ACM6000

Clamp-On Multimeter

Quickly measure current loads
without disconnecting wires using
the ACM6000’s handy clamp-on jaw

Alternator output testing

Starter draw testing

Blower-motor current testing

Fuel pump current draw

Additional tests:

• Open/shorted wiring

• Resistance measurement

• AC/DC voltage test

• Temperature test

The ACM6000
has the following features:

• Quickly measure current loads without disconnecting wires

• Alternator output testing

• Starter draw testing

• Blower-motor current testing

• Fuel pump current draw

• Lamps, lights & electric motors can all be tested

• Additional tests include: open/short wiring, resistance measurements,
AC/DC voltage tests, & temperature testing

• One year limited warranty

The ACM6000 Clamp-On Multimeter is ideal for
testing blower motors, lights, fuel pump current draw,
starter motor current draw and most other vehicle
electric motors (antennae, door-locks, mirrors, etc.). Its
a new way to test charging systems.

The ACM6000 is the perfect tool for those who want to
speed up their diagnostic test procedures. With its
easy to use current clamp jaw and standard DMM
measurements, this tester gets the job done.

The ACM6000 comes in an attractive protective pouch
and also includes an extremely helpful manual, a
temperature probe and a set of DMM test leads. It is
compatible with most existing meter leads and is
simple to understand so you can get started testing as
soon as you receive it.

Copyright © 2006 UEi Automotive Specifications are subject to change without notice. L807 AUTO 3/06

ACM6000 • Clamp-On Multimeter

Specifications

Distributed By:

1-800-547-5740 • Fax: [phone]
Service: [phone]
www.ueiautomotive.com
Email: [e-mail]

IN CANADA

Vancouver: Phone: [phone] • Fax: [phone]
Toronto: Phone: [phone] • Fax: [phone]

IN EUROPE

Phone: [phone] • Fax: [phone]

Range Resolution Accuracy

DC Current

20A 10mA ±3.5% ±6 digits
200A 100mA ±3.5% ±6 digits

AC Current 50 - 60 Hz 40 - 100 Hz 100 - 400 Hz 400 - 1000 Hz

20A 10mA ±3% ±4 digits ±3% ±7 digits ±3% ±10 digits ±3% ±30 digits
200A 100mA ±3% ±4 digits ±3% ±7 digits ±3% ±10 digits ±3% ±30 digits

DC Voltage (Input Impedance: 10MΩ)

200V .1V ±1% ±2 digits

AC Voltage (Input Impedance: 10MΩ) 50 - 60 Hz 40 - 400 Hz 400 - 1000 Hz

200V .1V ±1.5% ±3 digits ±2% ±10 digits ±3% ±25 digits

Temperature (K-type thermocouple)

40˚F to 1000˚F 1˚F ±3% ±6 digits (@ 50 - 90˚F) Ambient Temperature

Resistance Continuity Tone

2000Ω 1Ω ±1% ±2 digits  ≤25Ω

Standard Accessories:

Test Leads

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ATL55

Temperature Probe Adapter

. . . . . . . . . . . . . . . . . . . . . . .

ATT70

Wire Temperature Probe

. . . . . . . . . . . . . . . . . . . . . . . . . .

ATT29

Soft Pouch

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ACM6000P

Optional Accessories:

Surface Temperature Probe

. . . . . . . . . . . . . . . . . . . . . . .

ATT36

Immersion Temperature Probe

. . . . . . . . . . . . . . . . . . . .

ATT50

Extended Test Leads (10’)

. . . . . . . . . . . . . . . . . .

ADL7100A108
