Universal Electronics Atlas DVD/PVR 5-Device Universal Remote Control User Manual
ATLAS
DVR/PVR 5-DEVICE
Universal Remote Control
User’s Guide
TABLE OF CONTENTS
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features And Functions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Key Charts
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Device Table
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Batteries
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programming Device Control
. . . . . . . . . . . . . . . . . . . . . . 10
Programming TV/VCR Combo Control
. . . . . . . . . . . . . . . 12
Manufacturer’s Codes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setup Codes For Audio Amplifiers . . . . . . . . . . . . . . . . . . . . . . 13
Setup Codes For Audio Receivers . . . . . . . . . . . . . . . . . . . . . . 13
Setup Codes For Cable Boxes (Converters) . . . . . . . . . . . . . . . 15
Setup Codes For DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setup Codes For Satellite Receivers . . . . . . . . . . . . . . . . . . . . 16
Setup Codes For TVs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setup Codes For TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . 20
Setup Codes For VCRs And PVRs . . . . . . . . . . . . . . . . . . . . . . 21
Searching For Your Code
. . . . . . . . . . . . . . . . . . . . . . . . . . 24
Checking The Codes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Programming Channel Control Lock
. . . . . . . . . . . . . . . . 26
To De-Activate Channel Control Lock
. . . . . . . . . . . . . . . . . . 26
To Re-Activate Channel Control Lock
. . . . . . . . . . . . . . . . . . 26
Programming ID Lock
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Programming“Tune-In” Keys For Specific Channels
. . . 27
To Program A “Tune-In” Key . . . . . . . . . . . . . . . . . . . . . . . . . . 28
To Clear A “Tune-In” Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using The Master Power Key
. . . . . . . . . . . . . . . . . . . . . . . 29
To Program The Master Power Key. . . . . . . . . . . . . . . . . . . . . . 29
To Operate The Master Power Key . . . . . . . . . . . . . . . . . . . . . . 29
To Clear The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . . 29
Re-Assigning Device Keys
. . . . . . . . . . . . . . . . . . . . . . . . 30
Changing Volume Lock
. . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To Unlock Volume Control For A Single Device
(Individual Volume Unlock). . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To Unlock All Volume Control
(Global Volume Unlock). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To Lock Volume Control To One Mode
(Global Volume Lock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Instructions To The User
. . . . . . . . . . . . . . . . . . . . . . . . . . 34
Additional Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
2
Atlas DVD/PVR Manual 2/14/03 5:00 PM Page 2
INTRODUCTION
The Atlas DVR/PVR 5-Device Universal Remote Control
by Universal Electronics is our latest generation universal
remote control.Its sophisticated technology allows you to
consolidate up to five of your original home entertainment
remote co ntrols into o n e eas y-t o-use p roduct.Moreover,it’s
packed with advanced features such as:
• Preprogrammed control to operate the cable converter
supplied by your cable service provider
• Dedicated keys to control popular functions on your
DVR/PVR (Digital/Personal Video Recorder)
• Programmable Master Power key for master on/off
control of your home entertainment equipment with a
single keystroke
• Instant “Tune-In” keys for assignment to your
favorite channels
• Channel Lock to lock channel selection only to the
cable converter
• Volume Lock to lock volume controls to one mode or
individual modes
• Device Key Re-Assignment to remotely control
a second (duplicate) device
• Code Search to help program control ofolder or
discontinued components
• Color-coded keys to quickly locate popular functions
• Code library for popular video and audio devices
Before using the product,you will need to install the
enclosed batteries and also perform some programming
to operate the specific home entertainment devices you
wish to control.
Please follow the instructions detailed in this manual to
set up the unit and then start enjoying your new remote
control and cable service.
3
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 3
FEATURES AND FUNCTIONS
Use the illustration below to locate features on the
Atlas DVR/PVR 5-Device Universal Remote Control and
then study the Key Charts (on the next three pages) to
learn how they function.
To find out what type of devices can be controlled by each
device key after programming,see the Device Table on
page 8.
4
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 4
Key Charts
Use SETUP for all programming
sequences.
Press PWRon ce to turn on or
off a home e ntertainment device.
For MASTER POWERcontrol, see
Using The Master Power Key on
page 29.
Press AUX,DVD,AUD,TV,or CBL
once to sele ct a home entertainment device to control.Also see
the Device Table on page 8.
Each device key has an embedded
LED(red light) that blinks upon
selection and indicates the remote
control is working and (after programming) is sending signals.
Use GUIDEto display the program
guide.
Press MENU once to display
available interactive services.
Use INFO to display the current
channel and program information.
Press SETTINGS once to access
additional cable features.
Use the Cursorkeys to move t he
cursor in the program guide and
menu screens and to navigate
within the interactive service.
Use SELECTto choose options,
PPV events,and to tune programs
from the program guide.
Use PAGE+(or PAGE-) to page up
(or page down) through menu
screens and the program guide.
Use EXIT to exit out of your cable
converter’s menu and guide.
Use A,B,or Cto a ccess additional
cable features (see your cable
converter’s manual).
continued on next page...
5
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 5
FEATURES AND FUNCTIONS
Key Charts (continued)
Use VOL+(or VOL-) to raise (or
lower) the audio volume.
Use FAV to cycle through your
favorite channels stored in your
cable converter.
Use CH+(or CH-) to select the
next higher (or lower) channel.
For DVD players,use these keys to
skip forward (or reverse) through
chapters.
For amplifiers/receivers,use these
keys to select the next higher (or
lower) preset station.
Press MUTE once to turn the
sound offor on.
Press LASTonce to recall the last
channel.
Reserved for use as “Tune-In”keys
(see page 27).
Use to command your PVR
to instantly replay the last
7 seconds ofa program you are
watching.
Press LISTonce to display a list
ofreco rded shows on your PVR.
Press LIVEto return to watching
live TV.
In all modes except CBL,use REW,
PLAY,FFWD,STOP,and PAUSE to
control a VCR,DVD player,or a
PVR (after selecting a desired
device).To record in the VCR
mode,press REC twice.
In the CBL mode,use above keys
to control DVR/PVR functions of
the set-top box.
6
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 6
Use the keypadnumbers (1~9,
and 0) to directly tune channels
(e.g.,09).For amplifiers/receivers,
use the keypad number s to select
inputs 1 thro ugh 10.
In the CBL mode,use ENTER to
enter information and to access
music channels.
In the TV,DVD,or AUXmodes for
certain devices,press ENTER once
after enteri ng a channel number.
See your device’s owner’s manual.
Use PIP ON-OFFto switch the
Picture-In-Picture feature on or
off (if available on your TV or
cable service).
Use PIP SWAP to switch images
and sound between the main and
window pictures.
Use PIP MOVEto move the window
picture to different positions in the
main picture.
Use PIP CH+(or CH-) to select
the next higher (or lower) PIP
channel.
In the CBL mode,use VIDEO
SOURCEto view other video
sources (A or B) instead ofcable.
In all other modes,use VIDEO
SOURCEtowatch TV or video
programs on a desired device.For
amplifiers/recei v e rs,use VIDEO
SOURCEto select an input source.
7
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 7
FEATURES AND FUNCTIONS (continued)
Device Table
NOTE: Please refer to the table below when performing the
instructions in “Programming Device Control” on page 10 or
“Programming TV/ VCR Combo Control”on page 12.
After programming, the Atlas DVR/PVR 5-Device
Universal Remote Control will be able to control the
following types ofdevices:
8
DEVICE KEY CONTROLS THESE TYPES OF DEVICES
VCR,TV/VCR Combo,PVR
(Perso nal V ideo Record er),or
extra DVD Player
DVD Player
Audio Am plifier,Tuner ,or
Receiver
Television
Cable Box (Converter) or
Satellite Receiver
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 8
INSTALLING BATTERIES
1. On the back ofthe remote control,push the
tab and lift off the battery cover.
2. Locate the two (2) enclosed AA batteries.
Match the + and – marks with those in the
battery case,then insert them.
3. Align the cover’s keys with the case’s holes
and press the cover back into place.The tab
should click when the cover is locked.
4. Test the remote control by pressing
any mode key (e.g.,TV).Ifthe batteries are
inserted correctly,the LED(red light) will
blink once
NOTE:When batteries need replacement, the remote control will
cease to operate. Replace the batteries and the unit will be restored
to its full functionality, complete with your favorite settings.
9
❶
❸
❷
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 9
PROGRAMMING DEVICE CONTROL
The Atlas DVR/PVR 5-Device Universal Remote Control
is preprogrammed to operate the Scientific Atlanta cable
box (converter) provided by your cable system,an RCA
TV, a Toshiba DVD player,an RCA VCR (as an AUX
device),and a Pioneer audio receiver.To control devices
other than the default brands,perform the following steps;
otherwise skip this section:
NOTES: For TV/VCR Combo control, skip this section and perform
the instructions on page 12.Also refer to the “Device Table”on
page 8 to find out which devices can be programmed onto each
device key.
If you have another brand of cable converter or a satellite receiver
you would like to control, you’ll first need to unlock the cable ID
Lock before changing the converter code – see “Programming ID
Lock” on page 27.
1. Turn on a device and,if applicable,insert
video media,(e.g.,cassette or disc).
NOTE: Please read steps 2 through 4 completely
before proceeding. Highlight or write down the codes
and device you wish to program before moving on to
step 2.
2. On the remote control,press a device key once
(i.e..,AUX,DVD,AUD,TV,or CBL);it will blink
once.Then press and hold SETUPuntil the
selected mode key blinks twice,then release
SETUP.
3. Use the Manufacturer’s Codes (starting on
page13) to locate the the type of device and
brand name and then enter the first four-digit
code for your device.Ifperformed correctly,
the selected mode key will blink twice.
NOTE: If the selected mode key emits a long blink,
the entry is invalid. Repeat steps 2 through 3 and try
entering the same code again.
4. Aim the remote controlat the device and
press PWR once.The device should turn off.
If it does not,repeat steps 2 through 3,t rying
each code for your brand until you find one
that works.Ifit still does not respond,tr y
searching for the code (see Searching For Your
Code on page 24).
NOTE: If the device does not have a POWER key,
press the (Play) key.
10
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 10
5. Repeat steps 1 through 4 for each device you
want the remot e control to opera te.For future
reference,write down each working device
code in the following boxes:
AUX Code
Device Type:_______________________
DVD Code
Device Type:_______________________
AUD Code
Device Type:_______________________
CBL Code
Device Type:_______________________
TV Code
11
Atlas DVR/PVR Manual 3/20/03 5:00 PM Page 11
Loading...
