DATASHEET
2MP WDR Super Starlight VF Eyeball Network IR
Super Starlight illumination
Day/night functionality
Optical glass window with higher light transmittance
IR anti-reflection window to increase the infrared transmittance
Smart IR, up to 30m (98ft) IR distance
2D/3D DNR (Digital Noise Reduction)
Built-in motorized lens for remote zoom
Ultra 265, H.264, MJPEG
Triple streams
9:16 corridor mode
ONVIF Conformance
Support PoE power supply
Camera
IPC3632ER3-DUPZ-C
Key Features
Optics
Compression
Network
Structure
2
DATASHEET
Wide temperature range: -40°C ~ 60°C (-40°F ~ 140°F)
Wide voltage range of ±25%
IP67
3-Axis
Specifications
IPC3632ER3-DUPZ-C
Camera
Sensor
1/2.8", 2.0 megapixel, progressive scan, CMOS
Lens
2.7 ~ 13.5 mm, AF automatic focusing and motorized zoom lens
DORI Distance
Lens (mm)
Detect (m)
Observe (m)
Recognize (m)
Identify (m)
2.7
41.9
16.8
8.4
4.2
13.5
309.5
8 3.8
41.9
20.9
Angle of view (H)
121.36° ~ 33.51°
Angle of View (V)
74.1° ~ 13.2°
Angle of View (O)
157.8° ~ 41.2°
Adjustment angle
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotate: 0° ~ 360°
Shutter
Auto/Manual, shutter time: 1 ~ 1/100000s
Minimum Illumination
Colour: 0.0005Lux (F1.2, AGC ON)
0Lux with IR
Day/Night
IR-cut filter with auto switch (ICR)
Digital noise reduction
2D/3D DNR
S/N
>52dB
IR Range
Up to 30m (98ft) IR range
Defog
Digital Defog
WDR
120dB
Video
Video Compression
Ultra 265, H.264, MJPEG
H.264 code profile
Baseline profile, Main Profile, High Profile
Frame Rate
Main Stream: 2MP (1920*1080), Max 30fps, ;
Sub Stream: 2MP (1920*1080), Max 30fps;
Third Stream: D1 (720*576), Max 30fps
9:16 Corridor Format
Supported
HLC
Supported
BLC
Supported
OSD
Up to 8 OSDs
Privacy Mask
Up to 8 areas
ROI
Up to 8 areas
Motion Detection
Up to 4 areas
Audio
Audio Compression
G.711
Suppression
Supported
3
DATASHEET
Sampling Rate
8KHZ
Storage
Edge Storage
Micro SD, up to 256GB
Network Storage
ANR
Network
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x,
SNMP, QoS
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API
Interface
Network
1 RJ45 10M/100M Base-TX Ethernet
Built-in Mic
Supported
General
Power
DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 8.16W
Dimensions (Ø x H)
Φ129 x 110mm (Ø5.08” x 4.3”)
Weight
0.67kg (1.48lb)
Working Environment
-40°C ~ 60°C (-40°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Ingress Protection
IP67
Reset Button
Supported
Dimensions
Zhejiang Uniview Technologies Co., Ltd.
Building No.10, Wanlun Science Park, Jiangling Road 88, Binjiang District, Hangzhou, Zhejiang, China (310051)
Email: overseasbusiness@uniview.com; globalsupport@uniview.com
http://www.uniview.com
©2019 Zhejiang Uniview Technologies Co., Ltd. All rights reserved.
*Product specifications and availability are subject to change without notice.
