Uponor SMATR2 User Manual
Climate Control Zoning System II
instruction sheet
A3800165
A3801160
A3801165
A3800167
Contents
Overview .........................................3
Safety symbols ...................................3
Safety measures ..................................3
Power ...........................................3
Technical constraints ...............................3
Limitations for radio transmission .....................3
Compliance ......................................3
Proper disposal ...................................3
Installation
System components ...............................4
System example ..................................4
........................................4
Foreword
Uponor has prepared this document and all the content
included solely for information purposes. The contents of this
document (including graphics, logos, icons, text, and images)
are copyrighted and protected by worldwide copyright laws
and treaty provisions. Modication or use of any of the
contents of the document for any other purpose is a violation
of Uponor's copyright, trademark and other proprietary rights.
The presumption for the document is all safety measures have
been fully complied with and, further, that the Climate Control
Zoning System II, including any components that are part of
such system, covered by the manual:
• Is selected, planned and installed and put into operation by
a licensed and trained installer in compliance with current
(at the time of installation) installation instructions provided by
Uponor as well as in compliance with all applicable building
and plumbing codes and other requirements and guidelines;
• Has not been (temporarily or continuously) exposed to
temperatures, pressure and/or voltages that exceed the
limits printed on the products or stated in any instructions
supplied by Uponor;
• Remain in its originally installed condition and is not
repaired, replaced or interfered with, without prior written
consent of Uponor;
• Is connected to potable-water supplies or compatible
plumbing, heating and/or cooling products approved or
specied by Uponor;
• Is not connected to or used with non-Uponor products,
parts or components except for those approved or
specied by Uponor; and
• Does not show evidence of tampering, mishandling, insufcient
maintenance, improper storage, neglect or accidental damage
before installation and being put into operation.
Wiring diagram ....................................5
Thermostat operating instructions .....................5
System setup .....................................5
Register thermostat and/or system device to a controller. . .7
Enter registration mode ...........................9
Exit registration mode ............................9
Unregister one channel .............................9
Unregister all channels .............................9
Actuator autobalancing .............................9
Technical data
While Uponor has made efforts to ensure the document is
accurate, Uponor does not guarantee or warrant the accuracy
of the information contained herein. Uponor reserves the right
to modify the specications and features described herein, or
discontinue manufacture of the Climate Control Zoning System
II described at any time without prior notice or obligation. The
manual is provided "as is" without warranties of any kind, either
expressed or implied. The information should be independently
veried before using it in any manner.
To the fullest extent permissible, Uponor disclaims all
warranties, expressed or implied, including, but not limited
to, the implied warranties of merchantability, tness for
particular purpose and non-infringement.
This disclaimer applies to, but is not limited to, the accuracy,
reliability or correctness of the manual.
Under no circumstances shall Uponor be liable for any
indirect, special, incidental or consequential damages
or loss that result from the use of or the inability to use
the materials or information in the manual, or any claim
attributable to errors, omission or other inaccuracies in
the manual, even if Uponor has been advised of the
possibility of such damages.
This disclaimer and any provisions in this document do not
limit any statutory rights of consumers.
.....................................10
2 | uponorpro.com
Overview
This instruction sheet is intended for experienced installers.
Uponor strongly recommends reading the full installation
and operation manual before installing the control system.
Safety symbols
The following symbols are used in this document to indicate
special precautions when installing and operating any
Uponor equipment.
Warning! Ignoring warnings can cause injury or
damage to components.
Caution! Ignoring cautions can cause
equipment malfunctions.
Safety measures
Conform to the following measures when installing and
operating any Uponor equipment.
• Read and follow all instructions in this document.
• Ensure a trained installer performs all work in accordance
with local regulations.
• Do not make changes or modications not specied
in this document.
• Switch off all power supply before starting any wiring work.
• Do not use water to clean Uponor components.
• Do not expose Uponor components to ammable
vapors or gases.
Uponor cannot accept any responsibility for damage or
breakdown that can result from ignoring these instructions.
Power
Warning! The Uponor system uses 24 VAC, 60 Hz
power. In case of emergency, immediately disconnect
the power.
Technical constraints
Caution! To avoid interference, keep installation/data
cables away from power cables of more than 50 VAC.
Limitations for radio transmission
The Uponor Climate Control Zoning System II uses radio
transmission. The frequency used is reserved for similar
applications, and the chances of interference from other radio
sources are very low.
However, in some rare cases, it might not be possible to
establish perfect radio communication. The transmission
range is sufcient for most applications, but each building has
different obstacles affecting radio communication and maximum
transmission distance. If communication difculties exist, Uponor
recommends relocating the antenna to a more optimal position
and ensuring radio sources are at least 16" (40 cm) apart for
solving exceptional problems.
Compliance
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Note: The grantee is not responsible for any changes or
modications not expressly approved by the party responsible
for compliance. Such modications could void the user’s
authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including
interference that may cause undesired operation of
the device.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Proper disposal of waste electrical and
electronic equipment
This marking shown on the product or its literature
indicates it should not be disposed with other household
waste at the end of its working life. To prevent possible harm
to the environment or human health from uncontrolled waste
disposal, please separate this form from other types of wastes
and recycle it responsibly to promote the sustainable reuse of
material resources.
Contact your installer or local government ofce for details
about environmentally safe recycling.
Climate Control Zoning System II instruction sheet l 3
1234
1234
Installation
System components
Part no. Description
A3800165 Wireless Dial Thermostat (T-165)
A3800167
A3801165 Wireless Base Unit, 6 zones (X-165)
A3801160 Wireless Base Unit Expansion Module, 6 zones (M-160)
System example
Wireless Digital Thermostat (T-167)
4 | uponorpro.com
