DATASHEET
4MP SD Card Mini Fixed Bullet Network Camera
IPC2124SS-ADF28(40)KM
Key Features
High quality image with 4MP, 1/3"CMOS sensor
4MP (2688*1520)@30/ 25fps; 4MP (2560*1440)@ 30/25fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps;
Ultra 265, H.265, H.264, MJPEG
LightHunter technology ensures ultra-high image quality in low illumination environment
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic
Smart IR, up to 40m (131ft) IR distance
Support 256 G Micro SD card
IP67 protection
Support PoE power supply
2
DATASHEET
Specifications
IPC2124SS-ADF28KM
IPC2124SS-ADF40KM
Camera
Sensor
1/3", 4.0 megapixel, progressive scan, CMOS
Lens
2.8mm@F1.6
4.0mm@F1.6
DORI Distance
Lens (mm)
Detect (m)
Observe (m)
Recognize (m)
Identify (m)
2.8
63
25.2
12.6
6.3
4.0
90
36
18 9 Angle of View (H)
107.8°
82°
Angle of View (V)
57.0°
41.6°
Angle of View (O)
140.1°
100.9°
Adjustment angle
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotate:0° ~ 360°
Shutter
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour: 0.003Lux (F1.6, AGC ON)
0Lux with IR on
Day/Night
IR-cut filter with auto switch (ICR)
S/N
>52dB
IR Range
Up to 40m (131ft) IR range
wavelength
850nm
IR On/Off Control
Auto/Manual
Defog
Digital Defog
WDR
120dB
Video
Video Compression
Ultra 265, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main Profile, High Profile
Frame Rate
Main Stream: 4MP (2688*1520), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 2MP
(1920*1080), Max 30fps;
Sub Stream: 2MP (1920*1080), Max 30fps;
Third Stream: D1 (720*576), Max 30fps
Video Bit Rate
128 Kbps~16 Mbps
9:16 Corridor Mode
Support
OSD
Up to 8 OSDs
Privacy Mask
Up to 8 areas
ROI
Up to 8 areas
Motion Detection
Up to 4 areas
White Balance
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction
2D/3D DNR
Smart IR
Support
Flip
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping
Support
HLC
Support
BLC
Support
DATASHEET
Storage
Edge Storage
Micro SD, up to 256GB
Network Storage
ANR
Network
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x,
SNMP, QoS, NAS
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API
Client
EZStation
EZView
EZLive
Web Browser
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Built-in Mic
Support
Network
1 RJ45 10M/100M Base-TX Ethernet
Certifications
Certifications
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
Power
DC 12V±25%,PoE (IEEE 802.3af)
Power consumption: Max 5.0W
Dimensions (L × W × H)
155.9 × 63.1 × 62.7mm (6.1” ×2.5” × 2.5”)
Net Weight
0.43kg (0.94lb)
Material
Metal
Working Environment
-35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment
-35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
surge protection
2KV
Ingress Protection
IP67
Reset Button
Support
4
DATASHEET
Dimensions
Accessories
TR-JB05-A-IN TR-A01-IN TR-UP06-B-IN TR-UP06-C-IN
Zhejiang Uniview Technologies Co., Ltd.
Building No.10, Wanlun Science Park, Jiangling Road 88, Binjiang District, Hangzhou, Zhejiang, China (310051)
Email: overseasbusiness@uniview.com; globalsupport@uniview.com
http://www.uniview.com
© 2020 Zhejiang Uniview Technologies Co., Ltd. All rights reserved.
*Product specifications and availability are subject to change without notice.
