REMOTE USER GUIDE

Safety Instructions

You must keep safety in mind while using this device. Keep these and any other instructions for future reference. Observe Warnings: Carefully follow all warnings on the device and in the operating instructions. Heat: Do NOT place the device near heat sources such as radiators, stoves, heat registers, or other appliances that produce heat.

Care and Use

Cleaning: Do NOT use liquid, abrasive, solvent, or aerosol cleaners. Use a damp cloth for cleaning.

When Not in Use: Remove the batteries if this device is to be left unattended or unused for a long period of time.

Refer servicing to qualied personnel when a

solid object or liquid has fallen onto or into the device.

Do NOT attempt to service this device. Refer all

servicing to qualied personnel. Opening covers

other than the battery cover will void the warranty.

Publishing Information

Copyright © 2015. EchoStar Technologies L.L.C., Englewood, Colorado 80112. All rights reserved. The information in this User Guide may change without notice. Revisions may be issued to tell you about such changes.

Send comments or questions about this User Guide to techpubs@echostar.com or Technical Publications, EchoStar Technologies L.L.C, 90 Inverness Circle East, Englewood, Colorado 80112.

Document Number: 206231 Printed in

DISH is a registered trademark of DISH Network L.L.C.

All product names, trade names, or corporate names mentioned in this User Guide are acknowledged to be the proprietary property of the registered owners.

Insert the Batteries

Push the tab toward

the top of the remote to release the battery door latch and then lift the battery door from the remote.

Insert 2 AA batteries, making sure to match the plus (+) ends with the plus markings on the battery case.

Replace the remote battery cover.

Pairing Remote to the Hopper® or Joey® Receiver

For the remote to work with either a Hopper® or Joey® receiver, it must be paired. Use the following procedure to pair the remote.

Verify the antenna

E OT M

E R

NA N E T

N A

is installed on the back of your Hopper receiver. Joey receivers have an internal antenna.

Hopper:

Joey:

SYSTEM

INFO

SYS INFO

Turn your receiver and TV on, and press SYSTEM INFO on the front panel.

Conrm that you

see the System Info screen.

Press and release the SAT button on your remote (on the side of the remote). Wait until you hear a tone and see the remote listed on the screen. After pairing, you should hear a series of ascending tones.

Conrm that your

remote operates your receiver by pressing remote buttons. If this is not working, go back to step 4.

SAT Mode

To use the features described in this section, make sure you are in SAT mode by pressing the SAT Mode button. Note: Some features may not be available depending on your receiver model.

Apps

Displays the Apps menu

Home

Access receiver features and settings

Back/Live TV

Return to previous menu. Press and hold to return to viewing live TV

Options

Opens contextual options menu for each screen

Arrow/Select Buttons

Channel up/ down, navigate through menus, and select a desired option

Pause/Play

Pauses or plays a live or recorded program

Skip Back/ Back

Press to skip back 10 seconds in a program. Press and hold to reverse the program

Vol and Mute Buttons

Control TV volume

Programming required

Power & TV Power

Left button turns the

receiver on/off

Right button turns the

TV on/off

Number Buttons

Enter a channel number or navigate through menus and program guide

SAT/TV/AUX

Mode indicator lights

up when sending

signals in that mode

Guide

Display current

and future

satellite program

listings

DVR

Displays list

of recorded

programs

Search for

programs

Info/Help

Retrieve info on programs

and set a timer.

Press and hold

for contextual

help

Skip Forward/

Forward

Press to skip

forward

10 seconds in a

program. Press

and hold to

forward through

the program

Channel up/

down, navigate

through menus,

and select a

desired option

Recall

Return to

previously viewed

channel(s)

SAT Mode, continued

To use the features described in this section, make sure you are in SAT mode by pressing the SAT Mode button. Note: Some features may not be available depending on your receiver model.

Press this button for SAT Mode

SAT LED lights up

Input

Swaps the tuner

TV Mode

To use the features described in this section, make sure you are in TV mode by pressing the TV Mode button. Remote programming is required. Note: The remote has Limited Mode enabled, which means only the Volume, Mute, and TV

Power buttons work in TV Mode (see Enabling or Disabling Limited Mode on page 18). Note: Some features may not be

available depending on your TV model.

Press this button for TV Mode

Power & TV Power

Left button turns the

receiver on/off

Right button turns the

TV on/off

TV Menu

Access menu

features

available on

some TVs

Up/Down

Arrow Button

Channel up/ down on the

Select Button

Select a

program or

Input

Switch between TV inputs (available only

for certain makes and models of TVs)

Volume

Control TV

volume

Channel Up/

Down

Channel up/ down on the

Mute

Turn TV

volume on

or off

Number Buttons

Enter a channel

number

DVR Functions

• Displays a list of recorded programs.

• Plays a live or recorded program.

• Pauses a live or recorded program.

• Press SKIP BACK to skip back about

10 seconds in a program. Press and hold SKIP BACK to reverse the program four times as fast as normal play. Press BACK twice to reverse at 15 times normal speed, three times to reverse at 60 times normal speed, and four times to reverse at 300 times normal speed. The onscreen bar shows how far you’ve gone. For a live program, you can only reverse back to the last channel change or back

one hour, whichever occurs rst.

• Press SKIP FWD to skip ahead about

30 seconds in the program. Press and hold SKIP FWD (Forward) to fast-forward through the program four times normal speed. Press FWD twice to forward at 15 times normal speed, three times to forward at 60 times normal speed, and four times to forward at 300 times normal speed. The on-screen bar shows how far you’ve gone. Of course, you cannot forward a live program that has not been broadcast yet.

DVR Functions, continued

• Press PAUSE and then press and hold SKIP BACK to reverse the program in slow motion at 1/4 the speed of normal play. Press BACK again to reverse at normal speed.

• Press PAUSE and then press and hold SKIP FWD to forward the program in slow motion at 1/15 the speed of normal play. Press FWD twice to forward at 1/4 as fast as normal play. Press FWD three times to play the program. Of course, you cannot forward a live program that has not been broadcast yet.

Using Remote Button Shortcuts

In addition to their normal functions, some buttons on your remote control have special shortcut functions. These shortcuts are enabled while navigating the on-screen Electronic Program Guide (EPG) or viewing the scrollable list of events.

Buttons In Guide Display Scroll in Lists

Move 3 hours back

Move 3 hours ahead

24 hours back To beginning of list

24 hours ahead To end of list

By 1 screen

upward

By 1 screen

downward

Programming Remote to Control Another Device

There are three ways that you can program your DISH remote to control another device, such as a TV, DVD, Blu-ray Disc™ (BD) Player, VCR, audio

receiver, or amplier:

• Scanning the Remote Database

(see page 10)

• Entering a Code (see page 13)

• Learning Codes (see page 15)

Use Scanning the Remote Database if you do not know the device code. The receiver scans the database of codes for the particular device and tries

each code. When you nd one that works, you save

that code.

Use Entering a Code when you know the device code.

Use Learning Codes when either your device is not listed under Lookup or when you have scanned the database and none of the codes worked.

Typically, the TV mode button is programmed to a TV and the AUX button to a DVD, BD, VCR, audio

receiver, or amplier. However, each of the Mode

buttons are programmable to whatever device you select.

Each of these procedures is discussed in the following pages.
