Universal Air Tools UT8788DC User Manual

Operator Instructions

Air Pressure

Recommended Working

6.3

bar

90

PSI

Recommended Minimum

n/a

bar

n/a

PSI

Maximum

7.0

bar

100

PSI

Personal Safety Equipment

Use - Safety Glasses

Yes

Use - Safety Gloves
Use - Safety Boots
Use - Breathing Masks

Yes

Use - Ear Protectors

Includes - Foreseen Use, Work Stations, Putting Into Service, Operating,
Dismantling, Assembly and Safety Rules

Important

Read these instructions carefully before installing, operating,
servicing or repairing this tool. Keep these instructions in a safe
accessible place.

Manufacturer/Supplier Product Type

Universal Air Tool Company Limited
Unit 8
Lane End Industrial Park
High Wycombe
Bucks
HP14 3BY

Dual Action Sander ­6”(150mm) Pad

Model No/Nos Serial No

UT8788
UT8788DC

Tel No Fax No[phone] [phone]

RPM

10,000

Cycles Per Min

From 12010000
To 37120000

Product Nett Weight

3.96

1.8

lbs
Kg

Recommended Use Of

Balancer Or Support

No

Foreseen Use of Tool

This tool is designed for the purpose of cleaning or sanding of a variety
of materials typically metal, wood, plastic materials, etc. The dual rotary
orbital action reduces the amount of abrasive grinding marks and
hence is primarily a finishing sanding tool. It can be used with a variety of
grades of 150 mm (6” diameter) abrasive discs which, according to
pad fitted to the tool, can be self adhesive or Velcro attached. If fitted to
the dust collecting system this should always be used. The system may
be integral or required to be fixed to an external vacuum source.
The machine fitted with dust collection should not be used with water.
If use with water is required, water can act as a dust suppressor and the
dust collector would not be required.
Do not use the tool for any other purpose to that for which it has been
designed and use only abrasive discs as described.
Do not modify the tool for any other use or for its use as a sander without
first consulting the manufacturer or his authorised distributor.

Work Stations

The tool should only be used as a hand held
hand operated tool. It is always recommended
that the tool is used when standing on a solid
floor. It can be used in other positions but
before any such use the operator must be in a
secure position having a firm grip and footing
and be aware of the safety rules to be obeyed
when using the sander.

Recommended Hose Bore

Size - Minimum

Ins M/M Ft M

3/8 10 30 10

Noise Level

Sound Pressure Level 93.3 dB(A)

Recommended Max.

Hose Length

Sound Power Level 105.4 dB(A)

Test Method Tested in accordance with BS EN ISO
15744:2008

Vibration Level Normal (a) TBC

Uncertainty (K) TBC

Metres / Sec²
Metres / Sec²

Test Method Tested in accordance with BS EN ISO

28927-3:2009

Putting Into Service

Air Supply

Use a clean lubricated air supply that will give a measured air pressure
at the tool of 90 p.s.i./6.3 bar when the tool is running with the
trigger/lever fully depressed. Use recommended hose size and length.
It is recommended that the tool is connected to the air supply as shown
in figure 1. Do not connect the tool to the air line system without
incorporating an easy to reach and operate air shut off valve. The air
supply should be lubricated. It is strongly recommended that an air filter,
regulator, lubricator (FRL) is used as shown in Figure 1 as this will supply
clean, lubricated air at the correct pressure to the tool. Details of such
equipment can be obtained from your supplier. If such equipment is not
used then the tool should be lubricated by shutting off the air supply to
the tool, depressurising the line by pressing the trigger on the tool.
Disconnect the air line and pour into the intake bushing a teaspoonful
(5ml) of a suitable pneumatic motor lubricating oil preferably
incorporating a rust inhibitor. Reconnect tool to air supply and run tool
slowly for a few seconds to allow air to circulate the oil. If tool is used
frequently lubricate on daily basis and if tool starts to slow or lose power.

Page No 1

It is recommended that the air pressure at the tool whilst the tool is
running is 90 p.s.i./6.3 bar. The tool can run at lower and higher
pressures with the maximum permitted working air pressure of 100
p.s.i./7 bar.

Operating

Select a suitable abrasive disc (see Section "Foreseen use of the tool")
and make sure that it is fixed securely to the tool. Connect to suitable air
supply as recommended. Make sure that the side handle is tightened
securely.
Apply the sander lightly to the work and allow the abrasive disc to cut.
Take great care when sanding around sharp edges and surfaces to
avoid the disc snagging i.e. the disc may be brought to an abrupt stop or
considerably slowed that will cause the tool to kick in the hands.
It is always recommended to use safety glasses and a breathing mask.
The sanding of certain materials may create a hazardous dust which
may require special breathing equipment. Check before using the tool.
Even if the machine has a low noise level the actual sanding process
may cause a noise level such that ear protectors will be required. If there
are sharp areas on the material being sanded safety gloves are
recommended.
Do not continue to use abrasive discs that are worn or clogged. This will
make the sanding process inefficient and the need to apply
unnecessarily high forces to the tool.
Do not use undersized or oversized sanding discs. The disc should be
no more than 1/4" larger in diameter that the pad, and not smaller than
the pad.

Tool Maintenance

It shall be the tool owner’s and/or employer’s responsibility to assure
that tools are maintained in a safe operating condition. Tool
maintenance and repair shall be performed by authorised, trained,
competent personnel. Tools shall be disconnected from their
compressed air supply before repairs are attempted. Repairs shall be
consistent with the manufacturer’s recommended procedures. Tool,
hoses and fittings shall be replaced if unsuitable for safe operation. It
shall be the tool owner’s and/or employer’s responsibility to keep
required rating markings and warnings on the tool in legible condition.

Dismantling & Assembly Instructions

Disconnect tool from air supply.
Remove pad as fitted by gripping drive spindle (39) and for dust control
type remove fasteners/clips fixing dust extractor cone and pipe to main
tool body and handle. Remove dust cone and pipe. Locate an allen key
through the hole in the side of drive housing (32) and remove cap screw
(35) and pull off drive spindle (39) assembly. Unscrew screw (42) from
hex nut (46) and remove flat washer (43), spring washer (44), spacer
(48) and spindle lock (45). Take out retaining ring (41) and spring
washer (40) and from the rear end of orbital hub (36) tap out drive
spindle (39) assembly. Grip drive spindle (39) and unscrew hex bolt
(37) and remove wave washer (37A). Push drive spindle (39) out of
bearing (38). Unscrew 2 off each cap screws (33) and (34) and take off
drive housing (32) and gasket (31). Pull on the end of orbital hub (30) to
pull the motor assembly out of the motor housing (1) and note how the
pin (25) in the side of cylinder (26) locates the motor assembly to the
motor housing (1) via the slot in the front bore of the motor housing (1).
Take off retaining ring (23) and wave washer (49). Hold rear plate (24)
and tap the rear end of rotor shaft (30) to drive the rotor shaft (30)
through the rear plate (24) and bearing (22) assembly. Take off cylinder
(26) and take out 5 off rotor blades (28) from rotor (27) and O-ring (20)
from cylinder (26). Pull off rotor (27) and take out key (29) from rotor
shaft (30). Tap rotor shaft (30) through front plate (24) and bearing (22)
assembly. Drive out 2 off bearings (22) from 2 off end plates (24). Take
off retaining ring (18) and push out regulator valve (19) with 4 off O-rings
(21), unscrew hose adaptor (2) with screen (50). Do not remove the
rubber grip from motor housing (1) unless a replacement is required.
Remove hinge screw (11) and hex nut (9) and take off throttle lever (10).

Unscrew hex nut (14) and take off lock washer (13) and bracket (12).
Unscrew valve body (8) and take out throttle valve spring (3) with valve
stem (5) and take off O-ring (4) from valve stem (5) and O-rings (6) and
(7) from valve body (8). Take off housing cover (47) from motor housing
(1).

Reassembly

Clean all parts and examine for wear and replace any parts with parts
obtained from the manufacturer or an authorised distributor. Coat all
parts with a suitable pneumatic tool lubricating oil and reassemble in the
reverse order. On completing assembly make sure that the lever (10)
and regulator valve (19) operate correctly. Depress lever (10) and pour
into hose adaptor (2) 5ml of a suitable pneumatic tool lubricating oil and
release lever. Connect to a suitable air supply and run tool slowly for 2 to
3 seconds to allow the oil to circulate.

Safety Rules For A Sander

1) Read all the instructions before using this tool. All operators must be
fully trained in its use and aware of these safety rules.

2) Do not exceed the maximum working air pressure.

3) Use personal safety equipment.

4) Use only compressed air at the recommended conditions.

5) If the tool appears to malfunction remove from use immediately and
arrange for service and repair.

6) If the tool is used with a balancer or other support device ensure that
it is fixed securely.

7) Always keep hands away from the working attachment fitted to the
tool.

8) The tool is not electrically insulated. Never use the tool if there is any
chance of it coming into contact with live electricity.

9) Always when using the tool adopt a firm footing and/or position and
grip the tool firmly to be able to counteract any forces or reaction forces
that may be generated whilst using the tool.

10) Use only correct spare parts. Do not improvise or make temporary
repairs.

11) Do not lock, tape, wire, etc. the on/off valve in the run position. The
trigger/lever etc. must always be free to return to the 'off' position when
it is released.

12) Always shut off the air supply to the tool, and depress the
trigger/lever etc. to exhaust air from the feed hose before fitting,
adjusting or removing the working attachment.

13) Check hose and fittings regularly for wear. Replace if necessary. Do
not carry the tool by its hose and ensure the hand is remote from the
on/off control when carrying the tool with the air supply connected.

14) Take care against entanglement of moving parts of the tool with
clothing, ties, hair, cleaning rags, etc. This will cause the body to be
drawn towards the tool and can be very dangerous.

15) It is expected that users will adopt safe working practices and
observe all relevant legal requirements when installing, using or
maintaining the tool.

16) Do not install the tool unless an easily accessible and easily operable
on/off valve is incorporated in the air supply.

17) Take care that the tool exhaust air does not cause a problem or
blows on another person.

18) Never lay a tool down unless the working attachment has stopped
moving.

19) Always check the speed of the attachment is higher than the speed
of the tool.

20) Check speed of tool at regular intervals.

21) Check always that the material to be sanded may not cause a risk by
being sanded, i.e. fire or explosion.

22) If self fixing discs are used, i.e. self adhesive or Velcro, always ensure
the disc is fixed centrally to the pad.

Page No 2
