Uniview IPC2324SB-DZK-I0 DATASHEET

DATASHEET

IPC2324SB-DZK-I0

Camera

Sensor

1/3", 4.0megapixel, progressive scan, CMOS

Lens

2.7 ~ 13.5mm, AF automatic focusing and motorized zoom lens

4MP HD LightHunter IR VF Bullet Network Camera

IPC2324SB-DZK-I0

Key Features

High quality image with 4MP, 1/3"CMOS sensor

4MP (2688*1520)@30/25fps; 4MP (2560*1440)@30/25fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps;

Ultra 265, H.265, H.264, MJPEG

LightHunter technology ensures ultra-high image quality in low illumination environment

120dB true WDR technology enables clear image in strong light scene

Support 9:16 Corridor Mode

Alarm:1 in/1 out, Audio: 1 in/1 out

Smart IR, up to 50m (164ft) IR distance

Supports 256 G Micro SD card

IK10 vandal resistant

IP67 protection

Support PoE power supply

Specifications

2

DATASHEET

DORI Distance

Lens (mm)

Detect (m)

Observe (m)

Recognize (m)

Identify (m)

2.7

60.8

24.3

12.2

6.1

13.5

303.8

121.5

60.8

30.4

Angle of view (H)

98.26°~ 31.35°

Angle of View (V)

54.76°~ 18.55°

Angle of View (O)

127.74°~36.99°

Adjustment angle

Pan: 0° ~ 360°

Tilt: 0° ~ 90°

Rotate: 0° ~ 360°

Shutter

Auto/Manual, shutter time: 1 ~ 1/100000s

Minimum Illumination

Colour: 0.001Lux (F1.2, AGC ON)

0Lux with IR on

Day/Night

IR-cut filter with auto switch (ICR)

S/N

>56 dB

IR Range

Up to 50m (164ft) IR range

Wavelength

850nm

IR On/Off Control

Auto/Manual

Defog

Digital Defog

WDR

120dB

Video

Video Compression

Ultra 265, H.265, H.264, MJPEG

H.264 code profile

Baseline profile, Main profile, High profile

Frame Rate

Main Stream: 4MP (2688*1520), Max 30fps;4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 25fps; 1080P
(1920*1080), Max 30fps;

Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps;
CIF(352*288), Max 30fps;

Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;

Video Bit Rate

128 Kbps~16 Mbps

9:16 Corridor Mode

Supported

OSD

Up to 8 OSDs

Privacy Mask

Up to 4 areas

ROI

Up to 8 areas

Motion Detection

Up to 4 areas


White Balance

Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2

Digital Noise Reduction

2D/3D DNR

Smart IR

Support

Flip

Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise

Dewarping

Support

HLC

Support

BLC

Support

Audio

Audio Compression

G.711

Two-way Audio

Supported

Suppression

Supported

Sampling Rate

8KHZ
