-made mounting tracks, installation
clips and perimeter trim.
Assembly Overview
Design note: Because CELEBRATION and
G
EOMETRIX panels were designed for
ceiling applications and not to withstand
See pp. 4-5 for complete assembly details for G
impacts from foot traffic, rolling carts and
other incidental contact, USG strongly
recommends that panels be installed
above or away from floor activity.
EOMETRIX panels.
Celebration
System Panel CELEBRATION
Components
Mounting Hardware 48
for fastener (by others)
Perimeter Trim 98
(field-cut as needed)
Basketweave Track 24 Perimeter Track Resilient Washer,
Lengths
Colors Perimeter trim available standard in Flat White and Silver Satin. Additional colors available upon request.
2
Field Assembly
48" basketweave track
intersecting 48"
basketweave track or
24" perimeter track
CELEBRATION
panel
CELEBRATION panel
wall track
resilient washer
drywall anchor
by others
3
/4" approx.
distance from wall
48" basketweave track
intersecting 48"
basketweave track or
24" perimeter track
CELEBRATION
perimeter trim
C
ELEBRATION
panel
CELEBRATION
perimeter trim
CELEBRATION panel
wall track
resilient washer
drywall anchor
by others
3
/4" approx.
distance from wall
Perimeter Assembly
3
Geometrix
System Panels GEOMETRIX
Components
Mounting Hardware 48
for fastener (by others)
Perimeter Trim 9/16
Installation Clip 9/16
Batten 9/16
(98 lengths;
field-cut as needed)
24 notched and butt-cut,
98 field-cut for length
Basketweave Track 24 Perimeter Track Resilient Washer,
GEOMETRIX Panel 15/16 GEOMETRIX Panel
Panels 15/16 Panels
Panels 15/16 Panels
Colors Perimeter trim and battens available standard in Flat White and Silver Satin. Additional colors available
upon request.
4
Field Assembly
48" basketweave track
intersecting 48"
basketweave track or
24" perimeter track
installation clip
batten
GEOMETRIX panel
31/2" approx.
distance from wall
21/2" approx.
distance from wall
11/2" approx.
distance from wall
1" panel
2" panel
3" panel
adapter clip
resilient washer
drywall anchor
by others
wall track
48" basketweave track
installation clip
perimeter
trim
batten
GEOMETRIX panel
intersecting 48"
basketweave track or
24" perimeter track
G
EOMETRIX
perimeter trim
adapter clip
GEOMETRIX panel
wall track
resilient washer
drywall anchor
by others
7
/8"
approx.
distance
from wall
Perimeter Assembly
5
Geometrix
mounting track
GEOMETRIX
installation clip
mounting track
G
EOMETRIX
installation clip
Corner and Edge To install GEOMETRIX panels at corners and edges of an assembly, cut an installation clip through the center
Assemblies to remove one or two “legs.”
Corners
Edges
6
Acoustical Performance
wall
wall panel
Wall-mounted C
ELEBRATION
and G
EOMETRIX
panels, with perforation and A
COUSTIBOND
®
backer, can provide significant
sound absorption (NRC). The following table shows the estimated NRC of a wall-mounted assembly for each
shape and depth of G
G
EOMETRIX
Flat panels).
EOMETRIX
panel (C
ELEBRATION
panels provide the same acoustical performance as 5/16
Note that changing the orientation of individual panels within an assembly to create patterns does not affect
the sound absorption.
Perforation Pattern
C062 C062A C375 D250 D375
2% 9% 10% 11% 11%
Sound Absorption – Wall-Mounted Assembly G
Flat 3 0.65 0.80 0.85 0.85 0.85
2
1
5/16
(C
equivalent performance)
Wedge 3
2
1
Inside Corner Wedge 3
2
1
Outside Corner Wedge 3
2
1
EOMETRIX
Panel Size Estimated NRC
0.50 0.55 0.65 0.65 0.65
0.30 0.30 0.40 0.40 0.40
0.20 0.20 0.20 0.20 0.20
ELEBRATION
panels provide
0.55 0.60 0.65 0.65 0.65
0.50 0.50 0.50 0.50 0.50
0.40 0.40 0.40 0.40 0.40
0.55 0.65 0.70 0.70 0.70
0.50 0.55 0.60 0.60 0.60
0.45 0.45 0.45 0.45 0.45
0.50 0.55 0.60 0.65 0.65
0.40 0.45 0.50 0.50 0.50
0.35 0.35 0.35 0.35 0.35
Open Area
NRC estimated based on testing per ASTM C423, Standard Test Method for Sound Absorption and Sound
Absorption Coefficients by the Reverberation Room Method.
Panels affixed with Type A mount per ASTM E795, Standard Practices for Mounting Test Specimens During
Sound Absorption Tests.
7
Limitations
Wall Flatness As detailed, the wall should be flat, within about 1/2; any out-of-flat condition will be noticeable along
the bottom edge of perimeter trim. With shimming and framing, the wall could be almost any condition,
so long as the perimeter appearance can be made subjectively acceptable.
Wall Applications The systems described here are for wall applications only. CELEBRATION and GEOMETRIX panels should
not be installed as a ceiling using wall-mount hardware. Ceiling applications require an approved D
ONN
®
brand suspension system.
Interior Use Only Wall-mounted system desinged for interior applications only.
Impact Protection Because CELEBRATION and GEOMETRIX panels were designed for ceiling applications and not to withstand impacts
from foot traffic, rolling carts and other incidental contact, USG strongly recommends that panels be installed
above or away from floor activity.
Note
All products described here
may not be available in all
geographic markets and are
subject to change without
notice. Consult your local
sales office or representative
for information.
Manufactured by
USG Interiors, Inc.
550 West Adams Street
Chicago, IL 60661
Trademarks
The following are trademarks
of USG Interiors, Inc. or a
related company: A
ELEBRATION, DONN, GEOMETRIX.
C
800 USG-4YOU (874.4968)
www.usg.com
COUSTIBOND,
Notice
We shall not be liable for
incidental or consequential
damages, directly or indirectly
sustained, nor for any loss
caused by application of these
goods not in accordance with
current printed instruction or
for other than intended use.
Our liability is expressly limited
to replacement of defective
goods. Any claim shall be
deemed waived unless made in
writing to us within thirty (30)
days from the date it was or
reasonably should have been
discovered.
Safety First!
Follow good safety and
industrial hygiene practices
during handling and installation
of all products and systems.
Take necessary precautions
and wear appropriate personal
protective equipment as
needed. Read material safety
data sheets and related
literature on products before
specification and/or installation.
