Super Flux LEDS
MVL-904SG
Description
Package Dimensions
The MVL-904SG , utilizes a new generation of
solid state LED emitters which combine highly
efficient InGaN material with SiC substrate .
The package is water clear type .
Features
l Ultra - brightness
l Low power consumption
l TTL compatible
l Reliable
NOTES:
1.Dimensions are in millimeter(inches).
2.Dimensions without tolerances are nominal.
Unit: mm ( inches )
Absolute Maximum Ratings
Power Dissipation
Continuous Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Solder temperature 1.6 mm from body for 5 seconds at 260
Parameter
Symbol Maximum Rating Unit
P
ad
I
af
V
R
T
opr
T
stg
o
C
150 mW
40 mA
5 V
o
-20
C to +80oC
o
-30
C to +100oC
@ TA=25oC
Unity Opto Technology Co., Ltd.
11/10/2000
MVL-904SG
Optical-Electrical Characteristics
V
Forward Current I
(mA)
° 10° 20°
70°
60°
80°
Parameter Test Conditions Symbol Min . Typ . Max . Unit .
Total Flux
Forward Voltage
Reverse Current
Wavelength
Viewing Angle
IF=40mA
IF=40mA
VR=5V
IF=20mA
IF=20mA
Typical Optical-Electrical Characteristic Curves
I
V
I
λp/λ
2θ
@ TA=25oC
250 580 - mlm
F
R
d
1/2
- 4.0 4.5 V
- - 10
µA
- 502/505 - nm
- 40 - deg.
1
0.5
Relative Intensity
0
455 479 502 525 552
Wavelength (nm)
FIG.1 SPECTRAL DISTRIBUTION
40
30
20
10
Forward Current (mA)
0
0.0 1.0 2.0 3.0 4.0
Forward Voltage (V)
FIG.3 FORWARD CURRENT VS.
FORWARD VOLTAGE
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
Luminous Flux
0.1
0.0
0 10 20 30 40
Forward Current (mA)
FIG.5 RELATIVE RADIANT INTENSITY
VS. FORWARD CURRENT
10
1
0.1
Relative Luminous Intensity
0 20 30 50 70 90
Ambient Temperature (
FIG.2 LUMINOUS INTENSITY VS.
AMBIENT TEMPERATURE
40
F
30
20
10
0
0 20 40 60 80 100
Ambient Temperature TA (
FIG.4 RELATIVE RADIANT INTENSITY
VS. AMBIENT TEMPERATURE
0
1.0
0.9
0.8
Relative Luminous Intensity
0.5 0.3 0.1 0.2 0.4 0.6
FIG.6 RADIATION DIAGRAM
o
C)
o
C)
30°
40°
50°
90°
Unity Opto Technology Co., Ltd.
11/10/2000
