Universal Remote Control RFTX-1 Installation Manual

Order Number : GETEC-C1-09-089 FCC Part 15 subpart C Test Report Number : GETEC-E3-09-042 Page 1 / 1
EUT Type: RF Transmitter
FCC ID.: OZ5URCRFTX1
APPENDIX I
: USER’S MANUAL
RFTX-1 Installation Manual
RFTX-1 Installation Manual ©2009 Universal Remote Control, Inc.
The information in this manual is copyright protected. No part of this man­ual may be copied or reproduced in any form without prior written con­sent from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL.
The Home Theater installation on the cover was designed and installed by Stone-Glidden of King of Prussia and Doylestown, PA.
The information in this manual may be subject to change without prior notice.
Complete Control is a registered trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks of their respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
T
ABLE OF CONTENTS
Introduction 1
Parts Guide 2
Installation 2
Specifications 2
USA Limited Warranty Statement 3
FCC Interference Statement 4
Page 1
RFTX-1 BASE STATION
Introduction
The RFTX-1 is a Narrow Band transmitter for IP or Z Band base stations. It’s purpose is to transmit standard narrow band RF to URC Lighting controls.
3. The RFTX-1 transmits the code pat­terns sent by the MRZ-260 which oper­ates the lights via 418MHz (required for all URC lighting with an MRFA designa­tion) or 433MHz Narrow Band (required for all URC lighting with an MRFB desig­nation).
2. The MRZ-260 receives the Z Band signals of the MX-880Z and outputs the code patterns to the RFTX-1.
1. The MX-880Z sends Z Band radio waves in every direction, so you don’t have to point the remote any­more!
Page 2
RFTX-1 BASE STATION
Parts Guide
The RFTX-1 RF Base Station includes:
Installation
1. Plug the RFTX-1 into the RFTX jack of the IP or ZBand base station. The Red Power LED should light.
2. Select either the 418 or 433.92 band utilizing the switch on the side of the RFTX-1.
3. Place the RFTX-1 in a location away from microprocessor based AV compo-
nents and any metal walls or structure.
Note: The RF LED will light whenever the RFTX-1 transmits.
Specifications
RF Range (radio frequency): 50 to 100 feet, depending upon the environment RF Frequency: 418MHz or 433.92 MHz (User Selectable) Weight: 2.9 ounces Size: 1.5” H x 2.25” W x .45” D
1 - RFTX-1 Transmitter 2 - Mounting Plate for wall mounting the RFTX-1 3 - Screws for wall mounting 4 - Cable for connecting to the MRZ-260.
Page 3
RFTX-1 BASE STATION
USA Limited Warranty Statement
Your Universal Remote Control, when delivered to you in new con­dition, is warranted against defects in materials or workmanship as follows: UNIVERSAL REMOTE CONTROL, INC. warrants this prod­uct against defects in material or workmanship for a period of one (1) year and as set forth below. Universal Remote Control will, at its sole option, repair the product using new or comparable rebuilt parts, or exchange the product for a comparable new or rebuilt product. In the event of a defect, these are your exclusive remedies.
This Limited Warranty covers only the hardware components pack­aged with the Product. It does not cover technical assistance for hardware or software usage and it does not cover any software products whether or not contained in the Product; any such soft­ware is provided "AS IS" unless expressly provided for in any enclosed software Limited Warranty.
To obtain warranty service, you must deliver the product, freight prepaid, in its original packaging or packaging affording adequate protection to Universal Remote Control at the address provided in the Owner's Manual. It is your responsibility to backup any macro programming, artwork, software or other materials that may have been programmed into your unit. It is likely that such data, soft­ware, or other materials will be lost during service and Universal Remote Control will not be responsible for any such damage or loss. A dated purchase receipt, Bill of Sale, Installation Contract or other verifiable Proof of Purchase is required. For product support and other important information visit Universal Remote Control's website: http://www.UniversalRemoteControl.com or call the Universal Remote Control Customer Service Center (914) 835-
4484.
This Limited Warranty only covers product issues caused by defects in material or workmanship during ordinary consumer use. It does not cover product issues caused by any other reason, including but not limited to product issues due to commercial use, acts of God, third-party installation, misuse, limitations of technology, or modifi­cation of or to any part of the Universal Remote Control product. This Limited Warranty does not cover Universal Remote Control products sold as USED, AS IS, REFURBISHED, so-called "B STOCK" or consumables (such as batteries). This Limited Warranty is invalid if the factory-applied serial number has been altered or removed from the product. This Limited Warranty is valid only in the United States of America. This Limited Warranty specifically excludes products sold by unauthorized resellers.
Page 4
RFTX-1 BASE
STATION
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digi­tal device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or tel­evision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the following meas­ures:
Reorient or relocate the receiving antenna.Increase the separation between the equipment and receiver.Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning!
Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment. Note : The manufacturer is not responsible for any Radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for com­pliance could void the authority to operate equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
www.universalremote.com
OCE-0071A Rev.01
