DATASHEET
2MP HD LightHunter IR Fixed Dome Network
Camera
IPC322SB-DF28(40)K-I0
Key Features
High quality imaging with 2MP, 1/2.8"CMOS sensor
2MP (1920*1080)@30/25fps; 720P (1280*720)@30/25fps
Ultra 265, H.265, H.264, MJPEG
LightHunter technology ensures ultra-high image quality in low illumination environment
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Alarm:1 in/1 out, Audio: 1 in/1 out
Smart IR, up to 30m (98ft) IR distance
Supports 256 G Micro SD card
IK10 vandal resistant
IP67 protection
Support PoE power supply
2
DATASHEET
Specifications
IPC322SB-DF28K-I0
IPC322SB-DF40K-I0
Camera
Sensor
1/2.8", 2.0 megapixel, progressive scan, CMOS
Lens
2.8mm@F1.6
4.0mm@F1.6
DORI Distance
Lens
(mm)
Detect (m)
Observe (m)
Recognize (m)
Identify (m)
2.8
43.4
17.4
8.7
4.3
4.0
62.1
24.8
12.4
6.2
Angle of View (H)
106.7°
87.5°
Angle of View (V)
57.1°
46.3°
Angle of View (O)
115.7°
92.4°
Adjustment angle
Pan: 3° ~ 360°
Tilt: 0° ~ 68°
Rotate: 3° ~ 360°
Shutter
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour:0.001 Lux (F1.6, AGC ON)
0Lux with IR
Day/Night
IR-cut filter with auto switch (ICR)
Digital Noise Reduction
2D/3D DNR
S/N
>52dB
IR Range
Up to 30m (98ft) IR range
Wavelength
850nm
IR On/Off Control
Auto/Manual
Defog
Digital Defog
WDR
120dB
Video
Video Compression
Ultra 265, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 2MP (1920*1080), Max 30fps; 720P (1280*720), Max 30fps;
Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max
30fps;CIF(352*288), Max 30fps;
Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Video Bit Rate
128 Kbps~16 Mbps
9:16 Corridor Mode
Supported
OSD
Up to 8 OSDs
Privacy Mask
Up to 4 areas
ROI
Up to 8 areas
Motion Detection
Up to 4 areas
White Balance
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital Noise Reduction
2D/3D DNR
Smart IR
Supported
Flip
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping
N/A
HLC
Supported
3
DATASHEET
BLC
Supported
Audio
Audio Compression
G.711
Two-way Audio
Supported
Suppression
Supported
Sampling Rate
8KHZ
Storage
Edge Storage
Micro SD, up to 256GB
Network Storage
ANR, NAS(NFS)
Network
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x,
SNMP, QoS
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API
Client
EZStation
EZView
EZLive
Web Browser
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Audio I/O
1 Input: impedance 35kΩ; amplitude 2V [p-p]
1 Output: impedance 600Ω; amplitude 2V [p-p]
Alarm I/O
1/1
Network
1 RJ45 10M/100M Base-TX Ethernet
Certifications
Certifications
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
Power
DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 5.0W
Dimensions (Ø x H)
Φ108.7 x 81.1mm (Ø4.3” x 3.2”)
Net Weight
0.42kg (0.93lb)
Material
Metal + Plastic
Working Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection
2KV
Ingress Protection
IP67
Vandal Resistant
IK10
Reset Button
Supported
4
DATASHEET
Dimensions
Accessories
TR-JB03-G-IN TR-JB07/WM03-G-IN TR-WM03-D-IN TR-UM06-E-IN TR-UP06-IN TR-A01-IN
TR-SE24-IN TR-SE24-A-IN TR-CM24-IN
5
DATASHEET
Junction Mount
Pole Mount
TR-JB03-G-IN
TR-JB07/WM03-G-IN
TR-UM06-E-IN
TR-JB07/WM03-G-IN+TR-UP06-IN
TR-CM24-IN+TR-JB03-G-IN
Zhejiang Uniview Technologies Co., Ltd.
Building No.10, Wanlun Science Park, Jiangling Road 88, Binjiang District, Hangzhou, Zhejiang, China (310051)
Email: overseasbusiness@uniview.com; globalsupport@uniview.com
http://www.uniview.com
© 2020 Zhejiang Uniview Technologies Co., Ltd. All rights reserved.
*Product specifications and availability are subject to change without notice.
