ATLAS
CABLE 4-DEVICE
Universal Remote Control
User’s Guide
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features And Functions . . . . . . . . . . . . . . . . . . . . . . . . 4
Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programming Device Control . . . . . . . . . . . . . . . . . . . 8
Programming TV/VCR Combo Control . . . . . . . . . . . . 9
Setup Codes for Audio Amplifiers. . . . . . . . . . . . . . . . . . . . 11
Setup Codes for Audio Receivers . . . . . . . . . . . . . . . . . . . . 11
Setup Codes for Cable Converters . . . . . . . . . . . . . . . . . . . 12
Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . 12
Setup Codes for VCRs and PVRs . . . . . . . . . . . . . . . . . . . . 13
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setup Codes for TV/VCR Combos . . . . . . . . . . . . . . . . . . . . 19
To De-Activate Channel Control Lock . . . . . . . . . . . . . . . . . 23
To Re-Activate Channel Control Lock . . . . . . . . . . . . . . . . . 23
To Program The Master Power Key . . . . . . . . . . . . . . . . . . . 24
To Clear The Master Power Key. . . . . . . . . . . . . . . . . . . . . . 24
To Operate The Master Power Key. . . . . . . . . . . . . . . . . . . . 24
Example – Programming A Favorite Channel . . . . . . . . . . 26
Example – Programming A Master Power Key With
Instant Channel Selection . . . . . . . . . . . . . . . . . . . . . . . . 27
To Clear A Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
To Unlock Volume Control For A Single Device . . . . . . . . . . 28
To Unlock All Volume Control . . . . . . . . . . . . . . . . . . . . . . . 28
To Lock Volume Control To One Mode . . . . . . . . . . . . . . . . . 29
Programming Keymover. . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Restoring Keymoved Keys to Default Settings . . . . . . . . . . 30
2
INTRODUCTION
The Atlas Cable 4-Device Universal Remote Control by Universal Electronics is our latest generation universal remote control.Its sophisticated technology allows you to consolidate all of your original home entertainment remote controls into one easy-to-use product.Moreover,it’s packed with advanced features such as:
• Preprogrammed to operate the cable converter supplied by your cable system provider
• Master Power key for master on/off control of all of your equipment with a single keystroke
• Macro key for instant tune-in of favorite channels
• Cable ID Lock to lock your remote control for use only with the cable converter
• Channel Lock to lock channel selection only to the cable converter
• Volume Lock to lock volume controls to one mode or individual modes
• Device Key Re-Assignment to remotely control a second (duplicate) device
• Color-coded keys to quickly locate popular functions
• Code library for popular video and audio devices
Before using the product,you will need to program it to operate the specific home entertainment devices you wish to control.Follow the instructions detailed in this manual to set up your unit and then start enjoying your new remote control.
3
FEATURES AND FUNCTIONS
Use the illustration below to locate features on the Atlas Universal Remote Control and then study the Key Charts (on the next two pages) to learn how they function.
4
Key Charts
Use SETUP for all programming sequences.
Press POWER once to turn on or off a home entertainment device.
Press AUD,VCR,TV,or CBL once to select a home entertainment device to control. Each device key has an embedded LED (red light) that blinks upon selection and indicates that the remote control is working and is sending signals.
Use GUIDE to display the program guide.
Press MENU once to display the available interactive services.
Use INFO to display the current channel and program information.
Use SETTINGS to access additional cable features (see your cable converter’s manual).
Use PAGE+ (or PAGE-) to page up (or page down) through menu screens and the program guide.
Use the Cursor keys to move the cursor in the program guide and menu screens and to navigate within the interactive service.
Use SELECT to choose options,PPV events,and to tune programs from the program guide.
continued on the next page...
5
FEATURES AND FUNCTIONS
Key Charts (continued)
After programming, press MACRO once to run a macro (see Using Macros on page 26).
Use EXIT to exit out of your cable converter’s menu and guide.
Use A,B,or C to access additional cable features (see your cable converter’s manual).
Use DAY+ (or DAY-) to move a day forward (or back) on your cable converter’s program guide.
Use VOL+ (or VOL-) to raise (or lower) the audio volume.
Press LAST once to recall the last channel. For PVRs,use LAST to select live or recorded video.
Use FAV to cycle through your favorite channels stored in your cable converter.
Press MUTE once to turn the sound off or on.
Use CH+ (or CH-) to select the next higher (or lower) channel.
For DVD players, use these keys to skip forward (or reverse) through chapters. For amplifiers/receivers, use these keys to select the next higher (or lower) preset station.
Use the keypad (1~9, 0,,and) to directly select channels (e.g.,09).
Press ENTER once after entering channel numbers on some TVs.
For amplifiers/receivers, use the keypad to select inputs 1 through 10.
Use BYPASS to view other video sources (A or B) instead of cable.
6
Use TV/VCR to switch the TV input
❶
❸
❷
to view video or TV programs.For amplifiers/receivers,use this key to select input or output.
In all modes except CBL, use these keys to control a VCR,DVD player, or PVR.To record in the VCR mode, press REC twice.
In the CBL mode, use these keys except REC to control VOD (Video On Demand), if available.
INSTALLING BATTERIES
1. On the back of the remote control,push the tab
and lift off the battery cover.
continued on next page...
7
INSTALLING BATTERIES (continued)
2. Obtain two (2) new AA alkaline batteries.
Match the + and – marks with those in the battery case, then insert the new batteries.
3. Align the cover’s keys with the case’s holes and
press the cover back into place. The tab should click when the cover is locked.
4. Test the unit by pressing POWER and any mode
key (e.g.,TV). If batteries are inserted correctly, the selected mode key will blink once.
NOTE:When batteries need replacement, the remote control will cease to operate. Replace the batteries and the unit will be restored to its full functionality, complete with your favorite settings.
PROGRAMMING DEVICE CONTROL
The Atlas Universal Remote Control is preprogrammed to operate a Scientific Atlanta cable converter,an RCA TV, an RCA VCR,and a Pioneer audio receiver.To control devices other than the default brands, perform the following steps;otherwise skip this section:
NOTES: To control a DVD player, program the VCR key. To control a PVR, program the VCR key. To control a stereo amplifier or receiver, program the AUD key. For TV/VCR Combo control,skip this section and perform the instructions on the next page.
If you have another brand of cable converter and interactive ser­vice you would like to control, you’ll first need to unlock the cable ID Lock before changing the converter code – see “Programming ID Lock” on page 22.
1. Turn on a device and,if applicable, insert video
media, (e.g.,cassette or disc).
NOTE: Please read steps 2-4 completely before pro­ceeding. Highlight or write down the codes and device you wish to program before moving on to step 2.
2. On the remote control, press a device key once
(e.g., AUD,VCR, TV,or CBL). Press and hold SETUP until the selected mode key blinks twice, then release SETUP.
3. Use the Manufacturer’s Codes (starting on
page 11) to locate the the type of device and brand name and then enter the first four-digit code for your device.If performed correctly, the selected mode key will blink twice.
8
NOTE: If the selected mode key emits a long blink, the code is invalid.Repeat steps 2 through 3 and try entering the same code again.
4. Aim the remote control at the device and press
POWER once. The device should turn off. If it does not, repeat steps 2-3, trying each code for your brand until you find one that works. If it still does not work,try searching for the code (see Searching For Your Code on page 20).
NOTE: If the device does not have a POWER key, press the (Play) key.
5. Repeat steps 1 through 4 for each device you
want the the remote control to control. For future reference, write down each working device code in the following boxes:
AUD
Audio Device ____________________
VCR
TV
CBL
PROGRAMMING TV/VCR COMBO CONTROL
If you own a TV/VCR Combo,perform the following instructions to control this device:
1. Turn on your TV/VCR Combo and insert a
video cassette.
2. On the remote control,press VCR once.
Press and hold SETUP until the VCR ke y blinks twice, then release SETUP.
3. Use the Setup Codes For TV/VCR Combos (on
page 19) to locate the brand name and then enter the first four-digit code for your TV/VCR Combo.If you perform this procedure correctly, the VCR key will blink twice.
9
continued on next page...
PROGRAMMING TV/VCR COMBO CONTROL
3. (continued)
NOTE: If the VCR key did not blink twice after enter­ing the code’s last digit, then repeat steps 2 through 3 and try entering the same code again.
If you’ve located a TV/VCR setup code that works your TV/VCR Combo and a separate TV code is also listed,you’ll need to program this code into the remote control to access volume control (see Programming Device Control on page 8).
4. Aim the remote control at your TV/VCR
Combo and press POWER once. The device should turn off.If it does not respond,repeat steps 2-3 (starting on the previous page),trying each code listed for your brand until you find one that works. If it still does not work, try searching for the code (see Searching For Your Code on page 20).
5. For future reference, write down each working
device code in the boxes below:
TV/VCR
TV (if used)
10
MANUFACTURER’S CODES
Setup Codes for Audio Amplifiers:
GE 0078 Harman/Kardon 0892 JVC 0331 Luxman 0165 Marantz 0321, 0892 Nakamichi 0321 Optimus 0395 Philips 0892 Polk Audio 0892 Realistic 0395 Sansui 0321 Sony 0689 Soundesign 0078 Victor 0331 Wards 0078 Yamaha 0354
Setup Codes for Audio Receivers:
ADC 0531 Aiwa 0121, 1089,1405 Bose 1229 Capetronic 0531 Carver 1089, 1189 Compaq 1136 Denon 1104, 1160 Harman/Kardon 0110 Hewlett Packard 1181 JBL 0110 JVC 0074 Kenwood 0186, 1027, 1313,1569, 1570 MCS 0039 Magnavox 0531, 1089, 1189 Marantz 0039, 1089,1189 Onkyo 0135 Optimus 0531, 0670, 0186,1023 Panasonic 0039, 1518 Philips 1089, 1189, 1269 Pioneer 0531, 0014, 0150,0630, 1023 Proscan 1254 Quasar 0039 RCA 0531, 1023, 1254 Sansui 1089 Sharp 0186 Sony 1058, 1158, 1258 Soundesign 0670
continued on next page...
11
MANUFACTURER’S CODES
Setup Codes for Audio Receivers (continued):
Sunfire 1313 Technics 0039, 1308, 1309, 1518 Thorens 1189 Victor 0074 Wards 0014 Yamaha 0176, 0186, 1176
Setup Codes for Cable Converters:
ABC 0003, 0008, 0017 Americast 0899 Bell South 0899 General Instrument 0476, 0810 GoldStar 0144 Jerrold 0003, 0476, 0276,0810 Memorex 0000 Motorola 0476 Panasonic 0000 Paragon 0000 Philips 0305, 0317 Pioneer 0144, 0533, 0877,1877 Pulsar 0000 Quasar 0000 Runco 0000 Samsung 0144 Scientific Atlanta 0008, 0477, 0017, 0877,1877 Starcom 0003 Supercable 0276 Toshiba 0000 Zenith 0000, 0525, 0899
Setup Codes for DVD Players:
Aiwa 0641 Apex 0672,0755 Audiologic 0736 B & K 0655, 0662 Denon 0490, 0634 Emerson 0591 Fisher 0670 GE 0522, 0717 GPX 0769 Go Video 0715 Gradiente 0651 Harman/Kardon 0582 Hitachi 0573, 0664 Hiteker 0672
12
JVC 0558, 0623 Kenwood 0534, 0682 Konka 0711, 0719, 0720,0721 Magnavox 0503, 0675 Marantz 0539 Microsoft 0522 Mitsubishi 0521 Onkyo 0503, 0627 Optimus 0571 Oritron 0651 Panasonic 0490, 0632,0677, 0678 Philips 0503, 0539 Pioneer 0525, 0571, 0632 Princeton 0674 Proscan 0522 RCA 0522, 0571, 0704,0717 Samsung 0573 Sanyo 0670 Sharp 0630 Sherwood 0633 Sony 0533 Technics 0490 Techwood 0692 Theta Digital 0571 Toshiba 0503 Yamaha 0490, 0545 Zenith 0503, 0591
Setup Codes for VCRs and PVRs:
Admiral 0048, 0209 Adventura 0000 Aiko 0278 Aiwa 0037, 0000 Akai 0041 America Action 0278 American High 0035 Asha 0240 Audiovox 0037 Beaumark 0240 Bell & Howell 0104 Broksonic 0184, 0121, 0209,0002, 0479 CCE 0072, 0278 Calix 0037 Canon 0035 Carver 0081 Cineral 0278 Citizen 0037, 0278 Colt 0072 Craig 0037, 0047, 0240,0072
13
continued on next page...
MANUFACTURER’S CODES
Setup Codes for VCRs and PVRs (continued):
Curtis Mathes 0060, 0035,0041, 0162, 0760 Cybernex 0240 Daewoo 0045, 0278 Denon 0042 Dynatech 0000 Electrohome 0037 Electrophonic 0037 Emerex 0032 Emerson 0037, 0184, 0000,0121, 0043, 0209, 0002,0278, 0479 Fisher 0047, 0104 Fuji 0035, 0033 Funai 0000 GE 0060, 0035, 0048,0240, 0760 Garrard 0000 Go Video 0432 GoldStar 0037, 0038 Gradiente 0000 HI-Q 0047 Harley Davidson 0000 Harman/Kardon 0081, 0038 Harwood 0072 Hitachi 0000, 0042,0041 Hughes Net. Sys. 0042 JVC 0067, 0041 Jensen 0041 KEC 0037, 0278 KLH 0072 Kenwood 0067, 0041, 0038 Kodak 0035, 0037 LXI 0037 Lloyd’s 0000 Logik 0072 MEI 0035 MGA 0240, 0043 MGN Technology 0240 MTC 0240, 0000 Magnasonic 0278 Magnavox 0035, 0039, 0081,0000, 0149 Magnin 0240 Marantz 0035, 0081 Marta 0037 Matsushita 0035, 0162 Memorex 0035, 0037, 0048,0039, 0047, 0240, 0000,0104, 0209, 0162,
Minolta 0042 Mitsubishi 0048, 0067, 0043 Motorola 0035, 0048 Multitech 0000, 0072
0479, 1162
14
NEC 0104, 0067, 0041,0038 Nikko 0037 Noblex 0240 Olympus 0035 Optimus 0037, 0048, 0104,0162, 0432, 1162 Orion 0184, 0209, 0002, 0479 Panasonic 0035, 0162,0225, 0616, 1162 Penney 0035, 0037,0240, 0042, 0038 Pentax 0042 Philco 0035, 0209, 0479 Philips 0035, 0081, 0618,1081, 1181 Pilot 0037 Pioneer 0067 Polk Audio 0081 Profitronic 0240 Proscan 0060, 0760 Protec 0072 Pulsar 0039 Quasar 0035, 0162, 1162 RCA 0060, 0035, 0048,0240, 0042, 0149, 0760 RadioShack 0000 Radix 0037 Randex 0037 Realistic 0035, 0037,0048, 0047, 0000, 0104 ReplayTV 0614, 0616 Runco 0039 STS 0042 Samsung 0240, 0045 Sanky 0048, 0039 Sansui 0000, 0067, 0209,0041, 0479 Sanyo 0047, 0240, 0104 Scott 0184, 0045,0121, 0043 Sears 0035, 0037, 0047,0000, 0042, 0104 Semp 0045 Sharp 0048 Shintom 0072 Shogun 0240 Singer 0072 Sony 0035, 0032, 0000,0033, 0636 Sylvania 0035, 0081, 0000,0043 Symphonic 0000 TMK 0240 Tatung 0041 Teac 0000, 0041 Technics 0035, 0162 Teknika 0035, 0037, 0000 Thomas 0000 Tivo 0618, 0636 Toshiba 0045, 0043 Totevision 0037, 0240 Unitech 0240
continued on next page...
15
MANUFACTURER’S CODES
Setup Codes for VCRs and PVRs (continued):
Vector 0045 Vector Research 0038 Video Concepts 0045 Videosonic 0240 Wards 0060, 0035,0048, 0047, 0081, 0240,0000, 0042, 0072,0149,
White Westinghouse 0209, 0072, 0278 XR-1000 0035, 0000, 0072 Yamaha 0038 Zenith 0039, 0000, 0209, 0033,0479
Setup Codes for TVs:
AOC 0030, 0019 Admiral 0093, 0463 Aiko 0092 Aiwa 0701 Akai 0030 Alaron 0179 America Action 0180 Ampro 0751 Anam 0180 Audiovox 0451, 0180,0092, 0623 Baysonic 0180 Belcor 0019 Bell & Howell 0154, 0016 Bradford 0180 Brockwood 0019 Broksonic 0236, 0463 CXC 0180 Candle 0030, 0056 Carnivale 0030 Carver 0054 Celebrity 0000 Cineral 0451, 0092 Citizen 0060, 0030, 0056,0039, 0092 Concerto 0056 Contec 0180 Craig 0180 Crosley 0054 Crown 0180, 0039 Curtis Mathes 0047, 0054,0154, 0051, 0451,0093, 0060,0030, 0145,0056,
Daewoo 0451, 0019,0039, 0092, 0623, 0624 Daytron 0019 Denon 0145 Dumont 0017, 0019 Dwin 0720, 0774
0760
0016, 0039, 0166,0466, 1147, 1347
16
Electroband 0000 Emerson 0154, 0236, 0463,0180, 0282, 0178, 0019,0179, 0039, 0623,
Envision 0030 Fisher 0154 Fujitsu 0179, 0683 Funai 0180, 0179, 0171 Futuretech 0180 GE 0047, 0051, 0451,0093, 0282, 0178, 0021,0135, 1147, 1347 Gibralter 0017, 0030, 0019 GoldStar 0030, 0178,0019, 0056 Gradiente 0053, 0056 Grunpy 0180, 0179 Hallmark 0178 Harley Davidson 0179 Harman/Kardon 0054 Harvard 0180 Hitachi 0145, 0056,0016 Infinity 0054 Inteq 0017 JBL 0054 JCB 0000 JVC 0053 KEC 0180 KTV 0180, 0030, 0039 Kenwood 0030, 0019 Konka 0628, 0632, 0638,0703, 0707 LG 0056 LXI 0047, 0054, 0154, 0156,0178 Logik 0016 Luxman 0056 MGA 0150, 0030,0178, 0019 MTC 0060, 0030,0019, 0056 Magnavox 0054, 0030, 0179 Majestic 0016 Marantz 0054, 0030 Matsushita 0250 Megatron 0178, 0145 Memorex 0154, 0250, 0463,0150, 0178, 0179, 0056,0016 Midland 0047, 0017, 0051, 0039, 0135 Minutz 0021 Mitsubishi 0093, 0150, 0178, 0019 Motorola 0093 Multitech 0180 NAD 0156, 0178,0166 NEC 0030, 0019, 0056 NTC 0092 Nikko 0030, 0178, 0092 Onwa 0180 Optimus 0154, 0250, 0166 Optonica 0093, 0165
0624
continued on next page...
17
MANUFACTURER’S CODES
Setup Codes for TVs (continued):
Orion 0236, 0463, 0179 Panasonic 0051, 0250 Penney 0047, 0156,0051, 0060, 0030, 0178,0021, 0019, 0056,0039,
Philco 0054, 0463, 0030,0145, 0019 Philips 0054 Pilot 0030, 0019, 0039 Pioneer 0166, 0679 Portland 0019, 0039, 0092 Princeton 0717 Prism 0051 Proscan 0047 Proton 0178, 0466 Pulsar 0017, 0019 Quasar 0051, 0250, 0165 RCA 0047, 0051, 0093,0019, 0090, 0135, 0679,1047, 1147, 1347 RadioShack 0047,0154, 0165, 0180,0030, 0178, 0019, 0056, 0039 Realistic 0154, 0165,0180, 0030, 0178, 0019, 0056,0039 Runco 0017, 0030, 0603 SSS 0180, 0019 Sampo 0030, 0039 Samsung 0060, 0030, 0178,0019, 0056 Samsux 0039 Sansei 0451 Sansui 0463 Sanyo 0154 Scimitsu 0019 Scotch 0178 Scott 0236, 0180,0178, 0019, 0179 Sears 0047, 0054, 0154,0156, 0178, 0179, 0056,0171 Semivox 0180 Semp 0156 Sharp 0093, 0165, 0039,0688 Shogun 0019 Signature 0016 Sony 0000 Soundesign 0180, 0178, 0179 Squareview 0171 Starlite 0180 Supreme 0000 Sylvania 0054, 0030 Symphonic 0180, 0171 TMK 0178, 0056 TNCi 0017 Tandy 0093 Technics 0051, 0250 Technol Ace 0179 Techwood 0051, 0056
0135, 1347
18
Teknika 0054, 0180, 0150, 0060,0019, 0179, 0056, 0016,0039, 0092 Telefunken 0056 Toshiba 0154, 0156, 0060, 1256 Totevision 0039 Vector Research 0030 Victor 0053 Vidikron 0054 Vidtech 0178, 0019 Wards 0054, 0165,0030, 0178, 0021, 0019,0179, 0056, 0016 White Westinghouse 0463, 0623, 0624 Yamaha 0030, 0019 Zenith 0017, 0463, 0016, 0092,0624
Setup Codes for TV/VCR Combos:
Broksonic 0002, 0479 (for TV use 0463) Citizen 0278 Colt 0072 Curtis Mathes 0035 (for TV use 0051) Daewoo 0278 (for TV use 0624) Emerson 0002, 0278 (for TV use 0624), 0479 (for TV use 0463) Funai 0000 GE 0035 (for TV use 0051), 0048 (for TV use 0093),
GoldStar 0037 (for TV use 0056) Harley Davidson 0000 Hitachi 0000 Lloyd’s 0000 Magnasonic 0278 Magnavox 0000, 0081 (for TV use 0054) Magnin 0240 Memorex 0037, 0162 (for TV use 0250), 1162 MGA 0240 Mitsubishi 0048 (for TV use 0093) Optimus 0162 (for TV use 0250), 1162,1262 Orion 0002, 0479 (for TV use 0463) Panasonic 0035 (for TV use 0051),0162 (for TV use 0250), 1162 Penney 0035 (for TV use 0051),0037 (for TV use 0056), 0240 Quasar 0035 (for TV use 0051), 0162 (for TV use 0250) RCA 0035 (for TV use 0051), 0048 (for TV use 0093),
Sansui 0000, 0479 (for TV use 0463) Sanyo 0240 Sears 0000, 0037 (for TV use 0056) Sharp 0048 (for TV use 0093) Sony 0000, 0032 (for TV use 0000) Sylvania 0081 (for TV use 0054) Symphonic 0000, 0563 Thomas 0000 White Westinghouse 0278 (for TV use 0624) Zenith 0000
0060 (for TV use 0047), 0240
0060 (for TV use 0047), 0240
19
SEARCHING FOR YOUR CODE
If your home entertainment device does not respond to the Atlas Universal Remote Control after trying all of the codes listed for your brand,or if your brand is not listed at all, try searching for your code.
NOTE: To search for a code in the CBL mode, you’ll first need to unlock the cable ID Lock – see “Programming ID Lock”on page 22.
For example, to search for a code for your TV:
1. Turn on your TV.
2. On the remote control,press TV once.
Then press and hold SETUP until the TV key blinks twice,then release SETUP.
3. Enter 9 - 9 - 1.The TV key will blink twice.
4. Aim the remote control at the the TV and slowly
alternate between pressing POWER and TV. Stop when the TV turns off.
NOTE: In the search mode,the remote control will send IR codes from its library to the selected device, starting with the most popular code first.
5. Press SETUP once to lock in the code.
6. To search for the codes of your other devices,
repeat steps 1 through 5,but substitute the appropriate key (i.e.,AUD, VCR,or CBL) for the (Audio,VCR,or Cable) device you are searching for.
20
CHECKING THE CODES
If you have set up the Atlas Universal Remote Control using the Searching For Your Code procedure (on the previous page),you may need to find out which four-digit code is operating your equipment.For example,to find out which code is operating your TV:
1. On the remote control,press TV once.
Then press and hold SETUP until the TV key blinks twice,then release SETUP.
2. Enter 9 - 9 - 0.The TV key will blink twice.
3. To view the code for the first digit, press 1 once.
Wait 3 seconds and count the number of times the TV key blinks (e.g.,3 blinks = 3) and write down the number in the leftmost TV Code box (see below).
NOTE: If a code digit is “0”,the selected mode key will not blink.
4. Repeat step 3 three more times for remaining
digits. Use 2 for the second digit,3 for the third digit, and 4 for the fourth digit.Finish writing down the code in the TV Code boxes below.
5. To check for other device codes,repeat steps 1
through 4,but substitute the appropriate key (i.e., AUD,VCR,or CABLE) for the (Audio,VCR, or Cable) device you are checking.Write down the codes in the appropriate boxes below.
AUD Code
Audio Device ____________________
VCR Code
TV Code
CABLE Code
21
PROGRAMMING ID LOCK
The Atlas Universal Remote Control is preprogrammed and locked at the factory to operate a Scientific Atlanta cable converter.
However, if you have another brand or model of cable converter and interactive service that you would like to control, then you’ll need to perform the following steps to unlock the cable ID Lock,enter in a new manufacturer’s code, and lock the ID Lock again.
1. Turn on the cable converter.
2. On the remote control,press CBL once.
Then press and hold SETUP until the CBL key blinks twice,then release SETUP.
3. Enter 9 - 8 - 2.The CBL key will blink
four times.
4. Perform the instructions in Programming
Device Control on page 8 to program device control for the desired cable converter and interactive service. Upon completion, perform the remaining steps (5 and 6 on this page) to again lock the ID lock.
5. On the remote control,press CBL once.
Then press and hold SETUP until the CBL key blinks twice,then release SETUP.
6. Enter 9 - 8 - 2.The CBL key will blink twice.
22
PROGRAMMING CHANNEL CONTROL LOCK
By default, the remote control’s channel-control capabilities are locked to the cable converter. The affected keys* are 0~ 9,CH+, CH-,ENTER,and LAST.This will guarantee that you do not inadvertently change a channel on your TV or VCR.However,you can de-activate this feature to allow full access to these keys in the TV and VCR modes.
*NOTE: This feature does not affect the AUD mode.
To De-Activate Channel Control Lock:
1. On the remote control,press CBL once.
Then press and hold SETUP until the CBL key blinks twice,then release SETUP.
2. Enter 9 - 7 - 3.
3. Press CH- once. The CBL key will blink
four times.
4. Now,the remote control will provide TV and
VCR channel-control capabilities while in the TV or VCR mode.
To Re-Activate Channel Control Lock:
1. On the remote control,press CBL once.
Then press and hold SETUP until the CBL key blinks twice,then release SETUP.
2. Enter 9 - 7 - 3.
3. Press CH+ once. The CBL key will blink twice.
4. Now,regardless of what mode you select
(i.e., TV,VCR,or CBL), only the channel control capability of your cable converter will be accessible.
23
USING THE MASTER POWER KEY
The Atlas Universal Remote Control has a unique feature that allows you to sequentially turn on or off all of your home entertainment devices with a single key press.
To Program The Master Power Key:
1. On the remote control,press and hold SETUP
until the last-selected device key blinks twice, then release SETUP.
2. Enter 9 - 9 - 5.
3. For the first device you want in the power on
sequence,press a device key (e.g.,CBL) once and then press POWER once.
4. Repeat step 3 up to three more times to add the
second,third,and fourth device,as desired.
5. To save the settings and exit the program,press
and hold SETUP until the CBL key blinks twice, then release SETUP.
To Clear The Master Power Key:
1. Perform steps 1 and 2 in the above section.
2. Press POWER once.
3. To clear the settings and exit the program, press
and hold SETUP until the CBL key blinks twice, then release SETUP.
To Operate The Master Power Key:
1. After programming,point the remote control
at the devices. Press CBL once.
2. Press MASTER POWER once to sequentially turn
on or off all home entertainment devices.
NOTE: MASTER POWER only works in the CBL mode. If it is not programmed, only the cable converter will turn on or off. In any other mode, pressing MASTER POWER once will turn on or off the selected device.
3. You will see the devices turn on or off
according to the programmed sequence.
24
RE-ASSIGNING DEVICE KEYS
The Atlas Universal Remote Control can be set up to control a second TV or VCR, or any combination of up to four home entertainment devices. For example, to have the unit control a TV, a Cable Converter, and two VCRs,you will need to re-assign the unused AUD key to operate the second VCR as follows:
1. On the remote control,press VCR once.
Then press and hold SETUP until the VCR key blinks twice,then release SETUP.
2. Enter 9 - 9 - 2.The VCR key will blink twice.
3. Press VCR once, then press AUD once. The
VCR key will blink twice.
4. The AUD key is now ready to be programmed
for your second VCR. See Programming Device Control on page 8.
To re-assign other device keys,repeat steps 1 to 4 and substitute the key sequence using the following chart:
To Re-Assign Perform Key Sequence
TV as 2nd VCR key: SETUP - 9 - 9 - 2 - VCR - TV
TV as 2nd Audio key: SETUP - 9 - 9 - 2 - AUD - TV
TV as 2nd Cable key: SETUP - 9 - 9 - 2 - CBL - TV
TV back to TV: SETUP - 9 - 9 - 2 - TV - TV
VCR as 2nd TV key: SETUP - 9 - 9 - 2 - TV - VCR
VCR as 2nd Audio key: SETUP - 9 - 9 - 2 - AUD - VCR
VCR as 2nd Cable key: SETUP - 9 - 9 - 2 - CBL - VCR
VCR back to VCR: SETUP - 9 - 9 - 2 - VCR - VCR
AUD as 2nd TV key: SETUP - 9 - 9 - 2 - TV - AUD
AUD
as 2nd Cable key:
AUD
back to
AUD
:
Upon completion of a re-assignment,the selected mode key will blink twice to confirm your selection.Then, you’ll need to program device control (see Programming Device Control on page 8).
SETUP - 9 - 9 - 2 - CBL - AUD
SETUP - 9 - 9 - 2 - AUD - AUD
25
USING MACROS
With programming, the MACRO key on your Atlas Universal Remote Control can be setup to perform repetitive, time­consuming operations through the press of a single key. A macro can be used to control a home theater operation, to set a favorite channel, or for other multiple functions you would like to control with one key press (see exam­ples below).Moreover, the MACRO key can hold up to three macros with up to 15 key presses each. The macros are then activated,in the order they were stored, each time you press this key.
NOTE: If three macros are stored,programming a new macro will erase the first original macro.Thereafter, each new macro will overwrite the next original macro.
Example – Programming A Favorite Channel
With so many channels available through your cable provider,you can program a macro that directly selects a favorite channel with one key press.
For example, let’s assume your favorite cable programs are on channel 71.Use the following instructions to program a macro for direct access of this channel:
NOTE: This example assumes the TV tuner is connected directly to the cable line and not through a cable box.
1. On the remote control,press and hold SETUP
until the last-selected device key blinks twice, then release SETUP.
2. Enter 9 - 9 - 5.
3. Press MACRO once.
4. Press TV once.
5. Enter the channel number,7 -1.
NOTE: If you have access to over 100 channels,enter 0-7-1.Moreover, if the original remote control required pressing an Enter key to change the channel, also press the ENTER key after the channel number (e.g., 0-7-1-ENTER).
6. Press and hold SETUP until the last-selected
device key blinks twice,then release SETUP.
Now when you press MACRO,you will instantly see cable channel 71 on your TV set.
26
To Clear A Macro:
1. On the remote control,press and hold SETUP
until the last-selected device key blinks twice, then release SETUP.
2. Enter 9 - 9 - 5.
3. Press MACRO once.
4. Press and hold SETUP until the last-selected
device key blinks twice,then release SETUP.
NOTE:A macro will be cleared in the order it was originally stored.
27
CHANGING VOLUME LOCK
On the Atlas Universal Remote Control, Global Volume Lock is set to TV, so you can control TV volume while in the TV, VCR,or Cable mode.If desired, you can still perform Individual Volume Unlock on a selected device to set its volume control for independent operation.
NOTE: If you lock the volume controls to the AUDIO mode,you will still have control of the audio device’s volume in all other modes (i.e., TV,VCR,and CBL).
To Unlock Volume Control For A Single Device (Individual Volume Unlock):
1. Assuming Global Volume Lock is active, select a
mode on the remote control that you want to unlock (e.g.,CBL) and press it once. Next, press and hold SETUP until the device key blinks twice, then release SETUP.
2. Enter 9 - 9 - 3.
3. Press VOL– once.The selected device key (in
step 1) will blink four times.
4. Repeat steps 1 through 3 (of this section) for
each device you want volume to be unlocked.
5. Now,after you select a device that has volume
unlocked (e.g.,CBL), pressing VOL+, VOL–,or MUTE, will control the device’s volume only in its own mode.
To Unlock All Volume Control (Global Volume Unlock):
NOTE: Performing these instructions will set independent volume control for all programmed devices (e.g., TV volume control in TV mode,VCR volume in VCR mode,etc.).
1. On the remote control,press and hold SETUP
until the last-selected device key blinks twice, then release SETUP.
2. Enter 9 - 9 - 3.
3. Press VOL+ once. The last-selected device key
(in step 1) will blink four times.
28
To Lock Volume Control To One Mode (Global Volume Lock):
NOTE: If you lock the volume controls to the AUDIO mode,you will still have control of the audio device’s volume in all other modes (i.e., TV,VCR,and CBL).
1. On the remote control,press and hold SETUP
until the last-selected device key blinks twice, then release SETUP.
2. Enter 9 - 9 - 3.
3. Select a mode (e.g., TV) where you want to
globally lock the volume controls.The selected device key will blink twice.
4. Now,when you press VOL+, VOL–,or MUTE,the
volume of the selected device (e.g.,TV) can be controlled regardless of mode.
3. Enter 9 - 9 - 4. The selected device key will
blink twice.
4. Press the destination key twice (where the key-
moved key is stored). The selected device key will blink twice.
29
TROUBLESHOOTING
PROBLEM: Mode key does not blink when you press a key.
SOLUTION: Replace the batteries with two (2) new AA
alkaline batteries (see page 7).
PROBLEM: Mode key blinks when you press a key,but home
SOLUTION: Make sure you are aiming the remote control at
PROBLEM: The remote control does not control home
SOLUTION: Try all listed codes for the device brand being set
PROBLEM: TV/VCR combo does not respond properly.
SOLUTION: Use the VCR codes for your brand. Some combo
PROBLEM: No volume on a second TV.
SOLUTION: Follow instructions in Changing Volume Lock
PROBLEM: CH+ , CH – ,and LAST do not work for your
SOLUTION: Due to RCA design (1983-1987), only the original
PROBLEM: Changing channels does not work properly.
SOLUTION: If original remote control required pressing
PROBLEM: Tried “Search Method” and still could not find a
SOLUTION: Try the “Search Method” again after clearing out
PROBLEM: Remote control does not turn on Sony or Sharp
SOLUTION: For power on, these products require program-
entertainment device does not respond.
your home entertainment device and that you are within 15 feet of the device you are trying to control.
entertainment devices or commands are not performing properly.
up.Make sure all devices can be operated with an infrared remote control.
units may require both a TV code and a VCR code for full operation (see page 9).
(see page 28).
RCA TV.
remote control will operate these functions.
ENTER to change channels,press ENTER on the remote control after entering a channel number.
working code.
the device key as follows: Press and hold SETUP until mode key blinks twice,then release. Next enter 9 - 9 - 2. Then press and release the mode key to be cleared twice.
TV/VCR Combo.
ming TV codes on the remote control.For Sony, use TV code 0000 and VCR code 0032.For Sharp, use TV code 0093 and VCR code 0048.
30
ADDITIONAL INFORMATION
This product does not have any user-serviceable parts. Opening the case, except for the battery cover, may cause permanent damage to your Atlas Universal Remote Control.
For help via the Internet, visit us at:
www.urcsupport.com
For help via e-mail,contact us at:
cablehelp@ueic.com
Copyright 2002 by Universal Electronics Inc.No part of this publication may be reproduced,transmitted, tran­scribed, stored in any retrieval system, or translated to any language,in any form or by any means, electronic, mechanical, magnetic, optical, manual,or otherwise, with­out prior written permission of Universal Electronics Inc.
M4030 04/02
31
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
