DATASHEET
4MP VF Network IR Bullet Camera
Day/night functionality
Smart IR, up to 30m (98ft) IR distance
IR anti-reflection window to increase the infrared transmittance
2D/3D DNR (Digital Noise Reduction)
Ultra 265, H.265, H.264, MJPEG
Triple streams
ONVIF Conformance
Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
Wide voltage range of ±25%
IPC2324LBR3-SP(Z28)-D
Key Features
Optics
Compression
Network
Structure
2
DATASHEET
IP67
3-Axis
Specifications
IPC2324LBR3-SP-D
IPC2324LBR3-SPZ28-D
Camera
Sensor
1/3", 4.0 megapixel, progressive scan, CMOS
Lens
2.8 ~ 12mm, manual zoom lens
2.8 ~ 12mm, motorized zoom lens
DORI Distance
Lens (mm)
Detect (m)
Observe (m)
Recognize (m)
Identify (m)
2.86325.2
12.6
6.3
12
270
1085427
Angle of View (H)
91.0° ~ 27°
Angle of View (V)
54.4° ~ 13.7°
Angle of View (O)
118.3° ~ 33.2°
Adjustment angle
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotate: 0° ~ 360°
Shutter
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour: 0.01Lux (F1.6, AGC ON)
0Lux with IR on
Digital noise reduction
2D/3D DNR
Day/Night
IR-cut filter with auto switch (ICR)
S/N
>52dB
IR Range
Up to 30m (98ft) IR range
Wavelength
850nm
IR On/Off Control
Auto/Manual
Defog
Digital Defog
WDR
DWDR
Video
Video Compression
Ultra 265, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main Profile
Frame Rate
Main Stream: 4MP (2592*1520), Max 20fps;
Sub Stream:720P (1280*720), Max 20fps;
Third Stream: D1 (704*576), Max 20fps
Video Bit Rate
128 Kbps~16 Mbps
OSD
Up to 4 OSDs
Privacy Mask
Up to 4 areas
ROI
Up to 2 areas
Motion Detection
Up to 4 areas
White Balance
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction
2D/3D DNR
Smart IR
Support
Flip
Normal/Vertical/Horizontal/180°
Dewarping
NA
3
DATASHEET
HLC
Supported
BLC
Supported
Storage
Edge Storage
Micro SD, up to 256 GB
Network Storage
ANR
Network
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API
Client
EZStation
EZView
EZLive
Web Browser
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Network
1 RJ45 100M Base-TX Ethernet
Certifications
Certifications
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
Power
DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 7W
Dimensions (L × W × H)
240.3 × 86.4 × 75.6mm (9.46” × 3.4” × 2.98”)
Net Weight
1kg (2.2lb)
Material
metal
Working Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection
6KV
Ingress Protection
IP67
Dimensions
4
DATASHEET
Accessories
Junction Mount
Pole Mount
TR-JB07-D-IN(TR-JB06-A-IN)+ TR-UP06-C-IN
TR-UP06-B-IN
TR-JB07-D-IN TR-JB06-A-IN TR-UP06-B-IN TR-UP06-C-IN TR-A01-IN
Zhejiang Uniview Technologies Co., Ltd.
Building No.10, Wanlun Science Park, Jiangling Road 88, Binjiang District, Hangzhou, Zhejiang, China (310051)
Email: overseasbusiness@uniview.com; globalsupport@uniview.com
http://www.uniview.com
©2020 Zhejiang Uniview Technologies Co., Ltd. All rights reserved.
*Product specifications and availability are subject to change without notice.
