DH-IBVL-7550W
> 1/2.8" 2.4 Megapixel SONY CMOS
> 30fps @ 1080P
> 0.0 Lux with IRs On
> AGC, ATW, BLC, True WDR(via OSD Menu)
> Built-in IR LEDs (300ft IR Distance)
> 5-50mm Vari-Focal Lens
> IP66, Water-Resistant Housing, DC12V
> Separate BNC Outputs for Analog & HD-CVI
Model
DH-IBVL-7550W
IP Rating
IP66
Image Sensor
1/2.8” 2.4 Megapixel SONY CMOS
Horizontal Resolution
NTSC: 1920(H)X1080(V)
Frame Rate
30fps@1080P
Minimum Illumination
0.0 Lux (with IRs ON)
Lens
5-50mm Vari-Focal Lens
S/N Ratio
MORE THAN 50dB
IR LEDs
6 Array IR LEDs
IR Distance
300ft Depending on Scene Reflectance
Video Standard
NTSC
Electronic Shutter
Auto: 1/60 ~ 1/30,000s
OSD Control
On-Screen Display Menu (Languages, Privacy Area, Color, etc.)
Digital Noise Reduction
2D DNR
White Balance
Auto / Manual
Wide Dynamic Range
True WDR
Video Output
Separate 75 Ohm BNC Outputs for Analog & HD-CVI
Power Supply
DC 12V, Max 10W
Operating Temperature
-20℃ ~ 50℃ (-4℉ ~ 122℉)
Dimensions, Weight
3.19” (H) x 11.1” (L), 3.4 lbs.
