Universal Electronics 3013 User Manual

DIRECTV

Universal Remote Control

User Guide

CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Controlling Your DIRECTV

Setting Up Your DIRECTV Remote . . . . . . . . . . . . . . . . . . . . . . 7

Onscreen Remote Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Controlling Your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Deactivating TV Input Select Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Controlling Other Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Searching for TV, AV1 or AV2 Codes . . . . . . . . . . . . . . . . . . . . . . . . . 10

Verifying the Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Locking Volume to AV1, AV2 or TV . . . . . . . . . . . . . . . . . . . . .11

Restoring Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . 12

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

DIRECTV Setup Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Setup Codes for DIRECTV Setup Codes for DIRECTV Setup Codes for DIRECTV

Setup Codes, Other Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setup Codes for TV/DVD Combos . . . . . . . . . . . . . . . . . . . . . . 22

Setup Codes for TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . 24

Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Setup Codes for Satellite Set-top Boxes . . . . . . . . . . . . . . . .28

Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . . .29

Setup Codes for Audio Receivers. . . . . . . . . . . . . . . . . . . . . .33

Setup Codes for Audio Amplifiers. . . . . . . . . . . . . . . . . . . . . . 36

Setup Codes for Audio Accessories . . . . . . . .

Repair or Replacement Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Compliance with FCC Rules and Regulations. . . . . . . . . . . . . . . . . .

Receiver. . . . . . . . . . . . . . . . . . . . . . . . .7

Receivers. . . . . . . . . . . . . . . . . . 13

HD Receivers . . . . . . . . . . . . . . .13

DVRs. . . . . . . . . . . . . . . . . . . . . .14

. . . . . . . . . . . .36

INTRODUCTION

Congratulations! You now have an exclusive DIRECTV® Universal Remote Control that will control four components, including a DIRECTV Receiver, TV, and two stereo or video components (for example, a DVD, stereo, or second TV). Moreover, its sophisticated technology allows you to consolidate the clutter of your original remote controls into one easy-to-use unit that's packed with features such as:

s Four-position MODE slide switch for easy component

selection

s Code library for popular video and stereo components s Code search to help program control of older or dis-

continued components

s Memory protection to ensure you will not have to re-

program the remote when the batteries are replaced

Before using your DIRECTV Universal Remote Control, you may need to program it to operate with your particular component. Please follow the instructions detailed in this guide to set up your DIRECTV Universal Remote Control so you can start enjoying its features.

FEATURES AND FUNCTIONS

Key Charts

Press this key… To…

Slide the MODE switch to the DIRECTV, AV1, AV2 or TV positions to select the component

you want to control. A green LED under each switch position indicates t he component being controlled.

Press TV INPUT to select the available inputs on your TV. NOTE: Additional setup is required to deactivate the TV INPUT key. (See instructions on page 9.)

Press FORMAT to cycle through the resolution and screen formats. Each press of the key cycles to the next available format and /or resolution. (Not ava

all DIRECTV

Press PWR to turn on/off the piece of equipment the mode switch is set to.

Press TV POWER ON/OFF to turn the TV and DIRECTV Receiver on or off. (NOTE: These keys are only active after the remote has been setup for your TV. See page 8.)

Receivers.)

ilable on

Use these keys to control your DIRECTV DVR or your VCR, DVD, or CD/DVD player.

On a DIRECTV DVR, enables one-

touch record for any selected program.

Replay jumps back 6 seconds a plays video from that location. You can also hold the button down to jump back to the

beginning.

Advance jumps ahead in a recording. You can also hold the button down to jump forward to the end.

Use GUIDE to display the DIRECTV Program Guide. Pre ss twice to see programs by category.

Press this key… To…

ACTIVE displays the DIRECTV Active

Channel which includes local weather, horoscopes and more!

For non-DVR boxes, pressing LIST takes you to the To Do List. For DVR boxes, LIST takes you to the PLAYLIST (recordings).

(Not available on all DIRECTV

Press EXIT to exit menu screens and the Program Guide and return to live TV.

Press SELECT to choose highlighted items in menu screens or the Program Guide.

Use the ARROW keys to move around in the Program Guide and menu screens.

Press BACK to return to the previously displayed screen.

Press MENU to display the Quick Menu in DIRECTV mode, or other menu for another selected device.

Use INFO to display current channel and program information when watching live TV or in the Guide.

Displays various opt ions while viewing live TV, the Guide or the Playlist. Press YELLOW* to display TV Options Press BLUE* in full-screen TV to display the Mini-Guide Press RED* in the Guide to jump 12 hours back. Press GREEN* in the Guide to jump 12 hours forward. *Other functions vary–look for onscreen

hints or refer to your DIRECT V user guide. (Not available on all DIRECTV Receivers.)

Press VOL to raise or lower the sound volume. The volume key is only active when the remote is set up for your TV.

Receivers.)

Receiver's

Press this key… To…

While watchi ng TV, press CHAN (or

) to select the next higher (or

CHAN

lower) channel. While in the DIRECTV

menu, press PAGE+ (or PAGE-) to page up (or down) through available channels in the Guide.

Press MUTE to turn the sound off or back on.

Press PREV to return to the last channel viewed.

Press the number keys to directly enter a channel number (e.g. 207) while watching TV or in the Guide. Press DASH to separate main and subchannel numbers. Press ENTER to activate number entries quickly.

Program Guide or

INSTALLING BATTERIES

1. On the back of the remote control, push down on the door (as shown), slide the battery cover off, and remove the used batteries.

2. Obtain two (2) new AA alkaline batteries. Match their +and - marks to the + and - marks in the battery case, then insert them.

3. Slide the cover back on until battery door clicks into place.

CONTROLLING YOUR DIRECTV® RECEIVER

The DIRECTV® Universal Remote Control comes programmed to work with most DIRECTV Receivers. Should the remote control not work with your DIRECTV Receiver, you will need to set up the remote control by performing the following steps.

Setting Up Your DIRECTV Remote

1. Locate the DIRECTV Receiver's brand and model number (on the back or bottom panel) and write it in the spaces below.

BRAND:

......................................................................

MODEL: ......................................................................

2. Locate the 5-digit code for your DIRECTV® Receiver. (See page 14.)

3. Power on the DIRECTV Receiver.

4. Slide the MODE switch to the DIRECTV position.

5. Press and hold the MUTE and SELECT keys at the same time until the green light under the flashes twice, then release both keys.

6. Using the number keys, enter the 5-digit code. If performed correctly, the green light under the DIRECTV position flashes twice.

7. Aim the remote at your DIRECTV Receiver and press the PWR key once. The DIRECTV Receiver should turn off; if it does not, repeat steps - , tr ying each code for your brand until you find the correct code.

8. For future reference, write down the working code for your DIRECTV Receiver in the blocks below:

DIRECTV position

ONSCREEN REMOTE SETUP

Once your remote is setup to work with your DIRECTV Receiver, you can set it up for your other equipment using the steps detailed on the following pages, or you can set it up onscreen by pressing MENU, then SELECT on Settings, Setup in the Quick Menu, then selecting Remote from the left menu.

CONTROLLING YOUR TV

Once you have successfully set up your DIRECTV Remote to operate your DIRECTV Receiver, you can set it up to control your TV. We recommend you use the on-screen steps described on page 8, but you can also use the manual method below:

1. Turn on the TV.

NOTE

: Please read steps 2-5 completely before proceed-

ing. Highlight or write down the codes and component you wish to set up before moving on to step 2.

2. Locate the 5-digit code for your TV. (See “Setup Codes for TVs ” on page 15.)

3. Slide the MODE switch to the TV position.

4. Press and hold the MUTE and SELECT keys at the same time until the green light under the TV position flashes twice, then release both keys.

5. Using the number keys enter the 5-digit code for your brand of TV. If performed correctly, the green light under TV flashe twice.

6. Aim the remote at your TV and press the PWR key once. Your TV should turn off. If it does not turn off, repeat steps , trying each code for your brand until you find the correct code.

4ot6

sposition

7. Slide the MODE switch to the DIRECTV position. Press TV POWER. Your TV should turn on.

8. For future reference, write down the working code for your TV in the blocks below:

DEACTIVAT

If you want to deactivate the TV INPUT key, follow the steps below. Pressing the

1. Slide the

2. Press and hold the MUTE and SELECT keys until the

green light under the realease both keys.

3. Using the number keys, enter

under the

ING TV INPUT INPUT SELECT KEY

TV INPUT Key

MODE switch to the TV position.

will now do nothing.

TV position flashes twice, then

9-6-0

(The green light

TV position flashes four times .)

CONTROLLING OTHER COMPONENTS

The AV1 and AV2 switch positions can be setup to control a VCR, DVD, STEREO, second DIRECTV Receiver or second TV. We recommend you use the onscreen steps described on page 8, but you can also use the manual method below:

1. Turn on the component you wish to control (e.g. your DVD Player).

2. Locate the 5-digit code for your component. (See “Setup Codes, Other Devices” starting on page 15.)

3. Slide the MODE switch to the AV1 (or AV2) position.

4. Press and hold the MUTE and SELECT keys at the same time until the green light under AV1 (or AV2) flashes twice, then release both keys.

5. Using the keys, enter the 5-digit code for the brand of component being set up. If performed correctly, the green light under the selected position flashes twice.

6. Aim the remote at your component and press the PWR key once. The component should turn off; if it does not, repeat steps , trying each code for your brand until you find the correct code.

number

46 ot

7. Repeat steps 1 through 6 to set up a new component under AV2 (or AV1).

8. For future reference write down the working code for the component(s) set up under AV1 and AV2 below:

AV1:

COMPONENT: ___________________ AV 2 :

COMPONENT: ___________________

SEARCHING FOR TV, AV1 OR AV2 CODES

If you were unable to find the code for your brand of TV or component, you can try a code search. This process may take up to 30 minutes.

1. Turn on the TV or component. Insert a tape or disk if applicable.

2. Slide the MODE switch to the TV, AV1 or AV2 position, as desired.

3. Press and hold the MUTE and SELECT keys at the same time until the green light under the selected switch position flashes twice, th

4. Enter 9-9-1 followed by one of the following fourdigits:

en release both keys.

COMPONENT TYPE COMPONENT ID #

Satellite 0

TV 1

VCR/DVD/PVR 2

Stereo 3

5. Press PWR, or other functions (e.g. PLAY for VCR) you want to use.

6. Point the remote at the TV or component and press

CHAN

. Repeatedly press CHAN until the TV or component turns off or performs the action you selected in step 5.

NOTE: Ever y time CHAN

advances to the next code and power is transmitted to the component.

is pressed the remote

7. Use the CHAN key to step back a code.

8. When the TV or component turns off or performs the action you selected in step 5, stop pressing the CHAN

SELECT key.

NOTE: If the light flashes 3 times before the TV or com-

ponent responds, you've cycled through all codes and the code you need is not available. You must use the remote that came with your TV or component.

key. Then, press and release the

Verifying the Codes

Once you have set up the DIRECTV® Universal Remote Control using the above steps, use the following instructions to find out the 5-digit code to which your component responded:

1. Slide the MODE switch to the appropriate position.

2. Press and hold the MUTE and SELECT keys at the same time until the green light under the selected switch position flashes twice, then release both keys.

3. Enter 9-9-0. (The green light under the selected switch position flashes twice.)

4. To view the first digit in the code, Press and release the number 1 key. Wait three seconds, and count the number of times the green light flashes. Write this number down in the leftmost TV, AV1 or AV2 code box found on page 10.

5. Repeat step 4 four more times for the remaining digits; i.e., press number 2 for the second digit, 3 for the third digit, 4 for the fourth digit and 5 for the final digit.

CHANGING VOLUME LOCK

Depending on how you set up your remote, the VOL and MUTE may control the volume only on your TV, regardless

of the position of the MODE switch. This remote can be set up so that the VOL and MUTE keys work only with the component selected by the MODE switch. To enable this feature, perform the following steps:

1. Press and hold the MUTE and SELECT keys at the same time until the green light under the position flashes twice, then release both keys.

2. Using the number keys, enter 9-9-3. (The green light flash twice.)

3. Press and release the VOL+ key. (The green light flashes 4 times.)

Now the VOL and MUTE keys will work only for the component selected by the MODE switch position.

DIRECTV

Locking Volume to AV1, AV2 or TV

1. Slide the MODE switch to the AV1, AV2 or TV position to lock the volume.

2. Press and hold the MUTE and SELECT keys at the same time until the green light under the selected position flashes twice, then release both keys.

3. Using the number keys, enter 9-9-3. (The green light flashes twice.)

4. Press and release the SELECT key. (The green light flashes twice.)

NOTE: DIRECTV

so the remote will not allow the user to lock volume to the DIRECTV mode.

Receivers don’t have volume control,

RESTORING FACTORY DEFAULT SETTINGS

To reset all the functions of the remote control to the factory defaults (the original, out-of-the-box settings), follow these steps:

1. Press and hold the MUTE and SELECT keys at the same time until the green light flashes twice, then release both keys.

2. Using the number keys, enter 9-8-1. (The green light flashes 4 times.)

TROUBLESHOOTING

PROBLEM: Light at the top of the remote blinks when you

press a key, but the component does not respond. SOLUTION 1: Try replacing the batteries (see page 7).

SOLUTION 2: Make sure you are aiming the DIRECTV Universal Remote Control at your home entertainment component and that you are within 15 feet of the component you are tr ying to control.

PROBLEM: The DIRECTV Universal Remote Control does not control component or commands are not recognized properly.

SOLUTION

set up. Make sure all components can be operated with an infrared remote control.

PROBLEM: TV/VCR combo does not respond properly. SOLUTION: Use the VCR codes for your brand. Some combo

units may require both a TV code and a VCR code for full operation (see page 8).

PROBLEM: CHAN

your RCA TV. SOLUTION: Due to RCA design for certain models (1983-

1987), only the original remote control will operate these

functions.

PROBLEM: Changing channels does not work properly. SOLUTION: If original remote control required pressing

ENTER to change channels, press ENTER on the DIRECTV

Universal remote control after entering a channel number. PROBLEM: Remote control does not turn on Sony or Sharp

TV/VCR Combo. SOLUTION: For power on, these products require setting up

TV codes on the remote control. For Sony, use TV code 10000 and VCR code 20032. For Sharp, use TV code 10093 and VCR code 20048. (See “Controlling Other Components” on page 9.)

: Try all listed codes for the device brand being

, CHAN , and PREV do not work for

DIRECTV SETUP CODES

Setup Codes for DIRECTV® Receivers

DIRECTV all models 00001, 00002 Hughes Network Systems (most

models) Hughes Network Systems

models GAEB0, GAEB0A, GCB0, GCEB0A, HBH-SA, HAH-SA

GE models GRD33G2A and GRD33G3A, GRD122GW

Philips models DSX5500 and DSX5400

Proscan models PRD8630A and PRD8650B

RCA models DRD102RW, DRD203RW, DRD301RA, DRD302RA, DRD303RA, DRD403RA, DRD703RA, DRD502RB, DRD 503RB, DRD505RB, DRD515RB, DRD523RB, and DRD705RB

DRD440RE, DRD460RE, DRD480RE, DRD431RG, DRD450RG, DRD451RG, DRD485RG,DRD486RG, DRD430RGA, DRD450RGA, DRD485RGA, DRD435RH, DRD455RH, and DRD486RH

Samsung model SIR-S60W 01109 Samsung models SIR-S70, SIR-

S75, SIR-S300W, and SIRS310W

Sony models (All models except TiVo and Ultimate TV)

DRD430RG,

Setup Codes for DIRECTV

DIRECTV all models 00001, 00002 Hitachi model 61HDX98B 00819 HNS models HIRD-E8, HTL-HD 01750 LG model LSS-3200A,

HTL-HD Mitsubishi model SR-HD5 01749, 00749 Philips model DSHD8 Proscan model PSHD105 00392 RCA models DTC-100, DTC-210 00392 Samsung model SIR-TS360 01609 Samsung models SIR-TS160 01276

00749

01749

00566

00099

00566

00392

01108

01639

HD Receivers

01750

00R 01749

+ 28 hidden pages
