US Electronics NOVARI User Manual

VISIT US ON THE WEB
You can find programming instructions
and codes for all of our remote
controls, as well as information about
our other products on our website:
www.uselectronics.com
User’s Guide for the
for Scientific-Atlanta
®
Explorer 2000 & 3000 Converters
© 2003 US Electronics, LLC.
All rights reserved
Part Number USE18220 , version 2.0
01282003
Make sure to set your TV to channel 2, 3, or 4 as directed by your cable company.
This manual makes reference to “device keys.” These are the CBL, TV, VCR, DVD, and AUD keys at the top of the remote control.
After you have programmed the remote, you’ll use the device keys to select which device you want the remote control to operate.
BEFORE YOU BEGIN
1
2
!
Weak batteries may disrupt
normal operation of the remote.
We recommend that you use
only new Alkaline AA batteries.
Before you can program or operate the remote control, you must install two Alkaline AA batteries.
Step 1:
Remove the battery compartment cover on the back of your remote control.
Step 2:
Check battery polarity carefully, and install the batteries as shown in the illustration below.
Step 3:
Replace the battery compartment cover.
INSTALL BATTERIES
IMPORTANT NOTE
3
KNOW YOUR REMOTE
NUMBER KEYS allow
direct access to specific
channels and menu options
CH changes the channel up and down
DEVICE KEYS allow you to select which device your remote will operate. They are also used to set up the remote control
SELECT chooses the
highlighted item in the menu
VOL turns the
volume up and down
GUIDE displays the program guide
TV/VCR switches the
VCR between TV and VCR
123
456
7
89
0
ABC
TV VCR DVD AUD
SELECT
#
LAST
MUTE
VOL CH
INFO
GUIDE
P A G E
PPV
REW FF
PLAY
REC PAUSE
STOP
FAV EXIT
POWER
CBL
B
Y
P
A
S
S
The Scientific-Atlanta® Explorer set-top box has an on-screen program guide that can be sorted several different ways: A browse by title, channel, or theme
B browse by date C browse by current time
FAV steps through
favorite channels
INFO displays channel and
program information
EXIT exits out of
on-screen menus
LAST recalls the last channel that was viewed
MUTE
turns volume on/off
SETTINGS/MENU displays
current set-top box settings
POWER is used in conjunction
with the device keys to turn
devices on and off
Consult your set-top box manual for more information on the on-screen guide
When operating Tivo, A and C perform the skip forward and back functions.
TV/VCR
MENU
CHANNEL SURF: Press and hold the SELECT button for 3 seconds. The remote will automatically send 25 channel up/down signals (depending on which channel button was used last) in half-second intervals. If you see a channel that you want to watch, press any button on the remote to stop channel surfing.
FOUR-WAY CURSOR KEYS
allow you to navigate through
the on-screen menus. When the AUD key is selected, the
left and right arrow keys allow
you to tune stations on your
audio tuner/amplifier.
PAGE moves the menu forward and backward on page. When the DVD key is selected, the up and down keys perform skip forward and backward functions.
VCR KEYS perform standard
VCR functions when the VCR or
TV keys are selected, and DVD functions when the DVD key is
selected. If your cable provider
offers Video-on-Demand (VOD)
they operate VOD functions when
BYPASS functions differently
depending on what mode the
remote control is in:
• While in VCR mode, switches TV/VCR input
• While in TV mode, switches TV/Video input
• While in CBL mode, controls Bypass function
# functions as an ENTER key on devices that require ENTER to be Pressed after inputting a channel with the number keys.
The diagram below shows the functions of special keys for your set-top box and pro-
gram guide. US Electronics provides these function descriptions as a general guide
to allow you to become more familiar with your set-top box. Refer to your
set-top box manual for descriptions of specific functions.
On the remote control, press and hold the appropriate device key until the five device keys flash twice. The selected device key will continue to flash.
Enter the three-digit code.
After you press the first digit, the device key should light and stay on. After you press the last digit, the device key should flash three times and turn off.
If the device key does not flash three times before turning off, the code is invalid for this device type. Repeat the procedure with another device code.
Point the remote at the device and press POWER. If the device turns on or off, you have finished programming.
If you have tried all the codes listed for the manufacturer and the device does not respond, refer to the CodeScan
section later in this manual.
Write the codes below
Set-top Box code ___ ___ ___ TV code ___ ___ ___
VCR code ___ ___ ___ DVD Code ___ ___ ___ Audio code ___ ___ ___
1
By default, the TV, CBL, or AUD keys will send their own volume and mute signals to their device. If you would like to set up the Novari so that volume is always controlled by a particular device (set-top box, TV, or audio amplifier), follow these steps:
NOTE: volume will always be controlled byyour audio device when the remote control is in AUD mode — regardless of how you set up volume controlin this section.
Press and hold the CBL key for 3 seconds. The CBLkey will continue to flash.
Press CHANNEL UP; press CHANNEL DOWN; then press SELECT. The CBL Key will blink three times to confirm the procedure.
Repeat these steps to re-activate Channel Lock.
Channel Lock prevents the channel up and down functions from operating any device other than the set-top box — no matter which device (TV, CABLE, VCR, DVD, AUDIO) is currently selected.
The Novari comes with Channel Lock activated. If you want the remote control to operate channel functions on your TV or VCR you will need to de-activate Channel Lock. To de­activate Channel Lock, follow these steps:
0 2 5
Make sure all devices to be controlled are turned on. Press and hold the CBL key for approximately three seconds until all five
device keys flash twice. The CBL key will continue to flash. Press POWER twice. The CBL key will flash three times and turn off.
You can program your Novari to turn on and off all of your remote-controlled devices (TV, CABLE, VCR, DVD, AUDIO) when you press POWER. All devices must be in direct line of sight to ensure proper operation. Perform the following steps to enable or disable power controlfor each device:
Manually turn on power to the device for which you want to program the remote (TV, VCR, DVD, AUDIO).
Press and hold the appropriate device key for approximately three seconds until the five device keys flash twice. The selected device key will continue to flash. Pres s POWER. The device key will stop flashing and remain on.
Point the remote control at the device. Press and hold the UP ARROW key. Approximately once every second, the remote sends the power-off command using a different device code. When the device turns off, that means that the remote has reached a code that can control the device. Immediately release the UP ARROW key when the device turns off. If you accidentally press the UP ARROWkey after the device has turned off, press the DOWN ARROW key to return to the previous device code.
Test whether other functions operate using the remote control. If a primary function does not work, continue to press the UP ARROW keyto find another code that turns off the device. Then test the functions again. When you are satisfied that all primary functions are working, press SELECT to lockin the code.
If none of the codes listed for your device works, the SmartScan™procedure will allow you to cycle through all the available codes in the remote until you find the right one.
Press and hold a device key until the five device keys flash twice. The selected device key will continue to flash.
Press INFO. The device key flashes each of the three digits in the code. A pause separates each digit. For example, three flashes represent the number 3, and a rapid flicker represents 0, so a code of 103 will be shown as: FLASH <pause> FLICKER <pause> FLASH FLASH FLASH
Count and record the sequence of flashesto determine the three-digit code.
Perform the following steps to read the code currently set for a device. This is useful for retrieving a device code that was set using the CodeScan
procedure.
The Up Arrow Key
4
SETTING UP YOUR REMOTE
7
CHANNEL LOCK
8
SmartScan
9
RECALLING A DEVICE CODE
5
PROGRAMMING VOLUME CONTROL
To set up the Novari to operate a device, look for the list of manufacturers’ three-digit codes for the device type in sections 10-16 of this manual (the code for your set-top box is 0 2 5), then perform the following steps.
NOTE:
if you are setting up the remote for a: follow these instructions as if it were a:
TV/VCR Combo . . . . . . . . . . . . . . . . . . . . . . . . . . .VCR
TV/DVD Combo . . . . . . . . . . . . . . . . . . . . . . . . . . .DVD player (pleas e read section 16 before continuing)
Personal Video Recorder . . . . . . . . . . . . . . . . . . .VCR
6
MASTER POWER CONTROL
Press and hold the CBL key for approximately three seconds until the five device keys flash twice. The CBL key will continue to flash.
Press VOLUME UP then VOLUME DOWN then the Device Key (TV, CBL, or AUD) of the device that you want to control volume and mute functions. After you release the Device Key, the CBL keywill blink three times to confirm the procedure.
2
3
4
1
2
1
2
3
1
2
3
4
1
2
1
2
3
AOC 005 • 006 • 019 • 020 • 120 • 140 • 163
173 ASA 047 Admiral 003 • 018 • 034 • 041 • 090 • 125 • 129 Aiko 024 Aiwa 090 Akai 000 • 032 • 070 • 149 • 172 Alaron 034 Amark 120 • 224 • 225 Amstrad 033 Anam 005 • 009 • 021 • 041 • 120 • 121 • 183 Anam National 211 Archer 120 Audiovox 024 • 041 • 120 • 170 Bell & Howell 018 • 090 Broksonic 005 • 144 • 172 • 173 • 174 • 176 CXC 041 Candle 006 • 022 • 023 • 025 • 163 • 213 Capehart 019 Carver 151 Centurion 192 • 194 Citizen 006 • 016 • 018 • 022 • 023 • 024 • 025
026 • 144 • 163 • 202 • 213 • 224 Concerto 005 • 023 • 213 Contec 041 • 091 • 181 • 185 • 227 Corando 224 Coronado 225 Craig 021 • 041 Crown 026 • 041 Curtis Mathes 006 • 016 • 018 • 026 • 059 • 090
125 • 131 • 163 • 172 • 192 • 194 • 202 • 224
Daewoo 005 • 024 • 026 • 029 • 030 • 031 • 032
130 • 170 • 172 • 224 Daytron 026 • 192 • 194 • 224 Denon 169 Dimensia 125
Dumont 001 • 047 Electrohome 026 • 149 • 224 Emerson 017 • 023 • 026 • 028 • 033 • 034 • 035
036 • 037 • 038 • 039 • 041 • 090 • 122 • 141
143 • 144 • 171 • 172 • 176 • 181 • 187 • 203 Envision 163 Fisher 042 • 090 • 099 Fujitsu 034 • 187 Funai 034 • 041 • 132 • 187 Futuretech 041 General Electric 003 • 008 • 009 • 023 • 043 • 044
125 • 130 • 134 • 143 • 165 • 170
172 • 182 • 183 • 195 • 206 • 207 • 211
Goldstar 005 • 023 • 026 • 045 • 046 • 088
168 • 172 • 173 • 194 • 213 • 224 • 225 Gradiente 060 Grundig 047 Hallmark 023 • 172 Hinari 034 • 187 Hitachi 018 • 023 • 026 • 048 • 049 • 050
051 • 052 • 053 • 054 • 055 • 116 • 126
142 • 169 • 172 • 185 • 213 • 224 • 225 Infinity 010 • 066 • 151 JBL 010 • 066 • 151 JC Penney 003 • 005 • 006 • 014 • 016 • 026
043 • 044 • 096 • 125 • 131 • 134 • 149
163 • 165 • 172 • 194 • 202 • 206 • 207 • 224 JVC 057 • 058 • 059 • 060 • 186 KEC 041 KMC 224 • 225 KTV 026 • 039 • 041 • 172 • 224 • 225 Kenwood 006 Kloss 022 • 110 LXI 003 • 010 • 066 • 090 • 117 • 125 • 129
131 • 132 • 134 • 151 • 172 • 173 • 194
Lloytron 224
Lodgenet 018 Logik 018 Luxman 023 • 213 MGA 004 • 005 • 006 • 023 • 034 • 071
072 • 149 • 163 • 172 • 187 • 192 • 194
MTC 005 • 006 • 016 • 023 • 031 • 163
202 • 213 Magnasonic 024 • 034 • 129 • 131 • 151 Magnavox 000 • 006 • 008 • 010 • 017 • 020
025 • 027 • 028 • 034 • 064 • 065 • 066
067 • 068 • 110 • 132 • 144 • 151 • 154 • 163 Majestic 018 Marantz 006 • 010 • 066 • 068 • 088
149 • 151 • 163 • 172 Matsui 032 • 109 Memorex 018 • 032 • 034 • 072 • 090 • 149 • 172 Midland 001 • 003 • 165 Mitsubishi 004 • 005 • 023 • 034 • 070 • 071
072 • 122 • 123 • 129 • 149 • 172
173 • 187 • 192 • 194 Multitech 041 NAD 002 • 117 • 131 • 166 • 172 NEC 005 • 006 • 007 • 023 • 028 • 090 • 144
163 • 172 • 173 • 183 • 191 • 192 • 194 • 213 National 011 • 151 • 195 • 196 • 211 Nikkai 118 Onwa 041 Optimus 012 • 090 • 166 Optonica 129 Orion 176 • 204 Osume 091 Panasonic 008 • 009 • 010 • 011 • 012
066 • 151 • 165 • 177 • 183 • 195 • 196 • 211 Philco 005 • 006 • 025 • 064 • 065 • 067 • 068
110 • 149 • 151 • 163 • 169 • 172
176 • 183 • 224 • 225
Philips 005 • 010 • 025 • 027 • 066 • 068 • 088
146 • 151 • 163 • 164 • 220 • 225 Pioneer 002 • 008 • 048 • 051 • 076 • 131 • 166 Portland 005 • 024 • 026 • 172 • 224 • 225 Proscan 125 • 172 Proton 006 • 013 • 019 • 023 • 026 • 172 • 224 Pulsar 001 Quasar 008 • 009 • 012 • 165 • 183 • 195 • 211 RCA 003 • 005 • 008 • 014 • 048 • 078 • 079
080 • 082 • 084 • 085 • 086 • 087 • 125 130 • 134 • 149 • 172 • 182 • 183 • 210
Radio Shack 003 • 026 • 041 • 072 • 090 • 112
141 • 172 • 173 • 194 • 224 • 229 Realistic 035 • 041 • 090 • 141 • 172 • 194
222 • 224 • 229 Runco 00 1 SSS 005 • 041 Saba 051 • 116 • 142 Saisho 032 • 033 • 109 Sampo 006 • 019 • 163 • 192 • 194 Samsung 005 • 006 • 016 • 023 • 026 • 032
088 • 112 • 163 • 172 • 173 • 192
194 • 202 • 213 • 224 • 225 • 229 Sansui 176 Sanyo 042 • 089 • 090 • 091 • 092 • 109 • 194 Scott 026 • 034 • 037 • 041 • 093 • 172
173 • 187 • 192 • 194 • 204 • 224 Sears 003 • 023 • 034 • 042 • 090 • 096 • 098
099 • 101 • 102 • 104 • 117 • 125 • 131 • 132
134 • 151 • 172 • 187 • 194 • 202 • 224 • 225 Sharp 026 • 091 • 129 • 141 • 200 • 224 • 225 Signature 018 Sony 000 • 109 • 119 • 122 • 189 Soundesign 023 • 025 • 034 • 041 • 172 Spectricon 120 Starlite 041
Supra 022 • 023 Sylvania 006 • 010 • 025 • 064 • 065 • 066
068 • 110 • 112 • 132 • 151 • 163
172 • 173 • 192 • 194 • 229 • 231 Symphonic 132 • 179 TMK 023 • 172 • 213 Tandy 112 • 129 Tatung 009 • 183 • 211 Technics 008 • 012 • 165 Techwood 023 • 165 • 213 Teknika 004 • 005 • 016 • 018 • 022 • 023
024 • 025 • 026 • 034 • 041 • 072 • 114
149 • 151 • 187 • 202 • 213 • 224 • 225 Telerent 018 • 224 Teletech 032 Thomson 051 • 116 • 142 Toshiba 016 • 017 • 047 • 090 • 096
117 • 118 • 131 • 180 • 201 • 202 Totevision 026 • 224 Universal 043 • 044 • 206 • 207 Vector Research 006 Victor 057 • 060 Video Concepts 070 Vidtech 005 • 023 • 172 • 173 Viking 022 Wards 005 • 006 • 018 • 023 • 034 • 043 • 044
064 • 065 • 067 • 068 • 119 • 125 • 141 151 • 163 • 172 • 173 • 182 • 187 • 192
194 • 206 • 207 • 224
Westinghouse 041 • 090 • 130 • 170
171 • 176 • 204 Yamaha 005 • 006 Yorx 192 • 194 Zenith 001 • 018 • 024 • 178 Zonda 120
10
TELEVISION CODES
11
VCR CODES
ASA 065 • 134 Admiral 085 • 178 Aiwa 056 • 088 • 202 Akai 008 • 013 • 014 • 015 • 016 • 019
020 • 068 • 086 • 198 • 210 Alba 046 American High 158 Amstrad 088 Audio Dynamics 030 • 086 • 093 • 210 Audiovox 056 Bell & Howell 049 • 175 • 177 Broksonic 005 • 008 • 059 • 148 • 198 Bush 089 CCE 176 Calix 056 Candle 042 • 056 • 080 • 092 • 093 • 149 Canon 042 • 054 • 158 • 184 Capehart 046 Carver 065 • 136 Cineral 176 Citizen 056 • 091 • 092 • 093 Craig 044 • 056 • 082 • 091 Curtis Mathes 051 • 054 • 088 • 092 • 105
114 • 139 • 149 • 158 • 184 Cybernex 091 DBX 030 • 086 • 093 • 210 Daewoo 034 • 046 • 093 • 150 • 176 • 204 Daytron 046 Denon 173 Dimensia 105 Dual 210 Dumont 049 Dynatech 088 • 161 Electrohome 056 • 068 Electrophonic 056 Emerson 005 • 006 • 008 • 009 • 010 • 011 • 012
056 • 059 • 068 • 070 • 088 • 090 • 132
148 •169 176 • 190 • 192 • 193 • 198
204 • 211 • 212 • 213
Ferguson 210 Finlandia 049 Finlux 049 • 065 • 088 • 134 Fisher 048 • 049 • 081 • 082 • 084 • 175 Fuji 158 Funai 088 General Electric 025 • 033 • 050 • 051 • 052
054 • 091 • 105 • 133 • 139
149 • 158 • 167 • 178 • 184 • 194 Go Video 057 • 058 • 164 • 165 • 186 Goldstar 030 • 033 • 056 • 092 • 102 Goodmans 085 • 089 • 161 Gradiente 061 • 062 • 088 Graetz 210 Granada 049 • 081 Grundig 065 • 134 HQ 034 Harman Kardon 030 • 065 • 069 • 136 Hinari 089 Hitachi 037 • 038 • 040 • 041 • 086 • 088
094 • 095 • 121 • 139 • 173 • 210 ITT 210 Instant Replay 184 JC Penney 030 • 050 • 052 • 054 • 056 • 080
081 • 091 • 092 • 093 • 094 • 114
139 • 149 • 158 • 173 • 175 • 184 JCL 184 JVC 030 • 061 • 062 • 063 • 064 • 081
086 • 092 • 093 • 122 • 123 • 168 • 210 Jensen 013 • 086 • 210 KEC 056
Kenwood 062 • 081 • 086 • 088 • 092 • 093 • 210 Kodak 056 • 158 LXI 056 • 088 • 173 • 175 Lloyd 088 Logik 089 MEI 054 • 158 • 184 MGA 067 • 068 • 070 • 169 • 183 • 211
MGN Technology 091 MTC 080 • 088 • 091 Magnavox 027 • 033 • 034 • 050 • 054 • 065
076 • 085 • 088 • 111 • 130 • 134 • 136
137 • 138 • 139 • 141 • 143 • 158 • 159 • 184 Magnin 091 Marantz 030 • 054 • 065 • 081 • 085 • 092 • 093
102 • 134 • 136 • 158 • 159 • 161 • 184 Marta 056 Matsushita 114 • 158 Memorex 033 • 049 • 054 • 056 • 066 • 081 • 082
085 • 088 • 091 • 114 • 158 • 161 • 178 • 184 Minolta 094 • 173 Mitsubishi 062 • 067 • 068 • 069 • 070 • 071
124 • 125 • 140 • 169 • 178 • 183 • 211 Motorola 158 • 178 Multitech 088 • 089 • 091 • 174 NAD 073 NEC 030 • 031 • 032 • 049 • 062 • 081 • 086
092 • 093 • 102 • 127 • 128 • 160 • 210 National 184 Nikko 056 Noblex 091 Nokia 176 Nordmende 210 Olympus 158 Optimus 049 • 056 • 091 • 114 • 178 Optonica 085 • 130 • 161 Orion 005 • 006 Panasonic 023 • 024 • 026 • 054 • 078 • 098
114 • 129 • 139 • 149 • 170 • 171 • 184 Pentax 037 • 092 • 094 • 173 Philco 054 • 088 • 111 • 134 • 158 • 176 • 184
Philips 054 • 065 • 085 • 088 • 134 • 136
154 • 155 • 158 • 161 • 184 Pilot 056 Pioneer 062 • 073 • 074 • 075 • 076 • 093 Portland 046 • 093 Profitronic 091
Proscan 034 • 065 • 105 • 136 • 173 Pulsar 033 Quartz 081 Quasar 017 • 054 • 078 • 114 • 129
139 • 149 • 158 • 170 • 184
RCA 025 • 026 • 027 • 028 • 034 • 037
051 • 065 • 088 • 091 • 094 • 105 • 136 139 • 147 • 158 • 173 • 178 • 184 • 194
Radio Shack 068 • 081 • 082 • 084 • 085 • 088
091 • 114 • 130 • 161 • 172 • 184 Radix 056 Randex 056 Realistic 049 • 054 • 056 • 080 • 081
082 • 084 • 085 • 088 • 091 • 130
149 • 158 • 161 • 175 • 178 • 184 SBR 065 • 134 STS 173 Saba 210 Saisho 006 • 009 • 212 Salora 067 • 081 • 183 Samsung 015 • 034 • 079 • 080
091 • 165 • 174 • 186 • 204 Sanky 178 Sansui 032 • 062 • 086 • 088 • 093 • 210 Sanyo 044 • 048 • 049 • 081 • 082
083 • 084 • 175 • 176 • 177 Schaub Lorenz 210 Schneider 089 Scott 008 • 009 • 034 • 059 • 070 • 090
169 • 174 • 183 • 198 • 204 • 212 • 213
Sears 048 • 049 • 056 • 081 • 082 • 084
088 • 094 • 158 • 173 • 175 Semp 034 • 080 Sentra 046 Sharp 068 • 085 • 130 • 161 • 178 Shogun 091 Signature 085 • 088
Sony 000 • 001 • 002 • 003
004 • 007 • 017 • 158 • 180 Soundesign 088 Sylvania 050 • 054 • 065 • 067 • 070 • 088
111 • 134 • 136 • 158 • 159 • 169 • 183 • 184 Symphonic 088 TMK 006 • 091 • 190 Tandy 049 • 068 • 081 • 082
084 • 085 • 088 • 161 Tashiko 088 Tatung 086 • 210 Teac 086 • 088 • 210 Technics 114 • 158 Teknika 054 • 056 • 087 • 088 • 158 • 184 Telefunken 210 Thomson 210 Thorn 210 Toshiba 034 • 035 • 067 • 070 • 084
086 • 090 • 169 • 183 • 204 • 210 Totevision 056 • 080 • 091 Unitech 080 • 091 Vector 034 Vector Research 030 • 092 • 093 • 183 Victor 062 Video Concepts 030 • 034 • 068 • 088 • 092 • 093 Videosonic 091 Wards 027 • 033 • 054 • 065 • 068 • 080
082 • 085 • 088 • 089 • 090 • 091 • 130
136 • 143 • 158 • 161 • 173 • 178 • 184 XR-1000 158 Yamaha 030 • 081 • 086 • 088
092 • 093 • 175 • 210
Zenith 033 • 062 • 088
12
DVD CODES
Aiwa 179 Akai 163 Apex Digital 221 Broksonic 110 Denon 014 • 042 • 112 • 185 • 222 • 235 Emerson 100 Ferguson 205 Fisher 027 • 189 Funai 015 General Electric 205 Goldstar 057 • 233 • 234 Harman Kardon 231 Hitachi 181 • 244 JVC 117 • 249 • 250 KLH 187
Kenwood 018 • 053 Konka 105 Magnavox 008 • 020 • 021 • 215 Mitsubishi 008 • 009 • 020 • 232 NAD 020 • 224 Nordmende 205 Onkyo 008 • 225 Panasonic 003 • 027 • 031 • 042 • 185 • 188 Philips 008 • 021 Pioneer 010 • 020 • 188 Proceed 228 Proscan 205 Quasar 027 RCA 036 • 038 • 205 Radio Shack 015
Admiral 185 Aiwa 020 • 033 • 102 • 103 • 104 • 149 • 150
151 • 152 • 173 Akai 075 • 119 Bose 020 • 211 Carver 022 • 083 • 091 • 093 • 147 Casio 021 • 170 Cinema Sound 036 Citation 052 • 212 Curtis Mathes 021 Denon 036 • 106 • 107 • 108 • 109 • 110 Fisher 083 • 087 • 147 • 158 Garrard 075 Harman Kardon 052 • 113 • 160 • 212 Hitach 110 JBL 078 • 161 JC Penney 021 • 170 JVC 041 • 043 • 044 • 079 Jensen 114 • 206
Kenwood 058 • 083 • 087 • 135 • 162 • 214 LXI 021 Lloyds 170 MCS 021 Magnavox 028 • 119 • 170 • 210 Marantz 015 • 074 • 081 • 086 • 091 • 093
099 • 120 • 171 Memorex 151 Mitsubishi 045 • 082 Modulaire 170 NAD 099 Nakamichi 074 • 084 • 157 • 217 Onkyo 061 • 070 • 071 • 085 • 096 • 124
218 • 219 Optimus 037 • 075 • 175 • 176 Panasonic 038 • 126 • 177 • 220 Parasound 178 Philips 015 • 086 • 093 • 181
14
PERSONAL VIDEO RECORDER CODES
Panasonic 145 ReplayTV 142 • 145
Runco 20 7 Saba 205 Samsung 008 • 109 • 208 • 209 Sharp 053 • 197 Sherwood 246 Shinco 240 Sony 000 • 012 • 025 • 048 • 247 Sylvania 100 • 215 Technics 003 • 027 • 031 • 185 Theta Digital 021 Thomson 201 • 205 Toshiba 008 • 020 • 053 • 111 Yamaha 042 • 054 • 055 • 185 • 214 Zenith 008 • 057 • 203 • 233 • 234
Pioneer 023 • 062 • 088 • 187 • 221 RCA 053 • 063 • 089 • 119
129 • 130 • 131 • 158 • 184 • 222 Realistic 018 • 072 • 170 • 185 Rotel 019 • 233 • 234 Sansui 015 • 016 • 063 • 074 • 133 • 223 • 224 Sanyo 083 • 147 Sears 021 Sharp 106 • 135 • 239 Sony 000 • 001 • 002 • 003 • 004 • 005 • 006 Sound Stream 027 • 030 Teac 058 • 074 • 075 • 090 • 223 • 225 • 226 Technics 056 • 057 • 126 • 177 • 199 • 200 Vector Research 171 • 202 Wards 083 Yamaha 053 • 060 • 145 • 180 • 203 • 204 • 227 Yorx 170 Zenith 205 • 206 • 228
ShowStopper 145 TIVO 135 • 144 • 146
Aiwa 251 Audio Dynamics 238 Broksonic 219 • 226 Curtis Mathes 231 • 241 DBX 238 Daewoo 247 • 250 • 252 Electrohome 240 Emerson 219 • 223 • 226 • 251 • 253 Funai 251 General Electric 231 • 233 • 241 • 248 Goldstar 223 • 230 • 238 • 254 Harman Kardon 238 Hitachi 231 • 241 • 251 JC Penney 223 • 231 • 238 • 241 • 242 JVC 234 • 235 • 238 Kenwood 235 • 251 LXI 223 • 251 • 254 MGA 240 Magnavox 231 • 236 • 237 • 241 • 251
15
TV/VCR COMBO CODES
Marantz 237 • 238 Marta 223 Memorex 223 • 242 • 244 • 245 • 248 • 251 Mitsubishi 239 • 240 Optimus 242 Orion 219 • 226 Panasonic 231 • 241 • 242 Philco 236 • 237 • 251 Philips 223 • 236 • 237 • 251 Pioneer 235 Proscan 233 Pulsar 248 Quasar 231 • 241 • 242 RCA 231 • 233 • 241 • 251 Radio Shack 230 • 242 Realistic 223 • 251 Runco 24 3 Samsung 221 • 244 • 245 • 246 • 247 Sansui 219 • 235
Sanyo 244 • 245 Scott 247 Sears 223 Signature 251 Sony 232 Soundesign 251 Sylvania 237 • 240 • 251 Symphonic 251 Tandy 251 Teac 251 Technics 242 Teknika 223 • 251 Toshiba 240 • 247 Totevision 223 Vector Research 238 Victor 235 Video Concepts 238 • 251 Wards 251 Yamaha 238 • 251 Zenith 219 • 223 • 235 • 248 • 249 • 251
SA Novari manual• version 2.0 • page 2
US Electronics™and SmartScan™are trademarks of US Electronics, LLC. All other trademarks are the propertyof their respective owners.
17
Problem I programmed the remote, but it won’t work my TV, VCR, DVD player, or set-to p box.
Solution You may have entered the wrong code (or the correctcode might not be listed). Try the CodeScan procedure in section 8. It will allow you to cycle through all the codes until you find one that works.
Weak batteries may cause the remote to only operate one device or operate intermittently. Replace weak batteries with NEW alkaline batteries. Since your remote control has Memory Lock™, you won’t need to reprogram it after the batteries are replaced. If you are sure the batteries are good, try rolling them with your finger (while they are in the remote control) to ensure a good connection.
Finally, make sure that nothing is blocking the signal from the remote control from reaching your TV, VCR, or set-top box; and make sure that you are pointing the remote control at the correct device when you are pressing a key on the remote.
Problem I don’t get any picture and/or sound from my TV.
Solution Make sure all cables are connected properly and that all devices are powered on. Consult related owners manuals for specific installation and operation instructions for each device.
Problem The channel keys only operate myset-top box.
Solution Make sure that Channel Lock isn't engaged. Follow the steps in section 7 to disengage Channel Lock.
Problem The Video-on-Demand keys don’t work.
Solution Press the CBL key when you want the VCR/VOD keys to operate Video-on­Demand (VOD) functions. Press the TV or VCR keys when you want them to operate your VCR.
TROUBLESHOOTING
16
TV/DVD COMBO CODES
NOTE: Emerson and Sylvania TV/DVD combos require that the TVand DVD sections of the unit be programmed separately. If you own one of these models, note that there are two codes listed below. You will need to program the remote control for the TV and DVD sections of the device by using the two codes below and by following the instructions in section 4.
Broksonic 110 Emerson TV=230 DVD=100
Konka 105
Samsung 109 Sylvania TV=231 DVD=100 Toshiba 111
?
!
?
!
?
!
?
!
13
AUDIO AMPLIFIER CODES
Loading...
