chapter 1 getting to know the basics
Shuttle
Model name: Xyy0yy
(cy ould be 0~9, A~Z or blank to denote different
color of enclo
1-1
Ϯ
2
chapter 1 getting to know the basics
CHAPTER
GETTING TO KNOW THE BASICS
ϰ
ONE
This chapter introduces the features and
components of the computer.
1-
Ϯ
3
chapter 1 getting to know the basics
Performance Features
High Performance Processor with Napa Chipset
The notebook PC is equipped with a powerful Mobile Intel
Pentium M dual-core processor. Together with the latest
Napa chipset and technologies, the system offers very
advanced PC performances.
Advanced Graphic Engine
The system is built with ATI Mobility M54-P with 128MB
DDR2 dedicated frame buffer. The PCI-Express high-end
graphic engine offers excellent graphic performance for the
most demanding professionals or gamers. The advanced
graphic chip also incorporates a hardware-based
motion-compensation engine, which gives you smooth
MPEG video playback. DirectX 9 graphics capability also
adds realism to PC games.
Built-in Multiple Card Reader
There is built-in 4-in-1 card reader to access many of the
portable media formats (SD Card, MS Card, MMC Card,
and MS-Pro Card).
Gigabit Ethernet Port
The system provides built-in 10/100/1000Mbps Ethernet
network adapter for high bandwidth network connection.
Firewire (IEEE1394 / 1394a) and USB2.0 ports
In addition to a full array of built-in I/O por
offers IEEE1394 for ultra high-speed connection to high
bandwidth digital video devices and USB2.0 ports to
connect to any USB-based peripheral devices.
Wireless LAN
The internal Wireless LAN module allows your notebook to
connect wirelessly to other 802.11-enabled systems,
devices, or network.
ts, the computer
1-
Ϯ
4
chapter 1 getting to know the basics
Package Content
Please take a moment to make sure you have the following content
in the box.
[ Proposal: Will take a live black and white picture of the actual
items.]
1-
Ϯ
5
chapter 1 getting to know the basics
System At A Glance
Front View
Warning: Do not place any heavy objects on the top of computer. This may
damage the unit
1. Power / Suspend Button
The power/suspend button turns the computer on and off and it
also acts as a system suspend key. Press momentarily to turn
on the system. Press and hold for at least 4 seconds to turn off
the system. How this key behaves can be defined in [Start >
Settings > Control Panel > Power Options > Advanced] menu.
Press the power / suspend button again to return from the
suspend mode. (See Chapter 3 for more details on system
suspend function.)
2. 4-in-1 Card Reader
The 4-in-1 Card Reader supports SD Card, MS Card, MMC
Card, and MS-Pro Card.
3. USB2.0 Port (x1)
The Universal Serial Bus (USB2.0-compliant) port allows you to
1-
Ϯ
6
chapter 1 getting to know the basics
connect a wide variety of devices to your computer at a rate of
up to 480 Mbps. This port conforms to the latest USB2.0
plug-and-play standards.
4. Ventilation Grill
The fan grill is where air is exchanged to dissipate the internal
heat. Do not block this airway completely.
5. Optical Drive and Disk Eject Button and Manual Eject Key
Hole
If your computer comes with the Combo drive, DVD-RW,
DVD+RW, or DVD-Dual drive, you may save data onto a CD-R
/ CD-RW or DVD RW disc. Press the eject button to eject the
disk tray. The manual eject keyhole allows you to manually
eject a jammed disk.
This is a tray-less (slot-in) type of Optical Drive.
To Load a CD:
Gently insert the disc into the slot opening and XPC will
automatically load-in the rest of the disc.
To Eject a CD:
Push the Eject Button and the disc will be ejected automatically.
1-
Ϯ
7
chapter 1 getting to know the basics
1-
Ϯ
8
chapter 1 getting to know the basics
Rear Views
Warning: Do not block the Fan Grill outlet. Place the machine on hard
surface only. The bottom case may get very hot.
1. Power Jack (DC-in)
The DC-out jack of the AC Adapter connects here and powers
the computer.
2. DVI-I Port
The DV I-I video output port is for connecting the external LCD
monitor or projector.
3. Ethernet / LAN Port
The port connects to a network hub via the RJ-45 cable and
also conforms to 10/100/1000Base-TX transmission protocol.
4. S/PDIF-out Jack
You may connect the S/PDIF output to an external DTS, AC3,
or PCM sound processor / decoder in your home stereo
system.
1-
Ϯ
9
chapter 1 getting to know the basics
5. USB2.0 Port (x2)
The Universal Serial Bus (USB2.0-compliant) port allows you to
connect a wide variety of devices to your computer at a rate of
up to 480 Mbps. This port conforms to the latest USB2.0
plug-and-play standards.
6. TV (S-Video) Port
The S-Video port permits you to redirect the screen output to a
television set or any analog video playback device. This TV
Port is copyright protected; when DVD movie is played, the
output is scrambled to prevent analog recording.
7. Stereo Headphone / Line-out Jack
The stereo headphone jack (3.5-mm diameter) is where you
connect to the headphones or external speakers.
8. Audio Line-in Jack
The Audio Line-in jack (3.5-mm diameter) is where you connect
an external audio input source such as a CD Player.
9. Microphone Jack
The microphone jack (3.5-mm diameter) is where you connect
a microphone.
10. Firewire / IEEE1394 / 1394a Port
This is a high-speed serial data port. You may connect any
Fire-wire-ready device to this port.
11. USB2.0 Port (x2)
The Universal Serial Bus (USB2.0-compliant) port allows you to
connect a wide variety of devices to your computer at a rate of
1-
Ϯ
0
chapter 1 getting to know the basics
up to 480 Mbps. This port conforms to the latest USB2.0
plug-and-play standards.
12. Ventilation Grill
The fan grill is where air is exchanged to dissipate the internal
heat. Do not block this airway completely.
1-1
Ϯ
chapter 1 getting to know the basics
AC Adapter
1. DC-out Connector
The DC-out connector docks to the power jack (DC-in) on the
computer.
2. LED Lamp
The LED lamp appears green when the unit is plugged into a
valid AC source.
3. Adapter
The adapter converts alternating current into constant DC
voltage for the computer.
4. AC Plug
The AC plug plugs to the AC wall outlet.
Warning: Make sure that you are using a standard 3-prong AC plug with a
ground pin. If not, you may feel a slight tingling sensation when you touch the
computer’s metal parts such as the I/O ports. This is caused by a leakage
current when the AC adapter is not properly grounded via the ground pin.
However, the amount of leakage current is within the safety regulation and is
not harmful to the human body.
1-11
Ϯ
2
chapter 1 getting to know the basics
Using the Vertical Stand
The vertical stand allows you to mount the system vertically;
however, you must position the system in a correct manner to
prevent thermal-related issue. The following illustration shows you
how to correctly position the system onto the stand.
1-1
Ϯ
3
chapter 1 getting to know the basics
Connecting the System
Before turning on the system, you need to connect the following
devices to the XPC first. Please follow the steps according to the
illustrations.
1. Connecting Power
Note: The DC-in connector will only fit in a certain orientation.
Make sure the LED on the AC Adapter is lit. Do not press the
Power (ON) button yet.
2. Connecting Monitor
1-1
Ϯ
4
chapter 1 getting to know the basics
Note: The DVI connector will only fit in a certain orientation.
3. Connection Keyboard and Mouse
Note: You may plug the USB keyboard and Mouse to any of the
available USB port on the system.
1-1
Ϯ
5
chapter 1 getting to know the basics
4. Connecting Speaker and Microphone
(Picture not yet ready.)
5. Connecting to LAN
Note: The following illustration shows you how XPC may be
connected to the Network via a Router. If you do not have a
Router and/or do not need one, you may connect the Ethernet
Port directly to the Network Ethernet Port via an Ethernet
(RJ45-type) cable. Please refer to the Ethernet Section later in
this chapter to learn more about cabling restrictions.
1-1
Ϯ
6
chapter 1 getting to know the basics
6. Powering on the system
You may now turn on the system by pressing the Power (ON)
button.
After the system has successfully booted to Windows, you may
connect additional devices such as a USB printer, PC camera,
or Firewire-type video camera to the system. Once you plug in
the device, Windows will search for its driver. If Windows can
not find the driver, you may need to provide the device’s Factory
Installation CD to complete the installation process. Check the
1-1
Ϯ
7
chapter 1 getting to know the basics
device’s user manual for detailed instruction.
1-1
Ϯ
8
chapter 1 getting to know the basics
Audio Subsystem – How to Enable the DTS 7.1
Multi-channel Surround Sound System
The system only has a stereo mini-jack that provides line-out signal
to a two-speaker configuration. However, if you have an AC3/DTS
Home Theater Receiver with 7.1 Multi-channel speaker output, you
may use the following illustration to build a 7.1-channel
entertainment system.
1. Connecting to the DTS Receiver via S/PDIF Toslink
cable
Note: You may need to purchase a Toslink Cable to make
connection. Make sure that the Receiver also has the same
type of S/PDIF Toslink input jack.
2. Connecting the Speakers to the Receiver
1-1
Ϯ
9
chapter 1 getting to know the basics
Note: The following illustration assumes that your Receiver has
7.1-channel speaker output. You may need to refer to the
Receiver’s user manual for speaker connection and the correct
settings.
1-1
Ϯ
0
chapter 1 getting to know the basics
Adjusting the Audio Volume in Windows
1. Click the speaker symbol in the task tray in Windows.
2. Drag the volume control bar up or down to adjust the volume.
3. To temporarily silence the speaker without changing the
volume setting, click Mute.
Voice Recording
You will need an external microphone to record sound. You will
need to use audio processing software to enable the built-in
microphone. For example, you may use Microsoft Sound
Recorder.
{Insert an Illustration…}
1-2
Ϯ
chapter 1 getting to know the basics
Ethernet
Your computer is equipp ed with a 10/100/1000Base-TX Fast
Ethernet network adapter. Connect the active LAN cable to the
RJ-45 LAN port located on the left side of the computer. This allows
you to access and transmit data in the local area network.
Connecting to the Network
Use Unshielded Twisted Pair (UTP) Ethernet cable only.
1. Insert one end of the UTP cable into the network connector
until the connector snaps securely into the receptacle.
2. Either connect the other end of the cable to an RJ-45 jack
wall outlet or to an RJ-45 port on a UTP concentrator or hub in
the network.
Cabling Restriction for Networks
The following restrictions should be observed for
10/100/1000BASE-TX networks:
The maximum cable run length is 100 meters(m) (328
feet[ft]).
For 100Mbps or 1000Mbps operations, use Category 5
wiring and connections.
Note: Consult Windows manual and / or Novell Netware user’s guide for the
software installation, configuration, operation of the network.
1-21
Ϯ
2
chapter 1 getting to know the basics
CHAPTER
ϰ
TWO
BIOS SETUP AND SECURITY FEATURE
In this chapter, you will learn how to
enter the BIOS Setup Menu and
manipulate various hardware control
settings. You will also learn how to use
the built-in security features.
1-2
Ϯ
3
chapter 1 getting to know the basics
The Setup Utility is a hardware configuration program built into
your computer’s BIOS (Basic Input/Output System). It runs and
maintains a variety of hardware functions. It is a menu-driven
software, which allows you to easily configure and change the
settings.
The BIOS contains manufacture’s default settings for the
computer’s standard operations. However, there are occasions
when you may be required to modify the default settings in the
BIOS. For example, you may need to configure the BIOS power
management (APM) settings if you are using DOS, or
non-Windows operating system.
The BIOS allows you to set up passwords to limit access to users.
This is an important feature because a great deal of vital
information is carried within the computer nowadays. Unauthorized
access can be prevented. Later in this chapter, you will learn how to
use this security feature.
1-2
Ϯ
4
chapter 1 getting to know the basics
Entering the BIOS Setup Screen
First turn on the power. When the BIOS performs the POST
(Power-On Self Test), press F2 key quickly to activate the AMI
BIOS Setup Utility.
Note: You may need to press F2 key fairly quickly. Once the system begins to load
Windows, you may have to retry by cycle-power on again
Leaving the BIOS Setup Screen
When you have finished modifying the BIOS settings, exit the BIOS.
It takes a few seconds to record changes in the CMOS.
BIOS Action Keys
Function Key Command Description
Leaves a sub-menu to return to the
ESC Exit
previous menu OR exits the BIOS setup
while saving changes.
Enter Go to Sub Screen Shows the Sub Menu
F1 General Help Shows the Help Screen
F10 Save and Exit
<Tab> Select a field Selects the next field.
Х Select an item Selects the next upper item.
Ц Select an item Selects the next lower item.
- Lower value Selects the next value within a field.
+ Higher value Selects the next value within a field.
1-2
Saves changes and reboots the
computer.
Ϯ
5
chapter 1 getting to know the basics
Modifying the BIOS Settings
The AMIBIOS setup main menu is subdivided into sub-menus.
Each menu item is described in this section.
Main Setup
Under this menu, you may change time/date and view basic
processor and system memory information.
Item Selections /
Sub-menu
Date N/A Type in the current date, in MM/DD/YY
Time N/A Type in the current date, in HH:MM:SS
Description
format.
format.
Boot Setup
? Boot Settings Configuration
Item
Quick
Boot
Quiet Boot Disabled
Selections /
Sub-menu
Disabled
Enabled
Enabled
Description
Certain tests are skipped during boot-up,
therefore the system boots up faster.
When Enabled, the system will display
OEM logo instead of the POST
messages.
When Disabled, the system will display
POST messages (i.e. devices
information.)
1-2
Ϯ
6
chapter 1 getting to know the basics
? Boot Device Priority
Item
Selections /
Description
Sub-menu
1st Boot
Device
2nd Boot
Device
3rd Boot
Device
4th Boot
Device
Removable Dev.
CD/DVD
Hard Drive
Network: Realtek
Boot Agent
Disabled
Set the type of device for the 1st drive
BIOS attempts to boot from. If Realtek
Boot Agent is selected, system will
attempt to load boot sector from the
Ethernet port.
Set the type of device for the 2nd drive
BIOS attempts to boot from.
Set the type of device for the 3rd drive
BIOS attempts to boot from.
Set the type of device for the 4th drive
BIOS attempts to boot from.
Note: If you select Realtek Boot Agent, the system will attempt to boot from the
network.
Note: When the BIOS performs POST, you may also press F12 Key to enable the
Boot Device selection menu. You may choose CD/DVD, Hard Drive, or Realtek Boot
Agent as the first storage device to boot from. If you have already connected a USB
Floppy Disk Drive before powering up, it will appear as a Removable Device in the
Boot Device selection menu
1-2
Ϯ
7
chapter 1 getting to know the basics
Security Setup
? Boot Settings Configuration
Item
Change
Supervisor
Password
Change
User
Password
Using Password Protection
Two Levels of Password Protection are available. The BIOS
provides both a Supervisor and a User password. If you try to
activate both passwords, the Supervisor password must be set first.
The passwords activate two different levels of protection:
1. System always asks for password every time it is powered on.
2. System asks for password only when you attempt to enter
BIOS utility.
The passwords are encrypted and stored in NVRAM. Make sure
you write them down or memorize them. If you lost the passwords,
the computer may need to be sent back to the factory or to an
authorized service dealer to reset the passwords.
Selections /
Description
Sub-menu
N/A Install or Change the Password
N/A Install or Change the Password
1-2
Ϯ
8
chapter 1 getting to know the basics
Power Setup
Item
Selections /
Description
Sub-menu
Long Battery
Life Mode
Enable
Disable
When Enabled, maximum battery life can
be achieved. The processor performance
is lowered.
Power Button
Mode
On/Off
Suspend
[On/Off]: When the power button is
pressed, the system is turned off.
[Suspend]: When the power button is
pressed, the system enters the suspend
mode. !
Note: The Suspend Mode selection in BIOS only applies to older Windows version
(such as Windows 3.1 or Windows 95 or NT4) or non-Windows operating system. In
Windows ME / 98SE / 2000 / XP, suspend mode and settings are determined by
settings in the Power Options Properties (Start > Control Panel > Power Options).
1-2
9
Exit Setup
Ϯ
chapter 1 getting to know the basics
Item
Saves
Changes and
Exit
Discard
Changes
Load Optimal
Defaults
Selections /
Description
Sub-menu
N/A
After you have completed the BIOS
settings, select this item to save all
settings, exit BIOS Setup utility, and
reboot. New system settings will take
effect on next power-up. F10 key can be
used for this operation.!
N/A Discards changes done so far to any of
the setup questions.
N/A Load Optimal Default value for all the
setup questions. F9 key can be used for
this operation.
1-2
Ϯ
0
chapter 1 getting to know the basics
CHAPTER
TROUBLE SHOOTING
ϰ
THREE
In this chapter, you will learn how to
solve common hardware and software
problems.
1-3
Ϯ
chapter 1 getting to know the basics
Your computer has been fully tested and complies with the
system specifications before shipping. However, incorrect
operations and/or mishandling may cause problems.
This chapter provides a reference for identifying and correcting
common hardware and software problems that you may encounter.
When you encounter a problem, you should first try to go through
the recommendations in this chapter. Instead of returning the
computer and waiting for repair, you may easily solve the problems
by considering the following scenarios and possible solutions. If the
error continues, contact your reseller for service information.
Before taking further actions, consider the following suggestions:
Check to see if the problem persists when all the external
devices are removed.
Check to see that the green light indicator on the AC adapter
is lit.
Check to see the power cord is properly plugged to the wall
outlet and to the computer.
Check to see the power indicator of the computer is on.
Check to see if your keyboard is operational by pressing and
holding any key.
Check for any incorrect or loose cable connections. Make
sure the latches on the connectors latch securely on to the receptor
end.
Be sure you have not performed an incorrect setting on the
1-31
Ϯ
2
chapter 1 getting to know the basics
hardware devices in the BIOS Setup utility. A faulty setting may
cause the system to misbehave. If you are not sure of the changes
you made, try to restore all the settings to factory defaults.
Be sure all the device drivers are installed properly. For
example, without the audio driver properly installed, the speakers
and microphone will not work.
If external devices such as USB camera, scanner, printer do
not function correctly when connected to the system, it is usually
the device’ s own problem. Consult the device’ s manufacturer first.
Some software programs, which have not gone through
rigorous coding and testing, may cause problems during your
routine use. Consult the software vendor for problem solving.
Legacy peripheral are not plug -and-play capable. You need to
restart the system with these devices powered up and connected
first.
Be sure to go to BIOS SETUP and load DEFAULT SETTING
after BIOS re-flash.
Be sure the Quick Key Lockout Switch on the bottom of the
computer is not engaged; otherwise the quick keys will not work.
1-3
Ϯ
3
chapter 1 getting to know the basics
Audio Problems
No speaker output -
Software volume control is turned down in Microsoft
Sound System or is muted. Double-click the speaker icon on
the lower right corner of the taskbar to see if the speaker has
been muted or turned down all the way.
Most audio problems are software-related. If your
computer worked before, chances are software may have been
set incorrectly.
Go to [Start > Settings > Control Panel] and double-click
the Sounds and Audio Devices icon. In the Audio page, make
sure that Realtek HD Audio is the default playback device.
Sound cannot be recorded -
You will need to plug-in an external microphone to the
microphone connector to record sound.
Double-click the speaker icon on the lower right corner of
the taskbar to see if the microphone has been muted.
1. Click Options and select Properties.
2. Select Recording and click the OK button.
3. After Click OK button, the recording volume control panel
will appear.
Go to [Start > Settings > Control Panel] and double-click
the Multimedia icon (or Sounds and Audio Devices icon). In the
Volume or Audio page, make sure that Realtek HD Audio is the
default recording device.
1-3
Ϯ
4
chapter 1 getting to know the basics
Hard Disk Problems
The hard disk drive does not work or is not recognizable -
If you had just performed a hard disk upgrade, make sure
the hard drive connector is not loose and the hard disk drive is
also correctly seated. Remove it and reinsert it firmly, and
restart your PC. (Refer to Chapter 4 for details.)
The new HDD may need to be partitioned and
reformatted. O/S and drivers will need to be re-installed as well.
Check the hard disk indicator LED. When you access a
file, the LED lamp should light up momentarily.
The new HDD may be defective or is not compatible.
If your computer has been subjected to static electricity
or physical shock, you may have damaged the disk drive.
The hard drive is making abnormal whining noises -
You should back up your files as soon as possible.
Make sure the source of noise is indeed from the hard
drive and not the fan or other devices.
1-3
The hard disk drive has reached its capacity -
Run Disk Cleanup utility in Windows. [Start > All Programs
> Accessories > System Tools > Disk Cleanup] The system will
prompt you for what to do.
Archive files or programs that you had no longer used by
moving them to an alternative storage medium (floppy disk,
optical record-able disk, etc.) or uninstall programs that no
longer use.
Many browsers store files in the hard drive as a cache to
speed up the performance. Check the program’s Online Help
Ϯ
5
chapter 1 getting to know the basics
for instructions on decreasing the cache size or on removing
temporary Internet files.
Empty the Recycle Bin to create more disk space. When
you delete files, Windows saves them to the Recycle Bin.
The hard disk takes longer to read a file -
If you have been using the drive for a period, the files may
be fragmented. Go to [Start > Programs > Accessories >
System Tools > Disk Defragmenter] to perform a disk
defragment ation. This operation may take a while.
Interrupt requests or problems with other hardware
devices may have occupied the CPU and therefore slows down
the system performance.
The files are corrupted -
Run the Error -checking utility in Windows to check the
HDD. Double-click My Computer. Right-click C: and select
Properties. Click Check Now in Error-checking in Tools.
1-3
Ϯ
6
chapter 1 getting to know the basics
Optical Drive Problems
The optical drive does not work -
Try rebooting the system.
The disk is damaged or files are not readable.
After you have inserted a CD-ROM disk, it may take a
moment before you can access its content.
The drive dose not read any disks -
The CD may not be properly seated in the tray. Make
sure the disk is firmly seated onto the spindle.
The disk is damaged or not readable.
The disk cannot be ejected -
Normally, it takes a few seconds to eject the disk.
If the disk cannot be ejected, it may be mechanically
jammed. Straighten out a paper clip and insert it to a tiny hole
next to the eject button. This should reject the disk tray. If not,
return the unit for repair. Do not forcefully pull on the disk tray.
1-3
The Combo or DVD Dual or Supermulti drive (optional
device) cannot record -
You need to purchase and install a burner utility program
to record files to a blank media.
Ϯ
7
chapter 1 getting to know the basics
Display Problems
The display panel is blank when the system is turned on -
Make sure the computer is not in the Standby or
Hibernate suspend modes. The display is turned off to
conserve energy in these modes.
The screen is difficult to read -
The display resolution should at least be set to at
least1024x768 for optimal viewing.
1. Go to [Start > Settings > Control Panel] and double-click
the Display icon.
2. Under the Settings page, set screen resolution to at least
1024x768 and choose at least 256 colors.
The screen flickers -
It is normal if the display flickers a few times during
shutting down or powering up.
1-3
Ϯ
8
chapter 1 getting to know the basics
Keyboard and Mouse Problems
The built-in touch pad performs erratically -
Make sure there is no excess perspiration or humidity on
your hand when using the touch pad. Keep the surface of the
touch pad clean and dry.
Do not rest your palm or wrist on the surface of the touch
pad while typing or using the touch pad.
The built-in keyboard accepts no input -
If you are connecting an external keyboard to the system,
the built-in keyboard may not work.
Try restarting the system.
1-3
The characters on the screen repeat while I type.
You may be holding the keys down too long while you’ re
typing.
Keep the keyboard clean. Dust and dirt under the keys
could cause them to stick.
Configure the keyboard to wait longer before the auto
repeat feature starts. To adjust this feature, Go to [Start >
Settings > Control Panel], and double-click the Keyboard icon.
A dialogue box shows up with the adjustable settings for the
keyboard.
Ϯ
9
chapter 1 getting to know the basics
CMOS Battery Problem
A message “CMOS Checksum Failure” displays during the
booting process or the time (clock) resets when booting -
Try to reboot the system.
If the message “CMOS Checksum Failure” appears
during the booting procedure even after rebooting, it may
indicate failure of the CMOS battery. If so, you need to replace
the battery. This battery normally lasts two to five years. The
battery is of type CR2032 (3V).
1-3
Ϯ
0
chapter 1 getting to know the basics
Memory Problems
The POST does not show an increased memory capacity
when you have already installed additional memory -
Certain brands of memory module may not be
compatible with your system. You should ask your vendor for a
list of compatible DIMM.
The memory module may not be installed properly. Go
back to Chapter 4 to review the details of this operation.
The memory module may be defective.
The O/S issues an insufficient memory error message
during operation -
This is often a software or Windows-related problem. A
program is draining the memory resources.
Close the application programs you’ re not using and
restart the system.
You need to install additional memory module. For
instructions, go to Chapter 4 Upgrading Your Computer.
1-4
Ϯ
chapter 1 getting to know the basics
Network Adapter / Ethernet Problems
The Ethernet adapter does not work -
Go to [Start > Settings > Control Panel > System >
Hardware > Device Manager]. Double-click on Network
Adapters and check if Realtek RTL8169/8110 Family Gigabit
Ethernet NIC appears as one of the adapters. If it does not
exist, Windows has not detected the Realtek RTL8169/8110
Family Gigabit Ethernet NIC or the device driver has not been
installed properly. If there is a yellow mark or red-cross on the
network adapter, it may be a device or resource conflict.
Replace or update the device driver from the factory CD-ROM
disk or consult Windows manual on how to solve the resource
conflict problem.
Make sure the physical connections on both ends of
the cable are good.
The hub or concentrator may not be working properly.
Check to see if other workstations connected to the same hub
or concentrator is working.
The Ethernet adapter does not appear to operate in the
1000Mbps transmission mode -
Make sure the hub you are using supports 1000Mbps
operation.
Make sure that your RJ-45 cable meets the
1000Base-TX requirements.
Make sure the Ethernet cable is connected to the hub
socket that supports 1000Base-TX mode. The hub may have
both 100Base-TX and 1000Base-T sockets.
1-41
Ϯ
2
chapter 1 getting to know the basics
Performance Problems
The computer becomes hot -
In a 35
o
C environment, the certain areas of the
computer’s back case are expected to reach 50 degrees.
Make sure the air vents are not blocked.
If the fan does not seem to be working at high
temperature (50 degrees Celsius and up), contact the service
center.
Certain programs that are processor-intensive may
increase the computer temperature to a degree where the
computer automatically slows down its CPU clock to protect
itself from thermal damage.
The program appears stopped or runs very slowly -
Press CTRL+ALT+DEL to see if an application is still
responding.
Restart the computer.
This may be normal for Windows when it is processing
other CPU-intensive programs in the background or when the
system is accessing slow-speed devices such the floppy disk
drive.
You may be running too many applications. Try to close
some applications or increase system memory for higher
performance.
The processor may have been overheated due to the
system’ s inability to regulate its internal heat. Make sure the
computer’ s ventilation grills are not blocked.
1-4
Ϯ
3
chapter 1 getting to know the basics
Firewire (IEEE1394) and USB2.0 Problems
The USB device does not work -
Windows NT 4.0 does not support USB protocols
Check the settings in the Windows Control Panel.
Make sure you have installed the necessary device
drivers.
Contact the device vendor for additional support.
The IEEE1394 port does not work -
Go to [Start > Settings > Control Panel > System >
Hardware > Device Manager]. You should see an entry which
reads “Texas Instrument OHCI Compliant IEEE 1394 Host
Controllers” . If it does not exist, Windows has not detected the
host controller or the device driver has not been installed
properly. If there is a yellow mark or red-cross on the 1394 host
controller, it may be a device or resource conflict. Replace or
update the device driver from the factory CD-ROM disk or
consult Windows manual on how to solve the resource conflict
problem.
Make sure the cable is fully connected.
Make sure you have installed the necessary device
drivers.
Contact the device vendor for additional support.
1-4
Ϯ
4
chapter 1 getting to know the basics
APPENDIX
PRODUCT SPECIFICATION
ϰ
A
1-4
5
Processor
Core Logic
Memory Type
Default
Memory
Expansion
Graphic
Accelerator
Motion
Playback
Other
Features
Ϯ
chapter 1 getting to know the basics
ϰ
Processor and Core Logic
Mobile Intel Pentium M – Dual-Core Processor (Yonah),
up to 2.16 GHz, 2 MB L2 cache
Intel Calistoga 945PM + ICH7-M chipset with audio,
modem, and USB2.0 controllers integrated
667MHz Front Side Bus
533 / 667MHz DDR2 interface
ϰ System Memory
DDR2 SDRAM 533 / 667
256 / 512 / 1024MB
Two 200-pin DIMM sockets, Max 2 GB
ϰ
Graphic Subsystem
ATI M54-P (with 128MB DDR2 Frame Buffer)
Supports MXM Type II
Hardware Motion Compensation and IDCT Supported
for MPEG1/2 Playback
DirectX compatible
Chipset
Audio Codec
Sound
Capabilities
ϰ Audio
Intel (ICH7M) integrated audio controller
Realtek ALC880
DirectSound 3D, EAX 1.0 & 2.0 compatible
A3D, I3DL2 compatible
AC97 V2. 3 compatible
7.1 Multi-channel compatible
Azalia compatible
1-4
6
Module
Transmission
Protocol
Chipset
PnP Function
Flow Control
Speed
Selection
Other
Features
Ϯ
chapter 1 getting to know the basics
ϰ
Wireless LAN
Intel PRO/Wireless 3945ABG Card
Mini-Card Interface IEEE802.11 B&G
LAN / Ethernet
ϰ
Realtek 8110 Ethernet function for
10/100/1000Base-TX network standards
Windows 2000 / XP Plug and Play compatible
Automatic Jam and auto-negotiatio n for flow control
Auto Negotiation and Parallel detection for automatic
speed selection (IEEE 802.3u)
High performance 32-bit PCI bus master architecture
with integrated DMA controller for low CPU and bus
utilization
Remote Wake-up Scheme supported
Hot Insertion supported
Chipset
4-in-1 Card
Reader Format
Support
1-4
ϰʳ Multiple Card Reader
02 Micro 0Z128 (Card Reader)
Multimedia Card (MMC), Secure Digital Card (SD),
Memory Stick (MS), and MS Pro Card
7
Chipset
Capabilities
Hard Drive
DVD-Dual or
DVD-Multi
Standards
Ϯ
chapter 1 getting to know the basics
ϰ
Firewire IEEE1394(a)
TI TSB43AB22A IEEE1394 OHCI Host Controller and
Up to 400 Mbps
Expandable up to 63 devices in chains
ϰʳ Storage
3.5-inch format hard disk drive
Trayless-type (slot-in) 5.25 -inch format (12.7mm height)
fixed module (Optional Purchase)
Mic-In Port
Audio-Out
Audio-In Port
S/PDIF
Firewire
USB2.0 Port
Ethernet
S-Video
Power-In
DVI-I Port
Card Reader
Ports and Connectors
ϰʳ
One Microphone-in jack
One Headphone / Line-out jack
One Line-in jack
One S/PDIF Toslink (optical) jack
One Firewire (IEEE1394) host connector
Five USB2.0-compliant connectors
One standard network Ethernet connector (RJ-45)
One S-video (TV-out) output connector
One DC-in connector
One DVI-I video connector
One 4-in-1 Card Reader slot
1-4
8
Adapter
AC-Input /
DC-Output
PnP Function
Self Test
Auto
Detection
Power
Management
Security
Other
Features
Ϯ
chapter 1 getting to know the basics
ϰʳ
AC Adapter
Autosensing AC-in 100~240V, DC-out 20V, 120W
ϰʳ BIOS
AMI PnP BIOS
Power On Self Test
DRAM auto-detection, auto-sizing
L2 Cache auto-detection
Hard disk type auto-detection
APM 1.2 (Advanced Power Management) &
ACPI 2.0 (Advanced Configuration Power Interface)
Two Level Password Protections
32bit access, Ultra DMA, PIO5 Mode support
Multi-boot capability
O/S
Dimension
Weight
Environmental
Limits
1-4
Operating System
ϰʳ
Compatible with Microsoft Windows XP Professional
Edition
ϰʳ
Physical Specification
296 (W) x 210 (D) x 56 (H) mm
3.41 KG
Operating Temperature: 5 to 30
Operating Humidity: 20 to 80 percent RH (5 to 35
Storage Temperature: -15 to 50
o
C (41 to 86oF)
o
C (-5 to 122oF)
o
C)
Ϯ
9
chapter 1 getting to know the basics
APPENDIX
AGENCY REGULATORY NOTICES
ϰ
B
1-4
Ϯ
0
chapter 1 getting to know the basics
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio or television technician
for help.
Modifications
The FCC requires the user to be notified that any changes or modifications
made to this device that are not expressly approved by the Manufacture
may void the user’s authority to operate the equipment.
Connections to Peripheral Devices
Connections to this device must be made with shielded cables with metallic
RFI/EMI connector hoods to maintain compliance with FCC Rules and
Regulations.
European Notice
Products with the CE Marking comply with both the EMC Directive
(89/336/EEC) and the Low Voltage Directive (73/23/EEC) and R&TTE
Directive (1999/5/EC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the following
Any changes or modifications (including the antennas) made to this device that are not expressly
approved by the manufacturer may void the userϗs authority to operate the equipment.
1-5
Ϯ
chapter 1 getting to know the basics
European Norms:
EN55022 : 1998+A1: 2000+A2: 2003, CLASS B
EN61000-3-2 : 2000
EN61000-3-3 : 1995+A1: 2001
EN55024 : 1998+A1 : 2001+A1: 2003
IEC61000-4-2: 2001
IEC61000-4-3:2002+A1:2002
IEC61000-4-4:1995+A1:2000+A2:2001
IEC61000-4-5:2001
IEC61000-4-6:2001
IEC61000-4-8:2001
IEC61000-4-11:2001
EN50082 (IEC801-2, IEC801-3, IEC801-4) Electro-magnetic
Immunity
EN 300 328-2, EN 300 328-1, EN 301 489-1, EN 301 489-17 (ETSI
300 328, ETSI 301 489) Electro-magnetic Compatibility and Radio
Spectrum Matter.
TBR21 ( ETSI TBR21) Terminal Equipment.
EN60950 (IEC60950) I.T.E. Product Safety
Canadian Notice
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the radio interference
regulations of the Canadian Department of Communications.
Le present appareil numerique nemet pas de bruits radioelectriques
depassant les limites applicables aux appareils numeriques de Classe B
prescrites dans le reglement sur le brouillage radioelectrique edicte par le
Ministere des Communications du Canada.
REN (Ringer Equivalent Numbers) Statement
''NOTICE: The Ringer Equivalence Number (REN) assigned to each
terminal device provides an indication of the maximum number of terminals
allowed to be connected to a telephone interface. The termination on an
interface may consist of any combination of devices subject only to the
requirement that the sum of the Ringer Equivalence Numbers of all the
devices does not exceed 5.''
IC ID: 3409A-M30EI0
1-51
Ϯ
2
chapter 1 getting to know the basics
Attachment Limitations Statement
''Notice: This equipment meets telecommunications network protective,
operational and safety requirements as prescribed in the appropriate
Terminal Equipment Technical Requirements document(s). This is
confirmed by marking the equipment with the Industry Canada certification
number. The Department does not guarantee the equipment will operate to
the user's satisfaction.
Before installing this equipment, users should ensure that it is permissible
to be connected to the facilities of the local telecommunications company.
The equipment must also be installed using an acceptable method of
connection. The customer should be aware that compliance with the above
conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative
designated by the supplier. Any repairs or alterations made by the user to
this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the
equipment.
Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines and internal metallic water
pipe system, if present, are connected together. This precaution may be
particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves,
but should contact the appropriate electric inspection authority, or
electrician, as appropriate.''
Power Cord Requirement
The power cord supplied with the AC adapter should match the plug and
voltage requirements for your local area. Regulatory approval for the AC
adapter has been obtained using the power cord for the local area.
However, if you travel to a different area and need to connect to a different
outlet or voltage, you should use one of the power cords listed below. To
purchase a power cord (including one for a country not listed below) or a
replacement ac adapter, contact your local dealer.
U.S. and Canada
The cord set must be UL-Listed and CSA-Certified or C-UL Listed.
The minimum specifications for the flexible cord are (1) No. 18 AWG,
1-5
Ϯ
3
chapter 1 getting to know the basics
(2) Type SJ, and (3) 3-conductor.
The cord set must have a rated current capacity of at least 10 A.
The attachment plug must be an earth-grounding type with a NEMA
5-15P (15A, 125V) or NEMA 6 -15P (15 A, 250V) configuration.
Japan
All components of the cord set (cord, connector, and plug) must bear
a `PSE` mark and registration number in accordance with the
Japanese Dentori Law.
The minimum specification for the flexible cord are: (1) 0.75 mm
2
conductors, (2) Type VCT or VCTF, and (3) 3-conductor.
The cord set must have minimum rated current capacity of 7 A.
The attachment plug must be a two-pole, grounded type with a
Japanese Industrial Standard C8303 (15 A, 125 VAC) configuration.
Other Countries
The cord set fittings must bear the certification mark of the agency
responsible for evaluation in a specific country. Acceptable agencies
are:
BSI (UK)
OVE (Australia)
CEBEC (Belgium)
SEMKO (Sweden)
FIMKO (Finland)
DEMKO (Denmark)
NEMKO (Norway)
SETI (Finland)
EANSW (Australia)
SEV (Switzerland)
IMQ (Italy)
UTE (France)
CCC (China)
PSB (Singapore)
PSE (Japan)
BSMI (Taiwan)
B (Polish)
VDE (Germany)
SASO (Saudi Arabia)
The flexible cord must be of a HAR (harmonized) type
HO5VV-F 3-conductor cord with a minimum conductor size of
0.03 square inches.
The minimum specification for the flexible cord for Class II
1-5
Ϯ
4
chapter 1 getting to know the basics
product are: (1) 2X0.75 mm2 conductors, (2) 2-conductor
cord.
The cord set must have a current capacity of at least 10 A and a
nominal voltage rating of 125 / 250 VAC.
CAUTION: MODEL XPCIAx IS DESIGNED TO USE WITH THE
FLLOWING AC ADAPTER MODEL ONLY
Manufacture: LI SHIN INTERNATIONAL ENTERPRISE CORP.
Model: 0227A20120 (120W)
Laser Safety
The optical drive used with this computer is certified as a Class 1 laser
device according to the U.S. Department of Health and Human Services
(DHHS) Radiation Performance Standard and International Standards IEC
825 / IEC 825-1 (EN60825 / EN60825-1). The device is not considered
harmful, but the following precautions are recommended:
Do not open the unit.
Avoid direct exposure to the laser beam.
If the unit requires service, contact an authorized service center.
Ensure proper use by reading and following the instructions carefully.
Do not attempt to make any adjustment of the unit.
CLASS 1 LASER PRODUCT
APPAREIL A LASER DE CLASSE 1
LASERSCHUTZKLASSE 1 PRODUKT
Warning!
Do not attempt to disassemble the cabinet containing the laser. The laser
beam used in this product is harmful to the eyes. The use of optical
instruments, such as magnifying lenses, with this product increase the
potential hazard to your eyes. For your safety, have this equipment
serviced only by an authorized service provider.
Lithium battery warning / Bridge battery warning
This computer contains a lithium battery to power the clock and calendar
circuitry.
CAUTION: Danger of explosion if battery is replaced incorrectly. Replace
only with the same or equivalent type recommended by the manufacturer.
1-5
Ϯ
5
chapter 1 getting to know the basics
Discard used batteries according to the manufacturer’s instructions.
ATTENTION: Il y a danger d’xplosion s’il y a remplacement incorrect de la
batterie. Remplacer uniquement avcc unc batterie du meme type ou d’un
type recommande par le constructer. Mettre au rebut les batteries usagees
conformement aux instructions du fabricant.
VORSICHT! Explosionsgefahr bei unsachgemBen Austausch der Batterie
Ersatz nur durch denselben oder einem vom Hersteller empfohlenem
ahnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des
Herstellers.
Der Arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 betragt 70dB
(A) oder weniger.
Zum Netzanschlua dieses Gerates ist eine geprufte Leitung zu verwenden.
Fur einen Nennstrom bis 6A und einem Gerategewicht groBer 3kg ist eine
Leitung nicht leichter als (1)H05VV-F, 3G, 0.75mm
2
(2)2X0.75 mm
2
conductors einzusetzen.
Die Steckdose muB nahe dem Gerat angebracht und leicht
zuganglich sein.
CAUTION!
This part is hot. Be Careful.
VORSICHT!
Diese Flache wird sehr heiss.
When you see this symbol, be careful as this spot may be very hot.
1-5
Ϯ
6
chapter 1 getting to know the basics
Notice
The information in this user’ s manual is subject to change without notice.
THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS
OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE
FOR ANY CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE
PERFORMANCE OR USE OF THIS MANUAL.
The information in this user’ s manual is protected by copyright laws. No part of this
manual may be photocopied or reproduced in any form without prior written
authorization from the copyright owners.
Copyright 3/2006
All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation. DOS,
Windows 95/98/ME/2000/NT/XP are trademarks of Microsoft Corporation.
Product names mentioned herein may be trademarks and/or registered trademarks
of their respective owners/companies.
The software described in this manual is delivered under a license agreement. The
software may be used or copied only in accordance with the terms of the agreement.
This product incorporates copyright protection technology that is protected by U.S.
patents and other intellectual property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
.
1-5
Rev 1.0
Ϯ
7
chapter 1 getting to know the basics
TABLE OF CONTENTS
PREFACE
Symbols and Conventions
Protecting Your Computer - Avoid Abusive Handling and Adverse
Environment
Chapter Summaries
1. GETTING TO KNOW THE BASICS
Performance Features (1-2)
Package Content (1-3)
System at a Glance (1-4)
Front View (1-4,5,6)
Rear View (1-7,8,9)
AC Adapter (1-10)
Using the Vertical Stand (1-11)
Connecting the System (1-12,13,14,15,16)
Audio Subsystem –How to Enable the DTS 7.1 Multi-channel
Surround Sound System (1-17,18)
Adjusting the Volume in Windows (1-19)
Voice Recording (1-19)
Ethernet Adapter (1-20)
2. BIOS SETUP AND SECURITY
Entering the BIOS Setup Screen (2-3)
Leaving the BIOS Setup Screen (2-3)
BIOS Action Keys (2-3)
Modifying the BIOS Settings (2-4)
Main Setup (2-4)
Boot Setup (2-4,5)
Security Setup (2-6)
Power Setup (2-7)
Exit Setup (2-8)
3. TROUBLE-SHOOTING
First Step (3-2,3)
1-5
Ϯ
8
chapter 1 getting to know the basics
Audio Problems (3-4)
Hard Disk Problems (3-5,6)
Optical Drive Problems (3-7)
Display Problems (3-8)
Keyboard and Mouse Problems (3-9)
CMOS Battery Problems (3-10)
Memory Problems (3-11)
Network Adapter / Ethernet Problems (3-12)
Performance Problems (3-13)
Firewire (IEEE1394) and USB2.0 Problems (3-14)
APPENDIX A Product Specification
APPENDIX B Agency Regulatory Notices
1-5
Ϯ
9
chapter 1 getting to know the basics
Preface
Using This Manual
This User’ s Manual contains general information about the
hardware and software setup, troubleshooting, and technical
specifications of the XPC computer.
Symbols and Conventions
The following conventions and symbols are used in this manual:
When keys are to be pressed at the same time, a plus (+)
symbol is used. For instance, Fn+F7 means holding Fn and
F7 keys at the same time.
When a series of clicking actions is needed in Windows O/S, [ ]
and > symbols are used. For instance, [Start > Settings >
Control Panel > Display] means clicking the Start icon first,
then the Settings, then the Control Panel, then the Display
icon.
When you need to make a selection with the touch pad (or
mouse), you will be asked to ’ select’ or ‘ click’ or ‘ double-c lick’,
‘right-click’ the item.
Note: Text in this format and symbol means specific instructions, commentary,
sidelights, or any additional information or notes that you should be aware of.
Warning: Text in this format and symbol means that failures to comply with the
given instructions or information could result in damage to your computer or could
cause bodily harm or loss of life.
1-5
Ϯ
0
chapter 1 getting to know the basics
Protecting Your Computer - Avoid Abusive Handling and
Adverse Environment
Follow the advice below will help ensure that you get the most out
of your Investment.
Your computer will serve you well if you take good care of it.
Do not expose the computer to direct sunlight or place it
near sources of heat.
o
Do not subject it to temperatures below 0
o
above 30
C (86oF).
C (32oF) or
Do not expose the computer to magnetic fields.
Do not expose the computer to moisture or rain.
Do not spill water or liquid on the computer.
Do not subject the computer to adverse shock and
vibration.
Do not expose the computer to dust and dirt.
Do not place objects on top of the computer to avoid
damaging the computer.
Do not place the computer on rocky surfaces.
Here are some ways of taking care of your AC adapter.
Do not connect the adapter to any devices other than
your computer.
Do not let water get into the adapter.
Do not block the ventilation airway of the adapter.
Keep the adapter in a cool and ventilated place.
Do not step on the power cord or place heavy objects on
top of it.
Carefully tuck away the power cord and any cables
away from pedestrian traffic.
1-6
Ϯ
chapter 1 getting to know the basics
When unplugging the power cord, do not pull on the cord
itself but pull on the plug.
Keep the adapter away from children.
The total ampere ratings of the equipment plugged in
should not exceed the ampere rating of the cord if you are using an
extension cord.
The total current rating of all equipment plugged into a
single wall outlet should not exceed the fuse rating.
Do not connect other AC adapter to your XPC. This XPC
uses exclusively the AC adapter:
Li-shin 0227A20120 (120W)
When cleaning the computer, observe these steps:
1. Power off the computer and remove the battery pack.
2. Disconnect the AC adapter.
3. Use a soft cloth dampened with water. Do not use liquid or
aerosol cleaners.
Contact your dealer or see your service technician if any of the
following occurs:
Computer has been dropped or the body has been
damaged.
Liquid has been spilled into the product.
The computer does not operate normally.
Cleaning the Ventilation Grills:
It is suggested that you clean the ventilation grills regularly to
maintain optimal thermal regulation of the XPC. To do this, you may
use a soft brush or a vacuum cleaner (with appropriate head
adapter) to remove the dust buildup on the ventilation grills.
1-61
Ϯ
2
A
chapter 1 getting to know the basics
Chapter Summaries
The following is a summary of the available chapters and
appendices in this manual.
Chapter 1: Getting to Know the Basics
In this chapter, you will learn the basic operations and features
of your computer. It gives you a general understanding of the
components of your computer.
Chapter 2: BIOS Setup / Security
In this chapter, you will learn how to change various firmware
settings and what the settings mean. Also, you will learn how to
take advantage of the built-in security feature provided by the
BIOS.
Chapter 3: Trouble-Shooting
In this chapter, you will learn how to solve common hardware
and software problems.
Appendix A: Product Specification
In this section, you will find a list of the computer’s system
specifications.
Appendix B: Agency Regulatory Notices
In this section, you will find the general electro-magnetic and
safety regulatory information.
This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
ny changes or modifications (including the antennas) made to this device that are not expressly
approved by the manufacturer may void the user’s authority to operate the equipment.
1-6
Loading...
