Universal Remote UR5U-8780L, UR5U-8790L Operating Manual
CBL-IPTV
Manufacturer/Brand
Set-Up Code Number
CBL-CABLE Converters
Manufacturer/Brand
Set-Up Code Number
*Note : To return TV device to CBL channel
repeat steps above replacing [TV] with
[CBL] in Step 3.
I. Programming a ‘Macro’ button.
If your remote model has custom-programmable
Macro buttons available(See Section 4), they
can be programmed to act as a ‘Macro’ or
Favorite Channel button in CABLE mode. This
allows you to program up to five 2-digit channels,
four 3-digit channels or three 4-digit channels
that can be accessed with one button press.
STEP1
Press the [CBL] button to select the CBL
mode.
STEP2
Press the [MACRO] button and
[OK/SEL] button simultaneously for 3
seconds. The [CBL] button will turn
on for 30 seconds.
STEP3
Enter the the 2, 3 or 4-digit code for the
channel you want programmed first (for
example, 007) using the Number Pad,
then press the [STOP] button. Then
enter the code for the next channel (for
example, 050), then press the [STOP]
button. Repeat this process for the third
channel. The [CBL] button will blink
once for each channel entered.
STEP4
Press the [CH5] button to store the
channels that were selected. The
[CBL] button will blink twice to confirm
the storage of commands.
To access the programmed channels, press
the [MACRO] button once. This will bring up
the first channel. Press once again and it will
bring up the second channel. Press again and
it will bring up the third channel.
J Low Battery Warning
When the batteries are low and need to be
replaced with fresh batteries, the Device LED
lights will blink 2 times in sequence whenever a
[POWER] button is pressed to turn on equipment.
K. Memory Lock System
This remote control is designed to retain programmed memory for 10 years even after batteries are removed from the remote control.
L. Record Your Component Set-up Codes
TV Set-up Code Number:
VCR Set-up Code Number:
DVD Set-up Code Number:
AUX Set-up Code Number:
For additional information about your remote
control, go to www.universalremote.com
A. Quick Setup Method
It’s easy to program the remote control to operate your TV. Simply press the number buttons 0
through 9 that your TV brand is assigned to
using the following four steps.
STEP1
Manually turn on the TV you wish to
program.
STEP2 Press and hold simultaneously for 3
seconds both the TV and A (Yellow)
buttons or B (Blue) buttons, based
on the column your TV brand is
assigned to. The TV button LED light
will turn on for 30 seconds confirming that you are in the program
mode.
STEP3
While the TV button LED is on, point
the remote control at the TV and
press the number button assigned to
your TV brand as shown in the table
(e.g. for Sharp TV, button 5 ). The TV
should turn off. If it does not, press the
same number button repeatedly until
the TV turns off.
*Note : The remote will exit the programming
mode automatically if it does not have
matching codes and the LED will turn off.
STEP4
Once the TV has turned off, press the
TV button once again to save the
code. The remote control is now
ready to control your TV.
Repeat the above steps for all other components (TV, VCR, DVD, etc.).
*Note : If the matching code could not be found in
STEP3, use 3-Digit Code Method or Auto
Search Method.
Quick Set-up Code Tables
Cable Remote Control
Operating Instructions For
CLIKR
TM
-5
Universal Remote Control, Inc.
www.universalremote.com
OCE-0060L REV 22 (10/22/18)
1
Introduction
4
Button Functions
5
Programming the Remote Control
2
Replacing Batteries
3
Operations
The CLIKRTM-5 UR5U-8780L & UR5U-8790L is
designed to operate the CISCO / SA, Pioneer,
Pace Micro, Samsung and Motorola digital
set tops, Plus the majority of TV, VCR, DVD
and AUX equipment on the market as
shown below.
B. 3-Dight Code Method
STEP1
Turn on the equipment that you want
the remote control to operate (Cable
Box, TV, VCR, DVD, etc.).
STEP2
Press the [DEVICE] button and the
[OK/SEL] button simultaneously for
three seconds. The corresponding
device LED will turn on indicating that
it is ready to be programmed. The LED
will remain on for 30 seconds. The
next step must be entered while the
LED is on.
STEP3
Point the remote control toward the
equipment and enter the three-digit
code number assigned to your brand
from the code tables. If there are more
than one three-digit number listed for
your brand, try one code number at a
time until your equipment turns off.
*Note : You can verify that you have selected the
correct code by pressing the [POWER]
button. The equipment should turn back
on. Then try all of the functions on the
remote control (i.e. volume, mute, etc.) to
ensure you have the correct code. If any
of the functions do not operate as they
should, repeat the instructions from
STEP 3 above using the next three digit
code number from the brand list.
STEP4
Store the three-digit code by pressing
the same [DEVICE] button once
again. The device LED will blink twice
to confirm that the code has been
stored.
C. Auto Search Method
If none of the three digit code numbers
assigned to your brand of equipment works, or
the code table does not list your brand, you can
use the Auto Search Method to find the correct
three-digit code number for your equipment by
following steps:
STEP1
Turn on the equipment that you want
the remote control to operate (Cable
Box, TV, VCR, DVD, etc.).
STEP2
Press the [DEVICE] button and the
[OK/SEL] button simultaneously for
three seconds. The device LED will
turn on indicating that it is ready to be
programmed. The LED will remain on
for 30 seconds. The next step must be
entered while the LED is on.
STEP3
Press the [CH5] or [CH6] button one
at a time or keep it pressed. The
remote will emit a series of Power
ON/OFF code signals. Release the
[CH5] or [CH6] button as soon as the
equipment turns off.
*Note : You can verify that you have selected the
correct code by pressing the [POWER]
button. The equipment should turn back
on. Then try all of the functions on the
remote control (i.e. volume, mute, etc.) to
ensure you have the correct code. If any of
the functions do not operate as they should,
repeat the instructions from STEP 3 above
to continue the Auto Search Method.
STEP4
Press the same [DEVICE] button to
store the code. The Device LED will
blink twice to confirm that the code
has been stored.
D. To Identify the 3-Digit Code
Programmed for a Device
STEP1
Press the appropriate [DEVICE] button
and the [OK/SEL] button simultaneously
for three seconds. The device LED will
turn on for 30 seconds. The next step
must be performed while the LED is on.
STEP2
Press the [INFO] button. The device LED
will blink a number of times indicating
the number of each digit for the code.
Each digit is separated by a one second
interval of the LED being off.
Example : One blink, (pause) three blinks,
(pause) eight blinks indicates the
code number 138.
*Note : Ten blinks indicates the number 0.
E. Programming the AUX Device
You can take advantage of the AUX function to
program a devices such as a media PC, gaming console or satellite radio receiver. Follow
the instruction in section B to program an AUX
device. You can also program the AUX button
for a second TV, VCR or DVD player. To do this
follow the instructions below.
STEP1
Turn on the 5th device you want to
program (TV, VCR, DVD, etc.).
STEP2
Press the [AUX] button and the
[OK/SEL] button simultaneously for 3
seconds. The [AUX] device LED will
turn on for 30 seconds.
STEP3
Press the [Device] button For the type of
device you want to setup. Point the
remote control toward the device and
enter the 3-digit code number assigned
to your brand.
*Note : To program a second TV press TV, etc.
STEP4
When the equipment turns off verify
that you have selected the correct
code by pressing the [POWER] button.
The equipment should turn back on.
Then try all of the functions on the
remote control (i.e. volume, mute, etc.)
to ensure you have the correct code.
If any of the functions do not operate
as they should, enter the next 3-digit
code number from the brand list.
STEP5
Once you have found the correct
3-digit code, save it by pressing the
[AUX] button one more time. The [AUX]
LED light will blink twice to confirm the
code was stored.
F. Programming the System
On/Off Button
This allows you to program the System On/Off
button so it can send up to five power On/Off
commands with one button press.
STEP1
Press the [CBL] button.
STEP2
Press the [SYSTEM ON/OFF] button
and the [OK/SEL] button simultaneously
for 3 seconds. The [CBL] button will turn
on for 30 seconds.
STEP3
Press the first [DEVICE] button you want
to store in the [SYSTEM ON/OFF] button
and then press [POWER]. Repeat this for
the other components you want to turn
on/off with the [SYSTEM ON/OFF] button.
STEP4
Press the [CH5] button to save the
power commands you stored. The
[CBL] button will blink twice to confirm
the commands have been saved.
G. Programming Volume Control
Volume and Mute control are factory programmed
to automatically transfer to the respective Device
mode You select, as follows:
CBL :TV T V :TV VCR :TV
DVD :TV AUX :AUX
If you wish to store the CBL volume control in
CBL mode, use the following steps.
STEP1
Press the [OK/SEL] button and [CBL]
button simultaneously for three
seconds. The device LED will turn on
for 30 seconds. The next step must
be performed while the LED is on.
STEP2
Press the [VOL5] button. The device
LED will blink.
STEP3
Press [CBL] button. The device LED will
blink twice to confirm the programming.
*Note : To return CBL device to TV volume
repeat steps above replacing [CBL]
with [TV] in Step 3.
H. Programming Channel Control
You can program the channel controls (Channel
Up, Channel Down, Last and Numbers) from
one Device to operate in another Device mode.
Default channel control settings on the remote
control are as follows:
CBL : CBL T V : CBL VCR : CBL
DVD :DVD AUX : AUX
If you wish to store the TV channel controls in
TV mode, use the following steps.
STEP1
Press the [OK/SEL] button and [TV] button
simultaneously for three seconds. The
device LED will turn on for 30 seconds.
The next step must be performed while
the LED is on.
STEP2
Press the [VOL6] button. The device
LED will blink.
STEP3
Press [TV] button. The device LED will
blink twice to confirm the programming.
Before you program or operate the remote control,
you must install two new AA alkaline batteries.
STEP1 Remove the battery compartment cover
on the back of your remote control.
STEP2 Check battery polarity carefully, and
install the batteries as shown in the
illustration below.
STEP3 Replace the battery compartment cover.
CBL : Cable Set-top Box TV : Televisions
VCR : VCRs and TV/VCRs DVD : DVD Players
AUX : Audio Equipment, Media PC, etc.
0 RCA
1 SAMSUNG
2 SONY
3LG
4 VIZIO
5 SHARP
6 PANASONIC
7 SANYO
8 TOSHIBA
9 PHILIPS
0 COBY
1 MITSUBISHI
2 HITACHI
3 MAGNAVOX
4 JVC
5 ZENITH
6 INSIGNIA
7 EMERSON
8 WESTINGHOUSE
9TCL
TV
Manufacturer/Brand
Set-Up Code Number
CENTURION 116
CETRONIC 043
CHANGHONG 247
CIELO 714
Ciil 732
CITIZEN 116 002 003 363 043 258 143
CLARION 043
CLASSIC 043
CLP CLASSIC 333
COBY 640 641 671 363
COLORTYME 116
CONCERTO 363
CONCIERGE 073
CONTEC 043 050 051
Continu-us 161 746 747
CORNEA 116
CORONADO 143
CRAIG 043 054
CROSLEY 164
CROWN 043 143
CURTIS MATHES 116 258 363 143
CXC 043
CYBERHOME 015
DAEWOO 363 043 076 143
DAYTRON 363 143
DELL 320 164 363 618
DIGITAL PROJECTION 570
DIMENSIA 333
DREAMVISION 235
DUKANE 011
DUMONT 116 073
DURABRAND 096 052
DWIN 257
DYNASTY 043
DYNEX 400
EIKI 187
ELECTROBAND 001
ELECTROGRAPH 466
ELECTROHOME 143 024 076
ELEKTRA 072
ELEMENT 363 494 526 622 690
EMERSON 028 048 043 116 363 050 051 076 096 143 154 052 514
ENVISION 116
EPSON 324 590
ESA 323
Evervue 755
FISHER 007 057
FREEMOTION 688
FUJITSU 246 198 410
FUNAI 028 043 052
FUSION 642
FUTURETECH 043
GATEWAY 242 268
GE 073 116 008 009 034 056 333 363
GEM 391
GIBRALTER 116 073
GO VIDEO 026
GOLDSTAR 113 116 102 363 112 143
GPX 674
GRUNPY 028 043
HAIER 363 501 623 749
HALL MARK 363
HANNSPREE 349 381
HARLEY DAVIDSON 028
HARVARD 043
HELLO KITTY 076
HIMITSU 043
HISENSE 419 442 619 630 631 363 752
HITACHI 011 166 009 143 072 363 250 587 613 670 749
HP 378 316 327 421
HUMAX 518
HYPERION 609
HYUNDAI 337 338
ILO 472 399
INFINITY 164
INFOCUS 333 230 547 548 470 532 564 595 733
UR5U-8780L & UR5U-8790L
DEFAULT STATE:
Device Default: Cable Set-Top Box (STB)
Channel Default: CABLE channel and numbers
through the CABLE STB. You have the option of
controlling your CABLE channel and numbers
through the TV or VCR. Refer to section H for
programming steps.
Volume Default: Volume and Mute control are
automatically transferred to the respective
Component based on the Device selected:
CBL:TV ; TV:TV ; VCR:TV. DVD:TV ; AUX:AUX.
You have the option of controlling CABLE
Volume and Mute through the TV, VCR or
AUX. Refer to section G for programming
steps.
IMPORTANT SETUP NOTE!
In this section when you are instructed to press a [DEVICE] button, that means to press either the CBL, TV, VCR,
DVD or AUX button, depending on what device you are programming the remote to operate.
There are three ways you can program your remote:
* Quick Setup Method
* 3-Digit Code Method
* Auto Search Method
Quick Setup Method is a unique feature that enables the fastest and easiest setup by using a one digit code. This
is the quickest way to set up devices made by popular manufacturers.
3-Digit Code Method allows you to setup by entering 3-digit code numbers that correspond with the components manufacturer/brand. Code tables for this method are on the backside of the operating instructions.
Auto Search Method scans through all of the codes in the remote control, one at a time allowing you to identify the correct code.
IMPORTANT SETUP NOTE!
This pertains to all programming steps. When you are in setup mode the device LED will light for 30 seconds. If you do
not press a button within 30 seconds, the LED light will turn off and exit setup mode, and you will need to start over.
TV
Manufacturer/Brand
Set-Up Code Number
6
Setup Code Tables
MOTOROLA 002 148 206
PACE 001 005 002 206 217
PIONEER 001 103 034 051 063 076 105
SAMSUNG 001 030
SCIENTIFIC ATLANTA/CISCO
001 003 041 042 045 046
Amino 219
ARRIS 172 216
Cincinnati Bell 220
Cox Digital Cable 223
Digital Multimedia Technology
222
Duoson 218
Entone 221
EVOLUTION 189 215
Foxtel 228
Horizon 225
Layer3 226
Pico Digital 224
Sky 240 241
TECHNICOLOR 365
WINDSTREAM 212
ZeeVee 227
ADB 254
AMINO 260
ENTONE 213
MOTOROLA 253
A MARK 112 143
ACCURIAN 036
ADMIRAL 072 251 333
AD NOTAM 672
ADVENT 247 388
ADVENTURA 002
AFFINITY 680
AKAI 116 248 404 405 473 475 323 387 391 615
ALBATRON 017
ALERON 028
AMERICA ACTION 043
AMPRO 073
AMSTRAD 052
ANAM 043 054 056 080 112
AOC 116 363 112 616
APEX 572
APEX DIGITAL 006 724
AQUAVISION 573 574 686
ASTAR 477
AUDIOVOX 076 454 388
AUVIO 689
AVENTURA 052
Avera 761
AVIELO 627 628
AVION 441
AXESS 711
AXION 039
BELCOR 116
BELL&HOWELL 333 072
BENQ 423 600
BOXLIGHT 266
BRADFORD 043
BROCKWOOD 116
BROKSONIC 238
BYDESIGN 031 032
CANDLE 116 002 003 363
CARY AUDIO DESIGN 266
CELEBRITY 001
TV&A
Button
TV&B
Button
VCR
0 MITSUBISHI
1HP
2 PHILIPS
3 JVC
4 SAMSUNG
5 PANASONIC
6 PHILIPS MAGNAVOX
7 TOSHIBA
8 PIONEER
9LG
VCR&A
Button
DVD
0 HITACHI
1 SONY
2 PHILIPS
3 SAMSUNG
4 PHILIPS MAGNAVOX
5 PANASONIC
6LG
7 JVC
8 DENON
9 PIONEER
AUX
0 BOSE
1HP
2 ONKYO
3 APPLE / iPod
4 MICROSOFT / XBOX
5 SONY / PS2
6 LUTRON
7 X-10
8 YAMAHA
9 ROKU
DVD&A
Button
AUX&A
Button
TV
Button Press
Button Number
Brand
Button Press
Button Number
Brand
Button Press
Button Number
Brand
Button Press
Button Number
Brand
MEMORY BUTTONS
They’ve been programmed by the Cable MSO
to provide quick access to the most popular channels.
F
TRANSPORT KEYS
AUX-DVR(TIVO)
Manufacturer/Brand
Set-Up Code Number
AUX-Media PCs
Manufacturer/Brand
Set-Up Code Number
AUX-AUDIO
Manufacturer/Brand
Set-Up Code Number
DVD-TV/DVD Combos
Manufacturer/Brand
Set-Up Code Number
DVD-DVD Recorders
Manufacturer/Brand
Set-Up Code Number
AUX-iPod Controls
Manufacturer/Brand
Set-Up Code Number
DVD-DVD/VCR Combos
Manufacturer/Brand
Set-Up Code Number
DVD-Blu-ray & HD DVD
Manufacturer/Brand
Set-Up Code Number
AUX-SOUNDBAR
Manufacturer/Brand
Set-Up Code Number
AUX-Tuners & Satellite Radios
Manufacturer/Brand
Set-Up Code Number
AUX-Digital to Analog Converter box
Manufacturer/Brand
Set-Up Code Number
AUX-Lighting Controls
Manufacturer/Brand
Set-Up Code Number
AUX-Gaming Systems
Manufacturer/Brand
Set-Up Code Number
AUX-Home Theater Systems
Manufacturer/Brand
Set-Up Code Number
AUX-AUDIO
Manufacturer/Brand
Set-Up Code Number
DVD-TV/DVD/VCR Combos
Manufacturer/Brand
Set-Up Code Number
VCR-TV/VCR Combos
Manufacturer/Brand
Set-Up Code Number
TV-Projectors
Manufacturer/Brand
Set-Up Code Number
TV-Projection TVs
Manufacturer/Brand
Set-Up Code Number
TV
Manufacturer/Brand
Set-Up Code NumberTVManufacturer/Brand
Set-Up Code Number
TV-LCD & Plasma TVs
Manufacturer/Brand
Set-Up Code Number
TV-LCD & Plasma TVs
Manufacturer/Brand
Set-Up Code Number
VCR
Manufacturer/Brand
Set-Up Code Number
DVD
Manufacturer/Brand
Set-Up Code Number
INITIAL 282
INSIGNIA 350 400 052 164 403 454 457 604 617
INTEQ 073
JANEIL 002
JBL 164
JCB 001
JCPENNEY 024 116 008 009 030 065 258 143 333 363
JVC 038 034 001 199 210 533 581 639 406 668 701
KAWASHO 116 001
KEC 043
KENWOOD 116 001
KLEGG 466
KLOSS 002
KMC 143
KNOLL SYSTEMS 230 659
KONKA 457
KREISEN 530
KTV 043 116 143 154
KURAZAI 072
LG 363 113 116 102 112 143 569 284 648 741
LITEON 268
LODGENET 072
LOEWE 164 738
LOGIK 072
LUXMAN 363
LXI 166 007 138 052 251 333 164
MAGNAVOX 164 116 003 363 333 226 390 467 431 594
MAJESTIC 333 072
MARANTZ 116 164 281 562 584
MATSUI 164
MATSUSHITA 080
MAXENT 242
MEGATRON 116 011
MEMOREX 007 072 363
MGA 116 363 024 028
MIDLAND 333 073
MINTEK 362
MINUTZ 008
MISAKAI 052
MITSUBISHI 124 109 024 028 363 348 450 658
MONIVISION 017
MONTGOMERY WARD 333 072
MOTOROLA 081
MTC 116 363 258
MULTITECH 043
NAD 138
NEC 272 197 116 024 056 019 262 236 281 575 717 758
NET TV 242
NEXUS 620 454
NIKEI 043
NIKKO 116
NIKO 527
NORCENT 390
NUVISION 351 567
OLEVIA 432 363 333
ONKING 043
ONWA 043
OPTOMA 265 249
OPTONICA 019 251
ORION 096
PANASONIC 080 034 056 164 208 359 552 524 607 664
PEERLESS-AV 723 763
PHILCO 116 003 164 363 024 056
PHILIPS 164 038 116 003 363 206 431 333 161 594 629 727 773
PILOT 116
PIONEER 234 116 393 272 520 582 660
PLANAR 728 742 787 788
POLAROID 388 323 328 353 354 355 356 494 387 391 505 506 508
526
PORTLAND 363 143
PRINCETON 004
PRISM 034
PROSCAN 333 722
PROTON 363 112 143 528
PROTRON 392 398 498 499 500
PROVIEW 494
PROX 572
PULSAR 116 073
PYLE HOME 661 662
QUASAR 034 056 606
RADIO SHACK 019 363 143 043
ACCURIAN 036
AD NOTAM 672
ADVENT 247 388
AKAI 404 405 473 475 323 387 391 615
AOC 116 363 616
APEX 572
APEX DIGITAL 006
AQUAVISION 573 574 686
ASTAR 477
AUDIOVOX 454 388 076
AUVIO 689
AVION 441
AXION 039
BENQ 600
CHANGHONG 247
COBY 641 671
CYBERHOME 015
DAEWOO 076 363
DELL 320 164 363
DURABRAND 052
DWIN 257
DYNEX 400
ELECTROGRAPH 466
ELEMENT 363 494 526 622
EMERSON 514 363 076 052
ESA 323
FREEMOTION 688
FUJITSU 246 198
FUNAI 052
FUSION 642
GATEWAY 242 268
GO VIDEO 026
HAIER 363 501 623
HANNSPREE 349 381
HISENSE 419 442 619 630 631
HITACHI 011 363 613 670
HP 378 316 327 421
HUMAX 518
HYPERION 609
HYUNDAI 337 338
ILO 472
INFOCUS 547 470
INITIAL 282
INSIGNIA 350 400 052 164 403 454 457 604 617
JVC 038 210 581 639 668
KLEGG 466
KONKA 457
KREISEN 530
LG 363 569 113 116 284 648
LITEON 268
LOEWE 164
MAGNAVOX 164 363 226 390 467 431
MARANTZ 116 164 281
MAXENT 242
MINTEK 362
MITSUBISHI 124 363
NEC 272 262 575
NEXUS 620 454
NIKO 527
NORCENT 390
NUVISION 351 567
OLEVIA 432 363 333
PANASONIC 080 164 208 552 524 664
PHILIPS 164 363 431 161 594 629
PIONEER 234 393 272 520 582 660
POLAROID 388 323 328 353 356 494 387 391 505 506
PRINCETON 004
PROTON 528
PROTRON 392 398 498 499 500
PROVIEW 494
PROX 572
PYLE HOME 661 662
RCA 333 363 161 588
REVOLUTION HD 466
RUNCO 395 416 697 698
SAMPO 363 242
SAMSUNG 258 228 229 515 655
SANSUI 096 400 615
SANYO 166 007
SCEPTRE 276 699
SEIKI 690
ADMIRAL 149
ADVENTURA 034
AIKO 117
AIWA 034
AKAI 016 146 043 124
AMERICA ACTION 117
AMERICAN HIGH 145
AMPRO 072
ANAM 145
ASHA 102
AUDIO DYNAMICS 012 023 039 043
AUDIOVOX 101
BEAUMARK 102
BROKSONIC 129
CALIX 101
CANON 145
CAPEHART 108
CCE 024 117
CITIZEN 101 117
COLT 024
CRAIG 003 022 102
CURTIS MATHES 145
CYBERNEX 102
DAEWOO 116 117 010 108 120
DAYTRON 108
DBX 012 023 039 043
DYNATECH 034 149
ELECTROHOME 059
ELECTROPHONIC 101
EMERSON 006 034 101 129 131 153 116 145 120
FISHER 003 010 008 009
FUJI 145
FUNAI 034
GARRARD 034
GE 072 147 063 144 145
GO VIDEO 102
GOLDSTAR 101 020 012 123
GRADIENTE 034
HARLEY DAVIDSON 034
HARMAN KARDON 012
HARWOOD 024
HITACHI 034 043 063 137 020
HUGHES 817
HUMAX 817
HQ 034
INSTANTREPLAY 145
JCL 145
JCPENNEY 012 015 101 020 102
JENSEN 043
JVC 048 043 055 012 050 145
KEC 101
KENWOOD 048 034
KLH 024
KODAK 101 145
LG 101 020 012 123
LLOYD 03 4
LOGIK 024
LXI 034 003 009 120 101
MAGIN 102
MAGNAVOX 067 034 068 145
MARANTZ 067 069 012 145
MARTA 101
MATSUI 030
MATSUSHITA 145
MEI 145
MEMOREX 101 003 010 034 072 102 134 145 149
MGA 059
MGN TECHNOLOGY 102
MINOLTA 020
MITSUBISHI 059 020 168
MOTOROLA 145 149
MTC 034 102
MULTITECH 024 034
NEC 012 023 039 043 048
NIKKO 101
NOBLEX 102
NORDMENDE 043
OLYMPUS 145
OPTIMUS 101
OPTONICA 149
PANASONIC 070 145 083 133 157 074 167
PENTAX 020 063 145
PHILCO 034 067 145
PHILIPS 067 034 101 145 817
PILOT 101
PIONEER 020 048
PORTLAND 108
PROFITRONIC 102
PROTEC 024
PULSAR 072
QUASAR 145 075
RADIO SHACK 123
RADIX 101
RANDEX 101
RCA 144 147 158 145 020 034 102
REALISTIC 003 008 010 034 101 102 145 149
RICO 058
RUNCO 148
SAMSUNG 102 104 120 144 147
SANKY 149
SANSUI 022 043 048
SANYO 003 010 134 102
SCOTT 120 129 131
SEARS 003 008 010 020 101 009 073 120
SHARP 159 145 149
SHINTOM 024
SHOGUN 102
SIGNATURE 034
SINGER 024
SONY 001 057 058 003 154 145 149
SOUNDESIGN 034
STS 020
SYLVANIA 034 059 067 145
SYMPHONIC 034
TANDY 010 034
TATUNG 039 043
TEAC 034 039 043
TECHNICS 070 145
TEKNIKA 019 034 101 145
THOMAS 034
TIVO 817
TMK 006
TOSHIBA 131 008 059 020 120 817
TOTEVISION 101 102
UNITECH 102
VECTOR RESEARCH 012
VICTOR 048
VIDEO CONCEPTS 012 034
VIDEOSONIC 102
WARDS 003 020 024 034 131 102 145 120 149
WESTINGHOUSE 024
XR-1000 024 034 145
YAMAHA 012 034 039 043
ZENITH 072 048 101 034 058 001
AMERICA ACTION 117
DAEWOO 117
EMERSON 153
FUNAI 034
GOLDSTAR 101 123
HARLEY DAVIDSON 034
HITACHI 034
JCPENNEY 101
LG 101 123
LLOYD 034
MAGNAVOX 034 067
MEMOREX 101
PANASONIC 070 167
PHILIPS 034 067
RADIO SHACK 123
RCA 034 144
SEARS 101
SONY 057 154
SYLVANIA 067
SYMPHONIC 034
THOMAS 034
ZENITH 034
GO VIDEO 220 221 222
CYBERHOME 271
ILO 268
KISS 279
LITEON 265 268
MAGNAVOX 096
PANASONIC 138
PHILIPS 317
RCA 027
SAMSUNG 301
SENSORY SCIENCE 222
SONY 191
TOSHIBA 188 273
AIWA 146
AKAI 281
AUDIOVOX 284
DURABRAND 143
ESA 143
FUNAI 143
INSIGNIA 292 297 143
MAGNAVOX 282
MINTEK 282
POLAROID 284 295 297
SAMSUNG 165
SV2000 143
SYLVANIA 143
SYMPHONIC 143
TOSHIBA 130
TRUTECH 293
DURABRAND 143
EMERSON 143
ESA 143
INSIGNIA 143
MAGNAVOX 143
PANASONIC 144
SUPERSCAN 143
SV2000 143
SYLVANIA 143
SYMPHONIC 143
TOSHIBA 164
GO VIDEO 137
PANASONIC 150
PHILIPS 066 (VCR Functions for VCR 067)
RCA 027 (VCR Functions for VCR 144)
SAMSUNG 137 159
SANSUI 154
SONY 145
TOSHIBA 141
ZENITH 091 (VCR Functions for VCR101)
ADCOM 082 092 225 161 269 356
AIWA 170 018 104 202 203 213 211 188
AKAI 189
ANTHEM 335 337
ARAGON 687
ARCAM 141 077
ATLANTIC TECHNOLOGY
342
AUDIO FILE 071
B & K 096 097
BOSE 070 170 224 347 409 460 532
BOSTON ACOUSTICS 447
CAMBRIGE AUDIO 684
CARVER 006 028 061 071 201 214 226 185 013 077 284
CARY AUDIO DESIGN 378
DVD
Manufacturer/Brand
Set-Up Code Number
MICROSOFT / XBOX 851
MICROSOFT / XBOX 360
826
SONY / PS2 / PS3 829 498
COLORADIO VNET 849
CYRON 436
LEVITON 850
LIGHTOLIER CONTROLS
848
LITE TOUCH 843 844
LUTRON 841 839 341 435
RAKO 846 847
X-10 842 840 845
CISCO 577
DIGITAL STREAM 609
SONY 646 647
ARCAM 100
Bell'O Digital 534
Bose 799 548
BOWER & WILKINS 467
Cambridge Audio 815
DEFINITIVE TECHNOLOGY 582 703 537
DENON 728
Dynex 802
ENERGY 602
Harman Kardon 531
iLive 730 803 538
Insignia 802
INTEGRA 741
JBL 531
KLIPSCH 602 797 798 540 543 544 545
LG 700 541
Magnavox 520
MARTINLOGAN 763 517
Onkyo 557
Panasonic 257
PARADIGM 618 708 758 517
Peerless-AV 558
PHILIPS 727 526
PINNACLE 606
POLK AUDIO 605 732
Pyle 518
RCA 521
Samsung 522
SENTRY 729
Sharp 801 546
Sony 529
SPEAKERCRAFT 562
TOSHIBA 608
VIZIO 665
YAMAHA 568 644 725
ZVOX 796 535 477
CHANNEL MASTER 859
DSTV 787 788 789 786
SONY 804 805
Speco Technologies 879
TIVO 858
ZUUMMEDIA 855
BOSE 347 409 460
DENON 564
INSIGNIA 589
KEF 530
KOSS 573
NAD 598
NIRO 343
ONKYO 552
PANASONIC 516
PHILIPS 690 705
PIONEER 513
POLKAUDIO 685
ROTEL 654
SAMSUNG 571 653
SHARP 652
SONY 317 319 321 322 324 697
TOSHIBA 510
YAMAHA 644
Apple 917
BOSE 532 170
DELPHI 515
NEXUS AUDIO 751
PIONEER 556
RUSSOUND 445
SIRIUS 555 585 767
SONY 380
XM SATELLITE RADIO 515 556
APPLE / iPod 828 824
BOSE 827
DENON 559
DLO 418
GRIFFIN 835
KENSINGTON 825
MARANTZ 834
ONKYO 833
SONANCE 831
HP 820
Jadoo TV 915
ROKU 565
NEUNEO 067
NEXXTECH 068
NORCENT 005 006 007 069 071 072 073
ONKYO 076 141 180 273 338 035
OPPO 266 341
OPTIMUS 023
ORION 130
ORITRON 058
PANASONIC 138 144 150 285 021 346 347 379
PARASOUND 245
PHILIPS 066 276 317 344 381
PHILIPS MAGNAVOX 035 141 066
PIONEER 023 099 131 304 337 354 364 377
POLAROID 233 284 295 297
POLK AUDIO 141 066 035
PRESIDIAN 003 096
PRIMA 005
PRIMARE 193 194
PRINCETON 078
PROSCAN 027
RCA 027 307
RIO 091
RJTECH 269
ROTEL 204
SAMPO 081 082 085
SAMSUNG 070 165 137 159 275 380
SANSUI 154
SANYO 147
SEARS 130
SENSORY SCIENCE 222
SHARP 094
SHERWOOD 245 345 361
SHINSONIC 033
SONIC BLUE 091
SONY 001 033 145 191 286 241 242 243 340 343 351 363 368
378 382
SPECTRONIQ 310
SUNGALE 090 223
SUPERSCAN 143
SVA 092 093
SYLVANIA 143
SYMPHONIC 143
TAG MCLAREN 156
TASCAM 012
TATUNG 102
TEAC 023 270
TECHNICS 138
TECHWOOD 088
THETA DIGITAL 023
THOMPSON 027
TOSHIBA 130 141 164 188 273 035 356
TRUTECH 293
URBAN CONCEPTS 035
US LOGIC 111 282
VENTURER 149
VINC 161 308
VIZIO 375
X-BOX 027 206
YAMAHA 089 066 197 138 334 383
ZENITH 057 074 091
ANTHEM 361
CAMBRIDGE AUDIO 360
DENON 329 358
INSIGNIA 096 349
INTEGRA 273 338
LG 091 350
MAGNAVOX 096
MARANTZ 332
NAD 353
ONKYO 273 338
OPPO 341
PANASONIC 285 346
PHILIPS 344 381
PIONEER 304 354 364
SAMSUNG 275 380
SHERWOOD 345 361
SONY 286 340 351 363 368 378 382
TOSHIBA 273 356
VIZIO 375
YAMAHA 334 383
SHARP 251 363 684 692
SHERWOOD 349
SONY 001 608 651
SOVA 041
SOYO 528
SPECTRONIQ 499 500
SUNBRITE 633 634 635 386 605
SVA 328
SYLVANIA 052 164 333 514
SYMPHONIC 052
SYNTAX OLEVIA 432 363 333
TATUNG 056
TECHVIEW 045 557
TELEFUNKEN 615
TILEVISION 663
TOSHIBA 138 258 325
TRUTECH 529
VIEWSONIC 242 389
VIORE 472 592
VISCO 526
VITO 363
VIZIO 386 387 624 625 675
WESTINGHOUSE 076 276 435 001 690 695
WINBOOK 339
YAMAHA 116 363
ZENITH 363 073 072
AKAI 404 405 473 475
DAEWOO 076
EPSON 324
HITACHI 011
HP 378
INFOCUS 333 548
JVC 038
LG 363
LOEWE 164
MAGNAVOX 164 333
MITSUBISHI 109
OPTOMA 265
PANASONIC 080 524
PHILIPS 164 431
RCA 333
SAMSUNG 258
SANYO 166 007 187
SHARP 251
SONY 001
TOSHIBA 138
ZENITH 363 073 072
AVIELO 627 628
BENQ 423
BOXLIGHT 266
DELL 618
DIGITAL PROJECTION 570
DREAMVISION 235
EPSON 590
FUJITSU 410
HITACHI 250
INFOCUS 230 532 564 595 726
JVC 199 533 406 701
KNOLL SYSTEMS 230 659
MARANTZ 281 562 584
MITSUBISHI 348 658
NEC 236 281
OPTOMA 249
PANASONIC 359 607
RUNCO 342
SANYO 511 266 657
SELECO 205
SHARP 308
SIM2 205
SONY 646 702
TOSHIBA 230
VIDIKRON 342 174 188 192
YAMAHA 370
ACCURIAN 003 268
ADCOM 157
ADVENT 005
AIWA 146
AKAI 281
ALLEGRO 091
ALPINE 098
AMW 006 007
ANTHEM 361
APEX DIGITAL 087 111 115
ARCAM 122 374
ASPIRE DIGITAL 008 009
AUDIOVOX 003 010 014 015 149
BEL CANTO DESIGN 016
BLAUPUNKT 111
BROKSONIC 130
BUFFALO 26 4
CALIFORNIA AUDIO LABS
021 124
CAMBRIDGE AUDIO 323 333 360
CARY AUDIO DESIGN 174 266
CENTRIOS 019
CINEVISION 091
CITIZEN 020
COBY 260
CYBERHOME 271
DAEWOO 132
DENON 173 080 138 329 358
DIAMOND VISION 037 038 039
DISNEY 040 096
DUNE 366
DURABRAND 091
DVD 2000 017
DYNEX 349
EMERSON 091 143
ENTERPRISE 074
ESA 022 143
FISHER 147
FUNAI 143
GATEWAY 222
GE 027
GO VIDEO 137 091 220 221 222
GOLDSTAR 091
GPX 044 045
GRADIENTE 021
GREENHILL 111
GRUNDIG 083
HARMAN KARDON 084 140
HITACHI 101
HITEKER 087
ILO 268
INITIAL 111
INSIGNIA 143 292 297 091 096 349 385
INTEGRA 142 180 280 273 338
JATON 046
JBL 084
JSI 047
JVC 012
JWIN 048 050
KAWASAKI 149
KENWOOD 151
KISS 279
KLH 135
KONKA 051 052 054 055
KOSS 047 058 059
KREISEN 060
KRELL 104
LASONIC 061 062
LEXICON 148
LG 091 057 074 350
LITEON 264 265 268
LOEWE 063
MAGNAVOX 066 096 282 386
MALATA 267
MARANTZ 066 332
MCINTOSH 125
MEMOREX 040 096 163
MERIDIAN 153
MICROSOFT 027 206
MINTEK 111 282
MITO 149
MITSUBISHI 017
MYRYAD 102 134
NAD 088 353
NAKAMICHI 103
NESA 111
CITATION 148
CLARION 026
DELPHI 515 556
DENON 340 109 215 230 234 330 679 564 774
DIGITAL PROJECTION 660
DVICO 570
ELAN 057 290
ENLIGHTENED AUDIO 099 098
ESCIENT 451
FISHER 214 182
FLEXTRONICS 378
FOSGATE AUDIONICS 148 342
GOLDSTAR 008
HARMAN KARDON 318 148 233 077 028 118
HITACHI 020
INSIGNIA 589
INTEGRA 275 017 046 108 080 209 381
JAMO 399
JCPENNEY 216
JVC 163 191 114 279 291
KEF 530
KENWOOD 026 066 145 192 182 005 280 374
KLEGG 686
KLH 331
KLIPSCH 687
KOSS 216 573
KRELL 072 384 672
LEXICON 357 120 235 236 237 360
LINN 124 377
LUXMAN 009 139 052 165 115 004
MAGNAVOX 086 164 152 077
MARANTZ 006 028 031 040 063 185 186 265 289 492 712 719
MCINTOSH 238 286 311
MERIDIAN 100 012 013 628
MITSUBISHI 242 204
MONDIAL 157 158 042 043 081 112
MYRYAD 077
NAD 186 113 598
NAKAMICHI 040 244 245 172 183 287
NEC 176
NILES 403
NIRO 343
ONKYO 046 275 017 108 080 209 552 381
OPTIMUS 026 041
OUTLAW 342
PANASONIC 032 195 219 177 292 626 516
PARASOUND 129 130 132 261 294 295 333 334
PHILIPS 249 250 063 690
PIONEER 480 014 039 044 069 168 116 035 063 198 556 513
POLKAUDIO 556 685
PROCEED 144 268
RCA 010 048 117 156 067 288
REALISTIC 019 073 075 095
ROKU 739
ROTEL 083 074 085 654
RUSSOUND 445
SAMSUNG 016 653 571
SANSUI 040 048 110 063 065 228
SANYO 214
SCOTT 019
SHARP 026 094 175 652
SHERWOOD 024 102 106 447 370
SIRIUS 555 585 767
SONY 001 018 247 248 166 101 184 218 271 380 560
SOUNDESIGN 036
SUNFIRE 344 345 182
TEAC 005 019 049 040 212 217
TECHNICS 122 176 193 219 178 177 200 257 262
THETA DIGITAL 136
TOSHIBA 060 087 198 278 510
VIZIO 551
XM SATELLITE RADIO 515 556
YAMAHA 644 205 026 253 169 067 173 264 232 089 264 274
715 717 695 738 756 661
ZENITH 143 210
VCR
Manufacturer/Brand
Set-Up Code Number
RCA 333 065 116 363 024 056 161 588 713 751
REALISTIC 007 019 043
REVOLUTION HD 466
RUNCO 073 395 416 072 342 697 698
SAMPO 116 363 242
SAMSUNG 258 050 363 143 333 228 229 515 655
SAMSUX 116
SANSEI 076
SANSUI 096 400 615 454 762
SANYO 007 166 057 187 511 266 657 750
SCEPTRE 276 699
SCOTCH 116
SCOTT 028 043 048 143 363 497
SEARS 030 363 007 028 057 143 333 166 138
SEIKI 690
SELECO 205 011
SEURA 704
SHARP 251 019 028 363 143 175 308 684 692 735 765 766
SHENG CHIA 081
SHERWOOD 349
SHOGUN 116
SIGNATURE 072
Silo 001
SIMPSON 003
Skyvue 648
SONY 001 608 646 651 702
SOUNDESIGN 028 363 003 043
SOVA 041
SOYO 528
SPECTRICON 112
SPECTRONIQ 499 500
SQUAREVIEW 052
SSS 363 043
STARLITE 043
SUNBRITE 633 634 635 386 605 772
SUPERSCAN 052 081
SUPRA 116
SUPRE MACY 002
SUPREME 001
SVA 328
SYLVANIA 116 003 052 164 333 514 593
SYMPHONIC 052
SYNTAX OLEVIA 432 363 333
TANDY 251
TATUNG 056
TCL 705 749
TECHNICS 034 080
TECHNOL ACE 028
TECHVIEW 045 557
TECHWOOD 363
TEKNIKA 002 003 363 024 028 043 072 258 143
TELEFUNKEN 037 046 615
TELERENT 072
THOMSON 049 055
TILEVISION 663
TMK 363
TNCI 073
TOSHIBA 138 030 007 258 325 230 703
TOTEVISION 143
TRUTECH 529
TVS 096
UNIVERSAL 008 009
UPSTAR 708
VENTURER 721
VICTOR 038
VIDIKRON 174 164 188 192 342
VIDTECH 363
VIEWSONIC 242 389 720
VIKING 002
VIORE 472 592 258
VISCO 526
VITO 363
VIZIO 386 387 624 625 675
WARDS 363 008 009 019 028 072 143 164 034
W Box Technologies 731
WESTINGHOUSE 076 276 435 001 280 690 695
WINBOOK 339
YAMAHA 116 363 370
YORK 363
YUPITERU 043
ZENITH 363 073 072
ZONDA 112
Loading...
